Philips Norelco S9721 User manual

S9721
www.philips.com/support/ifu

3
1
2
4
5
6
7
8
9
10
11
12
13
14
15
16
18
17
19
20
21 22
23
24
25
26

empty page before TOC

English 6
Español 39

English
IMPORTANT SAFETY
INSTRUCTIONS
When using an electric product, basic
precautions should always be followed,
including the following:
Read all instructions before using this
product.
DANGER
To reduce the risk of electric shock:
-Do not reach for a corded product that has
fallen into water. Unplug immediately.
-The power plug and the accessories
connected to it are not for immersion or for
use in shower.
-Do not use an extension cord with this
product.
-Always unplug this product from the
electrical outlet immediately after
(re)charging.
-Unplug and remove power cord from the
product before cleaning.
-The batteries used in this product may
present a fire or chemical burn hazard if
mistreated. Do not disassemble, heat above
100°C (212°F) or incinerate.
6English

WARNING
To reduce the risk of burns, fire, electric
shock, or injury to persons:
-Close supervision is required when this
product is used by, on, or near children, or
persons with limited physical, sensory, or
mental capabilities or invalids.
-Use this product for its intended household
use as described in this manual. Do not use
attachments not recommended by Philips
North America LLC.
-Never operate this product if it has a
damaged power cord or charging plug, if it
is not working properly, if it has been
dropped or damaged, or dropped into
water while plugged in. For assistance call
1-800-243-3050.
-Keep the product, cord and charging plug
and any attachments away from heated
surfaces.
-Never drop or insert any object into any
opening.
-Do not use the adapter in or near a power
outlet that contains an electric air freshener
to prevent damage to the adapter.
-Do not charge, clean or plug in product
outdoors or operate where aerosol (spray)
products are being used or where oxygen is
being administered.
7
English

-Always check cutters and combs before
using the product. Do not use the product if
cutters or combs are damaged, as injury
may occur.
-Always attach plug to product first, then to
outlet. Be certain plug is inserted firmly into
shaver up to mark indicated on plug. To
disconnect, turn shaver off then remove
power cord from outlet.
-Keep the power cord dry at all times. Do not
handle with wet hands.
-Never put the product in direct sunlight or
store at a temperature above 140°F (60°C).
-To prevent possible damage to the power
cord, do not wrap power cord around the
product.
-Do not attempt to open the product to
remove or replace the built-in rechargeable
battery.
-Only use the power cord and other
accessories supplied with the product.
SAVE THESE
INSTRUCTIONS
IMPORTANT: The power plug contains a
transformer. Do not cut off the power plug to
replace it with another plug as this will cause a
hazardous condition.
General description (Fig. 1)
1 Click-on cleansing brush attachment
8English

2 Attachment base
3 Click-on precision trimmer attachment
4 Click-on shaving unit
5 On/off button
6 Socket for small plug
7 Exclamation mark
8 Replacement reminder
9 Travel lock symbol
10 Cleaning reminder
11 Charge symbol
12 Battery charge percentage
13 Personal comfort settings bar
14 + and - buttons for personal comfort
settings
15 SmartClean system
16 Cap of SmartClean system
17 On/off button
18 Replacement symbol
19 Rinsing symbol
20Drying symbol
21 Ready symbol
22 Charge symbol
23 Cleaning cartridge for SmartClean system
24 Power plug
25 Small plug
26Pouch
The accessories supplied may vary for
different products. The box shows the
accessories that have been supplied with your
product.
Introduction
Congratulations on your purchase and
welcome to Philips Norelco!
9
English

To fully benefit from the support that Philips
Norelco offers, register your product at
www.norelco.com/register.
The display
Note: Before you use the shaver for the first
time, remove the protective foil from the
display.
Personal comfort settings
The shaver has a feature that allows you to
personalize your settings. Depending on your
personal shaving needs, choose between
three settings. Slow: for an even more skin
friendly shave, Medium: for a standard
thorough shave and Fast: for a high-powered
shave. When you press the button on the left
or right of the display, the segment of the
personal comfort settings bar that lights up
shows the currently selected setting. To select
a lower or higher setting, press the button on
the left or right of the display.
Charging
When the shaver is charging, the battery
charge percentage and the battery symbol
flash white.
The battery charge is indicated by the battery
charge percentage shown on the display.
10 English

