Swim Spa Owner’s Manual
Plasc Development Company, Inc.
3743 West Fourth Street
Williamsport, PA 17701 USA
570‐323‐3060 tel 570‐323‐8485 fax
www.pdcspas.com
Pleasenote“swimspa”and“spa”areused
interchangeablythroughoutthismanual.
CongratulaonsonChoosingaQualityPDCSwimFitnessSpa!America’sBestSpas
You now own a high quality PDC Swim Fitness Spa built for years of enjoyment and relaxaon. It is of prime importance that
you understand the operaon of your swim fitness spa and enjoy it with safety in mind. You must read this manual
thoroughly and understand all of the safety precauons. Using your swim fitness spa within these guidelines assures years
of fun and relaxaon gained from adding a PDC Swim Fitness Spa to your lifestyle.
Please read the Owner’s Manual completely before installing and using your new swim spa. The purpose of this manual is
to provide you with safety, operaonal and installaon informaon which will allow you the fullest enjoyment of this fine
product. Please note that all references to a swim spa are also referencing a fitness spa. Fitness spas are built for aquac
exercise rounes and less aggressive swimming, while swim spas are designed for more acve aggressive swimming.
At the me of prinng, this manual was deemed as accurate as possible. PDC Spas reserves the right to change product in
an effort to enhance and improve, without prior noce. To be aware of any of these possible changes, log on to
www.pdcspas.com, referring to the Customer Care secon, or contact your retailer directly.
OwnershipInformaon
Name ___________________________________________________
Address ___________________________________________________
___________________________________________________
Installaon Date ____ / ____ / ____
Model Name _____________________________ Serial # __________________________________
Retailer Name _____________________________ Retailer Phone Number _____________________
Service Technician Contact Info _________________________________
RegisterYourSwimFitnessSpa
Please be sure to register your new swim spa upon delivery. Log onto www.pdcspas.com/customer care and enter the
required informaon. We have no record of ownership unl this is completed. This will ensure warranty coverage and
informaon regarding possible product updates.
LocangYourSerialNumber
The metal serial number plate can be found on the backside of the swim spa shell by removing the cabinet panel beneath
the digital control pad. This blue and silver plate includes a 5 digit serial number.
SAVETHISMANUALFORFUTUREREFERENCE!
Swim Spa Owner’s Manual 1
Plasc Development Company, Inc.
3743 West Fourth Street
Williamsport, PA 17701 USA
570‐323‐3060 tel 570‐323‐8485 fax
www.pdcspas.com
Swim Spa Owner’s Manual 2
DONOTREMOVEWARNINGLABELFROMSPA.
ALWAYSATTACH&LOCKYOURCOVERAFTERUSE.
!
! WARNING
This unit is a professional‐grade product. A knowledge of construcon techniques, plumbing and
electrical installaon according to codes are required for proper installaon and user sasfacon.
It is recommended that a licensed contractor perform the installaon. Warranty is voided for
improper installaon related issues.
! WARNING
REPLACE ALL SAFETY SUCTION COVERS EVERY 7 YEARS.
Replace with similar VGB approved fings at same or higher flow rangs.
Replacement applies to all swim and fitness spa models, both round and square grate fings.
READANDFOLLOWALLINSTRUCTIONS!!
Thisunitisaprofessional‐gradeproduct.Aknowledgeofconstrucontechniques,plumbingandelectricalinstallaon
accordingtocodesarerequiredforproperinstallaonandusersasfacon.Itisrecommendedthatalicensedcontractor
performtheinstallaon.WarrantyisvoidedforimproperInstallaonrelatedissues.
Itistheresponsibilityofthehomeownertoensurethatallusersoftheswimspaareadequatelyinformedofallprecauons.
Usetheswimspaonlyasdescribedinthismanual.Theswimspaisintendedforhomeuseonly.Donotusetheswimspaina
commercialorrentalseng.Allwarraneswillbevoided.
GROUNDALLMETALELECTRICALEQUIPMENT
AgreencoloredterminaloraterminalmarkedG,GR,Ground,orGrounding,islocatedinsidethesupplyterminalboxor
compartment.Thisterminalmustbeconnectedtothegroundingmeansprovidedintheelectricsupplyservicepanel,usinga
connuouscopperwireequivalentinsizetothecircuitconductorssupplyingthisequipment.*accordingto,butnotlimitedto:NEC,
NFPA70,Secon680.40,UL1563.
Atleasttwolugsmarked“BondingLugs”areprovidedontheexternalsurfaceorontheinsideofthesupplyterminalboxor
compartment.Connectthelocalcommonbondinggrid(householdground)intheareaoftheswimspatotheseterminals,using
aninsulatedorbarecopperconductornotsmallerthanNo.6AWG.
Allfield‐installedmetalcomponentssuchasrails,ladders,drainsorsimilarhardwarelocatedwithin5feetoftheswimspaorhot
tubmustbebondedtotheequipmentgroundingbuswithcopperconductorsnotsmallerthanNo.6AWG.
