Panasonic TH-65PX600U User manual

©2006 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
TH-65PX600U
GP9DU Chassis
Digital High Definition Plasma Television
Specifications
Power Source
A
C 120 V, 50/60 Hz
Power Consumption
Maximum 795 W
Standby condition 0.2 W (With CableCARDTM:22W)
Plasma Display panel
Drive method
A
C type
Aspect Ratio 16 : 9
Visible screen size
(W × H × Diagonal)
(No. of pixels)
165 cm
56.5 ” × 31.8 ” × 65 ” (1,434 mm × 807 mm × 1,646 mm)
2,073,600 (1,920 (W) × 1,080 (H)) [5,760 × 1,080 dots]
Sound
Audio Output 30 W [15 W + 15 W] (10 % THD)
PC signals VGA, SVGA, XGA, WXGA, SXGA
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Channel Capability (Digital/Analog) VHF/UHF: 2 - 69, CATV: 1 - 135
Operating Conditions Temperature: 32 °F - 104 °F (0 °C - 40 °C)
Connection Terminals
INPUT 1-3 VIDEO: RCA PIN Type × 1 1.0 V [p-p] (75 ohm)
S-VIDEO: Mini DIN 4-pin Y: 1.0 V [p-p] (75 ohm) C: 0.286 V [p-p] (75 ohm)
A
UDIO L-R: RCA PIN Type × 2 0.5 V [rms]
COMPONENT VIDEO
INPUT 1-2
Y: 1.0 V [p-p] (including synchronization)
PB,P
R: ± 0.35 V [p-p]
A
UDIO L-R: RCA PIN Type × 2 0.5 V [rms]
HDMI 1-3 TYPE A Connector
A
UDIO L-R: RCA PIN Type × 2 0.5 V [rms]
PC D-SUB 15 PIN: R, G, B/0.7 V [p-p] (75 ohm)
HD, VD/1.0 - 5.0 V [p-p] (high impedance)
ORDER NO.MTNC060802CE
B19 Canada: B07

1 Applicable signals 5
2 Safety Precautions 6
2.1. General Guidelines 6
3 Prevention of Electro Static Discharge (ESD) to
Electrostatically Sensitive (ES) Devices 7
4 About lead free solder (PbF) 8
5 Service Hint 9
6 Plasma panel replacement method 10
6.1. Remove the Back cover 10
6.2. Remove the rear terminal cover 10
6.3. Remove the P(P-1)-Board 10
6.4. Remove the P(P-2)-Board 10
6.5. Remove the PA-Board 11
6.6. Remove the D-Board 11
6.7. Remove the tuner unit 11
6.8. Remove the DT-Board 11
6.9. Remove the DG-Board 12
6.10. Remove the H-Board 13
6.11. Remove the Fan (Middle/R) 13
6.12. Remove the Fan (Big and Middle/L) 13
6.13. Remove the Fan (SC) 13
6.14. Remove the Fan (SS) 14
6.15. Remove the Shield cover (A) 14
6.16. Remove the Shield cover (B) and (C) 14
6.17. Remove the H3-Board (L, R) 14
6.18. Remove the Esc-fixing metal (A) 15
6.19. Remove the Esc-fixing metal (B) 15
6.20. Remove the SU-Board 15
6.21. Remove the SD-Board 15
6.22. Remove the SC-Board 16
6.23. Remove the SS2-Board 16
6.24. Remove the SS3-Board 16
6.25. Remove the SS-Board 16
6.26. Remove the Reinforcement Angles (L, R) and the
Connection Plate (A, B, C, D) 17
6.27. Remove the C1-Board 17
6.28. Remove the C2-Board 17
6.29. Remove the C3-Board 17
6.30. Remove the C4-Board 18
6.31. Remove the C5-Board 18
6.32. Remove the C6-Board 18
6.33. Remove the front bracket 18
6.34. Remove the G-Board, GH-Board and GK-Board 19
6.35. Remove the GS-Board 19
6.36. Remove the K-Board, R-Board and the S-Board 20
6.37. Remove the Plasma panel section from the Front frame
(glass) 20
6.38. Replace the plasma panel (finished) 21
7 Caution statement 22
7.1. Caution statement. 22
8 Location of Lead Wiring 23
8.1. Lead of Wiring (1) 23
8.2. Lead of Wiring (2) 24
8.3. Lead of Wiring (3) 25
8.4. Lead of Wiring (4) 26
8.5. Lead of Wiring (5) 27
9 Self-check Function 28
9.1. Check of the IIC bus lines 28
9.2. Power LED Blinking timing chart 30
9.3. No Power 31
A
UDIO L-R: Stereo Mini Jack ( 3.5 mm) × 1
IR Blaster G-LINK Jack × 1
Card slot SD CARD slot × 1, CableCARDTM slot × 1
AV PROG. OUT VIDEO: RCA PIN Type × 1 1.0 V [p-p] (75 ohm)
A
UDIO L-R: RCA PIN Type × 2 0.5 V [rms]
DIGITAL AUDIO OUT PCM/Dolby Digital, Fiber Optic
FEATURES 3D Y/C FILTER CableCARDTM slot
CLOSED CAPTION V-Chip Split-Screen
BBE VIVA 3D Photo Viewer TV GUIDE
Dimensions (W × H × D)
TV Set only 61.2 ” × 38.7 ” × 3.9 ” (1,554 mm × 984 mm × 99 mm)
Weight
TV Set only 174.2 lb. (79 kg)
Note:
Design and Specifications are subject change without notice. Weight and Dimensions shown are approximate.
CONTENTS
Page Page
2
TH-65PX600U

