Phcbi MDF-C8V1 User manual

©2018PHC Corporation
All rights reserved. Unauthorized copying
and distribution is a violation of law
Service Manual
Ultra-Low Temperature Freezer
PHC Corporation
Biomedical Div.

Effective models
This service manual is effective following models.
Model name Product code Voltage and Frequency
MDF-C8V1 823 012 51 115V 60Hz
823 012 52 220V 50Hz
823 012 53 220V 60Hz
823 012 54 220/230/240V 50Hz
823 012 55 220V 50Hz
823 012 56 110V 60Hz

Contents
Page
Specifications ------------------------------------------------ 1
- Structural specifications
- Control specifications
- Performance specifications
Dimensions ------------------------------------------------ 4
Cooling unit parts ---------------------------------------------- 5
Cooling circuit ---------------------------------------------- 6
Components on PCB ------------------------------------------- 7
Electric parts ---------------------------------------------- 8
Specifications of sensor -------------------------------------- 9
Wiring diagram ------------------------------------------------ 10
Circuit diagram ------------------------------------------------ 11
Connections on PCB ------------------------------------------ 12
Control specifications --------------------------------------- 13
Parts layout ------------------------------------------------ 22
Test data ------------------------------------------------ 25
- Pull-up & Pull-down temperature
- Pull-down temperature
- Pull-down pressure
- Pull-down current input
- Temperature uniformity (15points measured)
Instruction manual ---------------------------------------------- 34
Upon unit repair:
- Be sure to collect refrigerant thoroughly and pull vacuum for 5 minutes
at least, before you repair the unit. It may be caused fire in welding
process by using ‘R-600’.
- You should use ‘MU-N49’ for servicing.
Procedures for trial operation:
1. Turn all the switches (Power SW and Battery SW) off beforehand.
2. Connect the plug to outlet then turn Power SW on.
3. Turn Battery SW on.
(Note) If you turn battery switch on prior to turn power switch on,
buzzer should be emitted until the unit is reached to setting
temperature.

1
Specifications
ŶStructural specifications
Item Specifications
External dimensions W 550 × D 685 (+83)* × H 945㧔mm㧕
Internal dimensions W 405 × D 490 × H 425(mm)
Effective capacity 84 L
Exterior Painted steel
Interior Painted steel
Door Painted steel
Insulation Cabinet; Rigid polyurethane foamed-in place
and VIP(vacuum insulation panel)
Door; Rigid polyurethane foamed-in place
Door lock 1pc (also used as a latch)
Caster 4pc,㧔2 leveling foot㧕
Access port Ǿ17mm, back side, bottom
Refrigeration circuit Primary cooling system
Compressor Hermetic rotary type, 400W
Evaporator Tube on sheet type (also used as a inner cabinet)
Condenser Finless tube type
Refrigerant HFC mixed refrigerant (R245fa/R600/R23/R14)
Refrigerant oil Ze-NIUSL22SA
Power supply Local voltage
Weight 67 kg
Accessory 1 set of key, 1 scraper
Optional component Automatic temperature recorder (MTR-85H, MTR-G85)
Mounting kit for MTR-85H (MDF-S3085)
Recorder sensor cover (MTR-C8)
Back-up system (CVK-UB4)
Back-up mounting plate (MDF-UBK)
Inventory rack (IR-207C, IR-305C)
* means the dimension of projected area.











