Sharp VC-MH745SM User manual

GB-1
CONTENTS
BEFORE USING YOUR VCR
Important notes on your VCR ....................................................................................................... 2
Unpacking the accessories ........................................................................................................... 3
INSTALLING YOUR VCR
Connecting the cables ................................................................................................................. 4
Tuning the TV into the VCR............................................................................................................ 5
Auto installation .............................................................................................................................. 6
BASIC OPERATION
Important notes on your VCR and video tapes .........................................................................7
How to playback a video tape ....................................................................................................7
Pausing and slow motion........................................................................................ 8
Fast forwarding/rewinding a video tape.............................................................. 9
Immediate recording................................................................................................................... 10
How to set a delayed recording ................................................................................................ 11
Checking, changing and cancelling a recording ............................................ 13
ADVANCED OPERATION
Audio and your VCR .................................................................................................................... 14
Playback of a video tape ........................................................................................................... 16
Checking the amount of tape remaining .......................................................... 16
Playing back a video tape repeatedly .............................................................. 16
Digital Display................................................................................................................................ 17
Blue mute ...................................................................................................................................... 18
Colour ............................................................................................................................................ 18
Searching the video tape ........................................................................................................... 19
Skip searching the video tape ............................................................................. 19
Digital programme search system (DPSS)........................................................... 19
Recording from other equipment .............................................................................................. 20
SPECIAL FEATURES ON YOUR VCR
Child lock....................................................................................................................................... 21
CUSTOMISED INSTALLATION
Manually tuning a channel ......................................................................................................... 22
Broadcast and CATV channels .................................................................................................. 23
Decoder switching operation.....................................................................................................23
Manually sorting channels........................................................................................................... 24
Sorting the channels into your preferred order.................................................. 24
Changing the on-screen display language.............................................................................. 25
Manually setting the clock .......................................................................................................... 25
MORE INFORMATION ABOUT YOUR VCR VCR
VCR digital display ...................................................................................................................... 26
Selecting the output from the VCR ............................................................................................ 26
On-screen display......................................................................................................................... 27
Specifications................................................................................................................................ 28
Troubleshooting ............................................................................................................................ 29
TINS-3879ENG.book Page 1 Wednesday, June 14, 2000 9:44 AM

GB-2
BEFORE USING YOUR VCR
IMPORTANT NOTES ON YOUR VCR
IDEAL VCR LOCATION
PLACE THE VCR..
• ... on a flat level surface away from radiators
or other heat sources and out of direct
sunlight.
• ... and video tapes away from magnetic
sources such as speakers or microwave ovens.
• ... at least 8” (20cm) away from the TV.
• ... away from curtains, carpets or other
materials and allow ventilation space around
the VCR.
DO NOT...
• ... block the air-vent openings.
• ... expose the VCR to excessive dust,
mechanical vibration or shock.
• ... place any heavy object or liquid on top of
the VCR. If liquid drops inside the VCR unplug
immediately and contact your SHARP dealer.
Do not use the VCR.
• ... insert or drop anything into the tape
compartment or through the
air-vents, as this could result in serious
damage, fire or an electric shock.
POWER SOCKETS
• To avoid overheating or even fire, insert the
plug correctly into the socket.
DO NOT...
• ... overload power sockets, this may cause a
fire or electric shock.
• ... pull the power cord to disconnect the plug
from the mains.
• ... bind the power cords together.
• This VCR is not equipped with a mains power
switch. Accordingly, nominal current to drive
the clock is drawn at all times when the AC
power cord is plugged into a wall socket. If
the VCR is not to be used for an extended
period be sure to unplug the cord.
TINS-3879ENG.book Page 2 Wednesday, June 14, 2000 9:44 AM

GB-3
BEFORE USING YOUR VCR
UNPACKING THE ACCESSORIES
TO FIT THE BATTERIES INTO THE REMOTE CONTROL
Remove the battery cover on the back of the remote control.
Fit the batteries: to and to terminals. Place the
battery cover back into position.
CHECK ALL THESE ACCESSORIES ARE SUPPLIED WITH YOUR VCR. CONTACT YOUR DEALER IF
ANY ARE MISSING.
(TYPE AA/R6/UM3)
BATTERIES (X2)
for the remote control unit.
RF CONNECTION CABLE
connects the VCR to the TV.
Remote Control
• Remote Control must be pointed towards the VCR to operate.
• Do not expose to liquid or shock.
• May not function if the VCR is in direct sunlight or any other strong light.
• Replace both alkaline batteries (type AA/R6/UM3) if the remote control
fails.
• Remove the batteries and keep in a safe place if you do not plan to use
the VCR for several months.
• Remove and dispose of flat batteries safely and promptly.
• Incorrect use of batteries may cause them to leak or burst.
VIDEO CASSETTE RECORDER
REMOTE
CONTROL
For a more
detailed
picture of
your remote
control refer
to page (ii).
Battery cover
TINS-3879ENG.book Page 3 Wednesday, June 14, 2000 9:44 AM

