Philco DJ-NX6112 User manual
DJ MIXER ROCKY PARTY SYSTEM
DJ-NX6112
Caution: Read this before operating your unit.
1To assure the finest performance, please read this manual
carefully. Keep it in a safe place for future reference.
2Install this sound system in a well ventilated, cool, dry,
clean place - away from direct sunlight, heat sources,
vibration, dust, moisture, and/or cold. For proper
ventilation, allow the following minimum clearances
around this unit.
Top: 10 cm (4 in)
Rear: 10 cm (4 in)
Sides: 10 cm (4 in)
3Locate this unit away from other electrical appliances,
motors, or transformers to avoid humming sounds.
4Do not expose this unit to sudden temperature changes
from cold to hot, and do not locate this unit in an
environment with high humidity (i.e. a room with a
humidifier) to prevent condensation inside this unit,
which may cause an electrical shock, fire, damage to this
unit, and/or personal injury.
5Avoid installing this unit where foreign object may fall
onto this unit and/or this unit may be exposed to liquid
dripping or splashing. On the top of this unit, do not
place:
Other components, as they may cause damage and/or
discoloration on the surface of this unit.
Burning objects (i.e. candles), as they may cause fire,
damage to this unit, and/or personal injury.
Containers with liquid in them, as they may fall and
liquid may cause electrical shock to the user and/or
damage to this unit.
6Do not cover this unit with a newspaper, tablecloth,
curtain, etc. in order not to obstruct heat radiation. If the
temperature inside this unit rises, it may cause fire,
damage to this unit, and/or personal injury.
7Do not plug in this unit to a wall outlet until all
connections are complete.
8Do not operate this unit upside-down. It may overheat,
possibly causing damage.
9Do not use force on switches, knobs and/or cords.
10 When disconnecting the power cable from the wall outlet,
grasp the plug; do not pull the cable.
11 Do not clean this unit with chemical solvents; this might
damage the finish. Use a clean, dry cloth.
12 Only voltage specified on this unit must be used. Using
this unit with a higher voltage than specified is dangerous
and may cause fire, damage to this unit, and/or personal
injury. We will not be held responsible for any damage
resulting from use of this unit with a voltage other than
specified.
13 To prevent damage by lightning, keep the power cable
and outdoor antennas disconnected from a wall outlet or
this unit during a lightning storm.
14 Do not attempt to modify or fix this unit. Contact
Qualified service personnel when any service is needed.
The cabinet should never be opened for any reasons .
15 When not planning to use this unit for long periods of
time (i.e. vacation), disconnect the AC power plug from
the wall outlet.
16 Be sure to read the TROUBLESHOOTING section on
common operating errors before concluding that this unit
is faulty.
17 Before moving this unit,d isconnect the AC power plug
from the wall outlet.
18 Condensation will form when the surrounding
temperature changes suddenly. Disconnect the power
cable from the outlet, then leave this unit alone.
19 When using this unit for a long time, this unit may
become warm. Turn the power off, then leave this unit
alone for cooling.
20 Install this unit near the AC outlet and where the AC
power plug can be reached easily.
21 The batteries shall not be exposed to excessive heat
such as sunshine, fire or the like. When you dispose of
batteries, follow your regional regulations.
22 Excessive sound pressure from earphones and
headphones can cause hearing loss.
2
3
REAR PANEL
1. POWER
Three switches: AC , OFF, DC.
When switch to "AC", AC INPUT ON, the speaker is working and Battery can be
charged. If in standby mode, the battery can be charged also.
When switch to "OFF", AC and DC Power off, the speaker cant work under this status.
When switch to "DC", Battery ON/DC 12V ON mode, the speaker can work under the
Battery supply, no need AC INPUT
2. DC 12V INPUT
When you take the speaker outside, Battery level is low or run out, after switch to
"DC", you can connect your cars 12V battery to this DC 12V IN, so the speaker can work
normally
3. FM ANTENNA
4. AC INPUT
AC 230V~, 50Hz
4
1. LED DISPLAY
Display System parameter information, a half of
the left side display the INPUT A status, another
half of left side display the INPUT B status
2. VOLUME/MULTI
Rotate the knob to adjust the main volume ,
phones volume,treble, bass. Short press this key
to choose different music effect SCRATCH,
REVERB, BEAT BOX, YEAH, BRING IT, GEYA,
COME ON.
Long press play DRUMS effect.