Allmetalsurfaceswithin5feetoftheswimspamustbebondedtothehomebondinggrid.
GROUNDFAULTCIRCUITINTERRUPTERPROTECTION(orequivalent;RCD,forexportinstalls)
AllPDCSpasswimspasarepermanentlyinstalledunits.GROUNDFAULTCIRCUITINTERRUPTERPROTECTIONISREQUIRED.All
swimspaequipmentsystemsmustbeprotectedbyaclassAgroundfaultcircuitinterrupter(GFCI)orequivalent;RCD,forexport
installs.Agroundfaultcircuitinterruptertypecircuitbreaker(NOTSUPPLIED)mustbeinstalledinthehomepanelboxbya
licensedelectricianwhenmakingwireconnecontotheswimspasupportpackequipment.
DANGER:RISKOFELECTRICALSHOCK:
Installtheswimspaatleastfivefeet(1.52m)fromallungrounded(unbounded)metalsurfaces.
Groundfaultcircuitinterrupterproteconofthehomepowersupplytotheswimspaisnecessary.Yourelectricianshouldexplain
howitoperates.(Seeswimspamaintenanceforfunconandtesng)
Donotpermitanyelectricappliance,suchasalight,telephone,radioortelevision,withinfivefeet(1.52m)ofaswimspa.Keep
electricalappliancesandextensioncordsawayfromtheswimspa.Waterisaconductorofelectricity.
DANGER:RISKOFACCIDENTALDROWNING.
Extremecauonmustbeexercisedtopreventunauthorizedaccessbychildren.Toavoidaccidents,ensurethatchildrencannot
useaswimspaunlesstheyaresupervisedatallmes.
DANGER:TOREDUCETHERISKOFDROWNING:
1.Neverusetheswimspaalone.
2.Childrenshouldnotusetheswimspaunlesstheyaresupervisedbyanadult
3.Keeppetsawayfromtheswimspaatallmes.
4.ALWAYSREPLACEANDLOCKTHESWIMSPACOVERWHENTHESWIMSPAISNOTINUSE.
READANDFOLLOWALLIMPORTANTSAFETYINSTRUCTIONS
Wheninstallingandusingthisequipmentbasicsafetyprecauonsshouldalwaysbetakentoreducetheriskofelectricalshock,
toensuresafeusage,andtosafeguardtheuser’shealth.
Safety Instrucons 3
DANGER:TOREDUCETHERISKOFDROWNING
Prolongedimmersionintheswimspamaycausehyperthermia.Thecauses,symptomsandeffectsofhyperthermiamaybe
describedasfollows:Hyperthermiaoccurswhentheinternaltemperatureofthebodyreachesalevelseveraldegreesabovethe
normalbodytemperatureof98.6°F(37°C).Thesymptomsofhyperthermiaincludeanincreaseintheinternaltemperatureofthe
body,dizziness,lethargy,drowsiness,andfainng.Theeffectsofhyperthermiainclude:
1.Failuretoperceiveheat
2.Failuretorecognizetheneedtoexittheswimspa
3.Unawarenessofimpendinghazard
4.Fetaldamageinpregnantwomen
5.Physicalinabilitytoexittheswimspa
6.Unconsciousnessresulnginthedangerofdrowning
DANGER:RISKOFINJURY
Donotremovethesuconfings.Thesuconfinginthisswimspaissizedtomatchthespecificwaterflowcreatedbythe
pump.Shouldtheneedarisetoreplacethesuconfingorthepump,besurethattheflowratesarecompable.Neveroperate
theswimspaifthesuconfingisbrokenormissing.Neverreplaceasuconfingwithoneratedlessthantheflowrate
markedontheoriginalsuconfing.
DANGER:RISKOFACCIDENTALDROWNING
Keephairandbodypartsawayfromthesuconguard.Donotallowlonghairtofloatfreelyinthewater;longhairshouldbe
restrainedwithabathingcap.Toreducetheriskofdrowningfromhairorbodyentrapment,installasuconfing(s)witha
markedflowrateingallonsperminutethatequalsorexceedstheflowratemarkedontheequipmentassembly,ifreplacement
ofsuconfingsbecomesnecessary.
WARNING
Groundfaultcircuitinterrupterprotecon(GFCI)orequivelant;RCD,fortheswimspashouldbetestedpriortoeachusebythe
homeowner.Withtheswimspainoperaon,pushthe“test”buonontheGFCIcircuitbreakeratthepanelbox.Theswimspa
shouldshutdownimmediately.NowresettheGFCI.Theswimspashouldreturntonormaloperaon.IftheGFCIfailstooperate
inthismanner,thereexistsapossibilityofelectricalshock.Approvedtesngappliesforexportprotecondevices,i.e.RCD.
Disconnueswimspaoperaonbydisconnecngthepowersourceandnofyaqualifiedelectricianforidenficaonand
correconoftheproblem.