GB-4
INSTALLING YOUR VCR
CONNECTING THE CABLES
✔
The VCR is correctly connected.
Connect your existing aerial
cable to the
ANTENNA IN
socket on your VCR.
Optional:
Connect your
Satellite receiver or decoder to
the VCR using a scart lead to
LINE 2 IN/DECODER
socket on the VCR.
Connect the VCR to the
mains
Optional
SCART (not supplied). If you
have a scart lead connect it to your TV and
LINE 1 IN/OUT
socket on the VCR.
Connect your TV
to the VCR using
the supplied rf
connection cable,
i.e. connect the
VCR
RF OUT
socket to the TV
AERIAL IN
socket.
AERIAL OR
CATV CABLE
DECODER UNIT
OR SATELLITE SYSTEM
BACK OF
TELEVISION
TINS-3879ENG.book Page 4 Wednesday, June 14, 2000 9:44 AM

GB-5
INSTALLING YOUR VCR
TUNING THE TV INTO THE VCR
1.
Press
STANDBY
( ) to ensure your
VCR is still in the STANDBY mode.
2.
Switch on the TV. Select an unused
channel on your TV for your VCR (there
may be a dedicated video channel refer
to your TV operation manual).
3.
Press and hold the
MENU
button for 3
seconds. The VCR will search and display
the ideal RF channel.
CAUTION:
If the clear button is pressed at this point it will not allow the TV to be tuned to the VCR. Refer
to RF through ON/OFF.
4.
Tune the selected channel on your TV
(refer to your TV manual) until the menu
screen appears.
5.
Press
SET
to store the RF channel and to
place the VCR back into STANDBY.
NOTE:
✔
The TV is tuned to the VCR.
• If you have a preferred channel, the RF channel can be set manually (21-69) after
Step 3 using [ / ] keys.
RF THROUGH ON/OFF:
• If you wish to connect your VCR to the TV with only a scart lead, the RF Output on your
VCR can be turned OFF and ON by pressing the
CLEAR
button then
SET
to return to
STANDBY at point 2. This will help minimise interference.
VCR
Example:
MENU SCREEN
TIMER
MODE
SET UP
:SELECT
SET : ENTER MENU : EX I T
TINS-3879ENG.book Page 5 Wednesday, June 14, 2000 9:44 AM

GB-6
INSTALLING YOUR VCR
AUTO INSTALLATION
Press
STOP
to switch on your VCR.
This model will automatically tune in the TV channels in your area.
The screen opposite should be showing on your TV.
Follow the instructions from the screens.
(Auto sort will take a few minutes to complete)
On completion, the MOVE MENU will appear
showing the present channel order. Press
MENU
to
exit.
If you wish to customise the channel order refer to
MANUALLY SORTING CHANNELS
.
VCR RESET
1.
Press
STOP
to switch on the VCR.
2.
Press and hold
MENU
and
CHANNEL
buttons together on the front of the VCR
for 10 seconds.
3.
The AUTO INSTALLATION screen should now be showing on your TV.
4.
Follow the on-screen display to proceed with auto installation.
✔
All the programmes should now be correctly tuned in and the clock set.
✔
Refer to the
CUSTOMISED INSTALLATION
chapter if
• Your VCR could not tune automatically - due to for example poor reception.
• You wish to re-arrange the channel order.
• You wish to change the time on the clock or if the VCR could not set the time.
• If the screen above does not
appear, follow the procedure
VCR RESET below.
AUTO I NSTALLAT I ON
PRESS SET KEY TO START
AUTOMAT I SCHE E INSTELLUNG
ZUM BEGINN,DIE SET-TASTE
DRÜCKEN .
SET : ENTER MENU : EX I T
TINS-3879ENG.book Page 6 Wednesday, June 14, 2000 9:44 AM