9.4. No Picture 32
9.5. Local screen failure 33
10 Serviceman Mode 34
10.1. How to enter into Serviceman Mode 34
10.2. Contents of adjustment mode 34
10.3. Memory edit mode 35
10.4. Device data mode 36
11 Adjustment Procedure 37
11.1. Driver Set-up 37
11.2. Initialization Pulse Adjust 38
11.3. P.C.B. (Printed Circuit Board) exchange 38
11.4. Adjustment Volume Location 39
11.5. Test Point Location 39
12 Adjustment 40
12.1. White balance adjustment 40
12.2. Sub bright adjustment 42
12.3. ABL operation level adjustment 43
13 Hotel mode 44
14 Conductor Views 45
14.1. P-Board 45
14.2. PA-Board 51
14.3. H-Board 53
14.4. G-Board 55
14.5. GH and GS-Board 56
14.6. GK, H3, K, R and S-Board 57
14.7. DG-Board 58
14.8. DT-Board 61
14.9. D-Board 63
14.10. C1-Board 65
14.11. C2-Board 66
14.12. C3-Board 67
14.13. C4-Board 68
14.14. C5-Board 69
14.15. C6-Board 70
14.16. SC-Board 71
14.17. SU-Board 74
14.18. SD-Board 75
14.19. SS-Board 76
14.20. SS2 and SS3-Board 79
15 Schematic and Block Diagram 81
15.1. Schematic Diagram Notes 81
15.2. Main Block Diagram 82
15.3. P-Board (1 of 2) Block Diagram 83
15.4. P-Board (2 of 2) Block Diagram 84
15.5. P-Board (1 of 2) Schematic Diagram 85
15.6. P-Board (2 of 2) Schematic Diagram 86
15.7. PA-Board (1 of 2) and H3-Board Block Diagram 87
15.8. PA-Board (2 of 2) Block Diagram 88
15.9. PA-Board (1 of 3) Schematic Diagram 89
15.10. PA-Board (2 of 3) Schematic Diagram 90
15.11. PA-Board (3 of 3) and H3-Board Schematic Diagram 91
15.12. H-Board Block Diagram 92
15.13. H-Board (1 of 2) Schematic Diagram 93
15.14. H-Board (2 of 2) Schematic Diagram 94
15.15. G, GK, K, R and S-Board Block Diagram 95
15.16. G, GK, K, R and S-Board Schematic Diagram 96
15.17. DG-Board (1 of 4) and GH-Board Block Diagram 97
15.18. DG-Board (2 of 4) Block Diagram 98
15.19. DG-Board (3 of 4) Block Diagram 99
15.20. DG-Board (4 of 4) Block Diagram 100
15.21. DG-Board (1 of 11) Schematic Diagram 101
15.22. DG-Board (2 of 11) Schematic Diagram 102
15.23. DG-Board (3 of 11) Schematic Diagram 103
15.24. DG-Board (4 of 11) Schematic Diagram 104
15.25. DG-Board (5 of 11) Schematic Diagram 105
15.26. DG-Board (6 of 11) Schematic Diagram 106
15.27. DG-Board (7 of 11) Schematic Diagram 107
15.28. DG-Board (8 of 11) Schematic Diagram 108
15.29. DG-Board (9 of 11) Schematic Diagram 109
15.30. DG-Board (10 of 11) Schematic Diagram 110
15.31. DG-Board (11 of 11) Schematic Diagram 111
15.32. GH-Board Schematic Diagram 112
15.33. DT-Board (1 of 2) and GS-Board Block Diagram 113
15.34. DT-Board (2 of 2) Block Diagram 114
15.35. DT-Board (1 of 9) Schematic Diagram 115
15.36. DT-Board (2 of 9) Schematic Diagram 116
15.37. DT-Board (3 of 9) Schematic Diagram 117
15.38. DT-Board (4 of 9) Schematic Diagram 118
15.39. DT-Board (5 of 9) and GS-Board Schematic Diagram 119
15.40. DT-Board (6 of 9) Schematic Diagram 120
15.41. DT-Board (7 of 9) Schematic Diagram 121
15.42. DT-Board (8 of 9) Schematic Diagram 122
15.43. DT-Board (9 of 9) Schematic Diagram 123
15.44. D-Board (1 of 2) Block Diagram 124
15.45. D-Board (2 of 2) Block Diagram 125
15.46. D-Board (1 of 8) Schematic Diagram 126
15.47. D-Board (2 of 8) Schematic Diagram 127
15.48. D-Board (3 of 8) Schematic Diagram 128
15.49. D-Board (4 of 8) Schematic Diagram 129
15.50. D-Board (5 of 8) Schematic Diagram 130
15.51. D-Board (6 of 8) Schematic Diagram 131
15.52. D-Board (7 of 8) Schematic Diagram 132
15.53. D-Board (8 of 8) Schematic Diagram 133
15.54. C1, C2, C5 and C6-Board Block Diagram 134
15.55. C2, C3, C4, and C5 Block Diagram 135
15.56. C1-Board (1 of 2) Schematic Diagram 136
15.57. C1-Board (2 of 2) Schematic Diagram 137
15.58. C2-Board (1 of 2) Schematic Diagram 138
15.59. C2-Board (2 of 2) Schematic Diagram 139
15.60. C3-Board (1 of 2) Schematic Diagram 140
15.61. C3-Board (2 of 2) Schematic Diagram 141
15.62. C4-Board (1 of 2) Schematic Diagram 142
15.63. C4-Board (2 of 2) Schematic Diagram 143
15.64. C5-Board (1 of 2) Schematic Diagram 144
15.65. C5-Board (2 of 2) Schematic Diagram 145
15.66. C6-Board (1 of 2) Schematic Diagram 146
15.67. C6-Board (2 of 2) Schematic Diagram 147
15.68. SC-Board Block Diagram 148
3
TH-65PX600U

