PARRY FLEXI-SERVE FS-HT Series User manual

Instruction Manual
FS-HT Range
Available as:
FS-HT2, FS-HT3, FS-HT4, FS-HT5
Including Gantry versions & 800mm Height


Contents
Parry-British Built for Purpose
IN500-1
1
Contents...................................................................................................................................... 1
Product Overview .................................................................................................................... 2-4
Safety Instructions....................................................................................................................... 5
Installation Instructions ............................................................................................................ 5-9
Operating Instructions ............................................................................................................... 10
Cleaning Instructions ................................................................................................................. 11
Maintenance Instructions........................................................................................................... 12
Fault Finding ............................................................................................................................. 13
Service Information.................................................................................................................... 14
Wiring Diagram ......................................................................................................................... 15
Exploded View........................................................................................................................... 16
Parts List .............................................................................................................................. 17-18
Warranty Information................................................................................................................ 19
Disposal & Recycling ................................................................................................................. 20
Parry Catering Equipment (Midlands) Ltd, Town End Road, Draycott, Derby, DE72 3PT.
Sales Tel: 01332 875544 Fax: 01332 874455

Parry-British Built for Purpose
IN500-1
2
Product Overview
The new Parry Flexi-Serve range has been designed specifically to suit the
requirements of the user. The FS-HT Range comprises of a fan assisted heated
cupboard and heated Ceran tiles to the top of the unit.
The Flexi-Serve range can be manufactured with or without a gantry.

Parry-British Built for Purpose
IN500-1
3
It leads the industry in:
Design and aesthetic appeal
Performance
Power
Functionality
After sales support
900mm Height Range (Standard)
Features
FS-HT2
FS-HT3
FS-HT4
FS-HT5
External Dimensions
(mm)
860(w)
1160(w)
1495(w)
1830(w)
700(d) x 900 (h)
Internal Cupboard
(mm)
705(w)
1005(w)
1340(w)
1675(w)
580 (d) x 410 (h)
Shelves
2 Layers supplied 4 Positions
Height with Gantry
(mm) Optional
1440 (h)
Total Power (Watts)
1860
2040
2220
2400
Total Power with
Gantry (Watts)
2060
2440
2620
3000
Voltage
230V 50Hz ~
Weight (kg)
86
108
128.5
169.5
Weight with Gantry
(kg)
108
137
176
226.5

Parry-British Built for Purpose
IN500-1
4
800mm Height Range
Features
FS-HT2-8
FS-HT3-8
FS-HT4-8
FS-HT5-8
External Dimensions
(mm)
860(w)
1160(w)
1495(w)
1830(w)
700(d) x 800 (h)
Internal Cupboard
(mm)
705(w)
1005(w)
1340(w)
1675(w)
580 (d) x 310 (h)
Shelves
2 Layers supplied 3 Positions
Height with Gantry
(mm) Optional
1340 (h)
Total Power (Watts)
1860
2040
2220
2400
Total Power with
Gantry (Watts)
2060
2440
2620
3000
Voltage
230V 50Hz ~
Weight (kg)
76.5
93
113
149.5
Weight with Gantry
(kg)
96.5
122
157
202

Parry-British Built for Purpose
IN500-1
5
Safety Instructions
The unit has been designed to easily be moved into position and has four braked castors to
lock in position to avoid movement whilst in operation. Alternatively, the units can be
supplied on adjustable legs for fixed position.
This appliance has been designed to warm products and therefore during its use parts of the
appliance will become very hot. All personnel must be given adequate supervision and
training in the safe use of this appliance.
All appliances other than those fitted with a sealed moulded plug must be fitted with a
sealed moulded plug and must be fitted by a qualified electrician, in accordance with
current regulations.
The unit should be installed in compliance with the Installation Instructions and the
National regulations in force at the time. Particular attention should be paid to the
Health and Safety at Work Act.
To prevent shocks, all appliances whether gas or electric, must be earthed.
To avoid scratching the highly polished exterior surface of this equipment whilst in
transit, the protective film on the exterior surfaces has NOT been removed.
It is IMPORTANT that this protective film is peeled off before the equipment is used.
Ensure that vents intended to provide air flow in and around the unit are not obstructed.
Ensure the appliance is isolated from the power supply before installing, cleaning or
maintaining the appliance
Installation Instructions
The unit has been designed to easily be moved into position and has four braked castors to
lock in position to avoid movement whilst in operation. Alternatively, the units can be
supplied on adjustable legs for fixed position.
Mobile Use
Position the Flexi-Serve unit in the serving position and secure in place using the 4
braked castors.
Units fitted with 13amp plug, plug into a suitable socket.
Static Use
Position the Flexi-Serve unit in the serving position and adjust legs to suit the surface.
Units fitted with 13amp plug, plug into a suitable socket.

