PARRY ADJTAB10750EM Instruction sheet

Instruction Manual
Stainless Steel Height Adjustable Table
ADJTAB10750EM / ADJTAB15750EM

Contents
Parry-British Built for Purpose
IN296-1
1
Contents...................................................................................................................................... 1
Product Overview ....................................................................................................................... 2
Safety Instructions.................................................................................................................... 3-4
Installation Instructions ............................................................................................................... 4
Operating Instructions .............................................................................................................. 5-6
Cleaning Instructions ................................................................................................................... 6
Maintenance Instructions............................................................................................................. 7
Fault Finding ............................................................................................................................... 8
Service Information...................................................................................................................... 8
Exploded View / Parts List....................................................................................................... 9-11
Warranty Information................................................................................................................ 12
Disposal & Recycling ................................................................................................................. 13
Parry Catering Equipment (Midlands) Ltd, Town End Road, Draycott, Derby, DE72 3PT.
Sales Tel: [phone]

Parry-British Built for Purpose
IN296-1
2
Product Overview
The height adjustable table is ideal for when multiple tasks are required at different levels to
provide the operator with a suitable working environment.
ADJTAB10750ES
ADJTAB10750ES
Dimensions (w x d) mm
1000 x 750
1500 x 750
Adjustment Height (h) mm
780 - 1280
Maximum Operating Load kg
200
Plug
13 Amp
Power rating
(CBD4 Control Box)
400W
(Standby power 0.1W)
230V 50Hz ~
(CBD6 Control Box)
375W
(Standby power 0.1W)
230V 50Hz ~
Warranty
1 year
The unit leads the industry in:
Design and aesthetic appeal
Performance
Power
Functionality
After sales support

Parry-British Built for Purpose
IN296-1
3
Safety Instructions
IMPORTANT: PLEASE READ INSTRUCTIONS FULLY BEFORE USE
ALL APPLIANCES OTHER THAN THOSE FITTED WITH A SEALED MOULDED PLUG MUST BE
FITTED BY A QUALIFIED ELECTRICIAN, IN ACCORDANCE WITH CURRENT REGULATIONS.
The unit should be installed in compliance with the INSTALLATION INSTRUCTIONS and the
NATIONAL REGULATIONS in force at the time. Particular attention should be paid to the
Health and Safety at Work Act.
The control system used on this product is Class II.
A Class II or double insulated electrical appliance is one which has been designed in such a
way that it does not require a safety connection to electrical earth.
Additional Earth Point for static use.
An earth cable to be mounted on the desk construction (typically the top frame) in a way
that ensures good electrical contact. The function of the earth cable is to earth the desk and
ground static electricity. The earth connection does not protect other electrical products.
This can be found located under the table frame and connection can be made by use ring
terminal.
Safe use of the system is possible only when the operating instructions are
read completely, and the instructions contained are strictly observed.
The appliance is not intended for use by young children or infirm persons
without supervision.
If there is visible damage on the product it must not be installed.

Parry-British Built for Purpose
IN296-1
4
Safety Instructions
It is IMPORTANT that this protective film is peeled off before the equipment is used.
ENSURE THE APPLIANCE IS ISOLATED FROM THE POWER SUPPLY BEFORE INSTALLING,
CLEANING OR MAINTAINING THE APPLIANCE
Installation Instructions
Wheel the table into position.
Avoid obstruction that will prevent the table from rising or falling in
operation. (See operating instructions)
Apply the brakes to the castors.
Plug the lead into the control box located under the table.
Plug the 13 Amp plug top into a socket.

Parry-British Built for Purpose
IN296-1
5
Operating Instructions
Important Note
Ensure that there are, no obstruction that will prevent the table to rise of fall under
operation.
Turn on the socket.
Operating the Controls (With push buttons)
The controls are located under the right-hand side of the table.
Press the up or down button to set at the desired level.

Parry-British Built for Purpose
IN296-1
6
Operating Instructions
Operating the Controls (Paddle button)
The controls are located under the right-hand side of the table.
Press the paddle up or down to set at the desired level.
During operation
If the control box makes unusual noise or smells, switch off the mains voltage
immediately.
Take care that the cables are not damaged.
Unplug the mains cable on mobile equipment before it is moved.
If used in a static environment
An addition earth may have been connected, remove this prior to moving.

Parry-British Built for Purpose
IN296-1
7
Cleaning Instructions
Turn off unit at the mains power.
Wipe down the machine with a soft cloth, do not use abrasive materials.
Stainless steel cleaners maybe used and cleaning instructions on the product must be
adhered to.
Never clean the unit with water jets.
Maintenance Instructions
Ensure the appliance is isolated from the power supply before installing, cleaning or
maintaining the appliance.
Maintenance and service must only be undertaken by a qualified electrician.
Parry Catering provides a complete after-sales service by offering the sales of spare parts
directly to customers. Buying spares straight from the manufacturer allows customer to
experience exceptional value and speedy delivery on all spare parts.
For more information on buying spares visit:
www.parry.co.uk/parry-commercial-catering-spares

