M A N U A L
INSTRUCTION
P1S Robot Vacuum Cleaner
User manual
Please read this manual carefully before using the product and keep them properly.
1
Congratulations on the purchase of your petgugu ROBOTS!
We hope it brings you satisfaction. We trust your purchase will keep your home clean and provide you a high-quality
life.
Should you encounter situations that have not been properly addressed in this User Manual, please contact our
Customer Service Center, we will solve your specific problem. For more information, please visit the petgugu official
The Company reserves the right to make technological and/or design changes to this product for continuous
improvement.
2
IMPORTANT SAFETY INSTRUCTIONS
WARNING: Read all safety warnings and instructions. Failure to follow the warnings and instructions may result in
electric shock, fire or serious injury.
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE.
1. The robot must be used in accordance with the
directions in this User Manual. Our company cannot be
held liable or responsible for any damages or injuries
caused by improper use.
2. Do not allow to be used as a toy. Close attention is
necessary when used by or near children.x
Do not allow children to sit on the vacuum.
3. Clear the area to be cleaned. Remove power cords
and small objects from the floor that could entangle the
Robot. Tuck rug fringe under the rug base, and lift items
such as curtains and table cloths off the floor.
4. If there is a drop off in the cleaning area due to a step
or stairs, you should operate the Robot to ensure that it
can detect the step necessary to place a physical barrier
at the edge to keep the unit from falling. Make sure the
physical barrier is not a trip hazard.
5. Only use as described in this manual. Only use
attachments recommended or sold by the manufactur-
er.
6. Please make sure your power supply voltage matches
the power voltage marked on the Docking Station.
7. Do not handle or plug appliance with wet hands.
8. Non-rechargeable batteries are prohibited.
9. Do not use without dust bin and/or filters in place.
10. Do not operate the robot in an area where there are lit
candles or fragile objects on the floor to be cleaned.
11. Do not use and store in extremely hot or cold
environments (below -5°C /23°F or above 40°C/104°F).
Please charge the robot in temperature above 0°C/32°F
and below 40°C/104°F. Follow all charging instructions and
do not charge the battery pack or appliance outside of the
temperature range specified in the instructions. Charging
improperly or at temperatures outside of the specified
range may damage the battery and increase the risk of
fire.
12. Keep hair, loose clothing, fingers, and all parts of body
away from any openings and moving parts.
13. Do not operate the robot in a room where an infant or
child is sleeping.
14. For INDOOR use ONLY. Do not use the robot in outdoor,
commercial or industrial environments. Do not use
Appliance on wet surfaces or surfaces with standing water.
For Household use only
When using an electrical appliance, basic precautions should always be followed, including the following:
3
15. Do not allow the robot to pick up large objects like
stones, large pieces of paper or any item that may clog
the robot.
16. Do not use the robot to pick up flammable or
combustible materials such as gasoline, printer or copier
toner, or use in areas where they may be present.
17. Do not use the robot to pick up anything that is
burning or smoking, such as cigarettes, matches, hot
ashes, or anything that could cause a fire.
18. Do not put any object into openings. Do not use with
any opening blocked; keep free of dust, lint, hair, and
anything that may reduce air flow.
19. Take care not to damage the power cord. Do not pull
on or carry the robot or the Docking Station by the power
cord, use the power cord as a handle, close a door on the
power cord, or pull power cord around sharp edges or
corners. Do not run the robot over the power cord.Keep
power cord away from hot surfaces. Do not unplug by
pulling on cord, To unplug, grasp the plug, not the cord.
20. If the power cord is damaged, it must be replaced by
the manufacturer or its service agent in order to avoid a
hazard.
21. Do not use the Docking Station if it is damaged.
22. Do not use the robot or the Docking Station if it is not
working properly, has been dropped, damaged, left
outdoors, or come in contact with water. It must be
repaired by the manufacturer or its service agent in order
to avoid a hazard.
23. Turn OFF the power switch before cleaning or
maintaining the robot. Turn offall controls
24. The plug must be removed from the receptacle
before cleaning or maintaining the Docking Station.
25. Remove the robot from the Docking Station, and turn
OFF the power switch to the Appliance before removing
the battery for disposal of the robot.
26. The battery must be removed and discarded
according to local laws and regulations before disposal
of the robot.
27. Please dispose of used batteries according to local
laws and regulations.
28. Do not incinerate the robot even if it is severely
damaged. The batteries can explode in a fire.
29. When not using the Docking Station for a long period
of time, please unplug it.
30. Prevent unintentional starting. Ensure the switch is in
the offposition before connecting to battery pack,
picking up or carrying the appliance. Carrying the robot
with your finger on the switch or energizing the robot
that have the switch on invites accidents.
