Panasonic QuintrixF TX-28PK25 User manual

Colour Television
TX-28PK25
EURO-4H Chassis
SPECIFICATIONS
Power Source: 220-240V a.c., 50Hz
Power Consumption: 128W
Stand-by Power
Consumption: 1.4W
Aerial Impedance: 75Ωunbalanced, Coaxial Type
Receiving System: PAL-I , PAL-525/60 UHF
M.NTSC
NTSC (AV only)
Receiving Channels: UHF E21-E69
Intermediate Frequency:
Video/Audio
Video 39.5MHz
Audio 33.5MHz
32.95MHz (NICAM)
Colour 35.07MHz (PAL)
Video/Audio Terminals:
AUDIO MONITOR OUT Audio (RCAx2) 500mV rms 1kΩ
AV1 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
RGB (21 pin)
AV1 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
AV2 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
S-Video IN Y: 1V p-p 75Ω
(21-pin) C:0,3V p-p 75Ω
AV2 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
Selectable output (21 pin)
AV3 IN S-Video IN Y: 1V p-p 75Ω
(4-pin) C: 0,3V p-p 75Ω
Audio (RCAx2) 500mV rms 10kΩ
Video (RCAx1) 1V p-p 75Ω
AV4 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
S-Video IN Y: 1V p-p 75Ω
(21-pin) C: 0.3V p-p 75Ω
RGB (21 pin)
AV4 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
High Voltage: 30.5kV ±1kV
Picture Tube: W66EKT10X71 66cm
Audio Output: 2 x 15W (Music Power)
8ΩImpedance
Headphones: 8ΩImpedance
3.5mm
Accessories
supplied : Remote Control
2 x R6 (UM3) Batteries
Dimensions:
Height: 503mm
Width: 720mm
Depth: 527mm
Net weight: 43kg
Specifications are subject to change without notice.
Weights and dimensions shown are approximate.
NOTE: This Service Manual should be used in conjunction with
the EURO-4H Technical guide.
ORDER No. SM-01023
All manuals and user guides at all-guides.com
all-guides.com

ETD:2000-
TECHNICAL INFORMATION
Colour Television
Model:- All 100Hz Models
Chassis:- All above models displaying phenomenon described.
Date:- 23/11/01
Subject: Vertical Bands.
Please use the following IRIS codes when making a claim:-
1.Symptom = F343 2. Section Code = 0UT
3.Defect Code = T 4. Repair Code = K
Background: The reported Models (TX32PK25/28PK25) AND DVD players (SC-HT80 / SC-HT70)
shows 2 vertical bands that appear on screen. When the audio lead is removed from the
rear of the TV, the vertical shading bands disappear.
Remedy: Using Modification Kit TZS9EK018 refer to diagram below and carry out the following:-
Method: 1. Remove C2303.
2. Remove jumper chip resistor JA 115. (Not jumper wire JA115).
3. Connect the ferrite bead supplied between the earth pad of JK2301and the audio earth
of AV1 (Pin 4). Safety Notice ! : The ferrite bead must be glued in place
CHIP JUMPER C2303 JK2301 AV1 (PIN 4)
Panasonic
Document No:QUA0011 ISSUE:2
All manuals and user guides at all-guides.com

CONTENTS
SAFETY PRECAUTIONS..........................................................................................................................................................2
SERVICE HINTS.......................................................................................................................................................................3
ADJUSTMENT PROCEDURE AND FACTORY SETTINGS.....................................................................................................4
WAVEFORM PATTERN TABLE ...............................................................................................................................................5
ALIGNMENT SETTINGS...........................................................................................................................................................6
BLOCK DIAGRAMS..................................................................................................................................................................7
PARTS LOCATION.................................................................................................................................................................11
REPLACEMENT PARTS LIST................................................................................................................................................12
SCHEMATIC DIAGRAMS.......................................................................................................................................................24
CONDUCTOR VIEWS.............................................................................................................................................................31
SAFETY PRECAUTIONS
GENERAL GUIDE LINES
1. It is advisable to insert an isolation transformer in the
a.c. supply before servicing a hot chassis.
2. When servicing, observe the original lead dress in the
high voltage circuits. If a short circuit is found, replace
all parts that have been overheated or damaged by
the short circuit.
3. After servicing, see that all the protective devices
such as insulation barriers, insulation papers, shields
and isolation R-C combinations are correctly
installed.
4. When the receiver is not being used for a long period
of time, unplug the power cord from the a.c. outlet.
5. Potentials as high as 31.5kV are present when this
receiver is in operation. Operation of the receiver
without the rear cover involves the danger of a shock
hazard from the receiver power supply. Servicing
should not be attempted by anyone who is not
familiar with the precautions necessary when working
on high voltage equipment. Always discharge the
anode of the tube.
6. After servicing make the following leakage current
checks to prevent the customer from being exposed
to shock hazard.
LEAKAGE CURRENT COLD CHECK
1. Unplug the a.c. cord and connect a jumper between
the two prongs of the plug.
2. Turn on the receiver’s power switch.
3. Measure the resistance value with an ohmmeter,
between the jumpered a.c. plug and each exposed
metallic cabinet part on the receiver, such as screw
heads, aerials, connectors, control shafts etc. When
the exposed metallic part has a return path to the
chassis, the reading should be between 4M ohm and
20M ohm. When the exposed metal does not have a
return path to the chassis, the reading must be
infinite.
LEAKAGE CURRENT HOT CHECK
1. Plug the a.c. cord directly into the a.c. outlet. Do not
use an isolation transformer for this check.
2. Connect a 2kΩ10W resistor in series with an
exposed metallic part on the receiver and an earth,
such as a water pipe.
3. Use an a.c. voltmeter with high impedance to
measure the potential across the resistor.
4. Check each exposed metallic part and check the
voltage at each point.
5. Reverse the a.c. plug at the outlet and repeat each of
the above measurements.
6. The potential at any point should not exceed
1,4Vrms. In case a measurement is outside the limits
specified, there is a possibility of a shock hazard, and
the receiver should be repaired and rechecked before
it is returned to the customer.
X-RADIATION WARNING
1. The potential sources of X-Radiation in TV sets are
the high voltage section and the picture tube.
2. When using a picture tube test jig for service, ensure
that the jig is capable of handling 31.5kV without
causing X-Radiation.
NOTE: It is important to use an accurate periodically
calibrated high voltage meter.
1. Set the brightness to minimum.
2. Measure the high voltage. The meter should indicate.
30.5kV ± 1kV.
If the meter indication is out of tolerance, immediate
service and correction is required to prevent the
possibility of premature component failure.
3. To prevent any X-Radiation possibility, it is essential
to use the specified tube.
HOT CHECK CIRCUIT
a.c. VOLTMETER
WATER PIPE
(EARTH)
TO INSTRUMENT’S EXPOSED
METALLIC PARTS Fig. 1.
2kΩ10 Watts
2
All manuals and user guides at all-guides.com

SERVICE HINTS
How to remove the rear cover
1. Remove the 10 screws as shown in Fig.2.
LOCATION OF CONTROLS
3
Fig. 2.
Fig.2.
Abb.2.
SCREWS SCREWS
M-Board
Y-Board
E-Board
F-Board
Focus
Screen
P-Board
Z-Board E-Board
D-BoardM-Board
P-Board
All manuals and user guides at all-guides.com