WARNING
Toreducetheriskofinjury,donotpermitchildrentousethisproductunlesstheyarecloselysupervisedatallmes.
WARNING:TOREDUCETHERISKOFINJURY
Thewaterinaswimspashouldneverexceed104ºF(40°C).Watertemperaturesbetween100°F(38ºC)and104ºF(40°C)are
consideredsafeforahealthyadult.Lowerwatertemperaturesarerecommendedforextendeduse(exceeding10to15minutes)
andforyoungchildren.Neverexerciseorswiminwaterabove90°F(32°c).
Excessivewatertemperatureshaveahighpotenalforcausingfetaldamageduringtheearlymonthsofpregnancy.Pregnantor
possiblypregnantwomenshouldlimitswimspatemperaturesto100ºF(38°C).
Beforeenteringaswimspa,theusershouldmeasurethewatertemperaturewithanaccuratethermometersincethetoleranceof
watertemperatureregulangdevicesmayvaryasmuchas5ºF(3°C).
THEUSEOFALCOHOL,DRUGS,ORMEDICATIONBEFOREORDURINGSWIMSPAUSEMAYLEADTO
UNCONSCIOUSNESSWITHTHEPOSSIBILITYOFDROWNING.
Personssufferingfromobesityorwithamedicalhistoryofheartdisease,loworhighbloodpressure,circulaorysystem
problems,ordiabetesshouldconsultaphysicianbeforeusingaswimspa.
Alwaysconsultwithaphysicianpriortobeginninganyexerciseregimen.Donotoverexertyourself.Takefrequentbreaks.
Safety Instrucons 4
Personsusingmedicaonshouldconsultaphysicianbeforeusingaswimspasincesomemedicaonmayinducedrowsinesswhile
othermedicaonmayaffectheartrate,bloodpressure,andcirculaon.
Enterandleaveswimspaslowlyandwithcauon.Surfacesaroundswimspawillbewetandslippery.
WARNING
1.Neverusetheswimspaalone.
2.Donotbringanyobjectintotheswimspathatcoulddamagetheswimspashell.
3.Donotsitonswimspacoverorplaceobjectsonit;itisnotdesignedtosupportweight.
4.Removeanywaterordebristhatmaycollectontheswimspacover.
5.Keepallchemicalsawayfromchildrenandpets.
6.ThePHandchemicalbalanceofthewatermustbemaintainedasexplainedinthismanual.Failuretodosomaycause
injurytousersordamagetotheswimspa,andwillvoidyourwarranty.
WARNING:HEALTHCONSIDERATIONS
Theuseofalcohol,drugs,medicaoncangreatlyincreaseriskoffatalhyperthermia.
Individualswithinfeconsandopensoresorwoundsshouldnotusetheswimspa.Bacteriathriveinwarmandhotwater.
Alwayskeepyourswimspadisinfectedandmaintaintheproperchemicalbalance.
Showerbeforeandaerusingtheswimspa.Thiswillremoveanydeodorant,perspiraon,orbodyoilsthatcouldcontaminate
thewater.Showeringaerwillremoveanyresidualchemicalsandanybacteriathatmayhavebeenintheswimspa.
Donotusetheswimspaimmediatelyaerstrenuousexercise.
Ifyoufeelpainordizzinessatanymewhileusingtheswimspa,disconnueuseandcontactaphysician.
WARNING:TOREDUCETHERISKOFINJURY
Itisespeciallyimportantforpersonsovertheageof35orpersonswithpre‐exisnghealthproblems,suchasobesity,heart
disease,highbloodpressure,circulatoryproblems,ordiabetestoconsulttheirphysicianbeforeusingtheswimspa.
Theswimspajetsproduceastreamofwaterwithrelavelyhighpressure.Prolongedexposureofalocalizedareaofthebody
maycausebruisestotheskin.
Neverinsertanyobjectintoanyopening.
Donotusebreakablecontainersinorneartheswimspa.
WARNING:ELECTRICALCONSIDERATIONS
Forcontrolsotherthanunderwaterlighngcircuits:AGroundFaultCircuitInterrupter(orequivalentforexportinstalls)mustbe
providedifthisdeviceisusedtocontrolanunderwaterlighngfixture.TheconductorsontheloadsideontheGroundFault
CircuitInterruptershallnotoccupyconduit,boxes,orenclosurescontainingotherconductorsunlesstheaddionalconductors
arealsoprotectedbyaGroundFaultCircuitInterrupter(orequivalentforexportinstalls).
Theelectricalsupplyforthisproductmustincludeasuitablyratedswitchorcircuitbreakertoopenallundergroundsupply
conductorstocomplywithSecon422‐20oftheU.S.NaonalElectricCode.Thedisconnecngmeansmustbereadilyaccessible
totheswimspaoccupantbutinstalledatleast5FT(1.5M)fromtheswimspawater.
