Pertronic Villa Door Station User manual

Video Intercom Villa Door Station
User Manual

Video Intercom Villa Door Station User Manual
i
Legal Information
About this Manual
The Manual includes instructions for using and managing the Product. Pictures, charts, images and
all other information hereinafter are for description and explanation only. The information
contained in the Manual is subject to change, without notice, due to firmware updates or other
reasons. Please find the latest version of this Manual at the company website Please use this
Manual with the guidance and assistance of professionals trained in supporting the Product.
Trademarks Acknowledgement
Trademarks and logos mentioned are the properties of their respective owners.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI
Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. in the United
States and other countries.
LEGAL DISCLAIMER
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE PRODUCT
DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE PROVIDED “AS IS” AND
“WITH ALL FAULTS AND ERRORS”. OUR COMPANY MAKES NO WARRANTIES, EXPRESS OR IMPLIED,
INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR
A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT
WILL OUR COMPANY BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR LOSS OF
DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT (INCLUDING NEGLIGENCE),
PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH THE USE OF THE PRODUCT, EVEN IF
OUR COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF INTERNET PROVIDES FOR INHERENT SECURITY RISKS,
AND OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITIES FOR ABNORMAL OPERATION,
PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM CYBER-ATTACK, HACKER ATTACK,
VIRUS INSPECTION, OR OTHER INTERNET SECURITY RISKS; HOWEVER, OUR COMPANY WILL
PROVIDE TIMELY TECHNICAL SUPPORT IF REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND YOU ARE
SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE APPLICABLE LAW.
ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A MANNER THAT DOES NOT
INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING WITHOUT LIMITATION, RIGHTS OF
PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR DATA PROTECTION AND OTHER PRIVACY RIGHTS.
YOU SHALL NOT USE THIS PRODUCT FOR ANY PROHIBITED END-USES, INCLUDING THE
DEVELOPMENT OR PRODUCTION OF WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR
PRODUCTION OF CHEMICAL OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED
TO ANY NUCLEAR EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN

Video Intercom Villa Door Station User Manual
ii
RIGHTS ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW, THE LATER
PREVAILS.

Video Intercom Villa Door Station User Manual
iii
Symbol Conventions
The symbols that may be found in this document are defined as follows.
Symbol Description
Danger Indicates a hazardous situation which, if not avoided, will or could
result in death or serious injury.
Caution
Indicates a potentially hazardous situation which, if not avoided,
could result in equipment damage, data loss, performance
degradation, or unexpected results.
Note Provides additional information to emphasize or supplement
important points of the main text.

Video Intercom Villa Door Station User Manual
iv
Safety Instruction
●WarningThe working temperature of the device is from -10 ºC to 55 ºC.
●All the electronic operation should be strictly compliance with the electrical safety regulations,
fire prevention regulations and other related regulations in your local region.
●Please use the power adapter, which is provided by normal company. The power consumption
cannot be less than the required value.
●Do not connect several devices to one power adapter as adapter overload may cause over-heat
or fire hazard.
●Please make sure that the power has been disconnected before you wire, install or dismantle
the device.
●When the product is installed on wall or ceiling, the device shall be firmly fixed.
●If smoke, odors or noise rise from the device, turn off the power at once and unplug the power
cable, and then please contact the service center.
●If the product does not work properly, please contact your dealer or the nearest service
center. Never attempt to disassemble the device yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or maintenance.)
●Caution
●Do not drop the device or subject it to physical shock, and do not expose it to high
electromagnetism radiation. Avoid the equipment installation on vibrations surface or places
subject to shock (ignorance can cause equipment damage).
●Do not place the device in extremely hot (refer to the specification of the device for the detailed
operating temperature), cold, dusty or damp locations, and do not expose it to high
electromagnetic radiation.
●The device cover for indoor use shall be kept from rain and moisture.
●Exposing the equipment to direct sun light, low ventilation or heat source such as heater or
radiator is forbidden (ignorance can cause fire danger).
●Do not aim the device at the sun or extra bright places. A blooming or smear may occur
otherwise (which is not a malfunction however), and affecting the endurance of sensor at the
same time.
●Please use the provided glove when open up the device cover, avoid direct contact with the
device cover, because the acidic sweat of the fingers may erode the surface coating of the
device cover.
●Please use a soft and dry cloth when clean inside and outside surfaces of the device cover, do
not use alkaline detergents.
●Please keep all wrappers after unpack them for future use. In case of any failure occurred, you
need to return the device to the factory with the original wrapper. Transportation without the
original wrapper may result in damage on the device and lead to additional costs.
●Improper use or replacement of the battery may result in hazard of explosion. Replace with the
same or equivalent type only. Dispose of used batteries according to the instructions provided