ADJUSTMENT PROCEDURE
Item / Preparation Adjustments
+B SET-UP
1. Receive a Greyscale signal.
2. Set the controls :-
Brightness Minimum
Contrast Minimum
Volume Minimum
1. Set the +B voltage up as follows:-
Adjust R811 so that B2 shows 148V±1V.
2. Confirm the following voltages.
B9 5 ± 0,25V B10 5 ± 0,25V
B5 12 ± 0,5V B11 33 ± 1,5V
B4 15 ± 1V B7 8 ± 0,5V
B12 26 ± 2V B8 6±1V
B3 36 ± 1,5V B13 13 ± 1V
B1 205 ± 10V B14 14 ± 1V
CUT OFF / Ug2 Test
1. Receive a Greyscale signal.
2. Degauss the tube externally.
3. Set the TV into Service Mode 1.
4. Select Cut off mode.
To adjust Cutoff connect an oscilloscope to the Blue
cathode. Press "STR" and adjust "cutoff" value using the
"Yellow" and "Blue" buttons until the black level is 160V±5V,
press "STR" to store the value. Remove the oscilloscope.
Select Ug2 adjustment and adjust the screen VR until the
display shows "O.K."
FACTORY SETTINGS
Self-check is used to automatically check the bus lines and hexadecimal code of the TV set. To get in to Self-Check mode
press the down (-/v) button on the customer controls at the front of the TV set, at the same time pressing the STATUS button
on the remote control.
If the CCU ports have been checked and found to be incorrect or not located then " - - " will appear in place of "O.K.".
4
PCB O.K.
CAB O.K.
TX- 28PK25
OPTION1 00
OPTION2 A1
OPTION3 02
OPTION4 C0
OPTION5 B1
OPTION6
E1
VPC O.K.
SRC O.K.
DDP O.K.
TUN O.K.
E2 O.K.
MSP O.K.
DPL - -
To exit Self Check, switch off the TV set at the power button.
All manuals and user guides at all-guides.com

WAVEFORM PATTERN TABLE
Video Out
IC601 Pin 59
2V
64µS
B - Out
E8 Pin 4
64µS
4,6V
64µS
2V
H - Pulse
Base Q503
VFLB
IC451 Pin 3
1V
20mS
B - Out
IC601 Pin 39
275mV
64µS
64µS
3V
H - Out
IC601 Pin 50
Vert Out
IC601 Pin 31
20mS
0,7V
13µS
3,7V
SCL
IC1201 Pin 3
R - Out
E8 Pin 5
64µS
4
,
6V
HFLB
IC601 Pin 13
64µS
6,2V
R - Out
IC601 Pin 37
64µS
275mV
G - Out
IC601 Pin 38
275mV
64µS
Vert Drive
IC451 Pin 2
20mS
57V
HFLB
IC701 Pin 8
64µS
1,5V
G - Out
E8 Pin 3
64µS
4,4V
SVM Out
IC601 Pin 34
88mV
64µS
H - Out
IC701 Pin 5
30mV
64µS
5
All manuals and user guides at all-guides.com
all-guides.com

ALIGNMENT SETTINGS
(The figures below are nominal and used for representative purposes only.)
1. Set the Bass to maximum position, set the Treble to minimum position, press the volume down button
(-/v) on the customer controls at the front of the TV and at the same time press the INDEX button on the remote
control, this will place the TV into the Service Mode.
2. Press the RED / GREEN buttons to step up / down through the functions.
3. Press the YELLOW / BLUE buttons to alter the function values.
4. Press the STR button after each adjustment has been made to store the required values.
5. To exit the Service Mode, press the "N" button.
Alignment Function Settings / Special features
Horizontal Position H-Pos
061 Optimum setting.
Vertical Position V-Pos
005 Optimum setting.
Horizontal Amplitude H-Amp
055 Optimum setting.
Vert. Amplitude V-Amp
054 Optimum setting.
EW-amplitude E/W-Amp1
-128 Optimum setting.
EW-amplitude E/W-Amp2
006 Optimum setting.
Trapezium-comp Trapez-1
047 Optimum setting.
Trapezium-comp Trapez-2
-128 Optimum setting.
Vertical Linearity V-Lin
006 Optimum setting.
Vertical Symmetry V-Sym
002 Optimum setting.
DVCO DVCO
-005
Receive a PAL Colour Bar Pattern. For
DVCO alignment press "Blue" button, wait
until the colours are changing slowly and
press "STR".
Cut-off DC Cut-off
0171
Ug2 Test Ug2
055
O.K.
To adjust Cutoff connect an oscilloscope to
the blue cathode. Press "STR" and adjust
"cutoff" value using the "Yellow" and
"Blue" buttons until the black level is
160V±5V press "STR" to store the value.
Remove the oscilloscope.
Select Ug2 adjustment and adjust the
screen VR until the display shows "O.K."
Highlight
Lowlight High 0902 0777 0864 Low 0117 0132 0112 Optimum setting.
Sub-Brightness Sub-Brightness
255 Optimum setting.
6
Black Level
160V±5V
GND
All manuals and user guides at all-guides.com

7
VIDEO BLOCK DIAGRAM
Q320
Q105
AV1
9LGHR

2XW


9LGHR

,Q


AV2
E8
Q351
Q371
Q361
CRT
Y2
TUNER
Q
104
5HG


%OXH


*UHHQ


9LGHR

,Q


$9

&


9LGHR

2XW


77
VM
COILS
Q905
Q907
Q909
Q908
Q906
Y - BOARD
E - BOARD
39
IC351
R OUT
Q1502 Q1503 Q1504
Q1508 Q1509 Q1510
Q1505 Q1506 Q1507
Q1511 Q1512 Q1513
39
IC371
B OUT
39
IC361
G OUT
F - BOARD
25 26 24 23
33
31
32
Q1501
64
61
60
63
58
62
IC1504
IC1501
IC1502
67
65
63
IC1101 R 37
CVBS 68
G 38
B 39
MICRO
PROCESSOR
IC601
AV VIDEO
SWITCH
6
3
E26
1
E25
1
C.I.P.
VIDEO
PROCESSOR
DEFLECTION PROCESSOR
8
E1
6
E16A
6
E71
E1
8
6
4
2
6
C SW 79
M2
6
6
M3
8 6
4
2
M1
Q3201
JK3201
6
M
BOARD
Q320
Q
3202
27
33 34
27 33
34
35 35 28 28
29 29
26 26
30 30
25 25
33 22
11
66
77
88 99
5
4
5
4
3
3
E70 F1
All manuals and user guides at all-guides.com

8
AUDIO BLOCK DIAGRAM
AUDIO
MONITOR
OUT
TUNER
Q101
Q102
IC2101
AV2 AV1
DACM_R 24
SC1_OUT_R 30
SC1_OUT_L 31
1 R OUT
3 L OUT
1 R OUT
3 L OUT
2 R IN
6 L IN
2 R IN
6 L IN
47 ANA_IN1+
DACM_L 25
SC1_IN_R 42
SC1_IN_L 41
SC2_OUT_R 27
SC2_OUT_L 28
SC2_IN_R 40
SC2_IN_L 39
E - BOARD
AUDIO
PROCESSOR
Q2303 Q2301
Q2302 22 DACA_L
Q2304 21 DACA_R
E16
A
1
Q2102 Q2103
Q251
49 ANA_IN2+
Q
1
03
44 MONO IN
2
E10
125 6
Q252 M1
1
2
10
8
M2
JK3201
SC3R
R
SC3L
IC251
5 R R 7
2 L L 11
AUDIO
OUTPUT
L
M5
3 1
M4
R INT
L INT
R
L
1
M7
M - BOARD
1256Z4
1
Z3
IC2201 10
88
10
IC2221 1
Z - BOARD
AFB
All manuals and user guides at all-guides.com

