Panasonic PV-V4524S Assembly Instructions

LSQT0761 A
Video Cassette Recorder
Operating Instructions
(Basic Operations)
For advanced operations, see the separate
“Advanced Operations” instruction book.
Model No. PV-V4524S
• Limited Warranty • Customer Services Directory • Guía para rápida consulta (Spanish Quick Use Guide)
- 12 -
- 11 -
• Guía para rápida consulta (Spanish Quick Use Guide) • Location of Controls (Multi Function Display, Rear View of the VCR)
- 9 -
Panasonic Consumer Electronics Company,
Division of Matsushita Electric Corporation of America
One Panasonic Way Secaucus, New Jersey 07094
Panasonic Sales Company (“PSC”),
Division of Matsushita Electric of Puerto Rico, Inc.
Ave. 65 de Infantería. Km. 9.5 San Gabriel Industrial Park, Carolina,
Puerto Rico 00985
Printed in Indonesia
LSQT0761
A
S1203-1014
P
Hi-Fi Indicator
Lights up when Hi-Fi audio is present
in Playback Mode.
VCR Indicator
Lights up when the VCR/TV
selector is set to VCR.
Power Indicator
Lights up when power is on.
Clock/ Status/ Channel/ Speed Display
Displays current time. Briefly displays VCR
status when you press a function button,
channel number or “L1” or “L2” when you
select channel or line input, and recording
speed when you press SPEED.
Multi Function Display (FRONT DISPLAY)
Timer Indicator
Lights up when the VCR is set for a Timer
Recording, or when One Touch Recording
(OTR) is used.
Flashes when a Timer Recording is set, but a
tape has not been inserted into the VCR.
Location of Controls/ Reset All VCR Memory Functions
- 8 -
Spanish Quick Use Guide/ Guía para rápida consulta
VCR
VHF/UHF
Estuche convertidor
deTV por cable
Televisor Terminal
IN FROM ANT.
Entrada (IN) desde
ANT./CABLE
Terminal
OUTTO TV
TerminalIN FROM ANT.
Televisor VCR
VHF/UHF
Terminal
OUT TOTV
Entrada (IN) desde
ANT./CABLE
Spanish Quick Use Guide/ Guía para rápida consulta
CONEXIONES
Conecte el cable de la antena al
terminal IN FROM ANT del VCR.
Conecte el terminal OUT TO TV del
VCR a la entrada de la antena VHF/UHF
del TV con el cable RF incluido.
Para Ant/Cable ➛➛
➛➛
➛VCR ➛➛
➛➛
➛TV
Para Sistema Digital de Satelite (DSS)/ Convertidor de cable ➛➛
➛➛
➛VCR ➛➛
➛➛
➛TV
Conecte la salida de convertidor de
cable al terminal IN FROM ANT.
Conecte el terminal OUT TO TV del
VCR a la entrada de la antena VHF/UHF
del TV con el cable RF incluido.
1
2
1
2
Realice la conexión de la antena oTV por cable antes de enchufar el cable de CA.
La videograbadora iniciaráautomáticamente la fijación de los canales y del reloj al enchufar el cable de CA.
2
1
2
1
CONEXIONES/CONFIGURACIÓN INICIAL (READY TO PLAY)
1Encienda el TV y cambie al canal 3.
2Enchufe el cable de CA.
La videograbadora se encenderá e iniciará
las fijaciones de los canales y del reloj.
•Si la pantalla a continuación no aparece...
verifique todas las conexiones.
Intente sintonizar el TV en el canal 4.
•Para cambiar el canal de salida del VCR,
consulte las instrucciones de “VCR’s Output
Channel (Canal de salida del VCR)”en la
página 12 de las operaciones avanzadas.
Si estáusando un convertidor de TV por cable
y en su area hay un canal de Public Broadcast
Station (PBS), ajuste su convertidor al canal
PBS de su area.
Si estáusando un receptor DSS, este debe
estar apagado.
CONFIGURACIÓN INICIAL
3Las fijaciones se realizan
automáticamente. Cuando termina las
fijaciones, aparecerá la siguiente pantalla.
Si aparece en la pantalla “AUTO CLOCK
SET IS INCOMPLETE (FIJACION
AUTOMATICA DEL RELOJ ES
INCOMPLETO)”, Ajuste el reloj como se
describe a continuación.
AJUSTE MANUAL DEL RELOJ
Si la fijación ha sido incompleta.
1Presione la tecla ACTION en el control
remoto para visualizar la pantalla del menú
CLOCK.
2Presione para seleccionar el mes y
para ajustar. De la misma forma,
seleccione y ajuste la fecha, año, hora y
DST (Hora de Verano).
3Presione dos veces la tecla ACTION para
poner el RELOJ en marcha y salir.
Enchufe el cable de CA.
Nota
•Los botones de funciones no funcionan
durante la configuración inicial.
•Para retirar un cassette durante el ajuste
automático, presione EJECT en el control
remoto o STOP dos veces en el aparato.
En este caso, los ajustes de los canales y la
hora se deben hacer manualmente. Para los
ajustes seleccione la pantalla MENU.
(Vea la p.12 de Libro de Operaciones
Avanzadas).
•Dependiendo de las condiciones, el ajuste
automático puede durar más de 30 minutos.
En ese caso, presione STOP para detener el
ajuste automático y realice los ajustes
manualmente en la pantalla MENU. (Vea la
p.12 de Libro de Operaciones Avanzadas).
Returns to factory setting. Use if relocating VCR, or if Initial Setup needs to be redone.
•Make sure a tape is not inserted in the VCR.
Reset All VCR Memory Functions
21
Press and hold both PLAY and CHANNEL
on the VCR for more than 5 seconds.
•The power shuts off.
Turn VCR Power on.
3Perform “Initial Setup (Ready to Play)”on
page 4.
2
1
DST : O N
1 / 1/2004 THU -- - 12:00 PM
- - - - - - - - -- - - - - - - -- - - - - -
SET C L OC K
SELECT : SET :
END
: ACT I O N
DST : O N
6 /20/2004 SUN - - 15:30 PM
- - - - - - - - -- - - - - - - -- - - - - -
SET C L OC K
SELECT : SET :
START
: ACT I O N
AUTO CLOCK SET
IS
I NC O M PLETE
PLEASE SET CLOCK BY
PRESSING
ACT I ON KEY
AUTO CLOCK SET
PROCEEDING
CANCEL : STOP
CH AUTO SET PROCEEDING
CANCEL : STOP
Please read these instructions carefully before attempting to
connect, operate or adjust this product. Please save this manual.
Spanish Quick Use Guide is included.
(Guía para rápida consulta en español estáincluida.)
Rear View of the VCR
OUT
IN1
OUTTOTV
VIDEO
AUDIO
INFROM ANT.
VHF/UHF
R
L
VHF/UHF Antenna
Input Terminal
VHF/UHF Antenna
Output Terminal
VideoOutput
Connector Audio Output
Connector (L/R)
Audio Input Connector
(L/R)
Video Input Connector
AC Power Plug
While plugged into an AC outlet, the
VCR consumes 0.95 W of electrical
power in off condition.
- 10 -
Spanish Quick Use Guide/ Guía para rápida consulta
OPERACIONES BÁSICAS PARA LA
REPRODUCCIÓN
Detalles especiales durante la grabación
Presione FF oREW para búsqueda de
escenas hacia delante/ hacia atrás.
Presione PLAY para liberar.
Después de comenzar la búsqueda, cada vez
que presione FF o REW cambiarála velocidad.
Presione PAUSE/SLOW para imagen Fija
(Congelada).
Presione PLAY para liberar.
Mantenga pulsado PAUSE/SLOW en el
modo de imagen fija para imágenes en
cámara lenta.
Presione PLAY para liberar.
Presione EJECT en el control remoto, o
STOP/EJECT en el VCR para expulsar el
cassette.
Presione REW oFF en el modo de parada
para rebobinado/avance rápido del cassette.
1Inserte una cassette.
2Presione PLAY para reproducir el cassette.
•La alimentación del VCR se activa. Si Auto
VCR/TV (vea la p.10 de Libro de Operaciones
Avanzadas) estáen “ACT”, presione VCR/TV
en el control remoto para el modo VCR.
•Si el cassette no tiene la lengüeta de
prevención de grabación (p. 3), se inicia la
reproducción automáticamente.
3Presione STOP para detener el cassette.
PROGRAMACIÓN FÁCIL PARA LA
GRABACIÓN CON TEMPORIZADOR
1Presione PROG para visualizar la
pantalla de Programación.
Grabación de un toque.
Presione REC repetidamente para ajustar la
duración de la grabación como sigue: como
sigue: 30 min. ➛➛
➛➛
➛1 hr ➛➛
➛➛
➛1:30hr ➛➛
➛➛
➛2:00 ➛➛
➛➛
➛3:00
➛➛
➛➛
➛4:00 ➛➛
➛➛
➛Salida.
La VCR se apagara automáticamente en en
intervalo seleccionado de tiempo.
OPERACIONES BÁSICAS PARA LA
GRABACIÓN
1Inserte el cassette con lengüeta de
protección de grabación (p. 3).
•La alimentación del VCR se activa. Si Auto
VCR/TV (vea la p.10 de Libro de Operaciones
Avanzadas) estáen “ACT”, presione VCR/TV
en el control remoto para el modo VCR.
2Presione CH ,o las teclas de
números para seleccionar el canal.
3Presione SPEED para seleccionar la
velocidad de grabación (p. 3)
•SP = Reproducción normal,
•SLP = Reproducción extra larga.
4Presione REC para comenzar a grabar.
•Para eliminar escenas indeseadas, presione
PAUSE/SLOW para hacer una pausa, y al
presionar nuevamente continua la grabación.
5Presione STOP para detener la grabación.
Ver un canal y grabar otro.
Presione VCR/TV.
(La indicación VCR se apagara en la
“visualización de Multi-Función”)
➛➛
➛➛
➛Seleccione canales de TV (Mientras
permanece grabando)
Seleccione los canales en el VCR.
Presione VCR/TV en el modo de parada o
pausa.
(la indicación “VCR”se encenderáen la
vizualización multi-función)
➛➛
➛➛
➛Seleccione canales en su VCR.
PARA CANCELAR LA GRABACIÓN
CON TEMPORIZADOR
(la grabación está teniendo lugar)
Presione POWER y luego STOP dentro de
los 10 segundos para cancelar la grabación
con temporizador (el indicador TIMER se
apagaráen la Pantalla de Multi-Función)
•Rebobina una cinta T-120 en
aproximadamente 1 minuto.
Rebobinado/Avance rápido Presione para seleccionar un número
que no estáusando para ingresar mas
programas y presione para ajustar.
Luego repita el paso 2.
Presione nuevamente
PROG para salir.
Presione PROG para finalizar el
programa.
