Philips ESP 2 User manual

15
TABLE OF CONTENTS
Introduction...................................................................................1
Camera Features ..........................................................................2
Parts and Names ..........................................................................3
LC D Monitor .................................................................................5
Basic Operation•Quick Reference ..............................................7
Preparations .................................................................................7
Taking Pictures .............................................................................8
Playback and Erasure ..................................................................9
Safety Precautions .....................................................................10
Chapter 1. Getting Started
Before Using the Camera ............................................................. 16
Confirming the Package Contents .................................... 16
Attaching the Wrist Strap ..................................................16
Supplying Power to the Camera ...................................................17
Inserting Batteries .............................................................17
Inserting a Lithium Battery ................................................19
Using AC Power ................................................................21
Before You Begin Recording.........................................................22
Adjusting the Date and Time .............................................22
Adjusting the LCD .............................................................24
Holding the Camera .......................................................... 24
Chapter 2. Recording Basics
Taking Pictures ...........................................................................28
Picture-taking Sequence ...................................................28
Turning on the Power ........................................................28
Selecting the Image Quality .............................................. 29
Taking Pictures..................................................................30
Exposure Compensation...................................................32
Chapter 3. Picture-Taking Applications
Flash Mode..................................................................................36
Selecting a Flash Mode.....................................................36
Flash Off Mode..................................................................37
Forced Flash Mode ...........................................................38
Auto Flash Mode ...............................................................39
Setting theWhite Balance Mode ...............................................40
Selecting a White Balance Mode ......................................40
Daylight Mode ...................................................................41

16
Fluorescent Mode ............................................................. 42
Tungsten Light Mode.........................................................43
Special Functions.......................................................................44
Using the Self Timer..........................................................44
Macro Shooting (Close-up Shooting) ................................ 45
Chapter 4. Picture Playback/Erasure
Before Playback.......................................................................... 48
Displaying Information.......................................................48
Connecting to a TV............................................................49
File Playback ............................................................................... 50
File Playback .....................................................................50
Automatic Playback...........................................................50
File Erasing .................................................................................52
Operation Flow..................................................................52
Erasing One File ...............................................................52
Erasing All Files ................................................................54
Chapter 5. Additional Information
Changing a Camera Setting ......................................................56
Setting the Auto Power Off mode ......................................56
Setting the Power Saving Mode ........................................57
SavingYour Settings .........................................................58
Returning the settings to the Original Position .................. 59
System Configuration Figure ....................................................60
Accessories for ESP2 ................................................................62
Computer and DC Connections ................................................63
Handling Precautions ................................................................66
Caring forYour Digital Camera.................................................. 67
Troubleshooting ......................................................................... 68
UsingYour Digital Camera in Other Countries ........................ 71
Specifications .............................................................................72

1
Introduction
Testing the camera
Always test the camera by taking several sample pictures to confirm that the pictures are
recorded correctly.
Respecting copyrights
Reproduction or alteration of copyrighted documents and magazines other than for per-
sonal or family use or for a similarly limited extent, without the consent of the author, is
prohibited.
About lost files
We regret that we cannot be responsible for files lost due to any malfunction of the cam-
era.
About the warranty
This product is made according to local specifications.Should it malfunction while you
are abroad, we cannot be responsible for the cost or availability of service in other coun-
tries.
Radio-frequency interference
Using the digital camera near electric devices could inhibit the performance of both the
camera and nearby devices. Interference is likely to occur when the camera is placed
near a radio or television. If this condition occurs, perform the following procedures:
• Relocate the camera as far as possible from the interference source.
• Change the orientation of the radio or television antenna.
• Plug the camera into a different electrical outlet.
Microsoft, MS-DOS, and Windows are trademarks of the Microsoft Corporation of the U. S. A. and
are registered in the U. S.and other countries.
Macintosh is a trademark of Apple Computer Inc. of the U. S.A. and is registered in the U. S. and
other countries.
All trademarked product names mentioned in this manual are the property of their respective com-
panies.

