Panasonic WV-NP304 User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
No model number suffix is shown in this manual.
LOCK
WV-NP304
Network Camera
Installation Guide
Model No. WV-NP304

2
The lightning flash with arrow-
head symbol, within an equilater-
al triangle, is intended to alert the
user to the presence of uninsu-
lated "dangerous voltage" within
the product's enclosure that may
be of sufficient magnitude to con-
stitute a risk of electric shock to
persons.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and mainte-
nance (servicing) instructions in
the literature accompanying the
appliance.
WARNING:
• This apparatus must be earthed.
• To prevent fire or electric shock hazard, do not
expose this apparatus to rain or moisture.
• The apparatus should not be exposed to drip-
ping or splashing and that no objects filled with
liquids, such as vases, should be placed on the
apparatus.
• All work related to the installation of this prod-
uct should be made by qualified service per-
sonnel or system installers.
• The connections should comply with local elec-
trical code.
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC
SHOCK DO NOT OPEN
The serial number of this product may be found
on the surface of the unit.
You should note the model number and serial
number of this unit in the space provided and
retain this book as a permanent record of your
purchase to aid identification in the event of
theft.
Model No.
Serial No.
NOTE: This equipment has been tested and
found to comply with the limits for a Class A digi-
tal device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference when the
equipment is operated in a commercial environ-
ment. This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the instruc-
tion manual, may cause harmful interference to
radio communications.
Operation of this equipment in a residential area
is likely to cause harmful interference in which
case the user will be required to correct the inter-
ference at his own expense.
FCC Caution: To assure continued compliance,
(example - use only shielded interface cables
when connecting to computer or peripheral
devices). Any changes or modifications not
expressly approved by the party responsible for
compliance could void the user’s authority to
operate this equipment.
For U.S.A
For U.S.A
This Class A digital apparatus complies with
Canadian ICES-003.
For Canada

3
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
S3125A

4
Limitation of Liability
THIS PUBLICATION IS PROVIDED "AS IS"
WITHOUT WARRANTY OF ANY KIND,
EITHER EXPRESS OR IMPLIED, INCLUDING
BUT NOT LIMITED TO, THE IMPLIED WAR-
RANTIES OF MERCHANTABILITY, FITNESS
FOR ANY PARTICULAR PURPOSE, OR
NON-INFRINGEMENT OF THE THIRD
PARTY’S RIGHT.
Disclaimer of Warranty
IN NO EVENT SHALL MATSUSHITA ELEC-
TRIC INDUSTRIAL CO,.LTD. BE LIABLE TO
ANY PARTY OR ANY PERSON, EXCEPT FOR
REPLACEMENT OR REASONABLE MAINTE-
NANCE OF THE PRODUCT, FOR THE
CASES, INCLUDING BUT NOT LIMITED TO
BELOW:
(1) ANY DAMAGE AND LOSS, INCLUDING
WITHOUT LIMITATION, DIRECT OR
INDIRECT, SPECIAL, CONSEQUENTIAL
OR EXEMPLARY, ARISING OUT OF OR
RELATING TO THE PRODUCT;
(2) PERSONAL INJURY OR ANY DAMAGE
CAUSED BY INAPPROPRIATE USE OR
NEGLIGENT OPERATION OF THE USER;
(3) UNAUTHORIZED DISASSEMBLE,
REPAIR OR MODIFICATION OF THE
PRODUCT BY THE USER;
(4) INCONVENIENCE OR ANY LOSS ARIS-
ING WHEN IMAGES ARE NOT DIS-
PLAYED, DUE TO ANY REASON OR
CAUSE INCLUDING ANY FAILURE OR
PROBLEM OF THE PRODUCT;
(5) ANY PROBLEM, CONSEQUENTIAL
INCONVENIENCE, OR LOSS OR DAM-
AGE, ARISING OUT OF THE SYSTEM
COMBINED BY THE DEVICES OF THIRD
PARTY;
(6) ANY CLAIM OR ACTION FOR DAM-
AGES, BROUGHT BY ANY PERSON OR
ORGANIZATION BEING A PHOTO-
GENIC SUBJECT, DUE TO VIOLATION
OF PRIVACY WITH THE RESULT OF
THAT SURVEILLANCE-CAMERA'S PIC-
TURE, INCLUDING SAVED DATA, FOR
SOME REASON, BECOMES PUBLIC OR
IS USED FOR THE PURPOSE OTHER
THAN SURVEILLANCE;
(7) LOSS OF REGISTERED DATA CAUSED
BY ANY FAILURE.
THIS PUBLICATION COULD INCLUDE
TECHNICAL INACCURACIES OR TYPO-
GRAPHICAL ERRORS. CHANGES ARE
ADDED TO THE INFORMATION HEREIN, AT
ANY TIME, FOR THE IMPROVEMENTS OF
THIS PUBLICATION AND/OR THE CORRE-
SPONDING PRODUCT (S).

