Panasonic NR-BE755ASQA User manual
The smart way of using the refrigerator leads to energy saving.
• Thank you very much for purchasing "Panasonic" Refrigerator.
• Before operating this unit, please read these instructions completely.
• Before using this product, please pay particular attention to the "Safety precautions" for a safe use.
• Please keep operating instructions surely, and read them when you need.
Modelo No
:NR-BE755ASQA
NR-BE755ASAE
NR-BE755ASAS
NR-BE755ASSA
NR-BE755AWSA
Operating Instructions /
Refrigerator-Freezer /
SPECIAL FEATURE /
• INVERTER
According to changes in the inside temperature, the motors run at
different speed. At normal temperature, the motors run at a lower
speed. (Energy saving & lower noise).
When powerful cooling is required, the motors run at a higher speed.
–3–
CONTENTS /
PAGE /
SAFETY PRECAUTIONS
Please be sure to follow
4
PREPARATION
10
HOW TO INSTALL
10
WHEN USING…..
11
PARTS IDENTIFICATION
12
FOOD KEEPING TIPS
13
HOW TO USE THE REFRIGERATOR COMPARTMENT
13
HOW TO USE THE FREEZER COMPARTMENT
15
HOW TO MAKE ICE CUBES
15
DEFROSTING
17
HOW TO TAKE CARE OF YOUR REFRIGERATOR
18
HOW TO REMOVE AND ATTACH INDIVIDUAL COMPONENTS
19
IN THESE CASES
20
IS THIS A FAILURE
22
SPECIFICATIONS
24
How to use
When necessary
Preparation and
checks
–4–
The following explanations are provided for the items you should know to prevent personal injuries and property damages related to the users and other
people.
SAFETY PRECAUTIONS /
▓Do not install the product where water splashes are possible.
Deteriorating electrical insulation may lead to an electrical shock and fire.
▓
▓Do not block the ventilation port of the refrigerator or spaces around it.
Leaked refrigerant may cause a fire and result in an explosion.
. ▓
▓Provide a grounding connection or install a ground-fault interrupter when the product is installed in a moist or watery
location.
Ground leakage by a product malfunction may cause an electrical shock.
• Be sure to contact your distributor when installing a ground connection or ground-fault interrupter.
▓
•
When installing.... /
▓The following expressions are used to distinguish the degree of danger or damage caused when the product is used incorrectly by disregarding
the instructions provided in this manual.
▓
▓
The following symbols and explanations are provided to explain the types of act complied by the user. (Shown below are the examples of
pictograms used)
▓
This expression presumes possibility of death or serious injury.
This pictogram indicates a "Mandatory" item to be performed.
This expression presumes possibility of personal injury or material
damage.
This pictogram indicates a "Prohibited" type of act.
Please be sure to follow
WARNING CAUTION
WARNING /
–5–
For power plugs and cords.... /
When using.... /
▓Do not splash water or liquid detergents on the back of the refrigerator or into the mechanism room at the bottom of the
back side of refrigerator. Splashed water would possibly permeate into electrical parts and cause an accidental fire or other
dangers.
▓
▓When you detect burning smell, remove the power plug to stop operation.
Be careful in order to avoid an electric shock or a fire.
▓
▓Do not connect many plugs to a single outlet by exceeding the rated current or to an outlet other than 220 V a.c. ~ 240 V a.c.
Too many plugs in a single outlet may generate abnormal heat and possible fire.
240 220▓
▓Do not plug or unplug with wet hands. Electric shock is possible.
▓
▓Insert the power plug fully into the outlet.
Incomplete insertion may cause electrical shock and/or fire from overheating.
• Do not use damaged power cords or loose receptacles.
▓
•
▓Remove dust periodically from the power plug.
Dust accumulation on the power plug may cause an insulation failure with humidity and possible fire.
• Unplug the power cord and wipe with dry cloth.
▓
•
▓Do not damage the power cord or power plug.
Do not damage the cord, modify, bring close to a heating device, bend, twist, pull, place a heavy item on, pinch with the refrigerator
or bundle the cord.
Use of a damaged cord or plug leads to an electrical shock, short-circuit or fire.