2
Camera Features
Recording quickly
Recording can be performed quickly and simply by determining the image composition
while observing the LCD monitor and pressing the shutter release button.The memory is
stored in the main unit of the camera.
Confirming a file after recording
A recorded file can be confirmed by the LCD monitor right after the recording. Playback
the file by switching to the playback mode.
Taking several pictures by switching the mode
Three modes can be set.These modes include Normal mode, Fine mode (sets the re-
cording priority on image quality), and Economy mode, which records several which
images.
Natural color images
Use the Auto White Balance feature to place the subject in natural color, regardless of
the lighting conditions.
Close-up shooting
You may approach a subject as close as a distance of 1 cm.This is called Macro Shoot-
ing and is appropriate for pictures of flowers, insects, or other detailed subjects.
Monitoring on aTV
A recorded file may be viewed on aTV by connecting the video cable.Dubbing to a video
cassette tape and printing a full-color print are also possible if you connect the camera to
a video deck or a video printer (NTSC only).
Easy to carry, compact size
The compact size and light weight of the camera enable easy carrying.This camera has
an optional hard case, making it easy for you to take it with you anywhere.
Transferring files to a computer
Files can be transferred to a computer using the software for the ESP2.The file can be
printed with a color printer and color copier.

3
Parts and Names
Camera (main unit) (Top)
Lens
Self timer light
Release button
Macro dial
Wrist strap
eyelet
LCD monitor
Flash sensor
reception window
Flash
Remote control
reception
(Bottom)
Clock Battery compartment
Tripod screw hole

4
(Operation part)
Brightness adjustment dial
RECORD/PLAY switch
PIC (Image Quality) switch
Battery compartment
Power supply terminal
(DC IN 5V)
Operation panel
LCD monitor
Terminal cover
RS232C/AUX terminal
Reset button VIDEO OUT terminal
(Operation panel)
DATE
DATE button Flash LED
SelfTimer button
Erase button
Flash button
+/- (exposure com-
pensation) button
(FWD) button
(REV) button
Connection cable
AC adaptor (not supplied)
• AY3140 (100V to 240V)
Power cord

5
LCD Monitor
The battery condition, number of possible recordings, current mode, and other camera
conditions appear as symbols and numbers on the LCD monitor.
Recording Display
White balance display
(No display) : AUTO
: Daylight mode
: Fluorescent light mode
: Tungsten light mode
Flash display
: Flash OFF
: Forced flash
(No display) :Auto flash
Exposure compensation
value display
Message display
Macro mode
Date and time display
Battery symbol
Clock battery symbol
Recording data display
The remaining number of
images is displayed.
Date and time display
(The date and time that the
image was shot appears
here.)
Playback data display
The number of the current file
and the number of available file
are displayed.
Note:
• All data is displayed in this figure. However, only the necessary data is displayed.
• When the LCD monitor is opened, if no camera operations (button or switch operations) are
performed for more than approximately five minutes, the Auto Power Off mode is activated to
conserve energy.The display of the LCD monitor disappears.(The battery is only used slightly in
this condition.) Supply the power again or press the release button for more than one second to
turn the power on.
• The Auto Power Off setting can be changed.See page 56.
Playback Display
Self timer

6
Warnings
When the following warnings appear on the LCD monitor, verify the problem and correct
it.
Message Condition Description Reference page
Lights 17
Lights 19
Errors
When one of the following errors appears on the LCD monitor, verify the problem and
correct it.
Error message
Error message Description Reference page
ERROR RECORD 28
59
ERROR ERASE 28
52
59
ERROR PLAY 28
59
SYSTEM ERROR1 28
SYSTEM ERROR2 59
SYSTEM ERROR3
* When problems cannot be solved by following the steps above, please contact your
dealer or the local service representative.
This indicates that the batteries are depleted. Re-
place or recharge the batteries.
The clock battery is depleted or the clock battery is
not set.Replace or insert a new batteries.
The file is lost or damaged. Record the image again;
the data that was recorded at this time may not be
played back correctly. If the error message is still
displayed, turn on the power again or press the
Reset button.
The erase operation was not performed correctly.
Turn off the power by closing the LCD monitor, then
turn it on again and take a test image. If the test
image data is erased, the incorrectly erased data
will also be erased at this time.If the error message
is still displayed, press the Reset button.
The playback failed.Turn on the power again or press
the Reset button.
Turn on the power again.Otherwise, press the Re-
set button.

