Panasonic ES-8044 User manual

No.1 EN ( 豪州 )
Printed in China
Panasonic Electric Works Wanbao (Guangzhou) Co., Ltd.
Wanbao Base Shiguang Road, Panyu District,
Guangzhou, Guangdong, 511495 CHINA
Operating Instructions
Wet/Dry/Rechargeable Shaver
Model No. ES8044
Before operating this unit, please read these instructions completely.
06-11-21B424166_ES8044_AU_Torisetsu
OPERATINGINSTRUCTION
S

2
status
charge
low
mid
high I
I
OQ
RS
P
J
A
B
M
N
E
C
D
F
G
H
K
L
b
Ic
Ia
T
1
(A) (B)
3
4
5
(a) (b)
2
status
charge
low
mid
high
status
charge
low
mid
high
(A) (B)
3
6
status
charge
low
mid
high
7
8
9
06-11-21B424166_ES8044_AU_Torisetsu

4
10 11
12
a
b
g
c
e
d
f
(A) (B)
13
5
Beforeuse
This Wet/Dry shaver can be used for
wet shaving with shaving lather or for
dry shaving. You can use this water-
tight shaver in the shower and clean
it in water. The following is the sym-
bol of Wet shaver. The symbol means
that hand-held part may be used in
a bath or shower.
Treat yourself to wet lather shaves
for at least three weeks and notice
the difference. Your Panasonic Wet/
Dry shaver requires a little time to get
used to because your skin and beard
need about a month to adjust to any
new shaving method.
Partsidentification
(see fig. 1)
AProtective cap
BSystem outer foil
CSystem outer foil release
buttons
DFoil frame
EInner blades
FFoil frame release buttons
GPivot action selector
HLED display
IBattery capacity monitor
I-a high
I-b mid
I-c low
JCharge status lamp
KOn/Off switch
LFinger rest
MTrimmer
NTrimmer handle
OAdaptor
PPower cord
QCharging stand
RCleaning brush
SSoft case
TOil
READ ALL INSTRUCTIONS BE-
FORE USE.
Charging
Connect the power cord to the
shaver, and plug the adaptor to an
AC outlet. (see fig. 1 (A))
The shaver will be adjusted automati-
cally to voltages between 100-240V
AC.
In some areas, a special plug adap-
tor may be required.
• When charging the shaver for the
first time or when it has not been
in use for more than 6 months, the
charge status lamp may not illumi-
nate for a few minutes after opera-
tion. It will eventually illuminate if
kept connected.
Adequate ambient temperature for
charging is between 15 to 35 °C.
• If it is far below or over the appro-
priate temperature, the charging
time may extend, or the adaptor
may not function.
• In particular, low temperature
may shorten the life span of the
06-11-21B424166_ES8044_AU_Torisetsu

