PBI DMN-2410D User manual

P/N.85E19-M0501 Rev: A
www.pbi-china.com
DMM-2410D Quad Channels Receiver and Processor
User’s Manual
Brighten Your Digital View!

Pro Broadband Inc.
DMM-2410D Quad Channels Receiver and Processor
01 Notice
03 Before Using the Device
04 1 Overview
04 2 Features
04 3 Technical Specifications
06 4 Order Information
06 5 Block Diagram
07 6 Front panel and rear panel instructions
07 7 Operation instructions using DMM-1000CU programmer
08 7.1 Overview of the Menu
08 7.2 Description of menu
12 8 Web Control
12 8.1 Status
14 8.2 Configure
15 8.3 TS/IP
19 8.4 Remux
20 8.5 System
24 9 Installation
24 10 Accessories
Contents

Brighten Your Digital View!
1
www.pbi-china.com
Notices
COPYRIGHT (Copyright © 2013 Beijing Jaeger Communication Electronic Technology Co., Ltd.)
Not to be copied, used or translated in part or whole without Beijing Jaeger prior consent in writing
except approval of ownership of copyright and copyright law.
WARRANTY
This warranty does not cover parts which may become defective due to misuse of the information
contained in this manual.
Read this manual carefully and make sure you understand the instructions provided. For your
safety, be aware of the following precautions.
WARNING! IMPORTATNT SAFETY INSTRUCTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING
• To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
• To avoid explosion danger, do not dispose of batteries in an open fire.
CE MARK FOR EUROPEAN HARMONISED STANDARDS
The CE mark which is attached to these products means it conforms to EMC Directive
(89/336/EEC) and Low Voltage Directive (73/23/EEC).
IMPORTANT INFORMATION
Please retain the original packaging, should it be necessary at some stage to return the unit.
Disposal of Old Electrical and Electronic Equipment (Applicable in the European Union and
other European countries with separate collection systems)
This symbol on the product or on its packaging indicates that this product shall not be
treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By ensuring
this product is disposed of correctly, you will help prevent potential negative
consequences for the environment and human health, which could otherwise be
caused by inappropriate waste handling of this product. The recycling of materials will
help to conserve natural resources. For more detailed information about recycling of
this product, please contact your local Civic Office, your household waste disposal
service, or the shop where you purchased the product.

DMM-2410D Quad Channels Receiver and Processor
2
Pro Broadband Inc.
COPYRIGHTS
Television programs, movies, video tapes, discs, and other materials may be copyrighted.
Unauthorized recording of copyrighted material may be against the copyright laws in your region.
Also, use of this product with cable television transmissions may require authorization from the
cable television operator or transmitter/owner.
VENTILATION
• Do not expose the product to high temperatures, such as placing it on top of other product that
produce heat or in places exposed to direct sunlight or spot lights.
• The ventilation slots on top of the product must be left uncovered to allow proper airflow into the
unit.
• Do not stand the product on soft furnishings or carpets.
• Do not stack electronic equipment on top of the product.
• Do not place the product in a location subject to extreme changes in temperature. The
temperature gradient should be less than 10 degrees C/hour.
• Place the product in a location with adequate ventilation to prevent the build-up of heat inside the
product. The minimum ventilation space around the unit should be 7 cm. The ventilation should
not be impeded by covering the ventilation openings with items, such as newspapers, table cloth,
curtains, etc.
POWER SOURCES
• The product is not disconnected from the AC power source (mains) as long as it is connected to
the power outlet or wall socket, even if the product is turned off.
• If the product will not be used for a long period of time, disconnect it from the AC power outlet or
wall socket.