WARNING:Forswimspaswithaudio/videocomponents
1.CAUTION‐RiskofElectricShock.Donotleavecompartmentdooropen.
2.CAUTION‐RiskofElectricShock.Replacecomponentsonlywithidencalcomponents.
3.Donotoperatetheaudio/videocontrolswhileinsidetheswimspa.
4.WARNING‐PreventElectrocuon.Donotconnectanyauxiliarycomponents(forexamplecable,addionalspeakers,
headphones,addionalaudio/videocomponents,etc.)tothesystem.
Safety Instrucons 5
5.Theseunitsarenotprovidedwithanoutdoorantennae;whenprovided,itshouldbeinstalledinaccordancewithArcle
810oftheU.S.NaonalElectricalCode,ANSI/NFPA70.
6.Donotservicethisproductyourselfasopeningorremovingcoversmayexposeyoutodangerousvoltageorotherriskof
injury.Referallservicingtoqualifiedservicepersonnel.
7.Whenthepowersupplyconneconorpowersupplycord(s)aredamaged;ifwaterisenteringtheaudio/videocompart‐
mentoranyelectricalequipmentcompartmentarea;iftheprotecveshieldsorbarriersareshowingsignsofdeterioraon;
oriftherearesignsofotherpotenaldamagetotheunit,turnofftheunitandreferservicingtoqualifiedservicepersonnel.
8.Thisunitshouldbesubjectedtoperiodicrounemaintenance(forexample,onceevery3months)tomakesurethatthe
unitisoperangproperly.
ADDITIONALSAFETYCONSIDERATIONS
Installtheswimspatoprovidedrainageforcompartmentsofelectricalcomponents.
Forfloorrecessedswimspas:Installtopermitaccessforservicingfromaboveorbelowthefloor.Swimspaequipmentmust
beinstalledbelowwaterlevel.
Whenplanningyourswimspainstallaonsite,preparefortheunlikelyeventofrapidswimspadrainage.
Donotplaceswimspaindirectsunlightwhileunitisemptyorwhensealedinshippingmaterials.Excessiveheatbuildmay
causedamagetoswimspaandvoidwarranty.
Wheninstallingswimspa,allowamplespaceforfutureservicing,nonglocaonofallsupportequipmentperthemodel
specificaons.
SAVETHESEINSTRUCTIONS
Safety Instrucons 6
Safety Signs 7
WarningDangerSigns
CabinetInstalled:For your referral, safety and convenience, a weather resistant sign has been mounted on the
end cabinet side of your portable swim fitness spa. Become familiar with the precauons, exercise safety and care while
enjoying your swim spa. Nofy the factory or your retailer should you require addional signs or replacements.
WarningSignMustBePosted:An addional copy of this sign can be found packaged with your new swim fitness spa.
This sign must be posted permanently in a prominent area near the swim spa where it is clearly visible to all swim spa
occupants. Post this sign immediately upon installaon. Nofy the factory or your retailer should you require addional
signs or replacements.
WARNING:Readallinstruconsbeforeusingtheswimfitnessspa.PDCSpasassumesnoresponsibilityforpersonal
injuryorpropertydamagesustainedbyorthroughtheuseofthisproduct.
SAVETHISMANUAL,SIGNS,ANDINSTRUCTIONSFORFUTUREREFERENCE.
Important:It is extremely important that this sign be posted permanently placed in
clear view of persons using the swim spa. Occasional swim fitness spa users may not
be aware of some of the dangers hot water poses to pregnant women, small
children, seniors, and people under the influence of alcohol. If you did not receive a
warning sign or your sign has become damaged, please call your local retailer or the
factory for a replacement.
USE #6-3 WITHGROUND
Parts Descripon and Funcon 8
HydrotherapyJets:
Various sized fings mix water with air to produce localized therapy, in a straight stream, circular
moon, or in random paerns for massage. Posioned in massage seats from neck to feet,
RX6 massage columns.
ElitePro™Jets:
This is a large powerful jet (3 on Summit™ Series, 2 on Synergy™ Series, 1 on Vitality™ Series) that
is designed to move water at a high flow rate. The jet features a long horizontal nozzle for a wider,
more powerful and balanced fitness lane.
UltraMassageSelector:(DiverterValve)Located on swim spa lip this fing is much larger than
the air control described below. Turn to adjust pump power to selected jets which enhances water
acon through those jets by decreasing water acon through others. Be sure that no sand or
parcles are brought into the swim spa as they will cause the diverter to seize up. It is best to turn
the diverter valve only when the pump is turned off.
AirControls:Fings mounted on the lip of swim spa controlling amount of outside air mixed with
incoming water of the hydrotherapy jet. Your swim spa has mulple air control on the swim spa lip
that control air/ water mix for a segment of the jets. You choose the strength that best suits you.
When not in use, the air controls should be kept in the offposion.
