Philips AZ1837/85 User manual

www.philips.com/welcome
User manual
Always there to help you
Register your product and get support at
AZ1837
Question?
Contact
Philips

1EN
Contents
Contents
1 Important 2
Safety 2
2 Your CD Soundmachine 4
Introduction 4
What's in the box 4
Overview of the main unit 5
3 Get started 7
Install batteries 7
Connect power 7
Turn on 8
4 Use your CD Soundmachine 9
Play a CD 9
Play from USB device 9
Listen to radio 9
Control play 9
Program tracks 10
5 Other features 11
Listen to an external device 11
6 Product information 12
Specications 12
Supported MP3 disc formats 12
USB playability information 12
7 Troubleshooting 14
8 Notice 15

2EN
1 Important
Safety
This 'bolt of lightning' indicates uninsulated
material within the device may cause an
electrical shock. For the safety of everyone in
your household, please do not remove the
covering.
The 'exclamation mark' calls attention to
features for which you should read the enclosed
literature closely to prevent operating and
maintenance problems.
WARNING:Toreducetheriskofreorelectric
shock, the device should not be exposed to rain
ormoistureandobjectslledwithliquids,such
as vases, should not be placed on the device.
CAUTION:To prevent electric shock, fully
insert the plug. (For regions with polarized
plugs:To prevent electric shock, match wide
blade to wide slot.)
Important Safety Instructions
• Follow all instructions.
• Heed all warnings.
• Do not use this apparatus near water.
• Clean only with dry cloth.
• Do not block any ventilation openings.
Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such
as radiators, heat registers, stoves, or other
device(includingampliers)thatproduce
heat.
• Protect the power cord from being
walked on or pinched, particularly at plugs,
convenience receptacles, and the point
where they exit from the device.
• Onlyuseattachments/accessoriesspecied
by the manufacturer.
• Use only with the cart, stand, tripod,
bracket,ortablespeciedbythe
manufacturer or sold with the device.
When a cart is used, use caution when
moving the cart/device combination to
avoid injury from tip-over.
• Unplug this device during lightning storms
or when unused for long periods of time.
• Referallservicingtoqualiedservice
personnel.Servicingisrequiredwhenthe
device has been damaged in any way, such
as power-supply cord or plug is damaged,
liquidhasbeenspilledorobjectshave
fallen into the device, the device has been
exposed to rain or moisture, does not
operate normally, or has been dropped.
• Battery usage CAUTION –To prevent
battery leakage which may result in bodily
injury, property damage, or damage to the
device:
• Do not mix batteries (old and new or
carbon and alkaline, etc.).
• Install the battery correctly, + and - as
marked on the device.
• The batteries shall not be exposed to
excessiveheatsuchassunshine,reor
the like.
• Remove battery when the device is
not used for a long time.
• Device shall not be exposed to dripping or
splashing.
• Do not place any sources of danger on
thedevice(e.g.liquidlledobjects,lighted
candles).

3EN
• Where the MAINS plug or an appliance
coupler is used as the disconnect device,
the disconnect device shall remain readily
operable.
Warning
•Never remove the casing of this device.
•Never lubricate any part of this device.
•Neverplacethisdeviceonotherelectricalequipment.
•Keep this device away from direct sunlight, naked
amesorheat.
•Never look into the laser beam inside this device.
•Ensure that you always have easy access to the power
cord, plug, or adaptor to disconnect this device from
the power.

