Philips BDP3000 User manual

BDP3000
©Copyright 2009 Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise without
the prior permission of Philips.
Published by SL 0924 Service Audio Printed in The Netherlands Subject to modification
Blu-ray Disc Player
Version 1.0
CLASS 1
LASER PRODUCT
©
TABLE OF CONTENTS
Page
Technical Specifi
cations .......................................................1-2
Safety Instruction, Warning & Notes.....................................1-3
QSG & DFU Instruction ........................................................... 2
Mechanical and Dismantling Instructions ................................ 3
Software Version & Upgrades, Region Code Change............. 4
Trouble Shooting Chart ........................................................... 5
Set Wiring Diagram ................................................................. 6
Electrical Diagrams and PCB layouts...................................... 7
Set Mechanical Exploded view & Parts List ............................ 8
Revision List ............................................................................ 9
/55/78/93/98/94/96
3141 785 34180

Quick start guide
•
User manual•
CD-ROM built in multi-lingual user manual•
(not availabe for UK version)
Video
Signal system: PAL / NTSC•
Composite video output: 1 Vp-p (75 ohm)•
Component video output: 480/576i, 480/576p,•
720p, 1080i
Y: 1 Vp-p (75 ohm)•
Pb: 0.7 V-pp (75 ohm)•
Pr: 0.7 V-pp (75 ohm)•
HDMI output 480p, 576p, 720p, 1080i, 1080p,•
1080p24
Audio
2 Channel analog output•
Audio Front L&R : 2 Vrms (> 1 kohm)•
Digital output: 0.5 Vp-p (75 ohm)•
Coaxial•
HDMI output•
Sampling frequency:•
MP3: 32 kHz, 44.1 kHz, 48 kHz•
WMA: 44.1 kHz, 48 kHz•
Constant bit rate:•
MP3: 112 kbps - 320 kpbs•
WMA: 48 kpbs - 192 kpbs•
USB
As additional memory for software updates•
and BD-Live bonus contents. Not for media
play.
Main unit
Power supply rating•
Europe: 220~240V ~AC, ~50 Hz•
Russia: 220~230V ~AC, ~50 Hz•
Asia Pacific: 110~240V ~AC, 50~60 Hz•
Latin America: 110~240V ~AC, 50~60•
Hz
China: 110~240V ~AC, ~50 Hz•
Power consumption: 25W•
Power consumption in standby mode: 1W•
Dimensions (w x h x d): 435 x 58 x 227 (mm)•
Net Weight: 2.5 kg•
Laser Specification
Laser Type:•
BD Laser Diode: InGaN/AIGaN•
DVD Laser Diode: InGaAIP•
CD Laser Diode: A IGaAs•
Wave length:•
BD: 405 +5nm/-5nm•
DVD: 650 +13nm/-10nm•
CD: 790 +15nm/-15nm•
Specifications
Note
Specification and design are subject to change without
•
notice
Play media
BD-Video, DVD-Video, DVD+R/+RW, DVD-R/-
RW, DVD+R/-R DL, CD-R/CD-RW, Audio CD,
Video CD/SVCD, Picture CD, MP3-CD, WMA-CD,
DivX (Ultra)-CD.
Accessories supplied
Remote control and batteries•
Audio/Video cables•
Power cable•
for BDP3000/55
1-2

