1
MICROWAVE
OVEN
USER’S MANUAL
Please read these instructions carefully
before installing and operating the oven.
FOR MODEL:
1PMW13

23
Precautions to Avoid Possible Exposure to Excessive Microwave Energy ............4
Important Safety Instructions ...................................................................................... 4
Ground Instructions ..................................................................................................... 6
Installation Guide .............................................................................................................8
Cooking Utensils Guide ...................................................................................................5
Specications ..................................................................................................................9
Product Diagram ..............................................................................................................9
Control Panel .................................................................................................................10
Operation Instructions ....................................................................................................11
Setting the clock .....................................................................................................11
Express cooking .....................................................................................................11
+30 sec. function ....................................................................................................11
Setting the timer .....................................................................................................12
Microwave cooking ................................................................................................12
Time defrost ...........................................................................................................13
Weight defrost ........................................................................................................13
Cook by weight ......................................................................................................14
Multistage cooking .................................................................................................14
Child lock ...............................................................................................................15
Button closed protection ........................................................................................15
Auto cook ...............................................................................................................16
Maintenance ..................................................................................................................17
1. Do not attempt to operate this oven with the
door open since open-door operation can
result in harmful exposure to microwave
energy. It is important not to defeat or
tamper with the safety interlocks.
2. Do not place any object between the oven
front face and the door or allow soil or
cleaner residue to accumulate on sealing
surfaces.
3. Do not operate the oven if it is damaged.
It is very important that the oven door close
properly and that there is no damage to the
a) Door (including any bent),
b) Hinges and latches (broken or loosened),
c) Door seals and sealing surfaces.
4. The oven should not be adjusted or repaired by
anyone except qualied service personnel.
PRECAUTIONS
TO AVOID
POSSIBLE EXPOSURE
TO EXCESSIVE
MICROWAVE ENERGY
CONTENT

45
IMPORTANT SAFETY INSTRUCTIONS
WARNING! - To reduce the risk of burns, electric shock, re, injury to persons or exposure to
excessive microwave energy:
1. Read all instructions before using the appliance.
2. Read and follow the specic “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY” on page 1.
3. This appliance must be grounded. Connect only to properly grounded outlet. See “GROUNDING
INSTRUCTIONS” on page 4.
4. Install or locate this appliance only in accordance with the provided installation instructions.
5. Do not operate the oven when empty.
6. Some products such as whole eggs and sealed containers -for example, closed glass jars- are able to
explode and should not be heated in this oven.
7. Use this appliance only for its intended use as described in this manual. Do not use corrosive
chemicals or vapors in this appliance. This type of oven is specically designed to heat, cook, or dry
food. It is not designed for industrial or laboratory use.
8. As with any appliance, close supervision is necessary when used by children.
9. To reduce the risk of re in the oven cavity:
a) Do not overcook food. Carefully attend appliance when paper, plastic, or other combustible
materials are placed inside the oven to facilitate cooking.
b) Remove wire twist-ties from paper or plastic bags before placing bag in oven.
c) If materials inside the oven should ignite, keep oven door closed, turn oven off, and disconnect
the power cord or shut off power at the fuse or circuit breaker panel.
d) Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils or
food in the cavity when not in use.
10. Liquids, such as water, coffee, or tea are able to be overheated beyond the boiling point without
appearing to be boiling due to surface tension of the liquid. Visible bubbling or boiling when the
container is removed from the microwave oven is not always present. THIS COULD RESULT IN
VERY HOT LIQUIDS SUDDENLY BOILING OVER WHEN A SPOON OR OTHER UTENSIL IS
INSERTED INTO THE LIQUID. To reduce the risk of injury to person:
a) Do not overheat the liquid.
b) Stir the liquid both before and halfway through heating it.
c) Do not use straight-sided containers with narrow necks.
d) After heating, allow the container to stand in the microwave oven for a short time before
removing the container.
e) Use extreme care when inserting a spoon or other utensil into the container.
11. Do not heat oil or fat for deep-frying. It is difcult to control the temperature of oil in microwave oven.
12. Do not cover or block any openings on the appliance.
13. Do not store or use this appliance outdoors. Do not use this product near water, for example, near a
kitchen sink, in a wet basement, near a swimming pool, or similar locations.
