8” WHIRL GEN-2
OWNER’S MANUAL
OPERATING INSTRUCTIONS -MAINTENANCE -SAFETY -
TROUBLESHOOTING
This manual contains very important safety warnings and information.
Read and save these instructions for future reference.
Serial No.
Purchase Date
Dealer
Pearson Industries •5420 Newport Drive STE 56 •Rolling Meadows, IL 60008 •Phone: [phone]
1-888-3 •Fax: [phone] •Toll Free 888-364-9836
Rolling Meadows, IL 60008

MOTOR SPECIFICATONS
USA
www. WHIRL GEN-2
Voltage 115VAC~
Phase Single
Frequency 50/60 Hz
Electric Motor 1/3 H.P.
Current (amps) 2.2
R.P.M. 3450
Max. S.P. 1.8”
AIR FLOW RATES CFM M3/min.
Free Air 868 24
DIMENSIONS
Size 8” diameter (203 mm)
Weight 16 lbs. (7 kg)
Height 14” (356 mm)
Length 13” (330 mm)
Width 13” (330 mm)
pearsonind.com
Tel: [phone]
5420 Newport Dr. Suite 56
5420 Newport Drive Suite 56 • Rolling Meadows, IL 60008
Tel: [phone] • Fax [phone]
Toll Free: 888-364-9836
www.pearsonind.com
ITEM
PART#
DESCRIPTION
1
PII-15002R-C
Grill (REAR)
2
PII-15004W-C
Fan Blade Assembly
3
PII-15002F-C
Grill (FRONT)
4
PII-15003
Capacitor
5
PII-15008-NS
Switch Plate
6
PII-0200979A
Rocker Switch
7
PII-00163
Cord Strain Relief
8
PII-V71787
Screw
9
PII-15010G2
Motor 1/3 hp 50/60 hz
10
PII-15005G2
Shell
11
PII-0010
Rivet
12
PII-V00137
Rubber Foot

INTRODUCTION
Congratulations on your purchase of a new 8”
WHIRL GEN-2 vane axial fan from Pearson Indus
tries. Itis our goal to provide you with the highest
qualityair mover. The WHIRL GEN-2 is durable
and will provide years of trouble free service when
you follow there commendations included in this
manual.
Please read this manual before operating the
unit. If you do not understand any portion of this
manual, please contact Pearson or an authorized
dealer for additional assistance and guidance
before operating the fan.
GETTING STARTED
1) Read this owner’s manual to familiarize your-
self with all warnings and precautions.
2) Inspect the fan to confirm that it’s in its original
factory configuration. If it is not, contact Pearson
or an authorized Pearson representative.
3) Always use your legs to lift the fan to help
prevent back injury.
4) The fan should not be operated by a minor.
Use caution when operating this fan around chil-
dren.
5) Inspect the fan on aregular basis for signs of
any damage and lose or worn parts. Inspect all
accessories as well.
6) Understand how to turn the fan off in anemer-
gency. Turn it off by pushing the ON/OFF switch
which is located on the side of the unit or unplug
it at the power source.
7) The fan uses aNEMA 5-15P plug and is de-
signed to work ONLY from agrounded, 115 volt
nominal AC, 60Hz, single phase power source.
This power source should utilize aNEMA 5-15R
receptacle. Use aground fault circuit interrupter
(GFCI) to further protect against electrical shock
hazards caused by ground faults.
SAFETY INFORMATION
DO NOT operate the 8” WHIRL GEN-2 fan
without first reading this owner’s
Manual and understand-ing the fans operation.
Pearson has endeavored to design and make
the best ventilation equipment possible. How-
ever, the possibility exists that the fan can be
subjected to applications for which it was not
designed. This misuse can lead to serious in-
jury or death. Refer to current OSHAjob safe-
ty and health rules and regulations pertaining
to the construction industry. Pay particular at-
tention to the rules governing Permit-Required
Confined Spaces for General Industry 29 CFR
1910.
DANGER!
This fan is designed and made for air ventila-
tion only. It is not designed to move/transport
any sort of liquid or semi-liquid material.
Do not operate the fan in any explosive or
flammable atmosphere. Neither the mo-
tor nor the fan is designed to work in such
environments. Serious property damage,
injury or death may result if used in an ex-
plosive or flammable environment.
Keep the unit grounded with athree pronged
grounding plug and agrounded electrical out-
let. Do not use an ungrounded extension cord
or an ungrounded adapter.
DANGER!
Always use caution before entering a con-
fined space area. Test all confined space
air with gas detection equipment that is
appropriate for the job. Assume that a
confined space is contaminated until it is
proven otherwise.

