Philips HS8060/25 User manual

3
1
2
3
45
6
7
8
9
14
13
16
A B
15
12
17
11
10
1

4

HS8060
ENGLISH 6
INDONESIA 26
한국어 48
BAHASA MELAYU 68
ภาษาไทย 90
 106
繁體中文 126
简体中文 144

6
Important
Read this user manual carefully before you use the
appliances and save it for future reference.
Danger
Make sure the adapter does not get wet (your
adapter may differ from the one shown in the
gure).
Warning
The adapter contains a transformer. Do not cut
off the adapter to replace it with another plug, as
this causes a hazardous situation.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Caution
Never immerse the rell & charge station in water
nor rinse it under the tap.
Never immerse the charger in water nor rinse it
under the tap.
Always place and use the rell & charge station
and the charger on a surface that is uid-resistant.
Use, charge and store the appliances at a
temperature between 5°C and 35°C.
Only use the adapter, charger and the rell &
charge station supplied.
Do not use the rell & charge station if the
adapter or the station itself is damaged.
Do not use the shaver or the charger if it is
damaged.
-
-
-
-
-
-
-
-
-
-
-
ENGLISH

If the adapter is damaged, always have it replaced
with one of the original type in order to avoid a
hazard.
Compliance with standards
This shaver complies with the internationally
approved safety regulations and can be safely used
in the bath or shower and cleaned under the tap.
These Philips appliances comply with all standards
regarding electromagnetic elds (EMF). If handled
properly and according to the instructions in this
user manual, the appliances are safe to use based
on scientic evidence available today.
General
The adapter transforms 100-240 volts to a safe
low voltage of less than 24 volts.
Overview (Fig. 1)
AShaver
1 Protection cap
2 Trimmer
3 Shaving unit
4 Shaving conditioner cartridge
5 Shaving conditioner button
6 On/off button
7 Charging lights
BAccessories
8 Cap of the rell & charge station
9 NIVEA FOR MEN shaving conditioner bottle
10 Back panel
11 Trimmer storage recess
12 Socket for small plug
13 Conditioner bottle light
14 ’Filling conditioner cartridge’ light
15 Cleaning brush
-
-
-
-
ENGLISH 7

16 Adapter (your adapter may differ from the one
shown in the gure).
17 Charger
Getting started
1 Remove the tab of the NIVEA FOR MEN
shaving conditioner bottle.
2 Turn the cap of the conditioner bottle
clockwise (‘click’).
The cap moves downwards and the conditioner
nozzle appears.
3 Turnthecapoftherell&chargestation
anticlockwise to remove it.
4 Remove the packaging from the bottle docking
holeintherell&chargestation.
5 Place the conditioner bottle in the docking
hole with the nozzle pointing downwards.
6 Placethecapbackontotherell&charge
stationandturnthecapclockwisetoxit.
7 Putthesmallpluginthesocketoftherell&
charge station and put the adapter in the wall
socket.
,
ENGLISH8

8 Puttheshaverintherell&chargestationand
push it backwards (‘click’).
Note: The shaver is charged and lled with shaving
conditioner automatically.
9 Charge the shaver for 90 minutes.
Note: Charge the shaver before you use it for the rst
time or when the charging light indicates that the
battery is empty (see section ‘Charge indications’).
Note: A fully charged shaver has a shaving time of up
to 40 minutes.
Quick charge
After the shaver has charged for 9 minutes, it
contains enough energy for one shave.
Note: Quick charging is only possible when you have
already charged the shaver for 90 minutes once.
Charging by means of the charger
1 Put the small plug in the charger and put the
adapter in the wall socket.
2 Put the shaver in the charger.
The shaver is being charged.
3 Charge the shaver for 90 minutes.
Note: Charge the shaver before you use it for the rst
time or when the charging light indicates that the
battery is empty (see section ‘Charge indications’).
Note: A fully charged shaver has a shaving time of up
to 40 minutes.
,
ENGLISH 9