5
Preface
The network camera WV-NP304 is designed to operate using a PC on a network (10BASE-
T/100BASE-TX).
By connecting to a network (LAN) or the Internet, images and audio from the camera can be
monitored on a PC via a network.
Note:
• It is necessary to configure the network settings of the PC and its network environment to
monitor images and audio from the camera on the PC. It is also necessary that a web
browser is installed on the PC.
Features
Introduction of 1.3 mega pixel progressive
scan CCD
The introduction of the progressive scan type
of CCD has achieved excellence in perform-
ance for motion images and high resolution.
Adaptive black stretch
This function automatically detects dark and
less viewable portions of a subject and
makes the portions brighter.
Important:
• The use of the adaptive black stretch
function may increase noise at the dark
portions of the subject. The use of this
function may also emphasize the dark-
ness or brightness at the border between
the dark and bright portions compared
with other dark or bright portions.
JPEG/MPEG-4 dual encode
MPEG-4 images can be monitored while
monitoring JPEG images.
Focus assist function equipped
This function informs users of an optimal
focal point at focus adjustment.
No special power supply and cable instal-
lation required (Power over Ethernet)
Power can be supplied to the camera and
images/audio transmitted on a single LAN
cable by connecting to PoE-compatible net-
work devices. Special installation of a power
supply for the camera is not required.
Interactive communication with audio is
available
By using the audio output connector and the
microphone in connector, receiving audio
from the camera on a PC and transmitting
audio from the PC to the camera are avail-
able.
Motion detection function
When a motion is detected, this product will
take the following actions.
• Outputs alarm signals
• Transfers images to the FTP server
• Notifies by mail
• Saves images on the SD memory card

6
Note:
• The motion detector is not a function
dedicated to prevent theft or fire, etc. No
warranty is provided for any damage and
loss resulting in use of this function.
SD memory card slot
Images can be recorded on an optional SD
memory card both automatically (when
images fail to transmit using the FTP periodic
transmission function) and manually. It is
possible to play images saved on the mini
SD memory card using a web browser or to
download images displayed on a web brows-
er.
Note:
• Compatible SD memory card
Performance with this camera has been
checked by using Panasonic’s SD mem-
ory cards (64 MB, 128 MB, 256 MB, 512
MB, 1 GB, and 2 GB).
SD High Capacity (SDHC) card is not
compatible with this camera.
Installation on a ceiling or a wall is avail-
able
When using an optional mount bracket,
mounting on a ceiling or mounting on a wall
is available.

7
About These Operating Instructions
There are 3 sets of operating instructions for the WV-NP304 as follows.
• Installation guide (book, these operating instructions)
• Network operating instructions (PDF)
• Setup instructions (PDF)
The "Installation guide" contains descriptions of how to install and connect this camera, and of
how to perform the required network settings.
Refer to the "Network operating instructions (PDF)" and the "Setup instructions (PDF)" on the
provided CD-ROM for descriptions of how to perform the camera settings and how to operate
this camera. Adobe®Reader®is required to read the network operating instructions (PDF) and
the setup instructions (PDF).
System Requirements for a PC
CPU Pentium®4 2.4 GHz or faster (A 3.0 GHz CPU or faster CPU is
required when using Microsoft®Windows Vista®.)
Memory 512 MB or more (A minimum of 1 GB memory is required when
using Microsoft®Windows Vista®.)
Network interface 10/100 Mbps Ethernet port x1
Audio interface Sound card (when using the audio function)
Monitor Resolution: 1 024 x 768 pixels or more
Color: 24-bit True color or better
OS Microsoft®Windows Vista®Business (32-bit)
Microsoft®Windows®XP Home Edition SP2*
Microsoft®Windows®XP Professional SP2*
Web browser Windows®Internet Explorer®7.0
* Microsoft®Internet Explorer®6.0 SP2 is required when using
Microsoft®Windows®XP Home Edition SP2 or Microsoft®
Windows®XP Professional SP2.
Other CD-ROM drive: It is necessary to read the network operating
instructions and use the software on the provided CD-ROM.
DirectX®9.0c or later
Adobe®Reader®: It is necessary to read the operating instruc-
tions on the provided CD-ROM.
Notes:
• When using a PC that does not meet the above requirements, displaying of images may
become slow or the web browser may become inoperable.
• Audio may not be heard if a sound card is not installed on a PC. Audio may be interrupted
depending on the network environment.
• Refer to "Notes on Vista®" (PDF) for further information about system requirements for a PC
and precautions when using Microsoft®Windows Vista®.
• Use Microsoft®Windows Vista®when operating in an IPv6 network.

