Pendo SDB-1201 Manual

WIRELESS
BLUETOOTH
SPEAKER
QUICK START GUIDE & USER MANUAL
> Please read carefully before use
PEN_1289_DS-1073_user manual_02.pdf 1 16/08/12 11:36 AM

1
Package Content
• Pendo speaker unit
• USB Cable
• Aux in cable
• User Manual
• Cleaning cloth
Features
The Pendo speaker plays all of your audio files from your MP3 players,
tablet PCs, smart phones and laptops.
Aux input lets you connect a portable music player with a 3.5mm cable
DC battery power: built-in rechargeable lithium ion Battery life: ~4hours
Wireless range: 10m
Supports Bluetooth v2.1
•
•
•
•
•
CONTENTS
A1:
A2:
On-Off
Line in
Push to turn the unit on/off
Input connection for an auxilliary
Main Unit
PEN_1289_DS-1073_user manual_02.pdf 2 16/08/12 11:36 AM

2
GETTING START
Pairing a Bluetooth Device
Turn on the unit and then search on your Bluetooth device for available
devices to Pair with. The Pairing Indicator will flash blue quickly to indicate
that the speaker unit is ready to pair.
When pairing, remain within 1 meter of the unit.
Using the native controls on your Bluetooth device, select the “SDB-1201” in
your Bluetooth settings to pair.
If your device requests a password, enter the default password “0000”.
Refer to the user’s manual for your specific device for instructions on pairing
and connecting and Bluetooth devices.
When successfully paired and connected, the Pairing Indicator will display a
solid blue light and a beep will sound from the unit.
After initial pairing, the unit will stay paired unless unpaired manually by the
user or erased due to a reset of the device.
1.
2.
3.
Pairing a Bluetooth Device
Follow the instructions for Pairing a Bluetooth Device.
Use the native controls on the connected Bluetooth device to select a track.
To play the selected track, use the native controls on the connected
Bluetooth device to play/pause or skip.
Audio played through the connected Bluetooth device will now be heard
through the speakers.
Use the native controls on the connected Bluetooth device to adjust
the volume.
You can put your Bluetooth device in the holder. This is just a support for
your device (no re-charging function) and suitable for many
tablets/smartphones.
1.
2.
3.
4.
5.
6.
device. A 3.5mm line-in cable is required
for this connection (included).
Lights up when charging (red color).
Input connection for power charging.
Lights up when the speakers is on.
BLUETOOTH mode: blue light.
AUX mode: red light.
A3:
A4:
Charging Indicator
USB port
Pairing
Indicator
A5:
PEN_1289_DS-1073_user manual_02.pdf 3 16/08/12 11:36 AM

POWER
3
Playing Other Audio Devices (AUX in)
Plug one end of a 3.5mm audio input cable into the 3.5mm Audio Input on
the unit.
Plug the other end of the cable into the audio output/headphone output on
an MP3 player or other audio source.
Turn the unit on.
Audio played through the connected device will now be heard through the
speakers.
Note: Any audio being played through a connected Bluetooth device will
cease once the 3.5mm Audio source is connected.
AC Power
Requires an AC power adapter (not included).
USB Power
Requires a Mini USB to USB cable (included).
Note: PC must not be in sleep mode.
Initial charge time 3-4 hours.
Please make sure the unit is fully charged before use.
1.
2.
3.
4.
PEN_1289_DS-1073_user manual_02.pdf 4 16/08/12 11:36 AM

4
LED INDICATOR
SPECIFICATIONS
Charging Indicator Light
Status
Power Off
Charging
Fully Charged
Low battery
Indicator
No light
Red light
Red light off
Auto power off
Pairing Indicator Light
Status
Power Off
Ready to Pair
Bluetooth Connected
Line In Mode
Indicator
No light
Quickly flashing blue light
Slowly flashing blue light
Red light
Frequency Response
Impedance
Aux Input
Output Power
Li-battery
Unit Dimensions (L*W*H*)
Li-battery
120Hz-20KHz
4Ω
3.5mm
1.3x2(RMS)
3.7V 900mA
243x105x58mm
Nominal Voltage: 3.7V
Rated Capacity:900mAh
PEN_1289_DS-1073_user manual_02.pdf 5 16/08/12 11:36 AM

5
TROUBLESHOOTING
I cannot turn the unit on.
Ensure that the Li-battery of speaker unit is fully charged via a USB cable
connected to AC power or PC (PC must not be in sleep mode).
*
There is no sound during Bluetooth playback.
Increase the volume level of the speaker unit.
Try the following steps:
a. Disconnect the Bluetooth device.
b. Turn off the unit, wait 10 seconds, then turn the unit on again.
c. Reconnect the Bluetooth to the speaker.
There is no sound during AUX in playback.
If a Bluetooth devise is connected to the speaker, disconnect it.
Ensure that the headphone jack of the audio device is connected securely to
the AUX in jack on the back of the speaker unit.
Increase the volume level of the audio device; the increase the volume level
of the speaker unit.
*
*
*
The sound is distorted.
Ensure that all connections are secure.
Try reducing the volume level.
If your device supports it, try reducing the bass level.
*
*
*
*
*