Fecha de hoy
Orden para elegir
Ejemplo
3) Ajustes los ítems restantes, presione
para ajustar los tiempos de INICIO/
PARADA, CANAL o entrada de LINEA
(página 9 de las operaciones
avanzadas), y la velocidad de la cinta
(página 3).
Luego presione para seleccionar.
Presione POWER off para ajustar el
temporizador.
(Se ilumina “TIMER”en el panel delantero)
2
3
4
2) Para ajustar la FECHA de grabación,
presione para seleccionar:
1-31 = una vez, o
DIARIO = a la misma
hora de lunes a viernes,
o SEMANA = a la misma
hora cada semana.
DIARIO
7
2
1
31 68 9
/ Orden para elegir
SEMANAL
( SA )
SEMANAL
( LU )
SEMANAL
( DO )
1) Presione para ajustar.
P FE I N I C PARADA CA VEL
113 2 : 00p 3 : 20p 02 SLP
2 -- -- : -- -- : -- -- --
3 -- -- : -- -- : -- -- --
4 -- -- : -- -- : -- -- --
FIJACION ES COMPLETO
CANCELAR : ADD/DLT
ELEG I R: FIJAR:
TERM I NAR :PROG
P FE I N I C PARADA CA VEL
1 -- -- : -- -- : -- -- --
2 -- -- : -- -- : -- -- --
3 -- -- : -- -- : -- -- --
4 -- -- : -- -- : -- -- --
ELEG I R: FIJAR:
TERM I NAR :PROG
Table of Contents
Important Safeguards and Precautions ........................... 2
Before Using ................................................................... 3
Connections and Initial Setup (Ready to Play) ................ 4
Playback / Record on a Tape .......................................... 5
Timer Recording.............................................................. 6
Location of Controls ..................................................... 7, 8
Reset All VCR Memory Functions................................... 8
Spanish (Español) Quick Use Guide....................9, 10, 11
Limited Warranty / Customer Services Directory ........... 12
For assistance, please call : 1-800-211-PANA(7262) or, contact us via the web at:http://www.panasonic.com/contactinfo
Note to CABLE system installer
This reminder is provided to call the CABLE system installer’s attention to Article 820-40 of the NEC in USA
(and to the Canadian Electrical Code in Canada) that provides guidelines for proper grounding and, in
particular, specifies that the cable ground shall be connected to the grounding system of the building, as
close to the point of cable entry as practical.
Limited Warranty
Panasonic VHS VCR Products
Limited Warranty
Limited Warranty Coverage
If your product does not work properly because of a defect in materials or workmanship, Panasonic Consumer
Electronics Company or Panasonic Sales Company (collectively referred to as “the warrantor”) will, for the length of
the period indicated on the chart below, which starts with the date of original purchase (“warranty period”), at its
option either (a) repair your product with new or refurbished parts, or (b) replace it with a new or a refurbished
product. The decision to repair or replace will be made by the warrantor.
During the “Labor”warranty period there will be no charge for labor. During the “Parts”warranty period, there
will be no charge for parts. You must mail-in your product during the warranty period.
If non-rechargeable batteries are included, they are not warranted.
This warranty only applies to products purchased and serviced in the United States or Puerto Rico.
This warranty is extended only to the original purchaser of a new product which was not sold “as is”.
Mail-In Service
For assistance in the continental U.S.A. in obtaining repairs please ship the product to:
Panasonic Services Company
Customer Servicenter Suite B
4900 George McVay Drive
McAllen, TX 78503
For assistance in Puerto Rico call Panasonic Sales Company
[phone] or fax [phone]
When shipping the unit carefully pack and send it prepaid, adequately insured and preferably in the original carton.
Include a letter detailing the complaint and provide a day time phone number where you can be reached.
IF REPAIR IS NEEDED DURING THE WARRANTY PERIOD THE PURCHASER WILL BE REQUIRED TO
FURNISH A SALES RECEIPT/PROOF OF PURCHASE INDICATING DATE OF PURCHASE, AMOUNT PAID
AND PLACE OF PURCHASE.
CUSTOMER WILL BE CHARGED FOR THE REPAIR OF ANY UNIT RECEIVED WITHOUT SUCH PROOF OF
PURCHASE.
PANASONIC CONSUMER ELECTRONICS COMPANY,
DIVISION OF MATSUSHITA ELECTRIC
CORPORATION OF AMERICA
One Panasonic Way
Secaucus, New Jersey 07094
PANASONIC SALES COMPANY,
DIVISION OF MATSUSHITA
ELECTRIC OF PUERTO RICO, INC.,
Ave. 65 de Infantería, Km. 9.5
San Gabriel Industrial Park,
Carolina, Puerto Rico 00985
Limited Warranty Limits And Exclusions
This warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal
wear and tear or cosmetic damage. The warranty ALSO DOES NOT COVER damages which occurred in shipment,
or failures which are caused by products not supplied by the warrantor, or failures which result from accidents,
misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up adjustments,
misadjustment of consumer controls, improper maintenance, power line surge, lightning damage, modification,
introduction of sand, humidity or liquids, commercial use such as hotel, office, restaurant, or other business or rental
use of the product, or service by anyone other than a Factory Servicenter or other Authorized Servicer, or damage
that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER “LIMITED WARRANTY
COVERAGE”. THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS
WARRANTY. (As examples, this excludes damages for lost time, cost of having someone remove or re-install an
installed unit if applicable, travel to and from the servicer, loss of or damage to media or images, data or other
recorded content. The items listed are not exclusive, but are for illustration only.)
ALL EXPRESS AND IMPLIED WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE
LIMITED TO THE PERIOD OF THE LIMITED WARRANTY.
Some states do not allow the exclusion or limitation of incidental or consequential damages, or limitations on
how long an implied warranty lasts, so the exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which vary from state to
state. If a problem with this product develops during or after the warranty period, you may contact your
dealer or Servicenter. If the problem is not handled to your satisfaction, then write to the warrantor’s
Consumer Affairs Department at the addresses listed for the warrantor.
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR
RESPONSIBILITY.
Product or Part Name
All components of VCR except
item listed below
Video Tape (in exchange for
defective video tape)
Parts
One (1) Year
Five (5) Days
Labor
Ninety (90) Days
Not Applicable
Customer Services Directory
Obtain Product Information and Operating Assistance; locate your nearest Dealer or Servicenter;
purchase Parts and Accessories; or make Customer Service and Literature requests by visiting
our Web Site at:
http://www.panasonic.com/support
or, contact us via the web at:
http://www.panasonic.com/contactinfo
You may also contact us directly at:
1-800-211-PANA (7262),
Monday-Friday 9 am-9 pm; Saturday-Sunday 10 am-7 pm, EST.
Service in Puerto Rico
Matsushita Electric of Puerto Rico, Inc. Panasonic Sales Company
Factory Servicenter:
Ave. 65 de Infantería, Km. 9.5, San Gabriel Industrial Park,
Carolina, Puerto Rico 00985
Phone [phone] Fax [phone]
Purchase Parts, Accessories and Instruction Books online for all Panasonic Products by visiting
our Web Site at:
http://www.pasc.panasonic.com
or, send your request by E-mail to:
[email protected]
You may also contact us directly at:
1-800-332-5368 (Phone) 1-800-237-9080 (Fax Only) (Monday - Friday 9 am to 8 pm, EST.)
Panasonic Services Company
20421 84th Avenue South,
Kent, WA 98032
(We Accept Visa, MasterCard, Discover Card, American Express, and Personal Checks)
For hearing or speech impaired TTY users, TTY : 1-877-833-8855
For hearing or speech impaired TTY users, TTY : 1-866-605-1277
As of October 2003
Accessory Purchases
Medidas de seguridad y precauciones importantes
PARA REDUCIR EL RIESGO DE GOLPES ELÉCTRICOS, INCENDIOS, HERIDAS O DAÑOS A ESTE
PRODUCTO, LEA Y GUARDE TODAS LAS INSTRUCCIONES DE SEGURIDAD Y FUNCIONAMIENTO.
TENGA EN CUENTA TODAS LAS ADVERTENCIAS INDICADAS EN EL MANUAL Y EN EL PRODUCTO.
INSTALACIÓN
1 PRECAUCIÓN CON LA FUENTE DE ALIMENTACIÓN
El equipo solo debe hacerse funcionar desde una fuente
de a limentación que se indique en la unidad o en este
manual. Si fuera necesario, haga revisar la fuente de
alimentación de su hogar por parte de la Compañia de
Suministro Eléctrico o por parte de su Distribuidor de
Productos de Vídeo.
2 CONECTOR POLARIZADO O CON TOMA A TIERRA
Como característica de seguridad, este producto de
vídeo viene equipado con un enchufe de cable de
alimentación polarizado (solo una pata es más ancha que
la otra), o con un enchufe del tipo con toma a tierra de
tres patas.
PRECAUCIÓN CON EL ENCHUFE POLARIZADO
Este enchufe sólo entraráen la toma en un sentido.
Si no pudiera introducir el enchufe a fondo, intente darle la
vuelta. Si aún asíno entrara, llame a un técnico electricista
para que le instale una toma de red adecuada. No desactive
esta función de seguridad manipulando el enchufe de
ninguna manera.
PRECAUCIÓN CON ENCHUFES CON TOMA A TIERRA
Este enchufe sólo entraráen una toma con conexión a tierra
de tres orificios.
Si fuera necesario, que un técnico electricista le instale la
toma de red adecuada. No desactive esta función de
seguridad manipulando el enchufe de ninguna manera.
3 CABLE DE ALIMENTACIÓN
Asegúrese de que los cables de alimentación son
dispuestos de tal forma que no se apoye nada sobre
ellos, no ruede nada sobre ellos, o que estén en el paso
de tráfico al caminar.
Si se utilizara un cable alargador, asegúrese de que
también disponga de un enchufe polarizado o con toma a
tierra y de que puede conectarse firmemente.
Los cables pelados, los enchufes averiados o hilos
quebrados constituyen un peligro y deben ser
reemplazados por un técnico cualificado del servicio
técnico. Las tomas eléctricas de la red general
sobrecargadas y los cables de extensión constituyen
riesgos de incendio y han de evitarse en lo posible.
4 NO BLOQUEE LOS ORIFICIOS DE VENTILACIÓN
Las aberturas de ventilación del mueble liberan el calor
generado durante el funcionamiento de la unidad.
Si se bloquearan, el calor acumulado dentro de la unidad
podría ocasionar fallos que pueden llevar a riesgos de
incendio o daños por calor en las cassettes utilizadas.
5 EVITE UBICACIONES MUY CALIENTES O SOMETIDA A
CAMBIOS BRUSCOS DE TEMPERATURA
No coloque la unidad encima o cerca de cual quier tipo
de calefactor o regulador, bajo la luz solar directa, dentro
de vehículos, etc…
No traslade la unidad súbitamente entre sitios con
variaciones extremas de temparatura. Si la unidad es
llevada bruscamente de un sitio frío a otro cálido, la
humedad puede condensarse en la unidad y en la cinta.