GENERAL SAFETY INFORMATION
1) Do not operate any fan with adamaged cord
or plug. Discard fan or return to an authorized
service facility for examination and/or repair.
2) Do not run cord under carpeting. Do not cover
cord with throw rugs, runners, or similar cover-
ings. Do not route cord under furniture or appli-
ances. Arrange cord away from traffic area and
where it will not be tripped over.
3) Do not block the air intake grill.
4) Do not put any object in the air intake grill.
5) Do not place the fan in standing water be-
cause of extreme shock hazard.
6) Do not operate the fan outside when it is rain-
ing. Only store the fan indoors.
7) Do not discharge flammable solvents or
chemicals through the fan air intake grill.
8) Do not use the Fan in areas where flamma-
ble or combustible liquids, gases, vapors, dust,
fibers, or filings may be present.
9) This fan is not toy.
8) A properly grounded outlet should only be
used with this fan.
9) Unplug the fan from the power supply before
servicing and when not in use.
10) Do not handle thefan with wet hands. Do not
pull or carry the fan by its cord, do not use cord
as ahandle, do not close adoor on the cord, and
do not pull cord around sharp edges or corners.
Keep cord away from heated surfaces. Do not
unplug the fan by pulling on cord, grasp the plug
and not the cord.
11) Do not place hair, loose clothing, fingers,
and any partsof the body near the air intake grill.
12) Do not allow water inside the motor. Un-
plug the fan and let it dry thoroughly before
using again, if the motor becomes wet.
13) Do not remove ground from the power
cord. Removing it may result in electrical
shock or electrocution. Removing the ground
will void the warranty.
14) Inspect the fan if it has been dropped, left
outdoors, or dropped into water, etc.. Thor-
oughly inspect it prior to use.
15) Do not install ducting when the fan is in
operation.
DANGER!
DO NOT USE THE FAN IF THE INLET AND
OUTLET GRILLS ARE NOT INSTALLED.
If the Fan is not working or if you have a
question about its safe operation, do not
operate it.
Contact aPearson Industries Authorized Ser-
vice Center, or the factory direct at (847) 963-
9633 or www.pearsonind.com.

OPERATION
1) When unpacking the fan, inspect it for any
damage that may have occurred during ship-
ping.
2) Read this manual before connecting and
operating the fan.
3) Determine if your job is considered hazard-
ous. The working environment may contain
explosive gases or dust in explosive amounts.
4) The outlet to be used must be grounded.
5) Make sure that both grills on the fan are
not obstructed in anyway that may restrict the
airflow. Do not operate the fan at anytime if
the grills are not installed.
6) The fan is marked with an arrow on either
side. This is the direction of airflow.
7) Never stand in front of the fan in the di-
rection of airflow. Serious injury or death may
occur from being struck with debris that are
sucked into the fan and discharged at a high
speed.
8) Install duct when the fan is turned off and
unplugged.
9) Do not place the fan next to an obstruction
such as awall as this will decrease airflow.
10) Keep in mind that using duct will decrease
the airflow rate.
11) Always test the atmosphere for explosive
gases prior to turning on the fan. Be sure to
continually retest the atmosphere.
MAINTENANCE
DANGER!
Shut off the fan and unplug it before conduct-
ingany service orinspection. Accidentalelec-
trocution or shock may occur if the fan is not
disconnected from a power supply. Confirm
that the fan blade has stopped rotating before
removing the grills and handling the fan blade.
1) Check for any loose or broken fasteners
or components. Replace, repair or tighten as
needed with only factory approved parts.
2) Clean the fan blade of any debris. Abuild
up of debris such as paint, cement dust, dirt,
etc can unbalance the fan blade and damage
the unit.