Parry-British Built for Purpose
IN500-1
6
Taking Out the Doors
Attaching the Tray Slide onto the Unit
Slide door to the
middle
Lift door up
Angle bottom of
door forward
Pull door down

Parry-British Built for Purpose
IN500-1
7
Removing the Side and Front Panels
Fixing the Connecting Plates and Trims to the Units
Push the two units together that you require the joining plate to be attached to. Screw in
the supplied Allen screws with the supplied Allen key.
Top of Unit Bottom of Unit
Unscrew the screw from the bottom of the unit
with the supplied Allen Key.
Using the finger cutouts on the
bottom of the unit pull the
panel out and then slide down.

Parry-British Built for Purpose
IN500-1
8
Kick Plate Installation (If fitted on legs)
Kick plates clip onto the legs of the unit. You must order legs instead of castors to be
able to have kick plates.
Installation of Gantry Glass
Gantry Glass Standard Fully Enclosed Gantry Glass
Island Gantry Glass

Parry-British Built for Purpose
IN500-1
9
Installation or movement of shelves

Parry-British Built for Purpose
IN500-1
10
Operating Instructions
The unit is designed to keep food warm whilst serving and should never be used to try to
cook food.
Hot Cupboard
Turn on the mains power switch.
The Hot Cupboard fan will run.
Turn on Hot Cupboard control to full for 15 minutes to allow to warm up.
Whilst the hot cupboard is heating the green indicator lamp will be displayed.
When the hot cupboard achieves temperature, the lamp will distinguish.
This will turn on and off to maintain temperature throughout use.
Once the Hot Cupboard is up to temperature, place cooked hot food in suitable metal
containers into the hot cupboard.
Adjust the dial to desired level The Hot Cupboard will operate between 30-90°C.
Hot Top
Turn on Hot Top by selecting setting number 3 and allow to fully warm up for 15
minutes.
Whilst the dial is set on number 3 the green indicator lamp will be displayed.
If fitted with the optional gantry, turn on the power switch to this.
Once the Hot Top is up to temperature place suitable serving containers on top. Ensure
that the containers have a flat base to ensure optimum contact to the Hot Top.
Adjust the dial to desired level. Setting 3 is power is on permanently. Positions from 1 –
2 will regulate the power on and off. Setting these depends on the food mass that is
stored in the containers. Test to ensure food is kept at serving temperature.
Whilst serving is not in place best practice is to keep the lids on the containers.
After Use
Turn off power dials to the Hot Cupboard, Hot Top and power switch

Parry-British Built for Purpose
IN500-1
11
Cleaning Instructions
The appliance should be cleaned after every use.
Allow unit to cool down before cleaning
Turn off unit at the mains power.
Clean Ceran top with hot soapy water.
With the containers removed wipe down the machine with a soft cloth, do not use
abrasive materials.
Stainless steel cleaners maybe used and cleaning instructions on the product must be
adhered to.
Never clean the unit with water jets.

Parry-British Built for Purpose
IN500-1
12
Maintenance Instructions
Ensure the appliance is isolated from the power supply before installing, cleaning or
maintaining the appliance.
Maintenance and service must only be undertaken by a qualified electrician.
Parry Catering provides a complete after-sales service by offering the sales of spare parts
directly to customers. Buying spares straight from the manufacturer allows customer to
experience exceptional value and speedy delivery on all spare parts.
For more information on buying spares visit:
www.parry.co.uk/parry-commercial-catering-spares

Parry-British Built for Purpose
IN500-1
13
Fault Finding
Fault
Check
Solution
Hot plates not heating
Check that the power switch is
illuminated. If there is no
illumination
Turn on mains power
Hot Cupboard not heating
Check that the power switch is
on and the thermostat is
selected to desired
temperature.
Turn on mains power
See an engineer to replace
faulty switch, element or
thermostat.
Gantry not lighting
Check that the power switch is
illuminated. If there is no
illumination
Turn on mains power
See an engineer to replace
faulty switch
Single bulbs not lighting
Check if the bulb has blown
Replace with a 200W bulb

