Peco GRASS PRO BAGGER 3 HUSQVARNA PZ6029 Series User manual

ASSEMBLY OPERATION MAINTENANCE
P
PECOPECO
PPPP
PECOPECOPECO
GRASS COLLECTION SYSTEMGRASS COLLECTION SYSTEMGRASS COLLECTION SYSTEM
OPERATOR’S MANUALOPERATOR’S MANUALOPERATOR’S MANUAL
PRO BAGGER 3 PRO BAGGER 3
HUSQVARNA HUSQVARNA
PZ6029 SERIESPZ6029 SERIES
60” DECK 2010-201460” DECK 2010-2014
PRO BAGGER 3
HUSQVARNA
PZ6029 SERIES
60” DECK 2010-2014
$10.00 REV: 1 - 11/5/2014
MODEL #46131501 & 03
MANUAL PART #: Q0398MANUAL PART #: Q0398MANUAL PART #: Q0398

RESIDENTIAL BAGGING SYSTEM
TABLE OF CONTENTS
SAFETY
1. Read the operator’s manual carefully and familiarize yourself with the proper use of your attachment. Do not allow
anyone who is not acquainted with the Safety Instructions to use your attachment.
2. Know the controls and how to stop quickly. READ THE OPERATOR’S MANUAL!
3. Do not allow children to operate the mower. Do not allow adults to operate the mower or grass collection system
without proper instruction.
4. Be especially watchful of children and pets darting into the area while operating.
5. Keep your eyes and mind on your unit while mowing or operating your attachment. Don’t let others distract you.
6. Do not attempt to operate your unit or mower when not in the driver’s seat.
7. Always stop unit when emptying the container.
8. Stop unit, shut off deck attachment, set parking brake, shut off mower engine and remove spark plug wire before
removing clogs, removing or replacing hose, boot, blower cone, or performing any maintenance.
9. If a slope must be ascended, back up the slope; drive forward when descending.
10. It is recommended that the container be kept only half full when negotiating any slopes. Start mowing on slopes
when the container is empty and never mow slopes greater than 15 degrees.
11. Inspect your lawn and remove any foreign objects before mowing. Never deliberately run the mower across any
foreign object.
12. Wear ear protection if the noise level is offensive.
13. Wear eye protection to prevent debris from damaging your eyes.
SECTION PAGE
Safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2
Safety Alert Symbols - - - - - - - - - - - - - - - - - - - - - - 3
Warranty - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 4
I INTRODUCTION AND DESCRIPTION - - - - - - - - - - - - 5
1-1 Introduction - - - - - - - - - - - - - - - - - - - - - - - - - 5
1-2 Description - - - - - - - - - - - - - - - - - - - - - - - - - 5
II INSTALLATION FOR USE - - - - - - - - - - - - - - - - - - - - - 5
2-1 Preparation Of Mower - - - - - - - - - - - - - - - - - - 5
2-2 Rear Guard Support Bracket Installation - - - - - - 5
2-3 Lower Mount Tube Assembly Installation - - - - - - 5
2-4 Lower Mount Clamp Bracket Installation - - - - - - 6
2-5 Engine Mount Tube Plate Installation - - - - - - - - 6
2-6 Outer Engine Mount Tube Installation - - - - - - - - 6
2-7 Engine Mount Arm Assembly Installation - - - - - - 6
2-8 Engine/Blower/Blade Assembly - - - - - - - - - - - - 7
2-9 Upper Frame Assembly Installation - - - - - - - - - - 7
2-10 Top Assembly Installation - - - - - - - - - - - - - - - 7
2-11 Inlet Installation - - - - - - - - - - - - - - - - - - - - - - 8
2-12 Blower Cone Installation - - - - - - - - - - - - - - - - 8
2-13 Impeller Blade Removal/Replacement - - - - - - 8
SECTION PAGE
2-14 Throttle Cable Installation - - - - - - - - - - - - - - - 9
2-15 Boot To Mower Deck Installation - - - - - - - - - - - 10
2-16 Length Of Hose Adjustment - - - - - - - - - - - - - - 10
2-17 Upper Hose Installation - - - - - - - - - - - - - - - - 10
2-18 Lower Hose Installation - - - - - - - - - - - - - - - - 10
2-19 Weight Kit Assembly Installation - - - - - - - - - - - 10
2-20 Lower Hose To Boot Installation - - - - - - - - - - - 11
III OPERATING INSTRUCTIONS - - - - - - - - - - - - - - - - - - 12
3-1 General Safety - - - - - - - - - - - - - - - - - - - - - - - 12
3-2 Operation & Tips On Mowing - - - - - - - - - - - - - - 12
3-3 Disengagement Of The PTO Assembly - - - - - - - 12
3-4 Unloading The Collection System - - - - - - - - - - - 12
IV MAINTENANCE - - - - - - - - - - - - - - - - - - - - - - - - - - - - 12
4-1 Maintenance Checklist - - - - - - - - - - - - - - - - - - 12
V PARTS AND SERVICE - - - - - - - - - - - - - - - - - - - - - - - 13
5-1 Parts And Service Information - - - - - - - - - - - - - 13
Exploded Views/Parts List And Pack Drawing - - - - 14-16
Safety Decals - - - - - - - - - - - - - - - - - - - - - - - - - - 17
Torque Specifications - - - - - - - - - - - - - - - - - - - - - 18
2

