PheeNet IEEE802.11n User manual

User Manual WLn-402
Version 1.0
IEEE802.11n
Wireless Router

COPYRIGHT
Copyright © 2008/2009by PheeNet Technology Corp. All rights reserved. No part of
this publication may be reproduced, transmitted, transcribed, stored in a retrieval
system, or translated into any language or computer language, in any form or by any
means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise,
without the prior written permission of PheeNet Technology Corp
PheeNet Technology Corp makes no representations or warranties, either expressed or
implied, with respect to the contents hereof and specifically disclaims any warranties,
merchantability or fitness for any particular purpose. Any software described in this
manual is sold or licensed "as is". Should the programs prove defective following
their purchase, the buyer (and not PheeNet Technology Corp, its distributor, or its
dealer) assumes the entire cost of all necessary servicing, repair, and any incidental or
consequentialdamages resulting from any defect in the software. Further, PheeNet
Technology Corp reserves the right to revise this publication and to make changes
from time to time in the contents thereof without obligation to notify any person of
such revision or changes.

Federal Communication Commission
Interference Statement
FCC Part 15
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the
following measures:
1. Reorient or relocate the receiving antenna.
2. Increase the separation between the equipment and receiver.
3. Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
4. Consult the dealer or an experienced radio technician for help.
FCC Caution
This equipment must be installed and operated in accordance with provided
instructions and a minimum 20 cm spacing must be provided between computer
mounted antenna and person’s body (excluding extremities of hands, wrist and feet)
during wireless modes of operation.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including interference that may
cause undesired operation.
Any changes or modifications not expressly approved by the party responsible for
compliance could void the authority to operate equipment.
Federal Communication Commission (FCC) Radiation Exposure
Statement
This equipment complies with FCC radiation exposure set forth for an uncontrolled
environment. In order to avoid the possibility of exceeding the FCC radio frequency
exposure limits, human proximity to the antenna shall not be less than 20cm (8 inches)
during normal operation.
The antenna(s) used for this transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.

R&TTE Compliance Statement
This equipment complies with all the requirements of DIRECTIVE 1999/5/ECOF
THE EUROPEAN PARLIAMENT AND THE COUNCIL ofMarch 9, 1999 on radio
equipment and telecommunication terminal Equipment and the mutual recognition of
their conformity (R&TTE).
The R&TTE Directive repeals and replaces in the directive 98/13/EEC
(Telecommunications Terminal Equipment and Satellite Earth Station Equipment) As
of April 8, 2000.
Safety
This equipment is designed with the utmost care for the safety of those who install
and use it. However, special attention must be paid to the dangers of electric shock
and static electricity when working with electrical equipment. All guidelines of this
and of the computer manufacture must therefore be allowed at all times to ensure the
safe use of the equipment.
EU Countries Intended for Use
The ETSI version of this device is intended for home and office use in Austria,
Belgium, Denmark, Finland, France,Germany, Greece, Ireland, Italy, Luxembourg,
the Netherlands, Portugal, Spain, Sweden,and the United Kingdom.
The ETSI version of this device is also authorized for use in EFTA member states:
Iceland, Liechtenstein, Norway,and Switzerland.
EU Countries Notintended for use
None.

CATALOG
CHAPTER I:PRODUCT INFORMATION
1-1 Introduction and safety information
1-2 Safety Information
1-3 System Requirements
1-4 Package Contents
1-5 Familiar with your new wireless broadband router
CHAPTER II: SYSTEM AND NETWORK SETUP
2-1 Build network connection
2-2 Connecting to wireless broadband router by web browser
2-2-1 Windows 95/98/Me IP address setup
2-2-2 Windows 2000 IP address setup
2-2-3 Windows XP IP address setup
2-2-4 Windows Vista IP address setup
2-2-5 Router IP address lookup
2-3 Using ‘Quick Setup’
2-3-1 Setup procedure for ‘Cable Modem’
2-3-2 Setup procedure for ‘Fixed-IP xDSL’
2-3-3 Setup procedure for ‘PPPoE xDSL’
2-3-4 Setup procedure for ‘PPTP xDSL’
2-3-5 Setup procedure for ‘L2TP xDSL’
2-3-6 Setup procedure for ‘Telstra Big Pond’
2-4 Basic Setup
2-4-1 Time zone and time auto-synchronization
2-4-2 Change management password

