Panasonic Quintrix TX--25LD4C/Z User manual

TQB8E2629---eng
Operating
Instructions
Colour Television
TX-- 25LD4C/Z
This is an unapproved issue --- for information only.

2
Dear Panasonic Customer,
Welcome to the Panasonic family of customers. We hope that you have many years of enjoyment from your
new colour television. This is a very advanced television; however, the Quick Start Guide will tell you how to
have the TV operating quickly. You can then read the instructions completely and retain them for future
reference.
Warnings and Precautions 2.......................
Quick Start Guide 3...............................
Basic Controls 4..................................
Using the On Screen Displays 5....................
Picture Menu 6...................................
Sound Menu 7....................................
Setup Menu 8....................................
Tuning Menu 9...................................
Tuning Menu -- Programme edit 10.................
Tuning Menu -- Auto Setup 14......................
Tuning Menu -- Manual tuning 15...................
OSD Language 16................................
Q-- Link 17.......................................
AV Select and Setup 18...........................
VCR/DVD Operation 19...........................
Te l e t e x t O p e r a t i o n 2 0.............................
Audio / Video (AV) Connections 22.................
Via the front AV3 Audio / Video (RCA)
and Headphone Sockets 22........................
SCART and S-- Video Terminal Information 22..........
ViatherearAV1/AV221Pin(SCART)
and RCA Audio Out terminals 23.....................
Troubleshooting 24...............................
Foryourguidance 25.............................
Specifications 25.................................
DThis TV set is designed to operate on A.C. 220 -- 240V,
50Hz.
DTo prevent damage which might result in electric shock or
fire, do not expose this TV set to rain or excessive moisture.
DWARNING : HIGH VOLTAGE !!!
Do not remove the rear cover as live parts are accessible
when it is removed. There are no user serviceable parts
inside.
DAvoid exposing the TV set to direct sunlight and other
sources of heat.
DThe On/Off switch on this model does not fully disconnect
the TV from the mains supply. Remove the mains plug
from the wall socket when the TV set is not used for a
prolonged period of time.
DCABINET AND PICTURE TUBE CARE
Remove the mains plug from the wall socket. The cabinet
and picture tube can be cleaned with a soft cloth moistened
with mild detergent and water. Do not use solutions
containing benzol or petroleum. TV sets can produce static
electricity, care must be taken whenever touching the TV
screen.
DAdequate ventilation is essential to prevent failure of
electrical components, we recommend that a gap of at least
5cm is left all around this television receiver even when it is
placed inside a cabinet or between shelves.
WELCOME
CONTENTS
WARNINGS AND PRECAUTIONS

3
Batteries for
the Remote Control Transmitter.
(2 x R6 (UM3) size)
Remote Control Transmitter
(EUR511200)
Check that you have the accessories and items shown
L
Operating Instruction book
TV Guarantee
DMake sure that the batteries are fitted
the correct way round.
DDo not mix old batteries with new
batteries. Remove old, exhausted
batteries immediately.
DDo not mix different battery types, i.e.
Alkaline and Manganese or use
rechargeable (Ni-- Cad) batteries.
Plug in aerial and connect ancillary equipment
First, ensure that the VCR is in Standby mode
Plug in T.V. and switch on
Select your country
Auto setup will begin,
your stations will be
located and stored.
If a compatible VCR is
connected to the AV2
socket, programme data
will be downloaded to the
VCR via Q-- Link.
Seepage17.
Quick Start Guide
Remote control batteries
Adjust
Volume
Change Channel
Start ATP Suchlauf Abbruch
Land
ATP AKTIV
SUCHE LÄUFT : BITTE WARTEN
TV / AV : Abbruch
02 78:01 41
CH41
CH41
For Switzerland and Belgium,
select the desired language
Auswählen
Deutschland
Österreich
France
Italia
España
Portugal
Nederland
Danmark
Sverige
Norge
Suomi
Belgien
Schweiz
ELLADA
E.Eu
Press the red button
CH41 XYZ
OR
If you are installing a new Q-- Link compatible VCR, you can now switch
it ON. Downloaded tuning data will match the television’s.
If you are installing a new NextViewLink compatible VCR, you will need
to initiate download manually. See the VCR handbook for details.
DIf the VCR has not accepted download data from the TV, you may need to select the Download option from the VCR’s menu.
DIf Q-- Link is not operating correctly, check it is connected to the television’s AV2 socket, the SCART lead is a “full function” type, and
the VCR is compatible with Q-- Link, NextViewLink or similar technologies. Ask your dealer for further details.
DForfurtherinformationonQ-- Link and connecting equipment, see pages 17, 22 and 23.
1
2
3
4
QUICK START GUIDE