Video Intercom Villa Door Station User Manual
v
by the battery manufacturer.
●Input voltage should meet both the SELV and the Limited Power Source according to 60950-1
standard.
●The power supply must conform to LPS. The recommended adaptor models and manufacturers
are shown as below. Use the attached adapter, and do not change the adaptor randomly.
Model Manufacturer Standard
ADS-24S-12 1224GPCN SHENZHEN HONOR ELECTRONIC
CO.,LTD CEE
G0549-240-050 SHENZHEN GOSPELL DIGITAL
TECHNOLOGY CO.,LTD CEE
TS-A018-120015Ec SHENZHEN TRANSIN
TECHNOLOGIES CO., LTD CEE

Video Intercom Villa Door Station User Manual
vi
Regulatory Information
FCC Information
Please take attention that changes or modification not expressly approved by the party
responsible for compliance could void the user's authority to operate the equipment.
FCC compliance: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including interference that may cause
undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with
"CE" and comply therefore with the applicable harmonized European standards
listed under the EMC Directive 2014/30/EU, the RoHS Directive 2011/65/EU
2012/19/EU (WEEE directive): Products marked with this symbol cannot be
disposed of as unsorted municipal waste in the European Union. For proper
recycling, return this product to your local supplier upon the purchase of
equivalent new equipment, or dispose of it at designated collection points. For
more information see: www.recyclethis.info
2006/66/EC (battery directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentation for specific battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your supplier or to a

Video Intercom Villa Door Station User Manual
vii
designated collection point. For more information see:www.recyclethis.info
Industry Canada ICES-003 Compliance
This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements.

Video Intercom Villa Door Station User Manual
viii
Contents
Chapter 1 Appearance................................................................................................................1
Chapter 2 Terminal and Wiring Description ................................................................................6
2.1 Terminal Description.............................................................................................................6
2.2 Wiring Description.................................................................................................................7
2.2.1 Door Lock Wiring........................................................................................................7
2.2.2 Door Contact Wiring...................................................................................................8
2.2.3 Exit Button Wiring......................................................................................................8
2.2.4 Alarm Input Device Wiring.........................................................................................9
Chapter 3 Installation...............................................................................................................10
3.1 Accessory Introduction .......................................................................................................10
3.2 Surface Mounting with Protective Shield...........................................................................11
3.3 Surface Mounting without Protective Shield.....................................................................12
3.4 Flush Mounting with Protective Shield ..............................................................................14
3.5 Flush Mounting without Protective Shield.........................................................................16
Chapter 4 Activation.................................................................................................................19
4.1 Activate Device via Web .....................................................................................................19
4.2 Activate Device via Client Software....................................................................................19
4.3 Edit Network Parameters....................................................................................................20
Chapter 5 Remote Configuration via Web................................................................................. 21
5.1 Live View..............................................................................................................................21
5.2 User Management...............................................................................................................21
5.3 Number Settings..................................................................................................................22
5.4 Device Management ...........................................................................................................22
5.5 Parameters Settings ............................................................................................................22
5.5.1 Local Parameters Settings........................................................................................22
5.5.2 System Settings ........................................................................................................23
5.5.3 Network Settings......................................................................................................26
5.5.4 Video & Audio Settings ............................................................................................29
5.5.5 Image Settings ..........................................................................................................32

Video Intercom Villa Door Station User Manual
ix
5.5.6 Event Settings...........................................................................................................35
5.5.7 Schedule Settings .....................................................................................................37
5.5.8 Intercom Settings .....................................................................................................38
5.5.9 Access Control Settings ............................................................................................40
Chapter 6 Configuration via Client Software .............................................................................43
6.1 Device Management ...........................................................................................................43
6.1.1 Add Online Device....................................................................................................43
6.1.2 Add Device by IP Address.........................................................................................43
6.1.3 Add Device by IP Segment .......................................................................................43
6.2 Live View via Door Station ..................................................................................................44
6.3 Organization Management .................................................................................................44
6.3.1 Add Organization......................................................................................................44
6.3.2 Modify and Delete Organization .............................................................................44
6.4 Person Management...........................................................................................................44
6.4.1 Add Person ...............................................................................................................45
6.4.2 Modify and Delete Person .......................................................................................46
6.4.3 Change Person to Other Organization.....................................................................46
6.4.4 Import and Export Person Information...................................................................46
6.4.5 Get Person Information from Device ......................................................................47
6.4.6 Issue Card in Batch ...................................................................................................47
6.4.7 Permission Settings ..................................................................................................49
6.5 Video Intercom Settings......................................................................................................50
6.5.1 Receive Call from Door Station................................................................................50
6.5.2 Release Notice..........................................................................................................51
6.5.3 Search Video Intercom Information........................................................................51
6.5.4 Upload Armed Information .....................................................................................53

