Parallax QTI Sensor KickStart (#555-27401)
What It Can Do
•Detects differences between light and dark objects
•Proximity detection to judge relative distance to an object
•Works as an analog sensor, but can be connected to a digital I/O pin
The QTI Sensor uses an infrared light emitting diode and infrared phototransistor to provide
simple but effective non-contact detection of patterns and objects. In either case, light emitted by
the LED bounces off a surface or object, and is detected by the phototransistor.
For pattern detection, the sensor can differentiate between light and dark surfaces, such as a
black line drawn on a piece of white paper (useful as a robot line follower).
For object detection, the sensor can judge whether it’s close to an object by how much infrared
light is reflected from it (useful as a tabletop edge detector).

Copyright © Parallax Inc. Page 2 of 6
QTI stands for Charge Transfer Infrared, an acronym describing how the sensor uses the
charge/discharge time of a capacitor to provide a scaled output, without requiring any additional
analog-to-digital circuitry.
In a working circuit, your microcontroller measures the time it takes for the QTI's capacitor to
decay. This decay time is a measurement of the rate of charge transfer through the infrared
phototransistor, and indicates how much infrared light is reflecting off a nearby surface.
Parts List
•QTI Sensor
•BASIC Stamp HomeWork Board, Propeller BOE, Propeller QuickStart, or Arduino Uno
microcontroller (solderless breadboard as needed)
•22 gauge solid conductor hookup wire
Basic Wiring
•Power requirements: 3.3 to 5 VDC
•Communication: Analog output of capacitor decay time depending on level of infrared
reflectivity
•Dimensions: 1.25 x 0.37 in (31.7 x 9.4 mm)
Important! The labeling on the QTI Sensor refers to the colors of a 3-wire servo extension wire:
Black, Red, and White. The QTI does not follow the typical arrangement of 3-wire connections
where the center (red) wire is power. Be sure not to reverse the +V and Gnd wires!

Copyright © Parallax Inc. Page 3 of 6
Program KickStarts
Each of the example programs displays current value from the QTI sensor as a number.
•The lower the number, the lighter the surface. Or for object detection, the closer the sensor is to
the object.
•The higher the number, the darker the surface. Or for object detection, the farther the sensor is
to the object.
The range of values depends on the microcontroller (due to how the microcontroller measures
the capacitor transfer decay time), but is typically about 30 to 2000. The range will also depend
on the reflectivity of the object.
Some objects, like the black antistatic foam used to protect electronic circuit boards, reflect little
or no infrared light, and the QTI cannot reliably detect these.
BASIC Stamp HomeWork Board

Copyright © Parallax Inc. Page 4 of 6
' {$STAMP BS2}
' {$PBASIC 2.5}
SnsrIn CON 9 ' Line sensor input (R)
Duration VAR Word ' Holds duration value
Read_Sensor:
HIGH SnsrIn ' Discharge QTI cap
PAUSE 1 ' Wait 1 ms
RCTIME SnsrIn, 1, Duration ' Read sensor value
Display: ' Display value
DEBUG HOME
DEBUG "-----", CR
DEBUG DEC Duration, CLREOL
PAUSE 250 ' Wait 250 ms, repeat
GOTO Read_Sensor
Note: When this program is run, the BASIC Stamp Debug Terminal will automatically open.
Note: Depending on surface reflectivity, values will range from about 60 to 3400.
Propeller BOE and Propeller QuickStart
Propeller BOE Wiring Diagram
Propeller QuickStart Wiring Diagram
OBJ
debug : "FullDuplexSerial"
rc : "RCTime"
CON

Copyright © Parallax Inc. Page 5 of 6
_clkmode = xtal1 + pll16x
_xinfreq = 5_000_000
VAR
long RCValue
PUB Go
debug.start(31, 30, 0, 115200)
RCValue := 0
repeat
rc.rctime(0, 1, @RCValue) ' Get RC value on 0
debug.dec(RCValue / 100) ' Display results
debug.tx(13)
WaitCnt(ClkFreq / 4 + Cnt) ' Delay 250ms, repeat
Note: This program uses the FullDuplexSerial object library, which is included with the
Propeller Tool software download. To view the results of the demonstration, after uploading is
complete run the Parallax Serial Terminal from the Run menu, or press F12. Momentarily
depress the Reset button on the Propeller QuickStart board to restart the program. Depending on
surface reflectivity, values will range from about 3 to 2000.
Arduino Uno
void setup() {
Serial.begin(9600);
}
void loop() {
Serial.println(RCTime(2)); // Connect to pin 2, display results
delay(250); // Wait 250 ms

Copyright © Parallax Inc. Page 6 of 6
}
long RCTime(int sensorIn){
long duration = 0;
pinMode(sensorIn, OUTPUT); // Make pin OUTPUT
digitalWrite(sensorIn, HIGH); // Pin HIGH (discharge capacitor)
delay(1); // Wait 1ms
pinMode(sensorIn, INPUT); // Make pin INPUT
digitalWrite(sensorIn, LOW); // Turn off internal pullups
while(digitalRead(sensorIn)){ // Wait for pin to go LOW
duration++;
}
return duration;
}
Note: To view the results of the demonstration, after uploading is complete click the Serial
Monitor icon in the Arduino IDE. This displays the Serial Monitor window. Momentarily
depress the Reset button on the Arduino board to restart the sketch.
Note: Depending on surface reflectivity, values will range from about 40 to 1300.
For More Information
•Visit the full documentation for the QTI Sensor (#555-27401), available from its product page.
•The QTI Line Follower AppKit (#28108) contains four QTI sensors, plus mounting hardware to
attach to the BOE-Bot robot chassis, and is specifically designed to provide line following
capability.
•The Infrared Line Follower Kit (#28304) is a single module with eight integrated infrared sensors,
and is also designed to provide line following capability to the BOE-Bot robot chassis.