4EN
2 Your CD
Soundmachine
Congratulations on your purchase, and
welcometoPhilips!Tofullybenetfromthe
support that Philips offers, register your product
at www.philips.com/welcome.
Introduction
With the CD Soundmachine, you can:
• play CDs, MP3/wma discs
• playmp3/wmalesonUSBdevices
• listen to FM/MW radio
• programtheplaysequenceoftracks.
What's in the box
Check and identify the contents of the package:
• Main unit (without batteries)
• 1 x power cord
• 1 x MP3 link cable
• User Manual

5EN
Overview of the main unit
o
ad b c e f
gj hklmn i
qp
r

6EN
a Source selector: CD•USB/MW/FM/OFF
• SelectCD•USB,MW(AM),FMsource,
or turn off the unit.
b
• USB socket.
c VOL+/-
• Adjust volume.
d Display panel
• Show current status.
e OPEN/CLOSE
• Press to open or close the disc
compartment.
f Tuning
• Tune to radio stations.
g USB
• Select USB device source.
h CD
• Select CD source.
i - ALBUM +
• For MP3-CDs: skip to the next/
previous album in an MP3-CD.
j /
• Select the previous/next track.
• Search backward/forward.
k
• Pause or resume play.
l
• Stop play.
• Erase a program.
m MODE
• Select a play mode: REPEAT or
SHUFFLE.
n PROG
• For MP3-CDs: program tracks and
browse the program.
o Telescopic antenna
• Adjust FM reception.
p MP3 LINK
• Socket for connecting an external
device.
q Battery compartment
r AC~Mains
• Power supply socket.

7EN
3 Get started
Caution
•Use of controls or adjustments or performance of
procedures other than herein may result in hazardous
radiation exposure or other unsafe operation.
Always follow the instructions in this chapter in
sequence.
If you contact Philips, you will be asked for the
model and serial number of this apparatus.The
model number and serial number are on the
bottom of the apparatus.Write the numbers
here:
Model No. __________________________
Serial No. ___________________________
Install batteries
Note
•You can use both batteries and AC power as power
supply of this device.
1 Open the battery compartment.
2 Insert 6 x 1.5 V R14/UM2/C CELL
batteries (not supplied) with correct
polarity (+/-) as indicated.
3 Close the battery compartment.
Connect power
Caution
•Risk of product damage! Make sure that the power
supply voltage corresponds to the voltage printed on
the back or the underside of the product.
•Risk of electric shock! When you unplug the AC power
cord, always pull the plug from the socket. Never pull
the cord.
•Before you connect the AC power cord, make sure that
you have completed all other connections.
1 Switch the voltage selector at the bottom
of the unit to local power line voltage.
2 Connect AC power plug to AC outlet.
220V-
240V
110V-
127V

8EN
Turn on
After connected to power, the device switches
to the last selected source automatically.
Tip
•Switch the source selector to OFF and disconnect
the power plug from the wall outlet after use to save
energy.

9EN
4 Use your CD
Soundmachine
Play a CD
Note
•You cannot play CDs encoded with copyright
protection technologies.
You can play commercially available audio CDs:
• CD-Recordables (CD-R)
• CD-Rewritables (CD-RW)
• MP3-CDs
• WMA-CDs
1 Switch the source selector to CD•USB.
2 Press CD to select CD source.
3 Press to open the lid of the CD
compartment.
4 Insert a CD with the printed side facing up,
and close the CD lid.
» Play starts automatically. If not, press
.
• To select a track,press / .
• To pause CD play, press .
» [ ] ashes.
• To resume CD play, press again.
• To stop CD play, press .
Play from USB device
Note
•Make sure that the USB device contains playable audio
contents for supported formats.
1 Switch the source selector to CD•USB.
2 Press USB to select the USB source.
3 Insert a USB storage device into the
socket.
4 Press - ALBUM + to select a folder.
5 Press / toselectale,andpress
to start play.
Listen to radio
Tip
•Position the antenna as far as possible from TV,VCR, or
other radiation source.
1 Fully extend and adjust the position of the
antenna for optimal reception
2 Switch the MW/FM selector to MW or
FM.
3 Rotate TUNINGuntilyoundoptimal
reception.
4 Repeat step 3 to tune to more stations.
Tip
•To improve FM reception, you can extend, incline, or
turn the telescopic antenna for best reception.
•To improve MW reception, turn the device to face a
different direction.
Control play
Buttons Functions
VOL Rotate to adjust volume.
Stop play.
Pause or resume play.
/ Press to select a previous/next
track.
Press and hold to fast backward/
forward in a track.
PROG In CD/USB mode, program tracks.