Manual rell
You can also rell the shaving conditioner cartridge
without using the rell & charge station:
1 Place the nozzle of the conditioner bottle in
thellingopeningoftheconditionercartridge.
2 Movethebottleupanddownapprox.5times
to pump shaving conditioner into the cartridge
until you see that the cartridge is full.
DonotllthecartridgebeyondtheMAX
indication.
Indications on the shaver
Charging
The charging lights indicate to what level the
battery has been charged. During charging, the
bottom charging light rst ashes red, then ashes
green and nally lights up green continuously. After
this, the other lights rst ash green and then light
up green continuously one after the other.
Remaining battery capacity
The amount of energy left in the battery is
indicated by the number of charging lights that are
on.The remaining battery capacity is visible for a
few seconds when you switch the shaver on or
off.
Battery low
When the battery is low, the bottom light
burns red during shaving and ashes red
when you switch off the shaver.
Battery full
When the battery is fully charged, all charging
lights burn green.
-
-
-
-
ENGLISH10

Indications on the rell & charge station
Conditioner bottle light
Whentheconditionerbottlelightashesred,
there are two possibilities:
There is no conditioner bottle in the rell &
charge station or the bottle has not been placed
properly.
The conditioner bottle is empty.
’Filling conditioner cartridge’ light
The‘llingconditionercartridge’
light signals three different things:
When the conditioner cartridge is being lled, the
green ‘lling conditioner cartridge’ light ashes.
When the shaving conditioner cartridge is full,
the green ‘lling conditioner cartridge’ light is
on continuously.
If the conditioner bottle becomes empty while
the conditioner cartridge is being lled, the green
‘lling conditioner cartridge’ light goes out and the
conditioner bottle lights ashes red.
Using your shaver
Shaving
Note: Your skin may need 2 to 3 weeks to get
accustomed to a new shaving system.
1 Makesurethereissufcientshaving
conditioner in the shaving conditioner
cartridge.
2 Press the on/off button to switch on the shaver.
,
-
-
,
-
-
-
ENGLISH 11

3 Makesuretheshaverissufcientlycharged
(seechapter‘Gettingstarted’,section
‘Indications on the shaver’).
4 Gently move the shaving unit in circles over
your skin and press the shaving conditioner
button until there is enough shaving
conditioner on your skin for a comfortable
shave.
When you release the shaving conditioner button,
the appliance stops dispensing conditioner.
If you briey press the shaving conditioner button,
the appliance automatically applies a certain
amount of conditioner.
Press the shaving conditioner button again to
apply more shaving conditioner during shaving
to ensure that the shaving unit continues to glide
smoothly over your skin.
Note: The shaving conditioner button only works when
the shaver is switched on.
Note: This shaver can be used in a way similar to a
razor blade: you can use the shaver on a wet face.
Unlike a conventional electric shaver, this appliance
has no hair chamber that collects stubble. To prevent
stubble from falling on your clothes, apply sufcient
shaving conditioner while shaving.
5 Thoroughly clean the shaver after every use
(see chapter ‘Cleaning’).
6 Slide the protection cap onto the shaver to
prevent damage.
Tips for optimal gliding and a smooth
shaving result
Gently move the shaving unit in circles over your
skin.
-
-
-
-
ENGLISH12

Do not exert too much pressure on the shaver, as
this may cause skin irritation.
To ensure proper gliding, apply shaving conditioner
regularly.
You can also use the shaver in the bath or shower.
Trimming
Note: Because of the new open design, you hear the
cutting action of the trimmer more clearly than with
other trimmers. This is normal.
1 Remove the shaving unit from the shaver.
2 Pull the trimmer off the trimmer storage
recessontherell&chargestationandput
it on the shaver (‘click’).
3 Press the on/off button to switch on the shaver.
The appliance is now ready for use.
4 Use the trimmer to groom your sideburns
and/or moustache.
5 Thoroughly clean the trimmer after use (see
chapter ‘Cleaning’).
6 Remove the trimmer and put it back into the
trimmer storage recess.
7 Put the shaving unit back onto the shaver
(‘click’).
8 Slide the protection cap onto the shaver to
prevent damage.
-
-
-
,
ENGLISH 13