3
SAFETY
WARNING! NEVER operate the mower unless the discharge guard and either the deflector assembly or the
vacuum collector adapter are fastened securely in place.
WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower
blades and the blower impeller have stopped rotating.
WARNING! To avoid serious injury, perform maintenance on the vacuum collector; ONLY AFTER STOPPING
THE MOWER’S ENGINE AND WAITING FOR ALL MOVING PARTS TO COME TO A COMPLETE STOP. Set the
parking brake. Always remove the ignition key before beginning maintenance.
WARNING! For your own personal safety, ALWAYS back up the face of slopes. NEVER attempt to mow
excessively steep slopes, and use caution when turning on any slope.
Safety Alert Symbol
This Safety Alert Symbol means: “ATTENTION! BECOME
ALERT! YOUR SAFETY IS INVOLVED!”
This symbol is used to call attention to safety precautions that
should be followed by the operator to avoid accidents. When
you see this symbol, carefully read the message that follows
and heed its advice. Failure to comply with safety precautions
could result in death or serious bodily injury.
Safety Signs
The signal words DANGER, WARNING, and CAUTION are used on the equipment safety signs. These words are
intended to alert the viewer to the existence and the degree of hazard seriousness.
!
DANGER
!
WARNING
!
CAUTION
!
This signal word indicates a potentially hazardous situation which, if not
avoided, will result in death or serious injury.
This signal word indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
It may also be used to alert against unsafe practices.
This signal word indicates a potentially hazardous situation exist which, if
not avoided, will result in minor or moderate injury.
It may also be used to alert against unsafe practices.
White letters on RED
Black letters on ORANGE
Black letters on YELLOW