9
IC1101
TUNER
50 SCL 2
SDA 2
SDA 1
SCL 1
Q451
71
LOCAL
KEYS
SWITCH
MATRIX
60
Q854
52
Q853
74
Q1052
81
Q856
75
Q851
Q1106
Q1105
Q1107
Q1104
51 72 73
AV2
8
10 AV LINK
SLOW 2
AV1
8
10
12
SLOW 1
SCL 1 SDA 1
59
58
Q3006
Q3007
55
VPROT
KEYSCAN
ON/OFF
RC
LED
PROT 1
SLOW 2 OUT IN
SLOW 1
SERVICE
SCL SDA
48 49
SCL
SDA
E - BOARD
IC2101 4
8 7
AUDIO
PROCESSOR
MICRO
PROCESSOR
IC1103
6 5
EAROM
Q1051
AFC
61
AFC
IC601
5VIDEO
PROCESSOR
IC601
5
AV VIDEO
SWITCH
RC
E18
7 6 5 4 3
SDA 1 SCL 1 SDA 2 SCL 2
SERVICE
/
TEST
Q601
M1
E16A
8
8
IC1061
REMOTE
CONTROL
RECEIVER
F1
13
21
22
E70
13
21
22
SCL 1 SDA 1
E8
6SENSE
CONVERTER
68 54
17 20
29
62
IC1504 IC1503
67 21
DEFLECTION PROCESSOR
IC1501
VIDEO
PROCESSOR
IC1502
C.I.P.
26
53
19
18
55
56
54
32 31
To Y2
F - BOARD
M - BOARD
L/L’ POS/NEG
83 82
POS/NEG
L/L’
D_CTR_OUT0
E2
2
7
7
Q1062
D1061
Q1106
CONTROL BLOCK DIAGRAM
All manuals and user guides at all-guides.com

10
15V
M11
4 1
F - BOARD
IC801
T801
IC251 D850
TUNER
Q850
IC851
IC853
D454
IC1101 IC1102 IC1103 IC2101
5V SBY
5V SBY
5V
5V
8V
243 66 13132 833
46
3
4
3
1
3
1
S4
B2 P2
P1
S5
S2
S7
10
T551
9
8
5 6 2
12V
200V 150V
-14V
14V
27V
150V
29V
7V
5V
Q854 Q855
1
D805
R805 R814
IC850
1
2
D862
R854
33V
16
M - BOARD
IC1104
2
RESET
MICRO
PROCESSOR AUDIO
PROCESSOR
EPROM EAROM IC1105
2
RESET
REG
REG
REG
IC1501
31 C.I.P.
IC701
6
EW
CORRECTION
POWER
SUPPLY IC451
7
9
2
V-OUTPUT
AUDIO
OUTPUT
~
+
~
D801
E - BOARD
Y - BOARD
E3
2
Y3
2
E2
3 1
E5
1 3C806 IC351
6R OUT
12V
E16A9
M1 9
IC1061
REMOTE
CONTROL
RECEIVER
NEUTRAL
M10 41
Line
Filter
Mains
In
M - BOARD
E70
11 18 19 20
F1
11 18 19 20 IC1502
53
IC1503
VIDEO
PROCESSOR
IC1504
1
Deflection
Processor
CONVERTER
HOUT5V
3.3V
66 36
19
57
9, 25, 35
56, 57, 59
10
28 51
41, 51, 53
Q1502 /3 /5 /6 /8
/
9 /11 /12
E8
1Y2
1
D554
11
IC361
G OUT
IC371
B OUT
6
6
2 2 2
IC856
3
1REG
IC855
13
REG
F801
1
51
54
D458
Q908
Q1504 /7 /10 /13
Q1501
4
IC601
VIDEO
SW
7
IC852
REG
3
1
9V
VIA D1 & D4
VIA M13 & M12
LIVE
1
E16A
P2
1 1
E66
POWER SUPPLY BLOCK DIAGRAM
All manuals and user guides at all-guides.com
all-guides.com

PARTS LOCATION
11
NOTE:
The numbers on the exploded view below
refer to the mechanical section of the
Replacement Parts List.
22
3
17
9
23
24
8
5
4
19
7
62
13
11
10
25
12
26
21
14
1
18
15 16
20
All manuals and user guides at all-guides.com

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type
number to your order.
REPLACEMENT PARTS LIST
Im
p
ortant Safet
y
Notice
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
EXPLODED VIEW
SPEAKER1 EABG12505A2 TUNER2 ENG27514G REMOTE CONTROL3 EUR511211 PANASONIC BADGE4 TBM8E2246 POWER BUTTON5 TBX8E068 DOOR LID6 TKP8E1316 BACK COVER7 TKU8E00470-1 CABINET8 TKY8E380-2 DEGAUSS COIL9 TLK8E05175 CONTROL BRACKET10 TMW8E031 CHASSIS FRAME11 TMX8E037-1 D P.C.B.12 TNP8ED002AA E P.C.B.13 TNP8EE016AE F P.C.B.14 TNP8EF008AA M P.C.B.15 TNP8EM021AN P P.C.B.16 TNP8EP019AB Y P.C.B.17 TNP8EY018AR Z P.C.B.18 TNP8EZ003AB MODEL LABEL19 TQF8E3185 AC CORD20 TXASX01BZJG1 FOCUS LEAD ASSY21 TXJ/FC0DEG BATTERY COVER (REMOTE)22 UR51EC904A CRT FIXING SCREW23 VP19151 C.R.T.24 W66EKT10X71 ANODE CABLE25 ZTBZAD550A FBT26 ZTFM05014A
MISCELLANEOUS COMPONENTS
SET FOOT (FRONT). TBLG3019 SET FOOT (REAR). TBLG3020 PRESET LABEL. TBM8E1935 BLANKING LABEL. TBM8E1936-1 LID CATCH. TEK6940 CRT EARTH SPRING. TES2298 POWER BUTTON SPRING. TES8E021 SPEAKER REFLECTOR. TKK8E026 SPEAKER NET. TKP8E1284 LED COVER. TKP8E1288 I.R. COVER. TKP8E1300 REAR AV PANEL. TKP8E1490 SPEAKER HORN. TKX8E015-A LED HOLDER. TMW8E030 CARTON. TPC8E4925 CUSHION TOP. TPD8E687 CUSHION BOTTOM. TPD8E688 BATTERY PACK. UM-3DJ-2P IC SOCKETIC1101S PCSZT-084A-1 P PCB BRACKETPCH2 TMW8E052 ROTATION COILROT TLK8E05165 VIDEO CABINETVID VS-PK1/2
INSTRUCTION BOOKS
OPERATING INSTRUCTION. TQB8E3291-1
I.C.s
AUDIO OUTPUTIC251 LA4282 RGB OUTPUTIC351 TDA6111Q-N4 RGB OUTPUTIC361 TDA6111Q-N4 RGB OUTPUTIC371 TDA6111Q-N4 REGULATORIC381 TL431CLPM VERTICAL OUTPUTIC451 LA7845N VIDEO SWITCHINGIC601 TEA2114 E/W CORRECTIONIC701 TEA2031A POWER SUPPLYIC801 STRF6656LF57 ERROR AMPLIFIERIC850 SE140N 12V REGULATORIC851 BA12T-M3 8V REGULATORIC853 AN78L08TA REGULATORIC855 BA033T-M3 5V REGULATORIC856 AN7805LB LED RECEIVERIC1061 RPM6937-V4 MICRO PROCESSORIC1101 SDA5450C59 EPROM *IC1102 27C2001-T01 EEPROM *IC1103 XLM3-05JA RESETIC1104 MN1381-R(TA) RESETIC1105 MN1381-T(TA) VIDEO PROCESSORIC1502 VPC3230DQAB3 MICRO PROCESSORIC1503 SDA9400 DOLBY PROCESSORIC1504 DDP3310BPSF5 EARTH CORRECTIONIC1900 LA6515 AUDIO PROCESSORIC2101 MSP3410DPOC5 OPERATIONAL AMPLIFIERIC2201 AN6554NSF-E2 OPERATIONAL AMPLIFIERIC2221 AN6554NSF-E2 AMPLIFIERIC2302 BA15218F-E2
FUSES
FUSE HOLDERF802-2 EYF52BC FUSE HOLDERF802-1 EYF52BC FUSEF802 XBA2C50TH15
DIODES
DIODED251 MA2180BLFS DIODED253 MA700TA5 DIODED254 MA700TA5 DIODED351 ERA15-04V3 DIODED352 ERA15-04V3 DIODED361 ERA15-04V3 DIODED362 ERA15-04V3 DIODED371 ERA15-04V3 DIODED372 ERA15-04V3 DIODED376 MA165TA5 DIODED377 MA165TA5 DIODED378 MA165TA5 DIODED387 MA2160LFS DIODED453 MA165TA5 DIODED454 EU02 DIODED456 MTZJT-777.5B DIODED457 MA165TA5 DIODED501 MA165TA5
12
All manuals and user guides at all-guides.com