7
Basic Operation• Quick Reference
This section describes the basic operations. Refer to the additional pages for further
details.
Preparations
qInsert the batteries.
* When using the AC adaptor, connect the AC
adaptor to the camera, then connect the
adaptor to the wall outlet. See pages 19 -
20.
qOpen the LCD monitor.
wPress and hold the DATE button for more than
two seconds.
ePress the FWD Ubutton or the REV Tbutton
to change the information.
Each time the DATE button is pressed, the next
position starts flashing.
* Press the DATE button repeatedly to set (in
order)the year,month,date,hour, andminute.
When the selected date or time area is flash-
ing, press the Ubutton or the Tbutton to set
the correct numbers.
rStart the clock.
When the information is correct, press the DATE
button again to start the clock.
Setting the Date andTime Pages 22 - 23
Inserting the batteries Pages 17 - 21
DATE

8
Taking Pictures
qTurn on the power.The recording mode is
set.
Open the LCD monitor.Set the REC(ord) /PLAY
switch to the REC position.
wSet the image quality mode.
Set the PIC switch to F, N, or E.
eWhile viewing the LCD monitor, move the
camera toward the subject.
Briefly press the Release button and make sure
the message “READYTO SHOOT” appears.
rPress the Release button to take a picture.
Taking Pictures Pages 28 - 31
qOpen the LCD monitor and slide the
REC(ord)/PLAY switch to the REC position.
wPress the Flash button and select Flash Off
(),Forced Flash ( ) or Auto Flash (no sym-
bol).
eWhile viewing the LCD monitor, position the
camera to frame the subject, then press the
Release button to take the picture.
Changing the Flash Mode Pages 36 - 39
qOpen the LCD monitor and set the
REC(ord)/PLAY switch to REC.
wPress the SelfTimer button.The SelfTimer
() symbol will be displayed.
ePosition the camera to frame the subject,
then press the Release button to take the
picture.
The Self Timer lights, the shutter will be re-
leased after approximately 10 seconds.
Using the SelfTimer Page 44
DATE
DATE

9
Playback and Erasure
qOpen the LCD monitor and set the REC(ord)/
PLAY switch to PLAY.
wPress the UU
UU
Uand TT
TT
Tbuttons to move through
the files.
Viewing a File (File Playback) Page 50
qOpen the LCD monitor and slide the
REC(ord)/PLAY switch to PLAY.
wPress the ERASE button.
Add a note:
The Release button is also referred to as the
ENTER button in the LCD monitor.
Erasing a File Pages 52 - 54
eTo erase one file, press the UU
UU
Uand TT
TT
Tbuttons
to select ERASE, then press the Release
button. Press the UU
UU
Uand TT
TT
Tbuttons to select
the file to be erased. Press the Release but-
ton be consistent. Repeat as desired.
eTo erase all the files, press the UU
UU
Uand TT
TT
Tbut-
tons to select ERASE ALL, then Press the
RELEASE button to erase all files.Or, press
the Erase button if you do not want to erase
all files.
Erased files cannot be restored.
Check the contents of the file carefully be-
fore erasing the file.
DATE
ERASE
ERASE ALL?
ERASE 17 19

10
o
o
Safety Precautions
Display
Various messages enable you to use the product safely and prevent unexpected danger
to people or damage to property.
RWarning This symbol means operations may result in a serious injury or death
if this message is ignored or if incorrect operation is performed.
RCaution This symbol means mishandling may injure the users or damage ob-
jects if the message is ignored.
Display Example
mIndicates a warning of a prohibited operation.
mIndicates specifically prohibited items.
Display example
nMeaning:Touchprohibited.
qMeaning:Disassemblyprohibited.
Observe the following precautions in order to use this equipment safely.
RWarning
Turn off the power immediately if a fire, odor or other abnormal
condition is observed. Remove the batteries carefully, being care-
ful to avoid electrical shock or burning.When the power is supplied
by an electrical outlet, always remove the electrical plug from the
wall outlet to avoid fire or shock. Contact your nearest service rep-
resentative.Do not use this equipment when it is damaged or is not
operating correctly.
Turn off the power immediately if foreign matter (metallic objects,
water, fluid, etc.) enters the internal parts. Remove the batteries,
being careful to avoid electrical shock or burning.When the power
is supplied by an electrical outlet, always remove the electrical plug
from the wall outlet to avoid fire or shock. Contact your nearest
service representative.Do not use this equipment when it is dam-
aged or is not operating correctly.
m

