Paragon 103 User manual

POWER
SANITIZE
POWER
P
SANITIZ
SANITIZ
E
103 Facial
Vaporizer
Read this manual before assembling or using the
product. Keep the manual for future reference.
Owner’s Manual

1
General
• Touching the glass jar when it is hot may cause severe burns. Do not attempt to remove or
insert the glass jar when it is hot, during use, or immediately after use.
• Hot water spouting may cause severe burns. To prevent water from spouting, always
maintain the distilled water level at the proper level between the top and bottom red lines.
Beforeturningonthesteamer,llthewaterjartothetopredline.Donotoverllabovetop
red line.
• Breaking or shattering glass may cause serious injury. Always wait for water and jar to cool
before adding more water.
• To extend the lifecycle of the heating element and to prevent the glass jar from cracking, do
not add cold water while water is hot.
• Quick stops, excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn and cause serious injury to a person and damage the unit. Do not
place this unit on an unstable stand, tripod, bracket, or mount. Use only with a stand,
tripod, bracket, or mount recommended by the manufacturer or sold with the product. Any
mounting of the unit should follow the manufacturer’s instructions and should use a
mounting accessory recommended by the manufacturer. An appliance and cart
combination should be moved with care.
WARNING!
Operators of this unit must read, understand, and follow all the safety and operating instructions
before using the unit. Ensure that the employees receive proper training before allowing them to
operate the unit. Retain this manual for future reference.
Contents
Safety
Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Assembly ................................... 4
Use ......................................... 5
Maintenance ................................ 7
Troubleshooting ............................. 8
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

2
Fire and Electric Shock
Thefollowingwarningsmayresultinreorelectricshockandcauseseriousinjury.
• This unit should be operated only from the type of power source indicated on the marking
label. If you are not sure of the type of power supply you plan to use, consult your
appliance dealer or local power company. For units intended to operate from battery power
or other sources, refer to the operating instructions.
• This unit may be equipped with a polarized alternating-current line plug (a plug having one
bladewiderthantheother).Thisplugwilltintothepoweroutletonlyoneway.Thisisa
safety feature. If you are unable to insert the plug fully into the outlet, try reversing the plug.
Iftheplugshouldstillfailtot,contactyourelectriciantoreplaceyourobsoleteoutlet.Do
not defeat the safety purpose of the polarized plug. Alternately, this unit may be equipped
with a 3-wire grounding-type plug, a plug having a third (grounding) pin. This plug will only
tintoagrounding-typepoweroutlet.Thisisasafetyfeature.Ifyouareunabletoinsert
the plug into the outlet, contact your electrician to replace your obsolete outlet. Do not
defeat the safety purpose of the grounding-type plug.
• Power supply cords should be routed so that they are not likely to be walked on or pinched
by items placed upon or against them, paying particular attention to cords and plugs,
convenience overhead power lines or other electric light or power circuits or where it can
fall into such power lines or circuits.
• Never push objects of any kind into this unit through openings, as they may touch
dangerousvoltagepointsorshortoutpartsthatcouldresultinareorelectricshock.
Never spill liquid of any kind on the unit.
• Donotoverloadoutletsandextensioncordsasthiscanresultinariskofreorelectric
shock.
• Always unplug the unit from the outlet before cleaning.
• Do not attempt to service this unit yourself as opening or removing covers may expose you
to dangerous voltage or other hazards. If service is required, unplug the unit from the outlet
andreferservicingtoqualiedservicepersonnel.Conditions requiring service may
include:
◦When the power supply cord or plug is damaged.
◦If liquid has been spilled or objects have fallen into the unit.
◦If the unit has been exposed to rain or water.
◦If the unit does not operate normally by following the operating instructions. Adjust only
those controls that are covered by the operating instructions, as an improper
adjustment of other controls may result in damage and will often require extensive work
 byaqualiedtechniciantorestoretheunittoitsnormaloperation.
◦If the unit has been dropped or the cabinet has been damaged.
◦When the unit exhibits a distinct change in performance--this indicates a need for
service.
• When replacement parts are required, be sure the service technician has used
replacementpartsspeciedbythemanufacturerorhavethesamecharacteristicsasthe
originalpart.Unauthorizedsubstitutionsmayresultinre,electricshock,orotherhazards.