10 EN
MODE Select a play mode.
[ ] (repeat): repeat a track.
[ ALL] (repeat all): repeat an
entire CD/program.
[ ](shufe):playtracks
randomly.
[ ](shuferepeatall):
repeat all tracks randomly.
To return to normal play, press
MODE repeatedly until play mode
icons disappear.
-ALBUM+ Select previous/next album.
Tip
•When search reaches the end of the last track, the CD
stops.
•Shufeplaycannotbeselectedwhenyouplay
programmed tracks.
Program tracks
In DISC/USB mode, you can program up to 20
tracksinthedesiredsequence.
1 Press to stop play, and press PROG to
active the program mode.
» [PROG] and [P01] are displayed.
2 For MP3-CDs, press - ALBUM + to select
an album.
3 Press / to select a track, and then
press PROGtoconrm.
4 Repeat steps 2-3 to program more tracks.
» When all 20 tracks are stored, no
more tracks can be selected and [FUL]
is displayed.
5 Press to play the programmed tracks.
» During play, [PROG] (program) is
displayed.
• To erase the program, at the stop
position, press .

11EN
5 Other features
Listen to an external device
You can also listen to an external audio device
through this unit.
For an audio device with a headphone socket:
1 Connect the supplied MP3 LINK cable to:
• the MP3-LINK socket on the back of
the unit.
• the headphone socket on an MP3
player.
2 Start to play the MP3 player. (See the user
manual of the MP3 player.)

12 EN
6 Product
information
Note
•Product information is subject to change without prior
notice.
Specications
Amplier
Total Output Power 2 W
FrequencyResponse 125 -16000 Hz,
-3dB
Signal to Noise Ratio >55 dBA
Total Harmonic Distortion <1 %
Disc
Laser Type Semiconductor
Disc Diameter 12 cm/8 cm
Support Disc CD-DA, CD-R,
CD-RW, MP3-CD
Audio DAC 24 Bits / 44.1 kHz
Total Harmonic
Distortion
<1% (1 kHz)
FrequencyResponse 60 Hz - 16 kHz;
±3 dB
S/N Ratio >55 dBA
USB
USB Direct Version USB 1.1 or 2.0
USB 5 V Power ≤300mA
Tuner
Tuning Range FM: 87.5-108 MHz
Total Harmonic Distortion <3%
Signal to Noise Ratio >50 dBA
General information
Power Supply
- AC Power
- Battery
110-127/220-240 V~;
50/60 Hz
6 x 1.5 V R14/UM2/C
CELL batteries
Operation Power
Consumption
12 W
Dimensions - Main unit
(W x H x D) 341 x 122 x 236 mm
Weight - main unit 1.8 kg
Supported MP3 disc formats
• ISO9660, Joliet
• Maximum title number: 999 (depending on
lenamelength)
• Maximum album number: 99
• Supportedsamplingfrequencies:32kHz,
44.1 kHz, 48 kHz
• Supported Bit-rates: 32~256 (kbps),
variable bit rates
USB playability information
Compatible USB devices:
• USBashmemory(USB1.1or2.0)
• USBashplayers(USB1.1or2.0)
Supported USB formats:
• USBormemoryleformatFAT12,
FAT16, FAT32 (sector size: 512 bytes)
• MP3 bit rate (data rate): 32-320 Kbps
and variable bit rate
• Directory nesting up to a maximum of
8 levels

13EN
• Number of albums/ folders: maximum
99
• Number of tracks/titles: maximum 999
• File name in Unicode UTF8 (maximum
length: 16 bytes)
Unsupported USB formats:
• Empty albums: an empty album is an
albumthatdoesnotcontainMP3les,
and is not shown in the display.
• Unsupportedleformatsareskipped.
For example,Word documents (.doc)
orMP3leswithextension.dlfare
ignored and not played.
• AAC,WAV,PCMaudioles