6 PARA EVITAR LESIONES PERSONALES
•No coloque equipos no fijados en
superficies inclinadas.
•No coloque esta unidad sobre ningún
soporte que no estéfirme, nivelado y
que sea adecuadamente fuerte.
La unidad podría caerse y producir
graves lesiones a niños o adultos y
dañarse la unidad misma.
•La combinación de aparato y carrito
debe moverse con cuidado. Las paradas súbitas, una
fuerza excesiva ya las superficies irregulares pueden
ocasionar el vuelco de la combinación de aparato y
carrito.
•Siga atentamente las instrucciones de funcionamiento y
utilice los accesorios recomendados por el fabricante al
hacer funcionar esta unidad o al conectaria a otros
equipos.
UTILIZACIÓN DE LA UNIDAD DE VÍDEO
Si la unidad ha estado almacenada o es trasladada a una nueva
ubicación, remítase primero a la sección de INSTALACIÓN de
estas medidas de seguridad.
1 MANTENGA ESTA UNIDAD DE VÍDEO ALEJADA DEL AGUA O
DE HUMEDAD DE CUALQUIER TIPO
2 SI EL EQUIPO ES EXPUESTO A LA LLUVIA, HUMEDAD, O
FUERTES IMPACTOS, desenchufe la unidad y que sea revisada
por un técnico cualificado antes de volver a utilizarla.
3 DURANTE UNA TORMENTA ELÉCTRICA
Durante una tormenta con rayos, tanto en interiores como en el
exterior, o antes de dejar la unidad sin utilizar durante largos
períodos de tiempo, desconecte todos los equipos de la fuente
de alimentación asícomo la antena y el sistema de cableado.
4 AL ENCHUFAR LA UNIDAD
•No exponga nunca la unidad a la lluvia o el agua. NO LA HAGA
FUNCIONAR si se ha derramado líquido dentro de la unidad.
Desenchufe la unida inmediatamente ya que sea revisada por un
técnico. Pueden producirse incendios o sacudidas eléctricas
derivadas de cortocircuitos eléctricos causados por el contacto de
líquidos con el interior de la unidad.
•No deje caer ni introduzca ningún objeto por las aberturas de la
unidad. Algunas piezas internas tienen un voltaje peligroso y el
contacto con ellas puede producir sacudidas eléctricas o incendios.
•Evite colocar la unidad directamente encima o debajo del televisor,
ya que esto prodría causar interferencias eléctricas. Mantenga
cualquier tipo de imán alejados de equipos electrónicos.
5 UTILIZACIÓN DE ACCESORIOS
Utilice sólo accesorios recomendados por el fabricante para así
evitar riesgos de incendio, sacudidas eléctricas y otros peligros.
6 LIMPIEZA DE LA UNIDAD
Desenchufe la unidad. Luego utilice un paño limpio y seco, sin
tratamiento químico para quitar suavemente el polvo o suciedad.
NO UTILICE productos de limpieza, aerosoles, o aire comprimido que
pudieran causar un exceso de pulverización o introducirse en la
unidad y ocasionar sacudidas eléctricas. Caulquier substancia,
como cera, cinta adhesiva, etc., podría arruinar el acabado de la
superficie. La exposición a substancias grasosas, áreas húmedas o
polvorientas puede afectar de manera adversa a las piezas intemas.
SERVICIO
1 EL USUARIO NO DEBE REALIZAR NINGUNA OPERACIÓN DE
SERVICIO TÉCNICO POR SÍMISMO
Si, después de observar atentamente las detalladas instrucciones de
funcionamiento, este producto de vídeo no funcionara correctamente,
no intente abrir o extraer las tapas, o realizar cualquier ajuste no
indicado en este manual. Desenchufe la unidad y llévela a un técnico
cualificado de servicio técnico.
2 SI FUERAN NECESARIAS PIEZAS DE RECAMBIO
Asegúrese de que el técnico de servicio utiliza sólo piezas
especificadas por el fabricante, o de las mismas características que
las piezas originales. La utilización de subsitutos no autorizados
puede ser causa de incendios, sacudidas eléctricas, u otros peligros.
3 QUE EL TÉCNICO DE SERVICIO TÉCNICO REALICE UNA
COMPROBACIÓN DE SEGURIDAD
Después de cualquier servicio o reparación de la unidad, solicite
al técnico de servicio que realice una completa comprobación de
seguridad tal como se describe en la literatura de servicio técnico
del fabricante para asegurarse asíque la unidad de vídeo se
encuentra en condiciones de funcionamiento seguras.
INSTALACIÓN DE LA ANTENA EXTERIOR
1 CONEXIÓN SEGURA DE LA ANTENA Y DE LOS CABLES
Si se conectara una antena exterior o sistema de cable
conectado al equido, el usuario
deberáasegurarse de que la
antena o el sistema de cable
disponen de toma a tierra como
forma de proporcinar protección
contra la acumulación de cargas
estábicas y saltos de corrientes.
La sección 810 del Código
Eléctrico Nacional, ANSI/NFPA 70 (en
Canadá, la parte 1 del Código Eléctrico Canadiense)
proporciona información con respecto a la conexión a tierra
correcta del mástil y la estructura de soporte, conexión a tierra
de los cables de bajada de antena a una unidad de descarga,
tamaño de los conductores a tierra, ubicación de la unidad de
descarga de antena, conexión de los electrodos a tierra y
requisitos del electrodo de toma a tierra.
2 MANTENGA LA ANTENA LIBRE DE LÍNEAS O CIRCUITOS
DE ALTO VOLTAJE
Un sistema de antena exterior deberáser colocado bien alejado
de líneas de alimentación, luz eléctrica o circuitos de alimentación
para que nunca estéen contacto con tales fuentes de
alimentación si se cayera. Al instalar una antena exterior, debe
tenerse muchísimo cuidado para evitar las líneas de alimentación,
circuitos u otras fuentes de alimentación ya que esto podría
resultar mortal. Debido a los riesgos implicados en la instalación
de una antena, tal operación debe dejarse a un profesional.
EMPALMADOR
DECONEXIÓN
ATIERRA
EQUIPODE
SERVICIO
ELÉCTRICO
BAJADADE ANTENA
UNIDADDE DESCARGA
DELAANTENA (SECCIÓN
S10-20DEL NEC)
CONDUCTORESCONEXIÓN
ATIERRA (SECCIÓN
S10-20DEL NEC)
SISTEMADE ELECTRODOS DE
CONEXIÓNA TIERRA DEL SERVICIO
ELÉCTRICO(ART, 250 DEL NEC, PARTE H)
CÓDIGOOELÉCTRICO
NEC-NATIONAL
EMPALMADORDE
CONEXIÓNA TIERRA
PRECAUCION: PARA EVITAR LA POSIBILIDAD DE
UNADESCARGA ELECTRICA NO DESMONTAR LA
CUBIERTA(O LA PARTE TRASERA). ESTE APARATO
NOPUEDE SER REPARADO POR EL PROPIETARIO.
PARACUALQUIER TRABAJO DE SERVICIO SE
DEBERECURRIR A UN TECNICO ESPECIALIZADO.
PELIGRODE DESCARGA
ELECTRICANO ABRIR
PRECAUCION
Este símbolo advierte al usuario de que hay voltaje sin aislamiento dentro de la unidad de
suficiente magnitud como para ocasionar sacudidas eléctricas. Por lo tanto, resultarápeligroso
realizar cualquier tipo de contacto con toda pieza interna de la unidad.
Este símbolo alerta al usuario de que se ha incluido importante literatura sobre el funcionamiento
y mantenimiento de esta unidad. Por tanto, debe leerse atentamente tal literatura a fin de evitar
cualquier problema.
PRECAUCIONES DE SEGURIDAD
PARA PREVENIR INCENDIOS O CHOQUES ELÉCTRICOS NO
EXPONGA ESTE APARATO A LA LLUVIA O LA HUMEDAD.
PARA PREVENIR CHOQUES ELÉCTRICOS, ASEGURASE QUE LA CLAVIJA
HAGA JUEGO CON EL ENCHUFE Y CONÉCTELO COMPLETAMENTE.
Al usar cables coaxiales RF del tipo “tuerca”,
apriételos solamente con los dedos. Un apriete
excesivo puede dañar los terminales.
As an E NERGY S TAR ®Partner, Matsushita Electric Corporation
of America has determined that this product or product model
meets the
E NERGY S TAR ®guidelines for energy efficiency.
Al inicio, el idioma de
la pantalla estáfijado a
inglés.
Para cambiar el
idioma, seleccione la
pantalla MENU (para
su ayuda vea la
página 12 de las
operaciones
avanzadas.)
REVISIÓN, REEMPLAZO O BORRADO
DE PROGRAMACIONES
(no se puede efectuar durante la grabación)
a
b
c
Presione PROG para visualizar la
pantalla de Programación.
Presione para
seleccionar programa
deseado.
Para reemplazar programa...
1) Presione para
desplegar menu.
2) Repita paso 2 (ver
arriba) para introducir el
nuevo programa.
Para cancelar programas…
Presione ADD/DLT
dPresione PROG Para terminar
programacion.
P FE I N I C PARADA CA VEL
113 2 : 00p 3 : 20p 02 SLP
2
14 7 : 00p 7 : 30p 10 SP
3
-- -- : -- -- : -- -- --
4 -- -- : -- -- : -- -- --
CANCELAR : ADD/DLT
ELEG I R: FIJAR:
TERM I NAR :PROG
P FE I N I C PARADA CA VEL
113 2 : 00p 3 : 20p 02 SLP
2
14 7 : 00p 7 : 30p 10 SP
3
-- -- : -- -- : -- -- --
4 -- -- : -- -- : -- -- --
ELEG I R: FIJAR:
SALI R :PROG
P FE I N I C PARADA CA VEL
1 -- -- : -- -- : -- -- --
2 14 7 : 00p 7 : 30p 10 SP
3
-- -- : -- -- : -- -- --
4 -- -- : -- -- : -- -- --
ELEG I R: FIJAR:
TERM I NAR :PROG
o
PV-V4524S Basic-1 (040119).p65 2004/01/27, 12:271
LSQT0761A (Basic Operations)NEW - Front

Location of Controls
Front View of the VCR
RECORD
STOP/EJECT
Cassette Compartment
POWER
REWIND/
SEARCH
PLAY
CHANNEL /
TRACKING/ V-LOCK Remote
Sensor FAST
FORWARD/
SEARCH
Video
Input
Connector
Audio Input
Connector
(L/R)
*Important: If a remote control button does not work when pressed,
press the VCR button on the remote and try the button again.
- 7 -
Timer Recording
1Press PROG* to display program screen.
Press PROG to end programming.
2
3) Set remaining items,
press to set START/ STOP times, CH (channel) or
LINE input (p. 9 of Advanced Operations book), and
tape speed (p. 3).
