Parmco Ppov-9s-48 User manual

Installation

and Operating

Instructions

As part of Parmco Appliances commitment to improving and updang product ranges,

we reserve the right to alter, change and update technical specicaons and appearance

aributes of all Parmco Appliances products. E&OE.

Model:

PPOV-9S-48

Fix your serial number sticker here for easy reference.

You will need this serial number should your appliance require servicing.

Dear Valued Customer,

Thank you and congratulations on purchasing your new Parmco appliance.

All Parmco products are made to the highest quality and design standards. We are

sure you will enjoy your new appliance.

As a note, please read through these instructions carefully, as these will assist you

in gaining a complete understanding of the functions and features oered by your

appliance.

Please take special note of all detailed technical information and installation

instructions. It is essential that you only allow a qualied technician to install this

appliance to ensure the safety and reliability of this appliance.

Furthermore, not using appropiate personnel to install this appliance may aect any

future warranty claims lodged, so please check with Parmco Appliances before any

installation is carried out.

We hope you enjoy your new appliance. If you would like to nd out more about

this product or any other products in Parmco’s extensive range, visit us on the web

at www.parmco.co.nz.

Regards,

The Parmco Team

PAGE

Important Safety Information 4

Use and Care 5

Product Description 6

Operating Instructions 7

Oven Functions 11

Practical advice 13

Cooking guide 14

Maintenance 15

Installation Instructions 18

Technical data 20

IMPORTANT NOTE

It is the law in New Zealand that this appliance must be installed by authorised

persons. The installation must comply with all the appropriate New Zealand

Standards and Regulatory Requirements with particular reference to the New

Zealand Electrical Standards.

Any attempt to install this or any other Parmco product without an authorised

person could result in damage to the product and a possible health hazard. Not

having an authorised person install this appliance may result in all associated

warranties from Parmco Appliances being null and void.

INDEX

IMPORTANT SAFETY INFORMATION

We recommend that for best performance and to extend the life of your appliance you read the

instructions in this owner’s manual thoroughly before using your new appliance. It will provide you with

all the information you need to ensure its safe installation, proper use and maintenance. Retain this

owner’s manual for future reference.

To maintain the efficiency and safety of this appliance we recommend the following:

Before using this appliance

Read the instructions thoroughly.

Remove all plastic protective films on the appliance before using the appliance.

Remove the plastic film on the oven glass door (when provided).

To condition the oven for its first use it is necessary to allow oils and residues used to protect the

appliances during manufacture to burn off. Heat the empty oven at maximum temperature for 45

minutes on Fan Bake function. This allows unpleasant smells and smoke from protective oils used

during manufacture and from new thermal insulation to burn off.

Allow the unit to cool off and wash the oven out with soapy water and then rinse.

The oven only operates when the time has been set

NEVER place anything on the bottom of the oven when it is in operation because this will damage the

enamel.

For your safety

This appliance is designed for non-commercial, household use only and must not be altered in any

way.

This appliance can only be used safely when it is correctly connected to an efficient earthing system

in compliance with New Zealand Electrical Standards requirements.

Before maintenance or cleaning, always ensure that the appliance is disconnected from the mains.

Always use oven gloves to remove and replace cookware in the oven.

Packaging items such as plastic bags, polystyrene, nails etc that this appliance is delivered in are

potentially dangerous, and therefore appropriate measures must be taken to prevent children from

coming into contact with them.

This appliance must only be used by adults. Make sure that children do not touch the controls or play

with the appliance. Young children should be supervised to ensure they do not play with the

appliance.

Do not allow children to sit on or play with the oven door.

Do not use the drop down door as a stool to reach overhead cabinets.

This appliance is not intended for use by persons (including children) with reduced physical, sensory,

or mental capabilities, or lack of experience and knowledge, unless they have been given supervision

or instruction concerning the use of this appliance by a person responsible for their safety.

IMPORTANT SAFETY INFORMATION

The appliance becomes hot during use. Care should be taken to avoid touching heating elements

inside the oven.

Keep the appliance thoroughly cleaned. Food residues may cause fire risks.

DO NOT use a steam cleaner to clean this appliance.

NEVER place aluminium sheets, tins, trays or utensils directly on the bottom of the oven as doing

so may damage the enamel and elements.

WARNING: Accessible parts may become hot during use. To avoid burns, young children should be

kept away.

Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they

can scratch the surface and cause the glass to shatter.

After using the appliance please ensure that all controls are in the “OFF” position.

Avoid touching the oven with wet body parts.

Avoid improper or dangerous use of this appliance.

Do not obstruct the ventilation or heat dissipation slots.

Do not allow power cables of other appliances to come into contact with hot parts of this appliance.

This appliance is intended for indoor use only. Avoid exposing the appliance to atmospheric elements

such as direct sunlight and rain.

DO NOT USE OR STORE FLAMMABLE MATERIALS IN THE APPLIANCE OR NEAR THIS APPLIANCE.