8
Trademarks and Registered Trademarks
• Microsoft, Windows, Windows Vista,
Internet Explorer, ActiveX and DirectX
are either registered trademarks or trade-
marks of Microsoft Corporation in the
United States and other countries.
• Intel and Pentium are trademarks or reg-
istered trademarks of Intel Corporation or
its subsidiaries in the United States and
other countries.
• Adobe and Reader are either registered
trademarks or trademarks of Adobe
Systems Incorporated in the United
States and/or other countries.
• SD logo is a trademark.
• Other names of companies and products
contained in these operating instructions
may be trademarks or registered trade-
marks of their respective owners.
Network Security
As you will use this product connected to a network, your attention is called to the following
security risks.
1. Leakage or theft of information through this product
2. Use of this product for illegal operations by persons with malicious intent
3. Interference with or stoppage of this product by persons with malicious intent
It is your responsibility to take precautions such as those described below to protect yourself
against the above network security risks.
• Use this product in a network secured by a firewall, etc.
• If this product is connected to a network that includes PCs, make sure that the system is
not infected by computer viruses or other malicious entities (using a regularly updated anti-
virus program, anti-spyware program, etc.).
• Protect your network against unauthorized access by restricting users to those who log in
with an authorized user name and password.
• Apply measures such as user authentication to protect your network against leakage or
theft of information, including image data, authentication information (user names and
passwords), alarm mail information, FTP server information and DDNS server information.
• Do not install the camera in locations where the camera or the cables can be destroyed or
damaged by persons with malicious intent.

9
CONTENTS
Important Safety Instructions ........................................................................................................3
Limitation of Liability ......................................................................................................................4
Disclaimer of Warranty ..................................................................................................................4
Preface ..........................................................................................................................................5
Features ........................................................................................................................................5
About These Operating Instructions ..............................................................................................7
System Requirements for a PC .....................................................................................................7
Trademarks and Registered Trademarks .....................................................................................8
Network Security ...........................................................................................................................8
Precautions .................................................................................................................................10
Major operating controls and their functions ................................................................................12
Precautions for installation ..........................................................................................................13
Lens mounting .............................................................................................................................15
Adjustment of angular field of view and focus .............................................................................17
Installation ...................................................................................................................................19
Connection ..................................................................................................................................23
Insert/remove an SD memory card .............................................................................................27
Configure the network settings ....................................................................................................28
Troubleshooting ..........................................................................................................................30
Specifications ..............................................................................................................................31
Standard Accessories .................................................................................................................33

Cleaning the lens
Use a lens cleaning paper (used to clean
camera lenses or lenses of spectacles).
When using solvent, use an alcohols solvent.
Do not use a thinner or a glass cleaner.
Refresh interval
Image refresh interval may become slow
depending on the network environment, PC
performance, shooting subject, access traf-
fic, etc.
SD memory card
• When insert an SD memory card into the
SD memory card slot, turn the power of
the camera off. Otherwise, it may cause
malfunction or damage data recorded on
the SD memory card.
Refer to page 27 for descriptions of how
to insert/remove an SD memory card.
• When using an unformatted SD memory
card, format it using this camera.
Recorded data on the SD memory card
will be deleted when formatted.
If using an unformatted SD memory card
or using an SD memory card formatted
with other device, the camera may not
work properly or performance deteriora-
tion may be caused.
Refer to the setup instructions (PDF) for
descriptions of how to format an SD
memory card.
• It is recommended to use Panasonic’s
SD memory cards (64 MB, 128 MB, 256
MB, 512 MB, 1 GB, and 2 GB) since they
have tested and confirmed full compati-
bility with this camera.
If another SD memory card is used, the
camera may not work properly or per-
formance deterioration may be caused.
10
Precautions
To continue using with stable perform-
ance
Parts of this product may deteriorate and it
may shorten the lifetime of this product when
using in locations subject to high tempera-
tures and high humidity.
(Recommended ambient temperature: 35°C
or below)
Do not expose the product to direct heat
such as from a heater.
Handle this product with care.
Do not strike or shake, as this may damage
the product. It may cause a malfunction.
About the PC monitor
When displaying the same image on the CRT
PC monitor for a long time, the CRT PC moni-
tor may be damaged. It is recommended to
use a screen-saver.
When an error is detected, the camera will
reboot automatically.
This camera will reboot when detecting an
error caused by any reason. The camera will
be inoperable for around 30 seconds after
the reboot just as when the power is turned
on.
Cleaning the camera body
Turn the power off when cleaning the cam-
era.
Otherwise, it may cause injury.
Do not use strong abrasive detergent when
cleaning the camera body.
Otherwise, it may cause discoloration.
When using a chemical cloth for cleaning,
read the caution provided with the chemical
cloth product.
When the dirt is hard to remove
Use a mild detergent and wipe gently.
Then, wipe the detergent completely off with
a dry cloth.

