Pearller HY880MBT User manual

www.pearller.com
Instruction manual
HY880MBT
P.A. system Amplifier

32
Thank you for choosing
Pearller brand
The Pearller product you have purchased is the result of careful planning by specialized engineers. High quality
materials were used for its construction, to ensure its functioning over time. The product is manufactured in
compliance with the strict regulations imposed by the European Union, a guarantee of reliability and safety.
We suggest to read this manual carefully before starting using the device in order to take advantage of its full
potential.
Hoping that you will be satisfied of your purchase, we thank you again for your trust in our brand and we invite you
to read our website www.pearller.com where you will find the whole range of Pearller products, along with useful
information and updates.
This amplifier has been designed for “P.A. system“ purposes. It is used for example in offices, schools,
churches, shops, shopping centers, restaurants, convention centers, auditoriums, etc.
Its advanced protection systems prevent damages caused by short circuits, overheating and overloads and
make it safe and reliable.
It comes with 2 microphone inputs, 2 line inputs, and speaker terminals both for 4/8 Ohm and 70/100V
operation.
It is provided with Mp3 module for music track playback, tuner and bluetooth receiver to connect smartphones
or tablets.

32
Shipments and complaints
When purchasing or receiving the product, open the box and carefully check the content to make sure that all
parts are present and in good condition. Immediately notify the seller of any transport damage suffered by the device. If
you send the product for repair, it must be shipped with complete original packaging: we therefore recommend to keep it
along with invoice or the purchase receipt.
Cautions and warnings
• Read carefully the instructions given in this manual and follow them strictly.
• Keep this manual for future reference and include it if you give the product to another user.
• This device works with dangerous 250V mains power. Do not open, do not disassemble and don’t try to operate
inside. In case of wrong use an electric shock may occur.
• Contact a specialized technician for the installation.
• Always make sure to connect the device to a power outlet with the correct voltage.
• Avoid using the unit: in places with temperatures above 35°C, or in places exposed to rain, humidity, impacts and
vibrations.
• Do not allow flammable liquid, water or objects to enter the product.
• Install the product in a ventilated position, far from heat sources and don’t obstruct the air vents.
• In the event of a serious operating problem, stop using the product immediately. Never try to repair it by yourself, but
contact the authorized technical service center. Repairs carried out by unskilled persons could lead to serious
damages both to the fixture and to people.
• Disconnect the unit from power when it is not used.
• Wait for the product to cool before cleaning or maintenance.
• If the product doesn’t turn on, check the fuse and if necessary replace it with one of the same type and rating, after
disconnecting the fixture from power.
• Do not turn the product on and off at short intervals, it may reduce the life of the device.
• Never disconnect the product from the power source by pulling on the cord.
• Periodically check the condition of the power cord.

54
+
-Total = 16Ω
4Ω 4Ω 4Ω 4Ω +
-
Total = 4Ω
16Ω 16Ω 16Ω 16Ω
Total= 4Ω with 400W total power
2 speakers x
8 Ω= 16 Ω4 speakers x
4 Ω= 16 Ω
2 speakers x
8 Ω= 16 Ω
16 Ω
8Ω 4Ω 8Ω
8Ω
4Ω
4Ω
4Ω
100
W
50
W
25
W
8Ω
50
W
25
W
25
W
25
W
50
W
50
W
Before making any connection, be sure that the unit is unplugged from the power outlet.
All connections must be made with the appliance turned o.
Impedance speaker connection
This type of connection does not allow to limit individually the power of each single speaker, but it gives the possibility to
obtain higher performances. The main rule to be respected is that the total impedance of the speakers must be
compatible with the impedances supported by the amplifier where the speakers will be connected (4-8 Ω). If you use
more than one speaker, the value of impedance will be added up (in case of series wiring) or divided (in case of parallel
wiring).
If you connect only one speaker you have to consider the impedance of the speaker itself. Mixed connections are also
possible. Below are two examples:

54
Constant voltage speaker
connection
It is the type of monophonic system realized in shops, conference rooms, churches and in any place where a
uniform sound reinforcement is necessary, with maximum ease of installation and use. Only 2 wires are
used, starting from the amplifier and getting up to the last speaker. On the amplifier you have to connect a wire
to the “com” (common) terminal and the other wire to the 100V terminal.
The two wires will go all around the installation, and they will be connected to the speakers or rather the
transformers each speaker is equipped with.
100V
com
15W 20W
30W5W
20W
60W Amplier
EXAMPLE: You connect to the system 5 speakers for
a total of 90W. The amplier handles up to 110W: so in
the future you will be able to connect other speakers,
up to reach the amplier’s maximum power.