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
DIODED502 1SR124-4AT82 DIODED511 MTZJ4.7C DIODED553 1SR124-4AT82 DIODED554 1SR124-4AT82 DIODED556 MA165TA5 DIODED557 TVSRU2AMLFA5 DIODED558 EU02 DIODED560 RH3GLF102 DIODED561 UDZSTE-1722B DIODED562 1SS355TE-17 DIODED580 FMV-3GULF730 DIODED602 MTZJT-775.1B DIODED603 MA165TA5 DIODED604 MA165TA5 DIODED609 1SR124-4AT82 DIODED617 MA3068MTX DIODED620 MA165TA5 DIODED701 MA165TA5 DIODED702 MTZJT-775.6B DIODED704 MA29TA5 DIODED705 MTZJT-777.5B DIODED706 MA165TA5 DIODED707 AU02V0 DIODED708 MA165TA5 DIODED709 MA1033MTA DIODED710 MTZJT-7716C DIODED801 RBV-608LF-B THERMISTORD802 232266296706 DIODED803 1SR124-4AT82 DIODED804 1SR124-4AT82 PHOTO COUPLERD805 TLP621GR-LF2 DIODED806 1SR124-4AT82 DIODED807 MTZJT-7712C THERMISTORD808 232266296706 DIODED850 RU4BLF-L1 DIODED851 MTZJT776.2B DIODED852 MA165TA5 DIODED853 MA2180BLFS DIODED854 S3L20U04P15 DIODED855 D10SC6MRL DIODED856 RU4AMLF-M1 DIODED857 MTZJT-775.1A DIODED858 MA165TA5 DIODED859 MA165TA5 DIODED861 MA165TA5 DIODED862 MTZJT-7736A DIODED863 MA165TA5 DIODED865 MA165TA5 DIODED866 MA165TA5 DIODED867 EK06-V0 DIODED868 1N4150T-77 DIODED869 1N4150T-77 DIODED871 1N4150T-77 DIODED873 MTZJT-775.6C DIODED874 1SR124-4AT82 DIODED875 BZX79A75A26A DIODED890 MA165TA5 DIODED891 MA165TA5 DIODED901 MA165TA5 DIODED902 MA165TA5 DIODED903 MA165TA5 DIODED907 MA165TA5 DIODED910 R2KNLFA1 LEDD1061 LN81RPHCF3 DIODED1101 MA165TA5 DIODED1104 MA165TA5
DIODED1105 MA165TA5 DIODED1131 MTZJT-775.6C DIODED2101 MA723TA5 DIODED2102 MA723TA5 DIODED2103 MA723TA5 DIODED2104 MA723TA5 DIODED2105 MTZJT-778.2C DIODED2303 MA723TA5 DIODED2304 MA723TA5 DIODED3201 MTZJT-778.2C DIODED3202 MTZJT-778.2C DIODED3351 MA165TA5 DIODED3352 MA165TA5 DIODED3353 MA165TA5 DIODED3354 MA165TA5
TRANSISTORS
TRANSISTORQ101 BC847B TRANSISTORQ102 BC847B TRANSISTORQ104 BC847B TRANSISTORQ105 BC847B TRANSISTORQ251 2SD1328STX TRANSISTORQ252 2SD1328STX TRANSISTORQ253 BC847B TRANSISTORQ254 BC847B TRANSISTORQ351 2SA1767 TRANSISTORQ361 2SA1767 TRANSISTORQ371 2SA1767 TRANSISTORQ451 BC857B TRANSISTORQ503 2SK2962TPE6 TRANSISTORQ551 2SC5144LB228 TRANSISTORQ552 2SC1473ATA TRANSISTORQ553 BC847B TRANSISTORQ601 BC847B TRANSISTORQ701 BC857B TRANSISTORQ702 BC847B TRANSISTORQ703 IRF644R-M3S TRANSISTORQ850 2SD2396K-M3 TRANSISTORQ851 BC857B TRANSISTORQ852 2SD1858TV2 TRANSISTORQ853 BC847B TRANSISTORQ854 BC847B TRANSISTORQ855 BC847B TRANSISTORQ856 BC847B TRANSISTORQ857 2SA1018QTA TRANSISTORQ905 BC847B TRANSISTORQ906 BC847B TRANSISTORQ907 BC857B TRANSISTORQ908 2SA1535ARLB TRANSISTORQ909 2SC3944ARLB TRANSISTORQ1051 BC847B TRANSISTORQ1062 BC847B TRANSISTORQ1104 BC847B TRANSISTORQ1105 BC847B TRANSISTORQ1106 BC847B TRANSISTORQ1107 BC847B TRANSISTORQ1108 BC847B TRANSISTORQ1501 BC847B TRANSISTORQ1502 BC857B TRANSISTORQ1503 BC847B TRANSISTORQ1504 BC847B TRANSISTORQ1505 BC857B TRANSISTORQ1506 BC847B TRANSISTORQ1507 BC847B TRANSISTORQ1508 BC857B TRANSISTORQ1509 BC847B TRANSISTORQ1510 BC847B
13
All manuals and user guides at all-guides.com