• Consult with your distributor if you need to repair the power cord or plug.
▓
•
▓Supply cord and plug.
If the supplied cord or plug of the appliance is damaged, it must be replaced by the manufacturer of its service agent or similarly
qualified person in order to avoid a hazard.
▓
WARNING /
–6–
▓This appliance is not intended to be used se by people (including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use
of the appliance by a person responsible for their safety.
▓
▓Children should be supervised to ensure that they do not play with the appliance.
▓
▓When leakage of flammable gas (propane gas, city gas) is detected, do not touch the refrigerator and open the window for
ventilation.
Power plug connection/disconnection operations may cause sparks, which leads to fire, explosion, or burn.
▓
▓Flammable gas is used for insulation in this refrigerator.
When you throw away this unit, please discard it by proper method.
. ▓
▓Removal of the back cover is prohibited except by service personnel.
May cause injury, burn, or electrical shock.
▓
▓Always unplug the power cord when cleaning the refrigerator.
May cause electrical shocks and/or injury.
. ▓
▓Do not place a water container over the refrigerator.
Spilled water may damage insulation of electrical components and cause electricity leakage, fire or electrical shocks.
. ▓
▓Do not store flammable items in the refrigerator.
Benzine, ether, LP gas, paint thinner, adhesive etc may catch fire.
•Tightly cap the alcoholic beverage bottles.
.▓
•
▓Do not hang on the door or ride on the drawer compartment.
Injury is likely by a fallen refrigerator or body parts being pinched.
▓
▓Do not damage the cooling circuit (piping) in the refrigerator body.
. ▓
▓Do not apply water on the body or interior.
Electrical insulation deteriorates and may cause shocks or fire.
▓
▓Absolutely, do not disassemble, repair or modify the refrigerator.
An unexpected fire or movement may cause injuries.
• Consult with your distributor when you need a disassembly/repair.
. ▓
•
When using.... /
WARNING /
–7–
▓Do not place objects that are prone to fall on top of the refrigerator.
The vibration caused by the operation of the refrigerator may cause the object to fall.
. ▓
▓Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
▓
▓Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the
manufacturer.
▓
▓Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type
recommended by the manufacturer.
▓
▓This appliance is intended to be used in household and similar applications such as
•staff kitchen areas in shops, offices and other working environments;
•farm houses and by clients in hotels, motels and other residential type environments;
•bed and breakfast type environments;
•catering and similar non-retail applications.
▓
•
•
•
•
▓Do not store chemicals or scientific specimen.
Home-use refrigerator can not store those requiring a strict control.
▓
▓The insulation blowing gas and refrigerant is flammable. When disposing of the appliance, do so only at an authorized waste
disposal centre. Do not expose to flame.
▓
▓WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
▓
▓WARNING: Do not locate multiple portable socket-outlets or portable power supplies at the rear of the appliance.
▓
▓Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
▓
–8–
▓Do not attempt to dismantle, repair or tamper the refrigerator, otherwise an electrocution, fire or explosion
accident may occur.
▓
▓Since a flammable refrigerant is used, be sure to open the window for ventilation if the Cooling Loop (piping)
is faulted and then contact the Panasonic Service Station; otherwise an electrocution, fire or explosion
accident may occur.
▓
▓The refrigerator should be placed in a well ventilated location.
▓
▓Do not attempt to use mechanical tool or other tool to speed up the defrosting process.
▓
▓Do not damage the refrigerant loop. (Remark: This warning is applicable only for the tools that can be used
by the user to touch the Refrigerant Loop.)
▓
▓Except for the suggested tools, do not use other tools in the Food Refrigerating Compartment.
▓
▓Before moving the Refrigerator, be sure to remove the power plug and then connect the power after
relocating to the designed location securely.
▓
▓If the Refrigerator is damaged, be sure to contact the Panasonic manufacturer or Panasonic authorized
service center to avoid any damages.
▓
▓If the refrigerant circuit is damaged:
- Avoid opening flames and sources of ignition.
- Thoroughly ventilate the room in which the appliance is situated.
WARNING /
–9–
▓If you are discarding the refrigerator, remove the door completely as a safe way against small children being trapped inside.