Then press to select.
1) Press .
2) Set record DATE,
press to select:
1~31= one time,
or DAILY= Monday~Friday,
or WEEKLY= same time
each week (see right).
3To Enter More Programs
Press to select and press to set an unused program.
Then repeat step 2. Or, press PROG to exit.
Timer Recording
Example
Today
Press to select
desired program.
4 Press POWER off to set the timer recording. (“TIMER”lights on Multi Function Display.)
(Recording is not in progress)
aPress PROG
to display program screen.
b
cTo Replace program...
dPress PROG to end the programming.
•If you are using a Cable Box,VCR Timer Programming Channel (Step 2 above) must be set to the
Cable Box output channel and your Cable Box must be manually set to the desired channel.
The Cable Box must be left on.
•If a power interruption occurs while programming the timer, the timer program(s) may be canceled.
If “TIMER PROGRAMS WERE LOST DUE TO POWER INTERRUPTION”appears on-screen,
please re-enter the timer programs.
Important notes when using DSS receiver
•When recording programs via DSS receiver, DSS receiver must be left on.
•When recording programs via an antenna or cable, DSS receiver must be turned off.
Review, Replace, or Clear Program
1) Press to display.
2) Repeat Step 2
(above) to set new
programs.
Press ADD/DLT.
or
To Clear program...
Press POWER and then STOP within 10
seconds to cancel the Timer Recording.
(The TIMER indicator goes out on Multi Function
Display.)
Cancel a Timer Recording
(Recording is in progress)
- 6 -
Notes
DAILY
7
21
31 68 9
SELECT / Selection Order
WEEKLY
(SA) WEEKLY
(MO) WEEKLY (SU)
P DT STA R T ST O P CH SPD
1 13 2 : 00p 3 : 20p 02 SLP
2 14
7 : 00p 7 : 30p 10 SP
3 -- -- : -- -- : -- -- --
4 -- -- : -- -- : -- -- --
SELECT : SET :
EXIT : PROG
P DT STA R T ST O P CH SPD
113 2 : 00p 3 : 20p 02 SLP
2 -- -- : -- -- : -- -- --
3 -- -- : -- -- : -- -- --
4 -- -- : -- -- : -- -- --
CANCEL : ADD/DLT
SELECT : SET :
END : PROG
SET COMPLETED
P DT STA R T ST O P CH SPD
1 -- -- : -- -- : -- -- --
2 -- -- : -- -- : -- -- --
3 -- -- : -- -- : -- -- --
4 -- -- : -- -- : -- -- --
SELECT : SET :
END : PROG
P DT STA R T ST O P CH SPD
1 -- -- : -- -- : -- -- --
2 14 7 : 00p 7 : 30p 10 SP
3 -- -- : -- -- : -- -- --
4 -- -- : -- -- : -- -- --
SELECT : SET :
END : PROG
This video recorder, equipped with HQ
(High Quality) system, is compatible with
existing VHS equipment. Only use tapes
with the mark. Only tapes tested and
inspected for use in 2, 4, 6, and 8 hour
machines are recommended.
*Important: If a remote control button does not work when pressed,
press the VCR button on the remote and try the button again.
- 5 -
1 Insert a tape with a record tab (p. 3).
1Insert a tape.
Special Features During Play
2 Press PLAY to play tape.
•If tape has no rec. tab (p.3), auto play begins.
Record on aTape
Still (Freeze) Picture
➛Press PAUSE/SLOW.
➛Press PLAY to release.
Slow Motion Picture
➛Hold down PAUSE/SLOW in Still mode.
➛Press PLAY to release.
•Loose or peeling labels
may cause tape jam.
•VCR power comes on. “VCR”lights
on Multi Function Display.
If Auto VCR/TV (see p. 10 of
Advanced Operations book) is set to
“OFF,”press VCR/TV until “VCR”
lights on the Multi Function Display.
•These features work best in SP or SLP mode.
•The sound will be muted.
•To reduce picture noise, see “Manual
Tracking Control”on p. 3.
•After 3 minutes in Still or Slow mode, VCR
stops to protect the tape and the video heads.
Rapid Rewind/FF
Press REW or FF in Stop mode to
rewind or fast forward tape.
Press EJECT on remote,
or STOP/EJECT on VCR to eject tape.
3Press STOP to stop tape.
Playback aTape
•Picture interruption may occur with some TVs.
•FF and REW search speed may vary depending
on current tape position.
•After 10 minutes in search mode, VCR returns to
Play mode to protect the tape and the video
heads.
Playback / Record on a Tape
Auto Play
Insert a tape ➛Power comes on ➛Play starts if there is no record tab (see p. 3).
Auto Rewind
Play
Fast Forward
Play Auto Eject
(Repeat Play must be off)
Play ➛Tape end ➛Rewind ➛Stop➛Tape ejects if there is no record tab
Auto Operation Functions
Notes
➛Tape end ➛Rewind ➛Stop
Connections / Initial Setup (Ready to Play)
Connecting (Select a method)
Connect cable from
Antenna/Cable to VCR’s IN
FROM ANT. jack.
Connect VCR’s OUT TO TV
jack to TV’s ANT. IN jack
with included RF Cable.
For ANT./Cable ➛➛
➛➛
➛VCR ➛➛
➛➛
➛TV
For DSS/Cable Box ➛➛
➛➛
➛VCR ➛➛
➛➛
➛TV
Connect your cable box’s OUT
jack to the VCR’s IN FROM
ANT. jack with an RF cable.
Connect VCR’s OUT TO TV
jack to TV’s ANT. IN jack
with included RF Cable.
1
2
1
2
Make all cable or antenna connections before plugging into an AC outlet.
Plugging the VCR Power Cord into an AC wall outlet starts auto channel and clock set.
1Turn TV on and tune to channel 3.
2Plug VCR Power Cord into AC wall outlet.
VCR comes on and auto channel and clock
set starts.
•If screen below does not appear...
check all connections.
Try tuning TV to channel 4.
•To change VCR’s output channel,
see “VCR’s Output Channel”(p. 12)
in Advanced Operations book.
If you use a cable box, turn it on and set it to
the Public Broadcasting Station (PBS) channel
in your time zone. If you use a DSS receiver, it
must be turned off.
Initial Setup (Ready to Play)
3Settings are made automatically.
When complete, this screen appears.
If “AUTO CLOCK SET IS INCOMPLETE”
appears, manually set clock (below).
Manual Clock Set
If Auto Clock Set was incomplete.
1Press ACTION* on remote to display
CLOCK menu.
DST : O N
1 / 1/2004 THU -- -12:00 PM
- - - - - - - - -- - - - - - - -- - - - - -
SET C L OC K
SELECT : SET :
END
: ACT I O N
2Press to select the month and to set.
In the same manner, select and set the
date, year, time, and DST (Daylight Saving
Time).
3Press ACTION to start clock and exit.
- 4 -
Plug VCR Power plug into an AC wall outlet.
DST : O N
6 /20/2004 SUN - - 15:30 PM
- - - - - - - - -- - - - - - - -- - - - - -
SET C L OC K
SELECT : SET :
START
: ACT I O N
IN FROM ANT.
TV VCR
VHF/UHF
OUT TO TV
IN from
ANT./CABLE
Cable TV
Converter Box
Congratulations
on your new purchase! With proper use, this
dependable product will provide years of
enjoyment. Please fill in the information below.
(Serial number is on tag on back of VCR.)
Before Using
•Date of Purchase
•Dealer Purchased From
•Dealer Address
•Dealer Phone No.
•Model No. PV-V4524S
•Serial No.
Head Cleaning
•Important Safeguards •Accessories •Head Cleaning •Loading Batteries •Prevent Tape Erasure •Specifications •Record/Playback Time
- 3 -
Video Head Clog Sensor
Screen-right appears during
play if clogging is detected.
To remove screen, press PLAY.
•Use “dry”type head
cleaning cassette only.
(Part No. NV-TCL30PT is recommended.)
•Follow cleaning tape instructions carefully.
Excessive use of tape can shorten head life.
•If head clog symptoms persist, contact your
nearest servicenter by visiting our Web Site
(p. 12).
Old or damaged tapes may clog heads.
V I D EO HEADS M AY
N EED CLE A N I NG
PLEASE I NSERT HEAD
CLE A N I NG CASSE TT E
OR REFER T O MANUAL
END : P L AY
- 2 -
AUTO CLOCK SET
IS
I NC O M PLETE
PLEASE SET CLOCK BY
PRESSING
ACT I ON KEY
2Press CH or NUMBER keys
to
select the channel .
•If channel number is over 100, first press 100
key then the other 2 digits.
•For “LINE”input, see p. 9 of “Advanced
Operations”book.
3 Press SPEED to set record speed (p. 3).
4 Press REC to start recording.
•To edit, press PAUSE/SLOW to pause, and
again to resume recording.
5 Press STOP to stop recording.
OneTouch Recording
(recording in progress)
Press REC repeatedly to set length as follows:
30 min. ➛1 hr. ➛1:30 ➛2:00 ➛3:00
➛4:00 ➛exit.
The VCR shuts off at the length set.
Record one station, watch another
Press VCR/TV
(“VCR”goes out on Multi Function Display),
➛select channels on TV (recording continues).
Select channels on VCR
Press VCR/TV in Stop or Pause mode.
(“VCR”lights on Multi Function Display),
➛select channels on VCR.
•Watching one channel and recording
another is not possible when using Cable
Box or DSS Receiver.
•After 5 minutes in Pause mode, VCR stops to
protect the tape and the video heads.
•VCR power comes on. “VCR”lights on
Multi Function Display.
If Auto VCR/TV (see p. 10 of Advanced
Operations book) is set to “OFF,”press
VCR/TV until “VCR”lights on the Multi
Function Display.
Multi Function Display
(Front Display)
•Function buttons are void during Initial Setup.
•To eject a tape during Auto Set, press EJECT
on remote or STOP twice on VCR.
Then make settings manually.
(See Advanced Operations book, p. 12.)
•If Auto Clock Set takes more than 30 minutes,
press STOP and perform settings manually.
(See Advanced Operations book, p. 12.)
Notes
Notes
Notes
AUTO CLOCK SET
PROCEEDING
CANCEL : STOP
CH AUTO SET PROCEEDING
CANCEL : STOP
•Rewinds a T-120 tape in approx. 1 minute.
P DT STA R T ST O P CH SPD
113 2 : 00p 3 : 20p 02 SLP
2 14
7 : 00p 7 : 30p 10 SP
3
-- -- : -- -- : -- -- --
4 -- -- : -- -- : -- -- --
CANCEL : ADD/DLT
SELECT : SET :
END : PROG
PAUSE/SLOW
(Displays still, frame by frame,
or slow motion picture)
POWER
(Turns VCR off/on)
Remote Control Buttons
VCR/TV
(For TV or VCR mode)
VCR (mode)
(Enables VCR functions)
ACTION
(Displays menu)
VOLUME + / -
(Adjusts TV volume)
SAP/Hi-Fi
(Selects audio mode for play
or record)
COUNTERRESET
(Resets counter to zero)
EJECT
(Ejects tape)
SPEED
(Changes tape speed)
RECORD
(Records a program, etc.)
