pellenc Selion C21 HD User manual
51_82029_K - 03/2015
pellenc s.a.
Route de Cavaillon
B.P. 47
84122 PERTUIS cedex
(France)
Tel : +33(0)4 90 09 47 00 Fax : +33(0)4 90 09 64 09
www.pellenc.com
*
USER GUIDE
ENG
Translation of the
original user guide
READ THE USER GUIDE CAREFULLY BEFORE USING THE TOOL
*Optional (Carving guide ref:
80344).
2
SAFETY INSTRUCTIONS .....................................................................3
GENERAL SAFETY INSTRUCTIONS FOR THE TOOL..................................................................3
SAFETY INSTRUCTIONS FOR THE CHAINSAW ......................................................................5
CAUSES OF KICKBACK AND HOW THE USER CAN PREVENT IT .......................................................6
SAFETY EQUIPMENT ...........................................................................................7
SAFETY REFLEXES.............................................................................................7
SAFETY INDICATIONS ..........................................................................................8
SAFETY MEASURES .........................................................................9
WORKING WITH TREE SERVICE CHAIN-SAWS FROM ROPE AND HARNESS .............................................9
DESCRIPTION AND TECHNICAL CHARACTERISTICS ............................................12
TECHNICAL CHARACTERISTICS .................................................................................12
PUTTING THE TOOL INTO SERVICE ...........................................................13
CHAIN LUBRICATING SYSTEM ..................................................................................13
FORCED CHAIN LUBRICATING SYSTEM ..........................................................................13
CHAIN PROTECTION...........................................................................................13
STARTING ...................................................................................................14
HOLDING THE TOOL...........................................................................................14
STARTING AND USE ........................................................................15
INTRODUCTION...............................................................................................15
CHAIN BRAKE ................................................................................................15
CHECKING THE CHAIN BRAKE ..................................................................................15
INSTALLING THE CHAIN GUIDE..................................................................................16
INSTALLING THE CHAIN ........................................................................................16
AUTOMATIC CHAIN TENSIONING ................................................................................16
CHECKING AND REPLACING THE SPROCKET .....................................................................17
CLEANING THE CHAIN GUIDE ...................................................................................17
LUBRICATING THE CHAIN GUIDE ................................................................................17
THE FOUR BASIC RULES .......................................................................................18
SERVICING................................................................................19
CLEANING ...................................................................................................19
SERVICING INTERVALS ........................................................................................19
REPLACING THE CHAIN AND THE GUIDE .........................................................................20
GENERAL INSTRUCTIONS FOR SHARPENING THE CUTTERS .....................................21
SHARPENING THE CUTTERS USING A ROUND FILE ................................................................21
ADJUSTING THE DEPTH LIMITERS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
MAINTENANCE ............................................................................23
STORAGE OUT OF SEASON ....................................................................................23
OIL RESERVOIR ...........................................................................23
«PELLENC SA» TERMS OF WARRANTY AND NON-RESPONSIBILITY CLAUSE .......................24
"EC" DECLARATION OF CONFORMITY ........................................................25
Table of contents
3
Dear Customer,
Thank you for purchasing the SELION C21 HD chainsaw. Correctly used and maintained, this tool will give
satisfactory performance for years to come.
ENVIRONMENTAL PROTECTION
Your equipment comprises numerous materials which can be valorised or recycled. Entrust
these to your reseller or to an approved service centre so that they can be processed.
All through this user guide you will nd advisory notes and information entitled: REMARK,
CAUTION / WARNING.
A REMARK provides additional information, claries a point or explains a step to be followed in
detail.
The CAUTION and WARNING advisories are used to dene a procedure which, if neglected or incorrectly
performed, may lead to serious damage to the equipment and/or personal injury.
This advisory:
G
indicates that if the procedures or instructions are not complied with, any damage will not
be covered by the warranty and the owner will be responsible for the repair costs.
Safety indications are also given on the tool; they remind you of the safety precautions to be taken. Identify
and read these indications before using the tool. Immediately replace any indications that may become
partially illegible or deteriorated.
Refer to the «SAFETY INDICATIONS» heading in order to identify the location of the safety
indications on the tool.