USB
As additional memory for software updates•
and BD-Live bonus contents. Not for media
play.
Main unit
Power supply rating•
Europe: 220~240V ~AC, ~50 Hz•
Russia: 220~230V ~AC, ~50 Hz•
Asia Pacific: 110~240V ~AC, 50~60 Hz•
Latin America: 110~240V ~AC, 50~60•
Hz
China: 110~240V ~AC, ~50 Hz•
Power consumption: 25W•
Power consumption in standby mode: 1W•
Dimensions (w x h x d): 435 x 58 x 227 (mm)•
Net Weight: 2.5 kg•
Laser Specification
Laser Type:•
BD Laser Diode: InGaN/AIGaN•
DVD Laser Diode: InGaAIP•
CD Laser Diode: A IGaAs•
Wave length:•
BD: 405 +5nm/-5nm•
DVD: 650 +13nm/-10nm•
CD: 790 +15nm/-15nm•
Output power:•
BD: Max. ratings: 20mW•
DVD: Max. ratings: 7mW•
CD: Max. ratings: 7mW•
Specifications
Note
Specification and design are subject to change without
•
notice
Play media
BD-Video, DVD-Video, DVD+R/+RW, DVD-R/-
RW, DVD+R/-R DL, CD-R/CD-RW, Audio CD,
Video CD/SVCD, Picture CD, MP3-CD, WMA-CD,
DivX (Ultra)-CD.
Accessories supplied
Remote control and batteries•
Audio/Video cables•
Power cable•
Quick start guide•
User manual•
Video
Signal system: PAL / NTSC•
Composite video output: 1 Vp-p (75 ohm)•
Component video output: 480/576i, 480/576p,•
720p, 1080i
Y: 1 Vp-p (75 ohm)•
Pb: 0.7 V-pp (75 ohm)•
Pr: 0.7 V-pp (75 ohm)•
HDMI output 480p, 576p, 720p, 1080i, 1080p,•
1080p24
Audio
2 Channel analog output•
Audio Front L&R : 2 Vrms (> 1 kohm)•
Digital output: 0.5 Vp-p (75 ohm)•
Coaxial•
HDMI output•
Sampling frequency:•
MP3: 32 kHz, 44.1 kHz, 48 kHz•
WMA: 44.1 kHz, 48 kHz•
Constant bit rate:•
MP3: 112 kbps - 320 kpbs•
WMA: 48 kpbs - 192 kpbs•
%'3BB80LQGE6HF
1-2
for BDP3000/93

USB
As additional memory for software updates•
and BD-Live bonus contents. Not for media
play.
Main unit
Power supply rating•
Europe: 220~240V ~AC, ~50 Hz•
Russia: 220~230V ~AC, ~50 Hz•
Asia Pacific: 110~240V ~AC, 50~60 Hz•
Latin America: 110~240V ~AC, 50~60•
Hz
China: 110~240V ~AC, ~50 Hz•
Power consumption: 25W•
Power consumption in standby mode: 1W•
Dimensions (w x h x d): 435 x 58 x 227 (mm)•
Net Weight: 2.5 kg•
Laser Specification
Laser Type:•
BD Laser Diode: InGaN/AIGaN•
DVD Laser Diode: InGaAIP•
CD Laser Diode: A IGaAs•
Wave length:•
BD: 405 +5nm/-5nm•
DVD: 650 +13nm/-10nm•
CD: 790 +15nm/-15nm•
Output power:•
BD: Max. ratings: 20mW•
DVD: Max. ratings: 7mW•
CD: Max. ratings: 7mW•
Specifications
Note
Specification and design are subject to change without
•
notice
Play media
BD-Video, DVD-Video, DVD+R/+RW, DVD-R/-
RW, DVD+R/-R DL, CD-R/CD-RW, Audio CD,
Video CD/SVCD, Picture CD, MP3-CD, WMA-CD,
DivX (Ultra)-CD.
Accessories supplied
Remote control and batteries•
Audio/Video cables•
Power cable•
Quick start guide•
User manual•
Video
Signal system: PAL / NTSC•
Composite video output: 1 Vp-p (75 ohm)•
Component video output: 480/576i, 480/576p,•
720p, 1080i
Y: 1 Vp-p (75 ohm)•
Pb: 0.7 V-pp (75 ohm)•
Pr: 0.7 V-pp (75 ohm)•
HDMI output 480p, 576p, 720p, 1080i, 1080p,•
1080p24
Audio
2 Channel analog output•
Audio Front L&R : 2 Vrms (> 1 kohm)•
Digital output: 0.5 Vp-p (75 ohm)•
Coaxial•
HDMI output•
Sampling frequency:•
MP3: 32 kHz, 44.1 kHz, 48 kHz•
WMA: 44.1 kHz, 48 kHz•
Constant bit rate:•
MP3: 112 kbps - 320 kpbs•
WMA: 48 kpbs - 192 kpbs•
1-2
for BDP3000/98/94