15.69. SC-Board (1 of 4) Schematic Diagram 149
15.70. SC-Board (2 of 4) Schematic Diagram 150
15.71. SC-Board (3 of 4) Schematic Diagram 151
15.72. SC-Board (4 of 4) Schematic Diagram 152
15.73. SU and SD-Board Block Diagram 153
15.74. SU-Board (1 of 3) Schematic Diagram 154
15.75. SU-Board (2 of 3) Schematic Diagram 155
15.76. SU-Board (3 of 3) Schematic Diagram 156
15.77. SD-Board (1 of 3) Schematic Diagram 157
15.78. SD-Board (2 of 3) Schematic Diagram 158
15.79. SD-Board (3 of 3) Schematic Diagram 159
15.80. SS, SS2 and SS3-Board Block Diagram 160
15.81. SS-Board (1 of 2) Schematic Diagram 161
15.82. SS-Board (2 of 2), SS2 and SS3-Board Schematic
Diagram 162
16 Parts Location & Mechanical Replacement Parts List 163
16.1. Parts Location 163
16.2. Packing Exploded Views 164
16.3. Packing Exploded Views 165
16.4. Mechanical Replacement Parts List 166
17 Electrical Replacement Parts List 167
17.1. Replacement Parts List Notes 167
17.2. Electrical Replacement Parts List 168
4
TH-65PX600U