76
Front
Back
USB 26:26 USB AUX
SD
M
ECHO
MIN MAX
MIC 2
MIN MAX
BASS
-10dB +10dB
TREBLE
-10dB +10dB
MIC 1
MIN MAX
TIME
MIN MAX
LINE 2
MIN MAX
LINE 1
MIN MAX
MIN MAXVOL
Model: PAA 100TP
AC IN
230V 130W
T1.6A
MUTE COM 4Ω8Ω70V 100V
DC IN
12-24V MAX 5A
- +
OUTPUT INPUT
L
R
LINE 1 LINE 2 MIC 1 MIC 2 FM ANT
MODE
EQ
100+
VOL-
7 8 9
4 5 6
1 2 3
0
VOL+
+
PREV NEXT PLAY/PAUSE
MUTE SPEAKER OUTPUTS
-
+
12-24V
COM 4Ω 8Ω 70V 100V
FUSE
T2A
210-240V AC 50Hz 0,6A
P650C
60WRMS
L
R
L
R
AUX PHONO
INPUTS
MIC 2 MIC 1 FM ANT
PRIORITY
OFF ON
MODE
EQ
100+
VOL-
7 8 9
4 5 6
1 2 3
0
VOL+
+
PREV NEXT PLAY/PAUSE
blue USB
SD/MMC CARD
MODE Model: PAA 100T
POWER
10 11
912
8
713
6 14
155
416
3 17
2 18
119
0 20
-10 +10
TREBLE
-10 +10
BASS
MIN MAX
AUX
MIN MAX
PHONO
MIN MAX
MIC 2
MIN MAX
MIC 1
REPEAT
7
6
18 2
9
34 5
11
10
12 13 14 15 16 17 18 19

76
Functions
1. MIC 1 SOCKET
6,3mm jack to connect dynamic microphones.
This socket is endowed with priority function to
reduce the other sources’ signal. This function
cannot be disabled.
2. MIC 2 SOCKET
6,3mm jack to connect dynamic microphones.
This socket is endowed with priority function to
reduce the other sources’ signal. This function
cannot be disabled.
3. MIC 1
It adjusts the volume’s level of the signal
connected to the MIC1 socket(1).
4. MIC 2
It adjusts the volume’s level of the signal
connected to the MIC2 socket(2).
5. AUX 1
It adjusts the volume’s level of the signal
connected to the LINE IN 1 socket.
6. AUX 2
It adjusts the volume’s level of the signal
connected to the LINE IN 2 socket.
7. VOL
It adjusts the master output volume.
8. ON/OFF
9. MULTIMEDIA MODULE
It offers the possibility to play Mp3 files from
USB/ SD and AUX socket, manage bluetooth
connections and play FM radio.
10. POWER SOCKET
Plug here the supplied cable and connect it to a
common 110-230V household power outlet.
11. DC POWER
Thanks to these terminals it is possible to
connect or 12V external batteries, to use the
amplifier also on vehicles.
12. MUTE
It turns off the volume of all the signals.
It is mainly used by external fixtures to play
high priority or alarm messages.
13. COM
Negative pole (-) terminal for speaker
connection.
14. 4Ω/ 8Ω
Positive pole terminals (+), used along with the
connector COM (16) to connect speakers for 4Ω/
8Ω impedance operation.
15. 70V/100V
Positive pole terminals (+), used along with the
connector COM (16), to connect speakers for
70V/ 100V operation.
16. OUTPUT SOCKETS (RCA)
They supply a line signal for amplifiers,
recorders or other external fixtures.
17. LINE IN 1
RCA sockets to connect line sources (PC, CD,
DVD...)
18. LINE IN 2
RCA sockets to connect line sources (PC, CD,
DVD...)
19. FM ANT SOCKET
Socket to connect the FM antenna