Laser Specification
Laser Type:•
BD Laser Diode: InGaN/AIGaN•
DVD Laser Diode: InGaAIP•
CD Laser Diode: A IGaAs•
Wave length:•
BD: 405 +5nm/-5nm•
DVD: 650 +13nm/-10nm•
CD: 790 +15nm/-15nm•
Output power:•
BD: Max. ratings: 20mW•
DVD: Max. ratings: 7mW•
CD: Max. ratings: 7mW•
Specifications
Note
Specification and design are subject to change without
•
notice
Play media
BD-Video, DVD-Video, DVD+R/+RW, DVD-R/-
RW, DVD+R/-R DL, CD-R/CD-RW, Audio CD,
Video CD/SVCD, Picture CD, MP3-CD, WMA-CD,
DivX (Ultra)-CD.
Accessories supplied
Remote control and batteries•
Audio/Video cables•
Power cable•
Quick start guide•
User manual•
Video
Signal system: PAL / NTSC•
Composite video output: 1 Vp-p (75 ohm)•
Component video output: 480/576i, 480/576p,•
720p, 1080i
Y: 1 Vp-p (75 ohm)•
Pb: 0.7 V-pp (75 ohm)•
Pr: 0.7 V-pp (75 ohm)•
HDMI output 480p, 576p, 720p, 1080i, 1080p,•
1080p24
Audio
2 Channel analog output•
Audio Front L&R : 2 Vrms (> 1 kohm)•
Digital output: 0.5 Vp-p (75 ohm)•
Coaxial•
HDMI output•
Sampling frequency:•
MP3: 32 kHz, 44.1 kHz, 48 kHz•
WMA: 44.1 kHz, 48 kHz•
Constant bit rate:•
MP3: 112 kbps - 320 kpbs•
WMA: 48 kpbs - 192 kpbs•
USB
As additional memory for software updates•
and BD-Live bonus contents. Not for media
play.
Main unit
Power supply rating•
Europe: 220~240V ~AC, ~50 Hz•
Russia: 220~230V ~AC, ~50 Hz•
Asia Pacific: 110~240V ~AC, 50~60 Hz•
Latin America: 110~240V ~AC, 50~60•
Hz
China: 110~240V ~AC, ~50 Hz•
Power consumption: 25W•
Power consumption in standby mode: 1W•
Dimensions (w x h x d): 435 x 58 x 227 (mm)•
Net Weight: 2.5 kg•
1-2
for BDP3000/96

Safety instruction
1. General safety
Safety regulations require that during a repair:
. Connect the unit to the mains via an isolation transformer.
. Replace safety components indicated by the symbol ,
only by components identical to the original ones. Any
other component substitution (other than original type)
may increase risk of fire or electrical shock hazard.
Safety regulations require that after a repair, you must
return the unit in its original condition. Pay, in particular,
attention to the following points:
. Route the wires/cables correctly, and fix them with the
mounted cable clamps.
. Check the insulation of the mains lead for external
damage.
. Check the electrical DC resistance between the mains
plug and the secondary side:
1) Unplug the mains cord, and connect a wire between
the two pins of the mains plug.
2) Set the mains switch the “on” position (keep the
mains cord unplug).
3) Measure the resistance value between the mains
plug and the front panel, controls, and chassis
bottom.
4) Repair or correct unit when the resistance
measurement is less than 1M
¡
.
5) Verify this, before you return the unit to the
customer/user (ref. UL-standard no. 1492).
6) Switch the unit “off”, and remove the wire between
the two pins of the mains plug.
2.Laser safety
This unit employs a laser. Only qualified service personnel
may remove the cover, or attempt to service this device
(due to possible eye injury).
Laser device unit
Type :SemiconductorlaserGaAlAs
Wavelength : 650nm (DVD)
: 780nm (VCD/CD)
Output power : 7mW (DVD)
:10mW(DVD/CD)
Beam divergence: 60 degree
Note: Use of controls or adjustments or performance of
procedure other than those specified herein, may result in
hazardous radiation exposure. Avoid direct exposure to
beam.
Safet
y
instruction, Warnin
g
& Notes
1-3