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
TRANSISTORQ1511 BC857B TRANSISTORQ1512 BC847B TRANSISTORQ1513 BC847B TRANSISTORQ1514 BC847B TRANSISTORQ1515 BC847B TRANSISTORQ1900 BC847B TRANSISTORQ2101 BC857B TRANSISTORQ2102 BC857B TRANSISTORQ2103 BC857B TRANSISTORQ2201 BC847B TRANSISTORQ2202 BC847B TRANSISTORQ2301 BC847B TRANSISTORQ2302 BC857B TRANSISTORQ2303 BC847B TRANSISTORQ2304 BC857B TRANSISTORQ3006 BC847B TRANSISTORQ3007 BC847B TRANSISTORQ3201 BC847B TRANSISTORQ3202 BC847B TRANSISTORQ3203 BC857B TRANSISTORQ3204 BC857B TRANSISTORQ3205 BC847B TRANSISTORQ3206 BC847B TRANSISTORQ3207 BC847B TRANSISTORQ3208 BC847B TRANSISTORQ3209 BC847B TRANSISTORQ3352 BC857B
TRANSFORMERS
TRANSFORMERT501 ETH19Y193AY TRANSFORMERT801 10711520 TRANSFORMERT803 ETP35KAN619U
COILS
COILJ26 EXCELDR35V COILJ212 EXCELSA35V COILJA11 ELJFC2R2KF COILL104 EXCELSA35T COILL106 TLTACT100K COILL107 TLTACT6R8K COILL301 TLTACT4R7K COILL381 TLT220K991R COILL382 ELESN6R8KA COILL451 EXCELSA35T COILL501 EXCELSA35T COILL563 EXCELDR35C COILL581 ELHKLB026B COILL582 ELC18B221L COILL584 ELHKLB055B COILL585 ELC18B120L COILL606 ELESN100KA COILL701 ELC18B271E COILL704 ELC10D332E COILL705 EXCELDR35V COILL810 ETQR42T005A COILL850 EXCELSA35T COILL851 EXCELSA35T COILL852 ELEIE470KA COILL855 EXCELSA35T COILL856 EXCELSA39V COILL910 EXCELSA35T COILL911 EXCELSA35T COILL912 EXCELSA35T COILL1061 TLT331K991R COILL1103 TLTACT100K COILL1104 EXCELSA35T COILL1105 ELJFC2R2KF COILL1501 ELESN2R2KA
COILL1502 ELESN2R2KA COILL1503 ELESN2R2KA COILL1504 ELESN2R2KA COILL1505 ELESN100KA COILL1506 ELESN100KA COILL1510 ELESN100KA COILL1514 ELESN100KA COILL1515 ELESNR39KA COILL1518 ELESN4R7KA COILL1519 ELESNR39KA COILL1520 ELESN2R2KA COILL1521 ELESN1R0KA COILL1522 ELESN3R3KA COILL1523 ELESN3R3KA COILL1524 ELESN3R3KA COILL1526 ELESN100KA COILL1527 ELESN100KA COILL1528 ELESN100KA COILL1529 ELESN100KA COILL1601 ELESN3R3KA COILL1900 EXCELDR25V COILL2101 TLTACT100K COILL2103 EXCELSA35T COILL2104 TLTACT4R7K COILL2202 ELESN2R2KA COILL2222 ELESN2R2KA COILL3001 ELEMV1R5MA COILL3002 ELEMV1R5MA COILL3003 ELEMV1R5MA COILL3004 ELEMV1R5MA COILL3201 ELEBR6R8KA COILL3202 ELEBR6R8KA COILL3204 TLT331K991R
FILTERS
LINE FILTERL1901 ELF18N012A LINE FILTERL1902 ELF18N012A
CRYSTALS
CRYSTALX1101 TSSA121 CRYSTALX1501 4730007267 CRYSTALX1502 4730007341 CRYSTALX2101 4730007158
RESISTORS
S.M.CARBC101 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBC510 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBC2214 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBC2234 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA1 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA2 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA3 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA4 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA5 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA6 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA7 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA8 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA9 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA10 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA10 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA12 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA13 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA13 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA14 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA15 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA16 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA17 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA18 ERJ6GEY0R00 0.1W 5% 0
14
All manuals and user guides at all-guides.com

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CARBJA18 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA19 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA19 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA20 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA20 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA21 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA101 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA102 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA103 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA104 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA105 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA106 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA107 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA108 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA109 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA110 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA111 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA112 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA113 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA114 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA115 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA116 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA117 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA118 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA119 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA120 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJSE10 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE12 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE18 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE22 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE26 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE33 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE35 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE42 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE43 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSM7 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSM8 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSM10 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSY04 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBL114 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBL115 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBL1507 ERJ8GEY0R00 .125W 5% 0
S.M.CARBL1508 ERJ8GEY0R00 .125W 5% 0
S.M.CARBL1509 ERJ8GEY0R00 .125W 5% 0
S.M.CARBR101 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR102 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR103 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR104 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR105 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR106 ERJ6GEYJ681 0.1W 5% 680
S.M.CARBR107 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR111 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR112 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR113 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR116 ERJ6GEYJ562 0.1W 5% 5K6
S.M.CARBR117 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR118 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR121 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR251 ERJ6GEYJ820 0.1W 5% 82
S.M.CARBR252 ERJ6GEYJ751 0.1W 5% 750
S.M.CARBR253 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR254 ERJ6GEYJ820 0.1W 5% 82
S.M.CARBR255 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR256 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR257 ERJ6GEYJ180 0.1W 5% 18
S.M.CARBR258 ERJ6GEYJ751 0.1W 5% 750
S.M.CARBR259 ERJ6GEYJ180 0.1W 5% 18
S.M.CARBR260 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR261 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR262 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR263 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR264 ERJ6GEYJ103 0.1W 5% 10K
CARBONR265 ERD25TJ2R2 0.25W 5% 2R2
CARBONR266 ERD25TJ2R2 0.25W 5% 2R2
WOUNDR267 ERF7ZK4R7 7W 10% 4R7
S.M.CARBR268 ERJ6GEYJ103 0.1W 5% 10K
METALR269 ERQ14AJ101 0.25W 5% 100
S.M.CARBR271 ERJ6GEYJ103 0.1W 5% 10K
WOUNDR272 ERF7ZK4R7 7W 10% 4R7
FUSIBLER350 ERQ12AJ151P 0.5W 5% 150
S.M.CARBR352 ERJ6GEYJ202 0.1W 5% 2K
METALR355 ERG1ANJP683H 0.5W 5% 68K
S.M.CARBR356 ERJ6GEYJ181 0.1W 5% 180
CARBONR358 ERDS1TJ821 0.5W 5% 820
METALR360 ERO50PKF8251 0.5W 5% 8M2
S.M.CARBR362 ERJ6GEYJ202 0.1W 5% 2K
METALR365 ERG1ANJP683H 0.5W 5% 68K
S.M.CARBR366 ERJ6GEYJ181 0.1W 5% 180
CARBONR368 ERDS1TJ821 0.5W 5% 820
S.M.CARBR372 ERJ6GEYJ202 0.1W 5% 2K
METALR375 ERG1ANJP683H 0.5W 5% 68K
S.M.CARBR376 ERJ6GEYJ181 0.1W 5% 180
CARBONR378 ERDS1TJ821 0.5W 5% 820
S.M.CARBR382 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR383 ERJ6GEY0R00 0.1W 5% 0
METALR385 ERQ12HJ1R0 0.5W 5% 1
S.M.CARBR394 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR396 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR398 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR451 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR452 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR453 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR454 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR455 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR456 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR457 ERJ6GEYJ223 0.1W 5% 22K
CARBONR458 ERDS1TJ1R0 0.5W 5% 1
S.M.CARBR459 ERJ6GEYJ101 0.1W 5% 100
FUSIBLER461 ERX2SJS1R5H 2W 5% 1R5
CARBONR463 ERDS2TJ222T 0.5W 5% 2K2
S.M.CARBR464 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR465 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR467 ERJ6GEY0R00 0.1W 5% 0
METALR468 ERG3SJS221H 3W 5% 220
S.M.CARBR502 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR503 ERJ6GEYJ105 0.1W 5% 1M
METALR507 ERX3SJS4R7 3W 5% 4R7
METALR509 ERG2SJW272E 2W 5% 2K2
METALR510 ERG2SJW272E 2W 5% 2K2
METALR551 ERX3SJSR22 3W 5% R22
FUSIBLER555 ERQ12HKR82 0.5W 10% R82
CARBONR558 ERDS1TJ124 0.5W 5% 120K
FUSIBLER559 ERQ12HKR82 0.5W 10% R82
S.M.CARBR560 ERJ6GEYJ274 0.1W 5% 270K
S.M.CARBR561 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR563 ERJ6GEYJ564 0.1W 5% 560K
S.M.CARBR564 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR566 ERJ6GEYJ563 0.1W 5% 56K
WOUNDR567 ERF7ZK1R0 7W 10% 1
CARBONR568 ERDS1TJ120 0.5W 5% 12
S.M.CARBR569 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR571 ERJ6GEYJ104 0.1W 5% 100K
15
All manuals and user guides at all-guides.com
all-guides.com