2

ŶControl specifications
Item Specifications
Cooling performance -80(1/2H temp, AT 30, no load)
Temperature control range -60~-80(AT5~30, no load)
Temperature controller Microprocessor controlled system: Key-pad input
Temperature set range: -55~-85(1increment)
Set value kept in non-volatile memory
Temperature sensor Pt.1000ǡ
Temperature display LED digital display㧔1increment㧕
High temp. Selectable +5~+20for high temp. alarm (Initial; +10)
ALARM lamp blinks and intermittent buzzer sounds with
15min.of delay
Remote alarm contact: Normal Open, rating 30VDC, 2A
Temperature alarm turns on during power failure
(not linked with buzzer)
Low temp. Selectable -5~-20for low temp. alarm (Initial; -10)
ALARM lamp blinks and intermittent buzzer sounds with
15min.of delay
Remote alarm contact: Normal Open, rating 30VDC, 2A
Temperature alarm turns on during power failure
(not linked with buzzer)
Power failure ALARM lamp blinks with intermittent buzzer sounds, remote
alarm outputs.
Remote alarm 3P remote alarm terminal: Maximum 30VDC, 2A
NC-COMޔNO-COM
Outputs during temperature alarm and power failure alarm.
Battery check BATTERY lamp is lit when accumulation time is about 3 yrs
Alarms
Fan motor check BATTERY lamp blinks when accumulation time is about 6 yrs
Control panel Lamp: ALARM, BATTERY
BUZZER: Buzzer key
ALARM TEST: Alarm test key
SET: To switch SV and PV
㧪: To shift the digit
ȁ: To change the digit
Key lock function With 㧪key is pressed for 5 seconds;
L0: Unlocked L1: Locked
Temp. control sensor abnormality
zError code and chamber temp. are alternately displayed.
zRemote alarm contact is ON and the buzzer sounds.
Self diagnosis function
Fan motor malfunction
zError code and chamber temp. are alternately displayed.
zALARM lamp blinks and buzzer sounds.
Power switch Breaker switch
Compressor protection Internal thermostat and comp. sensor



3
ŶPerformance specifications
Cooling performance -80(ambient temperature; 30, no load)
Temp. control range -60to -80(ambient temperature; 30, no load)
Rated voltage AC110V AC115V AC220V AC230V AC240V AC220V
Rated frequency 60Hz 60Hz 50Hz 50Hz 50Hz 60Hz
Rated power consumption 330W 340W 310W 330W 365W 350W
Noise level 47 dB [A] (background noise; 20dB)
Maximum pressure 3.5MPa
Note) Specifications will be subject to change without notice.

4
Dimensions

5
Cooling unit parts
<MDF-C8V>
Item Specifications
Compressor
115V, 60Hz Type: C-2SN400L2W Compressor code: 807 780 22
220/230/240V,50Hz Type: C-2SN400L5W Compressor code: 807 780 25
Refrigerant oil Ze-NIUSL22SA Charged q’ty: 280cc
Cooling system Forced air cooling
Condenser
Type Finless tube Cascade condenser
Condenser 8 columns x 2 lines Coil pipeW200 mm x 8 columns
Pre-condenser 7 columns x 1 line P290 mm ʊ
Frame pipe Ǿ4.76 x T0.7 mm ʊ
Evaporator
Type
Ǿ7.94 x T0.7 mm
Tube on sheet (also used as interior)
Capillary tube Ǿ1.2
Resistance (PSI kg/cm2) 0.59 MpaG
Length (mm) 2000
Outer diameter (mm) Ǿ1.8
Refrigerant HFC mixed refrigerant: MU-N48(EU)/(DOT)Charged q’ty: 375+/-8 g
Dryer Dry core: D-SM032T Charged q’ty: 35g
Condensing fan Ǿ196 mm, 4 blades
Material: ABS
(115V, 60Hz) SE4-D041N1P Output: 4W
Condensing fan
motor (220/230/240V, 50Hz) SE4-D041N5P Output: 4W
<Compressor terminals layout>

C
S
R

6
Cooling circuits

7
Components on PCB
CN3
#1-#3 To Remote alarm terminal
CN4
#1-#2 To Temp. control relay
CN2
#1-#6 To MTR-480 (Option)
CN1
#1-#3 To Switching Power supply
CN8
#1-#2 To Battery
CN11
#1-#3 To Temp. sensor
CN7
#7-#8 To Comp. sensor
CN6
#1-#12 To Display board
CN5
#1-#5 To control board #6-#7 To Buzzer