31. When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins,keys, nails,
screws,ect, that can make a connection from one
terminal to another. Shorting the battery terminals
together may cause burns or a fire.
32. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
4
flush with water. If liquid contacts eyes, additionally seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
33. Do not use a battery pack that is damaged or
modified. Damaged or modified batteries may exhibit
unpredictable behavior resulting in fire, explosion or risk
of injury.
34. Do not expose a battery pack or appliance to fire or
excessive temperature. Exposure to fire or temperature
above 130°C/265°F may cause explosion.
35. Have servicing performed by a qualified repair person
using only identical replacement parts.
36. Do not modify or attempt to repair the robot or the
battery pack (as applicable) except as indicated in the
instructions.
37. Do not operate the robot in a room that has lit
candles on furniture that the vacuum may accidentally
hit or bump into.
38. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
39. Use the robot only with specifically designated
battery packs. Use of any other battery packs may create
a risk of injury and fire.
40. The robot contains batteries that are only replaceable
by skilled persons. To replace the robot's battery, please
contact Customer Service.
41. If the robot is not going to be used for a long time,
fully charge the robot, power it OFF, and unplug the
Docking Station.
SAVE THESE INSTRUCTIONS
Short-circuit-proof safety isolating transformer
Switch mode power supply
For indoor use only
Direct current
Alternating current
detachable supply unit
S
To satisfy RF exposure requirements, a separation
distance of 20 cm or more should be maintained
between this device and persons during device
operation.
To ensure compliance, operations at closer than this
distance is not recommended. The antenna used for this
transmitter must not be co-located in conjunction with
any other antenna or transmitter.
5
This marking indicates that this product should not be disposed of with other household waste
throughout the EU. To prevent possible harm to the environment or human health from uncontrolled
waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To recycle
your used device, please use the return and collection systems or contact the retailer where the product
was purchased. They can safely recycle this product.
Correct Disposal of this Product
Federal Communications Commission (FCC) Interference Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference received,
including interference that may cause undesired
operation.
FCC Caution:
Any changes or modifications not expressly approved by
the party responsible for compliance could void the user
5s authority to operate this equipment.
RF exposure warning
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.This
equipment must be installed and operated in
accordance with provided instructions and the
antenna(s) used for this transmitter must be installed
antenna(s) used for this transmitter must be installed
to provide a separation distance of at least 20 cm from
all persons and must not be collocated or operating in
conjunction with any other antenna or transmitter.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generate, uses and can
radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to
correct the interference by one of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
6
IC Caution:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic
Development Canada’s licence-exempt RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
Any changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
RF exposure statement:
The equipment complies with IC Radiation exposure limit set forth for uncontrolled environment. This equipment
should be installed and operated with minimum distance 20cm between the radiator and your body.
Cet appareil contient des émetteurs / récepteurs exemptés de licence conformes aux RSS (RSS) d'Innovation,
Sciences et Développement économique Canada. Le fonctionnement est soumis aux deux conditions suivantes:
(1) Cet appareil ne doit pas causer d'interférences.
(2) Cet appareil doit accepter toutes les interférences, y compris celles susceptibles de provoquer un fonctionnement
indésirable de l'appareil.
Tout changement ou modification non expressément approuvé par la partie responsable de la conformité pourrait
annuler l'autorité de l'utilisateur à utiliser l'équipement.
Déclaration d'exposition RF:
L'équipement est conforme à la limite d'exposition aux radiations de la IC établie pour un environnement non
contrôlé. Cet équipement doit être installé et utilisé avec une distance minimale de 20cm entre le radiateur et votre
corps.
7
Contents
1. Product introduction 8
1.1 Packing list
1.2 Part name
2. Preparation before use 11
2.1 Assembly and charging
2.2 Environmental preparation
4. Anomalies
4.1 Troubleshooting
18
5. Technical parameters 20
3. Product use 13
3.1 Buttons operation and light effect and display state
3.2 Use of virtual wall with magnetic stripe
3.3 App download and networking
3.4 Maintenance
8
1. Product introduction / 1.1 Packing list
* The illustration in this manual is for reference only, and the actual appearance should be subject to the physical object.
Robot
High efficiency filter
screen (HEPA)
Charging base &
power adapter
Dust bin
Side brush & cleaning tool
Virtual wall
with magnetic stripe
User manual
Pleaseread this manual carefully before using the product and keep them properly.
