Pfaff expression line User manual

Owner's manual

This household sewing machine is designed to comply with IEC/EN 60335-2-28 and UL1594.
IMPORTANT SAFETY INSTRUCTIONS
When using an electrical appliance, basic safety precautions should always be followed, including the
following:
Read all instructions before using this household sewing machine.
DANGER – To reduce the risk of electric shock:
• A sewing machine should never be left unattended when plugged in. Always unplug this sewing
machine from the electric outlet immediately after using and before cleaning.
• Always unplug before relamping. Replace bulb with same type rated 5 Watt.
WARNING – To reduce the risk of burns, Àre, electric
shock, or injury to person:
• This sewing machine is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the sewing machine by a person responsible for their
safety.
• Children should be supervised to ensure that they do not play with the sewing machine.
• Use this sewing machine only for its intended use as described in this manual. Use only attachments
recommended by the manufacturer as contained in this manual.
• Never operate this sewing machine if it has a damaged cord or plug, if it is not working properly, if
it has been dropped or damaged, or dropped into water. Return the sewing machine to the nearest
authorized dealer or service center for examination, repair, electrical or mechanical adjustment.
• Never operate the sewing machine with any air openings blocked. Keep ventilation openings of the
sewing machine and foot controller free from the accumulation of lint, dust, and loose cloth.
• Keep Àngers away from all moving parts. Special care is required around the sewing machine needle.
• Always use the proper needle plate. The wrong plate can cause the needle to break.
• Do not use bent needles.
• Do not pull or push fabric while stitching. It may deÁect the needle causing it to break.
• Wear safety glasses.
• Switch the sewing machine off (“0”) when making any adjustment in the needle area, such as threading
needle, changing needle, threading bobbin, or changing presser foot, etc.
• Always unplug sewing machine from the electrical outlet when removing covers, lubricating, or when
making any other user servicing adjustments mentioned in the instruction manual.
• Never drop or insert any object into any opening.
• Do not use outdoors.
• Do not operate where aerosol (spray) products are being used or where oxygen is being administrated.
• To disconnect, turn all controls to the off (“0”) position, then remove plug from outlet.
• Do not unplug by pulling on cord. To unplug, grasp the plug, not the cord.
• This sewing machine is provided with double insulation. Use only identical replacement parts.
See instructions for Servicing of Double-Insulated Appliances.
SAVE THESE INSTRUCTIONS
SERVICING OF DOUBLE INSULATED PRODUCTS
In a double-insulated product, two systems of insulation are provided instead of grounding. No ground
means is provided on a double-insulated product, nor should a means for grounding be added to the
product. Servicing of a double-insulated product requires extreme care and knowledge of the system and
should be done only by qualiÀed service personnel. Replacement parts for a double-insulated product must
be identical to those parts in the product. A double-insulated product is marked with the words ‘DOUBLE
INSULATION’ or ‘DOUBLE INSULATED’.

Congratulations!
Congratulations on purchasing your new PFAFF® sewing machine. As a sewing
enthusiast, you have acquired a machine that features the very latest in both design and
technology, enabling you to transform all your creative ideas into reality.
Before you start, please spend some time reading this owner’s manual. You will soon
discover how to maximize the use of your machine. Your authorized PFAFF® dealer will
of course also be pleased to help you at any time.
Your PFAFF® expression™ machine will deÀnitely enable you to experience a totally new
dimension of sewing!