8
Compressor Type C-2SN400L2W C-1RN40L6A C-1RN4L5C
Compressor code 802 012 11 802 012 16 802 012 15
Rated voltage (50/60Hz) 㱢1, 110~115V, 60Hz 㱢1, 200V, 60Hz ij1, 220~240V, 50Hz
Winding resistance C-R(Main) 1.674㱅(25㷄) 5.34㱅(25㷄) 7.37㱅(25㷄)
C-S(Aux) 3.419㱅(25㷄) 8.88㱅(25㷄) 15.76㱅(25㷄)
Starting relay Type AMVL-165A AMVL-300A AMVL-300A
Pick up voltage 95~115VAC 215~247VAC 215~247VAC
Drop out voltage 25~60VAC 69~132VAC 69~132VAC
Starting capacitor Rating 100µF, 160VAC 40µF, 300VAC 40µF, 300VAC
Running capacitor Rating 35µF, 220VAC 10µF, 400VAC 12µF, 370VAC
Condensing fan motor Type SE4-D041N1P SE4-D041N5P SE4-D041N5P
Rating 115V, 4P 220~240V, 4P 220~240V, 4P
Temp. control relay Type G4F-11123T G4F-11123T G4F-11123T
Contact capacity 20A, 12VDC 20A, 12VDC 20A, 12VDC
Switching power supply Type ZWS10-12/J ZWS10-12/J ZWS10-12/J
Rated output 12VDC, 0.85A 12VDC, 0.85A 12VDC, 0.85A
Breaker switch Type BAM215131 BAM215131 BAM215131
Rating 250V, 15A 250V, 15A 250V, 15A
Temperature sensor Type PT1000 PT1000 PT1000
Rating 1000㱅(0㷄) 1000㱅(0㷄) 1000㱅(0㷄)
Compressor sensor Type 502AT-1 502AT-1 502AT-1
Rating 5k㱅, 25㷄5k㱅, 25㷄5k㱅, 25㷄
Battery switch Type SLE6A2-5 SLE6A2-5 SLE6A2-5
Rating 4A, 250VAC 4A, 250VAC 4A, 250VAC
Battery Type 5HR-AAC 5HR-AAC 5HR-AAC
Rating 6V, 1100mAH 6V, 1100mAH 6V, 1100mAH
AC115V, 60Hz AC220/230/240V, 50Hz
MDF-C8V1
AC220V, 60Hz
Electric Parts

9
Specifications of sensor
<502AT-1>
Temp.
(C)
Resistance
Value (kǡ)
Temp.
(C)
Resistance
Value (kǡ)
Temp.
(C)
Resistance
Value (kǡ)
Temp.
(C)
Resistance
Value (kǡ)
㧙50 154.5 㧙36 71.80 㧙22 35.65 0 13.29
㧙49 145.9 㧙35 68.15 㧙21 33.99 5 10.80
㧙48 137.8 㧙34 64.71 㧙20 32.43 10 8.84
㧙47 130.2 㧙33 61.48 㧙19 30.92 15 7.20
㧙46 123.1 㧙32 58.43 㧙18 29.50 20 6.01
㧙45 116.5 㧙31 55.55 㧙17 28.14 25 5.00
㧙44 110.2 㧙30 52.84 㧙16 26.87 30 4.17
㧙43 104.4 㧙29 50.23 㧙15 25.65 35 3.50
㧙42 98.87 㧙28 47.77 㧙14 24.51 40 2.96
㧙41 93.70 㧙27 45.45 㧙13 23.42 45 2.51
㧙40 88.85 㧙26 43.26 㧙12 22.39 50 2.13
㧙39 84.18 㧙25 41.19 㧙11 21.41 55 1.82
㧙38 79.80 㧙24 39.24 㧙10 20.48 60 1.56
㧙37 75.67 㧙23 37.39 㧙5 16.43 65 1.35


<PT-1000ȍ>
Temperature
()
Resistance
(ȍ)
Temperature
()
Resistance
(ȍ)
-170
-160
-150
-140
-130
-120
-110
-100
-90
-80
-70
-60
-50
-40
326.92
368.57
409.87
450.83
491.47
531.83
571.92
611.76
651.38
690.78
729.99
769.02
807.87
846.58
-30
-20
-10
0
10
20
30
40
50
60
70
80
90
100
885.13
923.55
961.84
1000.0
1038.0
1076.0
1113.8
1151.4
1189.0
1226.4
1263.8
1301.0
1338.0
1375.0

