Panasonic PT-LB1V System manual

SPEC FILE
Prod ct N m b e r : PT-LB1V
Prod ct Name : LCD Projector
As of May 2011. Specifications and appearance are s bject to change witho t notice.
SFL11M001
1/10

SPEC FI L E
PT-LB1V
LCD Projector
As of May 2011
SFL11M001
2/10
Specifications
Power supply
Power consumption
Optical system
LCD panel Panel size
Display method
Drive method
Pixels
Pixel configuration
Lens
Lamp
Projection size
Colors
Brightness*2
Center-to-corner uniformity ratio*2
Contrast ratio* 2
Resolution RGB
Scanning frequency RGB
YPBPR
Video/S-Video
Optical axis shift
Keystone correction range
On-screen menu
nstallation
Built-in speakers Size
Output power
Terminals COMPUTER (RGB) N
RGB
YPBPR(YCBCR)
V DEO N
S-V DEO N
AUD O N
AUD O OUT
SER AL
LAN
Power cord length
Cabinet material
100–240 V AC, 50/60 Hz
290 W (approx. 0.3 W at 100–120V AC, approx. 0.4 W at 220–240 V
with standby mode set to eco*1, approx. 15 W with standby mode set
to normal, approx. 18 W in normal standby mode when set to audio
monitor out.)
Dichroic mirror separation/prism synthesis system
16 mm (0.63˝) diagonal (4:3 aspect ratio)
Transparent LCD panel (× 3, R/G/B)
Active matrix
786,432 (1,024 × 768) × 3, total of 2,359,296 pixels
Stripe
Manual zoom (1:1–1:1.2), manual focus
F 2.00 – 2.20, f 19.22 –22.68 mm
220 W UHM lamp
838–7,620 mm (33– 300 inches) diagonally, 4:3 aspect ratio
Full color (16,777,216 colors)
2,200 lumens
85%
600:1 (full on/full off)
1,024 × 768 pixels ( nput signals that exceed this resolution will be
converted to 1,024 × 768 pixels.)
Horizontal: 15.00 kHz– 91.00 kHz, Vertical: 50Hz–85 Hz
480i (525i): fH15.75 kHz; fV60 Hz
576i (625i): fH15.63 kHz; fV50 Hz
480p (525p): fH31.50 kHz; fV60 Hz
576p (625p): fH31.25 kHz; fV50 Hz
720 (750)/60p: fH45.00 kHz; fV60 Hz
720 (750)/50p: fH37.50 kHz; fV50 Hz
1080 (1125)/60i: fH33.75 kHz; fV60 Hz
1080 (1125)/50i: fH28.13 kHz; fV50 Hz
1080 (1125)/60p: fH67.50 kHz; fV60 Hz
1080 (1125)/50p: fH56.25 kHz; fV50 Hz
fH: 15.75 kHz, fV: 60 Hz [NTSC/NTSC4.43/PAL-M/PAL60]
fH: 15.63 kHz, fV: 50 Hz [PAL/SECAM/PAL-N]
5:1 (fixed)
Approx. ±30° vertically
17 languages: English, French, German, Spanish, talian, Korean,
Russian, Chinese, Japanese, Swedish, Norwegian, Danish, Portuguese,
Polish, Hungarian, Czech, and Thai
Front/rear, ceiling/desk (menu selection)
4 × 2 cm (oval) × 1,
1.0 W (monaural)
D-sub HD 15-pin (female) × 2
G: 0.7 Vp-p (1.0 V [p-p] for sync on green signals), 75 ohms,
R, B: 0.7 Vp-p, 75 ohms, HD/SYNC, VD: TTL (positive/negative polarity
compatible)
Y: 1.0 Vp-p (including sync signal), 75 ohms,
PBPR/CBCR: 0.7 Vp-p, 75 ohms
RCA pin × 1, 1.0 Vp-p, 75 ohms
Mini D N 4-pin × 1, Y: 1.0 Vp-p, C: 0.286 Vp-p, 75 ohms
M3 (L, R) × 2, 0.5 Vrms
M3 (L, R) × 1, 0 – 2.0 Vrms (variable)
D-sub 9-pin × 1, for external control (RS-232C compliant)