GB-7
BASIC OPERATION
IMPORTANT NOTES ON YOUR VCR AND VIDEO
TAPES
VIDEO TAPES
• If you use only good quality video tapes, generally it will not be necessary to clean the
video heads.
• If poor quality tapes are used, or if a tape is loaded after changing VCR location, oxide
from the tape may "clog" the video heads. This will cause the playback picture to be
"snowy", or even disappear.
• To remove minor contamination run a video tape in visual search mode. If this fails, you
will need to have the heads cleaned by a SHARP Service Facility. Please note, if cleaning
is necessary it is not covered by the guarantee.
• Use video tapes which carry the mark.
HOW TO PLAYBACK A VIDEO TAPE
PLAYBACK
1.
Switch on your TV and select the video channel.
2.
Carefully push a pre-recorded video
tape into the tape compartment.
This will switch the VCR on.
• If the record-protection tab has
been removed, the VCR will start
playback as soon as the video tape
has been loaded.
3.
To start playback, press
PLAY/X2
().
BEFORE YOU PLAYBACK A VIDEO TAPE
Condensation forms in the VCR when it is moved out of or into a warm place.
If you try to playback or record, the video tape and VCR may be damaged.
Turn the VCR on and wait for about two hours until the VCR reaches room
temperature before operating.
SECAMPAL
Record protection tab
TINS-3879ENG.book Page 7 Wednesday, June 14, 2000 9:44 AM

GB-8
BASIC OPERATION
HOW TO PLAYBACK A VIDEO TAPE
SHARP SUPER PICTURE
should enhance the picture quality during playback. It is
normally set to ON. To turn
SHARP SUPER PICTURE
on or off press
SUPER P.
on the
VCR front panel.
• For double speed playback (without sound), press
PLAY/X2
( ) again.
• To revert to normal playback, press
PLAY/X2
( ) again.
• To stop the video tape, press
STOP
().
• To eject the tape press
EJECT
on the VCR.
PICTURE DISTURBANCE DURING PLAYBACK
This VCR has an automatic tracking system which reduces picture disturbance when you start
to playback a video tape. When auto-tracking is in operation flashes on the on-screen
display. If the picture still has disturbance you may need to manually track the video tape:
During PLAYBACK of a video tape.
• Press
CHANNEL
or to position picture interference off the TV screen. (Manual
Tracking)
• Press
CHANNEL
and buttons together to start Auto Tracking.
PAUSING AND SLOW MOTION
1.
Press
PLAY/X2
( ) to start the video tape playing.
2.
To pause the video tape, press
PAUSE/STILL
()
.
• To minimise jitter whilst in pause mode press
CHANNEL
or .
• Press
PLAY/X2
( ) to resume playback.
3.
To playback in slow motion (without sound) press
SLOW
on the remote control. Slow
motion speed can be adjusted using the or buttons next to the slow button.
Picture disturbance can be improved by using the
CHANNEL
or during slow
motion playback.
• Press
PLAY/X2
( )to resume playback.
NOTES:
• When using SLOW MOTION function some mechanical noise may be heard.
• There will be picture interference and possibly a change to black and white picture
using Pause and Slow functions.
• PAUSE mode will disengage after about 5 minutes.
TINS-3879ENG.book Page 8 Wednesday, June 14, 2000 9:44 AM

GB-9
BASIC OPERATION
HOW TO PLAYBACK A VIDEO TAPE
FAST FORWARDING/REWINDING A VIDEO TAPE
1.
Press
STOP
( ) to stop the video tape.
2.
Press
FAST FORWARD
()/
REWIND ( ) on the remote control or turn the
shuttle ring on the VCR to the Right/Left and release.
3. To stop fast forward/rewind, press STOP ().
FORWARD/REVERSE VISUAL SEARCH
1. During playback, press FAST FORWARD ()/REWIND ( ) on the remote
control, or turn the shuttle ring fully to the Right/Left.
2. To lock search mode turn the shuttle far Right/Left and release.
3. To decrease the speed, press FAST FORWARD ()/REWIND ( ) again, or
turn the shuttle to the halfway position.
4. Press PLAY/X2 ( ) to resume playback.
NOTE:
• There will be picture interference and possibly a change to black and white picture
using Visual Fast Forward/Rewind functions.
TINS-3879ENG.book Page 9 Wednesday, June 14, 2000 9:44 AM