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CARBR572 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR573 ERJ6GEYJ101 0.1W 5% 100
METALR581 ERQ2CJP821 2W 5% 820
METALR583 ERG3FJ331 3W 5% 330
METALR585 ERG3FJ471 3W 5% 470
S.M.CARBR603 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR604 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR605 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR606 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR607 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR608 ERJ6GEYJ201 0.1W 5% 200
S.M.CARBR609 ERJ6GEYJ201 0.1W 5% 200
S.M.CARBR610 ERJ6GEYJ242 0.1W 5% 2K4
S.M.CARBR611 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR612 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR620 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR622 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR647 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR648 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR650 ERJ6GEYJ750 0.1W 5% 75
METALR701 ERQ12AJ330P 0.5W 5% 330
METALR702 ERX2SJS2R7H 2W 5% 2R7
METALR703 ERG2FJ821 2W 5% 820
S.M.CARBR704 ERJ6GEYJ563 0.1W 5% 56K
S.M.CARBR705 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR706 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR707 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR708 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR709 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR710 ERJ6GEYJ273 0.1W 5% 27K
METALR711 ERG1SJ101 1W 5% 100
S.M.CARBR712 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR714 ERJ6GEYJ223 0.1W 5% 22K
CARBONR715 ERD25TJ272F 0.25W 5% 2K7
METALR716 ERQ12AJ680P 0.5W 5% 68
S.M.CARBR718 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR719 ERJ6GEYJ394 0.1W 5% 390K
S.M.CARBR720 ERJ6GEYJ183 0.1W 5% 18K
SOLIDR802 ERC12ZGK335D 0.5W 10% 3M3
CARBONR805 ERD25TJ473 0.25W 5% 47K
CARBONR806 ERD25TJ100 0.25W 5% 10
CARBONR807 ERD25TJ332 0.25W 5% 3K3
CARBONR809 ERD25TJ681 0.25W 5% 680
WOUNDR810 ERW2PKR22 2W 5% 22
WOUNDR811 ERW2PKR22 2W 5% 22
CARBONR812 ERD75TAJ825 0.75W 5% 8M2
WOUNDR813 ERF10ZK2R7 10W 5% 2.7
CARBONR814 ERD25TJ473 0.25W 5% 47K
CARBONR815 ERD25TJ222 0.25W 5% 2K2
CARBONR817 ERDS2TJ104T 2W 5% 100K
CARBONR850 ERD25TJ122 0.25W 5% 1K2
S.M.CARBR852 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR853 ERJ6GEYJ102 0.1W 5% 1K
METALR854 ERG2FJ223 2W 5% 22K
S.M.CARBR855 ERJ6GEYJ752 0.1W 5% 7K5
S.M.CARBR857 ERJ6GEYJ752 0.1W 5% 7K5
S.M.CARBR858 ERJ6GEYJ752 0.1W 5% 7K5
S.M.CARBR859 ERJ6GEYJ753 0.1W 5% 75K
CARBONR861 ERDS2TJ221T 0.5W 5% 220
CARBONR862 ERD25TJ272F 0.25W 5% 2K7
CARBONR863 ERDS1TJ560 0.5W 5% 56
CARBONR864 ERDS1TJ151 0.5W 5% 150
S.M.CARBR865 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR866 ERJ6GEYJ681 0.1W 5% 680
S.M.CARBR867 ERJ6GEYJ272 0.1W 5% 2K7
S.M.CARBR868 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR869 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR870 ERJ6GEYJ272 0.1W 5% 2K7
S.M.CARBR871 ERJ6GEYJ153 0.1W 5% 15K
METALR872 ERG1SJ183 1W 5% 18K
METALR873 ERG1SJ223 1W 5% 22K
CARBONR874 ERDS2TJ104T 2W 5% 100K
S.M.CARBR876 ERJ6GEYJ103 0.1W 5% 10K
WOUNDR877 ERW2PKR47 2W 10% R47
S.M.CARBR878 ERJ6GEYJ473 0.1W 5% 47K
METALR879 ERG3FJ680H 3W 5% 68
METALR880 ERG5FJ120H 5W 5% 12
METALR882 ERG2FJ120 2W 5% 12
FUSIBLER890 ERX1FJ3R9P 1W 5% 3R9
S.M.CARBR913 ERJ6GEYJ183 0.1W 5% 18K
S.M.CARBR914 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR915 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR916 ERJ6GEYJ221 0.1W 5% 220
S.M.CARBR917 ERJ6GEYJ121 0.1W 5% 120
S.M.CARBR918 ERJ6GEY0R00 0.1W 5% 0
FUSIBLER919 ERQ14AJW390 0.25W 5% 39
FUSIBLER920 ERQ14AJW390 0.25W 5% 39
CARBONR922 ERDS2TJ683T 2W 5% 68K
CARBONR923 ERDS2TJ683T 2W 5% 68K
CARBONR924 ERDS1FYJ390 0.5W 5% 39
S.M.CARBR925 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR926 ERJ6GEY0R00 0.1W 5% 0
CARBONR927 ERD25TJ122 0.25W 5% 1K2
CARBONR928 ERD25TJ5R6 0.25W 5% 5R6
CARBONR929 ERDS1FVJ471 0.5W 5% 470
CARBONR931 ERDS1FYJ390 0.5W 5% 39
FUSIBLER935 ERQ14AJW3R9 0.25W 5% 3R9
FUSIBLER936 ERQ1CJP102 1W 5% 1K
FUSIBLER937 ERQ14AJW100 0.25W 5% 10
CARBONR938 ERD25TJ122 0.25W 5% 1K2
CARBONR941 ERD25TJ5R6 0.25W 5% 5R6
S.M.CARBR1051 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR1062 ERJ6GEYJ271 0.1W 5% 270
S.M.CARBR1063 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1101 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1102 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR1103 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR1104 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR1105 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1106 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR1107 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR1108 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR1109 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1110 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1111 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1112 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR1113 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1114 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1115 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1116 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1117 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1118 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1119 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1120 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1121 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1123 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1124 ERJ6GEYJ1R0 0.1W 5% 1
S.M.CARBR1125 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1126 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1127 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1128 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR1129 ERJ6GEYJ682 0.1W 5% 6K8
16
All manuals and user guides at all-guides.com