Warning
1.General
. All ICs and many other semiconductors are susceptible to
electrostatic discharges (ESD). Careless handing during
repair can reduce life drastically. Make sure that, during
repair, you are at the same potential as the mass of the
set by a wristband with resistance. Keep components and
tools at this same potential. Available ESD protection
equipment:
1) Complete kit ESD3 (small tablemat, wristband,
connection box, extension cable and earth cable)
4822 310 10671.
2) Wristband tester 4822 344 13999.
. Be careful during measurements in the live voltage
section. The primary side of the power supply , including
the heat sink, carries live mains voltage when you
connect the player to the mains (even when the player is
“off”!). It is possible to touch copper tracks and/or
components in this unshielded primary area, when you
service the player. Service personnel must take
precautions to prevent touching this area or components
in this area. A “lighting stroke” and a stripe-marked
printing on the printed wiring board, indicate the primary
side of the power supply.
. Never replace modules, or components, while the unit is
“on”.
2. Laser
. The use of optical instruments with this product, will
increase eye hazard.
. Only qualified service personnel may remove the cover
or attempt to service this device, due to possible eye
injury.
. Repair handing should take place as much as possible
with a disc loaded inside the player.
. Text below is placed inside the unit, on the laser cover
shield:
Notes: Manufactured under licence from Dolby
Laboratories. The double-D symbol is trademarks of Dolby
Laboratories, Inc. All rights reserved.
CAUTION: VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN, AVOID EXPOSURE
TO BEAM.
1-4

Lead-Free requirement for service
INDENTIFICATION:
Regardless of special logo (not always indicated)
One must treat all sets from 1.1.2005 onwards, according
next rules.
Important note: In fact also products a little older can also
be treated in this way as long as you avoid mixing
solder-alloys (leaded/ lead-free). So best to always use
SAC305 and the higher temperatures belong to this.
Due to lead-free technology some rules have to be
respected by the workshop during a repair:
xUse only lead-free solder alloy Philips SAC305 with
order code 0622 149 00106. If lead-free solder-paste is
required, please contact the manufacturer of your
solder-equipment. In general use of solder-paste within
workshops should be avoided because paste is not easy
to store and to handle.
xUse only adequate solder tools applicable for lead-free
solder alloy. The solder tool must be able
oTo reach at least a solder-temperature of 400°C,
oTo stabilize the adjusted temperature at the
solder-tip
oTo exchange solder-tips for different applications.
xAdjust your solder tool so that a temperature around
360°C – 380°C is reached and stabilized at the solder
joint. Heating-time of the solder-joint should not exceed
~ 4 sec. Avoid temperatures above 400°C otherwise
wear-out of tips will rise drastically and flux-fluid will be
destroyed. To avoid wear-out of tips switch off un-used
equipment, or reduce heat.
xMix of lead-free solder alloy / parts with leaded solder
alloy / parts is possible but PHILIPS recommends
strongly to avoid mixed
solder alloy types (leaded and lead-free). If one cannot
avoid, clean carefully the
solder-joint from old solder alloy and re-solder with new
solder alloy (SAC305).
xUse only original spare-parts listed in the
Service-Manuals. Not listed standard-material
(commodities) has to be purchased at external
companies.
xSpecial information for BGA-ICs:
- always use the 12nc-recognizable soldering
temperature profile of the specific BGA (for
de-soldering always use highest lead-free
temperature profile, in case of doubt)
- lead free BGA-ICs will be delivered in so-called
‘dry-packaging’ (sealed pack including a silica gel
pack) to protect the IC against moisture. After
opening, dependent of MSL-level seen on
indicator-label in the bag, the BGA-IC possibly
still has to be baked dry. This will be
communicated via AYS-website.
Do not re-use BGAs at all.
xFor sets produced before 1.1.2005, containing
leaded soldering-tin and components, all needed
spare-parts will be available till the end of the
service-period. For repair of such sets nothing
changes.
xOn our website:
www.atyourservice.ce.Philips.com
You find more information to:
BGA-de-/soldering (+ baking instructions)
Heating-profiles of BGAs and other ICs used in
Philips-sets
You will find this and more technical information
within the “magazine”, chapter “workshop news”.
For additional questions please contact your local
repair-helpdesk.
Notes
1-5