P1S Robot Vacuum Cleaner
User manual
9
1. Product introduction / 1.2 Part name
Internal view
Bottom view
Front view
Recharge botton
Start/pause botton
Front-facing
camera
Display screen
Fill light
Infrared anti-
collision sensor
Dust bin
Power switch
The green at the bottom of the button
is in the startup state,
The red at the bottom of the button
is in the shutdown state
Driving wheel
Anti-fall sensor
Suction port
Charging pole piece
Universal wheel
Fiber optic current sensor
Side brush
10
1. Product introduction / 1.2 Part name
Charging base
Dust bin
High efficiency filter (HEPA) assembly
Primary filter screen
Charging pole piece
Power adapter
Power adapter socket
Infrared signal emission area
11
2. Preparation before use / 2.1 Assembly and charging
* Place the charging base in an open
area.
* Connect the power supply and
arrange the power cord.
Place the charging base
/connect the power supply
Turn on the power
Remove the protective film on
the robot and and charging base
Install side brush
Place the robot to the charging base and pay attention to
aligning with the charging pole piece. The charging time is
about 4.5h.
Note: Please note that the robot cannot be charged when the
power switch is turned off.
Charging
Click
>0.5m
(1.64’)
>0.5m
(1.64’)
>1.5m
(4.92’)
Long press botton for 3s.
The botton indicator is on and flashes for 3 times, and
then you can hear the power-on voice prompt.
Note: If you press it for a long time and there is no
response, please open the top flip cover of the robot to
ensure that the bottom of power switch is in green
startup state (the default state is open state).
12
2. Preparation before use / 2.2 Using environment preparation
Sort out the space to be cleaned
If the carpet at home has
tassel edges, please put
the edges under the carpet
in advance.
Sort out the articles on the
floor, such as wires, slippers
and other sundries, so as to
avoid affecting the
operation of the robot.
The robot can climb to the
top of objects less than
12mm thick. If you don't
want the robot to climb on
them, please take them
away.
Please do not let the
robot operate on wet
and suspended floors,
and close the doors of
toilets and balconies.
13
3. Product use / 3.1 Buttons operation and display screen state
Robot state Recharge button light
display state Display screen state
Start up
In cleaning
Automatic recharge
In charging
Enter the networking state
Successful networking
Error No light
Start/pause button
Recharge button
Start/pause button
light display state
White light flashes slowly for three times and then goes out
No light
No light
No light
White light flashes slowly
No light
Red light is always on
Error No lightRed light flashes
Long press button for 3s:
Click button:
Double click button:
Click button:
Long press button for 6s:
Long press button and button
for 3s at the same time:
Turn on/off
Start/pause
Fixed-point cleaning
Enter recharge mode
Switch the broadcast language
(Chinese/English/Japanese)
enter the networking mode
14
3. Product use / 3.2 Use of virtual wall with magnetic stripe
The virtual wall with magnetic stripe can be used to
isolate any areas not to be cleaned (bathrooms with wet
floors or areas that may jam the robot).
In the area where you don’t want the robot to enter and
clean, stick the virtual wall with magnetic stripe along
the entrance.
Please fix the virtual wall with magnetic stripe on
the ground to prevent it from breaking away;
otherwise, the use effect of the virtual wall with
magnetic stripe will be affected.
If necessary, cut the magnetic stripe short with scissors. Be sure to measure the length correctly before cutting.
Virtual wall with
magnetic stripe Virtual wall with
magnetic stripe
15
3. Product use / 3.3 App download and networking
Downloading and installation of the “petgugu” app
Method I : Scan the following QR code, and then
download and install App as prompted.
Method II : Search "petgugu" in the App store, download
and install the petgugu app.
Tips:
* Follow the guidance in the petgugu app to register,
login, and pair the robot.
* Please make sure that the mobile phone is connected
to your Wi-Fi network before paring the robot vacuum
cleaner.
Note: The robot works with 2.4GHz Wi-Fi networks only.
petgugu
TP-Link_2.4G
TP-Link_5G
16
3. Product use / 3.4 Maintenance
* When cleaning and maintaining the robot and its accessories, please unplug the power supply of the charging base.
Remove the dust filter
assembly.
Clean the high-efficiency
filter screen.
Clean the primary filter screen.
Open the robot surface cover
and take out the dust bin.
Dump rubbish.
High-efficiency filter
screen is not washable
Warning
17
* When cleaning and maintaining the robot and its accessories, please unplug the power supply of the charging base.
3. Product use / 3.4 Maintenance
7. Clean the side brush to
prevent hair entanglement.
5. Clean the driving wheels and
keep them clean smoothly.
6. Clean the fiber optic current
sensor to ensure its sensitivity.
2. Clean the charging pole piece to
ensure smooth charging.
4. Clean the suction port to
ensure the cleaning effect.
1. Clean the anti-fall sensor to ensure its sensitivity.
8. Clean the charging pole
piece of the charging base
to ensure smooth charging.
3. Clean the universal wheel to
prevent hair entanglement.
Table of contents