RJ-45 × 1 for network connection, compliant with PJLink™,
100Base-TX/10Base-T
2 m (6.6 ft)
Molded plastic (PC+ABS)

SPEC FI L E
PT-LB1V
LCD Projector
As of May 2011
SFL11M001
3/10
Dimensions (W × H × D)
Weight
Operating environment Temperature
Humidity
Remote control unit Power supply
Operation range
Dimensions (W × H × D)
Weight
Supplied accessories
Optional accessories
307 × 69 × 210 mm (12-3/32˝ × 2-23/32˝ × 8-9/32˝)*3
Approx. 2.3 kg (5.1 lbs.)*4
0°–40°C (32°–104°F)*5
20%–80% (no condensation)
3 V DC (R03/AAA type battery × 2)
Approx. 7 m (23 ft) when operated from directly in front of the signal
receptor
46 × 115 × 21 mm (1-13/16˝ × 4-17/32˝ × 27/32˝)
Approx. 64 g (2.3 oz) (including batteries)
Power cord (× 1)
Power cord secure lock (× 1)
Wireless remote control (× 1)
Batteries for remote control (R03/AAA type × 2)
VGA cable for RGB signals (1.8 m (5 ft 11 in) × 1)
Carrying bag (× 1)
Software CD-ROM (Logo Transfer Software, Multi Projector
Monitoring and Control Software) (× 1)
Ceiling mount bracket: ET-PKB2
Highly durable filter unit: ET-KFB2
Replacement lamp unit: ET-LAB2
Replacement air filter for ET-KFB2: ET-RFB2
Weights and dimensions shown are approximate. Specifications and appearance are subject to change without notice.
*1: When the standby mode is set to eco, LAN-based network functions such as the standby on function will not operate and only certain com-
mands can be received from RS-232C control.
*2: Measurement, measuring conditions, and method of notation all comply with ISO 21118 international standards.
*3: rotruding parts not included.
*4: Average value. May differ depending on models.
*5: The operating temperature range is 0°C to 35°C (32°F to 95°F) when used in High-Altitude mode (1,400 m to 2,700 m (4,593 ft to 8,858 ft)). Also,
if the ambient temperature exceeds 35°C (95°F) (30°C (86°F) in High-Altitude mode) when the lamp power mode is set to NORMAL, the light
output may be reduced approximately 30% to protect the projector.

SPEC FI L E
PT-LB1V
LCD Projector
As of May 2011
SFL11M001
4/10
Dimensions
Terminals
79 179
(3-1/8) (7-1/16)
307 (12-3/32)
21049
6911
80
(8-9/32)(1-15/16)
(2-23/32)(7/16)
(3-5/32)
unit : mm (inch)
NOTE: This illustration is not drawn to scale.
12 3 45
6789
1 LAN connector
2 Serial input
3 Computer 1 input
4 S-Video input
5 Audio output
6 Computer 1 input
7 Video input
8 Audio 1 input
9 Audio 2 input

-30°
+30°
10°
10°
SPEC FI L E
PT-LB1V
LCD Projector
As of May 2011
SFL11M001
5/10
Standard setting-up positions
Projected image
Lower edge of projected image
Upper edge of projected image
Projected image
335–415
(13-3/16–
16-11/32)
Adjustable in
20-mm
(15/32-inch) step.
100
ø49
ø42
65
67.5
(2-9/16)
(2-21/32)
70
(3-15/16)
(1-15/16)
(1-11/16)
(2-3/4)
L
L
L
HH
unit : mm (inch)
NOTE:
Illustrations show the projector installed
using optional ceiling mount bracket.
