pear wireless
Series 100
Wall Access Point
User Manual
Version 1.1
61-3001A-03
™

Table of Contents
1. Introduction 1
2. Wireless LAN Basics 2
3. Hardware Overview 4
3.1 Internal Layout 4
3.2 LED Layout 5
3.3 Installation 5
4. PEAR Wireless WWAP Management Software 6
4.1 PEAR Wireless Quickstart Utility 7
4.1.1 Select Wireless Ethernet Device 7
4.1.2 IP Settings 9
4.1.3 Static IP Settings 10
4.1.4 Gateway Settings 10
4.1.5 Ready to Start the Web Interface 11
4.2 Contents of Web Interface 12
4.2.1 Settings Summary 12
4.2.2 Wireless Settings 13
4.2.3 Security Against Unauthorized
Network Access 14
4.2.4 Security Against Eavesdropping 17
4.2.5 Security Against Unauthorized
Configuration 20
4.2.6 Identity 22
4.2.7 IP Settings 23
5. Technical Specifications 24

pear wireless
™
User Manual
pear wireless
™
Wall
Access Point
Page
1
1. Introduction
Thank you for purchasing your Pear Wireless Wall Access Point. Since all
PEAR Wireless products are IEEE 802.11b compliant, you are assured of
interoperability with other wireless networking products adhering to the standard
that has brought wireless networking to the mainstream of enterprise and home
networking.
With Pear Wireless Network products, you can transparently transmit and
receive data at rates up to 11 Mbps—all without the need for wired connections
to your local LAN. Follow our easy-to-use installation and configuration steps.
In no time, you’ll be enjoying the freedom of wireless network access. This
manual will assist you with the installation procedure and the operation of your
new Pear Wireless product.
The package you have received should contain the following items.
•Pear Wireless Wall Access Point
•Power Adaptor
•User Manual (this document)
•CD ROM containing Pear WWAP Manager Software
•Quick Start Guide
•Warranty Card
•Registration Card
Note: If anything is missing, please contact the Pear Wireless Technical
Support Center or your local vendor.
A Wireless LAN (WLAN) is normally used as an extension of your current wired
Ethernet network. Wall Access Points are specifically mounted in places where
area coverage is optimized. These Wall Access Points are connected to a
wired network to communicate with each other and with servers and clients on
that network.
The Wall Access Point can be connected to a 10/100 Mbps Ethernet network
through a standard RJ45 (UTP) connector.

pear wireless
™
Page
2
pear wireless
™
Wall Access Point User Manual
2. Wireless LAN Basics
Wireless LAN (Local Area Network) systems offer many advantages over a
traditional, wired network. WLANs are more flexible, easier to setup and
manage, and often more cost effective than their wired equivalent.
Using radio frequency (RF) technology, WLANs transmit and receive data over
the air, minimizing the need for wired connections. Thus, WLANs combine data
connectivity with user mobility and, through simplified configuration, enable
movable LANs.
Figure 1. Wireless Local Area Network
With wireless LANs, users share information without looking for a place to plug
in. Network managers can set up or augment networks without installing or
moving wires. Wireless LANs offer the following productivity, convenience, and
cost advantages over traditional wired networks.
•Mobility -Wireless LAN systems can provide LAN users with access to
real-time information anywhere in the organization. This mobility supports
productivity and service opportunities not possible with wired networks.
•Installation Speed and Simplicity -Installing a wireless LAN system can
be fast and easy and can eliminate the need to pull cable through walls
and ceilings.

pear wireless
™
User Manual
pear wireless
™
Wall
Access Point
Page
3
•Installation Flexibility -Wireless technology allows the network to go
where wires cannot go.
•Reduced Cost-of-Ownership -While the initial investment required for
wireless LAN hardware might be higher than the cost of wired LAN
hardware, overall installation expenses and life-cycle costs will be
significantly lower. Long-term cost benefits are greatest in dynamic
environments requiring frequent moves, additions, and changes.
•Scalability -Wireless LAN systems can be configured in a variety of
topologies to meet the needs of specific Applications and installations.
Configurations are easily changed and range from peer-to-peer networks
suitable for a small number of users to full infrastructure networks of
thousands of users that allow roaming over a broad area.

pear wireless
™
Page
4
pear wireless
™
Wall Access Point User Manual
3. Hardware Overview
Your Pear Wireless Wall Access Point offers elegant designing with
effectiveness by combining a Wall antenna and an access point into one
package.
Figure 2. PEAR Wireless Series 100 Wall Access Point
3.1 Internal Layout
Figure 3. Wall Access Point Internal Layout
The internal layout features a splitter, antenna and radio, and the Reset button.
See Section ??? for instructions on resetting a Wall Access Point.
Splitte
r
Antenna and
radio
Reset button

pear wireless
™
User Manual
pear wireless
™
Wall
Access Point
Page
5
3.2 LED Layout
Figure 4. Wall Access Point LEDs
On the bottom of the Wall Access Point you will see three LEDs.
•ACT –the ACT LED indicates wireless activity
•Power –the Power LED indicates power is being supplied to the
WWAP
•LINK –the LINK LED indicates activity on the wired network
3.3 Installation
Please refer to the installation manual.
LINK LED
Power LED
ACT LED