Sucon:Circular fing mounted on the vercal wall of the footwell and serves as an addional
pump water inlet. These fings are in all Series Fitness and Swim Spas. In the event any damage to
the sucon cover occurs, replace immediately with a like VGB approved sucon. This replacement
must be done every 7 years regardless of damage or not.
Prisne™Filter:All swim and fitness spas are equipped with skim sucon‐side filters. They assure
opmum water filtering and ease of cleaning at spa side. Review the maintenance secon of this
manual for filter cartridge cleaning and replacement.
OzoneJets: All swim fitness spas are equipped with ozone jets for sanitaon. The filter cycle
should circulate 8‐10 hours daily for proper ozonaon. Use the programmable electronic control
center to program this operaon.
Ozonator: Your EverPure2™ system of Ozone and UV is a standard feature on all swim and
fitness spas and operate in conjuncon with your filtraon system. Ozone is a gas, O3, that has
been used for years as a sanitaon treatment for drinking water, and now as a proven purifier
for swim spas and hot tubs. The EverPure2™ offers advanced purificaon with the addion of
the UV element further reducing the use of harsh chemicals for sanitaon and minimizing overall
maintenance. On all dual zone models, the hot tub zone features EverPure™ for ozone
purificaon.
SlideValves: Valves are used to shut offthe water flow to the heater, circulaon pump,
Secondary pump, and Fitness pumps for specific service problems.
SupportPack: The control system operates all funcons of the swim spa. Make sure your
electrician connects the power supply accordingly to all Naonal Electric Code, and shows you
how to test the GFCI circuit breaker (not supplied). This pack is connected to a 50 amp breaker
and for dual zone products; FX219, FX219s and TSX 219, there will be two packs, one for the
fitness zone and another for the spa zone.
SmartTouch™Control:Digital lighted control center operates all pump funcons, temperature
control, scheduled filtraon cycles, lights and workout modes. Refer to the Control secon of this
manual for programming of personalized propulsion speed for custom workouts.
ProView™andAccent™Controls:Used to control all swim spa funcons. The topside is used to
control the water temperature, pumps, spa light, programmable filtraon cycles, and funcons.
The topside will display between the water temperature and the me, as well as display error
codes relang to service needs. (SynergySeriesFX‐ProView™shown.)
CirculaonPump:A dual speed pump designed to use low speed for water filtraon and heang
and a high speed for hydrotherapy. The jets one buon on the topside control will acvate the
circulaon pump. The FX219, FX219s, SX219 and SX219s will have a second circulaon pump for
the spa zone.
Heater:Your swim spa is equipped with a thermostat control at the spa side (topside control).
Set the swim spa at the temperature you enjoy. Leave the thermostat at that seng, and the
swim spa will automacally maintain the correct temperature; ready for your enjoyment anyme.
Avoid constant reseng of the thermostat; it is more economical to maintain temperature.
Never raise the temperature above 104 degrees. Never raise temperature above 86 degrees
for exercising. (HeaterisintegratedintheSupportPackasdescribedabove.)Dual zone models have a
separate heater for both the fitness zone and the hot tub zone allowing the user to control
temperature in each best opmized for acvity or relaxaon.
Parts Descripon and Funcon 9
Secondarypump: A single speed secondary pump has been added to the hot tub zone of the dual
zone models for addional relaxaon and therapy.
Fitnesspumps:Fitness pumps are designed to power the Elite Pro™ jets in both the swim and
fitness units. Refer to the Control Secon of this manual for detail on programming custom and
pre‐programmed workouts maximizing the aquac exercise experience.
LEDLighngPackages;
MoonGlow™:Low voltage underwater swim spa light, with varying shades of a color wash,
controlled at the spa side control panel. Choose rotaon of color or constant color of your choice.
Highlights™LEDLighng: Standard on all swim spa models, includes the MoonGlow™
underwater light with 8‐10 underwater pin lights and 6 water spout lights. Vitality™ Fitness Spas
feature 6 underwater pin lights and MoonGlow™.
Eclipse™ LEDLighng: Oponal for all series, this package includes 16 cabinet sconces on Synergy™
and Summit ™ models. The Vitality™ Fitness spas feature 12 cabinet sconces.
Oasis™LEDLighng:Oponal on Synergy™ and Summit™ Series models only. This package
includes up to 13 topside air and diverter controls enhancing operaon during nighme use.
EverLite2™:Exclusive to all PDC swim and fitness spa models is the cabinet mounted sight glass
which confirms the EverPure2™ ozone and UV purificaon system are properly operang. Dual zone
models also feature this sight glass on the hot tub zone equipped with EverPure™.
WaterSpoutControlValve:Every swim spa model includes 6 water spouts. These two control
valves operate the flow of 3 spouts, one on each side of the unit.
