Peavey PowerSlide User manual

TIPS AND TRICKS ON PLAYING YOUR NEW POWERSLIDE
Your new Peavey PowerSlide guitar is a totally new type of instrument
that incorporates all of the functions of a standard lap steel guitar
in a six-string conguration that makes it easy for standard electric
guitar players to play slide.
The PowerSlide incorporates a unique shape and exclusive design
features, such as a patent-pending, three-point suspension system
and adjustable “Y” strap that allow players to use the PowerSlide
in the horizontal conguration even while standing up. Players can
also play the PowerSlide like a conventional guitar in the vertical
orientation simply by using a standard guitar strap with two-point
suspension.
The specially designed pickup makes available an extremely wide
range of tones, which are augmented by Peavey’s patented tone/
mode control to allow the player to adjust from single-coil operation
continuously to dual-coil, hum-canceling mode, with high-end rolloff at
the extreme counterclockwise setting.
Once again, Peavey leads the eld with a unique and totally different
product!
Thank you for choosing Peavey. I hope you enjoy your new Peavey
PowerSlide.
Hartley Peavey

Slide/Steel
PowerSlide™ Guitar
Peavey® “Y” Strap
10
1s
4s
3s
3
4
1
2
6
5
7
11
9
8

Features:
1 - Strap Button: This button is used for either the special “Y” strap or standard shoulder strap.
2 - Strap Button: This button is used with a standard two-point suspension shoulder strap.
3 - Strap Button: This button is used to attach the front of the included three-point strap.
4 - Strap Button: This button is used to attach the adjustable “leg” of the three-point strap.
5 - Mode Control: In place of a TONE control, this knob sweeps the coil-tapping pickup from single
coil to dual coil hum canceling.
6 - Volume Control: Controls output level of the instrument.
7 - Coil Tapping Pickup: Turning the mode control from fully counterclockwise to fully clockwise will range
from hum cancelling with high-end roll off to single coil operation.
8 - Fret Markers: Not actual frets but indicators showing positions for proper intonation. The “sail”
patterns are to help easily identify octaves.
9 - Slide: Included slide used like typical bar slide/steel.
10 - Three-Point “Y” Strap: A Peavey-exclusive design to hold PowerSlide at any angle while standing up.
11 - Output Jack: Used the same as on any electric guitar, to output the signal to an amplier.
How to Use Three-Point Strap:
This three-point “Y” strap is included to help you play your PowerSlide in a horizontal position while standing
up. It is basically an extra-long strap with an adjustable “leg” to help hold the PowerSlide at the most
comfortable playing angle. Inside this manual you will nd variations on how to use the strap.
“Y” Strap instructions: (use to the left for reference)
1- Insert Strap Button “1” on guitar into Tab “1s” on the strap.
2- Insert Strap Button “3” on guitar into Tab “3s” on the strap.
3- Insert Strap Button “4” on guitar into Tab “4s” on the strap.
Now you are ready to play your new PowerSlide guitar.

Introduction:
While many of the same principals are used for playing guitar and slide guitar, there are important differences
in technique and approach. Here are some common tricks and tips used by experienced slide players. We
hope this basic introduction to the slide guitar will help you enjoy your new Peavey® PowerSlide™.
Playing Positions:
The PowerSlide is a completely new idea in slide guitars. Our unique, patent-pending design allows for
multiple playing positions to accommodate an array of playing techniques. Our three-point “Y” strap allows
you to play “lap style” while standing up, where the shape offers many other playing options. Now that
you have hooked up your strap as shown on page 1, below are several different ways to play your new
PowerSlide.
Standing:
Sitting:
Horizontal
Vertical
Vertical
Horizontal
Inverted Vertical
Table Top
Using the three-point “Y” strap you
can play in the natural lap style
while standing up with the guitar
perpendicular to your body.
The bottom edge is shaped to allow
for playing in a seated position.
Using a standard two-point shoulder
strap, you can play the PowerSlide like
a standard guitar using a slide.
Of course, you can also play it like
a traditional lap steel guitar!
Some players position their steel guitar
like a standard guitar but their playing
hand reaches over top of the neck.
The PowerSlide has a at back so
you can also play it on a table top.

Common Open Tunings:
Because there are no frets on a slide guitar, many slide guitar players use open tunings. An open tuning simply means
that playing all strings open will produce a chord. Here are three of the most common open tunings for slide guitar.
We encourage you to explore more tunings to achieve dierent sounds and playing styles.
Different Types of Slides:
How to Hold the Steel/Bar/Slides
OPEN-E: E,B,E,G#,B,E This tuning is popular for many types of slide guitar and is a good place to start.
OPEN-G: G,B,D,G,B,D This tuning is very popular for the blues and is common for dobro players.
OPEN-A: A,C#,E,A,C#,E This tuning is widely used in Hawaiian music and is the same as open-G, but up one step.
Included Peavey Slide: This slide is a
variation of the typical steel/slide.
Included Peavey Slide: Hold between
thumb and middle nger using the index
nger on top for control.
Bar Slide/Steel: This type of slide is
commonly used by lap and pedal steel
players.
Bar Slide/Steel: The inspiration for the
Peavey slide, a typical bar slide is used
in the same manner as the Peavey Slide.
Pipe Slide: This slide is used more for
resonator and standard guitar, than lap
steel, but is also great for playing the
PowerSlide™ in the vertical position.
Pipe Slide: For use on any nger
depending on your personal comfort and
playing style.

Intonation:
While on a regular guitar you position your ngers between the frets to play a note or chord, a slide guitar has no frets,
so your slide becomes the fret. This simply means that you must play the note on the fret marker, not between them.
See example below.
octave octave
tuning is OPEN-E
“E” “B” “A” “G”“C#”
Picking:
Slide Technique:
Many players use nger picks. You can
nd these special picks at your local
music instrument dealer. The technique
used is a combonation of plucking and
struming while muting unplayed strings.
Moving the slide at an angle across the
strings allows for harmonic changes to
your major chords. It is often important
to mute the strings between the slide
and nut to prevent string buzz.
Moving the bar along the fretboard
perpendicular to the strings is the same
as playing chords. Also notice muting of
the strings betwen the slide and nut.
You can also angle the slide to affect
individual strings, leaving the rest open
for chording. Note muting the strings
between the slide and nut.
Standard picking works the same as on
a regular guitar. Resting your hand on the
bridge, it is important to mute the strings
you are not playing to prevent feedback
at high volume levels.