GB-10
BASIC OPERATION
IMMEDIATE RECORDING
SELECTION OF A CHANNEL
Select the channel by using the number buttons on the remote control, or select the
next/previous channel by pressing CHANNEL [or].
To change between single digit and 2-digit channel numbers, press AM/PM .
For example, for channel 24, press AM/PM then press 24.
You can record the channel you are watching or a different channel.
1. Insert a video tape into your VCR.
2. Select the channel you wish to record on the VCR.
3. To start recording, press REC ().
4. To pause during recording, press PAUSE/STILL ().
5. To continue recording, press REC ().
6. To stop recording, press STOP ( ) once.
SIMPLE TIMED RECORDING:
1. To specify a stop time, press REC ().
2. Each additional press of REC ( ) will delay
the stop time by 10 minutes.
3. To stop recording at any time, press
STOP ( ) once.
NOTES:
• If the tape ends before the recording is complete the VCR will stop recording and
rewind, or eject if the VCR is in timer record mode.
• If the VCR ejects the video tape when you press REC ( ) the tape is record
protected. i.e. record protection tab has been removed.
STOP 15:30
TINS-3879ENG.book Page 10 Wednesday, June 14, 2000 9:44 AM

GB-11
BASIC OPERATION
HOW TO SET A DELAYED RECORDING
You can make a maximum of eight delayed recordings up to a year in advance.
The example shown is for 24-hour clock operation. 12-hour clock operation can be selected
from the manual clock setting menu.
12-hour clock am/pm can be selected using the AM/PM button on the remote control.
• If appears on the VCR display, press TIMER ON/OFF before starting.
• Check that the clock is displaying the correct time.
SETTING A RECORDING
For example: Recording a programme on channel 3 from 21:05 to 22:30 on July 9th.
1. Press STOP ( ) to switch on the VCR.
2. Press MENU .
3. Press [ / ] to select TIMER. Press SET to
confirm.
4. The position which is initially highlighted is the
next available timer record entry. Press SET to
confirm this.
• The display will automatically show today's
date.
Either: If this is the date you wish to make the
recording on, press SET to confirm this.
Or: enter the recording date using the[ /
] or the NUMBER BUTTONS. Enter two
digits for the day, then two for the month. For
example for July 9th, press 0 9 (9th), then 0 7
(July).
5. Then press SET to confirm.
6. If you want to make additional recordings at
the same time each day or week, use [ /
] or select D (daily) or W (weekly). Then
press SET to confirm.
7. Enter the channel using the [ / ] or the
NUMBER BUTTONS. For example to
record a programme on channel 3, press 0 3.
Then press SET to confirm.
MENU SCREEN
TIMER
MODE
SET UP
:SELECT
SET : ENTER MENU : EX I T
1/2
DATE PR START STOP
21/060212:0013:00SP
9/07 -- -:-- -:-- --
--/-- -- -:-- -:-- --
--/-- -- -:-- -:-- --
1/2
DATE PR START STOP
21/060212:0013:00SP
9/07D-- -:-- -:-- --
--/-- -- -:-- -:-- --
--/-- -- -:-- -:-- --
TINS-3879ENG.book Page 11 Wednesday, June 14, 2000 9:44 AM

GB-12
BASIC OPERATION
HOW TO SET A DELAYED RECORDING
8.
Enter the start time using the [ / ] or the
NUMBER BUTTONS
hours first then minutes
(when entering less than 10 minutes add a '0'
before the number), for example for 21:05 start,
press
2 1 0 5
. Then press
SET
to confirm.
9.
Enter the stop time, for example for 22:30 stop,
press
2 2 3 0
.
10.
If your VCR has long play facility
and you wish to
change the
RECORDING SPEED
, use the
[ / ] to highlight SP. Press [ / ] to
select standard play (SP) or long play (LP) as
required.
11.
Press
SET
to confirm.
• The MENU now shows all the timer settings you
have entered. If you wish to make additional
timer recordings, repeat this procedure.
12.
When you have completed entering timer
settings, press
MENU
to remove the menu
from the TV screen.
13.
Press
TIMER ON/OFF
once to place the VCR
in TIMER POWERSAVE/TIMER STAND-BY mode.
will be shown on the display.
NOTES:
• If flashes a video tape has not been inserted into the VCR.
• If the video tape is ejected when the VCR tries to record the record protection tab has
been removed.
• During recording, press
STOP
( ) to cancel the recording. If there are further
recordings to be made, the VCR will return to TIMER POWERSAVE/TIMER STANDBY.
1/2
DATE PR START STOP
21/060212:0013:00SP
9/07D03 21:05 -:-- SP
--/-- -- -:-- -:-- --
--/-- -- -:-- -:-- --
1/2
DATE PR START STOP
21/060212:0013:00SP
9/07D03 21:05 22:30 LP
--/-- -- -:-- -:-- --
--/-- -- -:-- -:-- --
1/2
DATE PR START STOP
21/060212:0013:00SP
9/07D03 21:05 22:30 LP
--/-- -- -:-- -:-- --
--/-- -- -:-- -:-- --
Module 07A.fm Page 12 Wednesday, June 21, 2000 8:57 AM