Parry-British Built for Purpose
IN296-1
8
Fault Finding
Fault
Check
Solution
Unit does not lift
1. The socket is turned on
2. Try a different appliance
in the socket
3. Try the unit in a
different socket.
4. The fuse in the plug
If the problem continues please
contact your distributor
Service Information
Enhanced 1 Year Warranty
Parry Catering (Midlands) Ltd offer an enhanced warranty of one year
(including parts and labour) on all of the Parry manufactured
fabrication products. To take advantage of this you should register
your warranty by logging onto the company website and filling out our
simple form.www.parry.co.uk/the-parry-warranty
If you have any issues with your product and wish to request a
warranty call you can contact our friendly team who will organize a
Parry approved service engineer to attend and fix your problem.
All warranty requests can be sent to [email protected]
alternatively call our warranty department for technical
assistance on 01332 875544

Parry-British Built for Purpose
IN296-1
9
Exploded View / Parts List
Control Box
CBD4
Part Code: CONTROLBOX
CBD6 (Current / Replacement Control Box)
Part Code: CONTROLBOX

Parry-British Built for Purpose
IN296-1
10
Exploded View / Parts List
Mains Lead
Part Code: MAINSCABLE
Motor Cable
Part Code: DESKMOTORCABLE

Parry-British Built for Purpose
IN296-1
11
Exploded View / Parts List
Control Buttons
Part Code: (A) DESKPANEL / (B) DESKPANELBRKT
Part Code: DESKPANELALT
Lifting Leg
Part Code: DESKLIFT

Parry-British Built for Purpose
IN296-1
12
Warranty Information
Not covered under warranty
Fault due to incorrect installation, poor maintenance
or equipment abuse.
Resetting of equipment or circuit breakers.
Faulty electrics –e.g. customer’s plug socket, plug,
wiring, junction box fault, wrong fuse.
Products must be serviced within the first 12
months to be eligible for the 2 year warranty
Product not covered by warranty if combustible
materials have been used, e.g. plastic trays.
Foil used on racks, blockages and lime scale issues.
Failure to grant access for pre-arranged service
call.
Equipment that has been set up or used incorrectly
e.g. dishwasher detergents, levelling and setting up
of doors on a six burner cooker.
Excessive carbon build-up on griddle plates or
overuse of lava rock on chargrills. (Recommended
use by Parry no more than 2kg.)
All of the above points are not covered by
warranty and any costs incurred, because of the
above, will be forwarded to the parties responsible
for placing the call.
The manufacturer’s warranty is only valid in the UK
mainland. Northern Ireland, Western Isles, Inner
Hebrides and Islands are parts only warranty. Please
be aware that the warranty starts from the date of
purchase from Parry and not the sale or installation
date of the equipment.
To be eligible for a 2 year warranty, products must be
serviced at least once within the first 12 months of
purchase.
All service calls will be carried out between 8am
and 5pm, Monday to Friday.
Your warranty is invalid if your equipment has not
been installed in accordance with the
manufacturer’s instructions. The misuse, alteration
or unauthorised repairs of the equipment will also
invalidate the warranty.
During the warranty period it is at Parry’s
discretion whether to repair or replace the
equipment.
The warranty only applies if the equipment has
been used in a professional manner following the
manufacturer’s instructions and maintenance
guidelines.
The warranty covers defects in the material and
component failure only. We are not liable for trading
loss, loss of perishable items, water damage or loss
due to injury or fire damage.
Please ensure you have referred to the
manufacturer’s instruction before placing a warranty
call.
Contact our warranty department on 01332 875544
for technical assistance.
Please have your model number ready before calling.
All warranty requests must be submitted to
[email protected]k.
Failure to pay any warranty charges will result in your
warranty being put on hold until the bill has been
settled. Any issues regarding the raised charges should
be put in writing to our warranty department for
further investigation.
Register your product by visiting our website
www.parry.co.uk

Parry-British Built for Purpose
IN296-1
13
Disposal & Recycling
This appliance is marked according to the European Directive 2002/96/EC on Waste
Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health which could otherwise be caused by
inappropriate waste handling of this product.
A symbol on the product, or on the documents accompanying the product, indicates that
this appliance may not be treated as household waste. Instead it should be
handed over to the applicable collection point for the recycling of electrical
and electronic equipment.
Disposal must be carried out in accordance with local environmental
regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of
this product, please contact your local city office, your household waste disposal service or
the shop where you purchased the product.
Parry Catering recognises our obligations to the EU DIRECTIVE covering the waste disposal
of electrical and electronic equipment (WEEE). Parry Catering are committed to this policy in
order to help conserve the environment.
At the end of this unit’s life you MUST dispose of it in an approved manner. You MUST not
discard the unit or place it in the refuse bin.
You have several options:
Take the unit to an approved WEEE scheme company, there will be one in your area.
Take the unit to an approved waste disposal site; many sites are managed by your local
authority.
Contact the units manufacturer, importer or their agent; the contact details will be on
the unit.
There will probably be a charge for this service which will depend on the physical size and
location of the unit. You will be given a collection price for a curb side collection based on
commercial rates prevailing at the time.
It should be noted that the unit to be collected should be suitably packed and sealed to
prevent dangerous gases and fluids from escaping. The condition of the unit must also be
clean to comply with health and safety regulations.