4
Switch between viewing TV or AV input
(see page 18)
Standby ON/OFF switch
Switches TV On or Off standby.
Programme position for selection of
two digit programmes (10-99) using
numeric buttons
Programme / channel change
buttons (0-9) and Teletext page
buttons (see page 20)
Menu buttons
Press to access the Picture, Sound
and Setup menus (see page 5)
Sound mute On/Off
Direct Channel Access
During normal TV viewing or when
in the Tuning, Programme edit or
Manual tuning menus, press and
then enter channel number using
the numeric buttons
Teletext buttons (see page 20)
Coloured buttons used for
Programme Edit functions (see page 10)
Teletext functions (see page 20)
AV selection (see page 18)
MAINS Power On/Off switch
STR (Normalisation store)
Used to store tuning and
other function settings
F (Function select)
Displays the On Screen Display functions,
use repeatedly to select from the available
functions -Volume, Contrast, Brightness,
Colour, Sharpness, Tint (in NTSC mode),
Bass, Treble, Balance, and Tuning mode.
Increases or decreases the
programme position by one.
When a function is already
displayed, press to increase or
decrease the selected function.
TV/AV switch (see page 18)
Headphonesocket(seepage22)
RCA Audio/Video sockets (page 22)
Red light indicates Standby mode.
Use Standby switch, -,+or0-9
buttons to switch TV On
The N button will recall settings
stored with STR
STR (Normalisation store)
Cursor buttons to make selections and
adjustments
The Help button provides a
demonstrationofOnScreen
Display menus
Ambience on/off
Direct TV Record button
(see page 17)
Status button
Press to display programme position,
programme name, channel number,
TV system, time stereo mode
and programme table
VCR / DVD buttons
(see page 19)
?
BASIC CONTROLS :
FRONT PANEL AND REMOTE CONTROL

5
This TV has a comprehensive system of On Screen Display menus to access
adjustments and options
Picture menu
Contrast
Brightness
Colour
Sharpness
Colour balance Normal
P-- NR Off
AI On
Select
Change
Exit
TV/AV
Some selections, for example, Contrast, Brightness, Colour and Sharpness
will allow you to increase or decrease their level.
Some selections, for example, Off timer, allow a choice to be made.
Some selections, for example Tuning menu, will lead to a further menu.
The PICTURE,SOUND and SET UP buttons are
used to open the main menus and also to return to
the previous menu.
The up and down cursor buttons are used to move
the cursor up and down the menus.
The left and right cursor buttons are used to access
menus, adjust levels or to select from a range of
options.
The STR button is used to store settings after
adjustments have been made or options have
been set.
The TV/AV button is used to exit the menu system
and return to the normal viewing screen.
The HELP button will run a demonstration of the
menus available. Press the HELP button and
select one of the options.
Menu Title
Selection bar
Sub-- menus
Indicator for options
Instructions
PICTURE SOUND SET UP
STR
HELP
?
TV/AV
?
USING THE ON SCREEN DISPLAYS