No part of this manual may be reproduced without the written consent of PELLENC. The technical
characteristics and the illustrations given in this manual are for information purposes and are in no way
contractual. PELLENC reserves the right to make any modication or improvement to its products as
deemed necessary without informing customers already in possession of a similar model. This manual
forms an integral part of the tool and must accompany the tool if it changes hands.
SAFETY INSTRUCTIONS
INTRODUCTION
Comply with the regulations in force in your country as concerns environmental protection
associated with your activity.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or preliminary instructions by a person responsible for their safety.
KEEP THESE INSTRUCTIONS
GENERAL SAFETY INSTRUCTIONS FOR THE TOOL
CAUTION Read all the safety measures and all the instructions.
Retain all the safety measures and instructions for later reading.
4
SAFETY INSTRUCTIONS
Work area safety
1– Keep the working area clean and well lit. Untidy or dark areas are conducive to accidents.
2– Do not operate electrical tools in an explosive atmosphere, for example where there are
ammable liquids, gases or dust. Electrical tools produce sparks which can ignite dust or smoke.
3– Keep children and adults away while you are using the tool. Distractions can cause you to lose
control of the tool.
Electrical safety
1– Do not expose tools to the rain or damp conditions. Water penetrating a tool will increase the risk of
electric shock.
2– Do not misuse the power cord. Never use the power cord to carry, pull or disconnect the tool.
Keep the power cord away from heat, lubricant, sharp edges or moving parts. Damaged or tangled
cords increase the risk of electric shock.
Personal safety
1– Remain vigilant, watch what you are doing and use common sense when using the tool. Do not
use a tool when you are tired or under the inuence of drugs, alcohol or medication. Temporary lack
of awareness while using the tool can result in serious injury.
2– Wear safety equipment. Always wear eye protection. Safety equipment such as dust masks, non-slip
safety shoes, helmets or acoustic protection used in appropriate conditions will reduce the risk of injury.
3– Avoid untimely starting of the tool. Make sure the switch is in the ‘off’ position before connecting
the tool to the mains and/or battery pack, picking it up or carrying it. Carrying the tools with your
nger on the switch or connecting tools with the switch in the ‘on’ position can cause accidents.
4– Remove any adjusting wrench before switching on the tool. A wrench left attached to a rotating part
can cause injury.
5– Do not rush. Maintain the correct position and balance at all times. This helps control the tool in
case of unexpected situations.
6– Dress appropriately. Do not wear loose clothing or jewellery. Keep hair, clothing and gloves away
from moving parts. Loose clothing, jewellery or long hair can get caught in moving parts.
Tool usage and maintenance
1– Do not force the tool. Use the tool adapted to your application. The adapted tool will do a better and
safer job, in accordance with the purpose for which it was designed.
2– Do not use the tool if the switch does not allow switching between on and off positions. Any tool
which cannot be controlled by the switch is hazardous and should be repaired.
3– Disconnect the plug from the power source and/or battery pack prior to any adjustment, change
of accessories or before putting the tool away. These preventive safety measures reduce the risk of
starting the tool accidentally.
4– When not in use, keep tools out of reach of children, and do not allow people to use the tool
if they do not know how to use it and if they are not familiar with these instructions. Tools are
dangerous for inexperienced users.
5– Comply with the tool servicing instructions. Check that the moving parts are not out of alignment
or jammed, that there are no broken parts or that there is no other condition which could affect the
operation of the tool. In case of damage, get the tool repaired before using it. Many accidents are due
to poorly maintained tools.
5
Maintenance and upkeep
1– Have the tool maintained by an authorised PELLENC distributor using only identical spare parts.
This will guarantee that the tool safety is maintained.
SAFETY INSTRUCTIONS FOR THE CHAINSAW
1– Keep the cutting chain away from all parts of your body when the chainsaw is operating. Before
turning on the chainsaw, ensure that the cutting chain is not in contact with anything. A momentary
distraction while using the chainsaws can result in your clothes or part of your body getting caught in the
cutting chain.
2– Always hold the rear handle of the chainsaw with your right hand and the front handle with your
left hand. Holding the chainsaw the other way round increases the risk of bodily injury and should never be
attempted.
