Panasonic TC-P65V10 User manual

© Panasonic Corporation 2009.
Unauthorized copying and distribution is a violation
of law.
ORDER NO.MTNC090753CE
B34 Canada: B07
65 inch Class 1080p Plasma HDTV
Model No. TC-P65V10
GPF12DU Chassis

2
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions -----------------------------------------------3
1.1. General Guidelines ----------------------------------------3
2 Warning --------------------------------------------------------------4
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatically Sensitive (ES) Devices ----------4
2.2. About lead free solder (PbF) ----------------------------5
3 Service Navigation------------------------------------------------6
3.1. Service Hint--------------------------------------------------6
3.2. Applicable signals ------------------------------------------7
4 Specifications ------------------------------------------------------8
5 Service Mode -------------------------------------------------------9
5.1. How to enter into Service Mode ------------------------9
5.2. Service tool mode ---------------------------------------- 11
5.3. Hotel mode------------------------------------------------- 12
6 Troubleshooting Guide---------------------------------------- 13
6.1. Check of the IIC bus lines------------------------------ 13
6.2. Power LED Blinking timing chart --------------------- 14
6.3. No Power--------------------------------------------------- 15
6.4. No Picture -------------------------------------------------- 16
6.5. Local screen failure -------------------------------------- 17
7 Service Fixture & Tools --------------------------------------- 18
7.1. SC jig -------------------------------------------------------- 18
8 Disassembly and Assembly Instructions --------------- 19
8.1. Remove the Rear cover -------------------------------- 19
8.2. Remove the Fan------------------------------------------ 19
8.3. Remove the P-Board ------------------------------------ 19
8.4. Remove the Side terminal cover and Rear
terminal cover --------------------------------------------- 19
8.5. Remove the Tuner unit --------------------------------- 20
8.6. Remove the A-Board ------------------------------------ 20
8.7. Remove the Speakers ---------------------------------- 21
8.8. Remove the Control button unit ---------------------- 21
8.9. Remove the GK-Board --------------------------------- 21
8.10. Remove the SU-Board---------------------------------- 21
8.11. Remove the SD-Board---------------------------------- 22
8.12. Remove the SC-Board---------------------------------- 22
8.13. Remove the SS2-Board -------------------------------- 22
8.14. Remove the SS3-Board -------------------------------- 23
8.15. Remove the SS-Board ---------------------------------- 23
8.16. Remove the Support metal (C) ----------------------- 23
8.17. Remove the Support metals (L, R) ------------------ 23
8.18. Remove the Vertical bar-down assy----------------- 24
8.19. Remove the C1-Board ---------------------------------- 24
8.20. Remove the C2-Board ---------------------------------- 24
8.21. Remove the C3-Board ---------------------------------- 25
8.22. Remove the Plasma panel section from the
Cabinet assy (glass)------------------------------------- 25
8.23. Remove the Glass holders ---------------------------- 25
8.24. Remove the Rear cover fix holders------------------ 26
8.25. Remove the S-Board ------------------------------------ 26
8.26. Remove the K-Board ------------------------------------ 27
8.27. Remove the GL-Board ---------------------------------- 27
8.28. Replace the plasma panel ----------------------------- 27
9 Measurements and Adjustments -------------------------- 28
9.1. Adjustment Procedure ---------------------------------- 28
9.2. Adjustment ------------------------------------------------- 31
10 Block Diagram --------------------------------------------------- 33
10.1. Main Block Diagram ------------------------------------- 33
10.2. Block (1/4) Diagram ------------------------------------- 34
