PROGRAMMEDRADIOSTATION FREQUENCIES
FM AM
1. 1.
2. 2.
3. 3.
4. 4.
5. 5.
The programmedstation memory will be erased inthe event that power to the
radio is disconnected due to electrical system repairs or due to low battery
voltage for morethan approximatelyoneweek. Therefore, recordthefrequen
-
cies of your favoritestations IN PENCIL above,for reprogrammingwhen power
is restored.
Seek tuning will not operate properly if the battery voltage is low. Should
“Code” appear
in thedisplay, refer to Page 5 of this manual.
1

DEAR PEUGEOT OWNER:
You have now purchasedone of the finest, most stylish, and most comfortable
automobiles manufactured today. For your listening comfort, your Peugeot is
equippedwith a digital, electronicallytuned,AM/FM stereo radiowith an auto-
reverse cassette, equipped with Dolby B* noise reduction. Control placement
and operation have been carefully engineered to minimize the time your eyes
are
off the road, thereby contributing to active safety. For your protection, it
also isequippedwith an electronic “anti
- theft coded” system.
Please read this manual thoroughly
so that you will be able to enjoy its many
features tothe utmost.
PEUGEOTMOTORS
OF AMERICA
“Dolby H I S a registeredtrademark of Dolby Laboratories, Inc
0 Peugeot Motors of America, Inc
2

DESCRIPTIONOF FEATURES
Anti - theft electronic code protectionsystem
Electronic radio tuning
Digital phase - locked loop frequency synthesizer.
Locks onto precise broadcast frequency to prevent
drift.
Separate bass and treble controls with built - in
loudness.
Bidirectional AM/FM seek tuning
5 AM and 5 FM programmable station memory
capability.
Bidirectional AM/FM scantuning.
Automatic local/distant signal attenuation
Automatic antenna trimmer.
Automatic stereo/mono blend circuitry to minimize
noise,when thesignal isweak.
One step memory programming of present radio
pushbuttons.
0 Fulllogic computer controlled.
Negative liquid crystal display for all tape and radio
functions.
Front/rear fader.
0 " Key off " tape pause.
Logic controltape fast forward and rewind.
Tape forward scan.
0 Bi - directionaltapeseek.
Auto reverse cassette mechanism.
Automatic tape cleaning indication (every 15 hours
oftape use).
Dolby B* tape noisereduction.
" Softload/eject" cassettemechanism.
120 µsec.and 70 µsec.automatic tape equalization.
3

THE PEUGEOTTHEFT DETERRENTPROGRAM
The elements of the Peugeot Theft Deterrent Program have been designed in cooperation
with law enforcementauthorities to not only help thwart theft of your radio, but to also reducethe
marketfor stolen radios.
Please read this section of the Owner’s Manual very carefully and completely
to obtain the
maximum benefitfromeach elementof this program.
COMPUTERIZED PROTECTION
The microprocessorcontrolling your radio isassigned a 5 digit “anti - theft code” as printedon
the identification cards on the last page of this manual. Should the voltage supply
to your radio
become disconnected (due
to theft or electrical repairs), or become very low (due to insufficient
battery charge), the radioand cassette will not operate when voltage is later restored. The display
will show the word “code:’ Unless a
5 digit “anti - theft code” assigned to your radio is entered as
outlined in the next paragraph,the radiowill not operate, therefore reducing the market potential
for stolen radios.It is extremely unlikelythat the correct
5 digit codecan beguessed.
4

DESCRIPTIONOF FEATURES
Anti - thenelectroniccode protectionsystem
Electronicradiotuning
Digital phase
- locked loop frequency synthesizer.
Locks onto precise broadcast frequency to prevent
drift.
Separate bass and treble controls with built
- in
loudness.
BidirectionalAM/FM seek tuning
5 AM and 5 FM programmable station memory
capability.
Bi
- directionalAM/FM scan tuning.
Automatic local/distant signalattenuation
Automatic antennatrimmer.
Automatic stereo/mono blend circuitry to minimize
noise,when thesignal is weak.
One step memory programming of present radio
pushbuttons.
Fulllogic computer controlled.
Negativeliquid crystal display for all tape and radio
functions.
Front/rear fader.
" Key off' tape pause.
0 Logic controltapefast forward and rewind.
Tape forwardscan.
Bidirectionaltapeseek.
Auto reverse cassette mechanism.
Automatic tape cleaning indication (every 15 hours
oftape use).
DolbyB* tape noisereduction.
" Soft Ioad/eject" cassettemechanism.
120 µsec.and 70 µsec.automatictapeequalization.
3

