Perge MC 5.20 CI Guide

190171- H (122010)
INSTALLATION AND USER INSTRUCTIONS
M C S E R I E S L O G B O I L E R
MC 5-20 CI 5/20 kW.
MC 5-30 CI PF 5/30 kW.
MC 5-30 CI GF 5/30 kW.

• INTRODUCTION AND REQUIREMENTS
Overview 3
Safety and Approvals 4
• INSTALLATION
Chimney and Flue Re uirements 5
General Re uirements 5
Boiler Description 6
• MISCELLANEOUS
Boiler Identification 7
Boiler Specification 7
Boiler / Appliance Contents 8
Boiler Dimensions 9
• ASSEMBLY
Boiler Assembly 10
• SETUP AND USE
Fitting and Calibration of the Thermostat 11
Use and Operation 11
• MAINTENANCE
Periodic Maintenance Re uirements 12
Ash Removal and Upper Chamber Cleaning Instructions 12
Rear Spigot Ash Door Cleaning and Removal 12
C ntents 2

3 Overview
C nf rmity
Thank you for purchasing a boiler from the Perge range of central heating boilers, please take time
to read the following guidance instructions on how to install and use your new boiler. It is important
that these guidelines are followed in order to give optimum performance from your new Perge boiler.
IMPORTANT: FOLLOWING INSTALLATION, PLEASE ENSURE THAT THESE INSTRUCTIONS ARE LEFT WITH THE USER
FOR FUTURE USE AND SERVICING.
To maintain the boilers high thermal efficiency and give trouble free operation, it should be serviced annually by
a suitably ualified heating engineer. THIS I S ALSO A CONDITION OF THE PRODUCT GUARANTEE.
Please contact Perge should you need help in finding an engineer.
All electrical work should be carried by a ualified electrician, in accordance with the latest regulations. Before
attempting any work on the boiler or system controls, ensure the mains supply is disconnected.
The boiler can be connected to most normal heating systems, but should there be any doubt in the application
please call Perge for further information. As it is a continuously burning appliance, it should be connected to a
heat-bleed device (such as a radiator) to dissipate any heat produced, due to a system pump failure. It is also
advisable to connect the integral 'Quench Coil' fitted as standard to all Perge MC series boilers.
This appliance must be installed in accordance with current Building Standards and Regulations, by an approved / com-
petent person.
The MC 5.20 CI and MC 5.30 CI both conform to European Directive:
EN 303-5
MC CI m del range
MODEL CODE
MC 5.20 CI 902 007
MC 5.30 CI PF 902 011
MC 5.30 CI GF 902 020

4 Safety and approvals
● It is a legal re uirement that the installa<on of this appliance is in accordance with Local Building Control Approval
and is installed by a ualified/competent person. We strongly recommend that a ualified heating & plumbing engi-
neer carries out this work. HETAS Ltd operate such a scheme and a listing of their competent persons can be found on
their website: www.hetas.co.uk.
● The boiler should be located on a level non-combustible surface, with suitable load bearing capacity.
● Allow sufficient room around the boiler for maintenance and cleaning.
● Ensure the customer is presented with this manual following installa<on.
● Ensure the appliance is installed and maintained in accordance with these instruc<ons. Failure to do so may result in
unsafe operation, and will invalidate any guarantee or warranty. The appliance and flue should be inspected and
cleaned annually. More fre uent cleaning may be re uired if unseasoned wood is used. Consult a ualified chimney
sweep or heating engineer if in any doubt.
● Improper use of this appliance can lead to injury or death of the user or third a party. Therefore, ensure the appli-
ance is installed in accordance with this manual and any rules in force. Any faults should be fixed immediately to en-
sure safe operation. The manufacturer accepts no responsibility for improper use and/or installation of this appliance.
This includes maintaining the installation, operation and conditions specified by the manufacturer.
B iler L cati n Requirements and Safety N tes.
THESE BOILERS MUST BE INSTALLED IN ACCORDANCE WITH CURRENT BUILDING STANDARDS AND REGULATIONS
AND ANY LOCAL BYE LAWS, BY A SUITABLY QUALIFIED/COMPETENT PERSON.

