Phil Jones Bass PJB SUPER FLIGHTCASE User manual

PJB SUPER FLIGHTCASE
OWNER'S MANUAL
Phil Jones Bass

1
Phil Jones Bass
TM
Thank you for purchasing the PJB SUPER FLIGHTCASE. A great deal of
dedication and passion went into designing and building this no
compromise, high performance compact-combo amplifier. It was conceived
to be a dedicated amplifier for the connoisseur bassist. Reading this
manual will enable you to get the best performance from it so that you may
enjoy many years of service.
READ THIS FIRST
!Before using the SUPER FLIGHTCASE please read ALL the
instructions.
!On receipt of product, check for any signs of physical damage arising
from shipping. If any damage is visible contact your dealer.
!Keep all original packing.
!Never use this product in the vicinity of water. If the SUPER
FLIGHTCASE were to get wet, it could kill you by electrocution.
!Do not use this amplifier in a way that would compromise its
ventilation system. When operating, never coverthe heat sink on rear
panel.
!Do not locate this amplifier near any heat source.
!This amplifier must be connected only to a power source specified in
this manual.
!For safety do not leave the amplifier plugged into a power source for
long periods of time when not in use.
!Do not let any liquid or foreign objects fall into any openings on the
amplifier.
!Never use this amplifier if it has:
1. Suffered any physical damage.
2. Been subjected to any liquids, rain or moisture.
3. Damaged cables connected to it.
If any of the above occurs, the amplifier should be examined by
qualified service personnel.
!Always operate this amplifier with the correctly rated fuse. Never use
this amplifier without proper grounding.

2
Phil Jones Bass
TM
OVERVIEW OF THE SUPER FLIGHTCASE
Never has amp existed for a bass player, that is so light, versatile and as high performance as
The SUPER FLIGHTCASE .It is so unique it has two patents applied for. PJB has invested a
massive amount of resources to develop advances in digital amplifiers for bass and string
instruments and ultra powerful lightweight new generation Neodymium loudspeaker units to
bring an amplifier to world of bassists who appreciate high performance yet demand compact
and lightweight amplification.
The six 5 inch proprietary PJB drivers have been acoustically optimally loaded by precise
computer analysis to provide a full-range, dynamic sound that can play down to an open B
and yet give every single harmonic startling definition so the amplifier becomes one with the
player.
This amplifier is designed to be placed on the ground and yet deliver full range sound in great
detail to both players and audience without the need of tilting back or being placed off the
ground, which can rob the amp of low frequency reproduction.
AMPLIFIER FEATURES
!Dedicated Active or Passive input stage.
!5 Band EQ
!Balanced Line Output with ground lift.
!Sophisticated protection circuitry
!250watt RMS Amplifier
!Ultra low noise pre amplifier circuit.

Phil Jones Bass
TM
3
FRONT PANEL OVERVIEW
BACK PANEL OVERVIEW
-18dB-18dB
FX SENDFX SENDINPUTINPUTINPUT LEVELINPUT LEVEL
+10dB+10dB
CLIPCLIP
0
-10dB-10dB
ACTIVEACTIVE
PASSIVEPASSIVE
+18dB+18dB-18dB-18dB
LO-BASSLO-BASS
+18dB+18dB-18dB-18dB
HI-BASSHI-BASS
POWERPOWERLIMITERLIMITERHEADPHONEHEADPHONEFX RETURNFX RETURN
MASTER VOLUMEMASTER VOLUME
TREBLETREBLEHI-MIDHI-MID
-18dB-18dB
LO-MIDLO-MID
+18dB+18dB -18dB-18dB+18dB+18dB
0MAXMAX
ONON
OFFOFF
+18dB+18dB
MINMIN MAXMAX