11
• When the LCD monitor is damaged, do not touch the fluid inside
the display. If any of the following conditions occur, perform the
appropriate action immediately.
• If liquid crystals contact the skin, wipe the crystals off the skin and
rinse the affected area with plenty of water.Then, wash the area
thoroughly with soap and water.
• If any fluid gets in your eyes, rinse your eyes with clean water for at
least 15 minutes. Contact a doctor immediately.
• If someone drinks the fluid in the display, rinse out the mouth thor-
oughly with water. Drink a large quantity of water and induce vom-
iting.Then, contact a doctor immediately.
Observe the following precautions to prevent the batteries from
leaking, exploding, igniting, or breaking.
• Never use batteries that are not specifically recommended for use
with this camera.
• Never dispose of the batteries in a fire; do not short-circuit the ter-
minals; and do not attempt to disassemble, heat, or recharge the
batteries. (Only Nickel Cadmium or nickel-metal-hydride (NiMH)
batteries can be recharged.) Doing so may damage the batteries
and cause a fire, injury, or environmental contamination.
• Do not use batteries incorrectly; do not use batteries of a different
type or name; do not use batteries of a different manufacturer;and
do not mix old and new batteries.
• Be sure to maintain the correct polarity (positive [+] and negative
[–] poles) when inserting the batteries.
• Do not solder the batteries.This may damage the batteries and
may cause a fire, injury, or environmental contamination.
• When using rechargeable batteries, do not mix them with other
types of batteries or with batteries in another charged condition.
• Store the batteries in a location that is not accessible to infants or
children in order to prevent the batteries from being swallowed ac-
cidentally. Contact a doctor immediately if the batteries are swal-
lowed accidentally.This may result in severe personal injury.
• Never leave this product within the reach of infants or children.
o
m
m
o
m

12
• Do not touch the inside of the camera.The internal high-voltage
circuits may cause an electrical shock. Remove the batteries right
away, being careful to avoid electrical shock or burns. When the
unit is damaged, contact the store where you purchased the prod-
uct or contact the service representatives.
• Never attempt to disassemble, repair, or modify the camera by your-
self.There are internal, high-voltage circuits which may cause se-
vere electrical shock.
• Never use the camera in the bathtub or shower.This may cause
fire or electrical shock.
• Do not use the unit near flammable gas, gasoline, benzene, thin-
ner, etc.This may cause an explosion, fire, or burns.
• Do not use the camera in an airplane or other location where us-
age is restricted. Using the camera in these locations may result in
an accident.
• When dust accumulates on the electrical plug, wipe it off thoroughly.
The dust may cause a fire.
• When using a household electrical outlet, always use the special
AC adaptor (product name: AY3140, optional). If a non-recom-
mended AC adaptor is used, this may cause fire, shock, or other
damage.
• When traveling outside the U.S., do not contact the AC adaptor to
power outlet.This may cause fire, shock or other damage.
m
o
m
n
q

13
Observe the following precautions in order to use this unit safely.
RCaution
Fluid leaking from a battery can cause skin burns. If you touch a
damaged battery, wash your hands with water immediately (do not
use soap).
If fluid leaks from the batteries, wipe off the fluid and replace the
batteries with new batteries.
Make sure that the electrical plug is plugged securely into the wall.
Do not get the camera wet.Do not touch the camera with wet hands.
This may cause an electrical shock.
Do not point the flash unit at the driver of a car, bicycle or train.This
may cause an accident.
To prevent fire and shock, do not use metal objects such as a twee-
zers to grasp the batteries.This may cause a short-circuit.
Special Products
• When using products that are optional, such as the Ricoh remote controller and AC
adaptor, read the section Safety Precautions in the operation manual for each prod-
uct before operation.
o
o
m
m
m