BDP3000
www.philips.com/welcome
© 2009 Koninklijke Philips Electronics N.V.
All rights reserved
Settings
HDMI
BDP3000_55_QSG_V1.0_923
2-1
The following excerpt of the Quick Start Guide serves as an introduction to the set.
The complete Direction For Use can be download in different languages from
Philips Customer Contact & Support site: www.p4c.philips.com
QSG for BDP3000/55:

Video Setup
Advanced Setup
Audio Setup
Preference Setup
EasyLink Setup
Menu Language
Parental Control
Screen Saver
Display Panel
Auto Standby
VCD PBC
Change Password
English
Off
Off
Normal
On
On
Video Setup
Advanced Setup
Audio Setup
Preference Setup
EasyLink Setup
Menu Language
Parental Control
Screen Saver
Display Panel
Auto Standby
VCD PBC
Change Password
HDMI
Y PBPR& AV OUTPUT L/R
VIDEO & AV OUTPUT L/R
2-2

BDP300
0
© 2009 Koninklijke Philips Electronics N.V.
All rights reserved
www.philips.com/welcome
Settings
2-1
The following excerpt of the Quick Start Guide serves as an introduction to the set.
The complete Direction For Use can be download in different languages from
Philips Customer Contact & Support site: www.p4c.philips.com
QSG for BDP3000/93:

Video Setup
Advanced Setup
Audio Setup
Preference Setup
EasyLink Setup
Menu Language
Parental Control
Screen Saver
Display Panel
Auto Standby
VCD PBC
Change Password
English
Off
Off
Normal
On
On
Menu Language
Parental Control
Screen Saver
Display Panel
Auto Standby
VCD PBC
Change Password
HDMI
Y PBPR& AV OUTPUT L/R
VIDEO & AV OUTPUT L/R
2-2

BDP300
0
© 2009 Koninklijke Philips Electronics N.V.
All rights reserved
www.philips.com/welcome
Settings
2-1
The following excerpt of the Quick Start Guide serves as an introduction to the set.
The complete Direction For Use can be download in different languages from
Philips Customer Contact & Support site: www.p4c.philips.com
QSG for BDP3000/98/94:

Video Setup
Advanced Setup
Audio Setup
Preference Setup
EasyLink Setup
Menu Language
Parental Control
Screen Saver
Display Panel
Auto Standby
VCD PBC
Change Password
English
Off
Off
Normal
On
On
Menu Language
Parental Control
Screen Saver
Display Panel
Auto Standby
VCD PBC
Change Password
HDMI
Y PBPR& AV OUTPUT L/R
VIDEO & AV OUTPUT L/R
2-2

BDP300
0
© 2009 Koninklijke Philips Electronics N.V.
All rights reserved
www.philips.com/welcome
Settings
2-1
The following excerpt of the Quick Start Guide serves as an introduction to the set.
The complete Direction For Use can be download in different languages from
Philips Customer Contact & Support site: www.p4c.philips.com
QSG for BDP3000/96:

Video Setup
Advanced Setup
Audio Setup
Preference Setup
EasyLink Setup
Menu Language
Parental Control
Screen Saver
Display Panel
Auto Standby
VCD PBC
Change Password
English
Off
Off
Normal
On
On
Menu Language
Parental Control
Screen Saver
Display Panel
Auto Standby
VCD PBC
Change Password
HDMI
Y PBPR& AV OUTPUT L/R
VIDEO & AV OUTPUT L/R
2-2