Table of contents
1
Introduction 1:5
Machine overview.................................................... 1:5
Front side...................................................................... 1:5
Top parts....................................................................... 1:5
Accessory tray.............................................................. 1:6
Included accessories.................................................... 1:6
Presser feet.................................................................... 1:7
Stitch overview......................................................... 1:8
Utility stitches .............................................................. 1:8
Quilt stitches .............................................................. 1:10
Needle art stitches ..................................................... 1:10
Decorative stitches .................................................... 1:10
Alphabets ................................................................ 1:11
2
Preparations 2:1
Unpacking................................................................. 2:1
Connect to the power supply ................................. 2:1
Pack away after sewing........................................... 2.2
Free arm..................................................................... 2:2
Thread cutter............................................................. 2:2
Spool pins.................................................................. 2:2
Threading the machine............................................ 2:3
Bobbin winding........................................................ 2:5
Inserting the bobbin................................................. 2:6
IDT (Integrated dual feed)...................................... 2:6
Electronic knee-lift (4.0)........................................... 2:7
Needles ...................................................................... 2:7
Changing the needle................................................ 2:8
Lowering feed dogs ................................................. 2:8
Changing the presser foot....................................... 2.8
Buttons for quilt expression™ 4.0........................ 2:10
Buttons for expression™ 3.0................................. 2:12
Buttons for expression™ 2.0................................. 2:14
Settings menu ......................................................... 2:16
3
Sewing 3:1
Sewing mode - overview............................................ 3:1
Select a stitch............................................................. 3:1
Sewing recommendations.......................................... 3:1
Stitch adjustments.................................................... 3:2
Mirroring................................................................... 3:3
Tie-off options........................................................... 3:3
Tapering program (4.0 and 3.0).............................. 3:4
Speed control ............................................................ 3:4
Personal stitches (4.0 and 3.0)................................. 3:5
Sewing techniques ................................................... 3:6
Handlook quilting ....................................................... 3:6
Darning ......................................................................... 3:6
Free-motion position (3.0 and 2.0) ............................ 3:7
Buttonholes................................................................... 3:7
Common sewing pop-ups ...................................... 3:9
4
Sequencing (4.0 and 3.0) 4:1
Sequencing - overview................................................ 4:1
Create a sequence..................................................... 4.1
Using the alphabet ................................................... 4:2
Manage your sequences.......................................... 4:3
Sewing a sequence ................................................... 4:3
5
Maintenance 5:1
Changing the light bulbs......................................... 5:1
Cleaning the machine.............................................. 5:1
Replacing the stitch plate........................................ 5:2
Troubleshooting ....................................................... 5:3
Index .......................................................................... 5:5
Note: The machine models will be referred to as simply 4.0, 3.0 and 2.0 in this manual.

PFAFF
quilt expression 4.0
10
20
30
40
50
2
1
mm
inch
00
1
2
14
3
4
5
6
7
8
9
10
11
13
12
15
17
18
19
20
242322 25 26 27
29 28
303132
5
21
16
Introduction
Front side
1. Lid with stitch overview and button ruler
2. Threading slots
3. Thread cutter
4. Sensormatic buttonhole foot socket
5. Light bulbs
6. Built-in needle threader
7. Needle bar
8. Needle thread guide
9. Stitch plate
10. Bobbin cover
11. Free arm
12. Presser foot
13. IDT
14. Presser foot bar and presser foot holder
15. Needle screw
16. Presser foot lift (3.0 and 2.0)
17. Buttons and graphic display
18. Handwheel
19. Main switch, connectors for power cord and
foot control
20. Slide for lowering the feed dogs
21. Connection for knee-lift (4.0)
Top parts
22. Pre-tension disk for threading and bobbin
winding
23. Bobbin winder thread guide
24. Thread guide
25. Bobbin thread guides
26. Bobbin thread cutter
27. Bobbin winder lever and bobbin spindle
28. Auxiliary spool pin
29. Spool caps
30. Spool pin
31. Thread tension disk
32. Take-up lever
Introduction
Machine overview
1:5

35
34
33
383736
424140
45
44
43
484746
39
Introduction
Accessory tray
The accessory tray features special compartments
for presser feet and bobbins, plus space for needles
and other accessories. Store the accessories in the
tray so they are easily accessible.
33. Space for accessories
34. Removable tray for presser feet
35. Removable bobbin holder
Included accessories
36. Thread net
37. Edge guide
38. Felt pad
39. Light bulb remover
40. Screwdriver
41. Seam ripper
42. Brush
43. Spool cap, large
44. Spool cap, medium
45. Spool cap, small
46. Multi-purpose tool
47. Bobbins
48. Knee-lift (4.0)
Included accessories not in picture
• Foot control
• Power cord
• Needles
1:6