For any enquiries please contact Parmco Appliances (09) 573 5678.

How to use your oven

We recommend that you read the instructions in this owner's manual carefully before use. It will provide

you with all the instructions you require to ensure safe installation, use and maintenance. Always keep

this owner's manual close to hand since you may need to refer to it in the future. Place the spare serial

number sticker on the front of this manual for future reference as you will need the serial number should

this appliance need servicing.

It is important to remember that this oven may perform differently to the way your previous appliance

worked. To obtain the best cooking results please experiment with the temperature, rack height and

cooking times. As a guide to help you with this process please refer to the “Cooking Mode Table”.

This multi-function oven combines the advantages of traditional convection ovens with those of the

more modern fan assisted models in a single appliance. It is an extremely versatile.

Steam and Condensation

Often owners of new ovens will see a higher level of steam and condensation than they are used to in

their previous appliance. This is normal and contributes to keeping the food moist during cooking. The

amount of steam and condensation will depend on the type of food (fresh, defrosted, frozen) being

cooked. The style of cooking (water baths) will also contribute to the amount of steam and condensation

generated. Climatic conditions also contribute to the generation of condensation.

When food is heated it produces steam in the same way a boiling kettle does. When steam comes into

contact with the oven door glass it will condensate and produce droplets. To reduce condensation,

ensure that the oven is well heated before placing food in the oven cavity. Oven pre-heating is necessary

before any cooking!

It is normal for steam to escape the oven when opening the door. To reduce the build-up of condensation,

pre-heat the oven for longer periods and occasionally open the door and carefully wipe away the

condensation. Adjusting your cooking practices will also ensure a minimum build up of condensation.

USE AND CARE

DESCRIPTION OF THE APPLIANCE

The Electronic Oven Control Panel

A Control Panel

G Oven Rack

H Side Rails

F Roast Dish / Grilling Dish

PRODUCT DESCRIPTION

GENERAL INSTRUCTIONS

1. The oven only operates when the time has been set.

2. Always switch the appliance on first by pressing the On/Off button.

3. When the desired function is set, the oven will heat up. A suggested temperature will appear on the

display.

4. The oven light is permanently on when in operation. The oven light will automatically switch off 10

minutes after operation has ceased.

5. Switch the appliance off using the On/Off button.

6. Do not open door whilst oven is pre-heating. By opening the door it will not allow the oven to reach full

temperature.

IMPORTANT INFORMATION

Please be aware this oven has a unique pre heating function to reduce the time it takes to reach

temperature therefore saving energy. When a heating option has been selected the oven will

utilize the rear fan, rear element and lower element to preheat the oven to the set temperature.

Once the oven has reached the set temperature the rear fan, rear element and lower element

will switch off and continue operating with the heating element associated with the desired

function.

BEFORE FIRST TIME USE

This oven will not operate until the clock time has been set.

Setting the Clock

The oven only operates when the time has been set. When the appliance is connected to the electrical

supply or when there has been a power cut, the symbol for Time flashes automatically. This is only a 24

hour clock.

1. To set or change the time, the oven must be off

2. To change time, press the Clock function button and hold until the symbol for time flashes.

3. Using the or button, set the current time. After about 5 seconds, the clock stops

flashing and displays the set time. The appliance is now ready for use.

Selecting the oven function

1. Switch on the oven, press and hold the On/Off button.

2. Press the or button until the desired oven function appears.

A suggested temperature appears on the temperature display.

If the suggested temperature is not changed within 5 seconds, the oven begins to heat up.

OPERATING INSTRUCTIONS

Changing the oven function

1. To change the oven function, press the or button repeatedly until the desired oven

function is displayed.

When a function mode is changed the suggested temperature of 180°C must be adjusted if required.

Changing the oven temperature

1. Press the or button, to raise or lower the temperature. The setting changes in

increments/decrements of 5C.

7. An alarm will be heard and the temperature on the display screen will begin to flash. While it is

flashing you can change the temperature using the + or – buttons.

8. Once the desired temperature is selected, the display will flash 5 times and then solidify, indicating

temperature has been set.

9. Press the to check the actual temperature of the oven. The oven temperature will be

displayed for approximately 4 seconds. Do NOT hold down the button as it will lock the oven

Thermometer symbol

The slowly rising bars on the thermometer symbol indicates how hot the oven is as it heats

up. Bars become solid as the oven reaches certain temperatures during the pre heating process.

Once the oven has reached the selected temperature an alarm is will be heard once and the last

bar will flash for approximately 1 minute and then become solid.

Three rapidly rising bars on the thermometer symbol show that Turbo pre heat has been

selected. Once selected temperature is reached an alarm is heard twice and all 3 rising bars

become solid.

Speed pre-heat

After an oven function is selected, with the use of the additional Speed pre heat function, the empty

oven can be pre-heated in a faster short time. For example 190 will take 10 mins.

