Panasonic KX-FT33 Series User manual

©2000 Kyushu Matsushita Electric Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
KX-FT33 Series
KX-FT35 Series
KX-FT37 Series
KX-FT42BX
KX-FT46BX
Personal Facsimile/Telephone Answering System With Facsimile
Subject : Parts Change
Please file and use this supplement manual together with the original and simplified service manuals for
the following models.
ORDER NO. KMF0002193S0

1 REPLACEMENT PARTS LISTS
1.1. REFERENCE CHART
Reason for Change
*The following items (1-8) indicate the reason for change. See the “Notes” column for each part in 1.2. ORIGINAL AND NEW PARTS
COMPARISON LIST(S).
1. Improve performance Remarks:
2. Change of material or dimension *a: To improve the electric conduction.
3. To meel approved specification *b: For prevention of static electricity.
4. Standardization *c: To facilitate the production process.
5. Addition *d: To share the part with other models.
6. Deletion *e: To modify the parameter for inspection on the production line.
7. Correction *f: To improve cutter’s performance
8. Other *g: The factory for production is transferred from Japan to China. (The place of production described
in the name plate is changed from “Made in Japan” to “Made in China”.)
Interchangeability Code
**The following items (V-Z) indicate the interchangeability. See the “Notes” column for each part in 1.2. ORIGINAL AND NEW PARTS
COMPARISON LIST(S).
Parts Set Production
VOriginal
New Early (before change) Late (after change) Original or new parts may be used in early or late production set. Use original parts until exhausted, then stock new parts.
WOriginal
New Early (before change) Late (after change) Original parts may be used in early production sets only. New parts may be used in early or late production sets. Use original parts where possible, then stock new parts.
XOriginal
New Early (before change) Late (after change) New parts only may be used in early or late production sets. Stock new parts.
YOriginal
New Early (before change) Late (after change) Original parts may be used in early production sets only. New parts may be used in late production sets only. Stock both original and new parts.
ZOther
Note:
Alphabets in the “Remarks” column in the following lists correspond to the alphabets in the “Remarks”in1.1. REFERENCE
CHART.
1.2. ORIGINAL AND NEW PARTS COMPARISON LIST(S)
1.2.1. KX-FT33YG
Ref No. Part No. Part Name & Descriptions Pcs/
Set Remarks Notes
Original Part No. New Part No.
CABINET AND ELECTRICAL SECTION
25 PFUS1095Z PFUS1095X OPEN EARTH 1*a 1 W
37 PFMH1046Z PFMH1046Y SHADING PLATE 1*b 1 W
93 PFDX1010Z PFDX1010Y CUTTER 1*d 4 V
97 --------------------------- PFHE1024Z SPACER, CUTTER (See 2.1. UPPER
CABINET SECTION.) 1*f 1 Y
104 PFAS50PTC01Y PFWE1FT31BX SPEAKER ASS’Y (See 2.2. LOWER
CABINET / P.C.B. SECTION.) 1*d 4 Y
104-1 --------------------------- PFUS1165Z SPRING, SPEAKER 1*d 4 Y
106 PFUS1089Z --------------------------- 0Deleted
108 PFMD1024Z PFMD1024Y FRAME, BOTTOM 1*d 1 V
156 --------------------------- PFHX1031Z SHEET, BRAKE (See 2.3. MOTOR
SECTION.) 1*f 1 Y
ACCESSORIES AND PACKING MATERIALS
P1 PFPK1450Z PFPK1484Z-J GIFT BOX 1*g 8 Y
FIXTURES AND TOOLS
EC5 PQZZ2K6Z PFZZ12K1Z CONNECTOR, 12PINS 1-------- 7---
EC9 PFZZ12K1Z PQZZ12K4Z CONNECTOR, 12PINS 1-------- 7---
2
KX-FT33 Series / KX-FT35 Series / KX-FT37 Series / KX-FT42BX / KX-FT46BX