Introduction
Presser feet
Standard presser foot 0A with IDT (attached on the machine upon delivery)
This foot is used mainly for straight stitching and zigzag stitching with a stitch length
longer than 1.0 mm.
Fancy stitch foot 1A with IDT
This foot is used for decorative stitches. The groove on the underside of the foot is
designed to Áow smoothly over the stitches.
Fancy stitch foot 2A
When sewing decorative stitches or short zigzag stitches and other utility stitches with
less than 1.0mm stitch length, use this foot. The groove on the underside of the foot is
designed to Áow smoothly over the stitches.
Blindhem foot 3 with IDT
This foot is used for blindhem stitches. The toe on the foot guides the fabric. The red
guide on the foot is designed to ride along the fold of the hem edge.
Zipper foot 4 with IDT
This foot can be snapped on either the right or the left of the needle, making it easy to
sew close to both sides of the zipper teeth. Move the needle position to the right or left to
sew closer to zipper teeth.
Sensormatic buttonhole foot 5A
When connected to the machine, the buttonhole is sewn in a suitable length to the button
size that has been entered into the machine.
Manual buttonhole foot 5M
This foot is used for sewing manual buttonholes. Use the markings on the foot to position
the garment edge. The Ànger on the back of the foot holds cording for corded buttonhole.
Sensormatic free-motion foot 6A (4.0)
This foot is used for sensormatic free-motion sewing. This foot can also be used for
darning.
Rolled hem foot 7 with IDT, 3 mm
This foot is used to sew narrow hems in light to medium weight fabric.
1/4” quilting foot with IDT (4.0)
This foot is perfect for piecing and patchwork, especially when used in conjunction with
the straight stitch needle plate. The clearance between the needle and the outer edge of
the toe is 1/4” (6 mm) and between the needle and the inner edge of the toe 1/8” (3 mm).
Free-motion/Darning foot (3.0 and 2.0)
Insert the pin of the foot as far as it will go into the hole at the back of the presser foot
holder. The ”C-shaped” guide should be positioned around the presser foot bar. The long
arm must be behind the needle bar. Tighten the screw.
Important: Make sure that the IDT is disengaged when using presser foot 2A, 5A, 5M, 6A and
the free-motion/darning foot.
1:7

Introduction
Stitch overview
Utility stitches
Stitch Stitch number Name Description
4.0 3.0 2.0
111
Straight stitch For seaming and topstitching. Select from 37 different needle positions.
Note: This stitch makes a stronger tie-off than stitch 51 (4.0) / 40 (3.0) / 32 (2.0).
222
Stretch triple straight stitch Reinforced seam. Topstitching.
333
Straight stitch reverse Sew continuous reverse.
444
Basting stitch Single stitch used for basting. Touch foot control to sew one stitch. Move fabric manually to desired
position and touch foot control again to sew another stitch.
555
Zigzag stitch Reinforce seams, clean Ànish, stretch sewing, lace insertion.
66–
Zigzag stitch Reinforce seams, clean Ànish, stretch sewing.
776
Z-zigzag stitch Appliqué, couching, eyelets.
887
Stretch triple zigzag stitch Elastic stitch for decorative hems or topstitching.
998
Three-step zigzag stitch Sewing elastic, darning, patching.
10 10 –
Elastic stitch Sewing elastic, darning, patching.
11 11 9
Triple stretch stitch Sewing elastic, darning, patching and decorative sewing.
12 12 10
Honeycomb stitch Decorative stitch for stretch fabrics and hems. Also used with elastic thread in the bobbin.
13 13 11
Bridging stitch Joining fabrics and quilt batting, decorative stitch for quilting, hemstitching.
14 14 12
Foundation elastic stitch Joining stitch for undergarments, terry cloth, leather, bulky fabrics where overlapping the seams.
15 15 –
Crosshem stitch Elastic decorative hem for stretch fabrics.
16 16 13
Blindhem stitch Sewing blindhems on woven fabrics.
17 17 14
Elastic blindhem stitch Sewing blindhems on stretch fabrics.
18 18 15
Stretch tricot stitch Sewing seams on stretch fabrics.
19 19 16
Closed overlock Seam and overcast stretch fabrics in one step.
20 – –
Closed overlock Seam and overcast in one step.
21 20 17
Closed overlock Seam and overcast in one step with reinforced edge.
22 21 18
Elastic overcast Seam and overcast stretch fabrics in one step.
23 – –
Standard overcast Seam and overcast stretch fabrics in one step with reinforced edge.
1:8