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CARBR1130 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1131 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1132 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1133 ERJ6GEYJ272 0.1W 5% 2K7
S.M.CARBR1136 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR1137 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1138 ERJ6GEYJ105 0.1W 5% 1M
S.M.CARBR1139 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1140 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1141 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1145 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1146 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1147 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1148 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1149 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR1151 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1152 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1156 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1157 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1158 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1159 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1160 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR1161 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1163 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1164 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1165 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1166 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1167 ERJ6GEYJ100 0.1W 5% 10
S.M.CARBR1168 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR1169 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1170 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR1171 ERJ6GEYJ224 0.1W 5% 220K
S.M.CARBR1172 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR1173 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR1174 ERJ6GEYJ221 0.1W 5% 220
S.M.CARBR1175 ERJ6GEYJ225 0.1W 5% 2M2
S.M.CARBR1178 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1251 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR1252 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR1253 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR1254 ERJ6GEYJ512 0.1W 5% 5K1
S.M.CARBR1255 ERJ6GEYJ912 0.1W 5% 9K1
S.M.CARBR1501 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1504 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1505 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1506 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1507 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1508 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR1509 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1510 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1511 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1512 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1513 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR1514 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1515 ERJ6GEYJ752 0.1W 5% 7K5
S.M.CARBR1521 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1522 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR1523 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR1524 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR1525 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1526 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR1527 ERJ6GEYJ122 0.1W 5% 1K2
S.M.CARBR1528 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR1529 ERJ6GEYJ122 0.1W 5% 1K2
S.M.CARBR1530 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1531 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR1532 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR1533 ERJ6GEYJ122 0.1W 5% 1K2
S.M.CARBR1534 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR1535 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1536 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR1537 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR1538 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR1539 ERJ6GEYJ271 0.1W 5% 270
S.M.CARBR1540 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR1541 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1542 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1543 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1544 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1545 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1546 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1547 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1548 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1549 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1550 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1551 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1552 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1553 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1556 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1557 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1574 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR1577 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1578 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1579 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1580 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1584 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1585 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1586 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1587 ERJ6GEYJ152 0.1W 5% 1K5
S.M.CARBR1588 ERJ6GEYJ511 0.1W 5% 510
S.M.CARBR1589 ERJ6GEYJ152 0.1W 5% 1K5
S.M.CARBR1590 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1598 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1601 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1602 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1603 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR1604 ERJ6GEYJ750 0.1W 5% 75
FUSIBLER1900 ERQ12HJ150 0.1W 5% 15
S.M.CARBR1901 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR1902 ERJ6GEYJ183 0.1W 5% 18K
S.M.CARBR1903 ERJ6GEYJ223 0.1W 5% 22K
CARBONR1904 ERDS1TJ2R2 0.5W 5% 2R2
S.M.CARBR1905 ERJ6GEYJ753 0.1W 5% 75K
S.M.CARBR1906 ERJ6GEYJ753 0.1W 5% 75K
S.M.CARBR1907 ERJ6GEYJ753 0.1W 5% 75K
S.M.CARBR1908 ERJ6GEYJ103 0.1W 5% 10K
CARBONR1909 ERDS1TJ2R2 0.5W 5% 2R2
CARBONR1910 ERDS1TJ8R2 0.5W 5% 8R2
CARBONR1911 ERDS1TJ8R2 0.5W 5% 8R2
SOLIDR1912 ERC12ZGK335D 0.5W 10% 3M3
S.M.CARBR1913 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1914 ERJ6GEYJ272 0.1W 5% 2K7
S.M.CARBR2101 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2102 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2103 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2109 ERJ6GEYJ183 0.1W 5% 18K
S.M.CARBR2110 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR2111 ERJ6GEYJ221 0.1W 5% 220
S.M.CARBR2112 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2113 ERJ6GEYJ562 0.1W 5% 5K6
S.M.CARBR2114 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2115 ERJ6GEYJ822 0.1W 5% 8K2
17
All manuals and user guides at all-guides.com

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CARBR2116 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2117 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2118 ERJ6GEYJ822 0.1W 5% 8K2
S.M.CARBR2119 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2120 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2200 ERJ6GEYJ183 0.1W 5% 18K
S.M.CARBR2201 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR2202 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2203 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2204 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR2206 ERJ6GEYJ272 0.1W 5% 2K7
S.M.CARBR2207 ERJ6GEYJ123 0.1W 5% 12K
S.M.CARBR2208 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2209 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2210 ERJ6GEYJ822 0.1W 5% 8K2
S.M.CARBR2211 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR2212 ERJ6GEYJ224 0.1W 5% 220K
S.M.CARBR2213 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2214 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2215 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR2216 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2217 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2218 ERJ6GEYJ151 0.1W 5% 150
S.M.CARBR2219 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2220 ERJ6GEYJ183 0.1W 5% 18K
S.M.CARBR2221 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR2222 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2223 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2224 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR2226 ERJ6GEYJ272 0.1W 5% 2K7
S.M.CARBR2227 ERJ6GEYJ123 0.1W 5% 12K
S.M.CARBR2228 ERJ6GEYJ154 0.1W 5% 150K
S.M.CARBR2229 ERJ6GEYJ151 0.1W 5% 150
S.M.CARBR2230 ERJ6GEYJ822 0.1W 5% 8K2
S.M.CARBR2231 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR2232 ERJ6GEYJ224 0.1W 5% 220K
S.M.CARBR2233 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2234 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2235 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR2236 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2237 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2238 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2239 ERJ6GEYJ154 0.1W 5% 150K
S.M.CARBR2240 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR2241 ERJ6GEYJ220 0.1W 5% 22
S.M.CARBR2302 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2303 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2304 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2305 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2306 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2308 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2309 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2310 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2311 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2312 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR3001 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3002 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR3003 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3004 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR3005 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3006 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR3007 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3008 ERJ6GEYJ153 0.1W 5% 15K
CARBONR3010 ERD25TJ750 0.25W 5% 75
S.M.CARBR3013 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3014 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR3015 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3016 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR3017 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3018 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR3019 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3020 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR3021 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3046 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3047 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3048 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR3049 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3050 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR3057 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3201 ERJ6GEYJ750 0.1W 5% 75
CARBONR3202 ERDS1TJ151 0.5W 5% 150
CARBONR3203 ERDS1TJ151 0.5W 5% 150
METALR3204 ERG2FJ221 2W 5% 220
METALR3205 ERG2FJ221 2W 5% 220
S.M.CARBR3207 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3208 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR3209 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3210 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR3211 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR3212 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR3213 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3214 ERJ6GEYJ683 0.1W 5% 68K
S.M.CARBR3215 ERJ6GEYJ302 0.1W 5% 3K
S.M.CARBR3216 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR3217 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR3218 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR3219 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3220 ERJ6GEYJ683 0.1W 5% 68K
S.M.CARBR3221 ERJ6GEYJ302 0.1W 5% 3K
S.M.CARBR3222 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR3223 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR3224 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3225 ERJ6GEYJ683 0.1W 5% 68K
S.M.CARBR3226 ERJ6GEYJ302 0.1W 5% 3K
S.M.CARBR3227 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3228 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR3229 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR3230 ERJ6GEYJ302 0.1W 5% 3K
S.M.CARBR3231 ERJ6GEYJ122 0.1W 5% 1K2
S.M.CARBR3232 ERJ6GEYJ242 0.1W 5% 2K4
S.M.CARBR3233 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR3234 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3354 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3355 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR3356 ERJ6GEYJ681 0.1W 5% 680
S.M.CARBR3357 ERJ6GEYJ681 0.1W 5% 680
S.M.CARBR3358 ERJ6GEYJ681 0.1W 5% 680
CARBONR3360 ERDS1TJ471 0.5W 5% 470
METALR3361 ERO50PKF1133 0.5W 5% 110K
S.M.CARBR3362 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3363 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3364 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR3601 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3602 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3603 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR3614 ERJ6GEYJ391 0.1W 5% 390
CAPACITORS
CERAMICC102 ECJ2VF1H103Z 50V 10nF
CERAMICC103 ECJ2VF1H104Z 50V 100nF
S.M. CAPC106 ECUV1H560JCX 50V 56pF
CERAMICC107 ECJ2VF1H104Z 50V 100nF
ELECTC108 ECA1CM100GB 16V 10µF
18
All manuals and user guides at all-guides.com