Brighten Your Digital View!
3
www.pbi-china.com
Before Using the Device
Thank you for purchasing the DMM-2410D Quad channels Receiver and Processor. This User
Manual is written for operators/users of the DMM-2410D to assist in installation and operation.
Please read this user manual carefully before installation and use of the device.
FOR YOUR SAFETY
This equipment is provided with a protective earthing ground incorporated in the power cord. The
main plug shall only be inserted in a socket outlet provided with a protective earth contact. Any
interruption of the protective conductor, inside or outside the device, is likely to make the device
dangerous. Do not remove the covers of this equipment. Hazardous voltages are present within
this equipment and may be exposed if the covers are removed. Only Beijing Jaeger trained and
approved service engineers are permitted to service this equipment.
The supplied AC power cable must be used to power the device. If the power cord becomes
damaged it must be replaced. No operator serviceable parts inside. Refer servicing to Beijing
Jaeger trained and approved service engineers. For the correct and safe use of the device, it is
essential that both operating and servicing personnel follow generally accepted safety procedures
in addition to the safety precautions specified in this manual. Whenever it is likely that safety
protection is impaired, the device must be made in-operative and secured against unintended
operation. The appropriate servicing authority must be informed. For example, safety is likely to
be impaired if the device fails to perform the intended measurements or shows visible damage.
WARNINGS
• The mounting environment should be relatively dust free, free of excessive vibration and the
ambient temperature between 0C° to 40C°. Relative humidity of 20% to 80% (non-condensed) is
recommended.
• Avoid direct contact with water.
• Never place the equipment in direct sunlight.
• The outside of the equipment may be cleaned using a lightly dampened cloth. Do not use any
cleaning liquids containing alcohol, methylated spirit or ammonia etc.
• For continued protection against fire hazard, replace line fused only with same type.
• Air intake for cooling is achieved via holes at the side of the device and the fans inside. The air
flow should not be obstructed. Therefore, the device has to be placed on a flat surface, leaving
some space at the sides of the device.
• When in operation, the internal temperature should not exceed the limit of 70C°.

DMM-2410D Quad Channels Receiver and Processor
4
Pro Broadband Inc.
DMM-2410D Quad Channels Receiver and Processor
1 Overview
The DMM-2410D professional Quad DVB Demodulator has 4 independent tuners, 4 ASI outputs
and 1 TS over IP port. It receives up to 4 TS streams with its tuner inputs and then remultiplexes and
converts to TS/IP and ASI outputs. The DMM-2410D' s internal remultiplexer enables to create new TS
streams that are subsets of the original streams. DVB services (TV or Radio) could be outputted as
multiple SPTS or MPTS over IP, as well as over ASI. Three TS/IP modes provided, they are simplex
DVB output mode, simplex IPTV output mode and full duplex DVB TS/IP mode. External services or
particular PID data from TS/IP input could be remultiplexed for outputs.
2 Features
¾Variety of input options DVB-T2/S2/S/C/T/T2 and TS/IP
¾Built-in TS re-multiple×er receives 4×Tuner and TS/IP Output
¾Dynamic PMT detection and automatic updating
¾UDP/RTP, Unicast/Multicast, and SPTS/MPTS over IP
¾Remote Control and Supervision by SNMP, HTTP WEB and Proprietary HDMS software
¾On Site software update through IP
¾RSSI, received Eb/No & BER monitoring
3 Technical Specifications
DVB-S/S2 Tuner Input
Connector Type 4×F type female 75Ωfor Input
female 75Ωfor loop through output
Input Frequency Range 950 2150MHz
Input Level -25 -65dBm
Symbol Rate 2 40MBauds
Roll-off Factor DVB-S QPSK: 0.35
DVB-S2 8PSK: 0.35, 0.25, 0.2
FEC Code Rate DVB-S QPSK 1/2, 2/3, 3/4, 5/6, 7/8
DVB-S2 QPSK 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9, 9/10
DVB-S2 8PSK 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
Satellite Selection Command DiSEqC 1.0
LNB Polarity Selection
Voltage
0,13V,18V selectable
LNB Band Selection Tone 0/22KHz selectable
DVB-C Tuner Input