6
This menu allows you to make adjustments to the picture quality
Open the Picture menu
Move to your choice
Increase or decrease levels or
set options
Press the TV/AV button to exit
the Picture menu
The Contrast, Brightness, Colour and
Sharpness levels can be adjusted to suit
your own preferences and the viewing
conditions.
The Tint adjustment will only appear as
a menu item if you have an NTSC signal
source connected to the TV and will
allow adjustment of the hue.
The Colour balance setting allows you to
set the overall colour tone of the picture.
P-- NR will automatically reduce
unwanted picture interference.
The AI setting automatically analyses
the incoming picture and processes it to
give improved contrast, optimum depth
of field and vivid colour tones.
PICTURE MENU
TV/AV
Picture menu
Contrast
Brightness
Colour
Sharpness
Colour balance Normal
P-- NR Off
AI On
Select
Adjust
Exit
TV/AV
Picture menu
Contrast
Brightness
Colour
Sharpness
Colour balance Normal
P-- NR Off
AI On
Select
Adjust
Exit
TV/AV
Sharpness
Contrast
Tint
Colour
Brightness
Sharpness
Colour balance
P-- NR
AI

7
The Sound menu will allow you to set your personal preferences for all aspects of sound quality
Open the Sound menu
Move to your choice
Increase or decrease levels or
set options
Press the TV/AV button to exit
the Sound menu
The Volume adjustment sets the overall
output volume.
Bass adjustment will emphasise the
lower, deeper frequencies and can be
increased or decreased.
Treble adjustment will emphasise the
sharper, higher frequencies and can be
increased or decreased.
Balance affects the levels of sound
between the left and right speakers.
Adjustment can be made so that the
level from the speakers will suit your
listening position.
The AI setting automatically analyses
the incoming sound signal and
processes it to give lower noise and
optimum tone for the programme
material.
MPX will usually be set to Stereo to
provide the best reproduction, however
if reception deteriorates or if the service
is not available then it is advisable to
switch to Mono. Mono (M1) and (M2)
can also be selected if signals are being
transmitted.
The sound can be improved during
Music or Speech mode by selecting the
appropriate function.
Ambience provides a dynamic
enhancer to simulate improved spatial
effects.
SOUND MENU
TV/AV
SOUND
Sound menu
Volume
Bass
Treble
Balance
AI On
MPX Stereo
Mode Music
Ambience Off
Select
Adjust
Exit
TV/AV
Sound menu
Volume
Bass
Treble
Balance
AI On
MPX Stereo
Mode Music
Ambience Off
Select
Change
Exit
TV/AV
Sound menu
Volume
Bass
Treble
Balance
AI Off
MPX Stereo
Mode Music
Ambience Off
Select
Change
Exit
TV/AV
Bass
Treble
MPX
Ambience
Balance
Mode
Volume
AI

8
The Setup menu provides access to various advanced features and also to the Tuning menu
Open the Setup menu
Move to your choice
Increase or decrease levels, set
optionsoraccessfurthermenus
Press the TV/AV button to exit
the Setup menu
The Teletext option allows you to choose
between TOP/FLOF or LIST mode.
Seepage20.
Aspect allows you to view widescreen
programme material with the correct
aspect ratio (16:9).
Off timer will switch the TV off within a
preset time which you can choose from
between 0 to 90 minutes in 15 minute
intervals.
Q-- Link allows you to enable or disable
data communication with a compatible
VCR.Seepage17.
The Tuning menu provides an entry to
many other features including
Programme edit, ATP, Fine tuning,
Manual tuning, Colour system and
Volume correction. See page 9.
OSD Language allows you to select the
language used for On Screen Displays.
Seepage16.
SETUP MENU
TV/AV
SET UP
Setup menu
Teletext FLOF
Aspect 4:3
Off timer Off
Q-- Link On
Tuning menu
OSD language
TV/AV
Select
Change
Exit
Setup menu
Teletext FLOF
Aspect 4:3
Off timer Off
Q-- Link On
Tuning menu
OSD language
TV/AV
Select
Change
Exit
Setup menu
Teletext FLOF
Aspect 4:3
Off timer Off
Q-- Link Off
Tuning menu
OSD language
TV/AV
Select
Change
Exit
Aspect
Off timer
Te l e t e x t
Q-- Link
Tuning menu
OSD Language