▓
▓Do not insert your hand into the bottom of the refrigerator.
Inserting your hand during cleaning in the bottom may cause injury by the sheet metal edge.
. ▓
▓Do not slide your hand on the rail and metal edges during interior cleaning.
You may injure yourself.
▓
▓When opening the bottom drawer, do not place your feet too close to the refrigerator.
The drawn compartment may hit your feet top.
. ▓
▓Install the glass shelves securely.
The glass shelf when dropped may break or cause injuries.
▓
▓Do not use the wheels on the bottom when placed on easy-to-mar floor.
The bottom wheels may damage the floor.
▓
▓Do not transport refrigerators in a horizontal position.
Laying a refrigerator horizontally may damage the piping.
. ▓
▓Do not place any protruding item out of the shelf area.
Bottles may drop and cause injuries.
▓
▓When opening a door or other person touching the refrigerator, make sure the moving door not to pinch anyone's finger. The
moving door may hit fingers and cause injuries.
▓
▓Do not eat any smelling or color-changed food.
Rotten food may cause illness.
▓
▓The compressor and the copper pipeline are high-temperature parts. Do not get in touch with them, or you may get burnt.
▓
▓Please, when carrying the appliance, do it with horizontal movements, never tilt or lay the refrigerator.
▓
CAUTION /
–10 –
PREPARATION /
Suitable location for the refrigerator
Install at a location not affected by heat higher
than 38°C or direct sunshine.
38
For minimizing deterioration of cooling power and avoiding wasted
electricity.
Secure heat dissipation spaces
Do not place items over the refrigerator. Secure a space of 2 cm on the
both sides and 10 cm or over the refrigerator. The back surface may be
fitted to the wall.
(Leave a space when vibration noise occurs)
The refrigerator dissipates heat around it for cooling the food inside.
2
10
HOW TO INSTALL /
Turn the adjustable leg to firmly fit on the floor to
prevent vibration or noise. When the floor is covered
with carpet, tatami or vinyl, place a solid board under
the refrigerator to avoid color change by heat.
To prevent the refrigerator from tumbling down due to
an earthquake or shaking of the refrigerator, a nylon
cord or robust string may be tied to the refrigerator on
the lugs on the top of the back side of the refrigerator
and hung to a hook on the wall.
Proper installation will help you get the most use out of your refrigerator.
Install at a low-humidity place, keep ventilation
openings in the appliance enclosure or in the
built-in structure, clear of obstruction.
For suppressing rust generation and avoiding wasted electricity.
more than 10 cm
10
more than 2 cm
2
more than 2 cm
2
–11–
To ensure the refrigerator structure not being affected by an uneven ground, please adjust the level carefully with the fol-
lowing steps.
Step 1:
Ensure the rear feet (left and right) are standing firmly. In
case of unevenness, please shim the suspending portion
until it is firmly supported.
:1
Step 3:
Adjust the left front foot to just contacting the ground.
* Excessively lifting the height of the left front foot
may result in skewed body and slanted door of the
refrigerator.
:3
Step 2:
Adjust the right front foot so that
the refrigerator slants backward
slightly, leaving the roller about
0.5cm above the ground.
(Method: Insert a flat screwdriver
into the gap of the adjustable foot
and turn clockwise, this will move
the adjustable foot downward.)
:2
0.5
WHEN USING….. /
Clean the interior with damp soft cloth.
•
The interior plastic parts may smell in
the beginning but the odor gradually
goes away when the interior gets cold.
•
The interior does not get cold
immediately after turning the power on.
•
The exterior surface of the refrigerator
gets hot in the beginning of use or
when the ambient temperature is high
as in summer, but it is not abnormal.
•
•It requires approximately 12 hours in a normal condition until the interior gets cold.
• It may take more than one day until reaching the set temperature in hot season.
• Refrain from opening the doors until it gets fully cold.
12 •
•
•
Wait more than ten minutes to re-start the refrigerator after you stop it once.