1 Applicable signals
5
TH-65PX600U

2.1.1. Leakage Current Cold Check
1. Unplug the AC cord and connect a jumper between the two
prongs on the plug.
2. Measure the resistance value, with an ohmmeter, between
the jumpered AC plug and each exposed metallic cabinet
part on the equipment such as screwheads, connectors,
control shafts, etc. When the exposed metallic part has a
return path to the chassis, the reading should be between
1Mohm and 5.2Mohm.
When the exposed metal does not have a return path to
the chassis, the reading must be .
Figure 1
2.1.2. Leakage Current Hot Check (See
Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use an
isolation transformer for this check.
2. Connect a 1.5kohm, 10 watts resistor, in parallel with a
0.15µF capacitors, between each exposed metallic part on
the set and a good earth ground such as a water pipe, as
shown in Figure 1.
3. Use an AC voltmeter, with 1000 ohms/volt or more
sensitivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the
voltage at each point.
5. Reverse the AC plug in the AC outlet and repeat each of the
above measurements.
6. The potential at any point should not exceed 0.75 volts
RMS. A leakage current tester (Simpson Model 229 or
equivalent) may be used to make the hot checks, leakage
current must not exceed 1/2 milliamp. In case a
measurement is outside of the limits specified, there is a
possibility of a shock hazard, and the equipment should be
repaired and rechecked before it is returned to the
customer.
2 Safety Precautions
2.1. General Guidelines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
6
TH-65PX600U

3 Prevention of Electro Static Discharge (ESD) to
Electrostatically Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and
semiconductor "chip" components. The following techniques should be used to help reduce the incidence of component damage
caused by electro static discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as alminum
foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static (ESD protected)" can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, alminum foil or comparable
conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise hamless motion such as the brushing
together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity (ESD) sufficient to
damage an ES device).
7
TH-65PX600U

4 About lead free solder (PbF)
Note: Lead is listed as (Pb) in the periodic table of elements.
In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.
The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For service and repair work, we’d
suggest the use of Pb free solder as well, although Pb solder may be used.
PCBs manufactured using lead free solder will have the PbF within a leaf Symbol PbF stamped on the back of PCB.
Caution
· Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40 °C) higher.
Please use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).
· Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).
If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before applying Pb
solder. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.
· After applying PbF solder to double layered boards, please check the component side for excess solder which may flow onto
the opposite side. (see figure below)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder.
However, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used.
8
TH-65PX600U

5 Service Hint
Board Name Function Board Name Function
P Power Supply C1 Data Driver (Upper Right)
PA DC-DC Converter
Speaker out, Audio AMP, Fan Control
C2 Data Driver (Upper Center)
C3 Data Driver (Upper Left)
H AV Terminal, AV Switch C4 Data Driver (Lower Left)
DG Digital Signal Processor, Micom, HDMI Interface C5 Data Driver (Lower Center)
DT ATSC Interface C6 Data Driver (Lower Right)
D Format Converter, Plasma AI, Sub-Field Processor SC Scan Drive
GS SD Card Slot SU Scan out (Upper)
R Remote receiver SD Scan out (Lower)
K Power LED SS Sustain Drive
S Power Switch SS2 Sustain Connector (Upper)
G Front Terminal SS3 Sustain Connector (Lower)
GK Key Switch
GH HDMI Interface
9
TH-65PX600U