8
8
A) Display
B) USB Socket: use this socket to connect your pen drive or external disk to the unit using
USB interface (note: mobile disk memory must be less than 64GB.)
C) TF Card Slot: use this socket to connect your memory card to the unit by TF card. (note: TF
card memory must be less than 64GB.)
D) Mode: it allows to select among USB/TF/ Bluetooth/ FM
E) Previous button: press to move the input to previous track in MP3 & Bluetooth mode, hold
for a few seconds to reduce the current MP3 or Bluetooth media volume.
F) Play/pause: press once to begin playing, press again to pause.
G) Next button: press to move the input to next track in MP3 & Bluetooth mode, hold for a few
seconds to increase the current MP3 or Bluetooth media volume.
H) Repeat button: here are 4 preset repeat modes. Press once to repeat button, and the LEDs
meter will be display "Fold", that unit will be on repeat all track in Folder, press it again and
the LEDs meter will be display "ONE", that unit into repeat current track. Press it third times
and LEDs meter will be display "RAN", that unit into random play mode. Press it fourth
times and LEDs meter will be display "ALL", that unit will be on repeat all track.
MODE
EQ
100+
VOL-
7 8 9
4 5 6
1 2 3
0
VOL+
+
PREV NEXT PLAY/PAUSE
MUTE SPEAKER OUTPUTS
Model: PAA 100T
POWER
10 11
912
8
713
6 14
155
4 16
3 17
2 18
119
0 20
-10 +10
TREBLE
-10 +10
BASS
MIN MAX
AUX
MIN MAX
PHONO
MIN MAX
MIC 2
MIN MAX
MIC 1
-
+
12-24V
COM 4Ω 8Ω 70V 100V
FUSE
T2A
210-240V AC 50Hz 0,6A
P650C
60WRMS
L
R
L
R
AUX PHONO
INPUTS
MIC 2 MIC 1 FM ANT
PRIORITY
OFF ON
The manufacturer, in order to improve its products, reserves the right to modify their characteristics whether technical or aesthetic, at
any time and without notice.
USB 26:26 USB
TF M
D E F G
CH
BLUETOOTH
This amplifier includes the bluetooth function to receive audio from smartphones and tablets
without using connection cables. To activate the function press the “mode” button (D) on the
multimedia module : the word “BLUE” will appear on the display. Enter the bluetooth setup menu of
your phone and scan for the amplifier to pair it. From this moment on, all the audio from your
phone will be sent to the amplifier.
FM RADIO
Using the mode button select the Radio function. Through the other keys you can
search for the desired radio station. Make sure you have connected the antenna to the FM
socket(19).
B
A

11
9
This symbol alerts you of the presence of important operating and maintenance instructions, in the manual or in
the documentation accompanying the product.
This symbol alerts you to the presence of uninsulated dangerous voltage within the product’s enclosure that might be
of sufficient magnitude to constitute a risk of electric shock. Do not open the product’s case.
To prevent possible hearing damage, do not listen at high volume levels for long periods.
The CE mark indicates that this product complies with the applicable European directives and their related standards.
Compliance documentation in complete form is available at the company Karma Italiana Srl
Directive 2012/19/UE regarding electric and electronic equipment waste (WEEE). The symbol of the crossed-out dustbin
indicates that the product at the end of its life must be collected separately from other waste . The user must ,
therefore , confer the fixture complete with all the essential components to an authorized disposal center for collection of
electronic and electrical waste, or return it to the dealer when buying new equipment of equivalent type, at a rate of one to
one, or one to zero if external dimension is less than 25cm. Appropriate separate collection to send the decommissioned
equipment to recycling , treatment and environmentally compatible disposal helps to prevent negative impact on the
environment and human health and promotes recycling of the materials making up the product. In Italy illegal dumping of
the product by the user entails the application of administrative sanctions pursuant to Legislative Decree n. 49
(14/03/2014).
The product’s remote control contains a battery which, according to the European Directive 2013/56/EU, cannot be
disposed of with normal household waste. Please inquire about the local regulations regarding the separate collection of
batteries: a correct disposal allows to avoid negative consequences for the environment and health.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER, CONTAINS NO USEFUL PARTS FOR THE USER.
REFER TO QUALIFIED STAFF FOR ASSISTANCE.

10
10
Made in China
www.pearller.com
TECHNICAL SPECIFICATIONS
Power 50W
Power supply 90VAC ~ 250VAC @ 50/60Hz; 12VDC
Output Impedance 4 - 8 Ohm
Constant voltage 70V - 100V
Line inputs 2
Mic inputs 2
MP3 player USB / TF / BT
Bluetooth Yes - Freq. 2.4Ghz
Other functions FM radio / Mute
Fuse 3A
Frequency response 20 Hz- 20 KHz; +/- 2dB
Dimensions 240 x 53 x 255 mm
