Par T Golf Double Eagle Elite Plus 4 Manual

INSTALLATION
AND
MAINTENANCE
MANUAL
THE DOUBLE EAGLE
ELITE PLUS 4
&
EAGLE STROKE GOLF
OPTRONICS LTD.
365 Bugatti Ave.
Salt Lake City, Utah 84115
[e-mail] www.eaglestroke.com
[phone] Phone
[phone] Fax .

TABLE OF CONTENTS
WELCOME
Section A: THE DOUBLE EAGLE ELITE Page
Chapter 1 Preparing for Installation .............................................................................. A2
Chapter 2 Area, Electricity and Lighting ....................................................................... A3
Section B: THE PLATFORM
Chapter 3 Platform Construction .................................................................................... B2
Chapter 4 Putting Carpet Installation ............................................................................ B12
Section C: THE FRAME
Chapter 5 Frame, Canopy and Screen Assembly ........................................................... C2
Section D: THE ELECTRONICS
Chapter 6 The Par T Optisense™.................................................................................... D3
Chapter 7 The Control Console ....................................................................................... D6
Chapter 8 The Video Projector ...................................................................................... D10
Section E: ENJOYING YOUR MACHINE
Chapter 9 Marking the Putting Carpet …….........................................................…...... E2
Chapter 10 Aiming and Aligning the Cameras ...............................................….............. E3
Chapter 11 Playing Golf ................................................................................................... E8
Chapter 12 Other Key Features ..………………………................................................. .E11
Section F: APPENDICES
Chapter 13 Troubleshooting ............................................................................................. F2
Chapter 14 Maintenance ................................................................................................... F11
Glossary ..................................................................................................................................................... F12
Appendix i Limited Warranty ......................................................................................... F14
Appendix ii Alternative Golf Games ................................................................................ F15
Index ........................................................................................................................................................ F16

Welcome to the World of Indoor Golf
Welcome To Par TGolf®and
The Double Eagle,
"The Incredible Golf Machine"®
Welcome to Par T Golf, the world leader in realistic indoor golf simulation. With the incredible Double Eagle
you and your friends or customers now have the rare opportunity of playing a full 18–hole round of golf on your
choice of available world class golf courses, using all your own regulation clubs and golf balls.
Up to 10 golfers at a time may select from a variety of World-Class courses or use the Practice Mode to improve
individual skills.
An average golfer can play 18 holes of Stroke Play in just 45 minutes, making this a perfect alternative for the
busy executive, salesperson or any other golf enthusiast who is short on time.
USGA rules are followed, including penalties, for optimum realism and performance. The Par T Golf Simulator
offers the most fun and opportunity for both beginning and advanced golfers, without regard to season, outdoor
weather conditions or the time of day.
How the Double Eagle Operates
Your Double Eagle consists of several primary components which are integrated by electronic cables and
supported by an attractive framework. These components compose of:
1) The Platform: Fashioned from wood and covered by decorative putting carpet, it serves as the base for
the entire system. All construction and installation is outlined in Section B.
2) The Frame: The metal framework is essential for the structure and support of the screen, canopy, audio
speakers and sensing system. Its assembly is made easy by the modular design and is outlined in Section C.
3) The Electronics: The Projector, the Optisense™ and the Control Console are the heart of the Double
Eagle. These systems integrate to form a state-of-the-art indoor golf system. They project course images,
sense ball flight and analyze collected data. Key vocabulary, as well as, installation, operation and
maintenance information for each system is given in Section D.
When a golfer takes a shot, the golf ball flies through the overhead cameras’ field of vision, strikes a projected
golf course image on the screen and falls to the putting carpet. Cameras immediately transmit the ball’s flight
information to the control console, which calculates speed, spin, elevation and direction of the ball. A graphical
display of the ball is generated and sent through the projector on to the screen.
Finally, the view on screen changes to reflect the golfers new lie.
An incredible process that all happens in a few split seconds.