Brighten Your Digital View!
5
www.pbi-china.com
Connector Type 4 x F type female 75Ω
Input Frequency Range 48~860MHz
Input Level 45 75dBµV
Symbol Rate 1 7MBauds ITU J.83 Anne× A
Constellation 16/32/64/128/256QAM
Bandwidth 6MHz/7MHz/8MHz
Return Loss 7dB
DVB-T/T2 Tuner Input
Connector Type 4 x F type female 75Ω
Input Frequency 104~862MHz (VHF/UHF)
Input Level -20 ~ -70dBm
Constellation DVB-T: QPSK, 16QAM, 64QAM
DVB-T2: QPSK, 16QAM, 64QAM, 256QAM
Bandwidth 6MHz/7MHz/8MHz
FFT Mode DVB-T: 2K/8K
DVB-T2: 1K, 2K, 4K, 8K, 16K, 32K
Guard Interval DVB-T: 1/4, 1/8, 1/16, 1/32
DVB-T2: 1/4, 5/32, 1/8, 5/64, 1/16, 1/32, 1/64, 1/128
FEC Code Rate DVB-T: 1/2, 2/3, 3/4, 5/6, 7/8
DVB-T2: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6
Return Loss 7dB (typ.)
ASI Output
Connector Type 4 x BNC female, 75Ω
Standard DVB-ASI, EN50083-9
Output Bit Rate ≤108Mb/s
TS over IP
Connector Type 1 x RJ-45, 100/1000 Base-T
Protocol UDP/RTP, Multicast/Unicast, IGMP V2/V3
Operation Mode
1. Simplex DVB output mode, total 5 DVB MPTS streams, 4 from Tuners, 1 from
internal reMUX
2. Simplex IPTV out mode, total 128 Program streams(for IP applications, no
stuffing/null packet, non DVB standard), from any one of 4 tuners or from internal
reMUX.
3. Full Duplex DVB mode, 1 DVB MPTS streams input and 1 DVB MPTS streams
output
Note: Please follow the User Manual to configurate these modes.
Effective Bit Rate
1. Simplex DVB out mode: 700Mb/s Max.
2. Simplex IPTV out mode: 550Mb/s Max.
3. Full Duplex DVB mode, Input: 80Mb/s Max., Output: 80Mb/s Max.
Control & Monitoring
Connector Type 1×RJ-45, 10/100 Base-T, for equipment IP Control
Remote Control SNMP, HTTP (Web Interface), Proprietary HDMS (Headend Device Management
System)

DMM-2410D Quad Channels Receiver and Processor
6
Pro Broadband Inc.
Software Upgrade FTP Loader and Telnet
Physical
Power Supply DC 3.3V/5V/12V, supplied by DMM-1000MF or DMM-200MF chassis
Power Consumption 15W
Weight 560g
Storage Temperature -10 to 55
Operating Temperature 0 to 45
Operating Humidity 10 to 90%, non-condensed
4 Order Information
5 Block Diagram
Function DMM-2400D-S2/S DMM-2400D-T2/T DMM-2400D-C
Tuner Input S2 x4 x4 x4
Output ASI x2
(1xBackup)
Control
IP reset

Brighten Your Digital View!
7
www.pbi-china.com
6 Front panel and rear panel instructions
7 Operation instructions using DMM-1000CU programmer
NOTE: The DMM-1000CU Programmer is an universal programmer unit for PBI DMM products family.
DMM-1000CU is a standalone product and not included in the package of DMM-2400D, please contact
local sales agency for more information.