14

Chapter 1. Getting Started
Before Using the Camera ....................................................... 16
Confirming the Package Contents .................................... 16
Attaching theWrist Strap................................................... 16
Supplying Power to the Camera ............................................ 17
Inserting Batteries .............................................................. 17
Inserting a Lithium Battery ................................................ 19
Using AC Power .................................................................. 21
BeforeYou Begin Recording .................................................. 22
Adjusting the Date andTime ............................................. 22
Adjusting the LCD .............................................................. 24
Holding the Camera............................................................ 24

16
Before Using the Camera
Confirming the Package Contents
Check the packaging to ensure you have received the following items. Read the war-
ranty, then store it in a safe place.
• Digital Camera (main unit)
• Video connection cable
• Soft Case
• Four AA Alkaline Batteries
• Lithium battery (CR2025)
• Wrist Strap
• Instructions for use
• Warranty Card
Attaching the Wrist Strap
For security, always use the wrist strap when carrying the camera.
qTo attach the wrist strap, pull the leading
end of the strap through the wrist strap
eyelet on the camera, then pull then re-
mainder of the strap through the looped
end of the strap as shown.
Important
• Avoid swinging the camera when carrying it.

17
1
Getting Started
Supplying Power to the Camera
The procedures for loading the batteries (alkaline batteries, Lithium battery) are explained
in this section. Electrical power supply by standard AC household current is also ex-
plained in this section.
Inserting Batteries
Insert four AA alkaline batteries to begin using the camera.It is recommended to use the
same type of batteries which are included in the package.
Note: The camera can also be powered by commercially available rechargeable nickel-cadmium
(NiCad) batteries or nickel-metal-hydride (NiMH) batteries.(It is recommended to use a high
capacity type of battery for NiCad batteries.)
RWarning
Observe the following precautions to prevent the batteries from leak-
ing, exploding, igniting fire or breaking.
• Never use batteries that are not specifically recommended for use
with this camera.
• Never dispose of the batteries in a fire; do not short-circuit the ter-
minals; and do not attempt to disassemble, heat, or recharge the
batteries.(Only Nickel Cadmium or nickel-metal-hydride (NiMH) bat-
teries can be recharged.) Doing so may damage the batteries and
cause a fire, injury, or environmental contamination.
• Do not use batteries incorrectly; do not use batteries of a different
type or name; do not use batteries of a different manufacturer; and
do not mix old and new batteries.
• Be sure to maintain the correct polarity (positive [+] and negative
[–] poles) when inserting the batteries.
• Do not solder the batteries. This may damage the batteries and
may cause a fire, injury, or environmental contamination.
• When using rechargeable batteries, do not mix them with other
types of batteries or with batteries in another charged condition.
• Store the batteries in a location that is not accessible to infants or
children in order to prevent the batteries from being swallowed ac-
cidentally. Contact a doctor immediately if the batteries are swal-
lowed accidentally.This may result in severe personal injury.
m
m
o

18
RCaution
Fluid leaking from a battery can cause skin burns. If you touch a
damaged battery, wash your hands with water immediately (do not
use soap).
If fluid leaks from the batteries, wipe off the fluid and replace the
batteries with new batteries.
Rechargeable batteries
• Before using commercially available Nickel Cadmium or nickel-metal-hydride batter-
ies, thoroughly read the safety precautions provided with each product.
Important
• Use only specified AA-type batteries.
• Never use manganese batteries, or any other type of battery that is not specifically recommended.
Use of such batteries may damage the camera or LCD monitor.
• Some batteries may become hot after a long period of use.Remove the batteries after they have
cooled.
qClose the LCD monitor, then press slide
the lever to open the battery compartment.
Note: See “Turning on the Power” on page 2 8 for informa-
tion about the camera power supply.
wInsert the batteries.
Important
• Carefully note the proper battery polarities (positive [+]
poles and negative [-] poles).
eClose the battery compartment lid.
o