AquaForce™andAquaCross™Mount:The Synergy™ and Summit™ Series models feature the
AquaCross™ tether exercise system as a standard feature, Vitality Series as an opon. The
telescopic pole is securely mounted on the swim spa lip in a stainless steel receptor on the end of
the unit. Assure a ght connecon prior to commencing aquac exercise. As an opon on both the
Synergy™ and Summit™ Series, standard on the Vitality™ fitness spas, the AquaForce™ upper body
rope and pulley fitness equipment also uses a stainless steel grommet for pole inseron. Read this
manual for safety and use instrucons prior to workout.
Parts Descripon and Funcon 10
Fitness Spa Specificaons—Vitality, SL12s Model 11
SPECIAL FEATURES
Highlights™ LED lighting Standard
Stainless Steel Jetting Standard
Eclipse™ LED cabinet lighting Optional
BlueTune™ Audio Optional*
AquaForce™ Trainer AF Standard
AquaCross™ Trainer AC Optional
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Fitness Pump 1 6.0 HP 6.0 HP
Electronics
Electrical Can 6 100NX Neo 2100 Series
Voltage 240 230
Amperage 50 1x32
Heater H 5.5 KW 3.0 KW
Operation System
Main Spa Side Control 7 SL-Accent™ Control Neo 2100 Series
GENERAL rev. 2020/01
Seating Capacity 1 seat, 2 RX6, fitness area
Shell Material Acrylic
Dimensions (Domestic) 144” x 92” x 56”
Dimensions (Export) 366 cm. x 234 cm. x 142 cm.
Water Capacity 1,792 gallons (6,784 liters)
Dry Weight 1,316 lbs. (597 kg.)
Skirt Material Permawood™
Water Flow 230 GPM
Fitness Length 94” approx.
** Not every jet is referenced. Each type of jet is noted for ease of identification. *Note location of audio components prior to install.
All specifications are accurate at time of print. Manufacturer reserves the option to change product without prior notice. Dimensions are approximate.
WATER SYSTEM** (photo ref.)
EverPure2™Treatment System OZ 1
Pristine™ Filter F 2
Slide Valves 2
Elite Pro™ Jet S 1
Euro Jet w/ Eyeball E 8
Mega’ssage™ Jet G 4
Ozone Jet O 2
Diverter Valves V 1
Safety Suction U 2
Air Control I 4
MotionGlow™ Light L 1
Large Euro Jet LE 6 U
U
V
I
I
E
E
E
E
G
AF
G
F
I
I
F O
O
LE
LE LE
L
S
OZ 6 H
1
7
Fitness Spa Specificaons—Vitality, SL12 Model 12
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Fitness Pump 1 6.0 HP 6.0 HP
Electronics
Electrical Can 6 100NX Neo 2100 Series
Voltage 240 230
Amperage 50 1x32
Heater H 5.5 KW 3.0 KW
Operation System
Main Spa Side Control 7 SL-Accent™ Control Neo 2100 Series
GENERAL rev. 2020/01
Seating Capacity 1 seat, recliner, fitness area
Shell Material Acrylic
Dimensions (Domestic) 144” x 92” x 56”
Dimensions (Export) 366 cm. x 234 cm. x 142 cm.
Water Capacity 1,835 gallons (6,946 liters)
Dry Weight 1,316 lbs. (597 kg.)
Skirt Material Permawood™
Water Flow 230 GPM
Fitness Length 76” approx.
** Not every jet is referenced. Each type of jet is noted for ease of identification. *Note location of audio components prior to install.
All specifications are accurate at time of print. Manufacturer reserves the option to change product without prior notice. Dimensions are approximate.
WATER SYSTEM** (photo ref.)
EverPure2™Treatment System OZ 1
Pristine™ Filter F 2
Slide Valves 2
Elite Pro™ Jet S 1
Euro Jet w/ Eyeball E 18
Mega’ssage™ Jet G 4
Ozone Jet O 2
Diverter Valves V 1
Safety Suction U 2
Air Control I 2
MotionGlow™ Light L 1
Large Euro Jet LE 2 U
U
V
E
E
AF
F
I
I
F
O O
S
L
7
SPECIAL FEATURES
Highlights™ LED lighting Standard
Stainless Steel Jetting Standard
Eclipse™ LED cabinet lighting Optional
BlueTune™ Audio Optional*
AquaForce™ Trainer AF Standard
AquaCross™ Trainer AC Optional
AC
OZ 6 H
1
LE
G
G
7
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Fitness Pump 1 6.0 HP 6.0 HP
Electronics
Electrical Can 6 100NX Neo 2100 Series
Voltage 240 230
Amperage 50 1x32
Heater H 5.5 KW 3.0 KW
Operation System
Main Spa Side Control 7 SL-Accent™ Control Neo 2100 Series
GENERAL rev. 2020/01
Seating Capacity 1 seat, 2 RX6, fitness area
Shell Material Acrylic
Dimensions (Domestic) 180” x 92” x 56”
Dimensions (Export) 457 cm. x 234 cm. x 142 cm.
Water Capacity 2,240 gallons (8,479 liters)
Dry Weight 1,570 lbs. (712 kg.)