CAUTION /
–12–
PARTS IDENTIFICATION /
ⒶFREEZER COMPARTMENT /
q Ice Tray /
w Ice Box /
e Tray /
r Freezer door shelf /
Ⓑ
REFRIGERATOR COMPARTMENT /
t Chilled case /
y Operating Panel /
u Refrigerator Temperature Control Dial /
i Refrigerator Lamp /
o Tray /
!0 Partition shelf /
!1 Vegetable compartment /
!2 Egg Tray /
!3 Egg case /
!4 Refrigeratore lamp switch /
!5 Small item case /
!6 Free-setting shelf /
!7 Bottle Stopper /
!8 Bottle shelf /
ⒸOTHER /
!9 Adjustable Leg /
▓Regarding replacement of the Refrigerator
lamp
• If the Refrigerator lamp does not work, please
contacts Panasonic service center to check what
problem is.
Do not remove and replace lamp light by yourself.
▓
Ⓐ
Ⓑ
–13 –
FOOD KEEPING TIPS /
▓Smart ideas for storage.
• Leave spaces among foods to help air circulation. Blocking the air flow
will cause warm temperature in the refrigerator compartment.
• Cool hot dishes to room temperature before placing them in your refrigerator.
• Cover juicy foods with tight lids, plastic film or foil.
• Do not keep the door open any longer than necessary, particularly in hot,
humid weather.
• Do not put carbonated liquids (fizzy drink, etc.) in the freezer compartment
as they may burst.
• Do not give children lollipops direct from the freezer compartment. They
may burn their lips by "freezer burn" due to low temperature.
▓
•
•
•
•
•
•
HOW TO USE THE REFRIGERATOR COMPARTMENT
• For temporary storage of immediately used items.
• For storing drinks.
•
•
[Food examples]
• Beer cans
• Juice / milk / pudding
• Tofu / raw eggs
• Jelly
• Vegetables in sealed tray
•
•
•
•
•
Request & Notice:
• Temperatures in the Fine Chilled case can be
very low. It is not suitable for storing puddings,
bean curd or tropical fruits.
• Please put vegetable and fruit into Vegetable Case.
•
Vegetable Case /
Egg Tray /
• For 10 eggs. (2 PCS)
10 •
Vegetables or fruits placed at the Glass Shelf PC, especially those near the vent
port, are prone to freeze. Avoid doing this as far as you can.
CAUTION /
CAUTION /
–14–
Request & Notice:
Food may be frozen in the following conditions.
•
either "MED" or " 1 ", MIN"
•
When placing watery food (tofu etc.) and eggs near the cold air
7 •
•
The thermostat, specially designed for this refrigerator, functions to maintain the optimum inside condition for food storage at
the "MED" dial setting, regardless of ambient temperature variations. Besides, in order to meet your individual requirements,
the refrigerator temperature as you desire can be obtained by adjusting the temperature control dials. Lower temperature can
be obtained by turning the dial clockwise on controls.
Temperature control of the refrigerator compartment
When the interior odor bothers you
Food items that tend to transfer odors
Garlic cloves, minced onion, shallots, dry foods, natto, miso, beef, pickles, sardines, kimchi, jiao-zi, etc.
• Be cautious with fermented foods.
•
Remove the odor-generating item or store in a sealed container.
–15 –
HOW TO USE THE FREEZER COMPARTMENT
FREEZER COMPARTMENT /
• For storing frozen foods.
• For storing frozen desserts.
• For storing dried foods. Frozen storage is suited for tealeaves, coffee
or seaweed that are deteriorated by moisture.
•
•
•
[Food examples]
• Frozen foods
• Lollipops – Ice cream
• Sherbet
• Tealeaves
• Seaweed, etc.
Do not place the food over capacity.
The unseated top case causes incomplete closure of the drawer
and malfunctions such as frosting in the compartment or failure
in freezing.
(Be cautious with these items)
• Long items
• Tall items in bags.
• Excessive quantity of items in plastic bags.
• Tall items in boxes.
•
•
•
HOW TO MAKE ICE CUBES /
NOTE
If you put wet ice cubes in the ice server, they may stick to one another.
Ҝቢ
Water level line
Pour water into the ice tray to the water
level line and put it in the ice tray rail.
Twist the ice tray and let the ice drop as
illustrated.