10
Wiring Diagram

11
Circuit Diagram

12
Connections on PCB
Following is the explanation of connections on Main PCB.
Connector Connects to Usage Voltage
CN1 Switching power supply To supply the power to PCB #1:12V
CN2 MTR-480㧔Option㧕To connect with interface
CN3
Remote alarm terminal
#1: COM.
#2: N.O.
#3: N.C.
Output for remote alarm contact
CN4 #1-#2: Temp. control relay To control chamber temperature
CN5 #1-#5: Control PCB (CN51)
#6-#7: Buzzer To control with each switches
CN6 #1-#12: Display PCB (CN52) To connect with each LED
CN7 #7-#8: Comp. sensor To detect compressor temperature
CN8 #1-#2: Battery To supply the power to Main PCB
during power failure
#2:6V
CN9 Unused
CN11 #1-#3: Temp. sensor To detect chamber temperature

13
㩷Control specifications
1. Key and Switch
BUZZER : In alarm condition, buzzer stops sounding with this key pressed.
Remote alarm output and alarm message would not be off.
During the power failure (battery back-up), press the key to show chamber
temperature.
ALARM TEST : With this key pressed to activate alarm test mode to be forcibly step into
alarm condition (ALARM lamp blinks, intermittent buzzer sounds, digital
LED goes off and remote alarm inputs).
After approx. 90seconds then, normal condition retrieves with Auto Return
activates.
With the battery switch turns off, “E09” blinks on the display.
SET : Pressthiskeyoncetoactivatesetmode(2
nd digit in LED blinks), press the
key again to store the value to be changed.
With Key Lock setting mode (“L 0” or “L 1” is displayed), press the key to
store the value to be changed.
During setting mode, the blinking digit shifts among the 1st digit or the 2nd
digit or 3rd digit.
In chamber temperature display, press this key over 5 seconds to be Key
Lock mode available with ‘L_0’ displayed.
During setting mode, count the blinking digit up. In chamber temperature
display, press the key over 5 seconds to be function mode available with
‘F00’ displayed.
Set your desire value with this key and key, you can use function
mode.
2. Temperature control
Setting range : -55㷄~-85㷄
Display range : -180㷄~+50㷄
Setting procedure : Press SET key and set the required value with key and key.
Press SET key to store the set value.
Unacceptable
setting:
If you try to set value which is out of temperature setting range, the
buzzer sounds for 1 second to inform the value is unacceptable.
3. Key Lock mode and Function mode
A) Key Lock mode
Setting range : 0, 1
Setting procedure: In chamber temperature display, press key over 5 seconds to enter
into Key Lock mode. (“L_0” or “L_1” is displayed. initial: L_0) with “0” or
“1” blinks.
Change the value with key and press SET key to store the value in
the non-volatile memory.
B) Function mode
Setting range : 00~50
Display range : 00~59
00, 04, 08, 13, 15, 16, 18~20, 26~29, 31, 33~49 are unavailable codes.
Setting procedure : In chamber temperature display, press key over 5 seconds to enter
into function mode with F00 is displayed. Change the blinking 1st digit to
desired function code with key and key.
Press SET key to be function code available.

14
Unacceptable
setting:
If you try to input F51~F59 and press SET key, the buzzer sounds to
inform the value is unacceptable.
4. Error codes
E01: Temp. sensor is disconnected
E02: Temp. sensor is short-circuited
E05: Comp. sensor is disconnected
E06: Comp. sensor is short-circuited
E09: Battery switch is OFF
E10: Compressor temperature abnormality
E15: Fan motor malfunction
(1) Temp. sensor abnormality
Disconnection:
E01 and 50㷄are displayed alternately, the buzzer sounds intermittently
and remote alarm contact outputs.
The compressor is continuous running.
Press BUZZER key to stop the buzzer sounding.
Short circuit:
E02 and -170㷄~-180㷄are displayed alternately, the buzzer sounds
intermittently and remote alarm contact outputs.
The compressor is continuous running.
Press BUZZER key to stop the buzzer sounding.
(2) Comp. sensor abnormality
Disconnection: E05 and chamber temperature are displayed alternately, the buzzer
sounds intermittently and remote alarm contact outputs.
Press BUZZER key to stop the buzzer sounding.
Short circuit: E06 and chamber temperature are displayed alternately, the buzzer
sounds intermittently and remote alarm contact outputs.
Press BUZZER key to stop the buzzer sounding.
(3) Battery switch is OFF Press ALARM TEST key to display E09.
(4) Comp. temperature abnormality E10 and chamber temperature are displayed alternately
and compressor stops running.
Press BUZZER key to stop the buzzer sounding.
(5) Fan motor malfunction E15 and chamber temperature are displayed alternately.
Press BUZZER key to stop the buzzer sounding.
(6) Error code priority
No.1: Temp. sensor abnormality (E01 or E02)
No.2: Comp. sensor abnormality (E05 or E06)
No.3: Comp. temperature abnormality (E10)
No.4: Fan motor malfunction (E15)
5. Warning functions
High temp. alarm : When chamber temperature is equal or higher than setting temperature +
high temp. alarm setting temperature + 1, ALARM lamp and digits are
blinking, intermittent buzzer sounds with about 15 minutes of delay, and
remote alarm output turns on.
When chamber temperature is equal or lower than setting temperature
ALARM lamp and digits go off, buzzer stops sounding and remote alarm
output turns off.
If you press BUZZER key, the buzzer stops sounding instead remote
alarm output does not turn off.