Skirt Material Permawood™
Water Flow 230 GPM
Fitness Length 130” approx.
** Not every jet is referenced. Each type of jet is noted for ease of identification. *Note location of audio components prior to install.
All specifications are accurate at time of print. Manufacturer reserves the option to change product without prior notice. Dimensions are approximate.
WATER SYSTEM** (photo ref.)
EverPure2™Treatment System OZ 1
Pristine™ Filter F 2
Slide Valves 2
Elite Pro™ Jet S 1
Euro Jet™ w/ Eyeball E 8
Mega’ssage™ Jet G 4
Ozone Jet O 2
Diverter Valves V 1
Safety Suction U 2
Air Control I 4
MotionGlow™ Light L 1
Large Euro Jet LE 6 U
U
V
I
I
E
E
E
E
G
AF
G
F
I
I
F O
O
LE
LE
LE
L
S S
S
SPECIAL FEATURES
Highlights™ LED lighting Standard
Stainless Steel Jetting Standard
Eclipse™ LED cabinet lighting Optional
BlueTune™ Audio Optional*
AquaForce™ Trainer AF Standard
AquaCross™ Trainer AC Optional
OZ 6 H
1
Fitness Spa Specificaons—Vitality, SL15s Model 13
I
E
E
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Fitness Pump 1 6.0 HP 6.0 HP
Electronics
Electrical Can 6 100NX Neo 2100 Series
Voltage 240 230
Amperage 50 1x32
Heater H 5.5 KW 3.0 KW
Operation System
Main Spa Side Control 7 SL-Accent™ Control Neo 2100 Series
GENERAL rev. 2020/01
Seating Capacity 1 seat, recliner, fitness area
Shell Material Acrylic
Dimensions (Domestic) 180” x 92” x 56”
Dimensions (Export) 457 cm. x 234 cm. x 142 cm.
Water Capacity 2180 gallons (8,252 liters)
Dry Weight 1,570 lbs. (712 kg.)
Skirt Material Permawood™
Water Flow 230 GPM
Fitness Length 112” approx.
** Not every jet is referenced. Each type of jet is noted for ease of identification. *Note location of audio components prior to install.
All specifications are accurate at time of print. Manufacturer reserves the option to change product without prior notice. Dimensions are approximate.
WATER SYSTEM** (photo ref.)
EverPure2™Treatment System OZ 1
Pristine™ Filter F 2
Slide Valves 2
Elite Pro™ Jet S 1
Euro Jet w/ Eyeball E 18
Mega’ssage™ Jet G 4
Ozone Jet O 2
Diverter Valves V 1
Safety Suction U 2
Air Control I 2
MotionGlow™ Light L 1
Large Euro Jet LE 2
U
U
V
7
AF
G
F
I
F O
O
L
S
SPECIAL FEATURES
Highlights™ LED lighting Standard
Stainless Steel Jetting Standard
Eclipse™ LED cabinet lighting Optional
BlueTune™ Audio Optional*
AquaForce™ Trainer AF Standard
AquaCross™ Trainer AC Optional
AC
OZ 6 H
1
G
LE
Fitness Spa Specificaons—Vitality, SL15 Model 14
Swim Spa Specificaons—Synergy, FX15 Model 15
GENERAL rev. 2020/01
Seating Capacity 2 seats, 2 RX6, fitness area
Shell Material Acrylic
Dimensions (Domestic) 180” x 92” x 56”
Dimensions (Export) 427 cm. x 234 cm x 142 cm.
Water Capacity 2,140 gallons (8,100 liters)
Dry Weight 1,645 lbs. (746 kg.)
Skirt Material Permawood™
Water Flow 647 GPM
Fitness Length 112” approx.
SPECIAL FEATURES
Spa Pillows 1
Highlights™ LED lighting Standard
Stainless Steel Jetting Standard
Eclipse™ LED cabinet lighting Optional
BlueTune™ Audio Optional*
Oasis™ LED lighting Optional
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Spa Pump 1 4.0 HP 4.0 HP
Swim Pump #1 2 6.0 HP 6.0 HP
Swim Pump #2 3 6.0 HP 6.0 HP
Electronics
Electrical Can 6 501X1 Neo 2100 Series
Voltage 240 230
Amperage 50 1x32
Heater H 5.5 KW 3.0 KW
Operation System
Main Spa Side Control 7 FX-ProView™ Control Neo 2100 Series
WATER SYSTEM** (photo ref.)
EverPure2™ Treatment System UV/C 1
Pristine™ Filter F 2
Slide Valves 6
Large Euro Jet w/ Eyeball E 26
Mega’ssage™ Jet G 10
Ozone Jet O 2
Diverter Valves V 1
Safety Suction U 6
Air Control I 6
MotionGlow™ Light L 1
Elite Pro™ Jet S 2
Lighted Water Spouts W 6
Water Spout Control CV 2
U
U
U U
U
U
7
S S
V
I I
E
E
E
E
G G
G
F
2 3
UV/C
I
I
1 H 6
F O
O
E
E
L
I I
U
U
W
W
W
W
W
W
CV
CV
** Not every jet is referenced. Each type of jet is noted for ease of idenficaon. *Note locaon of audio components prior to install.