Introduction
Stitch Stitch number Name Description
4.0 3.0 2.0
24 22 19
Overlock Seam and overcast stretch fabrics in one step.
25 23 20
Closed overlock Seam and overcast in one step, patch, hem.
26 24 21
Stretch knit overlock Seam and overcast stretch fabrics in one step.
27 – –
Reinforced overlock Seam and overcast stretch fabrics in one step and reinforce.
28 – –
Finished edge overlock Seam and overcast stretch fabrics in one step with reinforced edge.
29 – –
Mock cover hem Create the look of a serger cover hem for stretch fabrics.
30 – –
Open overlock blindhem Create decorative overlock blindhem for woven fabrics.
31 – –
Closed overlock blind hem Create decorative overlock blindhem for stretch fabrics.
32 25 22
Linen buttonhole Buttonhole for blouses, shirts and linen.
33 26 23
Standard buttonhole Basic buttonhole for blouses, shirts and jackets. Also for pillowcases.
34 27 24
Rounded buttonhole with
pointed tack
Buttonhole for garments.
35 28 –
Rounded buttonhole with
lengthwise tack
Buttonhole for garments.
36 29 –
Eyelet buttonhole with pointed
tack
Tailors buttonhole or decorative buttonhole.
37 30 25
Eyelet buttonhole with
lengthwise tack
Tailors buttonhole for jackets and trousers.
38 31 26
Rounded buttonhole Buttonhole for light garments or jackets.
39 32 –
Stretch buttonhole Buttonhole for stretch fabrics.
40 – –
Cross stitch buttonhole Decorative buttonhole.
41 – –
Decorative eyelet buttonhole Decorative buttonhole for jackets.
42 – –
Heirloom round buttonhole
with pointed tack
Decorative heirloom buttonhole.
43 33 27
Button sewing Sew on buttons or tacking.
44 34 28
Eyelet Heirloom sewing decorative trim.
45 35 29
Programmable darning stitch Darning holes or damaged fabric.
46 36 30
Programmable reinforced
darning stitch
Reinforced darning holes or damaged fabric.
47 37 31
Bartack Automatically reinforce seams and pockets.
1:9

Introduction
Stitch Stitch number Name Description
4.0 3.0 2.0
48 38 –
Denim bartack Automatically reinforce seams and pockets decoratively.
49 39 –
Decorative bartack Automatically reinforce seams and pockets decoratively.
50 – –
Cross bartack Automatically reinforce seams and pockets.
Quilt stitches
Stitch
4.0 51* 52 53 54 55 56 57 58 59 60 61 62 63 64 65 66 67 68 69 70 71 72 73 74
3.0 40* 41 - 42 - 43 - 44 45 - - 46 - 47 48 - - 49 50 51 - 52 - 53
2.0 32* 33 - 34 - 35 - 36 - - - 37 - 38 39 - - - 40 41 - - - 42
Stitch
4.0 75 76 77 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96
3.0 54--55--5657-58-5960-61-62-----
2.0 ---43--4445-46--47---------
Needle art stitches
Stitch
4.0 97 98 99 100 101 102 103 104 105 106 107 108 109 110 111 112 113 114 115 116 117 118 119 120
3.0 63 64 65 66 - 67 68 69 70 - 71 72 73 - 74 75 76 - 77 78 79 - 80 -
2.0 48 49 50 - - - 51 52 53 - 54 55 56 - - 57 58 - - 59 60 - 61 -
Stitch
4.0 121 122 123 124 125 126 127 128 129
3.0 8182- 838485868788
2.0 62 63 - - - 64 - 65 -
Decorative stitches
Stitch
4.0 130 131 132 133 134 135 136 137 138 139 140 141 142 143 144 145 146 147 148 149 150 151 152 153
3.0 89 90 - 91 92 93 94 - 95 - 96 97 98 99 100 101 - 102 103 - 104 105 106 -
2.0 6667--68-69---70-71-72--7374--75--
Stitch
4.0 154 155 156 157 158 159 160 161 162 163 164 165 166 167 168 169 170 171 172 173 174 175 176 177
3.0 - 107 - 108 109 - 110 - 111 112 113 - 114 115 116 117 118 119 120 121 122 - 123 124
2.0 - 76 - 77 78 - - - - 79 80 - 81 - - 82 83 - 84 85 86 - 87 88
* This stitch makes a more decorative tie-off than stitch 1.
1:10