3
NOTICE
• Do not run chemicals through the appliance such as cleaning agents or aroma additives.
These clog the water ways and leave deposits. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
• To avoid steamer burnout do not test run the appliance dry.
• Do not use attachments not recommended by the product manufacturer as they may cause
hazards.
• Require users to inspect equipment and test critical safety features before each day of use. If
equipment is in need of repair, please send the unit in for inspection and repair. Prior to
sending the unit in, please call in for a RA (Return Authorization) number. Upon completion of
any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is safe to operate.
• Openings are provided for ventilation, to ensure reliable operation of the unit, and to protect it
from overheating. These openings must not be blocked or covered. This unit should not be
placed in a built-in installation unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to.
• For added protection of this unit during a lightning storm, or when it is left unattended and
unused for long periods of time, unplug it from the wall outlet and disconnect the cable
system. This will prevent damage to the unit due to lightning and power line surges.

4
1
Steam Outlet
Ozone
ON/OFF
Steam Arm
Max Water Level
Min Water Level
Steam
ON/OFF
Water Cup
2
Burn Guard
3
4
Unpacking
• Unpack carefully. There are glass parts.
• Besuretoremoveallfoampackingller
before applying power to the unit.
1. Insert the steam arm into the slot
located on top of the dome portion of
the unit.
2. With the Burn Guard doors open, insert
the water cup into the unit with the unit.
Note: The heating unit should be
located inside of the water cup.
3. When properly installed, the water cup
handle should centered between the
burn guards.
4. Push both of the burn guards into the
closed position.
Assembly

5
Use
1
7
2
1. Placethefacialsteamerontoaat
stable surface.
2. Open the plastic lid and remove the
water plug.
3. Pour distilled water into the water cup
until it reaches the maximum water level
line. IMPORTANT! To prevent water
spoutingdonotoverllthewatercup.
4. Reinsert the water plug and close the
plastic lid.
5. Insert the facial vaporizer plug into a
power source.
6. Change the steam ON/OFF switch to the
ON position. The switch will light up when
the facial vaporizer is powered, and the
Steam switch is in the ON position.
7. Cover the client’s upper chest area with
towel or cloth to absorb excess moisture.
8. Allow 10 minutes for steam to appear.
Thesteamshouldbeasteadynemist
before directing the steam towards the
client.
9. Adjust the steam nozzle to the desired
direction, keeping a minimum distance of
12 inches from face.
10.Position the steam arm in an upward
direction so the steam will travel up the
torso towards the face.
3
12”
6
9
Plastic Lid

6
Aroma Therapy
To use the aroma therapy strips, place a few
drops of aroma onto the strip. Do not soak the
strip. Place the aroma strip into the Aroma Insert
Space and slide the cover to close. This design
allowstheclienttoexperiencethebenetsof
aromatic oils while simultaneously protecting the
appliance from clogging and spouting.
Ozone
Ozone is a form of oxygen sometimes used
as a form of disinfectant. The ozone function
in the facial steamer is an option. Check with
applicable regulatory agencies such as the
Department of Health and the Cosmetology
State Board concerning the use of ozone in
your area. To activate the ozone function, use
the on/off switch located next to the timer knob.
When ozone is in use, the green activate lamp
will light up.
Auto-Off Tipping Switch
Thisunitmustbeoperatedonaat,hard,and
stable surface. DO NOT SET UNIT ON A SOFT
SURFACE. The auto-off tipping switch must be
engaged for proper operation. In the event that
this vaporizer is tipped over the auto-off tipping
switch will release and shut the unit down as a
safety precaution.
Ozone
ON/OFF
Aroma Insert Space
Auto-Off
Tipping
Switch

