Philips CDC77517 User manual

5 CD CHANGER
•Changing while playing
While playing a disc it is possible to change 2 other discs
•Bitcheck Multibit DAC
A quick play button allows to quickly start the CD just put in
the player.Generally the mechanical contruction is such that
changing a disc goes very fast
• CD-Rewritable playback
AllowsAudio playback of CD-Rewritable discs (and CD Recordable
discs) recorded on either PC or Cd-Rewritable recorders
•Digital Output (CDR-Link)
For top quality digital recording to digital recorders
•Variable Headphone
To adjust the headphone volume level
•Repeat A/B
To replay a chosen part of the CD in a loop
•Edit and Peaksearch
As helpful aids for tape recordings (3 edit modes available)
•Fader
Fades the music slowly in and out when needed
•Philips Harmonized Components Design
5 CD CHANGER
• Changing while playing
While playing a disc it is possible to change 2 other discs
• Bitcheck Multibit DAC
A quick play button allows to quickly start the CD just put in
the player.Generally the mechanical contruction is such that
changing a disc goes very fast
• CD-Rewritable playback
AllowsAudio playback of CD-Rewritable discs (and CD Recordable
discs) recorded on either PC or Cd-Rewritable recorders
• Digital Output (CDR-Link)
For top quality digital recording to digital recorders
• Variable Headphone
To adjust the headphone volume level
• Repeat A/B
To replay a chosen part of the CD in a loop
• Edit and Peaksearch
As helpful aids for tape recordings (3 edit modes available)
• Fader
Fades the music slowly in and out when needed
• Philips Harmonized Components Design
CDC775
5 CD Changer
Provisional

CDC775
5 CD Changer
5 CD Changer
standard product information
UPC : 0378 4987 7692 3
Product Dimensions:
17.1" W x 4.7" H x 14.9" D (electronics)
Package Dimensions:
21.3"W x 8.9" H x 19.2" D
Product weight: 16.5 lbs
Carton contains: 5 CD changer player,Multi-Function Remote Control,
Batteries, Operating instructions,Warranty information
Printed in Singapore
Date Printed : Nov 1999
©1999 Royal Philips Electronics N.V.
All rights reserved
A Division of Philips Electronics North America Corp.
Specifications subject to change without notice.
audio performance
• frequency range : 20Hz - 20kHz
• frequency response ripple : 0.9 |dB|p (20Hz - 20kHz)
• low level linearity : < 1 dB (1kHz,-90dB)
• signal-to-noise ratio : 98 dB (1kHz,A-weighted)
• dynamic range : 95 dB (1kHz)
• channel separation : 90 dB (1kHz)
• T.H.D.+N : 0.006%,-84dB (1kHz)
• wow and flutter : quartz precision
optical read-out system
• laser type : linear tracking,three spots
audio output
• output level : 2V RMS ±3dB
• minimum load : protected against short circuit
• impedance : 1k Ohm
digital output
• maximum output level : acc.IEC 958
• load impedance : 75 Ohm
headphone connection
• output impedance : 120 Ohm
• stereo jack : 6.3mm gold plated
• output level : max.5Vrms EMF
• load impedance : 30-600 Ohm
remote control
• keys : 23-keys
• codes : RC5 infra red
power supply
• mains voltage : 230V (/00,+6% - 10%)
120V,230V (/01,+6% - 10%)
• mains frequencies : 50-60Hz
• power consumption : < 15W (in operation)
< 5W (in standby)
• electrical requirements : IEC 65
set
• material / finish : metal,hot-stamp foil onABS
• dimensions (incl.feet) : 17.1"W x 4.7" H x 14.9" D
• display : 2 colour starbust FTD
• weight : 16.5 lbs
package
• dimensions : 21.3"W x 8.9" H x 19.2" D
• weight (incl.set) : 22 lbs
accessories
• cinch cable
• remote control
• 2AAA batteries
• instruction manual
• warrenty information
CD-Rewritable Playback
Philips has introduced CD recording as a
mainstream consumer audio application.
With the Philips CD-Recorders it is
possible to record CD-R discs (recordable,
write once) and CD-RW discs (rewritable,
erasable). CD-R discs are fully compatible
with the CD standard, and can therefore
be played back on any CD player. CD-RW
(rewritable) discs have a lower surface
reflectance than standard CD's and
therefore cannot be played by all today's
CD players. Our new range of CD
products offer CD Rewritable Playback.
These players are recognised by the "CD
Rewritable Playback Compatible" logo.