6.1. Remove the Back cover
1. See Service Hint (Section 5)
6.2. Remove the rear terminal
cover
1. Remove the screws (×6 ,×8 ).
2. Remove the rear terminal cover.
6.3. Remove the P(P-1)-Board
Caution:
To remove P.C.B. wait 1 minute after power was off for
discharge from electrolysis capacitors.
1. Disconnect the couplers (P2, P9, P11, P52, P54 and P56).
2. Remove the screws (×10 ) and remove the P(P-1)-
Board.
6.4. Remove the P(P-2)-Board
Caution:
To remove P.C.B. wait 1 minute after power was off for
discharge from electrolysis capacitors.
1. Disconnect the couplers (P5, P10, P12, P23, P25, P51, P53
and P55).
2. Remove the screws (×9 ) and remove the P(P-2)-Board.
6 Plasma panel replacement method
10
TH-65PX600U

6.5. Remove the PA-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (PA2, PA5, PA10, PA31, PA32,
PA33, PA34, PA35, PA36 and PA40).
3. Disconnect the flexible cable (PA20).
4. Remove the screws (×4 ) and remove the PA-Board
unit.
5. Remove the screws (×4 ) and remove the PA-Board.
6.6. Remove the D-Board
1. Remove the PA-Board unit. (See section 6.5.)
2. Disconnect the couplers (D3, D5, D20 and D25).
3. Disconnect the flexible cables (D31, D32, D33, D34, D35
and D36).
4. Remove the screws (×4 ) and remove the D-Board.
6.7. Remove the tuner unit
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (D3, D5, DT10, H51, PA2, PA40
and relay couplers).
3. Disconnect the flexible cables (DG11 and PA20).
4. Remove the screws (×4 ) remove the tuner unit.
6.8. Remove the DT-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the coupler (DT10).
3. Remove the screws (×5 ) remove the DT-Board unit.
(Be careful the coupler (DT12-DG22) when remove the DT-
Board.)
4. Remove the screws (×2 ).
5. Remove the DT-Board shield case cover.
11
TH-65PX600U

6. Release the DT-Board shield case body claws (×6 ).
7. Remove the DT-Board.
6.9. Remove the DG-Board
1. Remove the DT-Board unit. (See section 6.8.)
2. Remove the screws (×8 ) and remove the DT-Board
metal frame.
3. Disconnect the couplers (DG2, DG3 and DG5).
4. Disconnect the flexible cables (DG1, DG11 and DG20).
5. Remove the screw (×1 ) and remove the DG-Board.
12
TH-65PX600U

6.10. Remove the H-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (H2, H40 and H51).
3. Disconnect the flexible cable (H1).
4. Remove the screws (×5 ) and remove the H-Board.
6.11. Remove the Fan (Middle/R)
1. Disconnect the relay couper.
2. Remove the screws (×4 ) and remove the Fan unit
(Middle/R).
3. Remove the screws (×4 ) and remove the Fan
(Middle/R).
6.12. Remove the Fan (Big and
Middle/L)
1. Disconnect the relay coupers.
2. Remove the screws (×4 ) and remove the Fan unit (Big
and Middle/L).
3. Remove the screws (×8 ) and remove the Fan (Big) and
the Fan (Middle/L).
6.13. Remove the Fan (SC)
1. Disconnect the relay coupers.
2. Remove the screws (×4 ) and remove the Fan unit (SC).
3. Remove the screws (×8 ) and remove the Fans (SC×2).
13
TH-65PX600U

6.14. Remove the Fan (SS)
1. Disconnect the relay coupers.
2. Remove the screws (×4 ) and remove the Fan unit (SS).
3. Remove the screws (×4 ) and remove the Fan (SS).
6.15. Remove the Shield cover (A)
1. Remove the screws (×4 ).
2. Remove the Shield cover (A).
6.16. Remove the Shield cover (B)
and (C)
1. Remove the screws (×2 each).
2. Remove the Shield cover (B) and (C).
6.17. Remove the H3-Board (L, R)
1. Remove the screws (×2 each) and remove the Speaker
Terminal unit (L, R).
2. Remove the screw (×1 each) and the screws (×2
each).
3. Disconnect the coupler (H37).
4. Remove the H3-Board.
14
TH-65PX600U