9
The Tuning menu provides access to manual, automatic and fine tuning menus
Open the Setup menu
Move to Tuning menu
Access Tuning menu
Move to your choice
Increase or decrease levels, set
optionsoraccessfurthermenus
Press the TV/AV button to exit
Accessing the Programme edit menu
will allow stations to be moved, added,
deleted, named or locked and provides
access to the TV -- system.
Seepage10.
The Auto setup menu allows you to
automatically retune the TV.
Seepage14.
The Manual tuning menu allows
individual programme positions to be
tuned manually. See page 15.
Stations can be finely tuned using the
Fine tuning adjustment.
The Colour system menu allows you to
decide the correct choice of
transmission standard.
Volume correction allows you to adjust
thevolumelevelofindividualstations.
This option is used when a decoder is
connected via AV2. Set to On if a
scrambled signal is to be processed by
the decoder. Set to Off after use.
TUNING MENU
TV/AV
SET UP
Setup menu
Teletext FLOF
Aspect 4:3
Off timer Off
Q-- Link Off
Tuning menu
OSD language
TV/AV
Select
Change
Exit
Setup menu
Teletext FLOF
Aspect 4:3
Off timer Off
Q-- Link Off
Tuning menu Access
OSD language
TV/AV
Select
Access
Exit
Programme edit Access
Auto setup
Manual tuning
Fine tuning
Colour system AUTO
Volume correc.
Decoder (AV2) Off
1
CH41
Return --
Select
Access
Exit
Store
TV/AV
STR
Tuning menu
Fine tuning
Colour system
Volume correction
Programme edit
Auto setup
Manual tuning
Decoder (AV2)

TV/AV
10
The Programme edit menu allows you to edit the programme position settings
Open the Setup menu
Move to Tuning menu
Access Tuning menu
Move to Programme edit menu
Access Programme edit menu
Make required changes
(see sections below)
Press STR button to store
changes
If you have finished in the
Programme edit menu, press the
TV/AV button to exit
To delete an unwanted programme position
Choose the programme position
PresstheRedbuttononremote
control
Press the Red button again to
confirm
If you have finished in the
Programme edit menu, press the
TV/AV button to exit
TUNING MENU -- PROGRAMME EDIT
TV/AV
STR
SET UP
Setup menu
Teletext FLOF
Aspect 4:3
Off timer Off
Q-- Link Off
Tuning menu
OSD language
TV/AV
Select
Change
Exit
Setup menu
Teletext FLOF
Aspect 4:3
Off timer Off
Q-- Link Off
Tuning menu Access
OSD language
TV/AV
Select
Access
Exit
Prog. Chan. Name Lock Sys
1: CH41 XYZ Off SC1
2: -- Off SC1
3: -- Off SC1
4: -- Off SC1
5: -- Off SC1
Delete Add Move TV > VCR
Return --
Change
programme
Select
option
Exit
Store
TV/AV
STR
Programme edit
Programme edit Access
Auto setup
Manual tuning
Fine tuning
Colour system AUTO
Volume correc.
Decoder (AV2) Off
1
CH41
Return --
Select
Access
Exit
Store
TV/AV
STR
Tuning menu