10.3. Block (2/4) Diagram ------------------------------------- 35
10.4. Block (3/4) Diagram ------------------------------------- 36
10.5. Block (4/4) Diagram ------------------------------------- 37
11 Wiring Connection Diagram--------------------------------- 39
11.1. Caution statement.--------------------------------------- 39
11.2. Wiring (1) -------------------------------------------------- 39
11.3. Wiring (2) -------------------------------------------------- 40
11.4. Wiring (3) -------------------------------------------------- 41
11.5. Wiring (4) -------------------------------------------------- 42
12 Schematic Diagram -------------------------------------------- 43
12.1. Schematic Diagram Note ------------------------------ 43
12.2. P(MULTI)-Board Schematic Diagram--------------- 44
12.3. P(SUS)-Board Schematic Diagram ----------------- 45
12.4. GK, GL, K and S-Board Schematic Diagram ----- 46
12.5. A-Board (1/22) Schematic Diagram----------------- 47
12.6. A-Board (2/22) Schematic Diagram----------------- 48
12.7. A-Board (3/22) Schematic Diagram----------------- 49
12.8. A-Board (4/22) Schematic Diagram----------------- 50
12.9. A-Board (5/22) Schematic Diagram----------------- 51
12.10. A-Board (6/22) Schematic Diagram----------------- 52
12.11. A-Board (7/22) Schematic Diagram----------------- 53
12.12. A-Board (8/22) Schematic Diagram----------------- 54
12.13. A-Board (9/22) Schematic Diagram----------------- 55
12.14. A-Board (10/22) Schematic Diagram --------------- 56
12.15. A-Board (11/22) Schematic Diagram --------------- 57
12.16. A-Board (12/22) Schematic Diagram --------------- 58
12.17. A-Board (13/22) Schematic Diagram --------------- 59
12.18. A-Board (14/22) Schematic Diagram --------------- 60
12.19. A-Board (15/22) Schematic Diagram --------------- 61
12.20. A-Board (16/22) Schematic Diagram --------------- 62
12.21. A-Board (17/22) Schematic Diagram --------------- 63
12.22. A-Board (18/22) Schematic Diagram --------------- 64
12.23. A-Board (19/22) Schematic Diagram --------------- 65
12.24. A-Board (20/22) Schematic Diagram --------------- 66
12.25. A-Board (21/22) Schematic Diagram --------------- 67
12.26. A-Board (22/22) Schematic Diagram --------------- 68
12.27. C1-Board (1/2) Schematic Diagram ---------------- 69
12.28. C1-Board (2/2) Schematic Diagram ---------------- 70
12.29. C2-Board (1/2) Schematic Diagram ---------------- 71
12.30. C2-Board (2/2) Schematic Diagram ---------------- 72
12.31. C3-Board (1/2) Schematic Diagram ---------------- 73
12.32. C3-Board (2/2) Schematic Diagram ---------------- 74
12.33. SC-Board (1/4) Schematic Diagram ---------------- 75
12.34. SC-Board (2/4) Schematic Diagram ---------------- 76
12.35. SC-Board (3/4) Schematic Diagram ---------------- 77
12.36. SC-Board (4/4) Schematic Diagram ---------------- 78
12.37. SS-Board (1/2) Schematic Diagram ---------------- 79
12.38. SS-Board (2/2), SS2-Board and SS3-Board
Schematic Diagram ------------------------------------- 80
13 Printed Circuit Board------------------------------------------ 81
13.1. P(MULTI)-Board------------------------------------------ 81
13.2. P(SUS)-Board -------------------------------------------- 84
13.3. GK, K and S-Board-------------------------------------- 86
13.4. GL-Board -------------------------------------------------- 87
13.5. A-Board ---------------------------------------------------- 88
13.6. C1-Board--------------------------------------------------- 90
13.7. C2-Board--------------------------------------------------- 91
13.8. C3-Board--------------------------------------------------- 92
13.9. SC-Board -------------------------------------------------- 93
13.10. SS-Board -------------------------------------------------- 95
13.11. SS2 and SS3-Board ------------------------------------ 97
14 Exploded View and Replacement Parts List----------- 99
14.1. Exploded View and Mechanical Replacement
Parts List --------------------------------------------------- 99
14.2. Electrical Replacement Parts List ------------------ 105