15
Low temp. alarm : When chamber temperature is equal or lower than setting temperature +
low temp. alarm setting temperature - 1, ALARM lamp and digits are
blinking, intermittent buzzer sounds with about 15 minutes of delay, and
remote alarm output turns on.
When chamber temperature is equal or higher than setting temperature,
ALARM lamp and digits go off, buzzer stops sounding, and remote alarm
output turns off.
If you press BUZZER key, the buzzer stops sounding instead remote
alarm output does not turn off.
Power failure alarm : When the power switch is OFF with battery switch is ON or the power to
the unit is disconnected or in case of power failure, ALARM lamp is
blinking, intermittent buzzer sounds and remote alarm output turns on.
If the power retrieves within 3 seconds, the unit starts to run with initial
settings. Remote alarm output turns off.
In case of power failure alarm, press BUZZER key to show chamber
temperature for 5 seconds.
6. Self diagnosis and safety functions
Auto Return : If there is not any key operation for 90 seconds in each setting mode,
Key Lock mode and Function mode, the display automatically reverts to
chamber temperature.
Ring back : Buzzer forcibly sounds again after setting time elapses even if anyone
press BUZZER key to stop buzzer sounding in alarming condition.
Ring back time is settable in F25.
Sensor temp. display F12: Temperature in temp. sensor is displayed
(Ex.-80.2㷄㩷 㸢㩷 displayed as ‘80.2’)
F14: Temperature of comp. sensor is displayed.
(Ex.+23㷄㩷 㸢㩷 displayed as ‘023’)
Battery lifespan
check:
F03: Notice of battery accumulation time
(Ex. 2years and 6months accumulated 㸢㩷 Displayed as ‘02.5’)
BATTERY lamp is lit if ’02.8’ is displayed.
<Reset of accumulation time>
Step into F06. Input ‘409’ and press SET key to reset
non-volatile memory to ’00.0’ with BATTERY lamp goes off.
Fan motor lifespan
check:
F32: Notice of fan motor accumulation time
(Ex. 5years and 8monts accumulated 㸢Displayed as ’05.6’)
Battery lamp is blinking when about 6years has passed.
<Reset of accumulation time>
Step into F06. Input ‘419’ and press SET key to reset
non-volatile memory to ’00.0’. The display reverts to chamber
temperature only.
ROMversion :
F30: ROM version is displayed (Ex. Ver. 1.00 㸢㩷 displayed as “1.00”)