3– Hold the tool only by its insulated gripping surfaces as the chainsaw can come into contact with
the hidden wiring or the tool’s own power cord. Saw-chains coming into contact with a "live" wire can
result in the electrication of the exposed metal parts of the electric tool and cause electric shock to the
operator.
4– Wear safety goggles and auditory protection. Additional protective equipment for your head,
hands, legs and ears is recommended. Appropriate protective clothing will reduce the risk of bodily injury
caused by ying debris or accidental contact with the cutting chain.
5– Always remain steady on your feet and only use the chainsaw on a stationary, safe and level
surface. Slippery or unstable surfaces such as ladders can cause a loss of balance or control of the
chainsaw.
6– When cutting a bent branch, beware of it springing back. When the tension of the wood bres is
released, the branch can spring back and hit the operator and/or result in a loss of control of the chainsaw.
7– Be extremely careful when cutting scrub and young shrubs. Fine materials can catch in the cutting
chain and be projected in your direction like a whip, or make you lose your balance because of the traction
effect.
8– Hold the chainsaw by the front handle, switch the power off and keep it away from your
body. When transporting or storing the chainsaw, always t the protective cover over the chain.
Appropriate handling of the chainsaw will reduce the likelihood of accidental contact with the mobile cutting
chain.
9– Follow the instructions concerning the lubrication, tension and chain replacement accessories.
A chain with incorrect tension and lubrication can break or increase the risk of kickback.
10– Keep the handles, dry, clean and free from oil and grease. Greasy, oily handles are slippery and
cause a loss of control.
11– Only cut wood. Do not use the chainsaw for any purpose other than for which it is intended.
For example: do not use the chainsaw to cut plastic materials, masonry or constructions other than
wood. Using the chainsaw for operations other than those for which it is intended can cause hazardous
situations.
6– Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting parts are less
likely to jam and are easier to control.
7– Use the tool, accessories and blades, etc. in accordance with these instructions, taking into
account the working conditions and the work to be carried out. Using the tool for operations other
than those provided for could result in hazardous situations.
6
Increased safety with three revolutionary PELLENC technologies!
The rst safety feature is PELLENC’s electronically-triggered kick-back sensor: this mechanism
instantaneously applies an electric chain brake in case of a fall or kick-back, and it is eight times more
sensitive than a combustion engine chainsaw chain brake.
The second safety feature is provided by the tool’s self-diagnostic system: When the tool is rst used, the
SELION C21 HD checks that the electronic kick-back sensor is operational, and if this is the case, the tool
can operate!
Finally, the third safety feature arises from the use of OREGON low kick-back chains: if there is a kick-
back, it will be less severe than with a standard chainsaw.
Globally, the SELION C21 HD is safer than conventional chainsaws
CAUSES OF KICKBACK AND HOW THE USER CAN PREVENT IT
Kickback can occur if the front or end of the chain guide
touches an object or if the cut in the wood closes and
traps the cutting chain in the cut.
In some cases, contact with the end of the chain guide
can suddenly cause the chain guide to kick upwards and
backwards towards the user.
If the cutting chain is trapped on the upper part of the
chain guide, the chain guide can abruptly push back
towards the user.
Either of these reactions can cause a loss of control
of the saw, likely to lead to serious injury. Do not rely
exclusively on the safety features built into your saw. The user of the chainsaw must take all necessary
measures to prevent risks of accident or injury when cutting.
Kickbacks result from incorrect use of the tool and/or incorrect operating conditions or procedures, and can
be avoided by taking the appropriate precautions specied below:
• Hold the saw rmly in both hands with your thumbs and ngers around the handles of the saw,
and position your body and arms so that you can resist the force of the kickback. The force of the
kickback can be controlled by the operator if appropriate measures have been taken. Do not let go of the
chainsaw.
• Do not stretch your arms out too far and do not cut above shoulder height. This helps prevent
unwanted contact with the end and facilitates control of the chainsaw in unforeseen situations.
• There are different models of chains according to the work to be done. Only use genuine
PELLENC chains and chain guides. Incorrect chain guides and replacement chains can cause the chain
to break and/or kickbacks.
• Follow the chainsaw chain sharpening and servicing instructions. Reduction in the depth gauge
level can lead to increased kickbacks.