TV (mode)
(Enables TV functions)
RemoteControl
EJECTbutton: Press to eject tape. EJECT is not available during recording.
INPUT
(For LINE or channel)
NUMBERKeys
(Selects channel directly)
ADD/DELETE
(Adds or deletes a channel)
TAPEPOSITION/STATUS
(Locates tape position/tape status)
DISPLAY
(Displays VCR status)
PLAY (Plays a tape)/
FASTFORWARD/SEARCH
(Fast forwards tape/ forward
visual search)
REWIND/SEARCH
(Rewinds tape/ reverse visual
search)
STOP (Stops tape)
PLAY, STOP, REW, and FF
function as
operation keys when menus
are displayed.
Remote keys
COMMERCIALSKIP/
ZEROSEARCH
(Starts COMMERCIAL SKIP/
Zero Search)
PROGRAM
(Displays Timer Program screen)
CHANNEL /
TRACKING/ V-LOCK
(Selects channel/ reduces
picture noise during Play and
Slow mode)
SEARCH/ENTER
(Set search system /
Tunes TV channel)
•Connections •Initial Setup •Clock Set •Select Channel •Playback •Record •Auto Operation
RFCoaxialCable
LSJA0418
Batteries 2 “AA”
RemoteControl
EUR7723KA0
Accessories
To order accessories, call toll free
1-800-332-5368.
Loading the Batteries
Battery replacement caution
•Do not mix old and new batteries.
•Do not mix alkaline with manganese batteries.
1) Open cover.
3) Close cover.
2) Insert batteries as
marked.
Prevent Accidental Tape Erasure
To record again
Break off the tab to
prevent recording.
Record Tab
Screw driver
Cover the hole
with cellophane
tape.
Only use tapes with the mark in this unit.
Record/Playback Time
SP
(Standard Play) 2 Hours
40 Minutes
2 Hours
6 Hours 8 Hours
SLP
(Super Long Play)
Type of Video Cassette
Tape Speed
Setting T180
T160
T120
3 Hours
9 Hours
Digital Auto Picture
Automatically controls the video output signal for
less noise depending on the tape condition.
Digital Auto Tracking
Continuously analyzes the signal and adjusts for
optimum picture quality.
Manual Tracking Control
(to reduce picture noise)
Use during Playback and Slow Motion mode to
reduce picture noise.
Press CH (TRACKING) /on the remote
control or on the VCR until the picture clears up.
To return to Auto Tracking, press POWER off,
then on again a few seconds later.
V-Lock Control (to reduce picture jitter)
In Still mode, CH (TRACKING) /operate as a
V-Lock control.
Features for a Quality Picture
R
R
R
R
R
R
R
R
Use soft, dry cloth or dusting attachment of a
vacuum to remove dust from all cabinet vent
holes. You may moisten cloth with non-abrasive,
antistatic cleaner/ polisher.
Caution:
Alcohol and various solvents could damage finish.
Cleaning the VCR
•Timer Recording •Location of Controls (Remote Control Buttons, Front View of the VCR)
•SP = Standard Play
•SLP = Super Long Play
Note: Designs and specifications are subject to
change without notice.
Power Source: 120 V AC, 60 Hz
Power Consumption: Power On
Approx. 18 W
Power Off
Approx. 0.95 W
Video Signal: EIA Standard NTSC color
Video Recording 4 rotary heads helical
System: scanning system
Audio Track: 1 track (Normal)
2 channel (Hi-Fi Audio Sound)
Tuner
Broadcast Channels: VHF 2 ~ 13, UHF 14 ~ 69
CABLE Channels: Midband A ~ I (14 ~ 22)
Superband J ~ W (23 ~ 36)
Hyperband AA ~ EEE
(37 ~ 64)
Lowband A-5 ~ A-1 (95 ~ 99)
Special CABLE channel 5A (01)
Ultraband 65 ~ 94, 100 ~ 125
Operating
Temperature: 5 °C ~ 40 °C (41 °F ~ 104 °F)
Operating Humidity: 10 % ~ 75 %
Weight: 2.3 kg(5.1 lbs).
Dimensions: 360 (W) x 93 (H) x 240 (D) mm
14-3/16”(W) x 3-11/16”(H) x
9-7/16”(D) inch
Specifications
Important Safeguards and Precautions
TO REDUCE THE RISK OF ELECTRIC SHOCK, FIRE, INJURY TO PERSONS OR DAMAGE TO
THIS PRODUCT, READ AND RETAIN ALL SAFETY AND OPERATING INSTRUCTIONS. HEED ALL
WARNINGS IN THE MANUAL AND ON THE PRODUCT.
INSTALLATION
1 POWER SOURCE CAUTION
Operate only from a power source indicated on the unit
or in this manual. If necessary, have your Electric Utility
Service Company or Video Products Dealer verify the
power source in your home.
2 POLARIZED OR GROUNDING PLUG
As a safety feature, this Video product comes with
either a polarized power cord plug (one blade is wider
than the other), or a three-wire grounding type plug.
POLARIZED PLUG CAUTION:
This plug will only fit into an outlet one way. If you cannot
fully insert the plug, try reversing it. If it still will not fit,
have an electrician install the proper wall outlet. Do not
defeat the safety feature by tampering with the plug.
GROUNDING PLUG CAUTION:
This plug will only fit into a three-hole grounding outlet.
If necessary, have an electrician install the proper outlet.
Do not defeat the safety feature by tampering with the plug.
3 POWER CORD
Make sure power cords are routed so that they are not
likely to have anything rest on them, roll over them, or
be in the way of walking traffic. If an extension cord is
used, make sure it also has either a polarized or
grounded plug and that the cords can be securely
connected. Frayed cords, damaged plugs, and damaged
or cracked wire insulation are hazardous and should be
replaced by a qualified service technician.
Overloaded outlets and extension cords are fire hazards
and should be avoided.
4 DO NOT BLOCK VENTILATION HOLES
Ventilation openings in the cabinet release heat
generated during operation. If they are blocked, heat
build-up inside the unit can cause failures that may
result in a fire hazard or heat damage to cassettes.
For protection, follow these rules:
a. Never cover ventilation slots or the unit while in use,
or operate the unit when placed on a bed, sofa, rug,
or other soft surface.
b. Avoid built-in installation, such as a book case or
rack, unless proper ventilation is provided.
5 AVOID EXTREMELY HOT LOCATIONS OR SUDDEN
TEMPERATURE CHANGES
Do not place the unit over or near any kind of heater or
radiator, in direct sunlight, inside a closed vehicle, etc..
Do not move the unit suddenly between areas of
extreme temperature variation. If the unit is suddenly
moved from a cold place to a warm place, moisture may
condense in the unit and on the tape.
6 TO AVOID PERSONAL INJURY
•Do not place unsecured equipment on a
sloping surface.
•Do not place this unit on any support
that is not firm, level, and adequately
strong. The unit could fall causing
serious injury to a child or adult and
damage to the unit.
•An appliance and cart combination should be moved
with care. Quick stops, excessive force, and uneven
surfaces may cause the appliance and cart
combination to overturn.
•Carefully follow all operating instructions and use the
manufacturer's recommended accessories when
operating this unit or connecting it to any other
equipment.
USING THE VIDEO UNIT
If the unit has been in storage or moved to a new location, refer
first to the INSTALLATION section of these safeguards.
1 KEEP THIS VIDEO UNIT AWAY FROM WATER OR
MOISTURE OF ANY KIND.
2 IF EQUIPMENT IS EXPOSED TO RAIN, MOISTURE, OR
STRONG IMPACT, unplug the unit and have it inspected by
a qualified service technician before use.
3 DURING AN ELECTRICAL STORM
During a lightning storm, whether indoors or outdoors, or
before leaving the unit unused for extended periods of time,
disconnect all equipment from the power source as well as
the antenna and cable system.
4 WHEN THE UNIT IS PLUGGED IN
•Never expose the unit to rain or water. DO NOT OPERATE
if liquid has been spilled into the unit. Immediately unplug
the unit, and have it inspected by a service technician.
Fire and shock hazards can result from electrical shorts
caused by liquid contact inside.
•Never drop or push any object through openings in the
unit. Some internal parts carry hazardous voltages and
contact can cause electric shock or fire hazard.
•Avoid placing the unit directly above or below your TV set
as this may cause electrical interference.
Keep all magnets away from electronic equipment.
5 USING ACCESSORIES
Use only accessories recommended by the manufacturer to
avoid risk of fire, shock, or other hazards.
6 CLEANING THE UNIT
Unplug the unit. Then, use a clean, dry, chemically untreated cloth
to gently remove dust or debris. DO NOT USE cleaning fluids,
aerosols, or forced air that could over-spray, or seep into the unit
and cause electrical shock. Any substance such as wax,
adhesive tape, etc. may mar the cabinet surface. Exposure to
greasy, humid, or dusty areas may adversely affect internal parts.
SERVICE
1 DO NOT SERVICE THIS PRODUCT YOURSELF
If, after carefully following the detailed operating
instructions, this Video product does not operate properly,
do not attempt to open or remove covers, or make any
adjustments not described in the manual. Unplug the unit
and contact a qualified service technician.
2 IF REPLACEMENT PARTS ARE REQUIRED
Make sure the service technician uses only parts specified by
the manufacturer, or those having the same safety
characteristics as the original parts. The use of unauthorized
substitutes may result in fire, electric shock, or other hazards.
3 HAVE THE SERVICE TECHNICIAN PERFORM A SAFETY CHECK
After any service or repairs to the unit, request the service
technician to conduct a thorough safety check as described
in the manufacture’s service literature to ensure that the
video unit is in safe operating condition.
OUTDOOR ANTENNA INSTALLATION
1 SAFE ANTENNA AND CABLE CONNECTION
If an outside antenna or cable system is connected to the
equipment, be sure the antenna or cable system is grounded
so as to provide some protection against built up static
charges and voltage surges.
Section 810 of the National
Electrical Code, ANSI/NFPA 70 (in
Canada, part 1 of the Canadian
Electrical Code) provides information
with respect to proper grounding of
the mast and supporting structure,
grounding of the lead-in wire to an antenna
discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes
and requirements for the grounding electrode.
2
KEEP ANTENNA CLEAR OF HIGH VOLTAGE POWER LINES OR CIRCUITS
An outside antenna system should be located well away from
power lines, electric light or power circuits and where it will never
come into contact with these power sources if it should happen
to fall. When installing an outside antenna, extreme care should
be taken to avoid touching power lines, circuits or other power
sources as this could be fatal. Because of the hazards involved,
antenna installation should be left to a professional.