ANTI - THEFT CODE ENTRY
1. When “code” appears inthe display, the 5 digit “anti - theft code” printed on the two “anti - theft
code” radioidentificationcards must be entered usingthe radiopushbuttonsnumbered
1 to 5.
a. If a “beep” is heardwhile enteringthe 5 digit code,STOP. Beginthe codeentry again.
b.
If an error is made in code entry, repeatedly press any of the 5 pushbuttonsuntil a “beep” is
heard,then
STOP . Beginthe codeentry again.
NOTE: If the assigned “anti
- theft code” is not entered in three successive tries, the micropro -
cessor will not accept any more code entries unless it is allowed to continuously remain on for
one hour. After one hour
of “on” time, it will again accept only three additional tries and this
processwill repeat itself.
2. Removeboth codecards fromthis manual. Placeone inthe primarydriver’swallet, andone with
the title papers
to ensure that the next owner receivesthe “anti - theft code” cards if the vehicle
issubsequentlysold.
DO NOT LEAVE THE CODECARDS IN THE VEHICLE.
3. Inthe event electrical repairs to your vehicle become necessary,you may wish to give the “anti -
theft code” to the repairingfacility to enablethem to reprogramyour radio.
4. If the “anti - theft” radio identification cards are lost, etc., contact a Peugeot dealer of your
choice. You may be charged for labor to remove and reinstall the radio
to ascertain the radio
serial number.
5

WARNING: Proof of vehicle ownership and proper identification (valid driver’s license) must be
verified by Peugeot dealer personnel.This informationmust begiven by authorizeddealer person
-
nel only to Peugeot Motorsof America before radio “anti - theft’’ codeswill be released by Peugeot
Motorsof America. This is necessaryfor your protection.
THWARTINGTHIEVES
The following measuresare to be taken
to thwart attemptsto stealyour radio and will requireyour
active participation:
a. Warning decals - remove the two “warning decals” from the back cover of this manual and
placethem onthe side windows near the door locks in compliancewith federal, state and local
regulations.
b. Hang tag - place the hang tag over the inside rear view mirror to warn thieves to help avoid
vehicle break
- inwhenthe vehicle is unattended.
c. Flashing LED - whenthe ignition key is removed, a red LED will flash continuouslyto serve as
awarning
to thieves.
d. Anti - removal feature - if any radio pushbutton is touched with the ignition key removed, the
radio will “beep” for
5 minutes. Should this feature be activated accidentally, simply turn the
ignition “on” momentarilyandthe beepingwill stop.
e. Radionon
- saleability warning decal - shoulda thief removeyour radio,a decal located on the
top
of the radio chassis will warn him that your radio is an “anti - theft” unit and therefore not
readily saleable.
6

ON/OFF, VOLUME
PUSH
- SCANUPSCALE
(TO SCAN DOWNSCALE,
PRESS
" < TUNE
AND THEN PRESS
VOLUME CONTROL)
RADIO MODE CONTROL OPERATION AND LOCATION
PULLAND ROTATE
FRONT/REAR PRE
- SET RADIOSTATIONPUSHBUTTONS
TIONS TO PRO GRAM ON N
I
LIQUID CRYSTAL DISPLAY OF
AM/FM INDI ATORS
F
ST - STEREO
TATION INDICATOR
TREBLE
AM/FM BANDSELECTOR
f CUT
7