This illustration is not drawn to scale.
L: Distance to screen
H: Height from the edge of screen to
center of lens
* This distance is especially recommend-
ed for ceiling-mounted use and other
permanent installations.
NOTE:
Values shown are approximate.
The value for L (distance to screen)
varies slightly depending on the zoom
lens characteristics.
When the shortest projection distance is
used, a small amount of distortion may
occur in the image due to the zoom lens
characteristics.
0.84 m
1.02 m
1.27 m
1.52 m
1.78 m
2.03 m
2.29 m
2.54 m
3.05 m
3.81 m
5.08 m
6.35 m
7.62 m
–
1.2 m
1.5 m
1.8 m
2.1 m
2.4 m
2.7 m
3.0 m
3.6 m
4.5 m
6.0 m
7.5 m
9.0 m
1.1 m
1.4 m
1.8 m
2.1 m
2.5 m
2.8 m
3.2 m
3.5 m
4.3 m
5.3 m
7.1 m
8.9 m
10.7 m
0.08 m
0.10 m
0.13 m
0.15 m
0.18 m
0.20 m
0.23 m
0.25 m
0.30 m
0.38 m
0.51 m
0.64 m
0.76 m
(33˝)
(40˝)
(50˝)
(60˝)
(70˝)
(80˝)
(90˝)
(100˝)
(120˝)
(150˝)
(200˝)
(250˝)
(300˝)
(–)
(3.9´)
(4.8´)
(5.8´)
(6.8´)
(7.8´)
(8.8´)
(9.8´)
(11.8´)
(14.8´)
(19.7´)
(24.7´)
(29.6´)
(3.8´)
(4.6´)
(5.8´)
(6.9´)
(8.1´)
(9.3´)
(10.5´)
(11.6´)
(14.0´)
(17.5´)
(23.4´)
(29.3´)
(35.1´)
(0.28´)
(0.33´)
(0.42´)
(0.50´)
(0.58´)
(0.67´)
(0.75´)
(0.83´)
(1.00´)
(1.25´)
(1.67´)
(2.08´)
(2.50´)
Projection size
[diagonal]
Height from the edge of screen
to center of lens [H]
Projection distance (L)
Min [wide] Max [telephoto]
Calculation of the projection distance
For a screen size different from the above, use the equation below to calculate the projection distance.
Aspect ratio 4 : 3
minimum L (m) = (diagonal screen size in inches) × 0.0302 – 0.035
maximum L (m) = (diagonal screen size in inches) × 0.0358 – 0.035
Aspect ratio 16 : 9
minimum L (m) = (diagonal screen size in inches) × 0.0330 – 0.041
maximum L (m) = (diagonal screen size in inches) × 0.0391 – 0.040
NOTE: Distances calculated with the above equations will include a slight error.
Installable angle
nstall the projector at an angle within the range shown below.
• Vertical direction
The projector
may be installed
at a vertical
angle of ±30°.
rojection distance for 4:3 aspect ratio screen
• Horizontal direction
The projector may be installed at a horizontal angle of ±10°.