–16 –
Request & Notice:
• When the green light is blinking after pressing the "QUICK
FREEZING" button, the refrigerator is in a defrosting process.
Automatic rapid freezing will start after defrosting.
Tips for good freezing /
Thin and small
Cutting in thin and small pieces
and storing in small packages is
convenient when using.
Fully seal the food
For preventing drying during
storage and transfer of odors.
Storing cooked foods while still warm would adversely affect
other items.
Do not refreeze
Use up the entire quantity once thawed. Refreezing
substantially deteriorates taste and nutrition and it's also
unhygienic.
The temperature can be adjusted for MIN-MED-MAX, levels indicating operation and cool level.
Indicates a higher temperature between -15°C ~ -17°C
-17-15
Indicates a lower temperature between -19°C ~ -22°C
-22-19
Temperature control of the freezer /
• The temperature for freezer compartment can be
set in Nine steps,more detailed than as "MIN" and
"MED"and"MAX" as shown on the table.
1. Set"MIN" with the "FREEZER" button.
2. Press the "FREEZER" button (for 10 Seconds).
3. Set by pressing the "FREEZER" button.
To reset the setting,repeat steps 1,2 and 3.
1
102
3
.321
Remark:
When operating the refrigerator for the first time, after connecting the plug, adjust the temperature to center position in each control and leave
it for 24 hours for an effective cooling operation. After that, adjust the temperature as you prefer. If you want to save energy, do not adjust the
temperature lower than the actual operating condition.
24
Cooling Level
LED display at "FREEZER" botton
MIN
MED
MAX
Minimum /
Middle /
Maximum /
●
● ○
● ●
○ ●
●
● ○
● ●
○ ●
●
●Lighting / ○Blinking /
–17–
When the refrigerator is handled in a slanted position, ensure the defrosted water is drained out, so that no water will spill out when moved.
DEFROSTING /
You never have to defrost the compartment since your refrigerator is designed to defrost itself completely and automatically.
Defrost water flows to the collector pan where it is forcibly evaporated into the air.
※How to drain the defrosted water. / .
Draining device /
11. Turn the drainage cap counterclockwise to remove it.
1
22. Use a sharp tool with forward rotation to open up the draining hole. (Only required for the
first-time, the defrosted water will drain out immediately after opening up.)
2
33. Let the water drain from the part marked with arrows. Collect the water with a container so it
does not wet the floor.
3
44. After draining, remember to re-install the cover. (Turn clockwise)
4
–18–
HOW TO TAKE CARE OF YOUR REFRIGERATOR
Since the function of the refrigerator is to store food, regular cleaning is advised. /
.
How to take care of your
Refrigerator
Wipe with cloth soaked with lukewarm water.
When a surface spot does not come off, use a neutral kitchen cleaning product and then wipe off with
the cloth soaked with lukewarm water and tightly wringed.
Operation panel / • Wipe off with soft dry cloth.
※If press any keys which change setting while wiping operation panel,
please reset setting.
•
※
Door surface / • Wipe off with damped soft cloth.
※This product is high gross metal, please avoid cleaning it with rough
face of cleaning cloth and contact with sharp object to prevent
surface damage. (such as metal, magnet, etc.)
※
Inspection after caring
Use a dry or tweaked-dry cloth to clean, preventing water or impurities from residing in the refrigerator, so as
to prolong the service lifespan of steel sheets of the refrigerator.
1. Are there any damages on the power cord?
2. Is the power plug hot?
3. Is the power plug securely inserted into the outlet ?
In case of any doubt, please contact your dealer immediately.
Panasonic Service Station.
1
2
3
▓Make sure to unplug the power cord before starting.
▓Do not handle the power plug with wet hands.
May cause injuries or electrical shocks.
▓Do not splash water on the exterior or interior surface.
May cause a fire or electrical shocks.
▓Periodically remove the dust on the power plug.
Dust accumulation on the power plug leads to insulation failure by
moisture and may cause a fire.
• Unplug the power cord and wipe with dry cloth
▓
▓
▓
▓
Cleaning fluids shown as alkaline or acids in the
property column of kitchen cleaning agent.
