Panda MD22 Series User manual

MD22xx barcode scanner quick guide
A standard packing includes a scanner, a USB cable and a CD (or a user manual).
Accessories include a stand, a RS232 cable, a 5V adaptor and a PS/2 cable.
Use a piece of dry and soft cloth when cleaning the scanner.
Parts of the scanner
①LED
②Exit window
③Trigger
④Cable interface port
⑤Release-hole of the cable
⑥Beeper
Installing the cable
1. Switch off the host;
2. Refer to the below pictures, connect the host with the scanner based on different cables;
3. Ensure that all connections are secure.
4. Switch on the host system. If installation is successful, the beeper will beep and LED will
light.
USB cable RS232 cable PS/2 cable
Removing the cable
1. Find the release-hole.
2. Insert a thin wire into the hole and pull out the cable gently.
Default value initialization and Firmware version list
Default value initialization Firmware version list
Programming instruction and example
Assembling the stand (accessory)
1. See the figure above, tighten the screws.
2. Bend the neck to the desired position for scanning.
Scan
“
SETUP
”
Scan
“
Option bar code
”
Scan
“
the
1
st c
h
aracter of option
”
Scan
“
the
2
nd character of option
”
Scan
“
END
”
Example: to set
Flow
control
to be XON/XOFF.

3. Screw mounting: Screw one #10 wood screw into each screw-mount-hole until the base of
the stand is secured.
4. Tape mounting: ①Peel the paper liner off one side of each piece of tape and place the sticky
surface over each of the three rectangular tape holders. ②Peel the paper liner off the
exposed sides of each piece of tape and press the stand on a flat surface until it is secure.
Note: 1. More details refer to User Manual；2. For better readability, please print this document with laser printer. 3. Version:
MD22xx_QG_EN_V1.5.