14 EN
7 Troubleshooting
Warning
•Never remove the casing of this device.
To keep the warranty valid, never try to repair
the system yourself.
If you encounter problems when using this
device, check the following points before
requestingservice.Iftheproblemremains
unsolved, go to the Philips Web page (www.
philips.com/support).When you contact Philips,
make sure that the device is nearby and the
model number and serial number are available.
No power
•Make sure that the AC power plug of the
unit is connected properly.
•Make sure that there is power at the AC
outlet.
•Insert the batteries with their polarities
(+/– signs) aligned as indicated.
•Replace the battery.
No sound
•Adjust the volume.
•Make sure that the track played is of a
compatible format.
Display does not function properly. /No
reaction to operation of any of the controls.
• Disconnect the AC power cord.
• Connect the AC power cord after a few
seconds.
Cannot play disc
•Make sure that the disc label is inserted
with the printed side facing up.
•Wipethediscwithbrecleaningcloth
from the centre to the edge in a straight
line.
•This disc may be defective. Play another
disc.
•MakesurethattheCDisanalizedCD/
CD-R/CD-RW.
•Make sure that the laser lens is clean.
•Make sure that the CD is not encoded
with copyright protection technologies.
The CD skips tracks
•Make sure that the CD is not damaged or
dirty.
•Makesurethatprogram/shufemodeis
deactivated.
USB device not supported
•The USB device is incompatible with the
apparatus.Try another one.

15EN
8 Notice
Anychangesormodicationsmadetothis
device that are not expressly approved by
WOOX Innovations may void the user’s
authoritytooperatetheequipment.
Your product is designed and manufactured
withhighqualitymaterialsandcomponents,
which can be recycled and reused.
Never dispose of your product with other
household waste. Please inform yourself about
the local rules on the separate collection of
electrical and electronic products and batteries.
The correct disposal of these products helps
preventpotentiallynegativeconsequenceson
the environment and human health.
Your product contains batteries, which cannot
be disposed of with normal household waste.
Please inform yourself about the local rules on
separate collection of batteries.The correct
disposal of batteries helps prevent potentially
negativeconsequencesontheenvironmentand
human health.
Please visit www.recycle.philips.com for
additional information on a recycling center in
your area.
Environmental information
All unnecessary packaging has been omitted.
We have tried to make the packaging easy to
separate into three materials: cardboard (box),
polystyrene foam (buffer) and polyethylene
(bags, protective foam sheet.)
Your system consists of materials which can
be recycled and reused if disassembled by
a specialized company. Please observe the
local regulations regarding the disposal of
packaging materials, exhausted batteries and old
equipment.
The USB-IF Logos are trademarks of Universal
Serial Bus Implementers Forum, inc.
Windows Media and the Windows logo
are trademarks, or registered trademarks of
Microsoft Corporation in the United States
and/or other countries.
Recording and playback of material might
requireconsent.SeeCopyrightAct1956and
The Performer’s Protection Acts 1958 to 1972.
The making of unauthorized copies of copy-
protected material, including computer
programs,les,broadcastsandsound
recordings, may be an infringement of
copyrights and constitute a criminal offence.
Thisequipmentshouldnotbeusedforsuch
purposes.
This apparatus includes these labels:
ClassIIequipmentsymbol
This symbol indicates that the apparatus has a
double insulation system.
Note
•The type plate is located on the bottom of the device.

Specifications are subject to change without notice
2014 © WOOX Innovations Limited. All rights reserved.
Philips and the Philips’ Shield Emblem are registered trademarks of Koninklijke
Philips N.V. and are used by WOOX Innovations Limited under license from
Koninklijke Philips N.V.
AZ1837_85_UM_V2.0