Introduction
Stitch
4.0 178 179 180 181 182 183 184 185 186 187 188 189 190 191 192 193 194 195 196 197 198 199 200 201
3.0 125 - 126 - - 127 - - - 128 129 130 131 132 133 - 134 135 136 137 138 - - 139
2.0 89--------9091-92---9394-9596---
Stitch
4.0 202 203 204 205 206 207 208 209 210 211 212 213 214 215 216 217 218 219 220 221 222
3.0 140 141 142 143 144 145 - - 146 147 148 149 150 - 151 152 153 - - - -
2.0 9798-99100101--102103--104--------
Alphabets
Comic (4.0 and 3.0)
Cyrillic (4.0 and 3.0)
Outline (4.0)
1:11

Preparations

ABC
Preparations
Preparations
Unpacking
1. Place the box on a steady, Áat surface. Lift
the machine out of the box, remove the outer
packaging and lift off the machine carrying
case.
2. Remove all outer packing material and the
plastic bag.
3. Slide off the accessory tray and remove the
styrofoam inside.
Note: Styrofoam left in the accessory tray while sewing
may affect stitch quality. The styrofoam is for packing
purposes only and should be removed.
Connect to the power supply
Among the accessories you will Ànd the power
cord and the foot control.
Note: Before plugging in the foot control, check to
ensure that it is type ”FR5” (see underside of foot
control).
1. Take out the foot control cord. Turn the foot
control over. Connect the cord to the socket
inside the space of the foot control. Push Àrmly
to make sure it is properly connected. Lay the
cord in the slot on the underside of the foot
control.
Note: Connecting the foot control cord to the foot
control is only necessary the very Àrst time you are
going to use the machine.
2. Connect the foot control cord to the front
socket on the bottom right side of the machine
(A).
3. Connect the power cord to the rear socket on
the bottom right side of the machine (B). Plug
the cord into the wall socket.
4. Press the ON/OFF switch to ON to turn on
power and light (C).
For the USA and Canada
This sewing machine has a polarized plug (one
blade wider than the other). To reduce the risk
of electric shock, this plug is intended to Àt in a
polarized outlet only one way. If the plug does not
Àt fully in the outlet, reverse the plug. If it still does
not Àt, contact a qualiÀed electrician to install the
proper outlet. Do not modify the plug in any way.
2:1

A
Preparations
Pack away after sewing
1. Switch the main switch off.
2. Unplug the cord from the wall socket and then
from the machine.
3. Unplug the foot control cord from the machine.
Wind the cord around the foot control for easy
storage.
4. Place all accessories in the accessory tray. Slide
the tray on to the machine around the free arm.
5. Place the foot control in the space above the
free arm.
6. Put on the hard cover.
Free arm
To use the free arm, slide off the accessory tray.
When attached, a hook keeps the accessory tray
locked to the machine. Remove the tray by sliding
it to the left.
Thread cutter
To use the thread cutter, pull the thread from back
to front as shown (A).
Spool pins
Your machine has two spool pins, a main spool
pin and an auxiliary spool pin. The spool pins
are designed for all types of thread. The main
spool pin is adjustable and can be used both in a
horizontal position (the thread reels off the spool)
and a vertical position (the thread spool rotates).
Use the horizontal position for normal threads and
the vertical position for large spools or specialty
threads.
Horizontal position
Place a spool cap and the thread spool on the spool
pin. Make sure that the thread reels over the top
and slide on a second spool cap.
Use a spool cap slightly larger than the thread
spool. For narrow thread spools, use a smaller
spool cap in front of the spool. For large thread
spools, use a larger spool cap in front of the spool.
The Áat side of the spool cap should be pressed
Àrmly against the spool. There should be no space
between the spool cap and the thread spool.
Small spool cap
Large spool cap
2:2

