Peltor DECT-Com II User manual



Repeaterinstallation
Installingrepeatersrequiresbothhardwareinstallationandsoftwareinstallation.
Increasecoverage
Therepeaterisabuildingblocktobeusedtoextendthecoverageareainasystem.Therepeater
doesnotincreasethenumberoftrafficchannels,howeveritprovidesalargerphysicalspreadingof
thetrafficchannelsandtherebyincreasesthecoverageareaestablishedwiththebasestations.The
repeatersaremainlyusedinareaswithlimitedtraffic.

Repeatersarewirelessanddoesnotneedanyphysicalconnectiontothebasestation,makingitvery
easytoinstall,itonlyneedmainspower.Therepeaterhasanexternalantennaconnectionwhich
allowsapossibilitytogetradiocoverageontheothersideofe.g.metalwall.

Therecanbe4talkchannelsoneachrepeateranditisonlypossibletorepeatthesoundonone
group,althoughitispossibletohaveatalkchannelonanyoftheactivatedgroupsontherepeater.
Whenusingrepeatersitisrecommendedtobeonatalkchannelsinceitwillgivethebetter
performance.
Repeatertypesandpartnumbers
PartdescriptionPartnumber
DECT‐ComII1.8GHzRepeater(excl.mainsadapter).DC2821
DECT‐ComII1.9GHzRepeater(excl.mainsadapter).DC2921
Mainsadapterforrepeater.DC2822
Repeaterprogrammingkit.DC2094
Repeaterindicator
TherepeaterhasoneLEDindicatorthedescribingtherepeateroperations:Whentheindicatorisoff,
therepeaterhasnotbeenpoweredup.WhentheLEDflashes,syncwiththebasehasnotbeen
established,assoonastherepeaterhassyncwiththebase,theLEDisconstantlylit.Foracorrect
functiontherepeatermustbeinsynchronizationwiththebasestationortherepeaterbeforeinthe
system.EachtimeaportablemakesahandovertotherepeatertheLEDwillflashoncetoindicateit
hascompletedahandover.
Repeaterinstallation
‐Radiocoveragedependsonbuildingconstructionmaterials,methodsofconstruction,and
thesurroundingenvironment.Therefore,eachinstallationisuniqueregardingthelocationof
basestations.

‐Avoidplacingbasestationsandrepeatersnearotherelectronicequipment,largemachinery,
metalconstructions,etc.,astherangecanbeseverelyaffected.Basestationandrepeaters
shouldbeplacedbetween6‐12feet/1.8‐3.6metersinheightonawallorupto30feet/10
meterswhensuspendedfromaceiling.Iftheyareplacedanylower,personswalkingaround
couldinterferewiththeradiosignal.Thecoverageareacanbeadverselyaffectedifthebase
stationandtherepeateraremountedimproperly.




‐Forefficienthandoverofconversationsbetweenbasestations,deployrepeaterswith
sufficientoverlapofradiocoverage.Coverageoverlapoccurswhentheradiofieldsofbase
stationandrepeatersoverlapeachother.Basestationandrepeatersmustbeplacedinsuch
awaythattheradiocoveragefromonebasestationtoarepeateroverlapsby30to45
feet/10‐15meters.Overlapsarenecessarytogivethehandsettimetodoahandovertoa
basestationorrepeaterfromwhichitreceivesabettersignalquality.

BASE REPEATER1REPEATER2REPEATER3
Coverageoverlap


‐Iftheoverlapareaisnotenough‐lessthan30–45feet/10‐15metersthereisariskofthe
connectionbeingdroppedwhilemovingfromonecoverageareatoanother.However,too
muchoverlapresultsinawastedcoveragearea.

‐Basestationsandrepeatersareomni‐directional,whichmeansthattheRFsignalis
propagatedverticallyandhorizontallyfromthebasestationsandrepeaters.Dependingon
buildingmaterialsthebasestationorrepeatercoverageareawilltypicallyextendtomore
thanonefloorofastructure.

‐Thehandsetwillnotnecessarilyswitchovertothebasestationorrepeaterfromwhichthe
strongestsignalisreceived.Thehandsetwillremainconnectedtoabasestationorrepeater
aslongasthequalityofthereceivedsignalisacceptable.

‐Differentweatherconditionscaninfluenceradiocoverage.Forexample,awetrooforwall
canactasashield.Also,newleavesontreesinthespringmightaffecttheradiocoverageof
basestationsandrepeaters.

‐Iftheconstructionmaterialsofthebuildingcontainmetal,signalreflectionmayoccur.When
signalreflectionsoccur,thesignalmaybeaffectedevenwhenthehandsetisverycloseto
thebasestation.Youshoulddocumenttheseareaswiththehelpofthecustomer.Ifyouare
awareofmetalinthebuildingconstruction,youhavetocarryoutaverythoroughsite
survey.

‐Therepeaterdoesnotaddchannels,itonlyaddsadditionalcoveragearea.




‐ForbestRFcoverage,therepeatermustbemountedverticallyonwall.Theantennasmust
alwaysbeperpendiculartothefloor.

‐CAUTION:Therepeatermustnotbeinstalledatanyangleotherthanvertical.Iftherepeater
isplacedupsidedown(powerinletpointingupwards),thecoverageareaisdecreasedby40
–50%.

Aftercompletingtheinstallationoftherepeaters,recordthelocationofeachrepeater.

Poweringtherepeaters
Insertthecordfromthemainsadaptor(DC2822)intothebottomoftherepeater,seepicturebelow.



Powersupplyfortherepeateris9VDC,300mA.





Programmingarepeaterwiththeprogrammingkit(DC2094)

Contentoftheprogrammingkit(DC2094).
‐Splitter
‐Serialcable
Setupofthehardware(DC2094)forrepeaterprogramming
‐Insertthesplitterintotherepeater.
‐Connecttherepeaterpowersupplyintothesplitterandmains.LEDstartstoflash.
‐ConnecttheserialcabletothesplitterandtheComportofyourcomputer.Therepeateris
nowreadyforprogrammingviathePeltorDect‐ComIIrepeatertool.
Note:theabovementionedorderofthesetupisveryimportant!
Programmingarepeaterwiththeprogrammingkit(DCS9)
ItisalsopossibletoprogramtherepeaterswiththeoldDCS9programmingdevice.
Setupofthehardwareforrepeaterprogramming
‐Insertthecorrectconnectorintotherepeater.
‐ConnectthepowersupplytoDCS9.LEDstartstoflash.
‐ConnectDCS9tothecomportonthecomputer.
‐TherepeaterisnowreadyforprogrammingviathePeltorDect‐ComIIrepeatertool.
Note:theabovementionedorderofthesetupisveryimportant!
PeltorDect‐ComIIrepeatertool





‐WritetheBASES/Nnumberintothe
firstfieldintheprogram.

‐Setiftherepeatershallsynchronizeon
thebaseorarepeaterdependingif
thereisachainconnection(maximum3
repeatersinachain)orstarconnection
(starconnection:allrepeatersshall
synchronizetothebase,chain
connection:repeater2shallsynchronize
onthebase,repeater3shall
synchronizeonrepeater2,seepicture
below).



Chainconnection
Starconnection
BASE1REP2REP3REP4
BASE1
REP2
REP4
REP5REP6
REP3



‐Setwhichnumbertherepeater(basestationisalwaysnumberone,thereaftermustthe
repeaternumbersbecountingupwardsinorder).
‐Setwhichgroupsounditshallrepeat.
‐Pressthe“Write”buttonandtherepeaterissetupok.
‐Powercycletherepeatertogetthechangesactivatedintherepeater.
