Philips AZ1047/94 User manual

EN User manual

1 Important
Safety
Important Safety Instructions
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
h Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
i Protect the power cord from being walked on or pinched, particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
j Only use attachments/accessories specified by the manufacturer.
k Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer or sold with the ap-
paratus.When a cart is used, use caution when moving the cart/apparatus combination to avoid injury from
tip-over.
l Unplug this apparatus during lightning storms or when unused for long periods of time.
m Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been dam-
aged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
n Battery usage CAUTION – To prevent battery leakage which may result in bodily injury, property damage,
or damage to the unit:
Install all batteries correctly, + and - as marked on the unit.
•
Do not mix batteries (old and new or carbon and alkaline, etc.).
•
Remove batteries when the unit is not used for a long time.
•
o Apparatus shall not be exposed to dripping or splashing.
p Do not place any sources of danger on the apparatus (e.g. liquid filled objects, lighted candles).
q This product may contain lead and mercury. Disposal of these materials may be regulated due to environ-
mental considerations. For disposal or recycling information, please contact your local authorities or the
Electronic Industries Alliance: www.eiae.org.

Warning
Never remove the casing of this Soundmachine.•
Never lubricate any part of this Soundmachine.•
Never place this Soundmachine on other electrical equipment.•
Keep this Soundmachine away from direct sunlight, naked flames or heat.•
Never look into the laser beam inside the Soundmachine.•
Ensure that you always have easy access to the power cord, plug or adaptor to disconnect the Soundmachine•
from the power.
Caution
Use of controls or adjustments or performance of procedures other than herein may result in hazardous radia-•
tion exposure or other unsafe operation.
Notice
The making of unauthorized copies of copy-protected material, including computer programs, files, broadcasts and
sound recordings, may be an infringement of copyrights and constitute a criminal offence.This equipment should not
be used for such purposes.
Recording and playback of material might require consent. See Copyright Act 1956 andThe Performer’s Protection
Acts 1958 to 1972.
Environmental information
All unnecessary packaging has been omitted.We have tried to make the packaging easy to separate into three
materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.)
Your system consists of materials which can be recycled and reused if disassembled by a specialized company. Please
observe the local regulations regarding the disposal of packaging materials, exhausted batteries and old equipment.
This Soundmachine includes this label:

enihcamdnuoSDCruoY2
enebyllufoT!spilihPotemoclewdna,esahcrupruoynosnoitalutargnoC �t from the support that Philips offers,
register your product at www.Philips.com/welcome.
noitcudortnI
yalpehtmargorposlanacuoY.oidarWM/MFotnetsildnascsidoiduayalpnacuoyenihcamdnuoSDCehthtiW
sequence of tracks. Dynamic Bass Boost (DBB) helps you to maximizes music enjoyment.
xobehtnis’tahW
:egakcapehtfostnetnocehtyfitnedidnakcehC
enihcamdnuoSDC
•
drocrewopCA•
launaMresU•
tinuniamehtfoweivrevO
c
a
b
d
e
h
i
j
k
g
f

1 VOLUME
Adjust volume level
•
2 DBB
Turn the bass enhancement on/off
•
3 Cassette recorder buttons
•
Pause play or record
•
Stop cassette play or record
Open the cassette holder
• /
Fast forward/rewind cassette
•
Start cassette play
•
Start cassette record
4 PROG
Program tracks and browse the program
•
5 MODE
Select a play mode: REPEAT or SHUFFLE
•
6 Basic play buttons:
•
l
m
o
n

Stop CD play
Erase a CD program
•
Start or pause CD play
•
/
Select the previous/next track
Fast search backwards/forwards within the current track
7 ALBUM +/-
Skip to the next/previous album in an MP3-CD
•
8 BAND
Select a wave band
•
9 MP3 LINK
Socket for audio input
•
10 TUNING +/-
•Tune to radio stations
11 LIFT TO OPEN
Open/Close the CD compartment
•
12 Telescopic antenna
Improve FM reception
•
13 AC MAINS~
Socket for the power cord
•
14 Battery door
15 Source selector: CD, TUNER, MP3 LINK,TAPE/OFF
Select CD, radio or MP3 source of sound
•
Switch to standby mode
•
3 Get started
Caution
Use the controls only as stated in this user manual.•
Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and serial number of your Soundmachine.The model number
and serial number are on the bottom of your Soundmachine. Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Install batteries

1 Open the battery compartment.
2 Insert 6 x 1.5V R14/UM-2/C-cell batteries with correct polarity (+/-) as indicated.
3 Close the battery compartment.
Tip
If you want to save battery life, use the supplied power cord.•
Connect AC power
Warning
Risk of product damage! Ensure that the power supply voltage corresponds to the voltage printed on the back•
or the underside of the Soundmachine.
Risk of electric shock! When you unplug the AC adaptor, always pull the plug from the socket. Never pull the
•
cord.
Note
Install the unit near the power supply socket and where the AC power plug can be easily reached.•
6 x 1.5V R-14/UM-2/C-cell

1Switch the voltage selector in the battery compartment of the Soundmachine to the local power line voltage.
2 Connect the power cord to the AC MAINS~ socket on the Soundmachine and to the power supply socket.
•To switch the Soundmachine off completely, disconnect the power cord from the power supply socket.
Tip
To save energy: After use, set the source selector to• TAPE/OFF.
4 Use your Soundmachine
Play a CD
Note
You cannot play CDs encoded with copyright protection technologies.•
You can play commercially available audio CDs:
CD-Recordables (CD-R)
•
CD-Rewritables (CD-RW)•
MP3-CDs•
1 Switch the source selector to CD.
2 Lift the lid of the CD compartment.