PECO LIMITED WARRANTY FOR NEW PRODUCTS
A. WHAT IS WARRANTED?
PECO extends the following warranties to the original purchaser of each new PECO consumer product subject
to the following limitations:
1. PRODUCT WARRANTY: Any part of any consumer product, which is defective in material or workmanship as
delivered to the purchaser will be repaired or replaced, as PECO elects, without charge for parts or labor, if the
defect appears within 12 months (90 days for commercial use) from the date of delivery of the product to the
original purchaser. ALL DEFECTIVE PARTS MUST BE RETURNED TO PECO FOR INSPECTION TO
DETERMINE VALIDITY OF WARRANTY CLAIMS. Freight and mailing will be borne by the customer.
2. PARTS REPLACED DURING WARRANTY: Any new PECO part which is furnished in performance of this
warranty and is defective in material or workmanship as delivered to the purchaser will be repaired or replaced,
as PECO elects, without charge if the defect appears within 90 days from the date of installation of such part or
before the expiration of the original warranty period, whichever is later.
B. SECURING WARRANTY ADJUSTMENTS.
Call PECO for Return Authorization. Damaged or broken parts, other than engines, batteries, and gearboxes
must be returned to PECO Inc., 100 Airport Road, Arden, NC 28704 before any warranty adjustment can be
authorized. At the time of requesting warranty adjustment, the purchaser must present evidence for date of
delivery of the product. The purchaser shall pay any charge for the product to and from Arden, NC.
C. ITEMS NOT COVERED BY PECO WARRANTY.
Engines, batteries and, gearboxes attached to PECO products are covered under a separate warranty by the
respective manufacturer.
D. UNAPPROVED ALTERATION OR MODIFICATION.
All obligations of PECO Inc., under this warranty, shall be terminated if products are altered or modified in
ways not approved by PECO Inc..
E. ACCIDENTS AND NORMAL MAINTENANCE.
The warranty covers only defective material and workmanship. It does not cover depreciation or damage
caused by normal wear, accident, improper use or abuse of products. The cost of normal maintenance and
normal replacement of service items such as belts, cutting blades, hoses, etc., which are not defective shall be
paid for by the purchaser.
F. NO REPRESENTATIONS ADDITIONAL WARRANTIES, DISCLAIMER.
Neither PECO Inc. nor any company affiliated with it makes any warranties, representations or promises as to
the quality of performance of its products other than those set forth herein. Except as described above, PECO
Inc. makes no other warranties AND SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED
WARRANTIES OF FITNESS AND MERCHANTABILITY.
G. ANY MACHINE USED FOR RENTAL PURPOSES ARE GUARANTEED FOR 45 DAYS FROM DATE
OF ORIGINAL SALE ONLY.
H. REMEDIED EXCLUSIVE.
The only remedies the purchaser has in connection with the breach or performance of any warranty on PECO
Inc. consumer products are set forth above. In no event will PECO be liable for special incidental or
consequential damages.
1. NO SERVICE CENTER WARRANTY.
The selling Service Center makes no warranty on his own on any item warranted by PECO Inc. unless he
delivers to purchaser a separate written warranty certificate specifically warranting the item. The dealer has no
authority to make any representation or promise on behalf of PECO or to modify the terms of this warranty in
any way.
4

Section I
INTRODUCTION &
DESCRIPTION
1-1 Introduction
Your grass collection system has been designed to give
you a low maintenance, simple, and effective way to
collect the grass clippings from your mower. This manual
is provided to give you the necessary instructions to
properly mount and operate the collection system on
your mower. Please read this manual thoroughly.
Understand what each control is for and how to use it.
Observe all safety decal precautions on the machine and
noted throughout the manual.
NOTE: all references made to right, left, front, rear, top
or bottom are as viewed from the normal operator’s
position on the mower.
1-2 Description
The collection system is designed for turf maintenance
where there is a need to collect the grass clippings as
the mower cuts the turf. It is also good for picking up
leaves and twigs in pre-season and post-season clean-
up.
The engine/blower/blade assembly, is mounted on the
right side of the unit. The blower draws grass clippings
from the discharge area of the cutter deck back to the (3)
4 cubic foot collection bags P#(G0003) at the rear
portion of the mower frame. The operator can engage
the engine/blower/blade assembly by starting the
engine. Once the bags are full, they can be released for
dumping.
Section II
INSTALLATION FOR USE
2-1 Preparation Of Mower
Carefully open the shipping box. The grass collection
system will have various parts located inside. Remove
and sort all parts for easy identification. Verify all parts
against the list on pages 14 and 15. If parts are missing,
please contact PECO Inc. at 1 [phone].
NOTE: Study all drawings and exploded views before
starting assembly.
Remove the grass deflector and hardware from the
mower deck as shown in Figure 2-1a and 2-1b.
2-2 Lower Mount Tube Assembly
Installation
Remove (2) 3/8”-16 x 2” carriage bolts from the rear
frame of the mower. Fasten the lower mount tube
assembly P#(A1720) to the rear frame of the mower
using (2) 3/8”-16 x 2” HHCS P#(K1208) and (2) 3/8”-16
nyloc nuts P#(K1216) as shown in Figure 2-2.
5
Figure 2-1a
Hardware
Grass Deflector
Figure 2-1b
Grass Deflector and
Hardware Removed
Figure 2-2
Remove
Carrige Bolts
Lower Mount
Tube Assembly
(2) 3/8”-16 x 2” HHCS
(2) 3/8”-16 Nyloc Nuts