11
To add a programme position
Choose the programme position
where the new program is to be
inserted
Press the Green button
Press the Green button again to
confirm
Thisblankprogrammecanthenbe
tuned, named, locked and be
allocated your choice of TV-- system
Press STR to store
If you have finished in the
Programme edit menu, press the
TV/AV button to exit
To move a programme to another position
Choose the programme position
to be moved
Press the Yellow button on
remote control
Choose new position
Press the Yellow button again to
confirm
If you have finished in the
Programme edit menu, press the
TV/AV button to exit
TUNING MENU -- PROGRAMME EDIT
STR
TV/AV
Prog. Chan. Name Lock Sys
1: CH41 XYZ Off SC1
2: -- Off SC1
3: CH44 ZXY Off SC1
4: -- Off SC1
5: -- Off SC1
Delete Add Move TV > VCR
Return --
Change
programme
Select
option
Exit
Store
TV/AV
STR
Programme edit
Prog. Chan. Name Lock Sys
1: CH41 XYZ Off SC1
2: -- Off SC1
3: CH44 ZXY Off SC1
4: -- Off SC1
5: -- Off SC1
Delete Add Move TV > VCR
Return --
Change
programme
Select
option
Exit
Store
TV/AV
STR
Programme edit
Prog. Chan. Name Lock Sys
1: CH41 XYZ Off SC1
2: -- Off SC1
3: -- Off SC1
4: -- Off SC1
5: CH44 ZXY Off SC1
Delete Add Move TV > VCR
Return --
Change
programme
Select
option
Exit
Store
TV/AV
STR
Programme edit
TV/AV

12
To tune a programme position
Choose the programme position
Move to the channel column
Increase or decrease channel
numberorusethe’C’keyforDirect
Channel Access (see page 4)
Press STR to store
If you have finished in the
Programme edit menu, press the
TV/AV button to exit
To rename a programme position
Choose the programme position
Move to the Name column
Choose the new character
Move to the next character position
Continue until renaming is done
Press STR to store
If you have finished in the
Programme edit menu, press the
TV/AV button to exit
TUNING MENU -- PROGRAMME EDIT
Return --
Change
channel
Select
option
Exit
Store
TV/AV
STR
Programme edit
Prog. Chan. Name Lock Sys
1: CH41 XYZ Off SC1
2: -- Off SC1
3: CH44 ZXY Off SC1
4: -- Off SC1
5: -- Off SC1
Return --
Change
character
Select
option
Exit
Store
TV/AV
STR
Programme edit
Prog. Chan. Name Lock Sys
1: CH41 XYZ Off SC1
2: -- Off SC1
3: CH44 ZXY Off SC1
4: -- Off SC1
5: -- Off SC1
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
+-- . 0123456789
STR
TV/AV
STR
TV/AV

13
To lock a programme position to prevent
access
Choose the programme position
Move to the lock column
Choose between lock on or lock off
Press STR to store
If you have finished in the
Programme edit menu, press the
TV/AV button to exit
Note :
When a programme position is locked, Direct Channel
Access using the ’C’ and numeric keys on the remote
control is not available.
To c h a n g e t h e T V -- system for a programme
position
Choose the programme position
Move to the Sys column
Choose the required sound system:
SC1 : PAL B/G, H / SECAM B/G
SC2 : PAL I
SC3 : PAL D/K / SECAM D/K
F:SECAML/L’
Press STR to store
If you have finished in the
Programme edit menu, press the
TV/AV button to exit
To copy programme information to a
compatible VCR connected to AV2
Move to the Prog. column
PresstheBluebuttononthe
remote control.
Programme data will now be sent
to the VCR. This might take a few
seconds, depending on the
number of stations stored.
If you have finished in the
Programme edit menu, press the
TV/AV button to exit
TUNING MENU -- PROGRAMME EDIT
STR
TV/AV
Return --
Change
TV system
Adjust
option
Exit
Store
TV/AV
STR
Programme edit
Prog. Chan. Name Lock Sys
1: CH41 XYZ Off SC1
2: -- Off SC1
3: CH44 ZXY Off SC2
4: -- Off SC1
5: -- Off SC1
TV>VCR IN PROGRESS
PLEASE WAIT
Programme : 63
Remote control unavailable
Return --
Lock
On/Off
Select
option
Exit
Store
TV/AV
STR
Programme edit
Prog. Chan. Name Lock Sys
1: CH41 XYZ Off SC1
2: -- Off SC1
3: CH44 ZXY Off SC1
4: -- Off SC1
5: -- Off SC1
STR
TV/AV
TV/AV