DMM-2410D Quad Channels Receiver and Processor
8
Pro Broadband Inc.
7.1 Overview of the Menu
Users are advised to restore factory setting of the machine before the first time using it. Because of
machine's too many functions, users are advised not to change those temporarily useless parameters in
order to avoid unnecessary fault.
After power on, the Local IP address will be shown on the LCD of DMM-1000CU. User can press ENTER
key to get into the main menu.
Status: show the status of the device.
Configuration: Configure remux and TS/IP parameters.
System: Configure the local settings of the device.
7.2 Description of menu
7.2.1 Status
Main-Menu Sub-Menu1 Sub-Menu2 Sub-Menu3 Description
Status
Tuner Status RSSI->Tuner 1/2/3/4
Strength Display tuner input signal Strength
C/N Display tuner input signal C/N
Eb-No Display tuner input signal Eb_No
BER Display tuner input signal BER
Input Bit Rate
T1/2/3/4 Display tuner 1/2/3/4 input Bit rate
IP Display TS IP input Bit rate
Output Bit Rate A1/2/3/4 Display ASI-1/2/3/4 total and valid bit
rate
TS/IP Status
Link Status Display IP link status:
10M/100M/1000M/Disconnect
Gigabit Output Status Display IP out status
Gigabit In Status Display IP in status

Brighten Your Digital View!
9
www.pbi-china.com
7.2.2 Configure
Main-Menu Sub-Menu1 Sub-Menu2 Sub-Menu3 Description
Configuration
Tuner
Setup
Tuner
1/2/3/4
LNB Frequency LNB Frequency
Satellite Frequency Satellite Frequency
Symbol Rate Setting Symbol Rate of Tuner1/2/3/4
LNB Voltage switch OFF/13V/18V
LNB 22KHz ON/OFF
DiSEqC OFF/Port A/Port B/Port C/Port D
Remux Remux
Setup
Program Select
select the programs to remux. Click on Enter
to select, double click to cancel. (The
program(s) will be marked with an asterisk (*)
once be selected)
Select SPTS from Tuner 1 ~ 4
IP Input:select the program(s) inputted via IP
input port. (Note: this sub-menu is displayed
only when the IP I/O is configured as
full-duplex mode.)
Bit Rate
Output Bit Rate: key in the bit rate of the
newly generated MPTS, valid range from
100K~216000 Kb/s
Packet Size 188 Byte/204 Byte
TS ID
TS ID: key in the TSID of the newly
generated MPTS, valid range from 0 to
65535 decimal
Remove CA ON/OFF:
Insert EIT ON/OFF:
Output Program display the remux program
TS/IP Gigabit
Output
Gigabit Out Switch Enable/Disable
Sourse Tuner1~4 Remux TS IP IN
Protocol
UDP: set UDP protocol to IP output
RTP: set RTP protocol to IP output
TS Pkts Per UDP
set the number of TS packets that can be
carried by each UDP packet, valid range from
1~7
Time To Live set TTL to the output IP packets, valid range
from 1~255
Type Of Service Min Delay/Max Reliability/Max
Throughput/Min Monetary Cost/Normal
Uni/Multi IP Address set the destination IP address

DMM-2410D Quad Channels Receiver and Processor
10
Pro Broadband Inc.
Uni/Multi UDP Port set the destination port number, valid range
from 1024~65531
ProMPEG FEC Enable/Disable
Column FEC UDP
Port Port
Row FEC UDP Port Port
ProMEG FEC Mode 1D,5x5/1D,5x20/1D,10x10/2D,5x5/2D,5x20/2
D,10x10
FEC Aligment Annex A/Annex B
Test Drop Packets
Gigabit Input
Only mode
Full
Duplex
Uni/Multicast select Unicast or Multicast
Source Identify on/off
Source IP Address Setting IP address
Multicast Address Setting Multicast Address
Uni/Multi UDP Port set the target port number of the uni/multicast
IP input, valid range from 1~65535
FEC Column UDP
Port Port
FEC Row UDP Port Port
TS Clock Recovery
Auto: it is suggested to set Auto when there is
accurate PCR carried by the inputted TS/IP
Fixed Rate: when fixed rate is selected, use
r
has to configure a bit rate to regenerate the
TS clock. The configured fixed bit rate has to
be a little bit higher than the bit rate of the
inputted TS/IP.
Gigabit Local
Gigabit Address set the IP address of the IP port
Gigabit Subnet Mask set the net mask of the IP port
Gigabit MAC
Address display the MAC address of the IP port
Gigabit Gateway set the gateway of the IP port
Gateway MAC
Address
set the MAC address of the gateway unde
r
which the unit is connected
ASI Output ASI-1/2/3/4
Output ASI Output