6
re-chargeable battery, In this case,
the charge status lamp blinks
twice in 1 second.
The charge status lamp will glow
when the shaver is being charged.
The battery capacity monitor will all
illuminate and the charge status lamp
will blink after charging is completed
(see fig. 2 (A)).
10 minutes after charging is com-
pleted, the battery capacity monitor
will extinguish and the charge status
lamp will continue to blink (see fig. 2
(B)).
You can fully charge the shaver in
1 hour if the LED display shows “low”
(low).
The battery capacity monitor indi-
cates the charge remaining in the
battery in 3 levels (high/mid/low). The
unit can be used once or twice more
after the “low” (low) starts to blink.
(Differs depending on the use situa-
tion.)
A full charge will supply enough
power for approx. 14 shaves
(3 minutes per shave for a normal
beard).
Before travelling, charge it fully for
1 hour if you will not be taking the
adaptor with you.
In case your shaver is without charge,
you may quick charge it for 1 shave
in about 5 minutes.
Charge with charging
stand
(see fig. 1 (B))
To charge with the charging stand,
connect the power cord to the charg-
ing stand. Place the shaver into the
stand, and plug the adaptor to the
AC outlet.
You can always store your shaver in
the charging stand to maintain full
battery capacity. This shaver cannot
be overcharged.
Using your shaver
Disconnect the power cord from the
shaver, and push the On/Off switch
to turn the shaver on.
Hold the shaver at a right angle (90°)
to your skin (see fig. 3). Start out
shaving by applying gentle pressure
Caution – The system outer foil is
very thin and can be damaged if
handled improperly. Before each
use, always check the foil for dam-
age. To avoid personal injury, do
not use if the foil or other parts of
the shaving head is damaged.
If you push and hold the On/Off
switch for more than 2 seconds, it
will activate the turbo mode for
“sonic” vibration cleaning.
(see “Cleaning your shaver”)
Caution:
Shaving with “sonic” vibration may
damage your skin. Please turn it
off and on again to deactivate the
turbo mode.
Do not place fingers on the On/Off
switch during use.
This may cause the shaver to stop
during use or change it to the
“sonic” vibration cleaning mode.
Place your finger on the finger rest
during use.
7
to your face. Stretch your skin with
your free hand and move the shaver
back and forth in the direction of your
beard. You may gently increase the
amount of pressure as your skin be-
comes accustomed to this shaver.
Applying excessive pressure does
not provide a closer shave.
Pivot action selector
(see fig. 4)
Use the pivot action selector to
choose the shaving mode, “soft”
(soft) and “lock” (lock) based on your
shaving preference.
The pivot action can be changed
whether the switch is turned on or off.
Systemouter foil
(see fig. 5)
System outer foil has a slit blade (a)
between 2 foils (b). They move up
and down independently to follow the
contours of your face.
The slit blade catches and cuts
longer and lying hairs easily.
For wet shaving
Put a thin layer of shaving foam on
your face which works as a lubrica-
tor. Shaving foam is the most suit-
able among many other shaving aids
(gel, soap, cream, etc.). Do not put a
thick layer of shaving foam as it may
affect shaver’s performance. If the
shaving head is clogged with foam,
simply rinse it under running water.
Using the trimmer
(see fig. 6)
Slide the trimmer handle up to open
the trimmer.
Place the trimmer at a right angle to
your skin and move it downward to
trim sideburns.
Cleaning your shaver
(see fig. 7)
For cleanliness and convenience, we
recommend that you clean your
shaver with water and a liquid hand
soap. Regular cleaning will keep your
shaver in good condition while pre-
venting odors or bacteria from devel-
oping, and maintain the cutting per-
formance.
With the system outer foil in place,
apply some hand soap onto the outer
foil.
Push and hold the On/Off switch
more than 2 seconds to activate the
turbo mode for “sonic” vibration
cleaning.
At the same time, the lamps of the
Battery capacity monitor will flash
around randomly.
Pour some water over the outer foil.
After about 20 seconds, it will be
automatically turned off, or you can
turn it off by pushing the On/Off
switch.
Remove the foil frame and push the
On/Off switch more than 2 seconds
to activate the turbo mode for “sonic”
vibration cleaning and clean it with-
running water.
Wipe off any moisture from the
shaver with a dry cloth and dry it with-
out the foil frame.
Warning – To prevent electric
shock or personal injury, discon-
nect the power cord from the
shaver before cleaning with water.
06-11-21B424166_ES8044_AU_Torisetsu