2-4-3 Remote Management
2-5 Setup Internet Connection (WAN Setup)
2-5-1 Setup procedure for ‘Dynamic IP’
2-5-2 Setup procedure for ‘Static IP’
2-5-3 Setup procedure for ‘PPPoE’
2-5-4 Setup procedure for ‘PPTP’
2-5-5 Setup procedure for ‘L2TP’
2-5-6 Setup procedure for ‘Telstra Big Pond’
2-5-7 Setup procedure for ‘DNS’
2-5-8Setup procedure for ‘DDNS’
2-6 Wired LAN Configuration
2-6-1 LAN IP section
2-6-2 DHCP Server
2-6-3 Static DHCP Leases Table
2-7 Wireless LAN Configuration
2-7-1 Basic Wireless Settings
2-7-1-1 Setup procedure for ‘AP'
2-7-1-2Setup procedure for ‘Station-Infrastructure'
2-7-1-3Setup procedure for ‘AP Bridge -Point to Point’
2-7-1-4Setup procedure for ‘AP Bridge -Point to Multi Point’
2-7-1-5Setup procedure for ‘AP Bridge -WDS’
2-7-1-6Setup procedure for ‘Universal Repeater'
2-7-2 Advanced Wireless Settings
2-7-3 Wireless Security
2-7-3-1 Disable wireless security
2-7-3-2 WEP -Wired Equivalent Privacy
2-7-3-3 Wi-Fi Protected Access (WPA)
2-7-3-4 WPA RADIUS
2-7-4 Wireless Access Control
2-7-5 Wi-Fi Protected Setup (WPS)
2-7-6Security Tips for Wireless Network

CHAPTER III:ADVANCED FUNCTIONS
3-1 Quality of Service (QoS)
3-1-1 Basic QoS Settings
3-1-2 Add a new QoS rule
3-2 Network Address Translation (NAT)
3-2-1 Basic NAT Settings (Enable or disable NAT function)
3-2-2Port Forwarding
3-2-3 Virtual Server
3-2-4 Port Mapping for Special Applications
3-2-5 UPnP Setting
3-2-6 ALG Settings
3-3 Firewall
3-3-1 Access Control
3-3-1-1 Add PC
3-3-2 URL Blocking
3-3-3 DoS Attack Prevention
3-3-3-1 DoS -Advanced Settings
3-3-4 Demilitarized Zone (DMZ)
3-4 System Status
3-4-1 System information and firmware version
3-4-2 Internet Connection Status
3-4-3 Device Status
3-4-4 System Log
3-4-5 Active DHCP client list
3-4-6 Statistics
3-5 Configuration Backup and Restore
3-6 Firmware Upgrade
3-7 System Reset

CHAPTER IV: APPENDIX
4-1 Hardware Specification
4-2 Troubleshooting
4-3 Glossary

1
Chapter I: Product Information
1-1 Introduction and safety information
Thank you for purchasing this wireless broadband router! This high
cost-efficiency router is the best choice for Small office / Home office
users, all computers and network devices can share a single xDSL / cable
modem internet connection at high speed. Easy install procedures allows
any computer users to setup a network environment in very short time -
within minutes, even inexperienced. When the number of your computers
and network-enabled devices grow, you can also expand the number of
network slot by simple attach a hub or switch, to extend the scopeof your
network!
All computers and IEEE 802.11b/g/Draft-N wireless-enabled network
devices (including PDA, cellular phone, game console, and more!) can
connect to this wireless router without additional cabling. The MIMO
technology also gives you the highest speed of wireless experience ever!
With a compatible wireless card installed in your PC, you can transfer
file for up to 150Mbps (transfer data rate)! The radio coverage is also
doubled, so don’t worry if your office or house is really big!
Other features including:
•High speed data rate –up to 150Mbps.
•Supports advanced IEEE802.11n technology, enhancing the
throughput and coverage range significantly
•Supports 64/128-bit WEP Encryption and WPA-PSK, WPA2-PSK
Security, Wi-Fi Protected Setup (WPS) with reset button
•Built-in Radius Server
•NAT/NAPT IP Sharing
•Anti-DoS Firewall
•Virtual Server/DMZ
•URL Filtering, MAC / IP Address Filtering
•Supports WMM function to meet the multi-media data bandwidth
requirement.

2
•Supports Special Applications (Port Triggers)
•Supports DDNS (DynDNS, TZO)
•VPN Pass Through (IPSec/PPTP)
•Obtain WAN IP by PPPoE/Static IP/PPTP/DHCP
•DHCP Server
•System Status monitoring, including active DHCP clients, Security
Log, and Device / Connection Status
•Web Interface Management, Firmware Upgrade