7
1 5
2
6
3
7
4
8
SAFETY EQUIPMENT
Protective equipment Wearing is
1 Helmet Mandatory
2 Visor Recommended
3 Gloves Mandatory
4 Non-slip safety boots Mandatory
5 Ear protection Recommended
6 Safety goggles Mandatory
7 Safety jacket or over-sleeves Mandatory
8 Protective trousers Mandatory
Keep your left arm straight for better control.
Hold the chainsaw at your side, and not in front of you.
Use Pellenc genuine chains and guides.
Keep the chain, the guide and the sprocket in good working condition.
Stand with your legs apart and well balanced.
Remember to vary your working position and to take regular breaks from work.
WARNING!
Clear the work area before cutting.
Calculate the point where the object you are cutting will fall.
Take care that the chainsaw is not pushed back by the object to be cut.
Position yourself correctly to prevent accidents.
Never cut when on a ladder.
Keep all other persons clear. Never have someone hold the object you are cuttting.
Cut the branches into suitably sized pieces from the outside of the tree towards the trunk.
Be careful of branches that bounce back when they drop to the ground.
NOTE: Chain speed : 14.5 m/s. Wear safety clothes suited to this chain speed. (Class 0 as per standard EN 381)
and which are not too big.
SAFETY INSTRUCTIONS
SAFETY REFLEXES
8
51_10_011C
1
2
3
4
5
76
1– Read the user guide
2– Safety goggles and a protective helmet must be worn
3– Suitable hand, fore-arm, leg and foot protection is mandatory
4– Risk of burns (motor)
5– Do not expose to rain
6– LwA sound power level guaranteed
7– This chain-saw is for trained tree service operators only
SAFETY INDICATIONS
9
E1
WORKING WITH TREE SERVICE CHAIN-SAWS FROM ROPE AND HARNESS
Overview
General requirements
Preparing to use the saw in the tree
This annex sets out working practices aimed at reducing the risk of injury from tree service chain-saws
when working at height from a rope and harness. While it may form the basis of guidance and training
literature, it should not be regarded as a substitute for formal training. The guidance given in this annex is
only an example of best working practice. National laws and regulations should always be followed.
It presents
• general requirements that should be met before using a tree service chain-saw for work at height from a
rope and harness,
• preparations for using a tree service chain-saw from a rope and harness, and
• use of a tree service chain-saw for pruning and dismantling, including secure work positioning for two-
handed use, starting the chain-saw, cutting with the chain-saw, restrictions on one-handed use and freeing
a trapped saw.
Operators of tree service chain-saws working at height from a rope and harness should never work alone.
A ground worker trained in appropriate emergency procedures should assist them.
Operators of tree service chain-saws for this work should be trained in general safe climbing and work
positioning techniques and be properly equipped with harnesses, ropes, strops, carabiners and other
equipment for maintaining secure and safe working positions for both themselves and the saw.
The chain-saw should be tted with a suitable strop for
attachment to the operator’s harness (see Figure E1):
a) secure the strop around the attachment point on the rear of
the saw;
b) provide suitable carabiners to allow indirect (i.e. via the
strop) and direct attachment (i.e. at the attachment point on
the saw) of the saw to the operator’s harness;
c) ensure the saw is securely attached when it is being sent
up to the operator;
d) ensure the saw is secured to the harness before it is
disconnected from the means of ascent.
SAFETY MEASURES
10
E3
E2
Using the chain-saw in the tree
Securing the work position for two-handed use
The ability to directly attach the saw to the harness reduces the risk of damage to equipment when moving
around the tree. Always switch the saw off when it is directly attached to the harness.
The saw should only be attached to the recommended
attachment points on the harness. These may be at mid-point
(front or rear) or at the sides. Where possible, attach the saw
to the centre rear mid-point to keep it clear of climbing lines
and to support its weight centrally down the operator’s spine.
See Figure E2.
When moving the saw from any one attachment point to
another, operators should ensure it is secured in the new
position before releasing it from the previous attachment point.