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M. CAPC109 ECUV1H102JCX 50V 1nF
CERAMICC110 ECJ2VF1H103Z 50V 10nF
ELECTC111 ECA1HMR33GB 50V 0.33µF
CERAMICC117 ECJ2VF1H103Z 50V 10nF
CERAMICC118 ECJ2VF1H104Z 50V 100nF
ELECTC119 ECA1CM221GB 16V 220µF
ELECTC120 ECA1CM221GB 16V 220µF
S.M. CAPC121 ECUV1H561KBX 50V 560pF
S.M. CAPC124 ECUV1H220JCX 50V 22pF
ELECTC125 ECJ2VC1H100D 50V 10µF
ELECTC251 ECA1CM100GB 16V 10µF
S.M. CAPC252 ECUV1H103KBX 50V 10nF
ELECTC253 ECA1HM4R7GB 50V 4.7µF
FILMC254 ECQV1H224JL3 50V 220nF
ELECTC255 ECA1EM101GB 25V 100µF
S.M. CAPC256 ECUV1H103KBX 50V 10nF
ELECTC257 ECA1HM4R7GB 50V 4.7µF
ELECTC258 ECA1CM100GB 16V 10µF
FILMC259 ECQV1H224JL3 50V 220nF
ELECTC260 ECA1VM102GB 35V 1nF
ELECTC261 ECA1VM102GB 35V 1nF
ELECTC262 ECA1HM2R2GB 50V 2.2µF
ELECTC263 ECA1HM010GB 50V 1µF
ELECTC264 ECA1HHG222E 50V 2200µF
ELECTC265 ECA1HM2R2GB 50V 2.2µF
ELECTC266 ECA1HM010GB 50V 1µF
CERAMICC267 ECJ2VB1H104K 50V 100nF
CERAMICC268 ECJ2VB1H104K 50V 100nF
CERAMICC270 ECJ2VB1H104K 50V 100nF
S.M. CAPC350 ECUV1H102JCX 50V 1nF
S.M. CAPC352 ECUV1H224ZFX 50V 220nF
CERAMICC353 ECJ2YB1H104K 50V 100nF
FILMC354 ECQM2104KZ 250V 100nF
CERAMICC355 ECKC2H102J 500V 1nF
CERAMICC358 ECJ2VC1H222J 50V 2.2nF
S.M. CAPC360 ECUV1H102JCX 50V 1nF
S.M. CAPC362 ECUV1H224ZFX 50V 220nF
CERAMICC363 ECJ2YB1H104K 50V 100nF
FILMC364 ECQM2104KZ 250V 100nF
CERAMICC365 ECKC2H102J 500V 1nF
CERAMICC368 ECJ2VC1H222J 50V 2.2nF
S.M. CAPC369 ECUV1H220JCX 50V 22pF
S.M. CAPC370 ECUV1H102JCX 50V 1nF
S.M. CAPC372 ECUV1H224ZFX 50V 220nF
CERAMICC373 ECJ2YB1H104K 50V 100nF
FILMC374 ECQM2104KZ 250V 100nF
CERAMICC375 ECKC2H102J 500V 1nF
CERAMICC378 ECJ2VC1H222J 50V 2.2nF
ELECTC381 ECA1HM101GB 50V 100µF
ELECTC382 ECA1CM471GB 16V 470µF
S.M. CAPC383 ECUV1H103KBX 50V 10nF
FILMC384 ECQM2104KZ 250V 100nF
ELECTC385 ECA2EM220B 250V 22µF
CERAMICC386 ECKC3D332J 2KV 3.3µF
FILMC395 ECQV1H104J 50V 100nF
CERAMICC451 ECJ2VG1H102J 50V 1000µF
S.M. CAPC453 ECUV1H152KBX 50V 1.5pF
FILMC454 ECQV1H105JZ 50V 1µF
ELECTC455 ECA1HM100GB 50V 10µF
ELECTC456 ECA1HHG221B 50V 220µF
FILMC459 ECQB1224KFW 100V 220nF
FILMC508 ECQB1H103J 50V 10nF
ELECTC509 ECA1VM470B 35V 47µF
FILMC511 ECQM2A104KZ 100V 100nF
CERAMICC551 ECKC3D561J 2KV 560pF
FILMC552 ECWH15H102JN 1500V 1nF
CERAMICC557 ECKC2H471J 500V 470pF
ELECTC558 ECA1HHG471E 50V 470µF
ELECTC561 ECA1EHG102B 25V 1000µF
CERAMICC562 ECKC2H101J 500V 100pF
ELECTC563 ECA2EHG220B 250V 20µF
ELECTC564 ECEA2AU2R2 100V 2.2µF
FILMC565 ECQP1H273J 100V 2700µF
CERAMICC566 ECKC2H471J 500V 470pF
ELECTC567 ECA1EHG102B 25V 1000µF
CERAMICC568 ECKC2H471J 500V 470pF
CERAMICC569 ECKC2H102J 500V 1nF
CERAMICC572 ECJ2YB1H104K 50V 100nF
FILMC581 ECWF4684JBB 400V 680nF
FILMC582 ECWF4474JBB 400V 470nF
FILMC583 ECWH20562JVB 200V 5.6nF
FILMC584 ECWH20562JVB 200V 5.6nF
FILMC586 ECQF4153JZH 400V 1.5nF
FILMC587 ECQM4223KC 400V 220nF
S.M. CAPC608 ECUV1H103KBX 50V 10nF
S.M. CAPC609 ECUV1H270JCX 50V 27pF
CERAMICC623 ECJ2VC1H121J 50V 120pF
CERAMICC624 ECJ2VC1H121J 50V 120pF
FILMC625 ECQV1H224JL3 50V 220nF
ELECTC626 ECA1CM100GB 16V 10µF
CERAMICC627 ECJ2VB1C104K 16V 100nF
FILMC628 ECQV1H224JL3 50V 220nF
ELECTC701 ECA1HHG101B 50V 100µF
S.M. CAPC702 ECUV1H103KBX 50V 10nF
ELECTC703 ECEA1HGE100 50V 10µF
CERAMICC704 ECJ2VB1H223K 50V 22nF
FILMC705 ECQB1H821J 50V 820nF
FILMC709 ECQV1H105JZ 50V 1µF
FILMC801 ECQE6104K 600V 100nF
CERAMICC806 ECKWNA101MBC 400V 100µF
CERAMICC807 ECKC2H472J 500V 4.7nF
CERAMICC808 ECKC2H472J 500V 4.7nF
CERAMICC809 ECKC2H472J 500V 4.7nF
CERAMICC810 ECKC2H472J 500V 4.7nF
ELECTC811 ECOS2GA221CA 400V 220µF
CERAMICC814 ECKC3D102J 2KV 1nF
CERAMICC815 ECKC1H471J 50V 470pF
ELECTC816 ECA1EM101GB 25V 100µF
CERAMICC818 ECKCNS332J 1.2KV 3.3nF
FILMC819 ECQB1H102J 50V 1nF
CERAMICC820 ECJ2VF1H104Z 50V 100nF
FILMC823 222233821154 250 150nF
ELECTC839 ECA1CM100GB 16V 10µF
CERAMICC840 ECJ2YB1H104K 50V 100nF
ELECTC841 ECA1AM222B 10V 2200µF
ELECTC842 ECA1CM100GB 16V 10µF
CERAMICC850 ECKC3D471JB 2KV 470pF
ELECTC851 ECA2CHG221E 160V 220µF
CERAMICC852 EEUEB2D101B 250V 100pF
CERAMICC853 ECKC2H471J 500V 470pF
ELECTC854 ECA1EM102GB 25V 100µF
CERAMICC855 ECKC2H471J 500V 470pF
ELECTC856 ECA1AHG332B 10V 3.3nF
CERAMICC857 ECKC2H471J 500V 470pF
ELECTC858 ECEA1HGE102 50V 1000µF
CERAMICC859 ECJ2VF1H104Z 50V 100nF
ELECTC860 ECA1HM101GB 50V 100µF
CERAMICC862 ECJ2VF1H104Z 50V 100nF
ELECTC863 ECA1HM101GB 50V 100µF
CERAMICC866 ECJ2VF1H104Z 50V 100nF
ELECTC867 ECA1CM100GB 16V 10µF
ELECTC868 ECA1CM100GB 16V 10µF
19
All manuals and user guides at all-guides.com
