Drum Type Washing Machine
Model No. NA-127VB6WSR
Product Colour : White
Destination : ISRAEL
TABLE OF CONTENTS PAGE PAGE
1 Safety Precautions----------------------------------------------- 2
2 Specifications ----------------------------------------------------- 3
3 Location of Controls and Components ------------------- 5
4 Installation Instructions---------------------------------------- 6
5 Operating Instructions------------------------------------------ 8
6 Test Mode ----------------------------------------------------------10
7 Service Mode -----------------------------------------------------12
8 Troubleshooting Guide----------------------------------------14
9 Critical Torque Values -----------------------------------------15
10 Disassembly and Assembly Instructions ---------------16
11 Component Specifications-----------------------------------32
12 Wiring Connection Diagram ---------------------------------40
13 Exploded View and Replacement Parts List -----------42

2
1 Safety Precautions

3
2 Specifications
2.1. Product Specifications
2.2. Name Plate (Example)
Model NA-127VB6
Product Type Front Loader
Capacity 7 kg
Max Spin Speed 1200 rpm
Drum Volume 50 lt
Energy Label Rating A+++
Energy Consumption 162 kWh / annum
Water Consumption 9240 L/annum
Noise Level Wash 58 dBA
Spin 74 dBA
Control Panel LCD Display
Wash Programs 15 settings
Spin Speed Setting 7 setting
Dimensions Height 84.5 cm Width 59.7 cm
Depth 52.7 cm
Door Opening Large door opening
Delay Time Setting Yes
Colour White
Water Protection Overflow Protection
Other Features Child Lock
Packaging Shrink package

4
2.3. Dimension
Dimension in millimetres
NA-127VB6

5
3 Location of Controls and Components

6
4 Installation Instructions
4.1. Moving and Installing
4.1.1. Removal of Transportation Screw
1. Transportation screws, which are located at the back side
of the machine, must be removed before running the
machine.
2. Loosen the screws by turning them anticlockwise with a
suitable spanner.
3. Pull out the screws and rubber washers.
4. The holes where the transport screws have been
removed should be covered with the plastic transport
caps found in the accessories bag.
5. The transportation screws that have been removed from
the machine must be re-used in any future transporting of
the machine.
4.1.2. Foot Adjustment
1. Do not install machine on rugs or similar surfaces.
2. For machine to work silently and without any vibration, it
should be installed on a flat, non-slippery firm surface.
Any suspended floor must be suitably strengthened.
3. You can adjust the level of machine using its feet.
4. First, loosen the plastic adjustment nut away from the
cabinet base.
5. Change the level by adjusting the feet upwards or down-
wards.
6. After level has been reached, tighten the plastic adjust-
ment nut again by rotating it upwards against the base of
the cabinet.
7. Never put cartons, wooden blocks or similar materials
under the machine to balance irregularities of the floor.
4.1.3. Electrical Connection
1. Washing machine requires a 50Hz supply of 220-
240Volts.
2. A special earthed plug has been attached to the supply
cord of washing machine. This plug must be fitted to an
earthed socket. The fuse value fitted to this plug should
be 13 amps. If you have any doubts about electrical sup-
ply, consult a qualified electrician.
THIS APPLIANCE MUST BE EARTHED.
Insert the machine’s plug to a grounded socket which
you can easily reach.

7
4.1.4. Water Supply Connection
1. Washing machine is supplied with a single (cold) water
inlet.
2. To prevent leakage from the connection joints, a rubber
washer is included in the hose packing. Fit this washer at
the end of water inlet hose on the tap side.
3. Connect the hose to the water inlet valve. Tighten the
plastic connector by hand. Please call a qualified plumber
if you are unsure about this.
4. Water pressure of 0,1-1 MPa from tap will enable
machine to work more efficiently. (0,1 MPa pressure
means water flow of more than 8 litres in 1 minute from a
fully opened tap)
5. After connection is complete, check for leakage by turning
on tap completely.
6. Make sure that water inlet hoses can not become folded,
damaged, stretched or crushed when the washing
machine is in its final position.
7. Mount the water inlet hose to a 3/4” threaded water tap.
4.1.5. Drain Connection
1. Make sure that water inlet hoses are not folded, twisted,
crushed or stretched.
2. The drain hose should be mounted at a minimum height
of 60 cm, and a maximum height of 100 cm from the floor.
3. The end of the drain hose can be connected directly to a
drainage stand-pipe or alternatively to a specific connec-
tion point designed for that purpose on the waste outlet of
a sink unit.
4. Do not extend the drain hose or guarantee will be invali-
dated.
4.2. Detergent Box Group
PREWASH = WATER ENTRY VALVE 1
MAIN = WATER ENTRY VALVE 2
SOFTENER = WATER ENTRY VALVE 1 + VALVE 2

8
5 Operating Instructions
5.1. LCD Screen, Function Buttons & Knobs
PR Program selector 16 programs including off position
SW1 Switch 1, Start / Pause
SW2 Switch 2, Temperature Selection
SW3 Switch 3, Spin Speed Selection
SW4 Switch 4, Delay Timer Selection
SW5 Switch 5, Extra Rinse Option
SW6 Switch 6, Easy Ironing Option
SW7 Switch 7, Eco/Speed Mode Option
SS1 7 Segment LCD for Temperature Display I8 Extra Rinse Symbol
SS2 7 Segment LCD for Spin Speed Display I9 Easy Ironing Symbol
SS3 7 Segment LCD for Remaining Time I10 Eco Mode Symbol
I1 Child Lock Symbol I11 Speed Mode Symbol
I2 Door Lock Symbol I12 Cold Wash Symbol
I3 Drain Phase Symbol I13 Temperature Sign
I4 Spin Phase Symbol I14 Program Proceeding Zone
I5 Rinse Phase Symbol Slow Blink ON 0.5 sec, OFF 0.5 sec, ON 0.5 sec
I6 Wash Phase Symbol Fast Blink ON 0.10 sec, OFF 0.10 sec, ON 0.10 se
I7 Delay Symbol

9
5.2. Program Details

10
5.3. Child Lock
Activation
1. Press SW7 for 5 seconds.
2. The Child Lock Symbol on appears on the LCD display as
Child Lock is active.
Deactivation
1. Press SW7 for 5 seconds.
2. The Child Lock Symbol will disappear on LCD display
upon deactivation.
6 Test Mode
6.1. Autotest
1. Set PR to program 3 (Colours)
2. While pressing SW5 (Extra Rinse), change position of the
PR from third program to second (Cotton-Prewash), and
release SW5.
3. Autotest starts.