3
1 Safety Precautions
1.1. General Guidelines
1. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials.
2. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the
wires have been broken or disconnected, do not attempt to repair or re-wire the units. Replace the entire wiring unit instead.
3. When conducting repairs and servicing, do not twist the Faston connectors but plug them straight in or unplug them straight
out.
4. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
5. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
6. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
1.1.1. Leakage Current Cold Check
1. Unplug the AC cord and connect a jumper between the
two prongs on the plug.
2. Measure the resistance value, with an ohmmeter,
between the jumpered AC plug and each exposed metal-
lic cabinet part on the equipment such as screwheads,
connectors, control shafts, etc. When the exposed metal-
lic part has a return path to the chassis, the reading
should be between 1Mohm and 5.2Mohm.
When the exposed metal does not have a return path to
the chassis, the reading must be .
1.1.2. Leakage Current Hot Check (See
Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use
an isolation transformer for this check.
2. Connect a 1.5kohm, 10 watts resistor, in parallel with a
0.15μF capacitors, between each exposed metallic part
on the set and a good earth ground such as a water pipe,
as shown in Figure 1.
3. Use an AC voltmeter, with 1000 ohms/volt or more sensi-
tivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the volt-
age at each point.
5. Reverse the AC plug in the AC outlet and repeat each of
the above measurements.
6. The potential at any point should not exceed 0.75 volts
RMS. A leakage current tester (Simpson Model 229 or
equivalent) may be used to make the hot checks, leakage
current must not exceed 1/2 milliamp. In case a measure-
ment is outside of the limits specified, there is a possibility
of a shock hazard, and the equipment should be repaired
and rechecked before it is returned to the customer.
Figure 1

4
2 Warning
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically
Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec-
trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and
semiconductor [chip] components. The following techniques should be used to help reduce the incidence of component damage
caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as alumi-
num foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as [anti-static (ESD protected)] can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or compara-
ble conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise ham less motion such as the brush-
ing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient
to damage an ES device).

5
2.2. About lead free solder (PbF)
Note: Lead is listed as (Pb) in the periodic table of elements.
In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.
The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For service and repair work, we’d
suggest the use of Pb free solder as well, although Pb solder may be used.
PCBs manufactured using lead free solder will have the PbF within a leaf Symbol PbF stamped on the back of PCB.
Caution
• Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40 °C) higher. Please
use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).
• Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).
If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before applying Pb sol-
der. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.
• After applying PbF solder to double layered boards, please check the component side for excess solder which may flow onto the
opposite side. (see figure below)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder. How-
ever, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used.

6
3 Service Navigation
3.1. Service Hint
Board Name Function Board Name Function
P Power Supply C1 Data Driver (Lower Right)
A DC-DC Converter, Tuner
Speaker out, AV Terminal, AV Switch, PC
Digital Signal Processor, SYSTEM MPU, HDMI Switch
Peaks-AVC, Ethernet
Format Converter, Plasma AI, Sub-Field Processor
C2 Data Driver (Lower Center)
C3 Data Driver (Lower Left)
SC Scan Drive
SS Sustain Drive
SS2 Sustain out (Upper)
K Remote receiver, Power LED, C.A.T.S sensor SS3 Sustain out (Lower)
S Power Switch SU Scan out (Upper)
Non-serviceable.
SU-Board should be exchanged for service.
GK Key Switch
GL SD blue LED
SD Scan out (Lower)
Non-serviceable.
SD-Board should be exchanged for service.

