PHI VILLA 3PCS PADDED CONVERSATION SETS Operation instructions

3PCS PADDED CONVERSATION SETS
ASSEMBLE INSTRUCTION
E02GF040802801
Warranty
1 YEAR FRAME AND 1 YEAR FABRIC LIMITED WARRANTY
CUSTOMER SERVICE
Safety Information
PRODUCTCAUTION
This dining set was made for the explicit purpose of providing outdoor functions and isnot tobeused as a toy. Thisproduct is intended for
normal outdoor use; however, themanufacturer recommends storing and / or covering this set when any formidable/ severe weather is
product.
Children under the age of 10, near theproduct, should be supervised byacompetent adult at all times. Thisproduct isNOT intended for
commercial use and will void the warranty.
Call Our After Sales Support Hotline [phone] Monday-Friday 7am-5pm CST
Or Our Email Address: [email protected]
AlphaMarts.com
AlphaMarts.com

PART LIST FIGURE QUANTITY DESCRIPTION
A 4PCS LEG
B 1PC LEG CONNECTOR
C 1PC TABLERIM
D 1PC TILE
E16+1PCS FLAT WASHER
F16+1PCS BOLT (M6*15)
G 1 ALLEN WRENCH
WEIGHT LIMIT
110 LBS
CARE AND CLEANING
IN ORDER TO PROLONG THE LIFE OF YOUR TABLE, PLEASE STORE IN DRY SHELTERED PLACE WHEN NOT IN USE OR DURING INCLEMENT
WEATHER.
S
TEP 1
A
. PLACE TABLE RIM (C) UPSIDE DOWN ON A FLAT, PROTECTED
S
URFACE.
B
. ATTACH LEGS (A) TO TABLE RIM (C) WITH FLAT WASHER (E)
A
ND BOLT (F) USING ALLEN WRENCH (G). DO NOT TIGHTEN
C
OMPLETELY.
STEP 2
A.
ATTACH LEG CONNECTOR (B) TO LEGS (A) WITH FLAT
W
ASHER (E) AND BOLT (F) USING ALLEN WRENCH (G). DO
N
OT TIGHTEN COMPLETELY.
STEP 3
A
. TURN TABLE TO UPRIGHT POSITION SO THAT IT STANDS
S
QUARELY ON THE FLOOR.
B
. TIGHTEN ALL BOLTS (F) SECURELY USING ALLEN WRENCH
(
G).
STEP 4
A. CAREFULLY PLACE TILE (D) ONTO TABLE RIM (C).
B. RETAIN ALLEN WRENCH (G) FOR USE TO TIGHTEN BOLTS (F)
PERIODICALLY OR AS NEEDED.
AlphaMarts.com
AlphaMarts.com

PART LIST FIGURE QUANTITY DESCRIPTION
A 1PC LEFT ARM
B 1PC RIGHT ARM
C 1PC BACK
D 1PC SEAT
E 2+1PCS SHORT BOLT(M6*20)
F 6+1PCS LONG BOLT (M6*40)
G 8+1PCS FLAT WASHER
H 1PC ALLEN WRENCH
WEIGHT LIMIT
250 LBS
CARE AND CLEANING
IN ORDER TO PROLONG THE LIFE OF YOUR CHAIR,PLEASE STORE IN DRY SHELTERED PLACE WHEN NOT IN USE OR DURING
INCLEMENT WEATHER.
STEP 1
A. PLACE LEFT ARM (A) UPSIDE DOWN ON A FLAT PROTECTED
SURFACE.
B. ATTACH SEAT (D) TO LEFT ARM (A) WITH FLAT WASHER (G)
AND BOLT (F) USING ALLEN WRENCH (H). DO NOT TIGHTEN
COMPLETELY.
C. PLACE RIGHT ARM (B) UPSIDE DOWN ON A FLAT
PROTECTED SURFACE, ROTATE ASSEMBLY FROM ABOVE
STEP ON TOP OF RIGHT ARM (B) .
D. ATTACH RIGHT ARM (B)TO SEAT (D) WITH FLAT WASHER
(G) AND LONG BOLT (F) USING ALLEN WRENCH (H) . DO NOT
TIGHTEN COMPLETELY.
STEP 2
A. CONNECT BACK (C) TO RIGHT ARM (B) AND LEFT ARM (A)
WITH FLAT WASHER (G) AND SHORT BOLT (E) USING ALLEN
WRENCH (H). DO NOT TIGHTEN COMPLETELY.
B. CONNECT BACK (C) TO SEAT WITH FLAT WASHER (G) AND
LONG BOLT (F) USING ALLEN WRENCH (H). DO NOT TIGHTEN
COMPLETELY.
C. CONNECT BACK (C) TO LEFT ARM (A) WITH FLAT WASHER
(G) AND SHORT BOLT (E) USING ALLEN WRENCH (H). DO NOT
TIGHTEN COMPLETELY.
STEP 3
A. TURN CHAIR TO UPRIGHT POSITION SO THAT IT STANDS
SQUARELY ON THE FLOOR.
B. TIGHTEN ALL BOLTS SECURELY USING ALLEN WRENCH
(H).
C. RETAIN ALLEN WRENCH (H) FOR USE TO TIGHTEN
BOLTS PERIODICALLY OR AS NEEDED.
STEP 4
PUT THE CUSHION ON THE SEAT ,WITH VELCRO TIE ON
THE CHAIR , THEN PUT ON THE BACK CUSHION.