GB-13
BASIC OPERATION
HOW TO SET A DELAYED RECORDING
CHECKING, CHANGING AND CANCELLING A RECORDING
CHECKING A RECORDING
1. If in TIMER POWERSAVE/TIMER STANDBY mode,
press TIMER ON/OFF to exit.
2. Press STOP to switch on the VCR.
3. Press MENU.
4. Press [ / ] to select TIMER. Press SET to
confirm
• All the delayed recordings in the VCR’s memory
will be shown.
• You can check the settings and change or cancel them.
CHANGING A RECORDING
1. Follow steps 1 to 4 of CHECKING A
RECORDING.
2. If you wish to change a delayed recording,
press [ / ] to highlight the recording,
then press SET.
3. Press [ / ] to highlight the setting to be
changed and correct it by using the[ / ]
or the NUMBER BUTTONS.
4. When all corrections are complete press SET,
then press MENU.
CANCELLING A RECORDING
1. Follow steps 1 to 4 of CHECKING A
RECORDING.
2. If you wish to cancel a delayed recording, press
[ / ] to highlight the recording to be
cancelled, then press CLEAR.
3. Press MENU.
NOTE:
• If there are some programmes to be recorded, do not forget to press TIMER ON/OFF
button to return the VCR to TIMER POWERSAVE/TIMER STAND-BY mode.
MENU SCREEN
TIMER
MODE
SET UP
:SELECT
SET : ENTER MENU : EX I T
1/2
DATE PR START STOP
21/060212:0013:00SP
--/-- -- -:-- -:-- --
--/-- -- -:-- -:-- --
--/-- -- -:-- -:-- --
1/2
DATE PR START STOP
21/060212:0013:00SP
--/-- -- -:-- -:-- --
--/-- -- -:-- -:-- --
--/-- -- -:-- -:-- --
TINS-3879ENG.book Page 13 Wednesday, June 14, 2000 9:44 AM

GB-14
ADVANCED OPERATION
AUDIO AND YOUR VCR
HI-FI STEREO SOUND
Stereo sound is possible from this VCR if you have a stereo TV connected to the VCR with a
scart lead, or audio equipment connected with audio phono leads. The VCR is normally set
so that stereo sound is possible. The sound output from the VCR is controlled by the
AUDIO OUT button on the remote control. If you wish to change the sound output you can
use the AUDIO OUT button as follows:
• Press AUDIO OUT once. The LEFT audio channel will be sent to BOTH speakers. L will
appear on the VCR display.
• Press AUDIO OUT twice. The RIGHT audio channel will be sent to BOTH speakers. R will
appear on the VCR display.
• Press AUDIO OUT three times. The MONO track will be sent to BOTH speakers. Land R
will disappear from the VCR display.
• Pressing AUDIO OUT a fourth time, normal Hi-Fi stereo sound will be heard. L and Rwill
appear on the VCR display.
NICAM/IGR Hi-Fi STEREO SOUND
Your VCR can receive and record programmes broadcast in NICAM or IGR sound (the factory
pre-set condition for NICAM is AUTO). NICAM or IGR sound may not be stereo, this depends
on the programme being received.
Audio is automatically recorded in two different ways:
(i) Hi-Fi: Using specialised rotary heads, two audio signals are recorded on to the tape. These
will be stereo, mono or bilingual depending on the sound being received.
(ii) Normal: A mono recording is also made on the conventional analogue audio track.
1. Press MENU to display the main menu on the
screen.
2. Press [ / ] to select MODE.
3. Press SET. NICAM will be selected.
4. Press [ / ] to select OFF.
5. Press SET, to return to the menu screen.
6. Press MENU, to exit to normal screen.
NOTES:
• If the tape being played back does not carry sound recorded on Hi-Fi tracks, L and R
will not appear on the display.
• lf the sound contains ‘crackling’ or ‘popping’ noises the sound quality may be
improved by adjusting the tracking using CHANNEL / .
• If the poor quality is for a long period the VCR will automatically select the mono track
and the sound will be in mono.
• Not all TV transmitters provide NICAM or IGR sound. In this case the VCR automatically
switches to receive the mono signal.
• NICAM sound may not be stereo.
➝NICAM AUTO OFF
COLOUR AUTO PAL MESECAM
TINS-3879ENG.book Page 14 Wednesday, June 14, 2000 9:44 AM