11
Code labels
Retain these labels for future reference.
The codes on the label will be requested
when you contact the service station.
It is recommended to paste one of the labels
onto the CD-ROM case.
Discoloration on the CCD color filter
When continuously shooting a bright light
source such as a spotlight, the color filter of
the CCD may have deteriorated and it may
cause discoloration.
Even when changing the fixed shooting
direction after continuously shooting a spot-
light for a certain period, the discoloration
may remain.
Do not aim the camera at strong light
sources.
A light source such as a spot light causes a
blooming (light bleeding) or a smear (vertical
lines).
Safety wire
The safety wire holder is provided on the top
of the camera. To prevent the camera from
dropping that may cause accidental injury,
attach one end of a safety wire (locally pro-
cured) to the safety wire holder of the camera
and the other end to a locally procured safety
wire holder (bracket, etc.) to be installed on
the foundation part of the building.
MPEG-4 Visual patent portfolio license
This product is licensed under the MPEG-4
Visual patent portfolio license for the person-
al and non-commercial use of consumer for(i)
encoding video in compliance with the
MPEG-4 Visual Standard ("MPEG-4 Video")
and/or(ii) decoding MPEG-4 Video that was
encoded by a consumer engaged in a per-
sonal and non-commercial activity and/or
was obtained from a video provider licensed
by MPEG LA to provide MPEG-4 Video. No
license is granted or shall be implied for any
other use. Additional information including
that relating to promotional, internal and com-
mercial uses and licensing may be obtained
from MPEG LA, LLC.
See http://www.mpegla.com.
Smear Bright subject
Blooming

12
Major operating controls and their functions
LOCK WV-NP304
INITIAL SET
LOCK WV-NP304
INITIAL SET
SD memory card cover
SD memory card slot
[INITIAL SET] button
Flange-back ring fixing screw
qPower indicator
wSD memory card error indicator/
Focus assist indicator
eFocus assist button
rLink indicator
tNetwork connector
yAccess indicator
uMonitor out connector
iExternal I/O terminals
oMicrophone in connector
!0 24V AC/12V DC Power cable terminal
!1 Audio out connector
About the [INITIAL SET] button
Turn on the power of the camera while holding down the button, and wait for around 5 seconds
without releasing this button. Wait another 30 seconds after releasing the button. The camera
will restart and the settings including the network settings will be reset to the default.
Flange-back adjustment ring
Before adjusting the flange-back
length, adjust the lens first. Refer to
page 16 for how to adjust the lens.
FOCUS
ASSIST LINK
POWER
AUDIO OUT MIC IN
EXT I/O
1 2 3 4
C B A
MONITOR OUT
SD
CARD
12V IN
24V IN
ACT
100BASE-T/
100BASE-TX
r
t
y
q
w
e
!1 !0 oi u
■Rear View
■Front/Side View