6
2-3 Rear Guard Support Bracket
Installation
Secure the rear guard support brackets P#(B1869) to
the rear guard of the mower using (1) 5/16”-18 x 1”
HHCS P#(K1154), (1) 5/16”-18 nyloc nut, and existing
hardware (PER BRACKET). Refer to Figure 2-3.
2-4 Lower Mount Clamp Bracket
Installation
Fasten the lower mount clamp bracket P#(B0302) to the
lower mount tube assembly P#(A1720) and the mower
rear guard. Place (1) 3/8”-16 x 2-1/4” U-bolt P#(K0136)
from the tube side. Secure with (2) 3/8” flat washers
P#(K0047) and (2) 3/8”-16 nyloc nuts P#(K1216). Refer
to Figure 2-4.
2-5 Engine Mount Tube Plate Installation
Fasten the (2) outer engine mount tube plates
P#(B0583) to the rear bumper of the mower using (1)
3/8”-16 x 3-1/2” U-Bolt P#(K0407) and (1) 3/8” flat
washer and P#(K0047) (2) 3/8”-16 nyloc nuts P#(K1216)
(PER SIDE). Leave the hardware loose until the
engine/blower/blade assembly is installed. Refer to
Figure 2-5 for reference.
2-6 Outer Engine Mount Tube Installation
Fasten the outer engine mount tube P#(B3727) to the
outer engine mount tube plates using (2) 3/8”-16 x 2-1/8”
U-bolts P#( K1119) (2) 3/8” flat washers P#(K0047) and
(4) 3/8”-16 nyloc nuts P#(K1216). Orientate the engine
mount arm detent pin hole on the engine mount tube to
the right of the engine and facing up. Fasten the U-bolts
to the outer engine mount tube plates first, then slide the
outer engine mount tube through the U-bolts. Leave the
hardware loose until the engine/blower/blade assembly
is installed. Refer to figure 2-6 for reference.
2-7 Engine Mount Arm Assembly
Installation
Insert the engine mount arm P#(A0942) into the outer
engine mount tube P#(B3727) and fasten with (1) detent
pin P#(J0248). Refer to Figure 2-7 for reference.
Engine Mount
Arm Assembly
Outer Engine
Mount Tube
Detent Pin
Figure 2-4
Lower Mount
Clamp Bracket
U- Bolt
Lower Mount
Tube Assembly
(2) 3/8” Flat Washer
(2) 3/8”-16 Nyloc Nut
Figure 2-5
(2) 3/8”-16 U-Bolts
(2) 3/8” Flat Washer
(4) 3/8”-16 Nyloc Nuts
Figure 2-6
Figure 2-7
Engine Mount
Tube Plate
(2) 3/8”-16 U-Bolt
(2) 3/8” Flat Washer
(4) 3/8”-16 Nyloc Nut
Outer Engine
Mount Tube
Rear Guard
Support Bracket
(1) 5/16”-18 x 1” HHCS
(1) 5/16” -18 Nyloc Nut
and Existing Hardware
Figure 2-3