GB-15
ADVANCED OPERATION
AUDIO AND YOUR VCR
CONNECTING TO AUDIO EQUIPMENT
The diagram below shows how to connect your VCR to audio equipment. When connected
in this way stereo sound is possible from the speakers.
RFOUT
SORTIE ANTENNE
ANTENNA IN
ENTREE
+
BACK OF
EXISTING AERIAL
CABLE
RF CONNECTION CABLE
RF-OUT
AUDIO OUT
AMPLIFIER
L and R
TELEVISION
AERIAL IN
AUDIO PHONO LEADS
(NOT SUPPLIED)
TINS-3879ENG.book Page 15 Wednesday, June 14, 2000 9:44 AM

GB-16
ADVANCED OPERATION
PLAYBACK OF A VIDEO TAPE
CHECKING THE AMOUNT OF TAPE REMAINING
When you load a video tape into the VCR it can calculate approximately the amount of
video tape remaining in hours and minutes. This is useful in determining whether or not there is
sufficient tape left to make a recording.
When a video tape is playing, the amount of tape remaining is calculated for you
automatically.
To display the amount of video tape remaining:
1. Load the video tape into the VCR
2. Press DISPLAY on the remote control as many times as necessary until “R” appears on
the VCR display. The tape will wind forward and then return to its original position. The
tape remaining will be shown on the VCR display in hours and minutes.
For example, if 1 hour 23 minutes is left on the tape:
NOTES:
PLAYING BACK A VIDEO TAPE REPEATEDLY
You can set your VCR to automatically rewind at the end of playing a video tape and replay
the entire tape again. REPEAT will appear on the on-screen display when selected.
To use this feature:
1. Press MENU to display the main menu on the
screen.
2. Press [ / ] to select MODE.
3. Press SET.
4. Press [ / ] to select REPEAT.
5. Press [ / ] to select ON.
6. Press SET.
7. Press MENU to return to normal screen.
• Do not interrupt the tape remaining calculation.
• If less than 5 minutes of tape remains the display will flash.
Pr
Pr
MODE MENU SCREEN
BLUE MUTE AUTO OFF
➝REPEAT ON OFF
:SELECT : CHANGE
S E T : EN T E R ME NU : E X I T
TINS-3879ENG.book Page 16 Wednesday, June 14, 2000 9:44 AM

GB-17
ADVANCED OPERATION
DIGITAL DISPLAY
TIME OF DAY
Shows current time of day, if the clock is set.
Press DISPLAY until the time of day appears. For
example, 21:20 appears:
OPERATION MODE
Shows status of tape. Press DISPLAY until the display
appears, for example:
TAPE COUNTER AND ZERO BACK
Tape counter measures the current position of the video tape in real time. ZERO BACK uses the
tape counter to determine a specific point on a tape you may wish to return to.
1. Press DISPLAY until tape counter appears, for
example:
2. To identify the current position on a video tape
press CLEAR and the tape counter will appear:
When you wish to return to this position on the video tape, press ZERO BACK. The tape will
rewind/advance to this point.
NOTE:
• The tape counter will only operate on recorded sections of tape.
TINS-3879ENG.book Page 17 Wednesday, June 14, 2000 9:44 AM