14. Do not operate this appliance if it has a damaged cord or a plug, if it is not working properly or if it has
been damaged or dropped.
15. Do not immerse cord or plug in water. Keep cord away from heated surface. Do not let cord hang
over edge of table or counter.
16. This appliance should be serviced only by qualied service personnel, contact nearest authorized
service facility for examination, repair, or adjustment.
17. When cleaning surfaces of door and oven that comes together on closing the door, use only mild,
nonabrasive soaps, or detergents applied with a sponge or soft cloth.
18. This equipment has been tested and found to comply with Part 18 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause undesired
operation.
CAUTION: Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the product.
19. This equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
SAVE THESE INSTRUCTIONS

67
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces risk of
electric shock by providing an escape wire for the electric current. This appliance is equipped with a cord
having a grounding wire with a grounding plug. The plug must be plugged into an outlet that is properly
installed and grounded.
WARNING! - Improper use of the grounding plug can result in a risk of electric shock.
Consult a qualied electrician or serviceman if the grounding instructions are not completely understood,
or if doubt exists as to whether the appliance is properly grounded, and if it is necessary to use an exten-
sion cord, use only a 3-wire extension cord that has a 3-blade grounding plug and a 3-slot receptacle that
will accept the plug on the appliance. The marked rating of the extension cord shall be equal to or greater
than the electrical rating of the appliance.
Electrical Requirements
The electrical requirements are 120-volt 60 Hz, 15 amp. It is recommended that a separate circuit serving
only the oven be provided. The oven is equipped with a 3-prong grounding plug. It must be plugged into a
wall outlet properly installed and grounded.
Power Cord
1. A short power supply cord is provided to reduce the risks resulting from becoming entangled in or
tripping over a longer cord.
2. Longer cord sets or extension cords are available and may be used if care is exercised in their use.
3. If long cord or extension cord is used:
a) The marked electrical rating of the cord set, or extension cord should be at least as great as
the electrical rating of the appliance.
b) The extension cord must be a grounding-type 3-wire cord, and The longer cord should be
arranged so that it will not drape over the countertop or tabletop where it can be pulled on by
children or tripped over unintentionally.
GROUNDING INSTRUCTIONS INSTALLATION GUIDE
1. Make sure that all the packing materials are removed from the inside of the door.
2. This microwave oven must be placed on a at.
3. For correct operation, the oven must have enough air ow. Allow 20cm of space above the oven,
10cm at back and 5cm at both sides. Do not cover or block any openings on the appliance.
Do not remove feet on which oven stands.
4. Do not operate the oven without glass tray, roller support, and shaft in their proper positions.
5. Make sure that the power cord is undamaged and does not run under the oven or over any hot or
sharp surface.
6. The socket must be readily accessible so the microwave oven can be easily unplugged in an
emergency.

7
Specifications
Power Consumption
120V/60Hz, 1400W(microwave)
Output
1000W
Operation Frequency
2450MHz
Outside Dimensions (W x Hx D)
21.22 x 11.81 x 17.71 in
Oven Capacity
1.3cu.ft.
Net Weight
38.13lb.
Product Diagram
1. Door Safety Lock System
2. Oven Window
3. Shaft
4. Roller Ring
5. Control Panel
6. Wave Guide (Please do not remove the
mica plate covering the wave guide)
7. Glass Tray
•MAKE NUMBERS MORE OBVIOUS, MAYBE NO CIRCLES.
89
COOKING UTENSILS GUIDE
Recommended
Microwave browning dish — Use to brown the exterior of small items such as steaks, chops, or
pancakes. Follow the directions provided with your browning dish.
Microwaveable plastic wrap — Use to retain steam. Leave a small opening for some steam to escape
and avoid placing it directly on the food.
Paper towels and napkins — Use for short-term heating and covering; these absorb excess moisture and
prevent spattering. Do not use recycled paper towels, which may contain metal and could ignite.
Glass and glass-ceramic bowls and dishes — Use for heating or cooking.
Paper plates and cups — Use for short-term heating at low temperatures. Do not use recycled paper,
which may contain metal and could ignite.
Wax paper — Use as a cover to prevent spattering.