Quick charge: When the battery symbol starts
to flash quickly, the shaver contains enough
charge for one shave.
Battery fully charged
When the battery is fully charged, the battery
charge percentage lights up white
continuously.
Note: This product can only be used without
cord. When you press the on/off button during
or after charging, you hear a sound to indicate
that the shaver is still connected to the power
outlet.
Note: When the battery is full, the display
switches off automatically after 30 minutes.
Battery low
When the battery is almost empty, the battery
charge indicator flashes orange and the shaver
beeps.
Remaining battery charge
The remaining battery charge is indicated by
the battery charge percentage shown on the
display.
11
English

Cleaning reminder
Clean the shaver after every shave for optimal
performance. When you turn off the product,
the cleaning reminder flashes to remind you to
clean the product.
Travel lock
You can lock the shaver when you are going to
travel. The travel lock prevents the shaver from
being switched on by accident.
Activating the travel lock
1Press the on/off button for 3 seconds to
enter the travel lock mode.
While you activate the travel lock, the travel
lock symbol lights up continuously. When
the travel lock is activated, the shaver
produces a sound and the travel lock
symbol flashes.
Deactivating the travel lock
1Press the on/off button for 3 seconds.
2The travel lock symbol flashes and then
lights up continuously. The shaver is now
ready for use again.
12 English

Note: You can also deactivate the travel lock
by connecting the shaver to the power outlet.
Replacement reminder
For maximum shaving performance, we advise
you to replace the shaving heads every year.
The shaver is equipped with a replacement
reminder which reminds you to replace the
shaving heads. The shaving unit symbol lights
up white continuously, the arrows flash white
and the shaver beeps to indicate that you
have to replace the shaving heads.
Note: After replacing the shaving heads, you
can reset the replacement reminder by
pressing the on/off button for 7 seconds. If you
do not reset the replacement reminder, the
shaver resets automatically after 9 shaves.
Exclamation mark
Overheating
If the shaver overheats during charging, the
exclamation mark flashes orange. When this
happens, the shaver turns off automatically.
Charging continues once the temperature of
the shaver has decreased to the normal level.
Blocked shaving heads
If the shaving heads are blocked, the
exclamation mark lights up orange
continuously. The replacement reminder and
the cleaning reminder flash white alternately
and you hear a sound. In this case, the motor
13
English

cannot run because the shaving heads are
soiled or damaged.
If the shaving heads are soiled, you have to
clean them. If the shaving heads are damaged,
you have to replace them.
Charging
-Charging, recharging, or using the product
at temperatures below 40°F (4.5°C) or
higher than 95°F (35°C) adversely affects
the lifespan of the battery.
-Do not charge the shaver in a pouch or
travel case.
-The power plug transforms 100-240V AC to
less than 24V DC.
Charge the shaver before you use it for the first
time and when the display indicates that the
battery is almost empty. The battery charge is
indicated by the battery charge percentage
shown on the display.
When you connect the shaver to the power
outlet, you hear a sound.
Charging takes approx. 1 hour. A fully charged
shaver has a shaving time of up to 60 minutes.
Note: You cannot use the shaver while it is
charging.
Charging with the power cord
1Make sure the shaver is turned off.
14 English