GB-18
ADVANCED OPERATION
BLUE MUTE
The TV screen will be blue if a TV channel with no signal is selected, an unrecorded section of
tape is played or the quality of the recording on the tape is poor. Select OFF to disable this
feature.
1. Press MENU to display the main menu on the
screen.
2. Press [ / ] to select MODE.
3. Press SET.
4. Press [ / ] to select BLUE MUTE.
5. Press [ / ] to select OFF.
6. Press SET and then MENU to return to the
normal screen.
COLOUR
If the VCR is playing poor quality recording, the picture may turn black and white. Selecting
PAL/MESECAM may improve this (depending on the recording), although coloured speckles
may appear on black and white recordings.
1. Follow steps 1 to 3 from BLUE MUTE.
2. Press [ / ] to select COLOUR.
3. Press [ / ] to select AUTO/PAL or MESECAM
4. Press SET and then MENU to return to the normal screen.
MODE MENU SCREEN
NICAM AUTO OFF
COLOUR AUTO PAL MESECAM
BLUE MUTE AUTO OFF
REPEAT ON OFF
TINS-3879ENG.book Page 18 Wednesday, June 14, 2000 9:44 AM

GB-19
ADVANCED OPERATION
SEARCHING THE VIDEO TAPE
SKIP SEARCHING THE VIDEO TAPE
You can search the tape in 30 second time intervals. To do this follow the procedure below:
1. Press PLAY/X2 ( ) to start the video tape playing.
2. Press SKIP SEARCH on the remote control.
The number of times you press SKIP SEARCH
determines the forward search time.
• After searching, normal playback
will resume automatically.
DIGITAL PROGRAMME SEARCH SYSTEM (DPSS)
Your VCR records a marker signal on the tape at the start of each recording. These signals can
be used later to locate the starting point of a recording.
Press DPSS to locate a previous programme or the next programme.
For example,
1. Load the video tape into the VCR.
2. Press DPSS three times. DPSS 3will appear on the on-screen display, and the VCR will
fast forward to locate the third recording after the current one.
3. Press DPSS once. DPSS -1will appear on the on-screen display and the VCR will
rewind to locate the beginning of the current recording.
4. To cancel the search before it has finished, press STOP ( ) or PLAY/X2 ().
NOTES:
• Recordings must be longer than 3 minutes..
• The starting point of playback may vary.
• This feature will only work with video tapes recorded on a VCR with the DPSS feature.
1 press = 30 seconds.
2 presses = 1 minute.
3 presses = 1 minute 30 seconds.
4 presses = 2 minutes.
/
-1
+1 +2
+3
RECORDING5
RECORDING4
RECORDING3
RECORDING2
RECORDING1
DPSS
Signals
Current tape position
Fast ForwardRewind
DPSS
Number
TINS-3879ENG.book Page 19 Wednesday, June 14, 2000 9:44 AM

GB-20
ADVANCED OPERATION
RECORDING FROM OTHER EQUIPMENT
You can record video and audio signals from various sources, for example a camcorder, onto
a video tape using your VCR.
For example, recording from a camcorder connected to LINE 2 IN/DECODER on your VCR:
1.
Load tape into the VCR.
2.
Press
INPUT SELECT
on the remote control
until the VCR display shows
L2
.
3.
If you wish to record from a source connected to
LINE 1 IN/OUT, select
L1
.
4.
Press
REC
to start the recording.
NOTE:
• There are many different ways of connecting external equipment to your VCR. Please
refer to your equipment operation manuals for further information.
RF OUT
SORTIE ANTENNE
ANTENNA IN
ENTREE
Optional Scart connection (not supplied)
Mono/Stereo Camcorder
AM PM
INPUT SELECT
CHANNEL
REW FF
PLAY / X2
78
0
9
AM/PM
➘
Input Select
AM PM
Module 13A.fm Page 20 Tuesday, June 20, 2000 11:57 AM
This manual suits for next models
1
Table of contents
Other Sharp VCR System manuals

Sharp
Sharp VC-MH713HM User manual

Sharp
Sharp VC-A220X User manual

Sharp
Sharp VC-A410X User manual

Sharp
Sharp VC-A565U User manual

Sharp
Sharp VC-FH300SM User manual

Sharp
Sharp VC-MH71SM User manual

Sharp
Sharp VC-H998U User manual

Sharp
Sharp VC-A136X User manual

Sharp
Sharp VC-A422U User manual

Sharp
Sharp VC-MH75HM User manual

Sharp
Sharp VC-SA350 User manual

Sharp
Sharp VC-H992U User manual

Sharp
Sharp VC-S2000HM User manual

Sharp
Sharp VC-90ET User manual

Sharp
Sharp DV-NC200SS User manual

Sharp
Sharp VC-H85X User manual

Sharp
Sharp vc-a260x User manual

Sharp
Sharp VC-MH835HM User manual

Sharp
Sharp VC-S101U User manual

Sharp
Sharp VC-M313HM User manual