GROUND
CLAMP
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
LEADIN
WIRE
ANTENNA
DISCHARGEUNIT
(NECSECTION810-20)
GROUNDINGCONDUCTORS
(NECSECTION810-21)
GROUNDCLAMPS
POWERSERVICEGROUNDING
ELECTRODESYSTEM
(NECART250, PART H)
NEC -NATIONAL
ELECTRICAL CODE
CAUTION:TO REDUCE THE RISK OF ELECTRIC SHOCK,
DONOT REMOVE COVER (OR BACK)
RISKOF ELECTRIC SHOCK
DONOT OPEN
CAUTION
NOUSER-SERVICEABLE PARTS INSIDE
REFERSERVICING TO QUALIFIED SERVICE PERSONNEL
This symbol warns the user that uninsulated voltage within the unit may
have sufficient magnitude to cause electric shock. Therefore, it is
dangerous to make any kind of contact with any inside part of this unit.
This symbol alerts the user that important literature concerning the
operation and maintenance of this unit has been included. Therefore, it
should be read carefully in order to avoid any problems.
Safety Precautions/Mesures de sécurité
To prevent fire or shock hazard, do not expose this equipment to rain or moisture.
To prevent electric shock, match wide blade of plug to wide slot, fully insert.
AVERTISSEMENT : Afin de prévenir tout risque d’incendie ou de chocs électriques, ne
pas exposer cet appareil àla pluie ou àune humiditéexcessive.
ATTENTION : Pour éviter les chocs électriques, introduire la lame la plus large de la
fiche dans la borne correspondante de la prise et pousser jusqu’au fond.
FCC WARNING: Any unauthorized changes or modifications to this
equipment would void the user’s authority to operate.
Forward/Reverse Scene Search
➛Press FF or REW.
➛Press PLAY to release.
After search has begun, each additional
press of FF or REW changes speed.
1
2
IN FROM ANT.
TV VCR
VHF/UHF
OUT TO TV
IN from
ANT./CABLE
2
1
Over tightening “Nut type”RF coaxial cables
may damage jacks. Finger tighten only.
PV-V4524S Basic-2 (040119).p65 2004/01/27, 12:273
LSQT0761A (Basic Operations)NEW - Back

Table of Contents
Multi-Brand Control Feature ............................................ 2
Advanced Connections (Cable/DSS) .............................. 3
MTS Broadcast................................................................ 4
VHS Hi-Fi Stereo System................................................ 5
Tape Operation ............................................................ 6, 7
Before Requesting Service ............................................. 8
Copying Your Tapes (Dubbing) ...................................... 9
Special VCR Features .................................................. 10
On-Screen Displays (OSD) ........................................... 11
Reset Language, Channels, Clock, VCR’s Output Channel.. 12
Reset Language, Channels, Clock, VCR’s Output Channel
Press ACTION
to display MENU.
Language
1) Press to select
language item.
For Spanish
For French
For English
Channels
2) Press to select
“ANTENNA,”then
press to set
your antenna system
(“TV”or “CABLE.”)
•After Channel Auto
Set is finished, Auto
Clock Set will be
performed.
3) Press to select
“AUTO SET,”then
press .
•If you use Cable
Box, set it to the
PBS channel in your
time zone.
Clock
2) Press to select
“MANUAL,”and press
. (For Auto Clock Set,
select “AUTO CLOCK
SET.”)
(“TIME ZONE ADJUST”
appears only when
auto clock is set.)
3) Press and
to select and set
the date, time, and
DST (Daylight
Saving Time).
4) Press ACTION to
start the Clock and
exit this mode.
and press to
subtract or add
hour(s) as necessary.
•“TIME ZONE
ADJUST”returns to
“0”if clock is set
manually.
VCR’s Output Channel
After 3 seconds
•To Make Corrections,
repeat steps 1) ~ 3).
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
ELEGIR :
SALIR : ACTION
FIJAR :
MENU
PREPARAR VCR
FIJAR RELOJ
FIJAR CANAL
LANGUE/LANGUAGE:ESPAÑOL
SALIDA DE VCR CANAL : 3
SEL. :
QUITTER : ACTION
REGLER:
MENU
REGLAGE MAGNETOSCOPE
REGLAGE HORLOGE
REGLAGE CANAL
LANGUAGE/IDIOMA:FRANÇAIS
CA SORTIE : 3
SELECT :
EXIT : ACTION
SET :
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
3) Press ACTION to exit.
1)Press to select
“SET UP CHANNEL,”
and press .
1)Press to select
“SET CLOCK,”and
press .
Time Zone
Adjust
1)Press to select
“SET CLOCK,”and
press .
(Only when Auto Clock
is set.)
2) Press to select
“TIME ZONE
ADJUST,”
3)Press ACTION.
Add or Delete a Channel
To add channel:
Select channel with NUMBER keys and
press ADD/DLT.
To delete channel:
Select channel with CH /or NUMBER
keys and press ADD/DLT.
DST (Daylight Saving Time)
VCR auto adjusts clock for DST.
Spring (First Sunday in April)
DST:ON ➛Sets clock ahead one hour.
Autumn (Last Sunday in October)
DST:ON ➛Turns clock back one hour.
•If your area does not observe Daylight
Saving Time, select DST:OFF.
•Keep these time changes in mind when
programming VCR for timer recordings.
1) Press to select
“VCR’S OUTPUT CH.”
3) Press ACTION.
2) Press .
- 12 -
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
SELE C T : SET :
EXIT : ACT I O N
ANT ENN A : CABLE
A U T O S E T
W EA K S I GN AL D I SPLA Y : OFF
SET UP CH A NNE L
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
AUT O C L OC K SET
M A NU ALAL
T I M E ZO N E A D JUS T : 0
SELE C T : SET :
EXIT : ACT I O N
SET C L OC K
AUT O C L OC K SET
M A NU AL
T I M E ZO N E A D JUS T : 0
SELE C T : SET :
EXIT : ACT I O N
SET C L OC K
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
IF YOU PRESS ACTION
KEY, VCR ’S OUTPUT CH
SWITCHES TO CH 4.
PLEASE TUNE YOUR TV TO
CH 4.
C HANNEL 08 ADDED
C HANNEL 08 DE L E T ED
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
On-Screen Displays (OSD)
VCR Status & Clock Displays
Function & Channel Displays Blank Tape/
No Video Signal Indications
When blank tape is detected during play, or
the current channel has no signal (with Weak
Signal Display feature (p. 10) set to OFF), the
TV screen will turn solid blue.
CH 0 8
When a function button is
pressed, e.g. PLAY, or you
change channels,
a 5 second display
appears.
To display or remove
overlay at right,
➛press DISPLAY*.
On-Screen Displays (OSD)
These displays will alert you to a missed operation or
provide further instructions.
OSD Caution Page
PLEASE SET CLOCK BY
PRESSING ACTION KEY If you attempt to set or review a Timer
Recording and the Clock is not set...
After a Timer Program has been set...
If you press REC on the remote
control or VCR, and a cassette is
inserted with no record tab...
If you press PLAY, FF, REW, or REC on
the remote control or VCR without a
cassette inserted...
CHECK CASSETTE
RECORD TAB
NO CASSETTE
TURN VCR OFF
FOR TIMER RECORDING
If you press POWER or STOP during
a Timer Recording...
(visible in VCR mode only)
TO CANCEL TIMER REC
PRESS POWER THEN
STOP KEY
VIDEO HEADS MAY
NEED CLEANING
PLEASE INSERT HEAD
CLEANING CASSETTE
OR REFER TO MANUAL
END :PLAY
VCR LOCK ACTIVATED
If head cleaning becomes necessary
while playing back a tape...
If you press a function button other
than STOP/EJECT or POWER while
the VCR is in VCR Lock mode...
Warning and Instruction Displays
See page 6 of Basic
Operations book
See page 6 of Basic
Operations book
See page 3 of Basic
Operations book
See page 5 of Basic
Operations book
See page 6 of Basic
Operations book
See page 3 of Basic
Operations book
See page 10
- 11 -
Special VCR Features
*Important: If a remote control button does not work when pressed,
press the VCR button on the remote and try the button again.
- 10 -
Insert pre-recorded tape. Insert blank tape with record tab.
Press REC, then PAUSE/SLOW immediately to
enter REC/PAUSE mode.
Press INPUT* to set VCR Input mode to LINE1
for Video Input (Rear) or to LINE2 for Video Input
(Front). (See “Selecting the Input Mode”below.)
Press PLAY to start dubbing.
Playing VCR starts playback.
Press PAUSE/SLOW to start dubbing.
Recording VCR starts recording.
Press STOP to stop dubbing.
To Monitor Dubbing on Your TV
1Turn your TV on and tune to the Recording
VCR channel (CH3 or CH4).
2Set the VCR/ TV Selector on the Recording
VCR to “VCR.”
•Dubbing tapes protected with Copy
Guard will have poor quality results.
Selecting the Input Mode
Method 1:
Press INPUT repeatedly.
Channel Number ↔↔
↔↔
↔LINE1 ↔↔
↔↔
↔LINE2
Method 2:
Press CH / .
Display will change as below.
•“L1”or “L2”lights on Multi-Function Display
(about 4 sec.) when LINE1 or LINE2 is
selected.
•LINE1: For rear audio/video connection.
LINE2: For front audio/video connection.
Press STOP to stop dubbing.
Press PLAY, then PAUSE/SLOW
immediately to enter PLAY/PAUSE mode.
Connection
Playing (Source) VCR Recording (Editing) VCR
1
2
3
4
5
Caution : Unauthorized exchanging and/or copying of copyrighted recordings may be
copyright infringement.
- 9 -
(Rear connection shown.)
Note
123
125
LINE1 (CABLE)
69
(TV)
or
LINE2
Copying Your Tapes (Dubbing)Before Requesting Service
Power
No power…
Recording & Playback
TV program cannot be recorded...
Timer recording cannot be
performed…
There is no playback picture, or the
playback picture is noisy or contains
streaks...
Special effects playback picture may
contain some vertical jitter when using
a TV with an Automatic Vertical Hold
Control...
VCR cannot be controlled...
Check the following points once again if you are having trouble with your VCR.
(BO : refers to “Basic Operations”Instruction book.)
(AO : refers to “Advanced Operations”Instruction book.)
Correction
•Completely insert Power Plug into an AC outlet.
•Press POWER button on.
•Make sure power source is active.
Miscellaneous
Programs cannot be viewed on TV...
Video cassette cannot be inserted...
Video cassette cannot be removed...
Video cassette ejects when a
recording is started or the power is
turned off for timer recording...
In Stop mode, the motor (CYLINDER)
continues to rotate...
Remote Control
VCR cannot be remote controlled...
ACTION and PROG buttons do not
respond...