13
Precautions for installation
All work related to the installation of this
product should be made by qualified serv-
ice personnel or system installers.
Use this product for indoor use only.
Do not expose this product to direct sunlight
for hours and do not install the product near
a heater or an air conditioner. Otherwise, it
may cause deterioration, discoloration and
malfunction. Keep this product away from
water.
Avoid installing in the following locations.
• Locations where it may get wet from rain
or water splash
• Locations where a chemical agent is
used such as a swimming pool
• Locations subject to steam and oil smoke
such as a kitchen
• Locations near flammable gas or vapor
• Locations where radiation or x-ray emis-
sions are produced
• Locations where it may be damaged by
briny air such as seashores
• Locations where the temperature is not
between –10 °C - +50 °C {14 °F - 122 °F}
• Locations subject to vibrations (This
product is not designed for on-vehicle
use.)
• Locations subject to condensation as the
result of severe changes in temperature
Be sure to remove this product if it is not
in use.
Before starting installation
• Use the camera mount bracket shown on
page 22 to mount the camera.
• When installing the camera and the cam-
era mount bracket on a ceiling/wall, use
the screws listed on page 21. Screws are
not provided with this product. Prepare
them after considering the total weight,
the material and strength of the area
where the camera is to be installed.
• The installing place shall be sufficiently
reinforced and anchors/screws to be
used shall be strong enough for the
installation.
• Do not install the camera on a plaster
board or on a wood board since they
don’t have enough strength for installa-
tion.
When tightening fixing screws
• Firmly tighten screws that are suited to fix
with the material and strength of the area
where the camera is to be installed.
• Do not use a powered screw driver.
Otherwise, it may damage the camera.
• Tighten screws firmly. After tightening
screws, check with eyes if the camera is
fixed firmly.
Safety wire
When using a locally procured safety wire to
prevent the camera from dropping, deter-
mine the installing place after considering
possibilities of injury that may be caused by
the camera mount bracket if it is damaged.
When using a safety wire, adjust the length to
stretch the wire with tension.
Adjustment of the tilting angle
Before adjusting the tilting angle of the cam-
era, make sure that the screws of the camera
mount bracket are loosened. Failure to do so
may damage both the camera and the cam-
era mount bracket. Tighten the screws firmly
after adjusting the tilting angle of the camera.
Radio disturbance
When this product is used near a TV/radio
antenna, or a strong electric field or magnetic
field (such as near a motor, a transformer or
power lines), images may be distorted and
noise may be caused.
PoE (Power over Ethernet)
Use a PoE hub/device that is compliant with
IEEE802.3af standard.

14
Router
When connecting this product to the Internet,
use a broadband router with the port for-
warding function (NAT, IP masquerade).
Refer to the setup instructions (PDF) for how
further information about the port forwarding
function.

15
Mount the lens by rotating it clockwise slowly. Then, connect the lens cable to the ALC lens
connector of the camera.
Optional lens
Lens type Model no.
ALC lens for 1/3-inch type CCD cameras WV-LZA62/2
2x varifocal (high resolution)
Other lenses for 1/3 inch CCD cameras can be mounted on this camera. However, high resolu-
tion scanning of this camera may not be fully used for scanning of "1 280 x 960".It is recom-
mended to use a dedicated high-resolution lens when shooting a dark subject with the aperture
opened.
How to use a varifocal lens
The following are descriptions of how to adjust a 2x varifocal
lens. Method of adjustment may be different depending on
the lens in use. Refer to the operating instructions of the lens
in use for further information.
1. Loosen the zoom lock screw and rotate to the "T" end.
2. Set the focus ring to near the "F" end.
3. Focus on a subject which is located around 10 m away
or further to adjust the flange-back length using flange-
back adjustment ring.
Important:
• Check if it is possible to focus on a subject which is located around 1.2 m away by rotating
the focus ring while setting the zoom lock screw to the "W" end.
T
W
Flange-back adjustment ring
Zoom lock screw
Focus ring
ALC lens connector
Within ø20 mm
CS-mount: Less than 8 mm
w
F
N
W
T
q
Focus ring
Zoom lock screw
Lens mounting

16
4. Loosen the zoom lock screw, and then move the angular field of
view between "TELE" and "WIDE". Tighten the zoom lock screw
after moving the angular field of view.
5. Press the focus assist button, and then rotate the focus ring to
focus on a subject appropriately.
Important:
• To change the angular field of view by moving the zoom ring, also move the focus ring to
adjust the focus coasely.
How to use a fixed-focus lens
When using a fixed-focus lens featured the focus adjustment, adjust the flange-back length
after setting the lens focus to the "FAR" end.
Before adjusting the flange-back length, make sure that the flange-back ring fixing screw is
loosened. Tighten the fixing screw after adjusting the flange-back length.
Recommended tightening torque: 0.05 N·m {0.5 kgf·cm}
Important:
• Do not tighten the flange-back ring fixing screw with excessive force. It may strip threads
of the screw and may result in out of focus subjects.
t
F
N
W
T
r