3
1-2 Safety Information
In order to keep the safety of users and your properties, please follow the
following safety instructions:
1. This router is designed for indoor use only; DO NOT place this router
outdoor.
2. DO NOT put this router at or near hot or humid places, like kitchen or
bathroom. Also, do not left this router in the car in summer.
3. DO NOT pull any connected cable with force; disconnect it from the
router first.
4. If you want to place this router at high places or hang on the wall,
please make sure the router is firmly secured. Falling from high places
would damage the router and its accessories, and warranty will be void.
5. Accessories of this router, like antenna and power supply, are danger to
small children under 3 years old. They may put the small parts in their
nose or month and it could cause serious damage to them. KEEP THIS
ROUTER OUT THE REACH OF CHILDREN!
6. The router will become hot when being used for long time (This is
normal and is not a malfunction).DO NOT put this router on paper,
cloth, or other flammable materials.
7. There’s no user-serviceable part inside the router. If you found that the
router is not working properly, please contact your dealer of purchase and
ask for help. DO NOT disassemble the router, warranty will be void.
8. If the router falls into water when it’s powered, DO NOT use your
hand to pick it up. Switch the electricalpower off before you do anything,
or contact an experienced technician for help.
9. If you smell something strange, or even see some smoke coming out
from the router or power supply, remove the power supply or switch the
electrical power off immediately, and call dealer of purchase for help.

4
1-3System Requirements
lInternet connection, provided by xDSL or cable modem witha RJ-45
Ethernet port.
lComputer or network devices with wired or wireless network interface
card.
lWeb browser (Microsoft Internet Explorer 4.0 or above, Netscape
Navigator 4.7 or above,Opera web browser, or Safari web browser).
lAn available AC power socket (100 –240V, 50/60Hz)

5
1-4Package Contents
Before you starting to use this router, please check if there’s anything
missing in the package, and contact your dealer of purchase to claim for
missing items:
□WLn-402, 802.11n Wireless Router (1 pcs)……………………… 1
□Quick installation guide (1 pcs) ………………………………… 2
□User manual CDROM (1 pcs) ………………………………….. 3
□A/C power adapter (1 pcs) ……………………………………..... 4

6
1-5 Familiar with your new wireless broadband router
Front Panel
LED Name Light Status Description
PWR On Router is switched on and correctly powered.
On Wireless WPS function is enabled.
Off Wireless network is switched off.
WLAN Flashing Wireless LAN activity (transferring or
receiving data).
On WAN port (Internet) is running at 100Mbps.
Off WAN port (Internet) is running at 10Mbps.
WAN
10/100MFlashing WAN activity (transferring or receiving data).
On WAN port is connected.
Off WAN port is not connected.
WAN
LNK/ACTFlashing WAN activity (transferring or receiving data).
On LAN port is running at 100Mbps.LAN
10/100M Off LAN port is running at 10Mbps.
On LAN port is connected.
Off LAN port is not connected.
LAN
LNK/ACTFlashing LAN activity (transferring or receiving data).

7
Back Panel
Item Name Description
Antenna A/B These antennas are 3dBi dipole antennas.
Power Power connector, connects to A/C power adapter.
Reset / WPS Reset the router to factory default settings (clear all settings) or
start WPS function. Press this button and hold for 10 seconds to
restore all settings to factory defaults, and press this button for less
than 5seconds to start WPS function.
1 -4 Local Area Network (LAN) ports 1 to 4.
WAN Wide Area Network (WAN / Internet) port.
Antenna A Antenna B

8
Chapter II: System and Network Setup
2-1 Build networkconnection
Please follow the following instruction to build the network connection
between your new WIRELESS router and your computers, network
devices:
1. Connect your xDSL / cable modem to the WAN port of router by
Ethernet cable.
2. Connect all your computers, network devices (network-enabled
consumer devices other than computers, like game console, or switch /
hub) to the LAN port of the router.

9
3. Connect the A/C power adapter to the wall socket, and then connect it
to the ‘Power’socket of the router.
4. Please check all LEDs on the front panel. ‘PWR’LED should be
steadily on, WAN and LAN LEDs should be on if the computer /
network device connected to the respective port of the router is
powered on and correctly connected. If PWD LED is not on, or any
LED you expected is not on, please recheck the cabling, or jump to
‘4-2 Troubleshooting’for possible reasons and solution.

10
2-2 Connecting to wireless broadband router by web browser
After the network connection is built, the next step you should do is
setup the router with proper network parameters, so it can work properly
in your network environment.
Before you can connect to the router and start configuration
procedures, your computer must be able to get an IP address
automatically (use dynamic IP address). If it’s set to use static IP address,
or you’re unsure, please follow the following instructions to configure
your computer to use dynamic IP address:
If the operating system of your computer is….
Windows 95/98/Me -please go to section 2-2-1
Windows 2000 -please go to section 2-2-2
Windows XP -please go to section 2-2-3
Windows Vista -please go to section 2-2-4
2-2-1 Windows 95/98/Me IP address setup:
1. Click ‘Start’button (it should be located at lower-left corner of your
computer), then click control panel. Double-click Network icon, and
Network window will appear. Select ‘TCP/IP’, then click ‘Properties’.

11
2. Select ‘Obtain an IP address from a DHCP server’and then click ‘OK’.