7
3.2. Applicable signals
* Mark: Applicable input signal for Component (Y, PB, PR), HDMI and PC
Note
• Signals other than above may not be displayed properly.
• The above signals are reformatted for optimal viewing on your display.
horizontal frequency (kHz) vertical frequency (Hz) COMPONENT HDMI PC
525 (480) / 60i 15.73 59.94 * *
525 (480) /60p 31.47 59.94 * *
750 (720) /60p 45.00 59.94 * *
1,125 (1,080) /60i 33.75 59.94 * *
1,125 (1,080) /60p 67.43 59.94 *
1,125 (1,080) /60p 67.50 60.00 *
1,125 (1,080) /24p 26.97 23.98 *
1,125 (1,080) /24p 27.00 24.00 *
640 ×400 @70 31.47 70.08 *
640 ×480 @60 31.47 59.94 *
Macintosh13 inch (640 ×480) 35.00 66.67 *
640 ×480 @75 37.50 75.00 *
852 ×480 @60 31.47 59.94 *
800 ×600 @60 37.88 60.32 *
800 ×600 @75 46.88 75.00 *
800 ×600 @85 53.67 85.08 *
Macintosh16 inch (832 ×624) 49.73 74.55 *
1,024 ×768 @60 48.36 60.00 *
1,024 ×768 @70 56.48 70.07 *
1,024 ×768 @75 60.02 75.03 *
1,024 ×768 @85 68.68 85.00 *
Macintosh 21 inch (1,152 ×870) 68.68 75.06 *
1,280 ×1,024 @60 63.98 60.02 *
1,366 ×768 @60 48.36 60.00 *

8
4 Specifications
Power Source AC 120 V, 60 Hz
Power Consumption
Maximum 729 W
Standby condition 0.2 W
Plasma Display panel
Drive method AC type
Aspect Ratio 16:9
Visible screen size 65 inch class (64.7 inches measured diagonally)
(W ×H ×Diagonal) 56.4 inch ×31.7 inch ×64.7 inch (1,434 mm ×806 mm ×1,645 mm)
(No. of pixels) 2,073,600 (1,920 (W) ×1,080 (H))[5,760 ×1,080 dots]
Sound
Audio Output 20 W [ 10 W + 10 W ] ( 10 % THD )
PC signals VGA, SVGA, XGA, WXGA, SXGA
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Channel Capability (Digital/Analog) VHF/ UHF: 2 - 69, CATV: 1 - 135
Operating Conditions
Temperature: 32 °F - 104 °F (0 °C - 40 °C)
Humidity: 20 % - 80 % RH (non-condensing)
Connection Terminals
VIDEO IN 1 VIDEO: RCA PIN Type ×1 1.0 V [p-p] (75 Ω)
S-VIDEO: Mini DIN 4-pin Y: 1.0 V [p-p] (75 Ω) C: 0.286 V [p-p] (75 Ω)
AUDIO L-R: RCA PIN Type ×2 0.5 V [rms]
VIDEO IN 2 VIDEO: RCA PIN Type ×1 1.0 V [p-p] (75 Ω)
AUDIO L-R: RCA PIN Type ×2 0.5 V [rms]
COMPONENT INPUT 1-2 Y: 1.0 V [p-p] (including synchronization)
PB, PR: ±0.35 V [p-p]
AUDIO L-R: RCA PIN Type ×2 0.5 V [rms]
HDMI 1-4 TYPE A Connector ×4
This TV supports [HDAVI Control 4] function.
RS232C (Serial) D-sub 9pin for external control
PC D-SUB 15PIN: R,G,B / 0.7 V [p-p] (75 Ω)
HD, VD / 1.0 - 5.0 V [p-p] (high impedance)
LAN (for VIERA CAST IPTV) RJ45 (10BASE-T/100BASE-TX)
Card slot SD CARD slot ×1
AUDIO OUT AUDIO L-R: RCA PIN Type ×2 0.5 V [rms]
DIGITAL AUDIO OUT PCM / Dolby Digital, Fiber Optic
FEATURES 3D Y/C FILTER CLOSED CAPTION
V-Chip IPTV (VIERA CAST)
Photo Viewer Movie player
HDAVI Control 4
Dimensions (W ×H ×D)
Including pedestal 61.9 inch ×40.0 inch ×16.4 inch (1,572 mm ×1,016 mm ×415 mm)
TV Set only 61.9 inch ×38.0 inch ×2.7 inch (3.9 inch) (1,572 mm ×964 mm ×68 mm (97 mm))
Mass
Including pedestal 147.8 lb. (67.0 kg)
TV Set only 134.5 lb. (61.0 kg)
Note
• Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.