7
2-8 Engine/Blower/Blade Assembly
Installation
Place the engine/blower/blade assembly onto the engine
mount arm assembly. Secure by using (4) 5/16"-18 x 1-
1/2" HHCS P#(K1157) and (4) 5/16"-18 nyloc nuts
P#(K1180) as shown in Figure 2-8. Slide the
engine/blower/blade assembly towards the engine, if
necessary. There needs to be a minimum of 1” clearance
between the blower housing and the rear wheel. When
the proper clearance is obtained, tighten all hardware
from the previous steps.
2-9 Upper Frame Assembly Installation
NOTE: During this step, it is suggested that two people
install the upper frame onto the lower mount tube.
Using (2) people to lift the upper frame P#(A0585), lift
the upper frame above the lower mount assembly
P#(A1720) making sure the frame is pointing away from
the mower. Slide the upper frame tube into the lower
mount tube assembly and align holes. Secure with (1)
clevis pin P#(K0133) and (1) hair pin clip P#(K0088).
Refer to Figure 2-9 for reference.
2-10 Top Assembly To Upper Frame
Assembly Installation
Align the pivot brackets of the top assembly P#(A0551)
to the pivot point on either side of the upper frame
assembly. Place (1) P#(K0041) fender washer between
each pivot point (Figure 2-10a) and fasten each side by
using (1) P#(K1153) 5/16”-18 x 3/4” HHCS and (1)
P#(K1180) 5/16”-18 nyloc nut. When fastening leave nut
slightly loose so that the top can pivot freely. See Figure
2-10b.
2-11 Inlet Installation
With the top assembly P#(A0551) in the upright position,
insert the inlet P#(V1054) into the right hand hole in the
top assembly as shown in Figure 2-11. Continue to insert
the inlet until it snap locks into place. The inlet should
now pivot freely about the hole.
Figure 2-8
Engine/Blower
Blade Assembly
Engine
Mount Arm
(4) 5/16”-18 x 1-1/2” HHCS
(4) 5-16”-18 Nyloc Nut
5/16”-18 x 3/4” HHCS
5/16”-18
Nyloc Nut
Figure 2-10b
Fender Washer
Figure 2-9a
Figure 2-11
Top Assembly
Inlet
Top Assembly
Lower Mount
Tube Assembly
Clevis Pin
Hair Pin Clip
Figure 2-9

3
1
2
4
5
8
2-12 Blower Cone Installation
Thread (1) 5/16”-18 jam nut P#(K0120) onto each end of
(2) 5/16”-18 x 2-1/2” HHCS P#(K0125). Now partially
thread the bolts into each of the two tabs located on the
blower housing. Place blower cone so the two tabs line
up with the bolts then tighten completely. Refer to Figure
2-12 for reference.
2-13 Impeller Blade Removal/Replacement
To Remove: First remove the 3/8”-16 x 1-1/2” HHCS
P#(K1211) (#1), taper lock bushing washer P#(K0278)
(#3) and spacer bushing P#(S3242) (#4) from the taper-
lock bushing (#5). See Figure 2-13. Next remove the (2)
1/4”-20 x 1” HHCS (#2) and place them into the
threaded holes of the taper-lock bushing P#(S4302)
(#5). Gradually thread each bolt evenly into the taper-
lock bushing, forcing the blade to break-away from the
taper-lock bushing. If the impeller will not move, carefully
hit the base of the impeller, between each vein, with a
hammer, then try again.
To Replace: Place impeller blade over the engine shaft.
Slide the taper-lock bushing (#5) on to the engine shaft
and into the impeller blade, aligning the non-threaded
holes of the taper-lock bushing to the threaded holes of
the impeller blade. Fasten by using (2) 1/4”-20 x 1”
HHCS (#2), (1) spacer bushing (#4) (1) taper lock
bushing washer (#3), and (1) 3/8”-16 x 1-1/2” HHCS
(#1). Torque to the proper specifications in the torque
chart on the back of this manual. Next, rotate the
impeller blade to ensure that the blade is clear of contact
on all sides of the blower housing.
Figure 2-12
(2) 5/16”-18 x 2-1/2”
All Thread HHCS Blower
Housing Tab
(2) 5/16”
Jam Nut
Blower
Housing
Blower
Cone Tab
Figure 2-13