If you cannot resolve the problem, please call the Customer Call Center for product
assistance at 1-800-211-PANA (7262).
To locate an authorized servicenter, please call toll free 1-800-211-PANA (7262).
or, contact us via the web at:http://www.panasonic.com/contactinfo
Correction
•Check connections between VCR, external antenna, and TV.
•Check connections selection. (BO p. 4, AO p. 3)
•Make sure your antenna system (CABLE or TV) is correctly
set. (Channels [AO p. 12])
•Make sure cassette record tab is intact. (BO p. 3)
•Confirm that clock is set to current time and date.
•Make sure Cable/DSS box (if used) is left on and tuned to
channel to be recorded.
•Set recording start/stop times correctly. (BO p. 6)
•Make sure VCR POWER button is pressed off. (BO p. 6)
•Timer recording may not be performed or continued if a power
interruption occurs before or during a Timer Recording, even
after power is restored.
•Select channel 3 or 4 on TV to match VCR output channel (3 or
4) (BO p. 4) or select LINE.
•Set VCR/TV selector to “VCR.”
•Adjust TRACKING control in either direction. (BO p. 3)
•Try Head Cleaning. (BO p. 3)
•Set TV’s Vertical Hold Control to MANUAL, then adjust.
•Make sure VCR power is on.
•Check Remote batteries.
•Make sure VCR LOCK is set to off. (AO p. 10)
•Make sure Timer Record is not in progress.
Panasonic Consumer Electronics Company,
Division of Matsushita Electric Corporation of America
One Panasonic Way Secaucus, New Jersey 07094
Panasonic Sales Company (“PSC”),
Division of Matsushita Electric of Puerto Rico, Inc.
Ave. 65 de Infantería. Km. 9.5 San Gabriel Industrial Park,
Carolina, Puerto Rico 00985
P
Correction
•Make sure VCR power is on.
•Make sure Remote is in VCR mode.
•Aim Remote Control directly at remote sensor on VCR. (BO p. 7)
•Avoid any object blocking signal path.
•Check Remote batteries. (BO p. 3)
•Make sure VCR LOCK is set to off. (AO p. 10)
•Exposing VCR remote sensor to direct fluorescent or outdoor
light may cause signal interference.
•Check connections between VCR, external antenna, and TV.
•Press VCR button for VCR mode. (AO p. 2)
•Check Remote batteries. (BO p. 3)
Correction
•Make sure TV power is on.
•Make sure TV is tuned to VCR's output channel (3 or 4).
•Check connections between VCR, external antenna, and TV.
•Set VCR/TV selector to “TV.”(BO p. 5, AO p.10)
•Make sure proper signal source is selected.
•Insert the cassette with window side up; record tab facing you.
•Check if a tape is already in the unit.
•Confirm Power Plug is fully inserted into an AC outlet.
•Make sure cassette record tab is intact. (BO p. 3)
•To enable Quick play mechanism, the cylinder will rotate for
about 5 minutes. This reduces response time from Stop to Play
mode and from Play to Rewind Search mode.
- 8 -
VCR CLOCK CHANNEL
CH AUTO SET PROCEEDING
CANCEL :
STOP
CH AUTO SET PROCEEDING
CANCEL : STOP
REC
1
2
Front of VCR
(Front Audio L/R Video IN jacks
are also provided)
Connect VIDEO OUT jack on Playing VCR to VIDEO IN jack on Recording VCR.
To monitor the dubbing, also connect a TV as shown.
Connect AUDIO L/R OUT jacks on Playing VCR to AUDIO L/R IN jacks on Recording VCR.
In place of a Playing VCR, you can use other equipment, such as a Camcorder.
Simply connect the unit’s Audio/Video outputs to the Recording VCR.
VCR
(HiFi) IN FROM ANT.
OUT TO TV
VIDEO OUT
AUDIO OUT
AUDIO IN
VIDEO IN
TV
VHF/UHF
R
L
R
L
R
L
R
VCR
(HiFi)
VIDEO IN 2 L-AUDIO IN2-R
•For more on VCR/TV selection, see “Record one
station, watch another”and “Select channels on
VCR”sections (p. 5 of Basic Operations book).
The VCR/TV selection can be set to auto or
manual.
Press to select
“AUTO VCR/TV,”
and press to set
“ON”or “OFF.”
1 Press ACTION to display MENU.
2
4
Press ACTION
to return to normal screen.
VCR/TV Selection Feature
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
REPEAT PLAY : O FF
AUT O SHU T - OFF : O FF
FRONT DISPLAY :
ON
AUT O VCR/TV : ON
TAPE SELECT :
T-120
SELE
C T : SET :
EXIT : ACT I O N
SET UP V CR
3
Press to select
“SET UP VCR,”
and press .
•OFF(Manual): You select “VCR”or “TV”mode
using the VCR/TV button on the
unit or remote.
•ON(Auto): “VCR”mode is automatically set
when VCR is turned on, or in Play
mode.
The power shuts off at a preset time.
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
Press to select
“AUTO SHUT-OFF.”
Press repeatedly to
change shutoff time as
shown below.
Auto Shut-Off Feature
1Press ACTION to display MENU.
2
•The shut-off countdown will not
function during Play or Record.
Note
REPEAT PLAY : O FF
AUT O SHU T - OFF : O FF
FRONT DISPLAY :
ON
AUT O VCR/TV : ON
TAPE SELECT :
T-120
SELE
C T : SET :
EXIT : ACT I O N
SET UP V CR
Press to select
“SET UP VCR,”
and press .
4 Press ACTION
to return to normal screen.
3
Note
When set to “ON,”picture is displayed regardless
of signal strength.
•ON : Picture is displayed even if signal
is very weak but quality may be poor.
OFF : Screen turns solid blue when signal
is weak or non-existent.
•Selecting “ON”has no effect on connected
equipment with blue back feature.
Press to select
WEAK SIGNAL
DISPLAY, and press
to set “ON”or “OFF.”
Weak Signal Display ON/OFF Feature
1 Press ACTION to display MENU.
2
4Press ACTION
to return to normal screen.
SELE C T : SET :
EXIT : ACT I O N
ANT ENN A : C ABLE
A
U T O S E T
W EA K S I GN AL D I SPLA Y: OFF
SET UP CH A NNE L
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
3
Press to select
“SET UP CHANNEL,”
and press .
Multi Function Display (Front Display) can be
set to ON/OFF.
•ON : When set to “ON,”
Multi Function Display is displayed
in Standby (OFF) mode.
OFF : When set to “OFF,”
Multi Function Display is not
displayed in Standby (OFF) mode.
If a Timer Program is set,
Multi Function Display is displayed.
Press to select
“FRONT DISPLAY,”
and press to set
“ON”or “OFF.”
Multi Function Display
(Front Display) ON/OFF Feature
1 Press ACTION to display MENU.
3
4Press ACTION
to return to normal screen.
REPEAT PLAY : O FF
AUT O SHU T - OFF : O FF
FRONT DISPLAY :
ON
AUT O VCR/TV : O N
TAPE SELECT :
T-120
SELE
C T : SET :
EXIT : ACT I O N
SET UP V CR
Multi Function Display
(Front Display)
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
2
Press to select
“SET UP VCR,”
and press .
2) Press repeatedly
to change language
item as shown below.
➡
SELECT :
EXIT : ACTION
SET :
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
Printed in Indonesia
LSQT0762
A
S1203-1014
When set to ON, all operations except for timer
record and tape eject are prohibited. Useful for
households with small children.
BLOQUEO DEL VCR:INACTBLOQUEO DEL VCR:INACTIVO
V CR L OC K O FF
•VCR Lock cancels in 24 hours.
To turn on, hold down REC
on the VCR in Stop mode with
no tape inserted for 7 sec.
(Please ignore the NO
CASSETTE warning.)
To turn off, repeat above.
VCR Lock Feature
•Special VCR Features •Copy Your Tapes (Dubbing) •Before Requesting Service
•Reset Language, Channels, Clock, Time Zone Adjust, VCR’s Output Channel •DST •On-Screen Displays (OSD)
Video Cassette Recorder
Operating Instructions
(Advanced Operations)
For Basic operations, see the separate
“Basic Operations”instruction book.
Model No. PV-V4524S
LSQT0762 A
Please read these instructions carefully before attempting to
connect, operate or adjust this product. Please save this manual.
The operation of steps 4 and 5 must be done on both playing
and recording VCRs at the same time.
REC 1 2 : 0 0 A M
0 : 25
CH 02
- 0 : 1 2 : 3 4
SP
S T ER EO
SAP
M ONO
Function Status
Rec Time Remaining
(OTR mode only.
See p. 5 of Basic
Operations book.)
Current Time Channel
Tape Speed
(See p. 3 of Basic
Operations book.)
Broadcast Audio
Being Received
Counter
*Important: If a remote control button does not work when pressed,
press the VCR button on the remote and try the button again.
For assistance, please call : 1-800-211-PANA(7262) or, contact us via the web at:http://www.panasonic.com/contactinfo
As an E NERGY S TAR ®Partner, Matsushita Electric Corporation
of America has determined that this product or product model
meets the
E NERGY S TAR ®guidelines for energy efficiency.
DST : O N
11/21/2004 SUN - 12:00 PM
- - - - - - - - -- - - - - - - -- - - - - -
SET C L OC K
SELECT : SET :
END
: ACT I O N
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 4
PV-V4524S Advanced-1 (040127).p65 2004/01/27, 12:271
LSQT0762A (Advanced Operation)NEW - Front

Tape Operation
- 7 -
*Important: If a remote control button does not work when pressed,
press the VCR button on the remote and try the button again.
Tape Operation
To Calculate Index Number
Example 1:
To go to rec. 2 from rec. 4, enter 3 and press REW.
Example 2:
To go to rec. 6 from rec. 2, enter 4 and press FF.
NOTE: indicates start points of each recording.
•If Index Search is started very close to an
index mark, that index mark may not be
counted in the search.
Search System
For each recording, an invisible index mark is
placed on the tape.
A program index and information are also
included for timer recordings.
These marks are used to access or scan
recordings.
Press SEARCH* to display
SEARCH in Stop or Play
mode, and then press
NUMBER keys to select
recording number.
•To calculate number,
see below.
Press FF or REW to start
search.
Play begins at search end.
To search forward or back 1
index, press FF or REW
while screen left is displayed
(10 sec.).
6
157
2 34
17
5
34 6
2
Index Search
1
2
- 6 -
Note
•To cancel, press PLAY or
STOP.
INDEX SEARCH
FORWARD SEARCH :FF
REVERSE SEARCH :REW
VHS Hi-Fi Stereo System
•Arrow indicates selection.
•Only tapes recorded in Hi-Fi stereo will playback with true stereo sound.
Standard stereo tapes will playback in monaural sound.
•To listen to Hi-Fi stereo playback, the VCR AUDIO (L/R) jacks must be connected to a
stereo TV or an external stereo amp and speakers. (See page 4.)