Cleaning and maintenance
Cleaning
Donotuseabrasives,scourersorliquidssuchas
alcohol,petroloracetonetocleantheappliances.
Shaver/trimmer
Clean the shaver and the trimmer after every use.
Be careful with hot water.Always check if the
waterisnottoohot,topreventyourhandsfrom
getting burnt.
Neverdrytheshavingunitwithatowelortissue,
as this may damage the shaving heads.
Note: The shaver is watertight and can be cleaned
under the tap.
1 Press the on/off button to switch on the shaver.
2 Clean the shaving unit and the trimmer while
the shaver is switched on.
There are two ways to clean the shaver/trimmer:
Rinse the shaving unit/trimmer under a hot tap for
at least 30 seconds.
Immerse the shaving unit/trimmer in hot water for
at least 30 seconds.
3 Switchofftheshaverandshakeoffexcess
water.
4 Slide the protection cap onto the shaver to
prevent damage.
Note: If the shaver doesn’t shave as well as it used
to and you are unable to solve this with the cleaning
methods described in this chapter, consult chapter
-
-
ENGLISH14

‘Frequently Asked Questions’ for an extra-thorough
cleaning method.
Rell & charge station
1 Cleantherell&chargestationwithadamp
cloth.
Pump unit
1 Remove the conditioner bottle and the shaver
fromtherell&chargestation(seechapter
‘Getting started’).
2 Removethepanelonthebackoftherell&
charge station.
3 Pull out the pump unit.
4 Rinse the pump unit under a hot tap.
5 Putthepumpunitbackintotherell&charge
station and reattach the back panel.
6 Put the conditioner bottle and the shaver back
intotherell&chargestation(seechapter
‘Getting started’).
Maintenance
1 Lubricate the trimmer teeth with a drop of
sewingmachineoileverysixmonths.
ENGLISH 15

Storage and transport
Storage
1 Storetheshaverintherell&chargestation.
2 If you are going to travel or if you do not
wanttostoretheshaverintherell&charge
station,puttheprotectioncapontheshaver
and store the shaver in the pouch.
Transport
If you are going to store the shaver for a longer
period or if you are going to travel, it is possible to
lock the shaver.The travel lock prevents the shaver
from being switched on by accident.
Activating the travel lock
1 Make sure the shaver is switched off.
2 Press and hold the shaving conditioner button.
3 Press the on/off button with your other hand.
4 Hold both buttons for a few seconds.Wait until
the shaver produces a brief humming sound
andthetopcharginglightontheshaverashes
a few times.
The travel lock is now activated.
Note: If you accidently press the on/off button rst, the
shaver starts working . If this happens, press the on/off
button again to switch off the shaver.
Note: If you press the on/off button when the travel
lock is activated, the charging light ashes green to
indicate that the shaver is locked.
,
ENGLISH16

Tip: Press the on/off button to check if the travel lock
is activated. If the travel lock is activated, the shaver
does not go on.
Deactivating the travel lock
1 Press and hold the shaving conditioner button.
2 Press the on/off button with your other hand.
3 Hold both buttons for a few seconds.Wait until
the shaver produces a brief humming sound
andthetopcharginglightontheshaverashes
a few times.
The travel lock is now deactivated.
Note: You can also deactivate the travel lock by placing
the shaver back into the rell & charge station or into
the charger.
Travel
If you are going to travel and you don’t want to take
the rell & charge station with you, you can take
the charger with you, to charge the shaver when
necessary.
Replacement
Shaving conditioner cartridge
For hygienic reasons, we advise you to replace the
shaving conditioner cartridge twice a year.You can
order a new shaving conditioner cartridge from
Philips Consumer Care by telephone. To nd its
phone number, visit www.philips.com and click on
‘Philips Consumer Care’.
,
ENGLISH 17

1 Remove the shaving conditioner cartridge from
the shaver.
2 Insert the lug at the top of the new shaving
conditioner cartridge into the slot in the rim of
the shaver (1).Then press the bottom part of
the cartridge with your thumb (2) to attach the
cartridge to the shaver (‘click’).
3 Fill the shaving conditioner cartridge (see
chapter ‘Getting started’).
Shaving unit
Replace the shaving unit every year for optimal
shaving results.
Only replace the shaving unit with an HS85 Philips
Shaving Unit.
1 Pull the old shaving unit off the shaver.
2 Put the new shaving unit on the shaver.
NIVEA FOR MEN shaving conditioner
bottle
Only use NIVEA FOR MEN shaving conditioner
bottles.
ENGLISH18