Parry-British Built for Purpose
IN500-1
14
Service Information
This appliance should be routinely serviced to prolong its lifetime. Parry recommends that
the appliance is serviced every 12 months by a Parry authorised engineer. Failure to service
your product within the initial 12 month warranty period will cause the 24 month warranty
to become void.
If the supply cord becomes damaged, it must be replaced by the manufacturer, it’s service
agent, or a similarly qualified person.
Enhanced 2 Years Warranty
Parry Catering (Midlands) Ltd offer an enhanced warranty of two
years (including parts and labour) on all of the Parry manufactured
products. To take advantage of this you should register you warranty
by logging onto the company website and filling out our simple form.
www.parry.co.uk/the-parry-warranty
If you have any issues with your product and wish to request a
warranty call you can contact our friendly team who will organize a
Parry approved service engineer to attend and fix your problem.
alternatively call our warranty department for technical assistance on
01332 875544

Parry-British Built for Purpose
IN500-1
15
Wiring Diagram

Parry-British Built for Purpose
IN500-1
16
Exploded View

Parry-British Built for Purpose
IN500-1
17
Parts List
Part Number
Description
Code
1
Main Body
No Code
2
Gantry Assembly
(Please note gantries are factory
fitted)
FS-HCHT2G
FS-HCHT3G
FS-HCHT4G
FS-HCHT5G
3
Glass Fixing
FS-GLASSFIXBOLT
4
Gantry Glass
(Standard Glass fitted with Gantry)
FS-HCHT2G = FS-PLGL2TOP
FS-HCHT3G = FS-PLGL3TOP
FS-HCHT4G = FS-PLGL4TOP
FS-HCHT5G = FS-PLGL5TOP
Other Options available, Island
Glass & Assisted Serve.
Please see extras
4a
Glass Rubber Gasket
FS-RUBBWASH
5
Rear Cladding
6
Side Cladding
7
Heater Vent Cover
No Code
8
Element
FS-RING15ELEM
9
Motor Plate
No Code
10
Insulation Board
FS-HBINSUL
11
Motor
P9EOMOTOR
12
Motor Cover
No Code
13
Gland
GLAND0M16
13a
Gland Nut
LOCKNTM16
14
Terminal Block
TB6POLET
15
Braked Castor
CASTOR100BHD
After Oct 2021 castor in use
CASTOR100HDB/C
16
Gland
GLAND0M16
16a
Gland Nut
LOCKNTM16
17
Rack
HCWIRESHELF
18
Shelf Support Rail
No Code
19
Shelf Supporting Bar (Sizes Vary)
No Code
20
Door Magnet
DRCT00010
21
Door Roller
DOOROLLER

Parry-British Built for Purpose
IN500-1
18
22
RH Door Assembly
No Code
23
LH Door Assembly
No Code
24
Ceran Top
CERAN530325
25
Ceramic Terminal Block
BTCER2WAY
26
Lamp Holder
CLICHOLD
27
Lamp Reflector
CLICREFLECTOR
28
Power Switch
SWRE00011
29
200w Quartz Lamp
CLIC200LAMP
30
Power Switch
SWRE0011
31
Thermostat
TMST5513015
32
Energy Regulator
SATT37071
33
Green Neon
LNGN2211P
34
Control Knob
KNOBPHEN
35
Tray Slide Assembly (Front)
Optional Extra
Tubed Tray Rail
FS-T2 (Size 2 GN)
FS-T3 (Size 3 GN)
FS-T4 Size 4 GN)
FS-T5 (Size 5 GN)
Plain Tray Slide
FS-ST2 (Size 2 GN)
FS-ST3 (Size 3 GN)
FS-ST4 Size 4 GN)
FS-ST5 (Size 5 GN)
Side Tray Slide
Tubed Tray Rail
FS-TSIDE
Plain Tray Slide
FS-STSIDE
Mains Cable
MLEAD25
Extras
Description
Code
Island Glass
FS-IG2 (Size 2 GN)
FS-IG3 (Size 3 GN)
FS-IG4 Size 4 GN)
FS-IG5 (Size 5 GN)
Assisted Glass
FS-AG2 (Size 2 GN)
FS-AG3 (Size 3 GN)
FS-AG4 (Size 4 GN)
FS-AG5 (Size 5 GN)
This manual suits for next models
4
Table of contents
Other PARRY Range manuals