Thermometers — Use only those labeled “Microwave Safe” and follow all directions. Check the food in
several places. Conventional thermometers may be used on microwave food once the food has been
removed from the oven.
Limited Use
Aluminum foil — Use narrow strips of foil to prevent overcooking of exposed areas. Using too much foil
can damage your oven, so be careful. You should keep distance of 1 inch (2.54cm) between aluminum
foil and cavity.
Ceramic, porcelain, and stoneware — Use these if they are labeled “Microwave Safe”. If they are not
labeled, test them to make sure they can be used safely.
Plastic — Use only if labeled “Microwave Safe”. Other plastics can melt.
Not Recommended
Glass jars and bottles — Regular glass is too thin to be used in a microwave. It can shatter and cause
damage and injury.
Paper bags — These are a re hazard, except for popcorn bags that are designed for microwave use.
Styrofoam plates and cups — These can melt and leave an unhealthy residue on food.
Plastic storage and food containers — Containers such as margarine tubs can melt in the microwave.
Metal utensils — These can damage your oven. Remove all metal before cooking.
Note: Should you wish to check if a dish is safe for microwaving, place the empty dish in the oven and microwave on HIGH for
30 seconds. A dish which becomes very hot should not be used.
SPECIFICATIONS
Power Consumption 120V/60Hz, 1400W(microwave)
Output 1000W
Operation Frequency 2450MHz
Outside Dimensions (W x H x D) 21.22 x 11.81 x 17.71 in
Oven Capacity 1.3 cu.ft.
Net Weight 38.13lb
PRODUCT DIAGRAM
➊ Door Safety Lock System
➋Oven Window
➌Shaft
➍Roller Ring
➎Control Panel
➏Wave Guide
(Please do not remove
the mica plate covering
the wave guide)
➐Glass Tray ➊
➍
➎
➏
➋
➌
➐

10 11
CONTROL PANEL
8
Control Panel
lDISPLAY
Cooking time, power, indicators and clock time are displayed.
lAUTO COOK MENUS
There are 6 kinds of auto cook menus. Use to set auto cook
program.
lCLOCK
Press to set clock time.
lDEFROST
Press to set defrost program based on time.
Press to set defrost program based on weight.
lTIMER
Press to set the oven timer function.
lPOWER LEVEL
Press to set microwave power level.
lTIME COOK
Press to set microwave cooking program.
lCOOK BY WEIGHT
Press to set cooking program based on weight.
lNUMBER BUTTONS (0-9)
Press to adjust power level, set time or food weight.
But use number buttons from 1 to 6 can set express
cooking program.
lSTOP/CLEAR
Press to cancel setting or reset the oven before setting a
cooking program.
Press once to temporarily stop cooking, or twice to cancel
cooking altogether.
•Display
Cooking time, power, indicators and clock time are
displayed.
•Auto Cook Menus
There are 6 kinds of auto cook menus. Use to set
auto cook program.
•Clock
Press to set clock time.
•Defrost
Press to set defrost program based on time.
Press to set defrost program based on weight.
•Timer
Press to set the oven timer function.
•Power Level
Press to set microwave power level.
•Time Cook
Press to set microwave cooking program.
•Cook By Weight
Press to set cooking program based on weight.
•Number of Buttons (0-9)
Press to adjust power level, set time or food weight.
But use number buttons from 1 to 6 can set express
cooking program.
•Stop/Clear
Press to cancel setting or reset the oven before
setting a cooking program.
Press once to temporarily stop cooking, or twice to
cancel cooking altogether.
It is also used for setting child lock function.
•Stop/+30 Sec.
Press to start cooking program.
Simply press it several times to set cooking time
and cook immediately at full power level.
OPERATION INSTRUCTIONS
➢ When the oven rst plugged in, beep will sound, and the display will show “1:01” and clock icon.
➢ In the process of cooking setting, broke about 30 seconds the oven will return to standby mode.
➢ During cooking, if press STOP/CLEAR button once, the program will be paused, then press
START/+30 SEC. button once to resume, but if press STOP/CLEAR button twice, the program will
be canceled.
➢ After cooking end, the screen will display End with sound every two minutes until user press STOP/
CLEAR button or open the door.