Front panel
display
Description
LOADING Loading a disc.
UNSUPP The disc is not supported.
BD Blu-ray disc is recognized.
HDMI ERR The HDMI video resolution is
not supported by TV.
FASTFWD Fast forward mode.
FASTBWD Fast reverse mode.
SLOWFWD Slow forward mode.
SETTINGS Setup menu is displayed.
HOME Home menu is displayed.
CHAPTER Current chapter is in chapter
repeat mode.
RESUME Resume play is possible.
DOLBY D Dolby Digital audio is being
played.
DOLBY HD Dolby HD audio is being
played.
UPGRADE Software upgrade is in
progress.
Product overview
Main unit
a
Turn on the disc player or switch to•
standby mode.
When EasyLink is enabled, switch the•
disc player and all EasyLink devices to
standby. Note that you must press and
hold for at least 3 seconds for this to
occur.
bDisc compartment
c
Open or close the disc compartment.•
dIR sensor
Point the remote control at the IR sensor.•
eDisplay panel
f
Start or resume play.•
g
Pause play.•
Move the paused picture one step•
forward.
2-3

cTOP MENU
•BD: Display the top menu.
•DVD: Display the title menu.
d
Access the home menu.•
eDISC MENU / POP-UP MENU
•BD: Access or exit the pop-up menu.
•DVD: Access or exit the disc menu.
fOK
Confirm an entry or selection.•
g
Navigate through the menus.•
hBACK
Return to a previous display menu.•
i/
Skip to the previous or next title, chapter,•
or track.
j/
Search backward or forward.•
k
Mute volume (applicable only to certain•
Philips brand TVs).
l+/-
Adjust volume (applicable only to certain•
Philips brand TVs).
mSUBTITLE
Select a subtitle language on a disc.•
nAUDIO
Select an audio language or channel on•
a disc.
oAlphanumeric buttons
Select an item to play.•
Enter values or letters (via SMS style•
entry).
p
Open or close the disc compartment.•
qTV CH +/-
Select a TV channel (applicable only to•
certain Philips brand TVs).
r
Stop play.•
s
Pause play.•
Move the paused picture one step•
forward.
t
Start or resume play.•
uINFO
Display the current status or the disc•
information.
Remote control
a
Turn on the disc player or switch to•
standby mode.
When EasyLink is enabled, switch the•
disc player and all EasyLink devices to
standby. Note that you must press and
hold for at least 3 seconds for this to
occur.
bBONUSVIEW
Turn on or off the secondary video•
in a small screen window during play
(applicable only to BD-video that
supports the BONUSVIEW or Picture-
In-Picture feature).
2-4
vOPTIONS
Access options for the current activity or•
selection.
wColor buttons
•BD: Select tasks or options.
xHDMI
Select the video resolution of HDMI•
output.
yREPEAT
Select repeat play or random play.•

Mechanical and Dismantling Instructions
Dismantling Instruction
The following guidelines show how to dismantle the player.
Step1: Remove 6 screws around the Top Cover, and then remove the Top Cover (Figure 1).
Figure 1
Step2: If it is necessary to dismantle Loader or Front Panel, the Front door should be removed first. (Figure 2)
Note: Make sure to operate gently otherwise the guider would be damaged.
Figure 2
3-1
Please kindly note that dismantle the front door
assembly carefully to avoid damage tray and the front door.
Detailed information please refer to the model set.

Mechanical and Dismantling Instructions
Dismantling Instruction
Step3: If the tray can’t open in normal way, you can make it through the instruction as below (Figure 3).
Note: Make sure to operate gently otherwise the guider would be damaged.
Figure 3
Step4: Dismantling Front Panel, disconnect the connectors(J306, CN502), need release 5snaps of Front Panel
and 2 snaps of bottom cabinet , then gently pull the Panel out from the set. (Figure 4 - Figure 6)
Figure 4
3-2
Detailed information please refer to the model set.
J303
J320
J306
PWR1
CN504
CN502