•If tracking is adjusted during playback, Hi-Fi audio may revert to normal audio.
•Hi-Fi and normal audio playback volume level may differ.
•Refer to “Receivable
Broadcast Types”on page 4.
•Select “HIFI(L/R)”or “HIFI(L)”
or “HIFI(R)”to listen to stereo
recordings in stereo sound.
Select “NORMAL”for
monaural sound.
Press SAP/ Hi-Fi repeatedly
to select desired mode.
Press SAP/ Hi-Fi repeatedly
to select desired mode.
Audio Mode for Recording
1 Press SAP/ Hi-Fi to display audio mode.
(Display disappears after 5 seconds.)
2
3
Make a recording.
See p. 5 of “Basic Operations”Instruction book.
Audio Mode for Playback
1 Start playback.
See p. 5 of “Basic Operations”Instruction book.
2 Press SAP/ Hi-Fi to display audio mode.
(Display disappears after 5 seconds.)
3
•Arrow indicates
selection.
- 5 -
*Important: If a remote control button does not work when pressed,
press the VCR button on the remote and try the button again.
Notes
MTS Broadcast
MONO broadcast
Normal monaural sound broadcast.
SAP broadcast
Secondary Audio Program (sub language) broadcast.
Select SAP audio mode for the sub language.
MTS Stereo broadcast
Multi-channel Television Sound Stereo broadcast.
Select STEREO audio mode.
•If stereo broadcast is weak and display flickers, select MONO
audio mode for possible better results.
MTS Stereo and SAP broadcast
Multi-channel Television Sound Stereo (main language) and
Secondary Audio Program (sub language) broadcasts are being
received simultaneously. Select STEREO or SAP audio mode.
The following are possible audio broadcast types and on-screen displays.
The signal being received is indicated with a “”mark while the selected audio mode is indicated
with an arrow.
To display the broadcast signal being received,
➛➛
➛➛
➛press DISPLAY*.
Equipped with
®
-TV Noise Reduction for true
MTS reproduction.
®
-TV Noise Reduction is
required for good stereo separation and audio
fidelity.
®
is a registered trademark, and is
licensed by
®
Technology Licensing.
Make the Audio/Video Connection as shown on page 3.
•You can use a TV connected to Stereo amp and speakers instead of a Stereo TV.
Stereo Amplifier
AUDIO IN
R
L
VCR
R
L
R
OUT TO TV
VHF/UHF
TV
R
L
AUDIO OUT
Connection
Receivable Broadcast Types
- 4 -
Advanced Connections
You Cannot
You Can
•record and view
both scrambled
and unscrambled
channels if
additional
equipment is
added.
This connection
requires: two
converter boxes,
an A/B switch, and
a 2-way splitter.
•view a channel
other than the
one selected for
any type of
recording.
•do a Timer
recording of a
channel unless
you select it at
the cable box.
If your TV has AUDIO IN and VIDEO IN terminals, you can connect your VCR
to them to receive higher quality picture and sound.
IN
VIDEO
AUDIO
R
L
OUT
IN FROM ANT.
OUT TO TV
AUDIO
IN 1
VHF/UHF
R
L
VIDEO
OUT
TV
IN 2IN 1
CABLE BOX
OUTIN
OUT 2
OUT 1
2-Way Splitter
CABLE BOX
OUT
A/B Switch
VCR
IN
VHF/UHF
■■
■■
■
Connect With Two Cable Boxes
VCR
IN FROM ANT.
OUT TO TV
AUDIO
IN 1
VHF/UHF
R
L
VIDEO
OUT
CABLE BOX
OUTIN
INR
L
OUT
TV
VIDEO
AUDIO
VHF/UHF
■ ■
■ ■
■ With a Cable Box (VCR Cable Box)
ANT
or
CATV
You CannotYou Can
•record scrambled
channels.
•view any
(including
scrambled)
channel.
•use VCR Remote
Control to select
channels without
using Multi-brand
control feature.
ANT
or
CATV
Audio/Video connection
- 3 -
Multi-Brand Control Feature
The Remote Control can be set to control some TV functions.
After remote is set up, you can select VCR or TV for the desired function.
Press VCR or TV on the remote.
(Table below shows available unit buttons for each mode.)
•Not all functions listed may be controllable.
•In TV mode, it may be necessary to press ENTER after pressing NUMBER keys for channel selection.
➛ hold down TV button,
➛ enter code with NUMBER keys.
•Repeat setup after remote battery replacement.
•Remote will not control every TV made by the manufacturer listed. If you get no response, your particular
unit cannot be controlled. There are NO additional codes for the products listed. If your product is not listed,
then the remote is not compatible with that product.
Multi-Brand Control Setup
1Find your TV Brand Code Number from those shown below.
2Set up for TV control,
3Confirm code entry,
➛ press POWER to turn your TV on or off.
•See table below for controllable functions in each mode.
Using Multi-Brand Control
Panasonic ................................... 01, 02
Quasar ......................................... 01, 02
RCA ................................................... 0 3
GE ...................................................... 03
Sharp ................................................. 06
TV Brand Code Numbers
Sony .................................................. 08
Toshiba.............................................. 09
Sanyo ................................................ 1 0
Fisher................................................. 10
Hitachi ............................................... 12
•Some manufacturers use several codes for one brand. If the first code entered fails, try the next one listed.
•Some TV brands require you to turn on the power manually.
- 2 -
Notes
Notes
Important Notes
To quickly return to a specified tape location.
•Unit will go into FF or REW
mode and stop at the last
point the Counter was set
to 0:00:00.
Press COUNTER RESET
on remote at desired
position to reset to
“0:00:00”.
Press CM/ZERO in
Stop mode to start
ZERO SEARCH.
Zero Search
1 Press DISPLAY during play
to display Counter.
2
3
Continue to record, playback, etc.
4 Press STOP.
5
PLAY 1 2 : 0 0 A M
0 : 0 0 : 0 0
SP
REW 1 2 : 3 0 A M CH 02
0 : 30 : 30
SP
STOP 1 2 : 3 1 A M CH 02
0 : 0 0 : 0 0
SP
Set to playback a recording over and over.
Repeat Play
1Press ACTION to display menu.
4Press ACTION
to return to normal screen.
ON :Play repeats at tape end
or if unrecorded portion
over 30 sec. is detected.
Press to select
“REPEAT PLAY,”
and press to set
“ON”or “OFF.”
3
REPEAT PLAY : O FF
AUT O SHU T - OFF : O FF
FRONT DISPLAY :
ON
AUT O VCR/TV : ON
TAPE SELECT :
T-120
SELE
C T : SET :
EXIT : ACT I O N
SET UP V CR
Set the VIDEO/TV selector of your TV (Monitor/Receiver) to “VIDEO.”
3
Connect VCR’s L/R AUDIO OUT jacks to the TV’s L/R AUDIO IN jacks.
2
Connect the VCR’s VIDEO OUT jack to the TV’s VIDEO IN jack.
1
INDEX SEARCH
ENTER INDEX NUMBER :1
USING 1 - 9 KEYS
FORWARD SEARCH :FF
REVERSE SEARCH :REW
EXIT :SEARCH
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
Press to select
“SET UP VCR,”
and press .
2
Tape Select
•“DETECTING TAPE
POSITION”only
appears the first time a
cassette is inserted
and it takes several
seconds for correct
indication to appear.
•The present tape
position indication and
amount of tape
remaining (according to
tape speed) are
displayed.
Tape remaining time
display may not be
precise.
To find out the present tape position and amount
of tape remaining.
DETECTING TAPE POSITION
2 PressTAPE POSITION (or wait 5 seconds)
to return to normal screen.
BE G I N END
SP
R 120 M
I N.
1PressTAPE POSITION
to detect tape position.
VCR fast forwards (skips) over 1, 2, or 3 minutes
of recorded tape as desired.
•Press CM/ZERO repeatedly to change skip
time as shown below.
•No indication appears.
PLAY
1st Press
2nd Press
3rd Press
1 min Skip
2 min Skip
3 min Skip
Commercial Skip
1 Press CM/ZERO in Play mode.
Select your tape length so the tape position and
amount of tape remaining are properly displayed.
(See “Tape Position and Tape Status Display”
section below.)
1Press ACTION to display menu.
4Press ACTION
to return to normal screen.
Press to select
“TAPE SELECT,”and
press to set “T-120,”
“T-160”or “T-180.”
3
Press to select
“SET UP VCR,”
and press .
2
REPEAT PLAY : O FF
AUT O SHU T - OFF : O FF
FRONT DISPLAY :
ON
AUT O VCR/TV : ON
TAPE SELECT :
T-120
SELE
C T : SET :
EXIT : ACT I O N
SET UP V CR
SELECT :
EXIT : ACTION
SET:
MENU
SET UP VCR
SET UP CLOCK
SET UP CHANNEL
IDIOMA/LANGUE : ENGLISH
VCR’S OUTPUT CH: 3
T-120 T-160 T-180
Tape position is displayed incorrectly in the
following cases:
•If VHS-C type cassettes, tapes under 30
minutes, tapes over 180 minutes, or
incompatible tapes are used.
•If the correct tape length is not selected.
(See “Tape Select”section above.)
•Select “T-120”for tapes 120 minutes or
less, “T-160”if 140 or 160 minutes, and
“T-180”if 180 minutes.
STER EO
SAP
M ONO
H I F I : L / R
H I F I : L
H I F I : R
N ORM AL
ST OP 1 2 : 0 0 A M
CH 02
0 : 0 0 : 0 0
SP
STER EO
SAP
M ONO
ST OP 1 2 : 0 0 A M
CH 02
0 : 0 0 : 0 0
SP
STER EO
SAP
M ONO
ST OP 1 2 : 0 0 A M
CH 02
0 : 0 0 : 0 0
SP
STER EO
SAP
M ONO
ST OP 1 2 : 0 0 A M
CH 02
0 : 0 0 : 0 0
SP
STER EO
SAP
M ONO
Notes
TV
VCR IN FROM ANT.
OUT TO TV
VHF/UHF
VIDEO IN
L
AUDIO IN
VIDEO OUT
R
ANTENNA
L
R
AUDIO OUT
•Advanced Connections •Multi-Brand Control Feature
•MTS Broadcast •VHS Hi-Fi Stereo System
•Tape Operation
Tape Position and Tape Status
Display
ModeUnit TV
VCR
TV
All VOL UP/DOWN
POWER, INPUT,
CH UP/DOWN, VOL UP/DOWN
VCR/TV, PLAY, STOP, EJECT, SAP/Hi-Fi, DISPLAY,
FF, REW, PAUSE/SLOW, REC, SPEED, CM/ZERO,
RESET COUNTER, TAPE POSITION
VCR
PV-V4524S Advanced-2 (040119).p65 2004/01/27, 12:273
LSQT0762A (Advanced Operation)NEW -Back