Setting the Clock
This is a 12- or 24- hour clock, and you can select it by pressing CLOCK button.
1. In standby mode, press CLOCK button once or twice to select 12- or 24- hour clock.
2. Use number buttons to enter correct time.
3. Press CLOCK button again to conrm.
Note: During cooking, the current time of the clock can be seen by pressing CLOCK button
Express Cooking
Directly in standby mode, press number button once (1-6), the corresponding system direct start cooking
time respectively 1 minute, 2 minutes, 3 minutes, 4 minutes, 5 minutes and 6 minutes. The oven will start
to cook at full power level.
30 Sec. Function
In standby mode, press START/+30 SEC. button repeatedly to enter cooking time (each press to increase
30 seconds, and up to 99 minutes and 99 seconds). The oven will auto start cooking at full power level.
Note: During express cooking and microwave cooking program, you can add cooking time by pressing
START/+30 SEC. button.

12 13
Setting Timer
1. Press TIMER button once.
2. Press number buttons to enter the amount of time. The longest time is 99 minutes and 99 seconds.
3. Press START/+30 SEC. button to conrm.
Note: When the countdown ends, the buzzer will beep to remind you. You can check the countdown time
by pressing TIMER button, but if STOP/CLEAR button is pressed when the display shows the time, the
function can be cancelled.
Microwave Cooking
1. Press TIMER button once.
2. Press number buttons to enter the amount of time. The longest time is 99 minutes and 99 seconds.
3. Press START/+30 SEC. button to conrm.
Note: When the countdown ends, the buzzer will beep to remind you. You can check the countdown time
by pressing TIMER button, but if STOP/CLEAR button is pressed when the display shows the time, the
function can be cancelled.
Use single digit to set a cooking power level:
Note: During cooking, the current cooking power level can be seen by pressing POWER LEVEL button.
If you want to set 100% power level, you can omit the step 3 given above.
Number button Cooking power (Display) Number button Cooking power (Display)
1,0 100% (100) 4 40% (40)
9 90% (90) 3 30% (30)
8 80% (80) 2 20% (20)
7 70% (70) 1 10% (10)
6 60% (60) 0 0% (0)
5 50% (50)
Time to Defrost
1. In standby mode, press DEFROST button once.
2. Press number buttons to enter defrosting time. The longest time is 99 minutes and 99 seconds.
3. Press START/+30 SEC. button to start.
Note: During defrosting program, the system will pause and sound beeps to remind user to turn food
over, and then press START/+30 SEC. button to resume.
Weight Defrost
1. In standby mode, press WEIGHT DEFROST button twice.
2. Press number buttons to enter weight of food. The frozen food weight ranges from 4 oz ~ 4 LB.
3. Press START/+30 SEC. button.
Note: • During defrosting program, the system will pause and sound to remind user to turn food over, after
that, press START/+30 SEC. to resume the defrosting.
• Weight must be in pounds and ounces. If label gives weight in pounds only, change the fraction of
a pound to ounces using the following chart.
Converting fractions of a pound to ounces:
Fractions of a pound Ounces Fractions of a pound Ounces
Less than .03 0.54 to .59 9
.03 to .09 1 .60 to .65 10
10 to .15 2 .66 to .71 11
.16 to .21 3 .72 to .78 12
.22 to .27 4 .79 to .84 13
.28 to .34 5 .85 to .90 14
.35 to .40 6 .91 to .97 15
.35 to .40 7 above .97 go to next even
47 to .53 8

14 15
Cook by Weight
The cooking time and power level are adjusted automatically once the food category and the weight are
programmed.
1. In standby mode, press COOK BY WEIGHT button once.
2. Press number buttons (1~3) to select a food code. (1 signs beef, 2 signs mutton, 3 signs pork).
3. Enter the food weight by pressing number buttons.
4. Press START/+30 SEC. button.
Cook by weight code description:
Note: • Meat must be defrosted and at refrigerated temperature..
• Weight must be in pounds and ounces. If label gives weight in pounds only, change the fraction of
a pound to ounces using the following chart.
• During cooking, the system will pause automatically and sound to remind user to turn food over,
after that press START/STOP to resume cooking.