Welcome to the Par T Golf, Double Eagle Elite
Using This Manual
Use this guide now to set up and begin enjoying your Double Eagle . Use it later as a reference for day-to-day
set-up and as a guide for maintenance and troubleshooting.
Chapters 1 through 10 are your complete guide for all phases of installation, from constructing a platform to
aiming and aligning the cameras. These chapters include illustrations along with step by step instructions.
Chapters 11 through 14 detail how to operate, maintain and readjust your simulator. A glossary, an index and an
appendix follow Chapter 14.
Each section begins with introductory text, a table of contents, listing chapters and illustrations within the section
and a key vocabulary.
The manual uses a double column page format. “What” to do appears in a step by step approach in the left
column. Detailed explanations of “How to” carry out the steps appear in the right column. Refer to the right
column only if you need more information to complete that step.
Technical Support
If you run into problems installing or using your new Double Eagle, this manual is the best place to quickly find
help. Check Chapter 13 for troubleshooting tips and answers to frequently asked questions.
When you are unable to find an answer in this guide, call Optronics technical support during business hours (8
am to 4:30 pm MST) at [phone] or fax us at [phone].
INFORMATION in this document is subject to change without notice and does not represent a commitment on the part of
Optronics Limited (hereinafter "Optronics"). The equipment and firmware described in this document are furnished under a
license agreement or nondisclosure agreement. No part of this manual, equipment and/or firmware may be reproduced or
transmitted in any form or by any means, electronic or mechanical, including photocopying, recording, or information
storage and retrieval systems, for any purpose other than the purchaser's personal use, without the express written permission
of Optronics.
Copyright © 2006 Optronics Limited. All rights reserved. Printed in the United States of America.

PAR T GOLF DOUBLE EAGLE INSTALLATION AND MAINTENANCE MANUAL
SECTION A THE DOUBLE EAGLE ELITE
A1
THE DOUBLE EAGLE ELITE plus 4 SECTION A
General Information about the Double Eagle
If you are like most new owners, you are anxious to begin enjoying the many benefits of indoor golf. This
section is designed to help you become familiar with the many components and electrical requirements of the
machine.
CONTENTS Page Description of Drawings
Key Vocabulary............................................................................... A1
Chapter 1 Preparing for Installation ........................................ A2
Simulator Positioning ...................................................... A2
Drawing 1A................................................................. A2 The Double Eagle
Chapter 2 Area, Electricity and Lighting ................................ A3
Playing Area ................................................................... A3
Drawing 2A................................................................. A3 Double Eagle Dimensions
Power Requirements......................................................... A4
Location of Electrical Outlets........................................... A4
Drawing 2B................................................................. A5 Wiring Detail
Recommended Lighting.................................................... A5
KEY VOCABULARY
Control Console – The control console features a state-of-the-art Pentium® micro-processor,
CD-ROM drive, a touch sensitive track pad and a key board.
Par T Optisense™ _ A patented ball-flight tracking system. It is housed in a topless metal
enclosure, measuring 16" x 6" x 48" (406 x 152 x 1219 mm) and includes
three overhead cameras, three infrared lights and accompanying fans.
Video Projector – A high-resolution, LCD color video projector. It is suspended from the
ceiling with a specially designed ceiling mount, above and behind the
golfers.
Par T Tri-Turf™
"The Incredible Golfing Mat" – A unique, patented driving surface which closely resembles fairway, rough
and sand trap conditions. The assembly measures 24" x 48” x 1 ½” and
is recessed into the center of the platform.
Platform – The base for the Double Eagle, which is built on-site by each owner.
Putting Carpet –A specially constructed carpet, that is golf-spike resistant.
Dedicated Circuit – An electrical circuit, complete with breaker, used solely for the Double
Eagle . A 15 Amp dedicated circuit is recommended for each Double Eagle
.
Duplex Electrical Outlet Box – A standard, metal or plastic electrical box, with two receptacles or outlets.
Power Switches – Conveniently located switches, to control power to your Simulator. It is
used to turn power off for repairs or for extended hours of non-use.

PAR T GOLF DOUBLE EAGLE INSTALLATION AND MAINTENANCE MANUAL
A2 THE DOUBLE EAGLE ELITE SECTION A
Chapter 1 PREPARING FOR INSTALLATION
SIMULATOR POSITIONING
There are a few items that need to be addressed prior to constructing the platform, the laying of carpet or
assembling any components. One of the most important aspects of installation is machine location within the
facility. We recommend that the machine be placed in an area that is well ventilated and an area that has little or
no ambient light. The Double Eagle works best when there is low lighting conditions and plenty of room for the
golfers to swing. This allows for maximum enjoyment and worry free operation.
The maintenance and installation guide is an important factor in the operation of the Double Eagle. It is
comprised of important information about the system and includes several “tricks-of-the-trade” and tips for set-up
and long term maintenance. Prior to calling customer service, refer to this guide.
It is also important for owners and operators to be very familiar with the machine and all of its components with
their associated names and functions. Being familiar with the names of the components aids in discussing issues
related to operation and service. The following is a drawing that illustrates the locations and names of the items
of your system. Please refer to this often to familiarize yourself with these very important components.
Drawing 1A The Double Eagle