Phil Jones Bass
TM
4
FRONT PANEL DESCRIPTION
1. INPUT LEVEL SENSITIVITY
2. INSTRUMENT INPUT SOCKET
This is a standard ¼inch mono jack socket.
3. FX SEND SOCKET
Connect the FX send to auxiliary FX unit input.
4. FX RETURN SOCKET
Connect the FX Return to auxiliary FX unit output.
5. HEADPHONE SOCKET (STEREO PHONES)
This jack accepts ¼ inch stereo headphone jacks. When a headphone is connected to the jack,
the speakers will be disconnected and therefore no sound from them.
6. COMPRESSOR THRESHOLD LEVELCONTROL
This will vary the level the limiter threshold. The compression ratio is 3dB to 1. Adjust this to
suit your playing style and output power of your instrument. The blue LED will light up when
the signal is being compressed. This will vary on how hard the instrument is played and how
the threshold is adjusted.
7. POWER INDICATOR.
8. ACITIVE / PASSIVE INPUT SWITCH
This switch allows you to match the SUPER FLIGHTCASE to match either active or passive
basses. PASSIVE - Higher sensitivity, high impedance input (450mV/4.7MÙ). For bass
instruments that do not have active electronics, suited for older 'vintage' basses. This setting
is precisely matched to high impedance pickups enabling them to faithfully reproduce the
true frequency and dynamic range of the instrument.
ACTIVE- Lower sensitivity input setting (1.4V) for basses with onboard electronics. Input
matched for low signal to noise ratio and optimum transfer of electrical signal from modern
high-end basses.
9. LOW BASS EQ CONTROL
This will adjust the fundamental tones of E and A strings on 4 string basses and B E & Aon 5
string basses.
10. HIGH BASS EQ CONTROL
This will adjust the fundamental tones of D and G-strings on 4 &5 string basses.
11. MID RANGE EQ CONTROL
12. LOW TEBLE EQ CONTROL

Phil Jones Bass
TM
5
13. HIGH TREBLE (PRESCENCE) EQ CONTROL
14. LIMITER IN/OUT SWITCH Sends
signal through limiter or bypass.
15. MASTER VOUME CONTROL
This is the master volume control and it controls how much power you send to your speakers
as well as the line out socket on the back of the amp. When setting up your tone or plugging in
your instrument, you should keep this control at a low level. All instruments are different
when it comes to how much output is from the pickups. Likewise for players, depending on
how hard or soft you play.
BACK PANEL DESCRIPTION
1. BALANCED LINE OUT
This is an ultra-low impedance (200Ù) balanced line out for use with recording or PA mixing
consoles. This output is not controlled by the volume control. Changing the level on your
instrument will however, vary the DI output.
2. GROUND LIFT SWITCH
This allows the grounding of balanced out socket to be disconnected. This is useful if you
are experiencing hum caused by grounding loops/problems.
3. LINE OUT
Can be used for driving a second amplifier.
4. TUNER OUT
Connect to instrument tuner. This output can also be used as an additional line out.
5. POWER ON/OFF SWITCH
This switches the main power on and off in the amplifier. When you turn on the power, it will
have about 2 seconds delay to protect the speaker.
Do not leave the amplifier plugged into a power source for long periods of time when not in
use.
6. AC INPUT SOCKET & FUSE.
Connects the amplifier to AC power supply. Always use a grounded plug and make sure the
AC cable is more than 3A rating at 250-volt AC. If you require a longer AC power cord, we
recommend the PJB heavy-duty 20 foot power cords. These are available as an accessory. If
fuse needs replacing, use a slow blow ¾inch fuse rated at 2.5 amps.
7. AC INPUT -VOLTAGE SELECTOR.
Switches the amplifier to run on either 110-120 volt or 220-240 volt AC power. Never try to
run the amplifier on a 220-240 volt supply when switched to 110-120 volt. This can
possibly cause major damage to the amplifier.

Phil Jones Bass
TM
6
OPERATION & POSITIONING
TURN THE VOLUME DOWN on the SUPER FLIGHTCASE before plugging in your
instrument.
Positioning the SUPER FLIGHTCASE for Best Sound
Often, playing in different venues will cause your bass to sound different. This is partially
due to the acoustics of the hall influencing the low frequency waves that are coming from
your speaker. Bass waves are large and room dimensions heavily influence them when the
walls reflect the sound waves, causing them to collide by adding together or canceling each
other out. This causes some fundamental notes (the ones you feel more than hear) to ring out
louder than others and some notes not to be heard at all.
Here is an indication of where fundamental bass frequencies are, showing open string's
approximate frequencies and acoustic wavelength:
This may give you some indication of the offending notes (frequencies) that may be booming or
resonating louder or quieter than others. For example if your speakers are five feet from a wall,
the open A string may sound weak. That could be because the path length of the reflected sound
off the wall from your speaker is exactly corresponding to half a wavelength on the open Astring
causing at that particular note to cancel out.
Where you position the SUPER FLIGHTCASE will ultimately affect your low frequency
limit. For best results keep the SUPER FLIGHTCASE on the floor. Placing it on objects off
the floor will cause it to sound thin and lack bass punch. Placing the SUPER FLIGHTCASE
with the back close to a wall will help reinforce the lower notes. Placing it in a room corner
will further enhance the low notes.
Room size makes a large difference in how deep the bass will sound. The further the distance
to the listener the less the bass will be. This is due to the physics of acoustics not the unit
itself.
Unfortunately for bass players, low frequencies are always very difficult to control with
room acoustics. The reproduced wavelengths of the notes you are playing often correspond
to the room dimensions, in which case the reflected sound off the walls interferes with the
sound from the speaker as you get further away from it.
F# string 24Hz 46feet
B string 31Hz 36feet
E string 41Hz 27feet
A string 55Hz 20feet
D string 73Hz 15feet
G string 98Hz 11feet
C string 130Hz 9feet