TURNED OFF AND UNPLUGGED!
TROUBLESHOOTING
DANGER!
ALL THE SERVICE PROCEDURES BELOW SHOULD BE CONDUCTED WITH THE UNIT
For parts and service contact aPearson IndustriesAuthorized Service Center, or the
factory direct at [phone] or www.pearsonind.com.
PROBLEM
CAUSE
SOLUTION
Unit does not run
1. Switch is not on.
2. No power at outlet.
3. Switch is broken.
4. Loose wiring.
1. Turn on switch.
2. Check circuit breaker for power to
outlet.
3. Replace Switch.
4. Check wiring, tighten as needed.
Unit runs briefly,
then shuts off on
overload.
1. Duct length is to long.
2. One or both grills are exhausted.
3. Motor bearing are failing or have
failed.
4. Internal motor wiring is faulty.
1. Shorten duct length.
2. Clear grills.
3. Replace motor
4. Replace motor
Unit vibrates exces-
sively when oper-
ating.
1. The fan blade is damaged.
2.Thereis dirtbuild up onthefanblade.
3. The motor shaft is bent because of a
severe jolt.
1. Replace fan blade.
2. Clean fan blade.
3. Replace motor. If necessary,
replace fan blade.
Unit makes a
scraping sound
while running.
1. Asevere jolt has deformed the hous-
ing.
2. A sever jolt has dislodged the mo-
tor from the housing and/or the motor
mount vanes.
1. Replace the housing or the entire
unit if necessary.
2. Replace the motor if necessary.
Replace the motor mount vanes if
necessary.
Fan does not run,
but motor makes
noise.
1.Asevere jolt has deformed the hous-
ing causing interference with the fan
blade.
2. The capacitor has failed or the ca-
pacitor wire is broken.
1. Repair or replace the housing as
necessary.
2. Repair or replace the capacitor as
necessary.

8” WHIRL GEN-2 EXPLODED VIEW

PEARSON INDUSTRIES LIMITED WARRANTY
The original purchaser of anew Pearson Industries fan is entitled to alimited warranty subject to the
termsand conditionsset forthherein. Pearson’s limited warranty is forthe replacement or repair of any
part that proves to be defective in workmanship or materials for aperiod of two (2) years from the date
of purchase by the original purchaser. During these two years, Pearson will provide all partsnecessary
to correct any defects free of charge. This limited warranty is not transferable and is only available for
the original purchaser.
The limited warranty is only for the repair or replacement of parts found to be defective upon Pearson’s
examination. This limited warranty will be null and void unless the assembled unit is returned, freight
pre-paid, together with aletter describing the problem to Pearson or an authorized Pearson dealer,
This warrantyis limited to ninety (90) daysfor laborfrom the date of the purchase.Thereafter, any labor
costs incurred will be charged to the customer at the current hourly rate.
This limited warranty is null and void if the product has been used in an improper manner, disassem-
bled, altered or not maintained properly. Furthermore, this limited warranty is null and void if fan has
been subjected to unauthorized repairs, corrosive chemicals, improper voltage, fire, flood, abnormal
wear or any causes beyond Pearson’s control.
This limited warranty is null and void if the serial number has been removed, obliterated, or defaced.
Pearson Industries reserves the right to make changes to the fan design, materials or specifications as
necessary and without priornotice. Pearson shallnot be obliged to make any changes or modifications
to any product previously manufactured.
Please provide the serial number of the fan and call Pearson to receive areturn authorization number.
Replacements parts cannot be provided unless Pearson has the proper information from the customer.
To obtain replacement parts pursuant to this limited warranty, you must write to Pearson or call (888)
364-9836 to receive an authorization number.
5420 Newport Drive STE 56
Rolling Meadows, IL 60008
Toll Free: [phone]
Phone: [phone]
Fax: [phone]
©2015 Pearson Industries