An analysis of accidents with these saws during tree service operations shows the primary cause as being
inappropriate one-handed use of the saw. In the vast majority of accidents, operators fail to adopt a secure
work position that allows them to hold both handles of the saw. This results in an increased risk of injury
due to
not having a rm grip on the saw if it kicks back,
a lack of control of the saw, such that it is more likely to come into contact with climbing lines and the
operator’s body (particularly the left hand and arm), and
loss of control owing to an insecure work position and resulting in contact with the saw (unexpected
movement during operation of the saw).
In order to allow the saw to be held with both hands, as a general rule operators should aim for a secure
work position in which they operate the saw at
• hip level, when cutting horizontal sections, and
• solar plexus level, when cutting vertical sections.
Where the operator is working close into vertical stems with
low lateral forces on the work position, then a good footing
could be all that is needed to maintain a secure work position.
However, as operators move away from the stem, they will
need to take steps to remove or counteract the increasing
lateral forces by, for example, a redirect of the main line via
a supplementary anchor point or use of an adjustable strop
direct from the harness to a supplementary anchor point (see
Figure E3).
SAFETY MEASURES
11
E4
E5
Freeing a trapped saw
One-handed use of the chain-saw
Operators should not use tree service chain-saws one-handed when work position is unstable or in
preference to a handsaw when cutting small diameter wood at the branch tips.
Tree service chain-saws should only be used one-handed
where
• operators cannot gain a work position enabling two-handed
use, and
• they need to support their working position with one hand,
and
• the saw is being used at full stretch, at right angles to and
out of line with the operator’s body (see Figure E5).
Operators should never
• cut with the kickback zone at the tip of the chain-saw guide bar,
• “hold and cut” sections, or
• attempt to catch falling sections.
It the saw becomes trapped during cutting, operators should
• switch off the saw and attach it securely to the tree inboard (i.e. towards the trunk side) of the cut or to a
separate tool line,
• pull the saw from the kerf whilst lifting the branch as necessary,
• if necessary, use a handsaw or second chain saw to release the trapped saw by cutting a minimum of 30
cm away from the trapped saw.
Whether a handsaw or a chain-saw is used to free a trapped saw, the release cuts should always be
outboard (toward the tips of the branch), in order to prevent the saw being taken with the section and
further complicating the situation.
Gaining a good footing at the working position can be assisted
by the use of a temporary foot stirrup created from an endless
sling (see Figure E4).
SAFETY MEASURES
12
1
6
12
17 8
9
5
11
4
18
19
20
3 2
10
DESCRIPTION AND TECHNICAL CHARACTERISTICS
1: Handle
2: Operating trigger
3: Safety trigger
4: Front right hand protection
5: Left-hand handle
6: Chain casing
8: Saw chain
9: Chain guide (*20: Optional carving guide)
10: Chain guard tightening nut
11: Oil reservoir cap
12: Tool power lead
17: Telescopic tightening wrench
18: Power-on light.
19: Arm band
TECHNICAL CHARACTERISTICS
Vibration emission value as per DIN EN 60745-2-13:2008 left hand
ah= 2.8 m/s²
uncertainty
Kd = 1.5 m/s²
Acoustic pressure level at work station - Equivalent weighted value A as per DIN
EN ISO 11201:1996 LpA = 84 dB K = 2.9 dB
Working capacity (time) According to use and battery type
Chain oil reservoir capacity 25 cm3
Useful cutting length / chain guide 30 cm (12’’) / specific to Pellenc
Chain Type / Pitch / Gage 25AP / 6.35 mm (1/4’’) / 1.3 mm (0.05’’)
Sprocket 11 teeth 1/4’’
Chain speed 14.5 m/s
Weight of tool without guide or chain 2.05 kg
Determining the sound levels and vibration rates is based on the operating conditions at the maximum
nominal rating.
Symbol Value Unit Reference Comment
LWAm 93,5 dB(A) 1 pW Measured sound power level
LWAg 96 dB(A) 1 pW Guaranteed sound power level
The recording of the measured sound power level and of the guaranteed sound power level has been performed according to a
procedure in accordance with directive 2000/14/CE appendix V.
13
51_14_004A
51_08_020A
51_08_021A
G
G
PUTTING THE TOOL INTO SERVICE
CHAIN LUBRICATING SYSTEM
CAUTION: Never use dirty or used oil.