PAR T GOLF DOUBLE EAGLE INSTALLATION AND MAINTENANCE MANUAL
SECTION A THE DOUBLE EAGLE ELITE
A3
Chapter 2 AREA, ELECTRICITY AND LIGHTING REQUIREMENTS
PLAYING AREA
The minimum playing area for the Double Eagle is 14’ x 20’ x 10’ (4267 x 6096 x 3048 mm). It is
recommended, however, that the playing area be 15’ x 20’ x 10’ (4572 x 6096 x 3048 mm). Although the larger
playing area is not required, it aids in the maintenance and set-up of the simulator.
1. Playing Area –The standard platform size is 14' X 20' X 3” (4267 x 6807 x 76 mm)
Allow one foot of space on left side
of platform (Optional) –One foot of space on the left side of the platform is recommended to
expand the golfer’s swinging area and for equipment servicing.
Allow one foot of space in back of
platform. (Optional) –A minimum distance of one foot, for working space is recommended
between the platform's screen-end and the back wall.
A ten foot seating area enhances
play (Optional) –If desired, a pleasant sofa corner or snack bar, can be added in front of
the platform to provide a place to rest between shots.
2. Playing area ceiling height (10’) –The ceiling above the platform should be 10’. A typical golfer’s swing
reaches heights of nearly 9’ 6” when standing on the 3 inch platform.
Drawing 2A Double Eagle Dimensions

PAR T GOLF DOUBLE EAGLE INSTALLATION AND MAINTENANCE MANUAL
THE DOUBLE EAGLE ELITE SECTION A
A4
ELECTRICAL POWER REQUIREMENTS
Each Double Eagle should receive power from a dedicated 15-ampere circuit, 110 volt circuit (220V where
applicable) to operate properly and safely. Power should be delivered from the circuit breaker to the outlet boxes
using grounded, No. 12-2 or No. 10-2 Romex™ wire. A transformer is recommended in areas with higher
voltage, or where a dependable power source is not available.
CAUTION: ALL ELECTRICAL LINES SHOULD BE INSTALLED BY A LICENSED ELECTRICIAN.
1. A dedicated 15-ampere circuit, with
105 to 125 volts, RMS 60 Hz AC
(220V, 50Hz where applicable).
–The Double Eagle is designed to operate in a range of 105 to 125 volts
(220V where applicable) of consistent power. One dedicated 15-ampere
circuit should be available to sustain the simulator's peak draw.
2. Use No. 12-2 or No. 10-2 grounded
Romex™ wire. –Always follow local electrical codes, however, No. 12-2 or No. 10-2
size, grounded, Romex™ wire should be used between the circuit
breaker and the electrical boxes.
3. Use a transformer, where voltage is
higher, or power is not stable. –If a dependable power source is not available, a constant-voltage
harmonic-neutralized transformer must be used to power the entire
system. Though not required where a stable source of power exists,
such a transformer, supplying a constant 110 volts (220 V where
applicable) of power will greatly extend the life of lamps in the unit.
4. Component Wattage –Control Console 0.5 Amp ( 50W @120V)
Optisense™ 10.4 Amp (1,250W @120V)
Video Projector 2.0 Amp ( 250 W @120V)
TOTAL 12.9 Amp (1550 W @120V)
LOCATION OF ELECTRICAL SWITCHES AND OUTLETS
IMPORTANT: Place a power switch near the control console. This switch will be used daily as you
start and stop play on the simulator. It is recommended that power to the Optisense and to the control
console be controlled by this switch. Also install a separate switch for the projector (the location is at
your discretion). Always shut the projector off according to the procedure outlined in the projector’s
manual. Failure to do so will result in premature failure of the lamp assembly.
During the platform construction phase of the installation, three electrical outlet boxes and power switches should
be installed by your electrician as indicated in Drawing 2B. Also see Drawing 2B Wiring Detail in this section
for recommendations on the location of the power switches and the outlet boxes.