RADIO MODE OPERATION
1.
For " onestep " reprogramming of preset radio station
pushbuttons:
a. Tune indesired station.
b. Push and hold desired pushbutton
1-5. After 1 '/2 sec -
onds, an audible " beep " will sound and the set station
will beautomatically
" memorized:'
c. 5 FM and 5 AM stationscanthusly be " memorized:'
d. The LED onthe pushbunonpressedwill exhibita red/
orangecolor to distinguish it fromthe others.
Mediumto highstrength radio stationscanbe listened
to
for seven seconds inthe " scanmode " as follows:
a. Up
- scale, pressthe volume control
2. SCAN
b. Down - scale, press "> tune " and then the volume
control.
To stop scanning when the desired station is reached,
pressthe volume controlagainduring the seven second
pause.
3. SEEK
The radio will automatically tune to the next station of
sufficientstrength if the
" seek buttons " in eitherthe ">"
(upscale) or "<" (downscale)directions are pressed.
FM signals reflect off or are blocked by hills, tall build
-
ings, etc. Therefore, occasional hissing and fluttering
noises can result. FM signal strength diminishes rapidly
after
25 milesfrom the transmitter.
AM RECEPTION
AM signals are reflected by the ionosphere and bend
around obstacles. They are affected by weather and the
time of day.
It is not unusual to receive stationsat night
from several hundred milesaway. These strong different
signals can therefore affect the
" SEEK " and " SCAN "
functions at night
4. FM RECEPTION
8

TAPE MODE CONTROL OPERATIONAND LOCATION
ON/OFF VOLUME PRESS 1
PUSH - TAPE FORWARDSCAN
I
DlSP
REVERSE TAPE PROGRAM(DIRECTION)
PRESS FOR REWIND(REW)
PRESS AGAIN
TO CANCEL " REW'
PRESSFOR FAST FORWARD(FF)
PRESSAGAINTO CANCEL
" FF
ID I /
S: 1 = SIDE 1 (TOP)
2 = SIDE 2 (BOTTOM)
MTL
= 70µs EQUALIZATION
CLEAN
= INSERTTAIPE
MECHANlSM
CLEANING CASSETTE
y
1- CLEAN
ANTI - THEFT /I
< " REWIND > " FAST FORWARD
LED ON
- DOLBY ON
LED OFF - DOLBY OFF DIRECTION' DIRECTION
NORMAL PLAYBACK TAPE SEEK
NOTE PROPERTAPE EQUALIZATION
IS AUTOMATICALLYSELECTED BY THE COMPUTER.
9

TAPE MODEOPERATION
1. COMPUTER CONTROL
The insertion of a cassette with the radio " on " will auto -
matically switch the unit from the " radio " to the " tape "
mode.
The display will indicate program
"1" if the top side of
the cassette is playing and program
" 2 " if the bottom
side is playing.
Regardlessof which side is playing,the computer logic
will automaticallyselectthe proper direction for
" fastfor -
ward " or " rewind. "
CAUTION:
Allow the vehicle interior to cool (or heat up) to normal
temperatures BEFOREinsertinga cassette.
The level of inherent
''HISS' in cassettetape is reduced
by encoding the tape with Dolby' noise reduction. Use
of the Dolby button with non
- Dolby' encoded tapes will
reduce high frequency response. Use of Dolbyencoded
tapes without the Dolby function will result in an artificial
intensification of high frequencies.This unit is designed
to operate properly with both non
- Dolby' or Dolby B*
encodedtapes.
3. TAPE " SEEK "
If you wish to hear the next tape selection. press the
"> seek " button. If you wish to hear the current selec-
tion again, pressthe
''< seek" button.
Tape selections can be
" scanned " by pressing the
volume control. The tape will fast forward only to the
2. DOLBY B NOISEREDUCTION
4. TAPE " SCAN "
10
5.
6.
beginning of each selection. The selection will play for
seven seconds and then fast forward
to the next selec -
tion, etc. To stop " scanning, " pressthe volume control
again.TapeScandoes notwork inthe"rewind" direction.
NOTE:
In order for the tape " seek " and " scan " functions to
operate properly, ihere must be at least 3 seconds of
silencebetween musicalselections.
Seek and Scanwill not function properly
if:
A. Excessive record noise or hum is present between
home recordedtapeselections.
B. Sound programs are intermittent, such as lectures,
newsbroadcasts, or musicselections with morethan
3 seconds of silencebetweenpassages.
C home-recordeo programs w
th less tnan 3 seconos
oetween selectionsare utilized
TAPE EQUALIZATION
The computer automatically selects the proper tape
equalization:
Normaltapes-120µsec--"MTL" indisplay
" OFF:
Chrome, metal-70µsec-"MTL" indisplay
" ON:'
TAPE PAUSE
The pnch-riir tape drive mechanism wi I ablomatical y
retract when the ,gnlion key s turned on I e go nto a
pawe' mooe This w
I prevent flat spots on tne dr ve
without requiring the tape to be reinserted again as
requiredonunitswithoutthis feature.
When the ignition is again turned on, the tape will again
begin playing.