3. PHONES MODE
Press this key to choose different EARPHONES
mode, INPUT A, INPUT B, INPUT AB
4. INPUT B PREV
Press this key to choose previous music with
USB B
5. INPUT B NEXT
Press this key to choose next music with INPUT B
6. INPUT B VOLUME
This is used to adjust the volume with INPUT B
7. INPUT B PAUSE
Press this key to choose play/pause music
with INPUT B
8. INPUT B MODE
Press this key to choose different INPUT B mode,
LINE,USB B
9. EARPHONES INPUT JACK
10. USB B input jack
11. GUITAR VOLUME
Adjust the volume of the GUITAR input
12. MIC VOLUME
Adjust the volume of the MICROPHONE input
13. ECHO
Adjust the ECHO depth of the MIC input
14. GUITAR jack
15. MIC jack
16. LlNE IN AUDIO INPUT JACK
Connect to LINE IN signal input jack.
17. CHARGING INDICATOR
When the battery is low 9V, the red light
When charging, the green light
18. AUX AUDIO INPUT JACK
Connect to AUX signal input jack.
19. USB A input jack
20. AC:CHARGE/STANDBY/NORMAL
A long Press on this key turns on or standby the unit.
A short Press on this key turns on the unit to
CHARGE,STANDBY,NORMAL mode
DC:BAT LEVEL
A Press on this key shows the current battery level.
21. INPUT A MODE
Press this key to choose different INPUT A mode,
AUX A, BT-A, FM, USB A
22. INPUT A PAUSE
Press this key to choose play/pause music with
INPUT A
23. INPUT A VOLUME
This is used to adjust the volume with INPUT A
24. INPUT A NEXT
Press this key to choose next music with INPUT A
25. INPUT A PREV
Press this key to choose previous music with INPUT A
26. MENU
This switch selects the main volume, bass, treble,
x driver, light mode
FRONT PANEL
CHARGING
C:CHARGE/STANDBY/NORMALC:CHARGE/STANDBY/NORMALC:CHARGE/STANDBY/NORMALC:CHARGE/STANDBY/NORMALC:CHARGE/STANDBY/NORMALC:CHARGE/STANDBY/NORMALC:CHARGE/STANDBY/NORMALC:CHARGE/STANDBY/NORMALAA
REMOTE CONTROL
If the remote control with other devices,the operation will be affected.conflicts
Do not simultaneously press buttons on the unit and the remote control.
Avoid using two remote controls at the same time as this wiII cause a malfunction.
Use only UM-4 ``AAA`` size batteries. Do not mix old batteries with new ones.
If the batteries Ieak, clean thoroughly before replacing with new ones.
Do not short two terminals of the batteries. Dispose of old batteries in a suitable place.
REMOTE CONTROL OPERATION:
1. LIGHT
2. STANDBY
3. NUMBER BUTTON
4. TUNING-
5. CHANNEL-
6. VOLUME+
7. X DRIVE
8. TREBLE+
9. VOLUME-
10. TREBLE-
11. AUX-A
12. USB-A
13. USB-A F.WARD
14. USB-A B.WARD
15. LINE
16. USB-B
17. USB-B F.WARD
18. USB-B B.WARD
19. MUTE
20. FM
21. AUTO
22. TUNING+
23. CHANNEL+
24. BT
25. DISCONNECT
26. BASS+
27. BASS-
28. INPUT-A REPEAT
29. PAUSEINPUT-A
30. PREVIOUSINPUT-A
31. NEXTINPUT-A
32. INPUT-B REPEAT
33. PAUSEINPUT-B
34. PREVIOUSINPUT-B
35. NEXTINPUT-B
5
OPERATING
NORMAL FUNCTION
1. Be sure to switch off the power and to connect to corresponding input jacks.
2. Turn on the power and wait 3-4 seconds until the speaker functions are connected.
3. Select an audio source by pressing the INPUT A key on the front panel to display AUX A, BT-A,
FM, USB A. Press the INPUT B key on the front panel to display LINE,USB B.
4. Adjust the VOLUME/MULTI knob on the front panel or the VOL+/- key on the remote control to
adjust the setting of the main volume, . Then turn the left push shot to adjust the treble, bass
volume of INPUT A, turn the right push shot to change the volume of the INPUT B.
5. Press the MENU key on the front panel to display BASS, TREBLE, XDRIVE,AUTO, MAIN then
adjust the VOLUME knob to change music treble,bass,light mode and sound effect.