1 Remove the tab of the NIVEA FOR MEN
shaving conditioner bottle.
2 Turn the cap of the conditioner bottle
clockwise (‘click’).
The cap moves downwards and the conditioner
nozzle appears.
3 Turnthecapoftherell&chargestation
anticlockwise to remove it.
4 Put the conditioner bottle in the bottle
docking hole with the nozzle pointing
downwards.
5 Pushthecapbackontotherell&charge
station(1)andturnitclockwise(2)toxit.
Disposal
Do not throw away the appliances with the
normal household waste at the end of their life,
but hand them in at an ofcial collection point for
recycling. By doing this, you help to preserve the
environment.
The rechargeable shaver battery contains
substances that may pollute the environment.
Always remove the battery before you discard
,
-
-
ENGLISH 19

and hand in the shaver at an ofcial collection
point. Dispose of the battery at an ofcial
collection point for batteries. If you have trouble
removing the battery, you can also take the shaver
to a Philips service centre.The staff of this centre
will remove the battery for you and will dispose of
it in an environmentally safe way.
Disposal of the rechargeable battery
Only remove the rechargeable battery when
you discard the shaver. Make sure the battery is
completely empty when you remove it.
Becareful,thebatterystripsaresharp.
1 Remove the shaving conditioner cartridge from
the shaver.
2 Undo the three screws at the back of the
shaver.
3 Remove the back panel of the housing with a
screwdriver.
4 Remove the rechargeable battery.
Guarantee and service
If you need information or if you have a problem,
please visit the Philips website at www.philips.com
or contact the Philips Customer Care Centre
in your country (you nd its phone number in
the worldwide guarantee leaet). If there is no
ENGLISH20

Customer Care Centre in your country, contact
your local Philips dealer or contact the Service
Department of Philips Domestic appliances and
Personal Care BV.
Guarantee restrictions
The shaving heads (cutters and guards) are not
covered by the terms of the international guarantee
because they are subject to wear.
The conditioner cartridge is a disposable item and
is not covered by the terms of the international
guarantee.
Frequently asked questions
This chapter lists the questions most frequently
asked about the shaver and the rell & charge
station. If you cannot nd the answer to your
question, contact the Customer Care Centre in your
country.
Question Answer
Why doesn’t
the shaving unit
glide smoothly
over my skin?
You may not have applied enough shaving
conditioner. Press the shaving conditioner button
until a sufcient amount of NIVEA FOR MEN
shaving conditioner has been released.This makes
the shaving unit glide smoothly across your skin again.
Why doesn’t
the shaver
shave as well as
it used to?
You may not have cleaned the shaver properly.
Thoroughly clean the shaver (see chapter ‘Cleaning
and maintenance).
Long hairs may be obstructing the shaving heads.
Clean the shaving heads by following the steps of the
extra-thorough cleaning method described below.
ENGLISH 21

Question Answer
The shaving unit may be damaged or worn. Replace
the shaving unit (see chapter ‘Replacement’).
Why
doesn’t the
shaver work
when I press
the on/off
button?
The battery may be empty. Recharge the battery
(see chapter ‘Getting started’).
The travel lock may be activated. Deactivate the
travel lock (see chapter ‘Storage and transport’,
section ‘Transport’).
Dried shaving conditioner may block the shaving
heads in the shaving unit. Clean the shaver
thoroughly before you continue shaving (see chapter
‘Cleaning and maintenance’).
You may not have reassembled the shaving unit
properly after extra-thorough cleaning. When you
reassemble the shaving unit, make sure you turn each
guard anticlockwise until it locks into position.
Why does
little shaving
conditioner
come out of
the holes even
though there
is enough
conditioner in
the cartridge?
One of the conditioner holes may be blocked. Rinse
or soak the shaving unit. If this does not work, pump
shaving conditioner into the shaving conditioner
cartridge until conditioner starts to come out of the
blocked hole. If this does not work either, try the
following method: 1) Switch off the shaver 2) Pull the
shaving unit off the shaver 3) Put your nger on the
hole that is not blocked 4) Switch on the shaver 5)
Press the shaving conditioner button several seconds
until conditioner starts to come out of the blocked
hole again.
ENGLISH22