9
5 Service Mode
5.1. How to enter into Service Mode
While pressing [VOLUME ( - )] button of the main unit, press [INFO] button of the remote control three times within 2 seconds.
5.1.1. Key command
[1] button...Main items Selection in forward direction
[2] button...Main items Selection in reverse direction
[3] button...Sub items Selection in forward direction
[4] button...Sub items Selection in reverse direction
[VOL] button...Value of sub items change in forward direction ( + ), in reverse direction ( - )

10
5.1.2. Contents of adjustment mode
• Value is shown as a hexadecimal number.
• Preset value differs depending on models.
• After entering the adjustment mode, take note of the value in each item before starting adjustment.
5.1.3. How to exit
Switch off the power with the [POWER] button on the main unit or the [POWER] button on the remote control.
Main item Sub item Sample Data Remark
ADJUST CONTRAST 46
COLOR 00
TINT 00
SUB-BRT 000
WB-ADJ R-CUT 80
G-CUT 80
B-CUT 80
R-DRV FC
G-DRV FF
B-DRV E8
ALL-CUT 80
ALL-DRV FC
OPTION BOOT ROM Factory Preset
STBY-SET - -
EMERGENCY ON
CLK MODE 00
CLOCK 000
AGING RGBW
VERTICAL LINE
COUNT
ALL WHITE
ALL RED
ALL GREEN
ALL BLUE
ON/OFF
RAMP WHITE
RAMP RED
RAMP GREEN
RAMP BLUE
1% WINDOW
COLOR BAR
A-ZONE B-ZONE/4 TRIO
SCROLL
WHITE FLAME
LOW SETUP RED
LOW SETUP GREEN
LOW SETUP BLUE
RM-SET CODE A Fixed
SRV-TOOL - See next

11
5.2. Service tool mode
5.2.1. How to access
1. Select [SRV-TOOL] in Service Mode.
2. Press [OK] button on the remote control.
5.2.2. Display of SOS History
SOS History (Number of LED blinking) indication.
From left side; Last SOS, before Last, three occurrence before, 2nd occurrence after shipment, 1st occurrence after shipment.
This indication except 2nd and 1st occurrence after shipment will be cleared by [Self-check indication and forced to factory ship-
ment setting].
5.2.3. POWER ON TIME/COUNT
Note : To display TIME/COUNT menu, highlight position, then press MUTE for (3sec).
Time : Cumulative power on time, indicated hour : minute by decimal
Count : Number of ON times by decimal
Note : This indication will not be cleared by either of the self-checks or any other command.
5.2.4. Exit
1. Disconnect the AC cord from wall outlet.

12
5.3. Hotel mode
1. Purpose
Restrict a function for hotels.
2. Access command to the Hotel mode setup menu
In order to display the Hotel mode setup menu, please
enter the following command (within 2 second).
[TV] : Vol. [Down] + [REMOTE] : INPUT (3 times)
Then, the Hotel mode setup menu is displayed.
3. To exit the Hotel mode setup menu
Disconnect AC power cord from wall outlet.
4. Explain the Hotel mode setup menu
item Function
Mode Select hotel mode ON/OFF
Input Select input signal modes.
Set the input, when each time power is
switched on.
Selection:
-/RF/COMP1/COMP2/HDMI1/HDMI2/
HDMI3/HDMI4/VIDEO1/VIDEO2/PC
Off: give priority to a last memory.
Channel Select channel when input signal is RF.
Set the channel, each time power is switched
on.
Selection:
Any channel number or [-].
[-] means the channel when turns off.
Volume Adjust the volume when each time power is
switched on.
Range:
0 to 100
Vol. Max Adjust maximum volume.
Range:
0 to 100
OSD Ctrl Restrict the OSD.
Selection:
OFF/PATTERN1
• OFF: No restriction
• PATTERN1: restriction
FP Ctrl Select front key conditions.
Selection:
Off/Pattern1/All
• Off: altogether valid.
• Pattern: only input key is valid.
• All: altogether invalid.
Pow Ctrl Select POWER-ON/OFF condition when AC
power cord is disconnected and then con-
nected.
OFF: The same condition when AC power
cord is disconnected.
ON: Forced power ON condition.