Display mode Display
resolution
(dots)1
Scanning frequency
H
(kHz) V (kHz)
Dot clock
frequency
(MHz)
quality2Input terminal
720 × 480i
720 × 576i
720 × 480i
720 × 576i
720 × 483
720 × 576
1280 × 720
1920 × 1080i
1920 × 1080
640 × 400
640 × 480
800 × 600
832 × 624
1024 × 768
1280 × 720
1280 × 768
1280 × 800
1152 × 864
1152 × 870
1280 × 960
1280 × 1024
1400 × 1050
1440 × 900
1600 × 1200
1680 × 1050
1920 × 1200
15.7
15.6
15.7
15.6
31.5
31.3
45.0
37.5
33.8
28.1
67.5
56.3
31.5
37.9
31.5
35.0
37.9
37.5
43.3
35.2
37.9
48.1
46.9
53.7
49.7
39.6
48.4
56.5
60.0
68.7
44.8
37.1
39.6
47.8
41.3
49.1
49.7
64.0
67.5
76.7
68.7
60.0
64.0
80.0
91.1
64.0
65.1
55.9
75.0
65.3
74.6
59.9
50.0
59.9
50.0
59.9
50.0
60.0
50.0
60.0
50.0
60.0
50.0
70.1
85.1
59.9
66.7
72.8
75.0
85.0
56.3
60.3
72.2
75.0
85.1
74.6
50.1
60.0
70.1
75.0
85.0
59.9
49.8
49.9
59.9
50.0
60.2
59.8
71.2
74.9
85.0
75.1
60.0
60.0
75.0
85.0
60.0
59.9
59.9
60.0
60.0
59.9
–
–
13.5
13.5
27.0
27.0
74.3
74.3
74.3
74.3
148.5
148.5
25.2
31.5
25.2
30.2
31.5
31.5
36.0
36.0
40.0
50.0
49.5
56.3
57.3
51.9
65.0
75.0
78.8
94.5
74.5
60.5
65.3
79.5
68.0
69.1
83.5
94.2
108.0
121.5
100.0
108.0
108.0
135.0
157.5
108.0
122.4
106.5
162.0
146.3
193.3
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
AA
AA
AA
AA
AA
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
A
B
NTSC/NTSC4.43/PAL-M/PAL60
PAL/PAL-N/SECAM
525i (480i)
625i (576i)
525p (480p)
625p (576p)
750 (720)/60p
750 (720)/50p
1125 (1080)/60i
1125 (1080)/50i
1125 (1080)/60p
1125 (1080)/50p
VESA70
VESA85
VGA60
VGA65
VGA72
VGA75
VGA85
SVGA55
SVGA60
SVGA70
SVGA75
SVGA85
MAC16
XGA50
XGA60
XGA70
XGA75
XGA85
WIDE750 (720)
WXGA768
WXGA800
MXGA70
MXGA75
MXGA85
MAC21
MSXGA60
SXGA60
SXGA75
SXGA85
SXGA60+
WXGA+
UXGA60
WSXGA+
WUXGA
VIDEO/S-VIDEO
COMPUTER (RGB/YPBPR)
COMPUTER (RGB only)
SPEC FI L E
PT-LB1V
LCD Projector
As of May 2011
SFL11M001
6/10
Computer data compatibility
This projector accepts up to 91 kHz horizontal scanning frequency and 193 MHz dot clock.
NOTE: ixel thinning is applied to signals that exceed a dot clock frequency of 170 MHz. The display resolution of this projector is 1,024 × 768
pixels. Input signals that exceed this resolution will be converted to 1,024 × 768 pixels.
List of compatible signals
1. The “i” appearing after the resolution indicates an interlaced signal.
2. The following symbols are used to indicate picture quality.
AA Maximum picture quality can be obtained.
A Signals are converted by the image processing circuit before picture is projected.
B Signals are compressed by the image processing circuit before picture is projected.

1
2
3
4
5
6
7
8
9
1
2
3
4
5
6
7
8
9
PC (DTE)Projector
NC
NC
NC
NC
NC
NC
NC
NC
SPEC FI L E
PT-LB1V
LCD Projector
As of May 2011
SFL11M001
7/10
STX ETXC1C2C3 : P1P2P3P4
Start
(1 byte) End (1 byte)
Colon
(1 byte) Parameter (1-4 bytes)Command
(3 bytes)
(Control and/or query commands)
Serial connector
The serial connector complies with RS-232C. To control the projector from a personal computer, com-
mands must be input through communication software, based on the format and satisfying the commu-
nication conditions shown below.
in assignments and signal names
Communication conditions (factory setting)
Basic format
Transmission from the computer begins with STX, then the D, command, parameter, and ETX are sent
in this order. Add parameters according to the details of control.
