Philips HQ6640 User manual

ENGLISH 4
DEUTSCH 12
FRANÇAIS 21
NEDERLANDS 30
ESPAÑOL 39
ITALIANO 48
PORTUGUÊS 57
TÜRKÇE 66
HQ6646, HQ6645, HQ6640

Important
Read these instructions for use carefully before
using the appliance and save them for future
reference.
◗Only use the mains cord supplied.
◗Do not use a damaged mains cord.
◗If the mains cord is damaged, always have it
replaced by one of the original type in order
to avoid a hazard.
◗The appliance is equipped with an automatic
voltage selector and is suitable for mains
voltages ranging from 100 to 240 volts.
◗Store and use the appliance at a temperature
between 5cC and 35cC.
C◗Keep the appliance and the mains cord dry.
Using the appliance
Shaving
C1Put the appliance plug in the shaver.
2Put the mains plug in the wall socket.
3Switch the shaver on by pushing the on/off
slide to position I.
C4Move the shaving heads quickly over your
skin, making both straight and circular
movements.
Shaving on a dry face gives the best results.
Your skin may need 2 or 3 weeks to get
accustomed to the Philips shaving system.
ENGLISH4

5Switch the shaver off by pushing the on/off
slide to position 0.
C6Put the protection cap on the shaver every
time you have used it, to prevent damage
to the shaving heads.
Trimming
For grooming sideburns and moustache.
C1Open the trimmer by pushing the slide
upwards.
The trimmer can be activated while the motor is
running.
2Close the trimmer ('click').
Cleaning and maintenance
Regular cleaning guarantees better shaving
performance.
C◗For easy and optimal cleaning, the Philips
Shaving Head Cleaner (type HQ100) is
available.Ask your Philips dealer for
information.
The Philips Shaving Head Cleaner may not be
available in all countries. Contact the Customer
Care Centre in your country about the availability
of this accessory.
ENGLISH 5

You can also clean the shaver in the following
way:
Every week: shaving unit and hair chamber
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Clean the top of the appliance first, using
the brush supplied.
C3Press the release button (1) and remove
the shaving unit (2).
C4Clean the inside of the shaving unit and the
hair chamber with the brush.
C5Put the shaving unit back onto the shaver.
ENGLISH6
2
1

Every two months: shaving heads
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Press the release button (1) and remove
the shaving unit (2).
C3Turn the wheel anticlockwise (1) and
remove the retaining frame (2).
C4Remove the cutters and guards and clean
them with the brush supplied.
Do not clean more than one cutter and guard at
a time, since they are all matching sets. If you
accidentally mix up the cutters and guards, it may
take several weeks before optimal shaving
performance is restored.
C5Clean the cutter with the short-bristled
side of the brush.
Brush carefully in the direction of the arrow.
C6Brush the guard.
ENGLISH 7
2
1
1
2

C7Put the shaving heads back into the shaving
unit. Put the retaining frame back into the
shaving unit (1) and turn the wheel
clockwise (2).
8Put the shaving unit back onto the shaver.
For extra thorough cleaning, clean the shaving
heads by putting them in a degreasing liquid (e.g.
alcohol) every six months.To remove the shaving
heads, follow steps 1 to 4 described above. After
cleaning, lubricate the central point on the inside
of the guards with a drop of sewing machine oil
to prevent wear of the shaving heads.
Trimmer
Clean the trimmer every time you have used it.
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Clean the trimmer with the brush
supplied.
C3Lubricate the trimmer teeth with a drop
of sewing machine oil every six months.
ENGLISH8
1
2

Storage
C◗Put the protection cap on the shaver to
prevent damage.
Replacement
Replace the shaving heads every two years for
optimal shaving results. Replace damaged or worn
shaving heads with HQ55 Philips Shaving Heads
only.
1Switch the shaver off, remove the mains
plug from the wall socket and pull the
appliance plug out of the shaver.
C2Press the release button (1) and remove
the shaving unit (2).
C3Turn the wheel anticlockwise (1) and
remove the retaining frame (2).
C4Remove the shaving heads and place new
ones in the shaving unit.
ENGLISH 9
2
1
1
2

C5Put the retaining frame back into the
shaving unit (1) and turn the wheel
clockwise (2).
6Put the shaving unit back onto the shaver.
Environment
C◗Do not throw the appliance away with the
normal household waste at the end of its life,
but hand it in at an official collection point for
recycling. By doing this you will help to
preserve the environment.
Accessories
The following accessories are available:
- HQ55 Philips Shaving Heads.
- HQ100 Philips Shaving Head Cleaner.
- HQ101 Philips Shaving Head Cleaning Fluid.
- HQ110 Philips Shaving Head Cleaning Spray.
Guarantee & service
If you need information or if you have a problem,
please visit the Philips website at www.philips.com
or contact the Philips Customer Care Centre in
your country (you will find its phone number in
the worldwide guarantee leaflet). If there is no
Customer Care Centre in your country, turn to
your local Philips dealer or contact the Service
Department of Philips Domestic Appliances and
Personal Care BV.
ENGLISH10
1
2

Troubleshooting
1Reduced shaving performance
BCause 1: the shaving heads are dirty.
BThe shaver has not been cleaned well enough or
has not been cleaned for a long time.
◗Clean the shaver thoroughly before you
continue shaving. See chapter 'Cleaning and
maintenance'.
BCause 2: long hairs are obstructing the shaving
heads.
◗Clean the cutters and guards with the brush
supplied. See chapter 'Cleaning and
maintenance', section 'Every two months:
shaving heads'.
BCause 3: the shaving heads are damaged or worn.
◗Replace the shaving heads. See chapter
'Replacement'.
2The shaver does not work when the on/off
slide is pushed to position I.
BCause: the shaver is not connected to the mains.
◗Put the mains plug in the wall socket.
ENGLISH 11

Wichtig
Lesen Sie diese Bedienungsanleitung vor dem
ersten Gebrauch des Geräts sorgfältig durch, und
bewahren Sie sie für eine spätereVerwendung
auf.
◗Verwenden Sie ausschließlich das mitgelieferte
Netzkabel.
◗Verwenden Sie auf keinen Fall ein beschädigtes
Netzkabel.
◗Wenn das Netzkabel defekt oder beschädigt
ist, darf es nur durch ein Original-Ersatzkabel
ausgetauscht werden, um Gefährdungen zu
vermeiden.
◗Das Gerät hat eine automatische
Spannungsanpassung und eignet sich für
Netzspannungen von 100 bis 240 Volt.
◗Verwenden Sie das Gerät nur bei
Temperaturen zwischen 5cC und 35cC.
Bewahren Sie es auch in diesem
Temperaturbereich auf.
C◗Halten Sie das Gerät und das Netzkabel stets
trocken.
Das Gerät verwenden
Rasieren
C1Stecken Sie den Gerätestecker in den
Rasierer.
2Verbinden Sie das Netzteil mit einer
Steckdose.
DEUTSCH12