Phil Jones Bass
TM
7
Setting Up the Limiter
Although a limiter is not essential to bass amplification, it can be a useful tool in smoothing
out the character of your instrument or playing style. The SUPER FLIGHTCASE limiter has
a preset compression ratio of 3 to 1. For each additional increase of 3dB above the set
threshold, the increase in level is actually 1dB. So the dynamic range of your instrument is
reduced.
First set up the limiter by having the compression control (6) set fully clockwise. Now switch
on the limiter (14). Start playing and turn control (6) counter-clockwise. You will see the
blue light start to come on and that is the indication that the limiter is now working. Set this
control to suit your taste.
TRANSPORTING AND STORING THE SUPER FLIGHTCASE
When transporting in a vehicle, it is recommended that you use an external case or heavy-
duty cover to prevent it being damaged by falling over or other objects falling on it.
When Storing:
!Keep in a dry location preferably at room temperature.
!Do not store in temperatures below -20 Degrees C or above 40 Degrees C.
!Do not allow it to get wet. If this occurs, never turn it on in this condition.
!Do not leave the SUPER FLIGHTCASE permanently connected to a power source.

Phil Jones Bass
TM
8
SPECIFICATIONS
Speaker
Computer Optimized Vented Enclosure
Speaker Frequency Response: 40Hz - 15KHz
Speaker Compliment: 6 x 5inch proprietary, extended-range drivers
Speaker Sensitivity: 94dB/W/M
Internal Speaker Impedance: 6 Ohm
Dimensions: 12.6” W x 20.5” H x 15.75”D
Weight: 33 lbs.
Amplifier
PJB 250watt, class A/B amplifier with digital switch mode power supply.
Frequency Response
Passive and Active input: 40Hz -120KHz
Low Cut Filter: 24dB/Octave at 40Hz.
Maximum Output Power
250 watt RMS
Signal to Noise Ratio
Better than 98 dB (EQ off, Volume on Full.)
Impedance
Passive Input: >4MÙ/22pF
Active Input: >100KÙ/22pF Line
Input: >75KÙ
Pre Amp Line Out: < 2KÙ
Bal. Out: <200Ù
Levels
Passive Input: 10mV-2.5V
Active Input: 20mV-5V
Pre Amp Out: 1.2V
FX send: 1V
Bal. Line Out: Typical 600mV
Compressor / Limiter
Gain: 0dB
Compression Ratio: 3dB: 1dB
EQ CENTER FREQUENCIES
50, 160, 630, 2.5K, 12K at +/- 18dB
Included Parts
12 ft AC Power Cord
Allen Key

Phil Jones Bass
TM
9

Phil Jones Bass
TM
10
SERVICE/WARRANTY INFORMATION
The SUPER FLIGHTCASE has a warranty period of 2 years, starting from the date of
purchase. The buyer must complete and return the enclosed warranty card within 14
days of purchase.
This warranty covers defect in materials or workmanship that occurs in normal use. Within
warranty period PJB will repair or replace the defect unit free of labor and parts charge. It is
the buyer's responsibility to use the unit strictly according to instructions written in this
manual and amplifier manual.
This warranty is not transferable; it is provided to original owner only. Damage/defects
caused by the following conditions are not covered by this warranty:
!Improper handling, neglect or failure to operate the unit in compliance with the
instructions given in user manual;
!Connection or operation of the speakers in any way that does not comply with the
technical or safely regulations applicable in the country where the product is used;
!Repairs or modifications by anyone other than authorized PJB service agent;
!Damages/defects caused by force majeure or any other condition that is beyond the
control of PJB.
Should you need any warranty service, please bring the SUPER FLIGHTCASE back to the
dealer from whom you purchased, along with your sales receipt. Depending on the
complexity of the repair work, your dealer may return the defect unit to PJB service center for
repair or replacement.
Phil Jones Bass
American Acoustic Development LLC
8559 Page Avenue St. Louis, MO 63114 USA
Phone: [phone]
Fax: [phone]
Phil Jones Bass is a division of American Acoustic Development LLC.
www.philjonesbass.com
[email protected]
www.aadsound.com

American Acoustic Development LLC
8559 Page Avenue St. Louis, MO 63114 USA
Phone: [phone]
Fax: [phone]