1
2
2Put the small plug in the shaver and
connect the power plug to any 100V to
240V AC outlet. Use only the power cord
provided.
The display of the shaver indicates that the
shaver is charging.
3After charging, remove the power plug from
the power outlet and pull the small plug out
of the shaver.
Charging in the SmartClean system (specific types
only)
1Put the small plug in the back of the
SmartClean system.
2Put the power plug in the wall socket.
3Press to open the SmartClean system cap,
to be able to place the shaver in the holder
('click').
4Hold the shaver upside down above the
holder. Make sure the front of the shaver
points towards the SmartClean system
holder.
1
2
3
5Place the shaver in the holder, tilt the
shaver backwards and press down the
SmartClean system cap to connect the
shaver (‘click’).
Note: The battery symbol starts to flash to
indicate that theappliance is charging. When
15
English

the battery is fully charged, the battery symbol
lights up continuously.
Note: An adapter plug may be necessary for
cord usage in some foreign countries. Use an
attachment plug adapter of the proper
configuration for power outlet.
Using the shaver
-Use this shaver for its intended household
use as described in this manual.
-For hygienic reasons, the shaver should
only be used by one person.
-Trimming is easier when the skin and hair
are dry.
Note: This shaver is waterproof. It is suitable
for use in the bath or shower and for cleaning
under the tap. For safety reasons, the shaver
can therefore only be used without charging
cord.
This symbol indicates that the shaver can be
used in the bath or shower.
16 English

Turning the shaver on and off
-To turn on the shaver, press the on/off
button once.
The display lights up for a few seconds.
-To turn off the shaver, press the on/off
button once.
The display lights up for a few seconds and
showsthe remaining battery charge.
Shaving
Put it to the test
-21 Day Trial and Conversion Process. It is a
fact that your skin and beard need time to
adjust to a new grooming system.
-Use your new shaver exclusively for 3 weeks
to fully enjoy the closeness of a Philips
Norelco shave.
-At first you may not get as close a shave as
you expect, or your face may even become
slightly irritated. This is normal since your
beard and skin will need time to adjust.
Invest 3 weeks and you'll soon experience
the full joy of your new shaver.
-Stick with it! If you alternate shaving
methods during the adjustment period, it
may make it more difficult to adapt to the
Philips Norelco shaving system.
-If you are still not convinced after 21 days,
Philips Norelco will refund you the full
purchase price as long as the request is
received within 45 days of purchase.
17
English

Shaving tips
-Selectyour personal comfort settings (see
‘The display’).
-For the best results on skin comfort, pre-
trim your beard if you have not shaved for 3
days or longer.
Dry shaving
1Switch the shaver on.
2Stretch your skin with your free hand so
blades can lift and cut whiskers. Gently
press shaver to skin so the floating heads
can follow the contours of your face.
Note: Do not press too hard. Too much
pressure can pinch the skin into the combs.
3Switch off and clean the shaver after each
use.
The display lights up for a few seconds to
show the battery status.
Wet shaving
For a more comfortable shave, you can also
use this shaver on a wet face with shaving
foam or shaving gel.
1Apply some water to your skin.
18 English

2Apply shaving foam or shaving gel to your
skin.
3Rinse the shaving unit under the tap to
ensure that the shaving unit glides smoothly
over your skin.
4Switch the shaver on.
5Move the shaving heads over your skin in
circular movements to catch all hairs
growing in different directions. Make sure
each shaving head is fully in contact with
the skin. Exert gentle pressure for a close,
comfortable shave.
Note: Do not press too hard, this can cause
skin irritation.
Note: Rinse the shaving unit regularly to
ensure that it continues to glide smoothly
over your skin.
6Dry your face.
7Switch off the shaver and clean it after each
use.
Note: Make sure that you rinse all foam or
shaving gel off the shaver.
19
English

Using click-on attachments
Note: The accessories supplied may vary for
different products. The box shows the
accessories that have been supplied with your
product.
Removing or attaching the click-on attachment
1Make sure the shaver is turned off.
2Pull the attachment straight off the shaver.
Note: Do not twist the attachment while you
pull it off the shaver.
3Insert the lug of the attachment into the slot
in the top of the shaver. Then press down
the attachment to attach it to the shaver
(‘click’).
Using the precision trimmer attachment
You can use the trimmer to groom your beard,
sideburns and moustache.
1Attach the trimmer to the shaver ('click').
2Turn on the shaver.
20 English