6. PHONES OUTPUT selection. Press the PHONES MODEL button on the front panel to display
INPUT A, INPUT B, or INPUT AB.
PHONES VOLUME adjustment. Press the PHONES MODEL button on the front panel to display
INPUT A or INPUT B or INPUT AB, then rotate the VOLUME/MULTI knob to adjust the PHONES
VOLUME of INPUT A or INPUT B or INPUT AB
7. Press the LIGHT button on the remote control or press the MENU button on the front panel to
display light mode,then press the VOLUME/MULTI knob to change the OFF,R,G,B,RG,RB,GB,
RGB, AUTO,DEMO light mode.
8. Press the MUTE key to mute, press it again to reset.
Press X DRIVE on the remote to turn on/off X-Bass effect.
LIGHT COLOR CONTROL FUNCTION
To control the light mode coming from the speaker panels by "Speaker" menu or "light model"
button on remote control
R = red lights flash●
G = green lights flash●
B = blue lights flash●
RG = red and green lights flash●
RB = red and blue lights flash●
GB = green and blue lights flash●
RGB = red, green, and blue lights flash●
Auto = the various color combinations cycle through and flash.●
Demo = lights flash and change color as if they were responding to the beat of the music.●
TUNER APPLICATIONS
1. Before using the radio functions, you must attach the supplied antenna. Adjust the antenna to
obtain optimum reception.
Press the INPUT A key on the front panel(amplifier)or the FM key on the remote control,to select
Fm function.
2. Press the CH+/CH- key on the remote control to find radio bands that you have previously saved .
3. Press or hold the TU+/TU- key on the remote control to adjust the radio frequency manually.
4. Press the AUTO key on the remote control, the machine will scan radio channels from
low-frequency to high-frequency by itself and memorize the channels one by one.
6
KARAOKE & GUITAR FUNCTION
1. The machine can auto detect whether MIC or GUITAR is inserted.
Please turn off the microphone volume and adjust the volume gradually after inserting the
microphone.
2. Press VOL+/- on the remote or a to change the djust the MIC.VOL knob on the front panel
microphone VOLUME.
3. A to change the microphone ECHO.djust the ECHO knob on the front panel
4. A to change the guitar VOLUME.djust the GUITAR.VOL knob on the front panel
Note: Do not touch the top of the microphone when singing in order to avoid howling effect.
Adjust the microphone volume gradually to avoid howling effect.
BLUETOOTH PAIR AND CONNECT
Turn off any Bluetooth devices previously paired (linked) with this unit.●
Turn on the Bluetooth features on your phone or music player.●
Turn on and set this unit to Bluetooth mode. The flashing blue light BT on LED display ●
indicates it is in pairing mode.
Set your phone or music player to search for Bluetooth devices.●
Select from search results on your phone or music player.●DJ-NX6112
Select OK or YES to pair this unit with your phone or music player.●
If protected, enter 0000 for passkey steady blue light indicates successful ●
connection.
Press the DISCONNECT key on the remote to disconnect the bluetooth.●
FUNCTION OF USB READER
This unit has two USB jacks. Press the INPUT A key to select USB A,then you can insert a USB
to play music.Press the INPUT B key to select USB B,then you can insert the another USB to play
music.
Important: The USB port is intended only for data transfer only, other devices cannot be used
with this USB connection. The use of USB extension cords is not recommended.
IN ORDER TO PROTECT THE BATTERY
1. When the battery is powered mode, standby operation is invalid.
2. When the battery is low, the system prompts "LOW POWER",POWER lamp blinks.
3. When the battery is serious shortage,the system prompts "NO POWER", POWER lamp
blinks .
After 1 minutes, the system to stop.
And the control panel has a red lamp,when the battery is enough ,the lamp is normally
turn on .
When the low battery ,the red lamp blinks.
BATTERY DISASSEMBLY
1. Remove the screws on the rear panel.
2. Take out the battery.
3. Disconnect
7
OPERATING
123
SPECIFICATION
Frequency Response -------------------------------------------------------------- 20Hz-20KHz
Power Source ----------------------------------------------------------------------- 230V~,50Hz
Power Consumption ------------------------------------------------------------------------ 120W
Remote control ---------------------------------------------------------------------------------------- 1 pc
Manual ------------------------------------------------------------------------------------ 1 pcInstruction
8
ACCESSORIES
Table of contents