14
The Auto setup menu will allow you to automatically retune the TV to your local stations.
It is useful if you move to a different region
Open the Setup menu
Move to Tuning menu
Access Tuning menu
Move to Auto setup
Access Auto setup
Press to confirm start
Select your country
Press to start Auto setup (ATP)
The TV will search for, locate and
sort into order your local stations.
If a compatible VCR is connected
via the AV2 socket, programme
data will be sent to the VCR via
Q-- Link (see page 17).
Once this operation is completed
the TV will display programme
position 1.
TUNING MENU -- AUTO SETUP (ATP)
Setup menu
Teletext FLOF
Aspect 4:3
Off timer Off
Q-- Link Off
Tuning menu Access
OSD language
TV/AV
Select
Access
Exit
WARNING
All current tuning
data will be erased
Start Auto setup
Exit
TV/AV
AUTO SETUP IN PROGRESS
SEARCHING : PLEASE WAIT
SETUP : Return to tuning menu
TV/AV : To exit
Found : CH41 XYZ
CH41
02 99:21 41
Programme edit
Auto setup Access
Manual tuning
Fine tuning
Colour system AUTO
Volume correc.
Decoder (AV2) Off
1
CH41
Return --
Select
Access
Exit
Store
TV/AV
STR
Tuning menu
SET UP

STR
TV/AV
SET UP
STR
F
F
TV/AV
-- /v
-- /v
15
Manual tuning of the Programme positions is available either from the On Screen Display menu
or from the front panel controls
Manual tuning menu
Open the Setup menu
Move to Tuning menu
Access Tuning menu
Move to Manual tuning
Access Manual tuning
Select the programme position
to be tuned
Start tuning
When the desired programme is
found, press STR to store
Press the TV/AV button to exit.
Manual tuning (Front panel)
Press the F button (Front panel)
until “Tuning mode” is reached
Press the -- or + button to access
Tuning mode
Press the TV/AV button to move
between “Change programme”,
“Search” or “Change TV system”
Press the -- or + button to change
programme position, start search,
or alter TV system
When the desired station is found,
press STR to store the changes
Repeat above procedure to tune
additional programmes or press the
F button to exit
TUNING MENU -- MANUAL TUNING
Manual tuning
02 99:21 41
1
CH41
Return --
Programme
down/up
Search
down/up
Exit
Store
TV/AV
STR
-- ,+ : Search
TV/AV : Move cursor
STR : To store
F : To exit
02 99:21 41
Manual tuning (Front panel)
STR F -- /V +/ TV/AV
1
CH41
SC1
Programme edit
Auto setup
Manual tuning Access
Fine tuning
Colour system AUTO
Volume correc.
Decoder (AV2) Off
1
CH41
Return --
Select
Access
Exit
Store
TV/AV
STR
Tuning menu

16
When you first installed the TV the On Screen Display language was set according to your choice of
country. If you wish to use a different language then it can be chosen from the OSD language menu
Open the Setup menu
Move to the OSD language
menu
Access the OSD language menu
Move to your choice
Press the TV/AV button to select
and exit
OSD LANGUAGE
Setup menu
Teletext FLOF
Aspect 4:3
Off timer Off
Q-- Link Off
Tuning menu
OSD language Access
TV/AV
Select
Access
Exit
OSD language
Deutsch Español Nederlands
English Norsk Suomi
Français Dansk Türkçe
Italiano Svenska Português
ELLHNIKA
Return --
Select
Select
Exit
TV/AV
TV/AV
SET UP