PAR T GOLF DOUBLE EAGLE INSTALLATION AND MAINTENANCE MANUAL
SECTION B THE PLATFORM
B1
THE PLATFORM SECTION B
Locating, Framing, Wiring and Carpeting
The platform construction is the most time consuming step toward installing your new simulator. It serves as the
base for the entire system. Read the platform construction plans carefully.
The platform should be constructed prior to receiving the actual equipment.
CONTENTS Page Description of Drawings
Key Vocabulary............................................................................... B1
Chapter 3 Platform Construction ............................................. B2
Framing the Platform (Bill of Materials).......................... B2
Installing Electrical Connections and Cables ................... B3
Attaching the Plywood to the Platform............................. B3
Cutting out the Ball Cup Hole ................ B3
Framing the Courtesy Walls (Optional)............................ B4
Figures 1 — 6 ............................................................. B5 Platform Construction Drawings.
Chapter 4 Putting Carpet Installation ........................................ B12
Placing the Tri-Turf ........................................................ B13
KEY VOCABULARY
Dedicated Circuit – An electrical circuit, complete with breaker, used solely for the Double
Eagle. A 15 Amp dedicated circuit is recommended for each Double Eagle.
Duplex Electrical Outlet Box – A standard, metal or plastic electrical box, with two receptacles or outlets.
Power Switches – Conveniently located switches, that control power to your Simulator. They
are used to turn power of to simulator electronics.
Par T Tri-Turf™
"The Incredible Golfing Mat" – A unique, patented driving surface which closely resembles fairway, rough
and sand trap conditions. The assembly measures 24" X 48” and is
recessed into the center of the platform (Figure 6)
Platform – The base for the Double Eagle, which is built on-site by each owner.
Putting Carpet –A specially constructed carpet, that works with our cameras.

PAR T GOLF DOUBLE EAGLE INSTALLATION AND MAINTENANCE MANUAL
B2 THE PLATFORM SECTION B
Chapter 3PLATFORM CONSTRUCTION
FRAMING THE PLATFORM
In this chapter, the procedure for constructing the platform is outlined. Generally, this phase is most easily
accomplished by first acquiring all necessary materials as outlined in the Bill of Materials, then cutting all of the
lumber, and finally, assembling the pieces in the order outlined below.
STEP 1 Necessary materials –A complete Bill of Material is found below.
Figure 1 –Carefully study Figure 1. Figure 1 outlines each item with its correct
placement. Figure 2 displays an orthographic view of the framed
platform.
BILL OF MATERIALS* — PLATFORM
* All platform members are 2" X 4" (1 1/2" X 3 1/2") [51 x 102mm (38 x 89mm)]
ITEM NO QTY LENGTH / DESCRIPTION
1 1 168” [4267 mm]
2 4 65” [1651 mm]
3 2 68 1/2” [1740 mm]
4 6 161” [4089 mm]
5 4 79 3/4” [2026 mm] LAY ALL 2 x 4s FLAT ON THE FLOOR
6 4 96” [2438 mm]
8 17 20 1/2” [521 mm]
9 5 18 3/4” [476 mm]
10 2 24 1/4” [616 mm]
11 2 44 1/2” [1130 mm]
10 10 48” x 96” x 3/4" (1219 x 2348 x 19 mm) PLYWOOD SHEETS
STEP 2 Cut lumber for the
platform –Cut Items #1 through #10, as described in Figure 1 and bill of materials.
STEP 3Assemble platform using
1" X 4" metal mending
plates (Optional)
–Assemble items #1 through #10 according to the plan specifications. It is
recommended that the platform members be connected using 1" by 4"
metal mending plates (not provided) or by “toe-nailing” members
together. Place notched side DOWN where applicable.
STEP 4Connect platform to floor
(Optional) –Using nails, screws or glue, you may want to connect your platform to
the floor to avoid future squeaking and movement.

PAR T GOLF DOUBLE EAGLE INSTALLATION AND MAINTENANCE MANUAL
SECTION B THE PLATFORM
B1
INSTALLING ELECTRICAL CONNECTIONS AND CABLES
IMPORTANT: ALL ELECTRICAL LINES SHOULD BE INSTALLED BY AN ELECTRICIAN.
STEP 5 Install power switches –Near the control console, place power switches that effect power to the
Optisense, control console and projector. The projector should be placed
on a separate power switch. (Note: Do not turn projector off without
letting the lamp cool. Refer to projector manual for proper on/off
procedure).
STEP6 Install box # 1 for control
console –Locate AC duplex box #1 near the front right-hand corner of the platform,
as shown in Figure 3
STEP 7 Install box # 2 for overhead
Optisense
Drawing 2B
–Electrical box #2 should be mounted in the ceiling if possible. It should
be located in the center of the platform (left to right) and 10’ 7” (3226
mm) from the screen end of the platform. This will be directly above the
overhead Optisense™ when installed.
STEP 8 Install box # 3 for the video
projector –Electrical box #3 should be mounted in the ceiling if possible. It should
be located in the center of the platform (left to right) and 19’ (5791 mm)
from the screen end of the platform. This will be directly above the video
projector when installed.
ATTACHING THE PLYWOOD
STEP 10 Attach plywood to the platform –For best results, start at the screen end of the platform, and use
wood screws and construction adhesive.
Figure 3 & 4 –IMPORTANT! Keep the plywood pieces removed for the
Tri Turf cut-out, they are used in step 12.
CUTTING OUT THE BALL CUP HOLE
STEP 11 Size and location of ball cup
hole –The ball cup hole is 4 ¼” (108 mm) in diameter.
Figure 3 –The ball cup hole is located in the center of the platform, left to
right (it is important that the cup be exactly in the center), and
approximately 36” (914 mm) from the screen-end of the
plywood (exact distance from end of plywood is not as critical).
_