Brighten Your Digital View!
11
www.pbi-china.com
7.2.3 System
Main-Menu Sub-Menu1 Sub-Menu2 Description
System
Network Setting
IP Address set the IP address, valid range from
0.0.0.0~255.255.255.255
Subnet Mask set the net mask, valid range from
0.0.0.0~255.255.255.255
Gateway set the gateway,valid range from
0.0.0.0~255.255.255.255
MAC Address to display the MAC address
Device Label Edit Product name
user allows to rename the unit, press Enter and key
in the name of the unit, then press Enter to confirm
the setting or press Exit to cancel.
Version Software Version display display the software version
Factory Default
Enter: Yes: press Enter to recall the factory default
settings.
Exit: No: press Exit to cancel
Machine Type
MAC Address to Modify the MAC address
S/N display the serial number of the unit
Gigabit MAC Address to Modify the Gigabit MAC address
Detail Version Display the detail version of MCU,FPGA,LINUX OS
WEB Login
Edit Login ID press Enter and key in the login ID for WEB
management
Edit Login Password press Enter and key in the password for WEB
management
Gigabit Mode
Multiple Output: the IP I/O is configured as multiple
uni/multicast output mode, which delivers up to five
streams over IP. There are four stuffed or un-stuffed
SPTS (lower bit rate but less PCR accurate than
normal SPTS, from local encoders) and one MPTS
(from internal reMultiplexer) over the IP with different
Unicast or Multicast IP addresses.
IPTV Ouput 128 Channels IPTV SPTS/MPTS.
Full Duplex: the IP I/O is configured as full duplex
mode, which allows only one MPTS or SPTS over IP
input and output in uni/multicast at the same time.

DMM-2410D Quad Channels Receiver and Processor
12
Pro Broadband Inc.
8. Web Control
DMM-2410D has an integrated web server. This web server allows configuration and status requests
with a standard web browser. First make sure the IP Control port is well connected in the network and
can be pinged by the host PC. Then enter IP address of the module into the browser, it will pop up a
dialog asking for login user and password. The default user name and password are “root” and “12345”.
The user name and password can be changed via either DMM-1000CU programmer or Web browser.
If the username and password are forgotten, user have to use a DMM-1000CU to reset it.
Figure 8-1 Login
8.1 Status
Via the status page, user can have an overview of four tuners working status of DMM-2410D.
Figure 8-2 Input Bitrate

Brighten Your Digital View!
13
www.pbi-china.com
Figure 8-3 Output Bitrate
Figure 8-4 Tuner Status
Figure 8-5 TS/IP Status

DMM-2410D Quad Channels Receiver and Processor
14
Pro Broadband Inc.
8.2 Configuration
8.2.1 Configuration - > Tuner
All parameters for Tuners and ASI Output can be found under the page “Configuration”. Click the
button "Apply" to submit your configuration or click the button "Cancel" to cancel and restore the
previous settings.
Tuner-1~4:
There are 6 options to set DVB-S2 parameters. After signal locked, the TUNER LOCK indicator on
front panel will turn green.
LNB Frequency: Input LNB frequency
Satellite Frequency: Input downstream frequency of satellite
Symbol Rate: Input symbol rate of satellite
LNB Voltage: select the correct LNB voltage output of the F-connector: Off, 13 V, 18 V. <A>
LNB 22KHz: activate the LNB 22 kHz control signal to the LNB: On or Off. <B>
DISQEC: Can select OFF/Port A/Port B/Port C/Port D
Note: please contact the local satellite operator for the satellite frequency and symbol rate.
<A> Normally, 13V switches the LNB to receive Vertical/Left hand polarization while 18V receive
Horizontal/Right hand.
<B> Normally, 22KHz control signal switches the LNB to receive high band if any.
8.2.2 Configuration - > ASI OUT
Set parameters for ASI Output.