9
2-14 Throttle Cable Installation
To install the throttle cable kit to the ROPS (roll over
protection system), place the 3/8” U-Bolt P#(K0136)
onto the ROPS with the threads facing the front of the
mower. Next slide on the throttle mount plate assembly
P#(A0666) with the rivets also facing toward the front of
the mower. Tighten the throttle mount plate assembly
securely to the ROPS using (2) 3/8”-16 nyloc nuts
P#(K1216) (Figure 2-14a). With the throttle cable facing
toward the engine/blower/blade assembly, place the
throttle base plate over the rivets, Slide the throttle
cable kit to the right, moving the smaller end of the slot
over the rivets. When positioned correctly, the throttle
spring plate will snap into place (Figure 2-14b).
NOTE: If mower is not equipped with a ROPS Intall the
throttle cable kit to the top frame assembly P#(A0585)
using the same steps as above. Make sure to locate the
throttle cable kit were it can be easily accessed from the
operator’s seat.
To remove the throttle cable kit, lift the throttle spring
plate and slide the throttle kit to the left.
Route cable over upper hose as shown in Figure 2-14c.
Attach J-Clip P#(K1455) onto blower housing using the
existing bolt located on blower housing. To fasten the
throttle cable end to the engine, place the throttle
control lever into the “stop” position. Rotate the engine
throttle lever to the “stop” position. Thread the wire end
of the throttle cable into the engine throttle lever eyelet
and tighten the screw. Thread the cable through the j-
clip and then fasten the throttle cable sleeve to the
clamp on the engine throttle (Figure 2-14d). Rotate the
throttle control lever into the “fast” position to check for
proper installation.
NOTE: Cable sleeve may need to be cut, depending on
the engine type. Once throttle cable is attached, pull the
box handle to dump the box and be sure the cable does
not alter the movement of the box.
Throttle Base Plate
Throttle Spring
Plate Throttle
Figure 2-14b
Properly Assembled
Throttle Cable Kit
ROPS
or
Upper Frame Assy.
(1) 3/8”-16 U-Bolt
(2) 3/8”-16 Flange Nuts
Throttle Mount
Plate Assembly
Figure 2-14a
Figure 2-14d
Throttle
Cable Clamp
Engine
Throttle Lever
Figure 2-14c
J-Clip
Throttle
Cable

10
2-15 Boot To Mower Deck Installation
Mount the boot plate P#B0581 to the boot P#E1902
using (3) 3/8”-16 x 1” carriage bolts P#(K1182), (3) 3/8”
flat washer P#(K0047) and (3) 3/8”-16 nyloc nuts
P#(K1216). Insert the carriage bolts from inside the boot
and fasten the nyloc nuts to the outside of the boot as
shown in Figure 2-15. This will prevent grass clippings
from collecting on the bolts. Position the boot plate over
the grass deflector mounting holes and insert (1) boot
rod P#(B0348). Fasten the boot pin with (1) hair pin clip
P#(K0099). Refer to Figure 2-15 for reference.
2-16 Length of Hose Adjustment
The hoses in steps 2-17 and 2-18 must be cut to fit your
mower. Follow steps 2-17 and 2-18, however, do not cut
the hoses until you have tried to fit them on your mower.
The hoses have to be long enough to allow for clamping
surface between the inlet, blower assembly, and boot.
2-17 Upper Hose Installation
Slide a hose clamp P#(J1000) over both ends of the
upper hose. Then slide one end of the upper hose onto
the inlet. Make sure there is about a two-inch overlap
between the hose end and the container inlet. Proceed
to slide the opposite end of the upper hose onto the
outlet of the blower assembly. See Figure 2-18 for
details. Tighten the hose clamps.
2-18 Lower Hose Installation
Slide a lower hose clamp P#(J1000) onto both ends of
the 8” lower hose. Slide one end of the lower hose onto
the blower cone, with 2” of the hose overlapping the
cone, and tighten the clamp. Slide the other end of the
lower hose over the boot, with 2” of the hose overlapping
the boot, and tighten the clamp. Refer to Figure 2-18 for
reference.
2-19 Weight Kit Installation
Mount the weight brackets to the caster axles as shown
in Figure 2-18a, using (2) 3/8”-16 x 4” U-bolt P#(K1419),
(4) 3/8” flat washer P#(K0047) and (4) 3/8”-16 nyloc nuts
P#(K1216). Position the weight as shown in Figure 2-
19a and fasten the weight P#(B2220) to the weight
brackets using (2) 1/2”-13 x 4-5/16” U-bolts P#(K0331),
(4) 1/2” flat washer P#(K0055) and (4) 1/2”-13 nyloc nuts
P#(K1247). Refer to Figure 2-19b for weight bracket
mounting locations.
Blower
Cone
Upper Hose
Clamps
Lower Hose
Clamps
Figure 2-18
Inlet
Boot
Figure 2-19b
Weight
Mounting Locations
Figure 2-15
(3) 3/8”-16 x 1” Carriage Bolts
(3) 3/8” Flat Washer
(3) 3/8”-16 Nyloc Nuts
Boot
Boot Plate
Hair Pin
Clip
Boot Rod
Figure 2-19a
Weight
Bracket
(2) 3/8”-16 U-Bolt
(4) 3/8” Flat Washer
(4) 3/8”-16 Nyloc Nut
(2) 1/2”-13 U-Bolt
(4) 1/2” Flat Washer
(4) 1/2”-13 Nyloc Nut