6.18. Remove the Esc-fixing metal
(A)
1. Remove the screws (×4 each).
2. Remove the Esc-fixing metal (A).
6.19. Remove the Esc-fixing metal
(B)
1. Remove the screws (×6 each).
2. Remove the Esc-fixing metal (B).
6.20. Remove the SU-Board
1. Remove the screws (×4 ).
2. Remove the flexible cables (SU1, SU2, SU3, SU4 and SU5)
connected to the SU-Board and remove the bridge
connector (SU45).
3. Slide the SU-Board to the left to disconnect from couplers
(SC41-SU41 and SC42-SU42) on the SC-Board and
remove the SU-Board.
6.21. Remove the SD-Board
1. Remove the screws (×4 ).
2. Remove the flexible cables (SD1, SD2, SD3, SD4 and SD5)
connected to the SD-Board and remove the bridge
connector (SD46).
3. Slide the SD-Board to the left to disconnect from couplers
(SC43-SD43 and SC44-SD44) on the SC-Board and
remove the SD-Board.
15
TH-65PX600U

6.22. Remove the SC-Board
1. Unlock the cable clampers to free the cable.
2. Remove the Fan (SC). (See section 6.13.)
3. Remove the SU-Board and SD-Board. (See section 6.20.
and 6.21.)
4. Disconnect the couplers (SC2, SC20 and SC23).
5. Remove the screws (×10 ) and remove the SC-Board.
6.23. Remove the SS2-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the coupler (SS23) and disconnect the flexible
cables (SS51 and SS52).
3. Remove the screws (×3 ) and remove the SS2-Board.
6.24. Remove the SS3-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the coupler (SS27) and disconnect the flexible
cables (SS57 and SS58).
3. Remove the screws (×3 ) and remove the SS3-Board.
6.25. Remove the SS-Board
1. Unlock the cable clampers to free the cable.
2. Remove the Fan (SS). (See section 6.14.)
3. Disconnect the couplers (SS11, SS12, SS23, SS27, SS35,
SS42 and SS44).
4. Disconnect the flexible cables (SS53, SS54, SS55 and
SS56).
5. Remove the screws (×10 ) and remove the SS-Board.
16
TH-65PX600U

6.26. Remove the Reinforcement
Angles (L, R) and the
Connection Plate (A, B, C, D)
1. Remove the plasma panel section from the servicing stand
and lay on a flat surface such as a table (covered), with the
plasma panel surface facing downward.
Spread a soft cloth or similar on the table for protection, so
the panel surface is not scratched.
2. Remove the screws (×2 each) and remove the
Reinforcement Angles (L, R).
3. Remove the screws (×2 each) and remove the
Connection Plate (A, B, C, D).
6.27. Remove the C1-Board
1. Remove the Fan unit (Middle/R). (See section 6.11.)
2. Remove the Esc-fixing metal (A) and (B). (See section 6.18.
and 6.19.)
3. Remove the Reinforcement Angle (R). (See section 6.26.)
4. Remove the flexible cables holder fastening screws (×10
).
5. Disconnect the flexible cables (CA1, CA2, CA3, CA4 and
CA5).
6. Disconnect the flexible cables (C10 and C11).
7. Remove the screws (×6 ) and remove the C1-Board.
6.28. Remove the C2-Board
1. Remove the Fan unit (Big and Middle/L). (See section
6.12.)
2. Remove the Esc-fixing metal (B). (See section 6.19.)
3. Remove the flexible cables holder fastening screws (×10
).
4. Disconnect the flexible cables (CA6, CA7, CA8, CA9, and
CA10).
5. Disconnect the flexible cables (C21, C22, C24 and C25).
6. Remove the screws (×6 ) and remove the C2-Board.
6.29. Remove the C3-Board
1. Remove the Fan unit (Big and Middle/L). (See section
6.12.)
2. Remove the Esc-fixing metal (A) and (B). (See section 6.18.
and 6.19.)
3. Remove the Reinforcement Angle (L). (See section 6.26.)
4. Remove the flexible cables holder fastening screws (×10
).
5. Disconnect the flexible cables (CA11, CA12, CA13, CA14
and CA15).
6. Disconnect the flexible cable (C31).
7. Disconnect the coupler (C35).
8. Remove the screws (×6 ) and remove the C3-Board.
17
TH-65PX600U