FORCED CHAIN LUBRICATING SYSTEM
Fit the guide and chain protection whenever you transport,
handle and store the chain saw.
CHAIN PROTECTION
Never transport the chain saw without its
protective cover. The chain saw must always have
its protective cover on when moved.
CAUTION:
Carry out forced lubrication at the start of each season
in order to check the chain lubricating function.
Carry out forced lubrication when necessary.
Reasonable oil consumption!
Oil consumption has been signicantly reduced by the
electronic control of the oil ow. This is a PELLENC
innovation.
1– Use special guide and chain oil (P/No. 85920).
2– Carefully pour the guide and chain oil into the reservoir.
3– Check the oil level every hour and top it up if necessary.
COMMENT:
PELLENC recommends using biodegradable chain oil in
compliance with RAL-UZ-48 norm (ref. 85920 or, by default,
any oil in compliance with RAL-UZ-48 norm)
1– Press the triggers and keep them hold.
2– Set the battery switch to «I».
3– An automatic cycle starts which sends oil from the
reservoir to the chain guide.
- 1 short beep every 20 seconds during the cycle.
- 3 beeps to validate the end of the cycle.
4– Loosen the triggers when you hear the rst beep.
14
51_08_023B
3
18
2
51_08_024C
G
G
PUTTING THE TOOL INTO SERVICE
STARTING
1. Take the chain saw by the handles and ensure nothing is
touching the chain.
2. Attach the power supply cord to your arm using the
supplied armband.
3. The chain saw is in its “start-up” position.
HOLDING THE TOOL
1– Put the tool in its starting position (see page 20). Remove the
chain guide protector.
2– Set the battery On/Off switch. to the on position «I». From
the moment the indicator light (18) comes on and the
battery emits 3 beeps, the tool is energized and ready to
operate.
3– Press and hold the safety trigger (3) while holding the
chainsaw by the upper handle.
4– In order to guarantee chainsaw safety when relocating, an
electronic device blocks the motor control 3 seconds after the
motor is stopped. Press the trigger (2) twice consecutively to
restart the motor. The chainsaw runs by keeping at least the
trigger (2) pressed.
5– Release the trigger (2) to stop the motor.
CAUTION! Do not cut anything other than wood.
Always keep both hands on the handles.
CAUTION:
When either the guide or the chain is replaced, they must be run in by operating the tool off load
for 1 to 2 minutes.
Check the chain tension after running in (see page 23).
The tool is equipped with a Pellenc-designed electric motor. The motor maintains a constant
speed, both off load and when cutting.
Allow the chainsaw to cut without pressing excessively.
Always start the motor before bringing the chainsaw into contact with the wood.
To prevent the motor from overheating, alternate between large cuts and small cuts.
The light on the handle indicates that the power supply is switched on.
CAUTION:
Never disconnect the power lead from the battery
without checking that the On / Off switch is in the off
position «0».
15
51_08_025A
51_08_026A
51_08_027A
STARTING AND USE
INTRODUCTION
Make sure that the chain tension is correct by pulling the chain.
1 to 3 drive links should appear.
The automatic chain tensioning (PELLENC innovation)
facilitates tool maintenance!
The automatic chain tensioning system (PELLENC
innovation) facilitates the installation of the chain and its
tension adjustment. Position the guide, and clip it, the guide
is in position! You can permanently lock it in position using
the retractable wrench (PELLENC innovation).
The automatic chain tensioning along with the PELLENC
retractable wrench can also be used to retighten the guide in
a few seconds: no need for additional wrenches!
CHAIN BRAKE
Your chain saw is tted with an impact detection system
In the event of impact (bounce) your chain saw will stop
immediately.
Ensure the chain is not in contact with anything before
you start up the chain saw again.
CHECKING THE CHAIN BRAKE
Realize dry movements from top to bottom to activate the
safety device.
WARNING: never operate the chain saw if the safety
device is not operating.
16
51_08_028A
51_08_029A
51_08_033A
STARTING AND USE
AUTOMATIC CHAIN TENSIONING
INSTALLING THE CHAIN GUIDE
Simplied chain maintenance!
No need for an additional wrench to remove and reinstall the
chain, PELLENC’s innovative retractable wrench system can
be used to tighten the chain in a few seconds.