• Let meat stand a few minutes before carving.
Multistage Cooking
Your oven can be programmed up to 3 automatic cooking sequences. Only when speed defrost be set in
the rst sequence, you can set 3 cooking sequences. Microwave can only set 2 cooking sequences.
A. Time defrost with one or two-stage microwave cooking
1. Open the door and place the food into the oven, close it.
2. Press DEFROST button once.
3. Enter desired defrosting time by pressing correct number buttons.
4. Input the rst microwave cooking program. Do not press START/+30 SEC. button.
Code Type Weight Range
1 Beef 4 oz~5 LB. 16 oz
2 Mutton 4 oz~5 LB. 16 oz
3 Pork 4 oz~4 LB. 8 oz
5. Input the second microwave cooking program.
6. Press START/+30 SEC. to start.
Note: Step 5 is not necessary if you have one microwave cooking program. Time defrost can only be set
in the rst stage.
B. Two-stage microwave cooking
Some recipes require different stages of cooking at different temperatures.
1. Input the rst microwave cooking program. Do not press START/+30 SEC. button.
2. Input the second microwave cooking program.
3. Press START/+30 SEC. to start.
Child Lock
The lock prevents unsupervised operation by children.
To set: In standby mode, press and hold the STOP/CLEAR button for 3 seconds, a beep sounds and lock
indication appears on the display for 3 seconds, the oven will auto enter child lock mode. In the lock state,
all buttons are disabled.
To cancel: Press and hold the STOP/CLEAR button for 3 seconds to cancel the program, a beep will
sound, and the indicator light will come off.
Button Closed Protection
In any state, if any button on the control panel is closed for 1 minute, the program stops working
immediately, the display shows “FAIL” and the system will sound beep. If the button keep closing,
beep will sound every, one minute. Any button is invalid currently. After troubleshooting, press the
STOP/CLEAR button to return standby mode.

16 17
Auto Cook
For the following food and cooking mode, it is not necessary to program the cooking time and power. It is
enough to indicate the type of food that you want to cook as well as the weight or servings of this food.
1. Press the corresponding menu button once or repeatedly to select the food weight or servings.
2. Press START/+30 SEC. button.
Auto cook menus:
Food Note:
Potato (8 oz/serving, 1-2 servings) The result of auto cook depends on factors
such as the shape and size of food, your
personal preference as to the doneness of
certain foods and even how well you happen
to place food in the oven. If you nd the result
at any rate not quite satisfactory, please adjust
the cooking time a little bit accordingly.
Popcorn (3.2 oz)
Pizza (6 oz, 11 oz, 16 oz)
Beverage (200 ml/cup, 1-3 cups)
Frozen Dinner (9 oz, 18 oz)
Reheat (7-28 oz)
MAINTENANCE
1. When cleaning the unit please be sure to turn off the unit and unplug the unit from the outlet.
2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe
with a damp cloth. Mild detergents may be used if the oven gets very dirty. Avoid using harsh cleaners
that may stain, streak or dull the door surface.
3. The outside of the oven should be cleaned with a damp cloth. To prevent damage to the operating
parts inside the oven, water should not be allowed to seep into the ventilation openings.
4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp
cloth to remove any spills or spatters. Do not use abrasive cleaner.
5. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the
control panel, leave oven door open to prevent oven from accidentally turning on.
6. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may
occur when the microwave oven is operated under high humidity condition. And it is normal.
7. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy water
or in a dishwasher.
8. The roller ring and oven oor should be cleaned regularly to avoid excessive noise. Simply wipe the
bottom surface of the oven with mild detergent. The roller ring may be washed in mild, soapy water or
in a dishwasher. When removing the roller ring, be sure to replace it in the proper position.
9. Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in a
microwaveable bowl. Microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.
10. If the light bulb burns out, please contact customer service to have it replaced.
11. The oven should be cleaned regularly, and any food deposits should be removed. Failure to maintain
the oven in a clean condition could lead to deterioration of surface that could adversely affect the life
of the unit and could possibly result in a hazardous situation.
12. Please do not dispose of this appliance into the domestic rubbish bin; it should be disposed to the
disposal center provided by the municipalities.
If you’re looking for quality home appliances, visit our website.