PRECAUTIONS
1. Useonly highquality C60 tapes. C90 and C120 tapes are of insufficientthicknessand therefore
lack the strength to cope with the extreme variations in vehicle interior temperatures
encountered.
2. Always place your tapes into their individual plastic case and store them in a multi - cassette
holder to protect them against dirt, dust, and excessive heat from direct exposure to the sun,
etc.
3. Do not expose the tapes to excessive heat or magnetic sources such as electric motors,per -
manent magnets,or TV sets.
4. Removeslack from the tape by insertinga pencil or similar object intothe cassettespindleand
turning it until all slack isremovedbeforethe cassette is insertedintothe radio. Failureto do
so
can result intape breakage.
5. Do not insertforeignobjects intothe cassette slot.
MODIFICATIONS
This unit is designed only to operate with the speakers provided. The installation of a power
booster or equalizer may damage the unit. Damage as a result of modificationsmay not be cov
-
ered bytheappropriatewarranty.
MAINTENANCE
“Clean” inthe display will flashfor 30 seconds andthe radiowill emit a beepingsound for 10 sec -
onds after each 15 hours of tape playingtime. This is a reminder to insert a tape cleaningcassette
to clean the playbackhead andcapstan.
Failure
to clean the unit will gradually result in loss of high frequency response and ultimately
distortion.
11

SPECIFICATIONS
Power Amplifier
MaximumOutput 30W
Output 4.4 W x 4Ch into
4 Ω
load100Hz to
20,000 Hz at 1 %
THD
0.1
% at 1WTotal Harmonic Distortion
Frequency
20 Hz - 20 kHz
Response f1 dB
Signal/Noise Ratio 80 dB
Tone Controls
Bass
Treble i12dB at 100Hz
f 12 dB at 10 kHz
FM Stereo Radio
FrequencyRange 87.9 - 107.9 MHz
UsableSensitivity 15.3dBf (1.6 µ V)
Signal/Noise Ratio 65dB
ImageRejection 50 dB
Spurious Rejection 70 dB
Capture Ratio 2 dB
StereoSeparation
Stereo Distortion 0.5%
IntermediateFrequency 10.7MHz
40 dB (1 kHz)
AM Radio
Frequency Range 530 kHz-1620 kHz
Intermediate Frequency 450 kHz
Sensitivity20dB S/N
Selectivity 50dB(+10kHz)
16 µ V
Tape Player
Fast ForwardTime 75 sec. (C-60)
Frequency Response 40 Hz to
Normal 14,000Hz f 3 dB
Frequency Response 40 Hz to
Metal 15,000Hz f3dB
Wow and Flutter 0.07% (WRMS)
Stereo Separation 40 dB
Signal/Noise Ratio 55dB
Wolbp Effect 10 dB
RewindTime 75 sec. (C - 60)
NOTE:SPECIFICATIONSSUBJECTTO
CHANGEWITHOUT NOTICE
12

NOTES:
13

BPEUGEOT
Ant i - T hef t Radio
Identification Card
If " beep " heard while entering code.
stop and begin code entry again
Anti - Theft Code 53142
88091 t 641 A
Your Radio
Serial Number
L
1
r 1
r
L i

PEUGEOT
68P81 707F12-0
Printed in Japan