NOTE
• f a wrong command is received, the projector will send an ER401 command to the computer.
• f a wrong parameter is received, the projector will send an ER402 command to the computer.
CAUTION
• t may not be possible to send or receive commands for about 10 to 60 seconds when the lamp is first turned on. f this occurs, wait for 60 seconds,
then try sending or receiving again.
• When sending multiple commands, be sure to wait for at least 0.5 second after receiving a response from the projector before sending the next com-
mand.
• Additional time is sometimes required for response due to processing inside the projector. Set the time-out period for command response to 10 seconds
or more.
D-sub HD 9-pin, female
No.
1
2
3
4
5
No.
6
7
8
9
Signal name
–
TXD
RXD
–
GND
Signal name
–
CTS
RTS
–
Description
NC
Send data
Receive data
NC
Ground
Signal name
Connected internally
Connected internally
Connected internally
NC
6
15
9
Signal level
Synchronization method
Baud rate
Parity
Character length
Stop bit
X parameter
S parameter
RS-232C-compliant
Start-stop synchronization
9,600 bps
None
8 bits
1 bit
None
None
Cable specifications

SPEC FI L E
PT-LB1V
LCD Projector
As of May 2011
SFL11M001
8/10
Control commands
*1Do not send PON, POF, or OSH commands continuously in a short period of time (0.5 second or less). Doing so may burst the lamp or shorten the
lamp replacement cycle.
*2These commands are effective when the standby mode is set to eco. (Other commands are not effective.)
PON*1/*2
POF*1/*2
AVL:<pl>
IIS:<input signal>
OST
OFZ:<off on>
OEN
OXG:0
OXG:1
OXG:2
VPM:<NAT>
VPM:<STD>
VPM:<DYN>
VPM:<BBD>
VPM:<WBD>
VXX:DLVI0=<+00000>
VXX:DLVI0=<+00001>
VXX:DLVI0=<+00002>
AUU
AUD
OMN
OCU
OCD
OCL
OCR
OAS
OSH*1
OIX
DZU
DZD
Power on (standby mode on)
Power off (standby mode off)
Volume control
Input signal selection
The same function as “default” button
Freeze
Enter
Wide mode: Off
Wide mode: On
Wide mode: Auto
Picture mode: Natural
Picture mode: Standard
Picture mode: Dynamic
Picture mode: Blackboard
Picture mode: Whiteboard
Daylight View: Off
Daylight View: Auto
Daylight View: On
Volume up
Volume down
Menu
Cursor up
Cursor down
Cursor left
Cursor right
Auto setup
AV mute
Index window
Digital zoom: Enlargement
Digital zoom: Reduction
PON
POF
AVL:<pl>
IIS:<input signal>
OST
OFZ:<off on>
OEN
OXG:0
OXG:1
OXG:2
VPM:<NAT>
VPM:<STD>
VPM:<DYN>
VPM:<BBD>
VPM:<WBD>
VXX:DLVI0=<+00000>
VXX:DLVI0=<+00001>
VXX:DLVI0=<+00002>
AUU
AUD
OMN
OCU
OCD
OCL
OCR
OAS
OSH
OIX
DZU
DZD
–
–
0
–
–
0
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
63
–
–
1
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
–
Command: <Parameter> Function Callback: <Parameter> Parameter value
Min Max

SPEC FI L E
PT-LB1V
LCD Projector
As of May 2011
SFL11M001
9/10
arameter format
Parameter format Size (Byte) Definition
<pl>
<off on>
<input signal>
<power condition>
<lamp condition>
<acctch>
<color temp>
3 (1 or 2 bytes also
possible when
under control)
1
3
3
1
4
1
Decimal without signs: 0 to 999 (000, 001, 002...999)
Decimal with signs: -99 to +99 (-99...-01, +00, +01, +02...+99)
Callback from the projector is 3 Byte.