6.30. Remove the C4-Board
1. Remove the Speaker Terminal unit (L). (See section 6.17.)
2. Remove the Esc-fixing metal (A) and (B). (See section 6.18.
and 6.19.)
3. Remove the Reinforcement Angle (L). (See section 6.26.)
4. Remove the flexible cables holder fastening screws (×10
).
5. Disconnect the flexible cables (CB11, CB12, CB13, CB14
and CB15).
6. Disconnect the flexible cable (C41).
7. Disconnect the couplers (C42 and C44).
8. Remove the screws (×6 ) and remove the C4-Board.
6.31. Remove the C5-Board
1. Remove the tuner unit. (See section 6.7.)
2. Remove the Esc-fixing metal (B). (See section 6.19.)
3. Remove the flexible cables holder fastening screws (×10
).
4. Disconnect the flexible cables (CB6, CB7, CB8, CB9 and
CB10).
5. Disconnect the flexible cables (C51, C52, C54 and C55).
6. Remove the screws (×6 ) and remove the C5-Board.
6.32. Remove the C6-Board
1. Remove the Speaker Terminal unit (R). (See section 6.17.)
2. Remove the Esc-fixing metal (A) and (B). (See section 6.18.
and 6.19.)
3. Remove the Reinforcement Angle (R). (See section 6.26.)
4. Remove the flexible cables holder fastening screws (×10
).
5. Disconnect the flexible cables (CB1, CB2, CB3, CB4 and
CB5).
6. Disconnect the flexible cables (C60 and C61).
7. Remove the screws (×6 ) and remove the C6-Board.
6.33. Remove the front bracket
1. Remove the Shield cover (A). (See section 6.15.)
2. Unlock the cable clampers to free the cable.
3. Disconnect the couplers (G1, G4 and G51).
4. Disconnect the flexible cable (GH11).
5. Remove the screws (×2 ) and remove the front bracket.
18
TH-65PX600U

6.34. Remove the G-Board, GH-
Board and GK-Board
1. Remove the front bracket. (See section 6.33.)
2. Remove the screws (×3 ) and remove the front bracket
cover.
3. Remove the screws (×5 ).
4. Remove the screws (×1 ) and remove the terminal shield
holder.
5. Remove the screws (×4 ) and disconnect the couplers
(G3-GK3).
6. Remove the G-Board and GH-Board.
7. Release the control button claws (×2 ).
8. Remove the GK-Board.
6.35. Remove the GS-Board
1. Remove the Shield cover (B). (See section 6.16.)
2. Remove the screws (×3 ).
3. Remove the SD card unit.
4. Remove the screws (×2 ).
5. Disconnect the coupler (G52).
6. Remove the GS-Board.
19
TH-65PX600U

6.36. Remove the K-Board, R-Board
and the S-Board
1. Unlock the cable clampers to free the cable.
2. Disconnect the couplers (G1 and G4). (See section 6.33.)
3. Remove the screws (×6 ) and remove the L/Front Panel-
left-assembly.
4. Remove the screw (×1 ).
5. Disconnect the coupler (R4) and remove the R-Board.
6. Remove the screws (×2 ).
7. Disconnect the couplers (K1 and K2) and remove the K-
Board.
8. Remove the screws (×2 ) and remove the S-Board unit.
9. Disconnect the coupler (S1).
10. Remove the screws (×2 ) and remove the S-Board.
6.37. Remove the Plasma panel
section from the Front frame
(glass)
1. Remove the Esc-fixing metal (A) and (B). (See section 6.18.
and 6.19.)
2. Remove the front frame and the plasma panel fastening
screws (×6 ).
3. Remove the spacers and spacer rings (×12 ).
20
TH-65PX600U