3 Insert a CD with the printed side facing up.
4 Close the CD lid gently.
The total number of tracks is displayed.
»
5 Press to start play.
»
[ ]is displayed.
To pause CD play, press• .
To resume CD play, press
• again.
To stop CD play, press
• .
Select a track
1 During play, press /to select a track.
Select an album
For MP3-CDs only.
1 During play, press ALBUM +/-to select an album.
Find a passage within a track
1 During play, press and hold /.
The CD is played at high speed and with reduced volume.
»
2 Release /to resume normal play.
Tip
When search reaches the end of the last track, the CD stops.•
Select play modes
Repeat play
You can repeat a track, an MP3 album, a disc, or a program.
• []– plays the current track continuously
• [ALB] – plays the current album continuously

• [ALL] – repeats the entire CD/program
1 During play, press MODE repeatedly until the display shows the repeat icon.
•Repeat one track.
Repeat an album.
•
• Repeat a program.
To stop repeat play, press• MODE repeatedly until the repeat icon is no longer displayed.
Shuffle play
You can play all tracks in random order.
1 During play, press MODE repeatedly until the display shows the shuffle icon.
To stop shuffle play, press• MODE again.
Program play sequence
You can store up to 20 tracks in the desired sequence.
1 In stop mode, press PROG to start to program play sequence.
»[PROG] and
[P01]
are displayed.

2 Press ALBUM +/- to select an album.
This step is only applicable for MP3-CDs.
3 Press /to select a track.
4 Press PROG to store the track.
»[PROG] and
[P02] are displayed.
5 Repeat steps 2 to 4 to select and store all tracks.
»When all 20 tracks are stored, no more tracks can be selected and the display shows
[PROG] and [ --- ] .
6 To play program, press .
In stop mode, press
»PROG repeatedly to browse stored tracks.
To cancel program, press
• twice.
Tip
When program play stops, the Soundmachine returns to normal play.To play program again, repeat steps 1 to 6.•
Listen to radio
1 Switch the source selector to TUNER.
2 Switch BAND to FM or MW.
3 Tu r n TUNING +/- to find a station.
Tip
To improve FM reception, you can extend, incline or turn the telescopic antenna for best reception.•
To improve MW reception, turn the Soundmachine to face a different direction.•
Play cassette recorder
1 Switch the source selector to TAPE/OFF.
2 Press to open the cassette holder, insert a cassette tape, and then close the cassette holder.
3 Press to start play.
To pause play, press
• .
To stop the play, press
• .
Find a passage within a tape

1 During stop, press / to search for a desired passage in a tape.
2 To stop fast search, press .
Record from CD
1 Switch the source selector to CD.
2 Insert a CD with the printed side facing up.
3 If you want to record tracks in the desired sequence, program the desired tracks.
4 Press to open the cassette holder.
5 Insert a blank cassette.
6 Close the holder.
7 Press to start to record.
»The disc/program starts automatically from the beginning.
To pause, press
• .
•To resume, press again.
To stop, press
• .
Record from radio
1 Switch the source selector to TUNER.
2 Tune to a radio station.
3 Press to open the cassette holder.
4 Insert a blank cassette.
5 Close the holder.
6 Press to start to record.
To pause, press
• .
•To resume, press again.
To stop, press
• .
5 Troubleshooting
Warning
Never remove the casing of this Soundmachine.•
To keep the warranty valid, never try to repair the system yourself.
If you encounter problems when using this Soundmachine, check the following points before requesting service. If
the problem remains unsolved, go to the Philips web site (www.Philips.com/support), or contact Philips (see Contact
information).When you contact Philips, ensure that your Soundmachine is nearby and the model number and serial
number are available.
No power

Ensure that the power cord is connected securely.•
Ensure that there is power at the power supply socket.•
Ensure that the batteries are installed correctly.•
No sound
Adjust the volume.•
Ensure that the track played is of a compatible format.•
Display does not function properly./No reaction to operation of any of the controls.
1 Disconnect the AC power cord.
2 Connect the AC power cord after a few seconds.
Cannot play disc
Ensure that the disc label is inserted with the printed side facing up.•
Wipe the disc with fibre cleaning cloth from the centre to the edge in a straight line.•
This disc may be defective. Play another disc.•
Ensure that the CD is a finalised CD/CD-R/CD-RW.•
Ensure that the laser lens is clean.•
Ensure that the CD is not encoded with copyright protection technologies.•
The CD skips tracks
Ensure that the CD is not damaged or dirty.•
Ensure that program/shuffle mode is deactivated.•
Poor cassette sound quality
Ensure that heads in the cassette holder are clean.
•
Ensure that a NORMAL (IECI) cassette tape is used for record.•
Cassette does not work for record
Ensure that cassette tabs are not broken.
•
6 Product information
Note
Product information is subject to change without prior notice.•
Dimensions (Main unit)
(W x H x D)
291 x 146 x 243 mm
11.5 x 5.8 x 9.6 inches
Weight (Main unit) 1.8 kg
3.8 pound
Power supply DC 9V 1.5 A
AC 110~127 / 220~240 V
Power consumption Active 12W
Standby < 2W
Power output 2 x 1W RMS
Operating temperature range -10°C - +50°C
14°F - 122°F

© 2010 Koninklijke Philips Electronics N.V.
All rights reserved.
AZ1047_UM_94_V2.0
