PEYOU 115-0163 User manual

PEYOU
R
Projection Alarm Clock
Operating Instructions
Model:115-0163
PEYOU and PEMOTech are trademarks of Peyou Trading Inc.

Projection Alarm Clock
QUESTIONS CONCERNS?
Welcome to contact our Customer Service Team
Go to Your Orders,find your order in the list and click
Seller Name.Then click the Ask a question button to
mail us.
You will get a responding within 24 hours.
<1>
Cus tome r Serv ice E mail :
Pey ou@c ont act- us.com

Projection Alarm Clock
COMPOSITION
Time Display
2 USB
charging port
DC
Projection
focus
adjustable
Alarm 2
Alarm 1
Project
Snooze/Adjust
Mode
Up
Down
Backup battery on 5V/1A(not include)
ATTENTION:Backup battery is only for time monitoring
and alarm setting in case of power failure
<2>

Projection Alarm Clock
FEAUTURES
LED time display
5 levels of display light luminance
5 levels of projection luminance
12/24 hour format optional
Dual alarm
Night mode
Snooze(5-60mins,default 9 mins)
Adjustable time projection-brightness&angle
7 function button
(down,up,mode,snz/light,project,AL1,AL2)
2 USB part for phone
USB charging cable
<3>

Projection Alarm Clock
Power on or Reset
MANUAL INSTRUCTION
-+mode
ZZ
12
1.The LED displays for 2 seconds, and enters the
standard mode after a beep of "BI".
2.When the alarm is in the process, only the button
battery CR2032 is powered after the AC power is
disconnected.Then,even if the AC power is
connected, the alarm is not maintained.
Note: The CR2032 backup battery is powered
separatelyand only retains memory and
timekeeping functions.
Time setting
1.Under standard mode, long press “mode” button
will enter the time setting mode.The setting
sequence:12h/24h-> hour -> minute ->second.
2.Hour/minute setting:Press “+” or “-”button,adjust
the hour/minute(single press for addition and
subtraction;long press for addition and subtraction
quickly[8 steps/ second]).
Power on or Reset
<4>

Note:
Second time cannot be setting.
When time setting,the set object will filck .
Without any operation in 10 seconds, it will
back to time mode.
When 12H mode ,”PM” LED light will appear in
the pm time.There is no AM LED light.
Projection Alarm Clock
Dual Alarm Mode
A.Alarm Mode
1.Alarm time for 2 minutes(BIBIBIBI),Alarm
frequency is 2048HZ
2.When the alarm sounds, the alarm symbol
flashes
3.Alarm format: AL1 ringtone: BI BI BI three beeps
per second; AL2 ringtone: BI BI BI BI four beeps
per second.
4.The alarm will be turned off on the day after 2
minutes of inactivity.
5.Only under the AC mode,the alarm function
works.
B.Alarm Setting
Press “ ” button will enter the alarm 1 setting mode.
Alarm 1 light turns on and long press “ ” button ,
“hour“ will flick.
The setting sequence: hour -> minute ->snooze time.
1
1
<5>

1.Press “+” or “-”button to set the hour/minute time.
2.After hour/minute setting , snooze time will filck
(default 9 minutes) .Press “+” or “-”button to set the
5-60 min snooze time .
3.The default Snooze time is 9 minutes(the default
interval is 5 minutes).
4.After alarm setting,press “ ”button or without
any operation in 10 seconds, it will back to time
mode.
Note:Repeat the manual of the alarm 1 to setting
alarm 2
Projection Alarm Clock
1
C.Stop Alarm
During the process of Alarm 1 or Alarm 2 , the related
AL1 or AL2 alarm symbol will flash. Press any button
except “ ”will stop alarm on the day, and then
the AL1 or AL2 icon will continue to light up.
ZZ
Snooze Time
1.The default Snooze time is 9 minutes(snooze time
can choose from 5-60 mins.
2.Press “ ”will stop alarm and enter into the
snooze time. After that “AL1” or “AL2”icon keep
lighting up on the display and will alarm on the next
snooze time.The number of snoozes is unlimited.
3.When snoozing ,press any button except “ ”
will stop snooze .
4.When alarm 2 turns on,alarm 2’s ring will replace
alarm’s ring even alarm 1 is alarming or in snoozing.
ZZ
ZZ
<6>

Brightness Adjustment
Projection Alarm Clock
1.5 luminance level:bright,medium,low,dim,off
(default bright)
2.Press “ ”button to switch the brightness.
ZZ
Night Mode
1.Under night mode,the LED display will enter into
the low light automatically.
2.Under the time mode,press the “mode”
button and the light mode shows turn on(ON)
and turn off(OFF) situation(the default is OFF) .
When the light mode is ON,the clock will enter
into the low light automatically between the
time 18:00-6:00.Press the “+” or “-”
button to choose the “ON” or“OFF”.
<7>

Projection Alarm Clock
Projection
1.When powered by DC adaptor,press “ ”button
can turn on the projection.press again to change
the luminance of projection.
2.5 projection lightness level:bright,medium,low,
dim,off(default bright)
3.When projection,long press the “ ” button,the
display will rotate 180°.
4.Rotating the project part as you like at the front
or back 90°.
5.When battery mode,there is no projection .
Dual USB Charging Port
1. Any mode can charge iPhone or a Android
phone by DC5V/2A
2. Charge for 2 devices at the same time
<8>

Projection Alarm Clock
ATTENTION
<9>
1.The projection alarm clock can only work under
the AC mode(powered by DC adaptor).Using the
battery is only used to store power for the
previous operation, such as setting the storage
time, setting the alarm, and so on. If the battery
is not added, the time alarm must be reset each
time the power is turned off .
2.It is recommended that the best projection be
2-3m / 7-10ft. If your house is a Gothic building or
a villa, the roof is very high, the projection effect
will be mediocre. For this type of room, it is best to
project on the wall.
3.You’d better use the projection function ,if the
display brightness affect you when sleeping at
night.
4.No projection function in battery mode.
5.The CR2032 battery used in the product is not
included in the product packaging.
6.With power outlet and USB charging cable.
7.Please email to us if there is a problem of the
product.
1x Button cell (CR2032) [excluded]
DC input 5V/2A (included)
1x USB cable (include)
2xUSB charge port. MADE IN CHINA
Power consumption