8
Lubrication
(see fig. 13)
To maintain shaving comfort for a
long time, it is recommended that
the oil provided with the shaver is
used.
1. Switch off the shaver.
2. Apply one drop of oil to each of
the outer foils.
3. Raise the trimmer and apply a
drop of oil.
4. Switch the shaver on, and run it
for approximately five seconds.
5. Switch off the shaver, and wipe
off any excess oil from the outer
foils with a soft cloth.
Brush cleaning
Squeeze the foil frame release but-
tons and lift the foil frame upward to
remove it (see fig. 9). Remove the in-
ner blades one at a time by grasping
it firmly at both ends and pulling it
straight away from the shaver. Clean
the outer foils, the shaver body and
the trimmer with the long brush (see
fig. 10). Clean the inner blades with
the short brush by moving it in the
direction in fig. 11 (A). Do not move
the brush in the direction in fig. 11
(B), as it will damage the inner blade,
and its cutting performance. Do not
use the short brush to clean the outer
foils.
Replacing shaving head
components
It is recommended that you replace
the system outer foil at least once a
year and the inner blade at least once
every 2 years to maintain your shav-
er’s cutting performance.
Replacing the system outer foil
(see fig. 8)
Squeeze the system outer foil re-
lease buttons and lift the system
outer foil upward to remove it. To in-
sert the new system outer foil, press
down until it snaps into place.
Replacing the inner blades
(see fig. 9)
Squeeze the foil frame release but-
tons and lift the foil frame upward to
remove it. Remove the inner blade
one at a time by grasping it firmly at
both ends and pulling straight away
from the shaver.
Do not touch the metal parts of inner
blades.
To insert the new inner blade, hold
the blade one at a time at both ends
and press downward until it snaps
into the shaver.
For environmental protec-
tionand recycling of
materials
This shaver contains a Litium-ion
battery.
Please make sure that the battery is
disposed of at an officially assigned
location, if there is one in your country.
How to remove the built-in
rechargeable battery before
disposal of the shaver
(see fig. 12)
WARNING:
Do not attempt to replace the bat-
tery for the purpose of reusing the
shaver. This could result in the risk
of fire or electric shock.
9
The battery in this shaver is not in-
tended to be replaced by consum-
ers. However, the battery may be re-
placed at an authorized service
center. The procedure described be-
low is intended only for removal of
the rechargeable battery for the pur-
pose of proper disposal.
1. Disconnect the power cord from
the shaver when removing the
battery.
2. Remove the bottom cover screw
(a).
3. Remove the bottom cover (b).
4. Slide the back panel (c) and re-
move it.
5. Remove the housing clips (d).
6. Remove the four housing screws
(e).
7. Remove the housing B (f).
8. Lift the battery (g) and remove it.
Caution
• Do not charge the shaver, where
it will be exposed to direct sunlight
or a heat source, or where there is
a lot of moisture.
• Use only the included adaptor
RE7-27 to charge the shaver.
• Dry the shaver completely before
charging it.
• The shaver and adaptor will be-
come slightly hot during use or
charging, however this is not a
malfunction.
• Keep the adaptor away from water
and handle it only with dry hands.
• Grip the adaptor when disconnect-
ing it from an AC outlet; tugging on
the power cord may damage it.
• Store the adaptor in a dry area
where it will be protected from dam-
age.
• Do not pull, twist, or severely bend
the power cord.
• Do not wrap the power cord tightly
around the appliance.
• If the power cord gets damaged, it
alone can not be replaced.
Contact an authorized service
center.
• In cases where static noise is emit-
ted from the television during use
or recharging, connect the adap-
tor to a different outlet.
• Do not touch the edge (metal part)
of the inner blade.
Failure to observe this may lead to
hand injuries.
• Wash the shaver in tap water. Do
not use salt water or boiling water.
Also, do not use cleaning products
that are designed for toilets, bath-
rooms or kitchen appliances. Do
not submerge the shaver for a long
time.
• Do not wipe any part of the shaver
with thinner, benzine or alcohol.
Clean it by using a cloth dampened
with soapy water.
• Do not take the housing apart as
this can affect the watertight con-
struction.
• Do not clean with water when the
shaver is connected to the power
cord.
• When cleaning the shaver with
water, do so with both the inner
blades attached. (Doing so with
only one of the inner blades at-
tached makes an abnormal noise
and may damage the shaver.)
• Keep the unit away from children.
• Keep instructions in a safe place.
• This applianse is not intended for
06-11-21B424166_ES8044_AU_Torisetsu

10
use by young children or infirm
persons unless they have been
adequately supervised by a
responsible person to ensure that
they can use the appliance safely.
• Young children should be super-
vised to ensure that they do not
play with the appliance.
This product is intended for house-
hold use only.
06-11-21B424166_ES8044_AU_Torisetsu