PF
A
AC
D
E
B
C
B
Preparations
Main spool pin in vertical position
Vertical position
Raise the spool pin to the vertical position. Slide
on the large spool cap and place a felt pad under
the thread spool. This is to prevent the thread from
reeling off too fast.
Do not place a spool cap on top of the spool pin as
that would prevent the spool from rotating.
Auxiliary spool pin
The auxiliary spool pin is used when winding a
bobbin thread from a second spool of thread or for
a second spool when sewing with a twin needle.
Raise the auxiliary spool pin. Slide on a large spool
cap and place a felt pad under the thread spool.
Threading the machine
Make sure that the presser foot is raised and the
needle is in the up position.
1. Place the thread on the spool pin and Àt a spool
cap of the right size.
2. Pull the thread into the thread guide (A) from
the front to the back. Pull the thread from the
right underneath the bobbin winder thread
guide (B) on the pre-tension disc (C).
3. Thread down through the right-hand
threading slot and then upwards through the
left-hand threading slot.
4. Bring the thread from the right into the take-up
lever (D) and down in the left-hand threading
slot to the needle thread guide (E).
5. Thread the needle.
Auxiliary spool pin and main spool pin in vertical
position.
2:3

PF
A
C
B
D
H
G
AC
E
F
B
Preparations
Needle threader
The needle threader allows you to thread the
needle automatically. The needle must be in the up
position to use the built-in needle threader. We also
recommend lowering the presser foot.
1. Use the handle to pull the needle threader all
the way down. The threader hook (G) swivels
through the needle eye.
2. Place the thread from the back over the hook
(H) and under the thread hook (G).
3. Let the needle threader gently swing back. The
hook pulls the thread through the needle eye
and forms a loop behind the needle. Pull the
thread loop out behind the needle.
Note: The needle threader is designed to be used for size
70-120 needles. You cannot use the needle threader for
size 60 needles or smaller, a wing needle, twin needle or
triple needle. There are also some optional accessories
that require manual threading of the needle.
Threading for twin needle
Replace the sewing needle with a twin needle.
Make sure that the presser foot is raised and the
needle is in the up position.
1. Place the thread on the spool pin and Àt a
spool cap of the right size. Raise the auxiliary
spool pin. Slide on a large spool cap and a felt
pad. Place the second thread on the spool pin.
2. Pull the threads into the thread guide (A) from
the front to the back. Pull both threads from
the right underneath the bobbin winder thread
guide (B) on the pre-tension disc (C).
3. Thread down through the right-hand
threading slot and then upwards through the
left-hand threading slot. Make sure that you
pass one thread to the left and one thread to
the right sides of the tension disk (D).
4. Bring the threads from the right into the
take-up lever (E) and down in the left-hand
threading slot. Make sure that one thread is
inside the needle thread guide (F) and the
other one outside. Make sure that the threads
do not become twisted together.
5. Thread the needles.
2:4

B
C
A
C
A
B
D
C C
E
Preparations
Bobbin winding
Winding from horizontal position
1. Place an empty bobbin on the bobbin spindle,
with the logo facing up. Use only the original
PFAFF® bobbins approved for this model.
2. Place the thread spool on the spool pin in
horizontal position. Slide a spool cap tightly
against the spool.
3. Place the thread into the thread guide (A) from
front to back. Pull the thread counter-clockwise
above the bobbin winder thread guide (B) and
then through the bobbin thread guides (C) at
the rear.
Note: Make sure the thread is pulled securely inside
the pre-tension device for correct thread tension.
4. Thread through the hole in the bobbin (D) from
the inside to the outside.
5. Push the bobbin lever to the right to wind. A
pop-up appears on the screen to inform you
that bobbin winding is active. Press the foot
control to start winding the bobbin.
When the bobbin is full, the bobbin winding
will slow down and stop automatically. The
pop-up closes. Remove the bobbin and cut the
thread using the bobbin thread cutter (E).
Winding through the needle
Make sure that the presser foot and the needle are
in the up position. Only wind through the needle if
using a metal presser foot.
Bring the thread up from the needle, under
the presser foot, upward through the left-hand
threading slot and through the bobbin thread
guides (C). Then follow step 4 and 5 above.
2:5