2-20 Installation/Removal Of Collection
Bags
To install the bag onto the bag ring, first make sure the
bag ring end caps are fastened to the bag ring. Place the
seam openings of the bag onto the bag ring openings
and turn the bag until the slot bracket in the bag ring is
protruding from the opening in the bag (Figure 2-20a).
Do this for each of three bags.
Install the completed assemblies onto the support frame
and close the plastic top. Fasten both draw latches to
hold the plastic top closed (Figure 2-20b).
To empty the bag, remove the bag and bag ring by lifting
and sliding rearward. Grasp the loop on the bottom of
the bag, turn it upside down and empty the collected
debris (Figure 2-20c). Repeat for the other bags.
Reinstall all bags, line with plastic bags if desired, close
the plastic top and reattach the draw latches.
Plastic lawn and leaf bags, 33 gallon size, may be used
inside the cloth bags. Be sure to leave enough plastic
bag hanging over the frame so the plastic bags can be
twist tied before emptying (Figure 2-20d).
Figure 2-20a
Draw Latches
Cloth Bag
Slot
Bracket
Bag Ring
Bag Ring
End Caps
Figure 2-20b
Figure 2-20c
Figure 2-20d
Plastic Top
Grasp Bag
Here
Plastic Bag
Cloth Bag
11

SECTION III
OPERATING INSTRUCTIONS
3-1 General Safety
Only qualified people familiar with this operator’s manual
and the mower’s operator’s manual should operate this
machine.
3-2 Operation & Tips On Mowing
A. Perform BEFORE EACH USE maintenance list in
paragraph 4-1.
B. Start the engine/blower/blade assembly.
B. Start mower.
C. With the mower at high idle speed, engage the mower
deck.
D. Proceed to operate the control levers of the mower.
NOTE: If the collection system does not appear to be
collecting the grass clippings; disengage the deck,
and blower, engage the parking brake and turn the
mower off. Check the upper hose, lower hose, top
screen and boot for clogs.
To obtain the maximum effectiveness from your
collection system the tips listed below should be
followed:
* Watch your speed- Normal conditions will allow a
speed of up to approximately 5 mph, but thick, heavy
damp conditions will require reduced ground speed.
* Mow with sharp blades- A sharp blade cuts cleaner.
* Wet grass and leaves will decrease effectiveness and
will increase horsepower requirements.
* Mow at higher cutting heights- Remove and mulch no
more than 2” of grass length with each mowing.
(Experts recommend not cutting off more than 1/3 of
the grass blade length at any given time.)
* Mow twice, at different height settings, (high, then low),
if grass is extra tall.
* Remember that horsepower requirements will vary with
the mowing conditions such as type and height of turf
grass, moisture content, amount of leaves, whether the
terrain is flat or sloped, etc.
3-3 Unloading The Collection System
A. Stop the forward movement of the mower.
B. Disengage the mower deck.
C. Using the throttle cable slow the engine down to idle.
D. Engage the parking brake.
12
E. Once the parking brake has been engaged, then and
only then, walk behind the mower and check the
collection bags by lifting the plastic hood. Load in
bags should not exceed the height of the installed
bag.
F. To release bags from frame, lift bag ring from tab on
bagger frame, slide bag out and turn bags over to
deposit clippings.
G. Follow steps on page 14 to re-attach bags back to the
bagger.
NOTE: Do not allow collection bags to become over-
filled as potential damage may occur to your
equipment. Also, be sure to clean the hood screen as
needed.
SECTION IV
MAINTENANCE
4-1 Maintenance Checklist
Before each use:
1. Check blades and spindles to be sure that no foreign
objects, such as wire or steel strapping bands, are
wrapped around them.
2. Inspect blades for wear. Replace if necessary. If it is
necessary to sharpen the blades, remove the blades
from the spindles before sharpening. DO NOT
sharpen blades while still attached to the mower.
3. Make sure all shields are in place and in good
condition. Repair or replace any missing or damaged
shields.
4. Listen for abnormal sounds, which might indicate
loose parts, damaged bearings, or other damage.
Correct any deficiency before continuing operation.
5. Check for wear or deterioration of the upper or lower
hoses. If there are any portions of the hose that have
been torn or worn through, replace with genuine
PECO parts.
After Each Use:
1. Clean all debris from machine especially from the
container, and off of safety decals. Replace any
missing or illegible decals.
2. Clean all debris from the box screen.
3. Inspect unit for worn or damaged components. Repair
or replace before the next use. Any replacement
component installed during repair shall include the
components current safety decal specified by the
manufacturers to be affixed to the component.