All specificaons are accurate at me of print. Manufacturer reserves the opon to change product without prior noce. Dimensions are approximate.
Swim Spa Specificaons—Synergy, FX15s Model 16
SPECIAL FEATURES
Spa Pillows
Highlights™ LED lighting Standard
Stainless Steel Jetting Standard
Eclipse™ LED cabinet lighting Optional
BlueTune™ Audio Optional*
Oasis™ LED lighting Optional
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Spa Pump 1 2.0 HP 4.0 HP
Swim Pump #1 2 6.0 HP 6.0 HP
Swim Pump #2 3 6.0 HP 6.0 HP
Electronics
Electrical Can 6 501X1 Neo 2100 Series
Voltage 240 230
Amperage 50 1x32
Heater H 5.5 KW 3.0 KW
Operation System
Main Spa Side Control 7 FX-ProView™ Control Neo 2100 Series
GENERAL rev. 2020/01
Seating Capacity 1 seat, 2 RX6, fitness area
Shell Material Acrylic
Dimensions (Domestic) 180” x 92” x 56”
Dimensions (Export) 427 cm. x 234 cm x 142 cm.
Water Capacity 2,240 gallons (8,479 liters)
Dry Weight 1,645 lbs. (746 kg.)
Skirt Material Permawood™
Water Flow 647 GPM
Fitness Length 130” approx.
** Not every jet is referenced. Each type of jet is noted for ease of idenficaon. *Note locaon of audio components prior to install.
All specificaons are accurate at me of print. Manufacturer reserves the opon to change product without prior noce. Dimensions are approximate.
WATER SYSTEM** (photo ref.)
EverPure2™ Treatment System UV/C 1
Pristine™ Filter F 2
Slide Valves 6
Large Euro Jet w/ Eyeball E 8
Mega’ssage™ Jet G 10
Ozone Jet O 2
Diverter Valves V 1
Safety Suction U 6
Air Control I 5
MotionGlow™ Light L 1
Elite Pro™ Jet S 2
Lighted Water Spouts W 6
Water Spout Control CV 2
Bypass Jet B 2
U
U
U
U
U
7
S
S
V
I I
E
E E
E
G
G
G
F
2 3
UV/C
I I
1 H 6
F
O
O
B
B
U
W
W
W
W
W
W
CV CV
L
Swim Spa Specificaons—Synergy, FX17 Model 17
GENERAL rev. 2020/01
Seating Capacity 2 seats, 2 RX6, fitness area
Shell Material Acrylic
Dimensions (Domestic) 204” x 92” x 56”
Dimensions (Export) 518 cm. x 234 cm x 142 cm.
Water Capacity 2,420 gallons (9,161 liters)
Dry Weight 1,784 lbs. (810 kg.)
Skirt Material Permawood™
Water Flow 647 GPM
Fitness Length 136”
SPECIAL FEATURES
Spa Pillows 1
Highlights™ LED lighting Standard
Stainless Steel Jetting Standard
Eclipse™ LED cabinet lighting Optional
BlueTune™ Audio Optional*
Oasis™ LED lighting Optional
ELECTRICAL SYSTEM
Pump Information Reference Number Domestic (60Hz) Export (50Hz)
Spa Pump 1 4.0 HP 4.0 HP
Swim Pump #1 2 6.0 HP 6.0 HP
Swim Pump #2 3 6.0 HP 6.0 HP
Electronics
Electrical Can 6 501X1 Waterway Neo 2100 Series
Voltage 240 230
Amperage 50 1x32
Heater H 5.5 KW 3.0 KW
Operation System
Main Spa Side Control 7 FX-ProView™ Control Waterway Neo 2100 Series
WATER SYSTEM** (photo ref.)
EverPure2™ Treatment System UV/C 1
Pristine™ Filter F 2
Slide Valves 6
Large Euro Jet w/ Eyeball E 26
Mega’ssage™ Jet G 10
Ozone Jet O 2
Diverter Valves V 1
Safety Suction U 6
Air Control I 6
MotionGlow™ Light L 1
Elite Pro™ Jet S 2
Lighted Water Spouts W 6
Water Spout Control CV 2
** Not every jet is referenced. Each type of jet is noted for ease of idenficaon. *Note locaon of audio components prior to install.
All specificaons are accurate at me of print. Manufacturer reserves the opon to change product without prior noce. Dimensions are approximate.
U
U U
U
U
7
S
V
I I
E
E
E
E
G
G
G
F
2 3
UV/C
I
I
1 H 6
F O O
E
E
L
I I
U
S
W
W
W
W
W
W
CV
CV
U U
This manual suits for next models
18
Table of contents
