Paradigm SOUNDTRACK 2 SYSTEM User manual

Remote ControlWhat’s in the box . . .
Soundbar power
cord (2 pieces)
Soundbar
Removable grille
Soundbar feet
‘AAA’ batteries for remote
Mute
Volume Down
Volume Up
Play/Pause
Next TrackPrevious Track
Enable
Bluetooth
Source
Power On/O
Soundbar on-wall brackets
Subwoofer feet and screws
Subwoofer
with cradle
(Adaptor for use when sub
is in horizontal position,
wired connection only)
#2 Phillips (not supplied)
Remote
110413
Set-Up Guide
The Ocial Sound of YOU™
Subwoofer
power cord
Optical cable
(digital)
A
Dual RCA cable
(analog)
B
C
D
Your Soundtrack 2 System is capable of
learning codes from remote controls you are
using for other sources. See manual for details. ATTENTION: remove
protective end caps
Music Mode*
* Sonic enhancements
to listening experience
according to mode
Movie Mode*
Greyed out buttons do
not apply to this model
FUNCTION AND OPERATION
System OFF: Press POWER
System ON: Press POWER
Auxiliary 3.5 mm Stereo Source:
Press SOURCE once
Analog RCA Source: Press SOURCE a second time
Digital Optical Source: Press SOURCE a third time
Bluetooth Wireless Connection: Press SOURCE
a fourth time (see Bluetooth connection for details)
Wireless Soundbar / Subwoofer Connection: Press SYNC.
LED ashes and stops ashing once there is a connection
Volume Up/Down: Press UP ARROW or DOWN ARROW
Max Volume: When volume is set to maximum level
the LED brightness increases and ashes rapidly
Min Volume: When volume is set to minimum level
the LED brightness increases and ashes rapidly
LED
Bluetooth Connection
1. FIRST TIME CONNECTION: To connect a phone/tablet that HAS NEVER
been connected to the Soundtrack 2, press the Enable Bluetooth
button on your remote or press the Source button (multiple times if
necessary) on the top-panel of the soundbar until the soundbar LED
rapidly ashes RED then BLUE ( ). The connection
process will take approximately 1 minute. See Step 2.
PREVIOUSLY CONNECTED: If your phone/tablet HAS previously
been connected to Soundtrack 2, the LED will ash RED then
BLUE ONCE ( ). Select Bluetooth as your playback
option and skip step 2.
2. While the LED on the soundbar alternates between RED and BLUE
(), enable Bluetooth on your phone/tablet and search for
“Soundtrack 2” on your Bluetooth device list. Select “Soundtrack 2” to
establish a connection. Once a connection is established, the LED
illuminates Solid Blue ( ). Depending on phone/tablet you may
need to change the playback device to “Soundtrack 2” or it may
change automatically.
x1
x2
x1 x1
x3
-
+
-
+
rapid
rapid
rapid
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks
of Dolby Laboratories.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and
any use of such marks by Paradigm Electronics Inc. is under license.
The “aptX® software is copyright CSR plc or its group companies. All rights reserved. The aptX®
mark and the aptX logo are trade marks of CSR plc or one of its group companies and may be
registered in one or more jurisdictions.”
For more information visit paradigm.com/shift
™
MODE
Functions and LED Indication
MODE
EN_Soundtrack_2_Set-Up_Guide.indd 1 13-11-04 5:18 PM

Choose subwoofer orientation Setting up the soundbar
Wireless subwoofer pairing
1
1
2
OR
5 76 8
+
BASS
–
BASS
MODE
ATTENTION: From the moment you
press the soundbar’s ‘Sync’ button
you have 30 seconds to connect the
subwoofer to the wall outlet.
DO NOT connect subwoofer
to wall outlet until step 7.
When subwoofer is in horizontal
position feet must be attached
for heat dissipation.
ATTENTION: If the soundbar’s
LED ashes red and blue,
pairing has failed. Repeat
the Subwoofer Pairing process.
Wireless setting Syncing Adjust subwoofer loudnessPower connection
WARNING! THE SET-UP AND SYNCING STEPS MUST BE DONE IN THE FOLLOWING ORDER. DO NOT PLUG IN SUBWOOFER UNTIL STEP 7.
OPTIONAL: For wall mounting instructions, refer to Owners Manual.
Attaching soundbar feet
Vertical
Horizontal
Lay your soundbar face down on a soft
surface. Insert feet as shown, press rmly
until you hear a 'click'.
Connect subwoofer to wall outlet.
Press the Sync button to initiate pairing with
subwoofer. The LED on the soundbar should
ash blue ( ) for 30 seconds. Once a connection
is established the LED switches to solid blue ( ).
Your subwoofer’s LEVEL knob is set to 12 o’clock to
suit average preferences. If desired, adjust up or
down to match sound level of your speakers.
Move switch to ‘wireless’ setting
on subwoofer.
D
2Power connection
Connect soundbar to wall outlet.
A
3
NOTE: Choose analog
OR digital connections
3.5-mm to mobile
audio device
(not included)
If desired, establish Bluetooth connection at this point (see rear for details)
Connecting to source Analog connection to
TV (use for good audio)
Digital connection to TV
(use for best audio)
B
C
TV
CB
4Power on, then initiate audio
Using the Remote or Top Panel Controls, turn Power
ON. Then repeatedly press the Source button until
you hear audio from your device (TV, iPhone, etc).
#2 Phillips (not supplied)
Wireless
Sync
SourcePower Volume
Down
Volume
Up
Top Panel Controls
Wireless Range
or 15 Meters
50’