0 = off, 1 = on
RG1 = computer 1, RG2 = computer 2, VID = video, SVD = S-Video
000 = power off (standby mode off), 001 = power on (standby mode on)
0 = standby, 1 = lamp on under control, 2 = lamp on,
3 = lamp off under control
Decimal without signs: 0000-9999 hours
0 = low, 1 = normal, 2 = high
Command example
To set the volume to +30, send the command as shown right.
STX AVL : 30 ETX
Start Command Parameter End
NOTE: If a wrong command is received, the projector will send an ER401 command to the computer.
*These commands can be operated in standby mode eco. Other commands shown can not be operated in standby mode eco.
NOTE: When sending commands without parameters, a colon (:) is not necessary.
Status request commands
Command Description Callback
<Parameter>
QPW*
Q$S*
QIN
QAV
QVC
QVT
QVB
QVR
QVS
QWR
QWG
QWB
QHP
QVP
QCP
QDC
QSP
QLG
QXG
QVX:DLVI0
QPM
QFZ
Q$L
QSH
QKS
QTE
Standby power status
Lamp status
Input signal status
Volume adjustment value
Color adjustment value
Tint adjustent value
Brightness adjustment value
Contrast adjustment value
Sharpness adjustment value
White balance: R adjustment value
White balance: G adjustment value
White balance: B adjustment value
Horizontal position adjustment value
Vertical position adjustment value
Clock phase adjustment value
Dot clock adjustment value
Projection method status
On-screen menu language
Wide mode status
Daylight View status
Picture mode status
Freeze status
Lamp run time
AV mute
Keystone correction status
Color temperature adjustment status
Off
On
Auto
Off
Auto
On
Natural
Standard
Dynamic
Blackboard
Whiteboard
<power condition>
<lamp condition>
<input signal>
<pl>
<pl>
<pl>
<pl>
<pl>
<pl>
<pl>
<pl>
<pl>
<pl>
<pl>
<pl>
<pl>
<pl>
<pl>
<0>
<1>
<2>
<+00000>
<+00001>
<+00002>
<NAT>
<STD>
<DYN>
<BBD>
<WBD>
<off_on>
<acctch>
<off_on>
<pl>
<color temp>

SPEC FI L E
PT-LB1V
LCD Projector
As of May 2011
SFL11M001
10/10
Notes on projector placement and operation
The projector uses a high-wattage lamp that becomes very hot during operation. Please observe the
following precautions.
1. Never place objects on top of the projector.
2. Make sure there is an unobstructed space of 500 mm (19-11/16˝) or more around the projector’s
exhaust openings. Also, make sure there is an efficient space for replacing lamp units or detaching
or attaching the air filter.
3. Make sure that nothing blocks the projector’s air intake and exhaust openings. Also, install the pro-
jector so that cool or hot air from other air conditioning equipment does not flow directly toward
the projector’s air intake or exhaust openings.
4. Do not install the projector in an enclosed space. f it is necessary to install it in an enclosed
space, add a separate ventilation system. f ventilation is insufficient, hot air will accumulate at the
intake opening. This may cause the projector’s protective circuit to interrupt projector operation.
Direction of air intake and exhaust
200 mm (7-7/8˝)
or more 500 mm (19-11/16˝) or more 500 mm (19-11/16˝) or more
Operating the projector continuously
1. f the projector is to be operated continuously 10 hours or more, lamp replacement cycle duration
becomes shorter.
2. The lamp replacement cycle duration becomes shorter if the projector is operated repeatedly for short
periods (one hour or less).
Intake
Exhaust
Weights and dimensions shown are approximate. Specifications and appearance are subject to change without notice.
PJLink is a registered trademark, or a trademark application has been filed, in Japan, the United States, and other countries and regions.
This product may be subject to export control regulations. All other trademarks are the property of their respective trademark owners.