Requirements 5
Chimney/ Flue requirements
Chimney installations and Ventilation should conform to re uirements of the Building Regulations and approved
Document J and all subse uent standards referred to. IF IN DOUBT CONSULT PERGE OR HETAS FOR ADVICE.
Twin wall insulated flue should be specified for use with multifuel / wood burning appliances.
Existing clay/brick chimneys should be lined with a flexible liner suitable for use with multifuel / wood burning
appliances.
If in any doubt as to the suitability of the flue or chimney, consult a flue manufacturer or Perge.
If the appliance is NOT used in conjunction with an accumulator tank, then it is advisable to fit a " flue damper /
stabiliser " to ensure correct operation in all conditions. Refer to the manufacturer for more advice.
A minimum effective flue height of 3 metres is recommended for use. Take into account any bends or elbows when
calculating this re uirement.
A soot door should be provided to aid in cleaning and servicing of the boiler installation.
A minimum height of 600mm above the boiler to any bend is re uired, taking into account that each bend will re uire
an additional flue height to be provided. Any bend should be no greater that 45 degrees.
IMPORTANT: A FLUE DRAUGHT OF BETWEEN 13 and 18 PASCAL IS REQUIRED WHEN RUNNING AT RATED OUTPUT.
ADDITIONAL FLUE PULL SHALL REQUIRE A DRAUGHT STABILISER TO BE FITTED TO PREVENT OVER-FIRING
General requirements
Electrical System
All the electrical connections and installation to the system or controls should conform to all relevant directives and
guidelines within EEC and part P building regulations within the UK.
Water
The heating system must be filled with water in accordance with BS 7593 (most recent revision). Code of Practice for
treatment of water in domestic hot-water and central heating systems guidelines "Avoiding Damage In Hot Water Sys-
tems"
Ventilation
Ventilation to the appliance should be provided in accordance with Document J of the Building regulations
Pressurised Systems
Any pressurised system MUST have a sufficiently sized expansion vessel fitted (10% of volume) and suitable PRV. In
addition the integral Anti-Boiling uench coil must be connected to a suitable mechanical safety valve (95degC)

6 Boiler information
The Perge MC series boilers are a range of wood burning boilers with ceramic combustion chamber technology.
The uni ue design of the Perge MC series boilers are covered by a patent No 8 211 712
They can be used for :
- Domestic Hot Water Only (in summer)
- Central Heating and Domestic Hot Water (in winter)
- Heating Only
These boilers can be designed into existing system layouts and/or alongside an accumulator tank to provide
flexibility of heating requirements.
The PERGE MC series boilers are comprised of a two part heat exchanger combustion
chamber.
- B tt m Heat Exchanger (1) : consisting of a high temperature refractory ceramic com-
bustion chamber with parallel heat exchanger tubes embedded in it (2).
- Upper Chamber (3) designed to maximise efficiency by incorporating a series
of water filled tubes through which flue gases pass.
- Anti-B iling Quench C il (4) : to prevent overheating.
Fuelbed Grate / Cleaning Door(5) to allow access for
cleaning and ash removal. This also houses the
primary air entrainment control system (6). Access to
the main combustion chamber is made through the
loading door (7), in order to load the chamber/ fuel bed
with logs.
A therm stat (8) automatically maintains the boiler water
temperature by controlling the primary air entrainment to
the combustion chamber (6).
*f r perating details n the therm stat see p 11.
B iler descripti n
Safety features
- Anti-Boiling Quench Coil, which can be connected to mains cold water to operate via a thermostatic valve should the
boiler reach boiling point.
This feature comes as standard on all the MC series boilers, but is an optional feature for use in open vented systems.

Miscellaneous 7
A Data Plate for each boiler is fitted to the top rear of the appliance, beneath the top cover.
This is re uired when calling regarding a spares or technical en uiry.
B iler Specifiati n

8 Miscellaneous - cont.
Appliance C ntents
B x 1: Contains the main boiler / combustion chamber engine unit; which is shrink-wrapped.
The following accessories are located within the boiler combustion chamber:
B x 3: Cardboard box containing the following components:
B x 2: 1 vertical flue spigot
(see pages 13 and 16)

Miscellaneous - cont. 9
B iler dimensi ns
Prior to installation, it is important to decide on the right location for your boiler:
- Locate your boiler so that you are able to easily access stored wood fuel
- Ensure there is sufficient access to load and clean the boiler
- Ensure the boiler is located in a dry, weather resistant atmosphere
- Allow a minimum 600 mm around the boiler for access and servicing

10 Assembly
B iler assembly

Technical 11
Fitting and calibrati n f the therm stat (Cal rstat)
Operati n f the b iler
- It is imp rtant t ensure that all installati n requirements are met.
- Pri r t initial use f the b iler, it is IMPORTANT that the b iler is fired at a reduced perating temperature in r-
der t drive any m isture fr m the refract ry ceramic c mbusti n chamber. In rder t d this the b iler sh uld be
run f r the first 8 h urs, firing at a reduced fuel l ad (setting the cal rstat at 40°C/50°C). This can then be progres-
sively increased.
Cracking of the combustion chamber ceramic will occur; this is normal and will not affected the operation of the boiler.
Position the control lever so that the chain in line with the primary air
damper. The regulator is factory set for vertical operation.
For a horizontal setting place the regulator control to read 30°C, then re-
move and rotate clockwise half a turn before refitting.
To set the chain position, set the control knob to read 80 degrees centi-
grade. When the thermometer indicates 80°C. Connect the chain to the
damper to give an opening gap of 1mm - 2mm. This will ensure correct
operation of the primary air control.

12 Operation and maintenance
It is important for both efficient and safe operation of the boiler that the following operations are carried out. Detailed be-
low are instructions on the removal of ash form the boiler and cleaning of the upper heat tubes and combustion chamber
Periodic maintenance
Ash removal and upper heat exchanger tube cleaning instruction
Ash door (rear spigot connection) (twice per month)
Remove the rear ash
trap collector plate and
dispense any ash that
may have collected.
Remove with two
screws, and replace.