PAR T GOLF DOUBLE EAGLE INSTALLATION AND MAINTENANCE MANUAL
SECTION B THE PLATFORM
B12
Chapter 4PUTTING CARPET INSTALLATION
In this chapter we outline the manufacturer's recommended procedures for attaching the putting carpet to your
newly constructed platform. It is recommended that a skilled carpet layer install the putting carpet.
THE CARPET SHOULD BE IN PLACE PRIOR TO ERECTING THE FRAME OR INSTALLING ANY
OF THE ELECTRONIC COMPONENTS.
CARPET INSTALLATION PROCEDURE
It is recommended that a skilled carpet layer install the putting carpet.
Ideal temperature for installation is from 55º F to 95º F with relative humidity between 10% and 65%.
Putting carpet should be installed with seams as shown in Figure 6.
STEP 1 Clean the platform –The plywood surface must be thoroughly cleaned which should include
sweeping and vacuuming, to insure that it is completely free of all dirt,
paint, grease, oils or contaminants which will prevent good adhesion.
STEP 2 Place and unroll carpet –Unroll the carpet, beginning at the screen-end of the putting platform.
Allow unrolled carpet one
hour to relax –The carpet should be allowed to lay unrolled and to relax, for at least one
hour before installation.
STEP 3 Cut and splice turf to fit
platform –The turf should be installed with the seams on the right side of the
platform facing the screen.
Figure 6
STEP 4
Apply Adhesive to half of
platform –You should need approximately 5 gallons of a standard carpet adhesive
to attach putting carpet to the platform.
–Using a 1/8” x 1/8” (3 x 3 mm) V-notched trowel, spread the adhesive to
one-half of the platform.
REMINDER: The adhesive should be non-flammable and compatible with carpet backing.
STEP 5 Use contact method for
carpet lay-in –Contact method of lay-in suggests that the turf is: (i) laid directly into the
wet adhesive immediately after the adhesive has been applied; (ii) then
flattened out using any flat object such as an industrial broom; (iii) then
pulled back out of the adhesive bed and allowed to air dry with both
adhesive surfaces exposed to the air for at least 5 minutes; and finally
(iv) re-laid onto the tacky adhesive.

PAR T GOLF DOUBLE EAGLE INSTALLATION AND MAINTENANCE MANUAL
B13 SECTION B THE PLATFORM
Attach carpet to half of the
platform –This method is used to assure that the carpet backing surface is covered
completely with at least fifty percent of the applied adhesive, resulting in
fewer installation bubbles or problems due to the adhesive. Bond
strength between carpet, adhesive and platform develops much faster
using the contact method.
STEP 6 Repeat steps 4 and 5 for
the other half of platform. –Follow the procedure outlined in Steps 4 and 5 above to lay the turf on
the remaining portion of the platform.
STEP 7 Roll the carpet –Once the carpet has been properly joined to the platform, the entire area
should be rolled using a 35 pound roller. Roll carpet in both E-W and
N-S directions to assure proper bond.
PLACING THE PAR T TRI-TURF™
STEP 8 Set Tri-Turf into place
Figure 6
–
_
Locate the plywood pieces removed for the Tri-Turf cut out and
place them in the hole, on the floor.
Set the Tri-Turf into place, on top of plywood scraps (above).
NOTE: In the event a bubble should develop, DO NOT cut or slit open the raised area. Most bubbles are
caused from solvents left in the adhesive and trapped under the turf during lay-in. The best way to remove
them is to puncture the bubble with an awl, ice pick or hypodermic syringe and press the trapped solvent
gas vapors out by pressing and squeezing the area with both hands. Allow the turf to lay back into the
adhesive and either sand bag or re-roll the area to develop maximum bond strength.
If for some reason the bubble does not re-bond adequately, the hypodermic syringe can be used with a
small quantity of seam sealer to re-bond the turf to the platform. After the sealer has been injected into
the bubble, spread the sealer by hand rubbing and then allow it to air dry for 5 to 10 minutes before
rolling.