1.2.2. KX-FT33YG-W
Ref No. Part No. Part Name & Descriptions Pcs/
Set Remarks Notes
Original Part No. New Part No.
CABINET AND ELECTRICAL SECTION
25 PFUS1095Z PFUS1095X OPEN EARTH 1*a 1 W
97 --------------------------- PFHE1024Z SPACER, CUTTER (See 2.1. UPPER
CABINET SECTION.) 1*f 1 Y
156 --------------------------- PFHX1031Z SHEET, BRAKE (See 2.3. MOTOR
SECTION.) 1*f 1 Y
FIXTURES AND TOOLS
EC5 PQZZ2K6Z PFZZ12K1Z CONNECTOR, 12PINS 1-------- 7---
EC9 PFZZ12K1Z PQZZ12K4Z CONNECTOR, 12PINS 1-------- 7---
1.2.3. KX-FT35CE/KX-FT37CE
Ref No. Part No. Part Name & Descriptions Pcs/
Set Remarks Notes
Original Part No. New Part No.
CABINET AND ELECTRICAL SECTION
25 PFUS1095Z PFUS1095X OPEN EARTH 1*a 1 W
37 PFMH1046Z PFMH1046Y SHADING PLATE 1*b 1 W
99 --------------------------- PFHE1024Z SPACER, CUTTER (See 2.1. UPPER
CABINET SECTION.) [KX-FT37CE only] 1*f 1 Y
156 --------------------------- PFHX1031Z SHEET, BRAKE (See 2.3. MOTOR
SECTION.) [KX-FT37CE only] 1*f 1 Y
FIXTURES AND TOOLS
EC5 PQZZ2K6Z PFZZ12K1Z CONNECTOR, 12PINS 1-------- 7---
EC9 PFZZ12K1Z PQZZ12K4Z CONNECTOR, 12PINS 1-------- 7---
1.2.4. KX-FT35HG/KX-FT37HG
Ref No. Part No. Part Name & Descriptions Pcs/
Set Remarks Notes
Original Part No. New Part No.
CABINET AND ELECTRICAL SECTION
25 PFUS1095Z PFUS1095X OPEN EARTH 1*a 1 W
37 PFMH1046Z PFMH1046Y SHADING PLATE 1*b 1 W
99 --------------------------- PFHE1024Z SPACER, CUTTER (See 2.1. UPPER
CABINET SECTION.) [KX-FT37HG only] 1*f 1 Y
104 PFAS50PTC01Y PFWE1FT31BX SPEAKER ASS’Y (See 2.2. LOWER
CABINET / P.C.B. SECTION.) 1*d 4 Y
104-1 --------------------------- PFUS1165Z SPRING, SPEAKER 1*d 4 Y
106 PFUS1089Z --------------------------- 0Deleted
108 PFMD1024Z PFMD1024Y FRAME, BOTTOM 1*d 1 V
156 --------------------------- PFHX1031Z SHEET, BRAKE (See 2.3. MOTOR
SECTION.) [KX-FT37HG only] 1*f 1 Y
FIXTURES AND TOOLS
EC5 PQZZ2K6Z PFZZ12K1Z CONNECTOR, 12PINS 1-------- 7---
EC9 PFZZ12K1Z PQZZ12K4Z CONNECTOR, 12PINS 1-------- 7---
3
KX-FT33 Series / KX-FT35 Series / KX-FT37 Series / KX-FT42BX / KX-FT46BX