17
Q-- Link allows the television to communicate with your VCR
Open the Setup menu
Move to Q-- Link
Confirm Q-- Link is set to “On”
Press the TV/AV button to exit
The VCR must be connected with a SCART lead (full function type) attached between the AV2 socket of the television and the
appropriate socket on your VCR. See the VCR handbook for further information. Q-- Link, NextViewLink or similar technology allows
the television to instruct a compatible VCR to record the programme that is currently being displayed on screen, regardless of the
programme position set on the VCR, thus simplifying the process of recording programmes.
To record the programme you are currently watching
Press the DIRECT TV REC button on the remote control
DIRECT
TV REC
If the VCR is off, it will automatically switch on when you press the DIRECT TV REC button.
A message, sent from the VCR, will appear on screen showing what is being recorded, or if it is not possible to record:
VCR recording preset prog VCR recording TV source
No recording NO TAPE
No recording TAPE IS PROTECTED
VCR is recording the programme signal from its
owntuner.IfyouwishyoucanswitchofftheTV
and leave the VCR recording in the normal way.
VCR is recording the programme signal from the television.
You must not change programme position or switch off the TV: if
you do, the VCR will automatically stop recording and switch off.
The write protection tab on the back of the cassette
has been removed.
No recording VCR IS PLAYING
No recording VCR ALREADY RECORDING
VCR recording own tuner
No recording TAPE MAY BE DAMAGED
VCR Recording VCR external No recording NO SOURCE AVAILABLE
Examples of other messages that might be displayed are:
To share tuning information
To ensure correct recordings are made, the television and VCR should share tuning information -- seepage13.
DWhenever the Auto setup (ATP) function is used, tuning data will be downloaded to the VCR.
Auto Power functions
With Panasonic Q-- Link VCRs these additional features are available:
DIf you insert a tape in your VCR and press the Play button, the television will automatically switch on and select the AV2 input so
you can view the tape.
DIf you switch off the television whilst the VCR is in Stop, Fast Forward or Rewind modes, the VCR will switch off automatically.
To turn off Q -- Link communication
If you do not wish to use the Q-- Link feature, go to the Setup menu and set the Q-- Link option to “Off”. See page 8.
Important Note:
Not all VCRs support this type of data communication system. Some may support certain features, but not others. See the VCR handbook
for further information.
If Q-- Link is inoperative, first confirm that your SCART lead is a full function type. Ask your dealer for further details.
Q-- LINK
Setup menu
Teletext FLOF
Aspect 4:3
Off timer Off
Q-- Link On
Tuning menu
OSD language
TV/AV
Select
Change
Exit
TV/AV
SET UP

Setup menu
Sound menu
18
The AV Select menu will allow you to choose which AV source to view
Press the TV/AV button
Press the appropriate coloured but-
ton of remote control (whilst the op-
tions remain on screen)
The options will disappear
You may wish to make adjustments
to the Setup or Sound menus
Open the Setup menu
Move to your choice
Access adjustments or options
Press the TV/AV button to exit
Open the Sound menu
Move to your choice
Access adjustments or options
Press the TV/AV button to exit
AV SELECT AND SETUP
TV/AV
TV/AV
TV/AV
SET UP
SOUND
AV1 AV2/S AV3
Setup menu
Teletext FLOF
Aspect 4:3
Off timer Off
Colour system AUTO
Volume correc.
Q-- Link On
OSD language
TV/AV
Select
Change
Exit
Sound menu
Volume
Bass
Treble
Balance
AI On
Mode Music
Ambience Off
Select
Adjust
Exit
TV/AV
AV1