17
Angular field of view and focus can be adjusted coasely according to the distance between
the camera and a subject. Adjust angular field of view and focus while determining the shoot-
ing direction.
zLoosen the zoom lock screw, and then adjust the angular field of view by rotating the zoom
lock screw. Move the focus coarsely by rotating the focus ring.
xTighten the zoom lock screw.
cPress the focus assist button.
→The "FOCUS ADJUSTMENT" screen appears.
The focus assist function provides optimal adjustment.
vMove the focus ring to near the focal point to automatically register the optimal focal point
as the "PEAK HOLD" value (higher value for closer to the focal point).
bMove the focus ring to display the value of the current focus state at "INDICATOR". Adjust
the focus ring to bring the value of "INDICATOR" close to the value of "PEAK HOLD".
nWhen the focal point is obtained, highlighted "BEST FOCUS" appears at the lower right
position.
mPress the focus assist button again to exit from the "FOCUS ADJUSTMENT" screen (or wait
for approx. 3 minutes to automatically terminate).
LOW HIGH
.......|............
↑
FOCUS ADJUSTMENT
INDICATOR 775 BEST
PEAK HOLD 780 FOCUS
Loosen Tighten
T
W
Focus ring
Zoom lock screw
Adjustment of angular field of view and focus

18
Note:
• If the angular field changed during adjustment, press the focus assist button to exit from
the "FOCUS ADJUSTMENT" screen once (because change in the angular field causes
change in the values of "PEAK HOLD" and "INDICATOR").After adjustment of angular field,
conduct the procedure from step 3.
Important:
• If a subject is applicable to the following, press the focus assist button again to exit form
the "FOCUS ADJUSTMENT" screen or obtain an optimal focal point while viewing the
image.
• Frequently moving subject
• Subject with remarkable illuminance change
• Subject with low illuminance
• Too bright or reflective subject
• Subject through a window
• Place where the lens easily becomes dirty
• Subject with less contrast such as white wall
• Subject with remarkable depth
• Subject with heavy flicker
• Subject with horizontally parallel lines such as a shutter

Attach a safety wire
The following is a safety wire attachment example. Procure an appropriate safety wire kit
according to the installing place.
Refer to the operating instructions of the safety wire kit in use together with this installation
guide when attaching a safety wire.
Important:
• To prevent the camera from dropping that may cause accidental injury, attach a safety
wire between the camera and the installing place. Contact your dealer for attachment of a
safety wire.
When installing on a ceiling
<Required camera mount bracket and safety wire kit>
• Camera mount bracket: WV-7010A
• Safety wire kit: WV-Q141
zDetach the tripod mount base from the camera.
xFix the tripod mount base and the safety
wire attachment bracket for ceiling
mount (provided) using the fixing screw.
Use the removed screw (used to fix the
tripod mount base).
When a screw other than the removed
screw (with a different height) is used, it
may result in drop or damage of the
camera.
Recommended tightening torque: 0.39
N·m {4 kgf·cm}
cAttach the two safety wires to the safety wire attachment holes (front/rear).
qPass the loop end of the safety wire through the safety wire attachment hole.
wHook the loop end of the safety wire on the safety wire hook.
19
Safety wire attachment hole
Safety wire Safety wire hook
Installation
T
Tripod mount base
Fixing screw
Safety wire
attachment
bracket for ceiling
mount (provided)
Safety wire
attachment hole
(rear)
Safety wire
attachment hole
(front)

xAttach the safety wire to the safety wire attachment hole.
qPass the loop end of the safety wire through the safety wire attachment hole.
wHook the loop end of the safety wire on the safety wire hook.
When installing on a wall
<Required camera mount bracket and safety wire kit>
• Camera mount bracket: WV-831
• Safety wire kit: WV-Q140
zAttach the safety wire attachment bracket for wall mounting (provided) to the screw hole
for the camera mount bracket using the fixing screw (provided).
Important:
• Use the provided screw to attach the
safety wire attachment bracket for wall
mounting.
When a screw other than the removed
screw (with a different height) is used, it
may result in drop or damage of the
camera.
Recommended tightening torque: 0.39
N·m {4 kgf·cm}
20
T
W
Safety wire attachment hole
* Do not attach the
safety wire here.
Screw hole for the
camera mount
bracket
Fixing screw (provided)
Safety wire
attachment bracket
for wall mount
(provided)
Safety wire attachment hole
Safety wire
Safety wire hook