13
6 Troubleshooting Guide
Use the self-check function to test the unit.
1. Checking the IIC bus lines
2. Power LED Blinking timing
6.1. Check of the IIC bus lines
6.1.1. How to access
Self-check indication only:
Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control
for more than 3 seconds.
Self-check indication and forced to factory shipment setting:
Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [MENU] button on the remote con-
trol for more than 3 seconds.
6.1.2. Exit
Disconnect the AC cord from wall outlet.
6.1.3. Screen display
6.1.4. Check Point
Confirm the following parts if NG was displayed.

14
6.2. Power LED Blinking timing chart
1. Subject
Information of LED Flashing timing chart.
2. Contents
When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the
defective block can be identified by the number of blinks of the Power LED on the front panel of the unit.

15
6.3. No Power
First check point
There are following 2 states of No Power indication by power LED.
1. No lit
2. Red is lit then turns red blinking a few seconds later. (See 6.2.)

16
6.4. No Picture

17
6.5. Local screen failure
Plasma display may have local area failure on the screen. Fig-1 is the possible defect P.C.B. for each local area.
Fig-1

18
7 Service Fixture & Tools
7.1. SC jig
Purpose:
To find the failure board (SC or SU/SD) when the power LED is blinking 7 times.
SC jig:
Jumper connector to connect to SC50 connector on SC board
Part number:
TZSC09187
How to use:
Caution: Remove SC jig from SC board after inspection.
1. Remove all connector between SC board and SU/SD board to isolate SC board from both SU and SD board electrically.
Note: The board will be damaged if all connector is not removed (for example; remove connector only for SU board and stay
connecting with SD board. The board will be damaged.)
2. Connect SC jig to connector SC50 at left bottom side of SC board
3. Turn of the TV/Display Unit and confirm the power LED blinking.
LED blinking: Possible cause of failure is in SC board
No LED blinking (Lighting or no lighting): Possible cause of failure is in SU or SD board
4. After inspection, turn off the TV/Display Unit and wait a few minutes to discharge.
5. Remove SC jig from SC board.
Remark: This SC jig can be used for all 2009 Plasma TV and Plasma Display.

19
8 Disassembly and Assembly Instructions
8.1. Remove the Rear cover
1. See Service Hint (Section 3)
8.2. Remove the Fan
1. Unlock the cable clampers to free the cable.
2. Remove the screws (×3 ).
3. Remove the relay connectors and remove the Fan unit.
4. Remove the screws (×2 ) on the back side.
5. Remove the Fan.
8.3. Remove the P-Board
Caution:
To remove P.C.B. wait 1 minute after power was off for dis-
charge from electrolysis capacitors.
1. Unlock the cable clampers to free the cable
2. Disconnect the connectors (P51-P52, P53-P54 and P55-
P56).
3. Disconnect the connectors (P2, P6, P7, P9, P11, P25 and
P35).
4. Remove a short-jumper connector P34 and re-use for
new P-Board.
5. Remove the screws (×6 ) and remove the P(SUS)-
Board.
6. Remove the screws (×9 ) and remove the P(MULTI)-
Board.

20
8.4. Remove the Side terminal
cover and Rear terminal cover
1. Remove the claw (×1 ).
2. Remove the Side terminal cover.
3. Remove the Adjustment cover.
4. Remove the screws (×4 , ×4 ).
5. Remove the Rear terminal cover.
8.5. Remove the Tuner unit
1. Unlock the cable clampers to free the cable.
2. Disconnect the connectors (A1, A6 A11, A12, A25 and
A30).
3. Disconnect the flexible cables (A31, A32 and A33).
4. Remove the screws (×2 , ×1 ) and remove the
Tuner unit.
8.6. Remove the A-Board
1. Remove the Tuner unit. (See section 8.5.)
2. Remove the clampers (×2 ).
3. Remove the screws (×8 ) and remove the A-Board.