Brighten Your Digital View!
15
www.pbi-china.com
8.3 TS/IP
2410D provides three TS/IP operation modes,“Multiple output”, “Full Duplex”and “IPTV” .The
management webpage will be different following the change of the operation mode.
8.3.1 Multiple Output Mode
The pages below are displayed under Multiple Output mode. To change the TS/IP operation mode,
please refer to chapter System-Device.
8.3.1.1 Gigabit Out
Under multiple output operation mode, user can set output uni/multicast IP address and port number for
the built-in remux, and Tuner input. Each IP output channel can be switched ON/OFF independently. The
source for TS/IP output 1-4 is forced linking with Tuner input 1-4 respectively and cannot be changed.
(Note: the page below is displayed only when the TS/IP operation mode is Multiple Output mode. To
change the TS/IP operation mode, please refer to chapter System-Device.)

DMM-2410D Quad Channels Receiver and Processor
16
Pro Broadband Inc.
8.3.1.2 Gigabit In
Under Multiple output mode, the Gigabit Input is not available.
8.3.1.3 Local Settings
Set parameters for the TS/IP output port.
8.3.2 Full-duplex Output Mode
The pages below are displayed under Full-duplex mode. To change the TS/IP operation mode, please
refer to System-Device.
8.3.2.1 Gigabit Out
Under full-duplex operation mode, the device supports single uni/multicast output. The default source
for TS/IP output is the built-in remux.
(Note: the page below is displayed only when the TS/IP operation mode is Full-duplex mode. To
change the TS/IP operation mode, please refer to chapter System-Device.)

Brighten Your Digital View!
17
www.pbi-china.com
IP Out Switch: Enable or Disable the IP output
Source: select the source for the IP output in the drop-down list
Protocol: select UDP or RTP protocol for the IP output
TS Pkts Per UDP: select the number of TS packets that can be carried by each UDP packet
Time To Live: set TTL to the output IP packets
Type of Service: select the service type for the outputted IP streaming
Uni/Multi IP Address: set the unicast or multicast IP address for the output IP streaming
Uni/Multi UDP Port: set the port number, valid range from 1~65535
ProMPEG FEC Switch: Enable or Disable the ProMPEG FEC
8.3.2.2 Gigabit In
Under full-duplex operation mode, the device supports single uni/multicast reception. Set the
uni/multicast target IP address and port number in the page.

DMM-2410D Quad Channels Receiver and Processor
18
Pro Broadband Inc.
Uni/Multicast: select Unicast or Multicast
Source Identify:Enable or Disable.
Source IP Address: set the multicast address for the incoming IP streaming. To receive a unicast
streaming, the submenu can be ignored.
Multicast IP Address: set the multicast address for the incoming IP streaming. To receive a unicast
streaming, the submenu can be ignored.
Uni/Multicast UDP Port: set the port number for the incoming IP streaming.
FEC Column UDP Port: set the port number for column FEC
Row FEC UDP Port: set the port number for row FEC
TS Clock Recover:
Auto: it is suggested to set Auto when there is accurate PCR carried by the inputted TS/IP
Fixed Rate: when fixed rate is selected, user has to configure a bit rate to regenerate the TS
clock. The configured fixed bit rate has to be a higher than the bit rate of the inputted
TS/IP.
8.3.2.3 Gigabit Local
Set the parameters for the TS/IP output port.
Gigabit Address: set the IP address of the IP port
Gigabit Subnet Mask: set the net mask of the IP port
Gigabit MAC Address: display the MAC address of the IP port, cannot be modified by user
Gigabit Gateway: set the gateway address under which the IP port is connected
Gateway MAC Address: set the MAC address of the gateway under which the device is connected,
this is necessary when the IP streaming is needed to pass through the gateways