13
Model Number
Serial Number
PECO
OUTDOOR POWER EQUIPMENT
Arden, North Carolina 28704
WRITE THE MODEL AND
SERIAL NUMBER IN THE
BOX ABOVE FOR FUTURE
REFERENCE.
THE SERIAL NUMBER PLATE
IS LOCATED ON THE PLASTIC
TOP ASSEMBLY P#(A0551)
Unit Model Number: _____________________________
Unit Engine Size: _____________________________
Unit Serial Number: _____________________________
Date of purchase: _____/_____/_________
Dealer/Distributor Name: ________________________________________
Dealer’s/Distributor’s: _______________________ State: __________ Zip: ___________
Phone Number: ____________________________
Address: PECO Inc.
10 Walden Drive
Arden, NC 28704
Phone #: [phone] or Toll Free: [phone]
Email: [e-mail]
SECTION V
PARTS AND SERVICE
5-1 Parts And Service Information
PECO collection system owners should record the
name and telephone number of their Service Center.
Your Service Center will be happy to supply
replacement parts, accessories, and do any service or
repairs to your collection system. If for any reason your
Service Center is unable to service your collection
system or supply replacement parts, contact PECO and
include the following information on the chart below.

14

15

16
Exploded View Of The
A0551 - Bagger Assembly (2) K1144 - 5/16”-18 x 1”
CARRIAGE BOLT
(6) K1142 - 5/16”-18 x 3/4”
CARRIAGE BOLT
(4) K1010 - 1/4”-20 x 5/8”
CARRIAGE BOLT
(1 LEFT, 1 RIGHT)
B0237 - PIVOT
BRACKET
(1) V1054 - INLET
(1) B8002 - PLASTIC
SCREEN
(2) C0051 - LONG
SCREEN MOUNT
STRIP
(2) C0052 - SHORT
SCREEN MOUNT
STRIP
(1) V0002 - PLASTIC TOP
(2) K1126 - 1/4”-20
FLANGE NUT
(2) K0037 - 1/4” FLAT
WASHER
(1) C0048 -
LATCH MOUNT
BRACKET
(2) K1025 - 1/4”-20
x 1” CARRIAGE
BOLT
(2) J4005 - FLEXIBLE
DRAW LATCH
(2) C0047 - PIVOT
BRACE
(2) C0049 - SCREEN
BRACE
(8) K1178 - 5/16”-18
FLANGE NUT
(1) V0005 - BAG RING SEAL
(6) J0274 - BAG RING END CAP
(3) A0584 - BAG RING
ASSEMBLY
(2) K1180 - 5/16”-18
NYLOC NUT
(2) K0041 - 5/16”
FENDER WASHER
(2) K1153 - 5/16”-18
x 3/4” HHCS
(1) A0585 - UPPER FRAME
ASSEMBLY

SAFETY DECALS
To promote safe operation, PECO supplies safety decals on all products manufactured. Damage can occur to
safety decals either through shipment, use or reconditioning. Contact your local Service Center for replacement decals.
Part #: R1054
Part #: R1057
Part #:R1051
17
Part #: R1065
Part #: R4027
Part #: R1069
Part #:R4008
Part #:R4015
Part #: R2007
Part #: R2008
Part #: R1090

18

NOTES:
19

10 WALDEN DRIVE
ARDEN, NORTH CAROLINA 28704
[phone] OR [phone] FAX: [phone]
EMAIL: [email protected]
WEBSITE: www.lawnvac.com
P
PECOPECO
PPPP
PECOPECOPECO