7
Maintenance
Safety
• Perform a safety check before the start of each day’s use. If the unit is unsafe or needs repair, call
the manufacturer for information on sending the unit in for service.
The Water Jar
• Only use distilled water. The use of tap water will eventually cause malfunction of the machine due
to calcium build-up
• Do not use essential oils in the water jar.
• Always maintain the proper water levels. The distilled water should always remain between the two
red lines.
• Improper water levels may cause the vaporizer to spit.
• Do not add cold water to a hot water jar. This will stress and crack the jar.
• Check for steam pipe obstruction/mineral build-up and alignment.
• If the water level is below the red line the water level sensor safety fuse may burn out.
The Steam Arm
• Always maintain a minimum safe distance of 12” from the client’s skin.
• Position the steam arm in an upward direction so the steam will travel up the torso towards the face.
• Waituntilthesteamisatasteadyowbeforedirectingtowardstheclient.
Cleaning
• Maintain a clean heating element. Use a soft brush to clean the heating element.
• Empty the water jar at the end of each day’s use.
• Do not run harsh chemicals or cleaning agents through the machine.
• Only use essential oils on the aroma therapy nozzle (if available).
Troubleshooting
Problem Solution
Basic issues:
When the
machine fails to
work properly
• Check the power cord for proper connection.
• Make sure the water level is between the top and bottom red lines.
• Check the power source by connecting another electrical appliance to the AC
outlet.
• If the water level is repeatedly below the lower red line, the thermostat may
burn out. If the thermostat has burned out, the power lamp will not light and
the vaporizer will not turn on. Please contact an authorized agent for repair.
• If the problem persists, please contact your dealer for assistance.
• To prevent an electrical shock, DO NOT DISASSEMBLE THE MACHINE.
Steam escaping
from jar
Wait until the jar has cooled, then try to tighten the retaining screw located
beneath the jar for a tight seal. Check that the gasket ring is atop the water jar
and in good condition.

8
ONE YEAR LIMITED WARRANTY
WARRANTY COVERAGE
Gareld’swarrantyobligationsforthisproductarelimitedtothetermssetforthbelow:
Thiswarrantyextendstoyouonlyifyouaretherstend-userpurchaser.GareldIntl.Co.,Inc.
warrants this product against defects in material or workmanship for a period of one (1) year
from the date of original purchase and is valid in the United States of America, not including
shipping.
IfadefectarisesandavalidclaimisreceivedbyGareldwithintheWarrantyPeriod,atits
option,Gareldwill(A)repairtheproductatnocharge,usingneworrefurbishedreplacement
parts, (B) exchange the product with a product that is new or which has been manufactured
from new or serviceable used parts and is at least functionally equivalent to the original product.
EXCLUSIONS & LIMITATIONS
This warranty does not apply:
(A) To regular cleanings; (B) To glass jars/parts, hoses, neckrests, rubber parts, accessories,
attachments, bulbs, fuses; parts otherwise deemed by the manufacturer as “wear-and-tear”
items; detachable parts and/or accessories; (C) To damage caused by accident, abuse, misuse,
misapplication,ornon-Gareldproducts;(D)Todamagecausedbyserviceperformedby
anyoneotherthanauthorizedGareldtechnicians;(E)Toaproductorapartthathasbeen
modiedwithoutthewrittenpermissionofGareld;(F)IfanyGareldserialnumberhasbeen
removed or defaced
OBTAINING WARRANTY SERVICE
Before seeking warranty service, please review the instructions manual.
This warranty does not include shipping costs. In order to obtain warranty service, the product
must be delivered to and picked up from the manufacturer at the user’s expense. Before you
deliver your product for warranty service it is your responsibility to (A) provide a serial number
and obtain a return authorization number, and (B) securely pack the items/units. Items damaged
during shipping for repair will not be covered by this warranty.
Warranty

GareldIntl.Co.,Inc.
15977 Heron Avenue
La Mirada, Ca 90638
Call:1•888•731•6688
email:www.gareld.com
Paragon®isaTrademarkofGareldInternational.