16
7. Function modes
F00 Automatically revert to chamber temperature display
F01 High temp. alarm setting
F02 Low temp. alarm setting
F03 Battery lifespan check
F04 Automatically revert to chamber temperature display
F05 Compressor delay time setting
F06 Service code input (code: 384)
F07 * Temp. sensor Zero Adjustment
F08 * Automatically revert to chamber temperature display
F09 * Factory test mode …… Unavailable
F10 * Factory test mode …… Unavailable
F11 * Factory test mode …… Unavailable
F12 * Display of temperature in temp. sensor
F13 * Automatically revert to chamber temperature display
F14 * Display of temperature in Comp. sensor
F15 * Automatically revert to chamber temperature display
F16 * Automatically revert to chamber temperature display
F17 * Model code setting (Initialization of non-volatile ROM and memory)
F18 * Automatically revert to chamber temperature display
F19 * Automatically revert to chamber temperature display
F20 * Automatically revert to chamber temperature display
F21 Communication ID setting
F22 Communication mode setting
F23 * Automatically revert to chamber temperature display
F24 Linkage between Remote alarm terminal and buzzer
F25 Ring back time setting
F26 * Display of actual operation rate
F27 * Automatically revert to chamber temperature display
F28 Factory test mode …… Unavailable
F29 Factory test mode …… Unavailable
F30 * Display of ROM version
F31 * Automatically revert to chamber temperature display
F32 * Fan motor lifespan check
F33~F49 Automatically revert to chamber temperature display
F50 * Temp. alarm delay time setting
Setting
procedure:
In chamber temperature display, press key over 5seconds to display “F00”.
Input the desired function code with key and key.
Press SET key to be function mode available.
* … You should input service code (384) in F06 beforehand.
To cancel service code, input “000” in F06 or turn the power off.
F01: <Function> High temp. alarm setting
<Operation> Input F01 and press SET key to display “010” (initial value).
Set the value in the range “005”~“020” with key. Press SET key
to store the value and revert to chamber temperature display.
F02: <Function> Low temp. alarm setting
<Operation> Input F02 and press SET key to display “-10” (initial value).
Set the value in the range “-05”~“-20” with key. Press SET key to
store the value and revert to chamber temperature display.
F03: <Function> Battery lifespan check
<Operation>
<Reset>
Input F03 and press SET key to display alternately F03 with “00.0”
(in case battery used for 36 days or less). Press SET key to revert to
chamber temperature display.
Step into F06. Input ‘409’ and press SET key to reset non-volatile
memory to ’00.0’ with BATTERY lamp goes off.

17
F05: <Function> Compressor is turned on with forcibly delayed (by minute increment)
when the power retrieves from the power failure.
<Operation> Input “F05” and press SET key to display “003” (initial).
Change the value in the range “003”~”015” with key and key.
Press SET key to store the value and revert to chamber temperature
display.
F06: <Function> Service code input and initialization of accumulation time
<Operation> Input F06 and press SET key to display “000” (initial value).
Set to “384” with key and key. Press SET key to store the
value and revert to chamber temperature display.
<Cancel> Input F06 and press SET key to display “384”.
Change to “000” with key and key. Press SET key to store
the value and revert to chamber temperature display.
Service code is cancelled when the power is ON and OFF, or
accumulation time is reset.
F07: <Function> To match temperature of temp. sensor with temperature of center at
the chamber.
<Operation> Input service code in F06 prior to use this mode.
Input F07 and press SET key to display “00.0” (initial value).
Change to the desired value with key and key in the range of
“-4.9”~”04.9”. Press SET key to store the value and revert to
chamber temperature display.
F12: <Function> To display the temperature of temp. sensor
<Operation> Input service code in F06 prior to use this mode.
Input F12 and press SET key to display alternately F12 and “XX.X”
(chamber temperature). Press SET key to revert to chamber
temperature display. 3 digits indication. Minus “-“ is not displayed.
Ex) “-79.5㷄” 㸢㩷 indicated as “79.5”
F14: <Function> To display the temperature in comp. sensor
<Operation> Input service code in F06 prior to use this mode.
Input F14 and press SET key to display alternately F14 and “XX.X”
(present temperature in comp. sensor). Press SET key to revert to
chamber temperature display.
F17: <Function> Non-volatile memory initialization, model code change
<Operation> Service code should be input in F06 prior to use this mode.
Input F17 and press SET key to display “001”. Change the value
with key and key. Press SET key to store and revert to
chamber temperature display.
Model code ‘003’: MDF-C8V1
<Initial values in non-volatile memory>
Zero adjustment for temp. sensor
Compressor forcibly OFF
Ring back time
Setting temperature
High temp. alarm setting temp.
Low temp. alarm setting temp.
Linkage between remote alarm
and buzzer
Compressor delay time
Communication ID
Communication mode
Temp. alarm delay time
Key lock
: 0㷄
: 8 min.
: 30 min.
: -80㷄
: +10㷄
: -10㷄
: OFF
: 3 min.
: 000
: 000
: 15 min.
: OFF