1.2.5. KX-FT35PD/KX-FT37PD
Ref No. Part No. Part Name & Descriptions Pcs/
Set Remarks Notes
Original Part No. New Part No.
CABINET AND ELECTRICAL SECTION
25 PFUS1095Z PFUS1095X OPEN EARTH 1*a 1 W
37 PFMH1046Z PFMH1046Y SHADING PLATE 1*b 1 W
93 PFDX1010Z PFDX1010Y CUTTER 1*d 4 V
99 --------------------------- PFHE1024Z SPACER, CUTTER (See 2.1. UPPER
CABINET SECTION.) [KX-FT37PD only] 1*f 1 Y
104 PFAS50PTC01Y PFWE1FT31BX SPEAKER ASS’Y (See 2.2. LOWER
CABINET / P.C.B. SECTION.) 1*d 4 Y
104-1 --------------------------- PFUS1165Z SPRING, SPEAKER 1*d 4 Y
106 PFUS1089Z --------------------------- 0Deleted
108 PFMD1024Z PFMD1024Y FRAME, BOTTOM 1*d 1 V
156 --------------------------- PFHX1031Z SHEET, BRAKE (See 2.3. MOTOR
SECTION.) [KX-FT37PD only] 1*f 1 Y
DIGITAL BOARD PARTS
IC2 PFWIFT35PD PFWIFT35PD1 IC (ROM) 1*e 1 W
IC2 PFWIFT37PD PFWIFT37PD1 IC (ROM) 1*e 1 W
FIXTURES AND TOOLS
EC5 PQZZ2K6Z PFZZ12K1Z CONNECTOR, 12PINS 1-------- 7---
EC9 PFZZ12K1Z PQZZ12K4Z CONNECTOR, 12PINS 1-------- 7---
1.2.6. KX-FT35YG/KX-FT37YG
Ref No. Part No. Part Name & Descriptions Pcs/
Set Remarks Notes
Original Part No. New Part No.
CABINET AND ELECTRICAL SECTION
25 PFUS1095Z PFUS1095X OPEN EARTH 1*a 1 W
37 PFMH1046Z PFMH1046Y SHADING PLATE 1*b 1 W
93 PFDX1010Z PFDX1010Y CUTTER 1*d 4 V
99 --------------------------- PFHE1024Z SPACER, CUTTER (See 2.1. UPPER
CABINET SECTION.) [KX-FT37YG only] 1*f 1 Y
104 PFAS50PTC01Y PFWE1FT31BX SPEAKER ASS’Y (See 2.2. LOWER
CABINET / P.C.B. SECTION.) 1*d 4 Y
104-1 --------------------------- PFUS1165Z SPRING, SPEAKER 1*d 4 Y
106 PFUS1089Z --------------------------- 0Deleted
108 PFMD1024Z PFMD1024Y FRAME, BOTTOM 1*d 1 V
156 --------------------------- PFHX1031Z SHEET, BRAKE (See 2.3. MOTOR
SECTION.) [KX-FT37YG only] 1*f 1 Y
ACCESSORIES AND PACKING MATERIALS
P1 PFPK1421Z-J PFPK1485Z-J GIFT BOX (KX-FT35YG) 1*g 8 Y
P1 PFPK1422Z-J PFPK1486Z-J GIFT BOX (KX-FT37YG) 1*g 8 Y
FIXTURES AND TOOLS
EC5 PQZZ2K6Z PFZZ12K1Z CONNECTOR, 12PINS 1-------- 7---
EC9 PFZZ12K1Z PQZZ12K4Z CONNECTOR, 12PINS 1-------- 7---
1.2.7. KX-FT37YG-W
Ref No. Part No. Part Name & Descriptions Pcs/
Set Remarks Notes
Original Part No. New Part No.
CABINET AND ELECTRICAL SECTION
25 PFUS1095Z PFUS1095X OPEN EARTH 1*a 1 W
99 --------------------------- PFHE1024Z SPACER, CUTTER (See 2.1. UPPER
CABINET SECTION.) 1*f 1 Y
156 --------------------------- PFHX1031Z SHEET, BRAKE (See 2.3. MOTOR
SECTION.) 1*f 1 Y
FIXTURES AND TOOLS
EC5 PQZZ2K6Z PFZZ12K1Z CONNECTOR, 12PINS 1-------- 7---
EC9 PFZZ12K1Z PQZZ12K4Z CONNECTOR, 12PINS 1-------- 7---
4
KX-FT33 Series / KX-FT35 Series / KX-FT37 Series / KX-FT42BX / KX-FT46BX

1.2.8. KX-FT42BX
Ref No. Part No. Part Name & Descriptions Pcs/
Set Remarks Notes
Original Part No. New Part No.
CABINET AND ELECTRICAL SECTION
97 --------------------------- PFHE1024Z SPACER, CUTTER (See 2.1. UPPER
CABINET SECTION.) 1*f 1 Y
156 --------------------------- PFHX1031Z SHEET, BRAKE (See 2.3. MOTOR
SECTION.) 1*f 1 Y
FIXTURES AND TOOLS
EC5 PQZZ2K6Z PFZZ12K1Z CONNECTOR, 12PINS 1-------- 7---
EC9 PFZZ12K1Z PQZZ12K4Z CONNECTOR, 12PINS 1-------- 7---
1.2.9. KX-FT46BX
Ref No. Part No. Part Name & Descriptions Pcs/
Set Remarks Notes
Original Part No. New Part No.
CABINET AND ELECTRICAL SECTION
99 --------------------------- PFHE1024Z SPACER, CUTTER (See 2.1. UPPER
CABINET SECTION.) 1*f 1 Y
156 --------------------------- PFHX1031Z SHEET, BRAKE (See 2.3. MOTOR
SECTION.) 1*f 1 Y
DIGITAL BOARD PARTS
IC2 PFWIFT46BX PFWIFT46BX1 IC (ROM) 1*e 1 W
FIXTURES AND TOOLS
EC5 PQZZ2K6Z PFZZ12K1Z CONNECTOR, 12PINS 1-------- 7---
EC9 PFZZ12K1Z PQZZ12K4Z CONNECTOR, 12PINS 1-------- 7---
5
KX-FT33 Series / KX-FT35 Series / KX-FT37 Series / KX-FT42BX / KX-FT46BX

2 CABINET, MECHANICAL AND ELECTRICAL PARTS
LOCATION
2.1. UPPER CABINET SECTION
Models:
KX-FT33YG, KX-FT33YG-W, KX-FT37CE, KX-FT37HG, KX-FT37PD, KX-FT37YG, KX-FT37YG-W, KX-FT42BX, KX-FT46BX
2.2. LOWER CABINET / P.C.B. SECTION
6
KX-FT33 Series / KX-FT35 Series / KX-FT37 Series / KX-FT42BX / KX-FT46BX

2.3. MOTOR SECTION
Models:
For the models with cutter only
7
KX-FT33 Series / KX-FT35 Series / KX-FT37 Series / KX-FT42BX / KX-FT46BX