• Plastic parts may break with the agent.
Tooth paste, powder soap, petroleum, boiling water,
scrubber, acids, benzine, paint thinner, alcohol etc.
• Deteriorates the surface, coating or plastic parts.
When using a chemical wiper, comply with the
cautions given with the product.
Do not use the following items.
▓Do not insert your hand underneath the refrigerator.
▓Do not rub rails or metal edges strongly.
Injuries are likely.
▓
▓
CAUTION /
WARNING /
–19–
HOW TO REMOVE AND ATTACH INDIVIDUAL COMPONENTS
Washable / Partes Internas /
Vegetable Case / Rack /
• Hold the rack with hands and lift it up
vertically, this will remove the rack.
Tempered Glass Shelf /
Open the freezer preserve door to a proper
position (as shown on the figure A)
Pull the tempered glass shelf toward you.
• Dirty gasket leads to damages and cold air leakage.
•
Immediately when soiled
The door gasket (especially the bottom portion) can be damaged by
spilled milk, juice, etc.
To protect the gasket, it should be kept clean at all times.
Any spilled liquid will collect in the gap under the bottle rack. Then, if it
overflows, it will collect in the gap located at the lower front section of
the inner wall.
Be sure to wipe off such spillage before it overflows from these gap.
To protect the door gasket /
Door Gasket
Door Gasket
Top of refrigerator
Pull out the drawer to the outer most
position.
Slightly lift up the drawer, then pull
it out.
.
–20–
Problem's corresponding measures /
Preserve Door Open
Indicator
• In case the freezer preserve door is opened exceeding the period of time
as listed below, an audible alarm will sound, indicating the door is open,
together with light-up indicators as depicted below:
* The door is open for more than 1 minute: the buzzer on the “external
* The door is open for more than 3 minute: the buzzer on the “external
reaction; the indicator will be out when the door is closed.
•
43
5
QUICK FREEZING
indicator flashes in
green
• When the QUICK FREEZING indicator flashes in green, it indicates the Quick
Freezing is in a standby resulting from one of the following conditions:
* The freezer is defrosting –
Press the QUICK FREEZING button, and the QUICK FREEZING function will
be activated immediately after the completion of the defrosting process.
•
QUICK FREEZING
indicator lights in red
• If the QUICK FREEZING indicator lights in red when the freezer preserve
door is open not exceeding 5 minutes, you need to call the Panasonic service
station or the dealer for a repair.
5 •
Four indicators on the
Operation Panel light
up sequentially
• When the 4 indicators on the Operation Panel light up sequentially
(MAX, MED, MIN, QUICK FREEZING, MAX), it means the system is
in the service mode (functional detection check). The service mode does
not affect the normal operation of the refrigerator, do not worry.
•
IN THESE CASES /
QUICK FREEZING
QUICK FREEZING
QUICK FREEZING
This manual suits for next models
5
Other Panasonic Refrigerator manuals
Panasonic
Panasonic NR-D513XZ User manual
Panasonic
Panasonic NR-YW590Y User manual
Panasonic
Panasonic NR-BW414MN User manual
Panasonic
Panasonic NR-BX41BV User manual
Panasonic
Panasonic NR-C290GH-W3 User manual
Panasonic
Panasonic NR-A19KN-W7 User manual
Panasonic
Panasonic NR-BC572VSAE User manual
Panasonic
Panasonic NR-AH143S User manual
Panasonic
Panasonic NR-A191GW User manual
Panasonic
Panasonic NR-BS60MSX1 User manual
Panasonic
Panasonic NR-D511XS User manual
Panasonic
Panasonic NR-BN30PGW User manual
Panasonic
Panasonic NR-BS734MSSA User manual
Panasonic
Panasonic NR-BC36MS Series User manual
Panasonic
Panasonic NR-B32SX1 User manual
Panasonic
Panasonic NR-B32SW2 User manual
Panasonic
Panasonic NR-BY608X User manual
Panasonic
Panasonic NRA4UT1K - TRUCK REFRIGERATOR Assembly instructions
Panasonic
Panasonic NR-AF172SNAE User manual
Panasonic
Panasonic NRC387BI User manual