Loosen the chain guard (10) nut by 3 turns.
The chain is tensioned automatically when the guide moves
forward.
Tighten the chain guard nut correctly using the telescopic
wrench and put the wrench handle back on its magnetic
holder.
2 types of chain guide bar can be mounted on the chainsaw:
standard 12’’ guide bar (ref. 72884)
carving 12’’ guide bar (ref. 80344).
Do not use other chain guide bar than those recommended.
INSTALLING THE CHAIN
Adjust the tension of the chain.
Always set the switch to the off position «0» and disconnect
the battery connector before doing any work.
Remove the chain guard by unscrewing the chain guard (10)
lock.
Push the guide towards the sprocket to enage the lock.
Install the chain in accordance with the cutting direction.
Reinstall the chain guard.
Follow the chain installation procedure.
Replace the chain guide or turn it round if necessary.
The chain guide must be replaced whenever necessary
or when 3 or 4 chains have been replaced. Turn the
chain guide round every week.
Always set the switch to the off position «0» and disconnect
the battery connector before doing any work.
(P/No. 81794).
17
51_08_030A
51_07_015A
51_07_016A
51_08_025A
Adjust the tension as often as necessary.
Check the tension by pulling the chain in the middle of the
guide: 1 to 3 drive links should appear.
STARTING AND USE
CHECKING AND REPLACING THE SPROCKET
LUBRICATING THE CHAIN GUIDE
Lubricate the chain guide every day using a grease gun (P/
No. 68518).
CLEANING THE CHAIN GUIDE
Remove and clean the chain guide every day. Clean the
guide and the lubricating holes.
Remove the chain guide and the chain.
Remove the circlip and remove the sprocket.
Replace the sprocket whenever necessary or when two
chains have been replaced (P/No. 85643).
Reinstall the assembly and pay attention to the direction of
installation of the circlip.
Carry out this operation each time you change work
sites in order to disinfect the tool a little.
Clean the lubricating holes as often as necessary.
Always set the switch to the off position «0» and disconnect
the battery connector before doing work.
The circlip must be replaced each time it is removed
(P/No. 01357).
Always set the switch to the off position «0» and
disconnect the battery connector before doing work.
18
51_07_022A
51_07_021A
STARTING AND USE
RULE No. 1
The chain must be correctly tensioned.
See page 23
RULE No. 2
The chain must be well lubricated.
Constant lubrication of the guide, the chain and the sprocket
is vital.
See page 20
RULE No. 3
The depth limiters must be correctly adjusted.
The depth limiters must be correctly adjusted and of the right
shape to ensure good performance and safety.
See page 29
RULE No. 4
The chain must be sharpened.
If the chain is correctly sharpened, it will do the work. If it is
not correctly sharpened, its you who will do the work, and
your cutting accessories will wear out more rapidly.
See page 28
THE FOUR BASIC RULES
19
51_08_031A
G
G
SERVICING
Keep the tool clean by cleaning it frequently using a damp
cloth and compressed air. Pay particular attention to the
parts in contact with the wood (chain, guide).
CAUTION:
Never use solvents (Trichlorethylene, White Spirit, gasoline, etc) to clean the tool.
SERVICING INTERVALS
REMARK:
Overhaul the chain saw every 200 hours or at least once a year.
Make sure the chain saw is always clean and the battery charged before storage.
At each start-up
Every 2 hours
Each week
After use
Each year or when neces-
sary
Visual check of the tool X
Functional check of the safety trigger X
Check and topping up of the oil X X
Check of chain lubrication X
Check and tensioning of the chain X X
Check of chain sharpness X X
Check of chain brake X
Check and cleaning of the chain guide X
Greasing of the chain guide X
Check of sprocket wear X
Check of battery charge level X
Check of the tool by an authorized distributor X
CLEANING
20
G
SERVICING
REPLACING THE CHAIN AND THE GUIDE
WARNING:
Before working on the tool, check that the On / Off switch is in the off position «0» and disconnect
the battery power lead.
WARNING:
Never use a chain or a guide other than that specied by PELLENC, otherwise there is a risk
of personal injury.
Other manuals for Selion C21 HD
1
Table of contents
Other pellenc Chainsaw manuals