Video Intercom Villa Door Station User Manual
1
Chapter 1 Appearance
Single-Button Villa Door Station
Figure 1-1 Single-Button Villa Door Station Appearance
Table 1-1 Description
No. Description
1 Microphone
2 Indicator
Unlock (Green)/ Call (Orange)/ Communicate

Video Intercom Villa Door Station User Manual
2
No. Description
(White)
3 Camera
4 Loudspeaker
5 Button
6 Card Reading Area
7 IR Light
8 Micro SD Card Slot (Reserved) & Debugging
Port
9 LAN
10 Terminals

Video Intercom Villa Door Station User Manual
3
Two-Button Villa Door Station
Figure 1-2 Two-Button Villa Door Station Appearance
Table 1-2 Description
No. Description
1 Microphone
2
Indicator
Unlock (Green)/ Call (Orange)/ Communicate
(White)
3 Camera
4 Loudspeaker

Video Intercom Villa Door Station User Manual
4
No. Description
5 Button
6 Card Reading Area
7 IR Light
8 Micro SD Card Slot (Reserved) & Debugging
Port
9 LAN
10 Terminals
Four-Button Villa Door Station
Figure 1-3 Four-Button Villa Door Station Appearance

Video Intercom Villa Door Station User Manual
5
Table 1-3 Description
No. Description
1 Microphone
2
Indicator
Unlock (Green)/ Call (Orange)/ Communicate
(White)
3 Camera
4 Loudspeaker
5 Button
6 Card Reading Area
7 IR Light
8 Micro SD Card Slot (Reserved) & Debugging
Port
9 LAN
10 Terminals

Video Intercom Villa Door Station User Manual
6
Chapter 2 Terminal and Wiring Description
2.1 Terminal Description
Figure 2-1 Terminal Description
Table 2-1 Description of Terminal and Interfaces
Name Interface Description
DOOR
NC2 Door Lock Relay Output 2 (NC)
COM2 Common Interface
NO2 Door Lock Relay Output 2 (NO)
GND Grounding
NC1 Door Lock Relay Output 1 (NO)
COM1 Common Interface
NO1 Door Lock Relay Output 1 (NO)
GND Grounding
ALARM IN
AI1 Alarm Input 1 (For the access of Door Contact)
AI2
Alarm Input 2 (For the access of Door Contact)
Note
Before accessing to the Door Contact, select
Input as Door Status in I/O Settings page first.
AI3 Alarm Input 3 (For the access of Exit Button)
AI4 Alarm Input 4 (For the access of Exit Button)

Video Intercom Villa Door Station User Manual
7
Name Interface Description
Note
Before accessing to the Exit Button, select
Input as Exit Button in I/O Settings page first.
RS-485 485+ RS-485 Communication Interface
485-
Power Input 12 VDC 12 VDC Input
GND
Network LAN Network Interface
2.2 Wiring Description
2.2.1 Door Lock Wiring
Figure 2-2 Door Lock Wiring
Note
●Terminal NC1/COM1 is set as default for accessing magnetic lock/electric bolt; terminal
NO1/COM1 is set as default for accessing electric strike.
●To connect electric lock in terminal NO2/COM2/NC2, it is required to set the output of terminal
NO2/COM2/NC2 to be electric lock with Guarding Vision client software.

Video Intercom Villa Door Station User Manual
8
2.2.2 Door Contact Wiring
Figure 2-3 Door Contact Wiring
2.2.3 Exit Button Wiring
Figure 2-4 Exit Button Wiring

Video Intercom Villa Door Station User Manual
9
2.2.4 Alarm Input Device Wiring
Figure 2-5 Alarm Input Device Wiring

Video Intercom Villa Door Station User Manual
10
Chapter 3 Installation
Note
●Make sure the device in the package is in good condition and all the assembly parts are
included.
●Make sure your power supply matches your door station.
●Make sure all the related equipment is power-off during the installation.
●Check the product specification for the installation environment.
3.1 Accessory Introduction
Figure 3-1 Accessory Introduction
Note
The dimension of gang box for door station is: 174 (length) × 83.66 (width) × 18 (depth) mm.