1. Set the desired cooking function. If necessary, change the suggested temperature.

2. Press the Turbo preheat button. The symbol lights up.

The bars are flashing rapidly after another show that Turbo pre heat cook function is operating.

When the temperature set is reached, the bars of the heat indicator all light up and the alarm

sounds.

The oven will now continue heating according to the pre-set oven function and temperature. You

can now place food in the oven.

Important: Do not put the food to be cooked into the oven, until Speed pre-heat is completed and the

oven is operating using the desired function.

CLOCK FUNCTIONS

General instructions

After a clock function has been selected, the corresponding symbol flashes for approx. 5 seconds. During

this time, the desired times can be set or modified using the or button.

Once the time has been set, the minute minder will begin to count down, or the time set for Cook Time

or End Time begins to count down. Once the set time has elapsed the oven will turn off.

Please note the End Time can only be used in conjunction with Cook Time.

Minute Minder - allows you to use the oven as a timer (this function can only be used when the

oven is off)

Cook Time – is the time required to cook the food (how long the oven is in use)

End Time – is the time at which the oven needs to turn off.

Time

To set, change or check the time (See “Before first time use” section)

Minute Minder

Minute Minder - allows you to use the oven as a timer (this function can only be used when the oven is

off).

Press the Clock Function button repeatedly until the symbol for Minute minder flashes.

Set the desired Countdown time using the or button (max.59 minutes).

The symbol for Minute minder lights up.

When the time set has elapsed, an audible alarm sounds for 1 minute. “0.00”lights up and the

symbol for Minute minder flashes. To turn off the alarm press any button.

Cook time

Select oven function by pressing or button, then select desired temperature using

the or buttons

Press the Clock Function button once until the symbol for Cook time flashes.

Use the or button to set the desired cooking time. The oven switches itself on and the

symbol for Cook time lights up

By pressing the Clock Function button once, the current time can be displayed.

When the time has elapsed, an audible alarm sounds once and then oven switches itself off.

“0.00”is displayed and the symbol for Cook time flashes. To turn off the alarm, press any button

Delayed Start function

The timer can be set so that the oven will come on at a pre-determined time and cook for a specified

period then turn itself off. The oven will automatically calculate the delayed start time from the finishing

time selected. Please note that you will need to take into account the time for preheating when setting

this function.

Please ensure the time is set (See “Before first time use”)

Select oven function and temperature.

Using the Cook time function , set the time that the dish needs to cook,

Using the End time function , set the time at which the dish is to be ready,

The symbols for Cook time and End time light up.

The oven switches on automatically at the time set.

When the set cooking time has elapsed, an alarm sounds and then the oven switches itself off.

OTHER FUNCTIONS

Programme Memory function

The Memory function can be used to save a setting which is frequently used. Only has 1 memory

setting.

Set the oven function, temperature and if necessary the clock function, Cook time and/or

End time

Press and hold the button for approx. 2 seconds, two beeps will sound. Your preferred

setting is now stored. Repeat steps 1-2 to replace the previously saved setting with a new one.

Starting the Memory function

Switch the oven on using the button On/Off .

Using the button recall the saved setting.

Switching off the display

You can save energy by switching off the display.

Switch off the appliance using the On/Off button.

Press the Clock Function button first, then the button and hold at the same time until

the display goes out.

As soon as the appliance is switched on again, the display comes on automatically. When the

appliance is next switched off, the display goes out again.

Repeat first two steps to Turn on the display.

Child safety function

The child safety lock can be activated while to oven is off and also at time during operation. As soon as

the child safety lock is engaged, none of the controls can be activated.

Activating the child safety device

With the oven turned off press and hold the button until appears in the display. The

oven controls are now locked.

With oven operating press and hold the button until the appears in the display. The oven

controls are now locked.

Deactivating the child safety device

Press and hold the button until disappears from the display. The child safety device is

now deactivated and the appliance controls can be used.

Audible Tone

If preferred, you can disable the button beeps when making selections through the control panel.

To turn off button beeps

Switch off the appliance using the On/Off button.

Press the button first and then the buttons and hold together until an audible alarm

sounds (approx.2 seconds). The button beep is now switched off.

Switching on button beeps

Press the button first and then the button. Hold together until an audible alarm

sounds (approx.2 seconds). The button beep is now switched on.

OVEN FUNCTIONS

Cooking Function Description Symbol

Conventional

Bake

The top and bottom elements operate together like a ‘normal’

conventional oven that you have probably used before. Conventional

mode is best suited for traditional baking and roasting. You should

only use one shelf at a time, otherwise there will be uneven heat

distribution. You can balance the amount of heat between the top

and bottom of the dish by selecting a different shelf height. If you

want more heat at the top of the dish, place the dish on the top or

second shelf. For more heat on the bottom of the dish, place the dish

on the third or fourth shelf.

Fan Assisted Bake