pear wireless
™
Page
6
pear wireless
™
Wall Access Point User Manual
4. Pear Wireless WWAP Management Software
The Pear Web Management Software and Quickstart application provide a
consistent view of the wireless network. The system administrator can use it to
control a large number of Access Points from a single location.
Supported features include:
•Configuring Access Points with Browser based web pages.
•Restricting access to the wireless network
•Managing data protection options such as IEEE 802.11b Wired Equivalent
Privacy (WEP)
•Assigning radio channels for optimal cell management
•Forming multiple WLANs (containing one or more Access Points) with
individual access control and security options
•Programming a Access Point with a specified IP address
•Setting the SNMP Write Community string
•Verifying the status of all Access Points in the network

pear wireless
™
User Manual
pear wireless
™
Wall
Access Point
Page
7
4.1 Pear Wireless Quickstart Utility
To launch QuickStart, double click the QuickStart icon.
Figure 5. Quickstart Opening Window
When you click Next, QuickStart will search for all Access Points within range,
whether they have been configured properly or not.
4.1.1 Select Wireless Ethernet Device
You can select the device you want to manage from the list as showed below.

pear wireless
™
Page
8
pear wireless
™
Wall Access Point User Manual
Figure 6. Select Wireless Ethernet Device Window
After that you can click on Next to continue to the next screen, or click on
Rescan to rescan for a wireless device.
Device Information
The Scan Screen contains information about the wireless devices that were
found.
Name:
The (optional) name of the AP
MAC address:
Every Ethernet device has a unique address that is permanently linked to
that device. It cannot be changed.
IP address:
In order to access a TCP/IP network, a device must have an IP address.
SSID:
The SSID is also known as Service Set ID. This is the name of the
wireless network that the AP belongs to.

pear wireless
™
User Manual
pear wireless
™
Wall
Access Point
Page
9
Location: The (optional) physical location of the AP.
Contact: The (optional) name of a contact person who is responsible for
this AP.
Scanning and rescanning for devices
If the device that you want to manage is in the list, select it, and click Next. If
you click the Rescan button, QuickStart will search fo
r Access Points again.
Use this to find Access Points that have just been switched on or reset.
4.1.2 IP settings
In this screen you can select to either use dynamic (if DHCP is available) or
static IP settings.
Figure 7. IP Settings Window
Select Dynamic IP settings when you install the Access Point in a network with
a DHCP server or Auto IP. Select Static IP settings when you want to configure
the IP settings manually. Click on the Next button to continue to the next
screen.

pear wireless
™
Page 10 pear wireless™ Wall Access Point User
Manual
•If you selected the option “Use dynamic IP settings” you will continue to the
screen of Changing IP settings directly.
•If you selected the option “Use static IP settings” you will continue to the
screen Set IP address of Wireless Device.
4.1.3 Static IP settings
When you have selected the option “Use static IP settings,” the screen below
appears:
Figure 8. Static IP Settings Window
In this screen you can either manually insert the IP address and Subnet mask,
or you can click on the button of “Suggest” to
let the system find the IP settings.
Click Next to continue to the next screen.

pear wireless
™
User Manual
pear wireless
™
Wall
Access Point
Page
11
4.1.4 Gateway Settings
In this screen you can install the Gateway address of the wireless device. Click
on Next to continue to the next screen.
Figure 9. Gateway Settings Window
4.1.5 Ready to start the Web Interface
If you click Finish in this screen, QuickStart will launch a Web browser and open
the Web management software page (Web interface) for the Access Point you
have chosen. Then QuickStart quits.

pear wireless
™
Page 12 pear wireless™ Wall Access Point User
Manual
Figure 10. Quickstart End Window
Web Interface is launched
Once the QuickStart application has finished and the Access Point is available
for configuration in the network, the Web Management Software is launched in
a web browser. You can now edit the settings for the Access Point.
4.2 Contents of Web Interface
The Web Management Software contains the following subjects:

pear wireless
™
User Manual
pear wireless
™
Wall
Access Point
Page
13
4.2.1 Settings Summary
On this page you will find an overview of the current settings.
Figure 11. Wireless Settings Summary Window

pear wireless
™
Page 14 pear wireless™ Wall Access Point User
Manual
4.2.2 Wireless Settings:
The wireless settings such as SSID and channel are displayed and can be
edited here.
Figure 12. Wireless Settings Window
SSID : This is the Service Set ID. Only Access Points and clients that share the
same SSID are able to communicate with each other.
Radio Channel: This is the channel that the Access Point uses to transmit and
receive information. The channel that you select here is restricted to the
channels that can be used within your Regulatory domain.
Regulatory Domain: The Regulatory domain is displayed here. Every country
has a Regulatory Domain concerning radio channels that can be used to
transmit and receive signals. This setting is a factory default that cannot
be changed.