12
43
A
B
C
D
Preparations
Inserting the bobbin
1. Remove the bobbin cover by sliding it towards
you.
2. Place the bobbin in the bobbin case with the
logo facing up and the thread unreeling from
the left of the bobbin. The bobbin will then
rotate counter-clockwise when you pull out
the thread.
3. Place your Ànger on the bobbin to keep it from
turning as you pull the thread Àrmly to the
right and then to the left into the tension spring
(A) until it “clicks” into place.
4. Continue threading around (B) and to the right
of the thread cutter (C). Replace the cover. Pull
the thread to the left to cut.
Note: The bobbin cover can be used as a magnifying
glass.
IDT (integrated dual feed)
For sewing any fabric precisely PFAFF®
expression™ sewing machine provides the ideal
solution: the integrated dual feed, IDT system. As
on industrial machines, the IDT feeds the fabric
from the top and bottom at the same time. The
material is fed precisely. On light fabrics such as
silk or rayon the dual feed prevents puckering of
the seam. The even feeding action also ensures
perfect matching of checked and striped fabrics.
The IDT keeps all layers of quilt projects aligned to
prevent shifting of the top layers.
Engaging the IDT
Important: For all work with the IDT, use presser feet
with the center back cut-out (D).
Raise the presser foot. Press the IDT down until it
engages.
Disengaging the IDT
Raise the presser foot. Hold the IDT with two
Àngers at the ribbed ankle. Pull the IDT down, then
pull it away from you to release the IDT slowly
upward.
2:6

G
H
I
A
BCDEF
Preparations
Electronic knee-lift (4.0)
Your machine comes with an electronic knee-lift
for regulating the presser foot height.
Insert the knee-lift in the provided hole on the
machine. Adjust the rectangular bar on the knee-
lift (A) until it is positioned at a comfortable height
for you.
If you press the knee-lift to the right, the presser
foot will raise. You can now guide the fabric with
both hands.
To remove the knee-lift, just pull it straight out of
the hole.
Needles
The sewing machine needle plays an important
role in successful sewing. Use only quality needles.
We recommend needles of system 130/705H.
The needle package included with your machine
contains needles of the most frequently used sizes.
Universal needle (B)
Universal Needles have a slightly rounded point
and come in a variety of sizes. For general sewing
in a variety of fabric types and weights.
Stretch needle (C)
Stretch Needles have a special scarf to eliminate
skipped stitches when there is a Áex in the fabric.
For knits, swimwear, Áeece, synthetic suedes and
leathers. Marked with a yellow band.
Embroidery needle (D)
Embroidery Needles have a special scarf, a slightly
rounded point and a slightly larger eye to avoid
damage to thread and materials. Use with metallic
and other specialty threads for embroidery and
decorative sewing. Marked with a red band.
Denim needle (E)
Denim needles have a sharp point to penetrate
tightly woven fabrics without deÁecting the needle.
For canvas, denim, microÀbers. Marked with a blue
band.
Wing needles (F)
The Wing Needle has wide wings on the side of
the needle to poke holes in the fabric when sewing
entredeux and other hemstitches on natural Àber
fabrics. Decrease the stitch width for best results.
Note: Change the needle often. Always use a straight
needle with a sharp point (G).
A damaged needle (H) can cause skipped stitches,
breakage or snapping of the thread. A damaged needle
can also damage the stitch plate.
Do not use asymmetrical twin needles (I), since it may
damage your sewing machine.
2:7

Preparations
Changing the needle
1. Use the hole in the multi-purpose tool to hold
the needle.
2. Loosen the needle screw. Use the screw driver
if necessary.
3. Remove the needle.
4. Insert the new needle, using the multi-purpose
tool. Push the new needle upwards with the
Áat side away from you until it will go no
further.
5. Tighten the needle screw as tight as it will go.
Lowering feed dogs
You can lower the feed dogs by moving the switch
on the front of the sewing machine to the left.
Move the switch to the right if you wish to raise the
feed dogs.
Changing the presser foot
Remove presser foot
Press the presser foot downwards until it
disengages from the presser foot holder.
Attach presser foot
Place the presser foot under the presser foot holder,
so that when the presser foot is lowered, the pins of
the foot engage in the presser foot holder.
Note: Check that the presser foot is properly attached by
raising the presser foot.
2:8