19
The Remote Control is capable of operating some functions of selected Panasonic VCRs and DVD (Digital Versatile Disc) equipment.
Some VCR and DVD equipment have different functions, so to ensure compatibility please refer to the equipment’s instruction book
or consult your dealer for details.
VCR / DVD OPERATION
Press to switch the VCR or DVD to standby mode.
Press again to switch back on.
Standby
Press to playback the tape or DVD.
Play
Press to stop the tape or DVD.
Stop
VCR: Press to fast forward the tape. In Play mode, press
to view the picture rapidly forward.
DVD: Press once to skip to the next track. In play mode
press and hold to view the picture rapidly forward.
Skip/FastForward/Cue
VCR: Press to rewind the tape. In Play mode, press to
view the picture rapidly in reverse.
DVD: Press once to skip to the previous track. In play
mode press and hold to view the picture rapidly in
reverse.
Skip / Rewind / Review
Press in playback mode, the picture will pause.
Press again to restart play.
Pause / Still
Press to increase or decrease the VCR programme
position by one.
Programme Up / Down
Press this button to start recording.
Record
21 3
4 5 6
7 8 9
C
SOUND
SET UP
TV/TEXT
DIRECT
TV REC
F. P. I N D E X H O L D
VCR
0
TV/AV
STR HELP
?
Use this switch to select whether controls operate
DVD equipment or your VCR.
VCR / DVD switch
N
PROGRAMME
REC VCR
DVD
REC
VCR
DVD

20
DTeletext features may vary depending on the Broadcasting Companies and is only available if the channel selected is transmitting
Tele t e x t .
DPressing the Picture button whilst in Teletext operation will display the contrast function with a cyan bar, press A"to alter the
setting as required.
Pressing the Setup button whilst in Teletext operation will display special function options at the bottom of the screen.
DWhen in Teletext mode, the volume may still be altered to the desired listening level.
What is LIST mode?
In LIST mode, four differently coloured page numbers are situated at the bottom of the screen. Each of these numbers can be altered and
stored in the TV’s memory.
What is FLOF (FASTEXT)?
In FASTEXT mode, four differently coloured subjects are situated at the bottom of the display. To access more information about one of
these subjects, press the appropriately coloured button. This facility enables fast access to information of the subjects shown.
What is TOP Teletext?
TOP Teletext makes the task of selecting the desired Teletext pages easier and shorter. In fact page access time is almost instantaneous,
just press the button and the page appears.
How does it work?
TOP uses the four coloured buttons, Red, Green, Yellow and Blue to select the following information.
DTo move between subject blocks (SPORT for example) use the Blue button. Within this SPORT topic it is possible to select
different groups such as Tennis, Football, Baseball etc, by using the Yellow button. When the last group within the block is
reached, the yellow button moves to the next block.
DThe Green button will select the next available page UP.
DThe Red button will select the next available page DOWN.
What are the advantages?
DPage selection at the touch of a single button.
DEasy to use step-- by-- step selection of the topical subject.
DReduction of waiting time.
DIf non existent page number is entered, a question mark will appear at the bottom of the screen.
DPage status line at bottom of screen so you always know which button will take you to the desired information.
Press the TV/TEXT button.
The screen will display the Teletext page.
Press again when you wish to return to TV. mode.
TV / Teletext mode
Pages can be selected in two ways :
a. Press the Up / Down buttons to increase or decrease the page number by one.
b. By entering the page number, using 0 -- 9 on the remote control.
Page Selection
Press the SET UP button to display special functions, followed by the Green button.
Press the Green button again to expand the BOTTOM half.
Press again to return to normal (FULL) size.
Full/Top/Bottom
Press the SET UP button to display special functions, followed by the Red button to
reveal hidden words e.g. quiz page answers. Press again to hide.
Reveal
In TOP or FASTEXT mode these correspond to the differently coloured subjects.
In LIST mode they correspond to the differently coloured page numbers.
Red / Green / Yellow / Blue buttons
In LIST mode the four page numbers can be altered for channel positions 1 -- 25 only.
To do this, press one of the coloured buttons and enter the new page number.
Press and hold STR, the page numbers will change colour.
List Store
TV/TEXT
STR
SET UP
SET UP
TELETEXT OPERATION
